Bretford CUBE Tower User manual

031-11204 Rev. 2 08/2022 1 of 9
User Guide

031-11204 Rev. 2 08/2022 2 of 9
About Your Product
Product Overview
The CUBE TowerTM Mobile Charging Station
The Beacon
AC Outlets
20 Foot Power Cable
Locking Casters
Power Cord Winder
Power Switch

031-11204 Rev. 2 08/2022 3 of 9
About Your Product
Product Overview
The CUBE TowerTM Pre-Wired Mobile Charging Station
The Beacon
USB-C Power Adapters
Power Cord Winder
Locking Casters
Power Switch
20 Foot Power Cable
Power Adapter Access Panel
Cord Holder
Cord Grommet

031-11204 Rev. 2 08/2022 4 of 9
About Your Product
Technical Specifications
CUBE TowerTM
Model CTWR800 CUBE TowerTM Mobile Charging Station, 8 AC Outlets
CTWR800USBC CUBE TowerTM Pre-Wired Mobile Charging Station, 8
USB-C Power Adapters
Outer Dimensions
16
ʺ
x 16.25
ʺ
x 39
ʺ
/ 40.6cm x 41.3cm x 99.1 cm
Outlets CTWR800: 8 AC
CTWR800USBC: 8 USB-C Power Adapters included
Weight
21lbs / 9.5kg
28lbs / 12.7kg
Rating
125V, 12A. 60Hz
Charging CTWR800 supports power adapters up to 180W each, or 1,440W total
CTWR800USBC comes equipped with 65W power adapters
Warranty
For the latest information, please visit bretford.com/warranty.
Certifications
ETL Listed to UL 62368-1

031-11204 Rev. 2 08/2022 5 of 9
Using Your Product
CUBE TowerTM
Getting started
Move your CUBE TowerTM to the desired location in the room. Unwind
the power cable from the product and connect into the wall. Locate the
power switch on the cord winder side and toggle the power switch on
(“RESET"). The Beacon indicator light will turn on and confirm power to
the CUBE TowerTM.
The Beacon
At Bretford, we like to think The Beacon indicator light helps inspire
learning in the classroom. When the unit is plugged in, The Beacon is
turned on and your CUBE TowerTM is ready to use.

031-11204 Rev. 2 08/2022 6 of 9
Using Your Product
CUBE TowerTM
CUBE TowerTM Pre-Wired USB-C Cable
The CUBE TowerTM Pre-Wired USB-C cables extend 5 feet from the unit.
The cable holder at the top is intended to be used to rest the cords when
not in use. The hooks at the bottom can be used to wrap the cords to
help with organization and storage of the unit.

031-11204 Rev. 2 08/2022 7 of 9
Using Your Product
CUBE TowerTM
Power Adapter Replacement (CUBE TowerTM Pre-Wired Only)
The power adapters can be accessed through the side access panel by
removing two screws, with a torx T25 head, at the top and side - right.
See image for location. To remove an adapter, feed the cable from the
outside of the CUBE TowerTM through the grommet. Remove the power
adapter from the holder and remove the plug from the e-unit. To reinstall
a power adapter, place the power adapter in the holder with the plug side
up.Push the plug into the e-unit and route the USB-C cord through the
grommet. Reinstall the access panel with the bottom tabs first and then
secure with the two screws.
Access Panel Screws
Adapter holder
Power Adapter Storage

031-11204 Rev. 2 08/2022 8 of 9
Important Information
Safety Notice
•
Product for indoor use only
•Do not plug the unit in if the switch or power cord has been damaged.
•For safety purposes, make sure all electrical components do not exceed
the maximum load rating of 12 amps.
•Do not sit on, stand on, ride on or place unreasonably heavy objects on
the unit.
•Before moving the product from one room to the next, wrap the power
cable on the winders located on the side.
•Engage locking casters when product is not in transit.
•Product must be plugged into a socket with an earthing connection.

031-11204 Rev. 2 08/2022 9 of 9
Additional Resources
Contact Support
Technical support is available by contacting Bretford Customer Care via
phone, email or the web:
Hours of Operation: M-F, 7:30am - 4:30pm CST
Telephone: [phone]
Email: [email protected]om
Website: www.bretford.com/contact
