SenNet IoT CO2-TH Sigfox User manual

SenNet CO2-TH Sigfox
www.satel-iberia.com
1
SenNet IoT CO2-TH Sigfox
General description
SenNet IoT CO2-TH Sigfox is a low power device, that take samples of temperature, humidity and CO2 level with
a interval of time setup.
Use sigfox network to connect with your cloud or platform.
These are the reference at depend of power supply type battery or AC power:
Wired & Setup
Reference
Power supply type
CO2-TH Sigfox bat ++
Battery
3.6v@18000mAh (LS26500 x2)
CO2-TH Sigfox AC
AC Power supply
100-265Vac
Basic steps to intall:
1. Set interval to send (by default 15 minutes).
2. Take note ID / PAC to sign the device on Sigfox Cloud.
3. Plug-in pack batteries or AC power supply.
Setup parameters methods:
•Throught donwlink message (see donwlink message seccion) ,
recommend method.
•By cable micro-USB with PC console enter menu to set these
parameters.
Nivel de CO2
400-5.000ppm
(+/-30ppm)
Temperatura
0-50°C
(+/-1°C) *
Humedad
0-100%RH
(+/-5%) *

SenNet CO2-TH Sigfox
www.satel-iberia.com
2
Battery life
This device is desing to very long life. Life of batteries will depend of three variables:
type message , interval to send, number of impulses readed. Adjust interval to send and type of message by
customer requeriment
wall mount (by default)
rail din mount (accesory)
*specify on your order
Battery life estimation
10 minutes sends
2 years
20 minutes sends
5 years
30 minutes sends
7 years
Holding case
IP Grade
IP-60*
Temperature details
Working temperature
-20ºC...+70ºC
Store temperature
-20ºC...+75ºC
Holding
Dimensions
119 x 111 x 53 mm
Type mount
Wall or din rail
Plastic Material
ABS –V0
*If you need an upper grade contact with out support team.

SenNet CO2-TH Sigfox
www.satel-iberia.com
3
Type Message
SenNet IoT Pulse Counter Sigfox is an very low power device capable to measure temperature / humidity and
CO2 level. There is only one type of message 01, and its format to use on parser function is:
A common point in all types of messages is the head (defined with 2 bytes) that includes important information
embedded in the message (type device/type message/errors.. etc). In the next table are defined the mean of
these info-fields.
Field Info
Byte
Byte 1
Byte 2
Type Master Device
01 - Easy Meter
02 –Pulse Counter
03 –TH (Temp/Hum)
04 - CO2-TH
05 - PM
06 –GW Modbus
07 –Not defined
Type Message
type 0 (info)
type 1 →CO2 + Temp + Hum
type 2 →(not defined)
type 3 (not defined)
type 4 (not defined)
..
type 15 (not defined)
Low level Battery
Internal Error CO2 sensor
Downlink error
Not used
Not used
Feedback Error
Bit
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Byte1
Bit 7-6-5
Byte1
Bit 4-3-2-1
Byte1
Bit 0
Byte2
Bit 7-6
Byte2
Bit 5-4-3
Byte2
Bit 2-1-0
Table 1
First message after power on the device is debug message with internal
information about build firmware. This message must be not parser by client
platform, and requeriment a donwlink message for remote settings.
Type 1 : CO2 + Temperature + Humidity
Field
Info
Temperature
Humidity
CO2 Level
Type
data
See Table
1
1 byte temperature Payload
[-10ºC…60ºC] conversion
function
Temperature=Payload*0.2745-10
1 byte humidity
Payload
[0-100%]
Humidity=Payload
2 byte Co2 level
[0-5000ppm]
CO2 level =Payload
Byte
1
2
3
4
5
6
Type 0 : debug message
Field
Info
HW device
Version FW
Revision FW
Not used
Type data
See Table 1
-
Byte
1
2
3
4
5
6-9
Nivel de CO2
400-5.000ppm
(+/-30ppm)
Temperatura
0-50°C
(+/-1°C) *
Humedad
0-100%RH
(+/-5%) *

SenNet CO2-TH Sigfox
www.satel-iberia.com
4
Secuence of messages:
Downlink Message
It’s possible set the device in the cloud without interacting with it locally, defining this type of downlink message
and CT value on the sigfox backend or in your platform. That method is optional but it’s not necessary.
Byte
1
2 - 5
6
7
8
Field
Easy Meter Setup byte
(1byte)
Not used
(4 bytes)
Type uplink
Message
(1 byte)
Interval to
send
(minutes)
Not
Not
used
Value
Bit 7
1 (by default)
0x00 0x00
0x00 0x00
01
[10…59]
0x00
Bit 6
0 (by default)
Bit 5
1/0 enable/disable set Type uplink Messsage
Bit 4
1/0 enable/disable set Interval to send
Bit 3
0 (by default)
Bit 2
0 (by default)
Bit 1
0 (by default)
Bit 0
0 (by default)
Example for downlink message:
90 00 00 00 00 01 0F 00 →With this downlink message setup interval to send to 15minutes.
Power on
Message type 0
ask for Donwlink message for
remote settings
Message
type 1 or 2
Message
type 1 or 2

SenNet CO2-TH Sigfox
www.satel-iberia.com
5
Warranty
Satel Spain guarantees its products against all manufacturing defects for a period of 1 year.
No return of material will be accepted, nor will any equipment be repaired if it is not accompanied by a report (RMA) indicating the defect
observed or the reasons for the return.
The warranty will be void if the equipment has suffered "misuse" or the storage, installation or maintenance instructions in this manual
have not been followed. “Misuse” is defined as any use or storage situation contrary to the National Electrical Code or that exceeds the
limits indicated in this manual.
Satel Spain declines all responsibility for possible damage to the equipment or to other parts of the installations and will not cover possible
penalties derived from a possible breakdown, poor installation or "misuse" of the equipment. Consequently, the guarantee is not applicable
to breakdowns produced in the following cases.
•Due to overvoltage and/or electrical disturbances in the supply.
•By water, if the product does not have the appropriate IP rating.
•For exposing the equipment to extreme temperatures, which exceed the operating or storage temperature limit.
•Due to a modification of the product by the client without prior notice to Satel Spain.
Faced with possible errors in this technical sheet, keep it updated in our website.
