ASPEN LED MIRROR CABINET - SE30816C0 INSTALLATION INSTRUCTIONS
GENERAL
zone
2
radius
zone
2
zone
2
225cm
zone
1
60CM
60CM
60CM
The product must be installed with a
minimum distance of 150mm between
the infrared sensor and an adjacent
countertop or obstrucon to ensure correct
funcon of the sensor(see diagram le)
IMPORTANT
Please read these instrucons carefully before installaon.
Installaon should be carried out by a qualified electrician.
IEE Bathroom Zones Diagram
OUTSIDE ZONES
A1 - 2
Aspen - SE30816C0
Any Queries Call : 0845 0340 780
THIS PRODUCT CONFORMS TO UK SAFETY STANDARDS AND MUST BE INSTALLED IN
ACCORDANCE WITH CURRENT IEE WIRING REGULATIONS AND BUILDING REGULATIONS (PART P).
THIS PRODUCT MUST BE EARTHED, AND SHOULD NOT BE CONNECTED TO AN UNEARTHED CIRCUIT.
IF THERE ARE ONLY TWO WIRES COMING FROM YOUR POWER SUPPLY IT MEANS THAT THIS FITTING
CAN BE WIRED TO AN UNEARTHED CIRCUIT.
ENSURE THAT CONNECTIONS ARE TURNED OFF AT THE CONSUMER UNIT OR FUSE BOARD BEFORE
INSTALLING OR CARRYING OUT ANY MAINTENANCE.
THIS PRODUCT IS FOR IN DOOR USE ONLY.
THIS PRODUCT IS IP44 RATED AND CAN BE INSTALLED IN BATHROOM ZONE 2 (AS DEFINED BY THE IEE
WIRING REGULATIONS) AND BEYOND. SEE BATHROOM DIAGRAM BELOW.
REPLACE FAILED LAMPS IMMEDIATELY. ALLOW THE GLASS, LAMP AND FITTING TO COOL
BEFORE REPLACING THE LAMP.
MIN
150mm
Do NOT strike mirror glass with hard or pointed items. It is
recommended that the product is cleaned with a so, dry,
non abrasive cloth. Do NOT use cleaning agents or abrasive
materials on any type of finished surface. Do NOT allow
moisture to come into contact with the electrical components.
Compliance
This product complies with the following safety standards:
BS EN 60598-1: 2008+A11: 2009, EN60598-2-1: 1989
Wiring
This product is manufactured to class I category and requires
an earth connecon
COLOUR CODING:
L - Live = Brown
- Neutral = Blue
- Earth = Green & Yellow
REPLACEMENT OF LED STRIPS
WARNING - turn off at consumer unit or fuse board before accessing wiring.
When replacing an LED strip please follow the steps illustrated below.
When working at heights, please use a suitable plaorm to work from.
Please note: For new installaons, check for any electrical cables or pipe
work (gas/water) in the vicinity of the intended mounng point before proceeding
with the installaon.
Ensure that the fixing locaon is able to take the weight of the complete fing.
Wear suitable eye protecon when drilling. Be careful when using power tools near water.
1. 2.

ASPEN LED MIRROR CABINET - SE30816C0 INSTALLATION INSTRUCTIONS
A
2 - 2
Installaon procedure
1.Open the carton and make sure all the parts listed below are present
Any Queries Call : 0845 0340 780
Waste Electrical & Electronic Equipment Regulations (WEEE) requires that any of our
products showing this mark (left) must not be disposed of with other household or commercial waste.
Sensio Ltd does not levy any WEEE disposal charges to its customers for affected WEEE related
products. To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate any such product from other waste types and recycle it responsibly at your
local facilities. Check with your Local Authority, Recycling Center or retailer for recycling advice.
DISTANCE ABETWEEN
CENTRE OF BRACKETS
2.Mark a desired height of the mirror and draw a horizontal line on the wall which corresponds with the height of the cabinet
hangers. Drill the required holes and insert the wall plugs. Note: Wall plugs supplied are only suitable for solid stone/brick walls.
Then screw the brackets to the all using the screws provided. Please ensure the screws are fully ght.
3.Make the electrical connecons, make sure to turn off the electrical supply at the mains. Connecon must be made in
accordance with the latest IEE regulaons. This cabinet is manufactured to Class I and requires an earth connecon.
4.Hang the cabinet on the wall bracket. The claws on the cabinet hangers must be securely located on the wall brackets. Using
a spirit level to adjust the angle of the cabinet by turning the screw A with a cross head screwdriver.When the angle is properly
adjusted, ghten the screw B on both hangers. Then secure the base of the cabinet to the wall with provided screw and
over-cap.
5.Close and secure the internal top electrical cover with the small screws removed earlier. And switch on the electrical supply at
the mains to test the funcon of the lamp and the shaver socket.
6.Insert the shelf supports in the desired posions starng with the top shelf. On the double door item, one of the doors should
be removed so the glass shelves can be inserted. Please make sure to ghten the plasc screw at the boom of the shelf
support to prevent the shelves becoming loose. Rubber plugs provided can be used to cover unused shelf holes.
7.If the doors are out of alignment, please first remove the so-close buffer (from boom hinges), then adjust the screws A, B
and C on hinges for 3 direconal adjustment, see below diagram.
A
B
C
A
3x
1x
7x
2x 12x1x 1x 8x
7x
1.
2.
3.
4.
A
Choose desired height
from basin (must be a
minimum of 0.6m)
