CHARGER BASE KIT

OPERATIONAL MANUAL

Read and understand instructions before use.

CONTENTS

FOR YOUR SAFETY �� 3

GAS TRAC® LZ-30 CHARGER BASE KIT (871-00099) .............................................. 3

LZ-30 CHARGER BASE KIT �� 4

DESCRIPTION...................................................................................................... 4

SPECIFICATIONS/RATINGS .................................................................................. 4

LABELS AND MARKINGS ..................................................................................... 4

SETUP................................................................................................................. 5

INDICATOR LIGHT CONFIGURATION.................................................................... 5

BATTERY CHARGING: INSTALLED IN INSTRUMENT................................................. 5

MAINTENANCE AND SERVICE............................................................................. 5

NOTES�� 6

NOTES�� 7

WARRANTY�� 8

3

FOR YOUR SAFETY

GAS TRAC® LZ-30 CHARGER BASE KIT (871-00099)

⚠WARNING: Charging Station shall only be used in a non-hazardous area.

⚠ WARNING: Use only GAS TRAC®LZ-30 CHARGER BASE KIT (871-00099) with the

GAS TRAC®LZ-30 Instrument (834-00000-01AA).

⚠WARNING: Do not use with any non-rechargeable batteries.

⚠WARNING: Charge only in a temperature range of 0° to 40°C (32° to 104°F).

⚠WARNING: To prevent risk of ignition of a flammable atmosphere, battery pack must only

be charged in an area known to be non-hazardous.

⚠WARNING: Charger must be used and stored in a clean, dry area.

⚠ WARNING: This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensor, or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved.

⚠WARNING: Cleaning and user maintenance shall not be made by children without

supervision.

⚠ WARNING: Only use the detachable power supply provided by SENSIT Technologies

(PHIHONG, Model PSAC12R-120).

⚠WARNING: For indoor use only.

⚠WARNING: Children should be supervised to ensure that they do not play with the

appliance.

KEEP FREE OF DUST

INDOOR USE ONLY

DO NOT EXPOSE TO MOISTURE

4

LZ-30 CHARGER BASE KIT

DESCRIPTION

The GAS TRAC®LZ-30 Charging Base is used for recharging the GAS TRAC®LZ-30 (834-00000-01A)

which contains a rechargeable Lithium-Ion battery pack.

SPECIFICATIONS/RATINGS

SIZE: H-2.8 x W-4.4 x D-3.9 in (72.2 x 111.4 x 99.37mm)

ENVIRONMENTAL CONDITIONS: Altitude (<= 2000 meters)

Relative Humidity (<=98% non-condensing)

Pollution Degree (pollution degree 1)

PARAMETER VALUE

Input Voltage 12 VDC

Input Current 1.5 ADC Max

Nominal Output Voltage 4.2 VDC

Maximum Output Voltage 4.2 VDC

Output Current 0.9 ADC Max

Operating Temperature 0-40 °C

LABELS AND MARKINGS

LED Indicator

Serial

45

SETUP

Upon receiving the GAS TRAC®LZ-30 CHARGER BASE KIT (871-00099), remove it from the

packaging with which the unit was shipped.

1. Inspect the Power Supply and supply cord. If the supply cord is damaged, it must be replaced by

a special cord or assembly available from the manufacturer or its service agent.

2. Plug the Power Supply (vehicle or wall) into the appropriate power source.

3. Plug the male connector on the Power Supply into the threaded receptacle on the left side(with

serial label facing you) of the Charging Station

4. Tighten the nut on the male connector of the Power Supply until hand tight.

INDICATOR LIGHT CONFIGURATION

YELLOW: Power connected to Charger Base

RED (SOLID): Charging

RED (BLINKING): Error, Charge suspended (Outside allowable temperature)

GREEN (SOLID): Fully charged

BATTERY CHARGING: INSTALLED IN INSTRUMENT

1. Make sure the YELLOW power light is lit on the front face of the charger base (PN:871-00098).

This indicates power is connected to the charger, and it is ready for charging.

2. Insert GAS TRAC®LZ-30 into the Charger Base, bottom face down. Insert GAS TRAC®LZ-30 into

the Charger Base, bottom face down.

3. Push down until the shrapnel side clips, snap into place.

4. The RED light should be solid on the front face of the charger. This indicates the instrument is

charging.

Once charging is complete, the red light will turn off and the green light will turn on, typically <10 hours.

To remove the Instrument:

1. Hold the charger base down.

2. Pull the instrument up.

MAINTENANCE AND SERVICE

Inspect the device whenever the device is uninstalled, and reinstalled at a new location, or once every 6

months.

If the supply cord is damaged, it must be replaced by a special cord or assembly available from the

manufacturer or its service agent.

To clean the unit, wipe with a damp cloth soaked in water.

If the equipment is used in a manner not specified by the manufacturer, the protection provided by the

equipment may be impaired.

6

NOTES

__________________________________________________________________________________________

67

NOTES

__________________________________________________________________________________________

8

WARRANTY

Your GAS TRAC®LZ-30 Charger Base Kit is warranted to be free from defects in materials and workmanship

for a period of two years after purchase. The circuit board is warranted for 5 years. If within the warranty

period, your instrument should become inoperative from such defects, the unit will be repaired or replaced

at our option.

This warranty covers normal use and does not cover damage which occurs in shipment or failure which

results from alteration, tampering, accident, misuse, abuse, neglect, or improper maintenance. Proof of

purchase may be required before warranty is rendered. Units out of warranty will be repaired for a service

charge. Internal repair or maintenance must be completed by a SENSIT Technologies authorized

technician. Violation will void warranty. Units must be returned postpaid, insured and to the attention of

the Service Dept. for warranty or repair.

This warranty gives you specific legal rights and you may have other rights which vary from state to state.

GAS TRAC®LZ-30 CHARGER BASE KIT Operation Manual (English)

Part Number: 750-00095

Revision: 10/28/2022

851 Transport Drive

Valparaiso, IN 46383-8432

Phone: 219.465.2700

Toll Free: 888.4.SENSIT (473.6748)

Fax: 219.465.2701

Website: www.gasleaksensors.com

MADE IN THE USA

WITH GLOBALLY SOURCED COMPONENTS
