Sensoray 314 User manual

1
11
1
SENSORAY CO., INC.
PC/104+ MPEG
Video/Audio Grabber
Model 314 Rev.A
May 8, 2006
 Sensoray 2006
7313 SW Tech Center Dr.
Tigard, OR 97223
Phone 03.684.800 • Fax [phone]
www.sensoray.com

2
22
2
Table of Contents
LIMITED WARRANTY .................................................................................................. 3
SPECIAL HANDLING INSTRUCTIONS ........................................................................... 4
INTRODUCTION ......................................................................................................... 5
Feature Summary .................................................................................................. 5
REFERENCE................................................................................................................
Connectors ............................................................................................................
PC/104+ Bus Connector, CON2. .................................................................... 7
PC/104 Bus Connector AB, CON1. ................................................................. 8
PC/104 Bus Connector CD, CON3. ................................................................. 9
A/V (Audio and Video) in and out Connector, J4............................................. 9
LED..................................................................................................................... 10
Power-OK indicator, D8. ............................................................................. 10
Configuration DIP Switches .................................................................................. 10
A/V routing DIP switch, SW1....................................................................... 10
PCI slot # select and interrupt routing DIP switch, SW2. .............................. 10
Device Driver and SDK ......................................................................................... 11
Windows ................................................................................................... 11
Linux ......................................................................................................... 11
Specifications ...................................................................................................... 12
APPENDIX A: TESTED 314 FEATURES....................................................................... 13
APPENDIX B: PLAYER COMPATIBILITY AND INTEROPERABILITY ............................... 14

3
33
3
Limited warranty
Sensoray Company, Incorporated (Sensoray) warrants the hardware to be free from defects in
material and workmanship and perform to applicable published Sensoray specifications for two
years from the date of shipment to purchaser. Sensoray will, at its option, repair or replace
equipment that proves to be defective during the warranty period. This warranty includes parts
and labor.
The warranty provided herein does not cover equipment subjected to abuse, misuse, accident,
alteration, neglect, or unauthorized repair or installation. Sensoray shall have the right of final
determination as to the existence and cause of defect.
As for items repaired or replaced under warranty, the warranty shall continue in effect for the
remainder of the original warranty period, or for ninety days following date of shipment by
Sensoray of the repaired or replaced part, whichever period is longer.
A Return Material Authorization (RMA) number must be obtained from the factory and clearly
marked on the outside of the package before any equipment will be accepted for warranty work.
Sensoray will pay the shipping costs of returning to the owner parts that are covered by warranty.
A restocking charge of 25% of the product purchase price will be charged for returning a product
to stock.
Sensoray believes that the information in this manual is accurate. The document has been carefully
reviewed for technical accuracy. In the event that technical or typographical errors exist, Sensoray
reserves the right to make changes to subsequent editions of this document without prior notice to
holders of this edition. The reader should consult Sensoray if errors are suspected. In no event
shall Sensoray be liable for any damages arising out of or related to this document or the
information contained in it.
EXCEPT AS SPECIFIED HEREIN, SENSORAY MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, AND SPECIFICALLY DISCLAIMS ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. CUSTOMER’S
RIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE
PART OF SENSORAY SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID
BY THE CUSTOMER. SENSORAY WILL NOT BE LIABLE FOR DAMAGES RESULTING
FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR
CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY THEROF.
Third party brands, names and trademarks are the property of their respective owners.

4
44
4
Special handling instructions
The circuit board contains CMOS circuitry that is sensitive to Electrostatic Discharge (ESD).
Special care should be taken in handling, transporting, and installing circuit board to prevent ESD
damage to the board. In particular:
• Do not remove the circuit board from its protective anti-static bag until you are ready to
install the board into the enclosure.
• Handle the circuit board only at grounded, ESD protected stations.
• Remove power from the equipment before installing or removing the circuit board.

5
55
5
Introduction
Model 314 is a PC/104+ MPEG video and/or audio grabber. It captures video and/or audio from a
standard NTSC/PAL analog video source optional with stereo or monochrome audio source into one
of following compressed MPEG streams: MPEG1, MPEG2, MPEG4, H.2 3, or MJPEG. It also
supports capturing raw frames from NTSC/PAL video source. The capturing frame rate is up to 30
fps for NTSC and 25 fps for PAL.
A single +5V input power supply is required to power the board, through PC/104+ connector.
Feature Summary
 PC/104+-based MPEG video/audio grabber (capturing module)
 Raw frame grabbing or previewing feature support
 Video input: 4 multiplexed input channels ( 2 S-Video or 4 Composite )
 Audio input: 1 pair of stereo or 1 mono
 Resolution (Max): Full-D1:
NTSC: 720 x 480 @ 30 fps or 720 x 240 @ 0 fps
PAL: 720 x 57 @ 25 fps or 720 x 288 @ 50 fps
 Other supported video Resolution:
D1.N: 720 x 480 D1.P: 720 x 57 D.5: 480 x 352
SIF: 352 x 240 2SIF: 704 x 240 4SIF: 704 x 480
VGA: 640 x 480 QVGA: 320 x 240 QQVGA: 160 x 112
CIF: 352 x 288 QCIF: 17 x 144 SQCIF: 128 x 9
4CIF: 704 x 57
 Video encoding formats:
MPEG-4 SP@L3, plus B-frame support, progressive and interlace,
Microsoft, DivX, Sigma Design compatible
MPEG-2 MP@ML, progressive and interlace
MPEG-1
H.2 3
MJPEG (Motion JPEG)
 Bit-rate control: CBR/VBR, 1Kbps to 10 Mbps
 OSD (On-Screen Display): 9 characters, 1 x1 pixel font, multi-window supported.
 Motion detection support
 Signal loss detection support
 1 digital input and 1 digital output: TTL signals
 Driver and SDK for Linux and Windows

Reference
Connectors

7
77
7
PC/104+ Bus Connector, CON2.
Pin Signal Pin Signal Pin Signal Pin Signal
A1 Ground B1 n/c C1 +5 V D1 AD0
A2 VIO* B2 AD2 C2 AD1 D2 +5 V
A3 AD5 B3 Ground C3 AD4 D3 AD3
A4 C/BE0# B4 AD7 C4 Ground D4 AD
A5 Ground B5 AD9 C5 AD8 D5 Ground
A AD11 B VIO* C AD10 D M EN*
A7 AD14 B7 AD13 C7 Ground D7 AD12
A8 n/c B8 C/BE1# C8 AD15 D8 n/c
A9 SERR# B9 Ground C9 SB0* D9 PAR
A10 Ground B10 PERR# C10 n/c D10 SDONE*
A11 STOP# B11 n/c C11 LOCK* D11 Ground
A12 n/c B12 TRDY# C12 Ground D12 DEVSEL#
A13 FRAME# B13 Ground C13 IRDY# D13 n/c
A14 Ground B14 AD1 C14 n/c D14 C/BE2#
A15 AD18 B15 n/c C15 AD17 D15 Ground
A1 AD21 B1 AD20 C1 Ground D1 AD19
A17 n/c B17 AD23 C17 AD22 D17 n/c
A18 IDSEL0 B18 Ground C18 IDSEL1 D18 IDSEL2
A19 AD24 B19 C/BE3# C19 VIO* D19 IDSEL3*
A20 Ground B20 AD2 C20 AD25 D20 Ground
A21 AD29 B21 +5 V C21 AD28 D21 AD27
A22 +5 V B22 AD30 C22 Ground D22 AD31
A23 REQ0# B23 Ground C23 REQ1# D23 VIO*
A24 Ground B24 REQ2# C24 +5 V D24 GNT0#
A25 GNT1# B25 VIO* C25 GNT2# D25 Ground
A2 +5 V B2 CLK0 C2 Ground D2 CLK1
A27 CLK2 B27 +5 V C27 CLK3* D27 Ground
A28 Ground B28 INTD#* C28 +5 V D28 RST#
A29 +12 V B29 INTA# C29 INTB# D29 INTC#
A30 n/c B30 n/c C30 n/c D30 Ground
Note:
* not connected.
n/c not connected.

8
88
8
PC/104 Bus Connector AB, CON1.
Pin Signal Pin Signal
A1 n/c B1 Ground *
A2 SD7 B2 RSTDRV
A3 SD B3 +5 V
A4 SD5 B4 IRQ9
A5 SD4 B5 -5 V
A SD3 B DRQ2
A7 SD2 B7 -12 V
A8 SD1 B8 n/c
A9 SD0 B9 +12 V
A10 IOCHRDY B10 n/c
A11 AEN B11 n/c
A12 SA19 B12 n/c
A13 SA18 B13 IOW#
A14 SA17 B14 IOR#
A15 SA1 B15 DACK3#
A1 SA15 B1 DRQ3
A17 SA14 B17 n/c
A18 SA13 B18 n/c
A19 SA12 B19 REFRESH#
A20 SA11 B20 n/c
A21 SA10 B21 IRQ7
A22 SA9 B22 IRQ
A23 SA8 B23 IRQ5
A24 SA7 B24 IRQ4
A25 SA B25 IRQ3
A2 SA5 B2 DACK2#
A27 SA4 B27 TC
A28 SA3 B28 BALE
A29 SA2 B29 +5 V
A30 SA1 B30 OSC
A31 SA0 B31 Ground *
A32 Ground * B32 Ground *
Note:
* Only ground connected; all other pins are not connected.

9
99
9
PC/104 Bus Connector CD, CON3.
Pin Signal Pin Signal
C0 Ground * D0 Ground *
C1 SBHE# D1 MEMCS1 #
C2 LA23 D2 IOCS1 #
C3 LA22 D3 IRQ10
C4 LA21 D4 IRQ11
C5 LA20 D5 IRQ12
C LA19 D IRQ15
C7 LA18 D7 IRQ14
C8 LA17 D8 n/c
C9 MEMR# D9 n/c
C10 MEMW# D10 DACK5#
C11 SD8 D11 DRQ5
C12 SD9 D12 DACK #
C13 SD10 D13 DRQ
C14 SD11 D14 DACK7#
C15 SD12 D15 DRQ7
C1 SD13 D1 +5 V
C17 SD14 D17 n/c
C18 SD15 D18 Ground *
C19 n/c D19 Ground *
Note:
* Only ground connected; all other pins are not connected
A/V (Audio and Video) in and out Connector, J4.
Pin Signal Pin Signal
1 Digital I/O 1 2 +5V
3 Digital I/O 0 4 Digital ground
5 Audio Ground Audio in - R
7 Audio in – L 8 Audio out – R
9 Audio out – L 10 Audio Ground
11 Composite video out 3 / S-Video 1 - C 12 Video Ground
13 Composite video out 2 (for loopback) 14 Video Ground
15 Composite video out 1 / S-Video 1 - Y 1 Video Ground
17 Composite video in 4 / S-Video 2 - C 18 Video Ground
19 Composite video in 3 / S-Video 1 - C 20 Video Ground
21 Composite video in 2 / S-Video 2 - Y 22 Video Ground
23 Composite video in 1 / S-Video 1 - Y 24 Video Ground

10
1010
10
LED
Power-OK indicator, D8.
The LED D8 is used for indicating on-board Power-OK status.
Configuration DIP Switches
A/V routing DIP switch, SW1.
The DIP switch, SW1, is used for choosing audio input routing and video direct loopback routing.
Refer to the following chart to select the A/V routing that you prefer:
DIP ON (down) OFF (up)
SW1-5 J4-pin (AIN-R) == J1-R, and => both of
Audio-in Right1 and Right2 on PCI A/V decoder
Audio-in Right1 <= J4-pin , and
Audio-in Right2 <= SteroeJack J1-R
SW1-4 J4-pin (AIN-L) == J1-L, and => both of
Audio-in Left1 and Left2 on PCI A/V decoder
Audio-in Left1 <= J4-pin7, and
Audio-in Left2 <= SteroeJack J1-L
SW1-3 Composite video out 1 <= Composite video in 1
or S-Video out 1 – Y <= S-Video in 1 – Y
No direct loopback (v-in1=>v-out1)
or (sv-in1-y => sv-out1-y)
SW1-2 Composite video out 2 <= Composite video in 1
or S-Video out 1 – C <= S-Video in 1 – C
No direct loopback (v-in2=>v-out2)
or (sv-in1-c => sv-out1-c)
SW1-1 Composite video out 3 <= Composite video in 1 No direct loopback (v-in3=>v-out3)
Note: in the chart, == presents connected; <= presents “take from”; => presents “pass to”.
PCI slot # select and interrupt routing DIP switch, SW2.
The DIP switch, SW2, is used for selecting PCI slot number and interrupt routing for the Model
314.
Refer to the following tables to choose a right/preferred setting for Model 314 in a (your) PC/104+
stack:
SW2-2 (SelB) SW2-1 (SelA) PCI Slot #
ON (down) ON (down) 0
ON (down) OFF (up) 1
OFF (up) ON (down) 2
OFF (up) OFF (up) 3

11
1111
11
SW2- SW2-5 SW2-4 SW2-3 Interrupt line used
ON (down) OFF (up) OFF (up) OFF (up) INTA#
OFF (up) ON (down) OFF (up) OFF (up) INTB#
OFF (up) OFF (up) ON (down) OFF (up) INTC#
OFF (up) OFF (up) OFF (up) ON (down) INTD#
All other combinations Not valid
Device Driver and SDK
Device driver and SDK including demo application program are available for both Windows and
Linux.
Windows
Sensoray Co. provides 314 WDM driver and DirectX filter for Windows platform. All are packaged in
S314-Win-SDK (coming soon).
Linux
Linux SDK package, s314-lnx-sdk, provides device drive, A/V capturing & streaming service library,
and A/V capturing & streaming over-IP demos, for Linux platform. Currently, kernel version 2.4.23
and/or above are supported.
To demonstrate the application, two server demos are enclosed in Linux SDK, s314-lnx-sdk:
The server cap-server is mainly used for demonstrating how to capture video and/or audio streams
from 314 and save them into files (in a variety of supported formats including MPEG1, MPEG2,
MPEG4 (.avi or .divx), H.2 3, MJPEG (.avi), and even VOB, SVCD/VCD for A/V, and WAV/MP2 for
audio only).
The server str-server is used for demonstrating how to stream the live A/V over IP. Also, a variety
of supported formats listed above is supported.

12
1212
12
Specifications
Dimension 9 mm x 105mm x 23mm
Weight 78 g
Power +5V, 500mA
Bus PC/104+
Video inputs 4 multiplexed input channels: 2 S-Video or 4 Composite, 75 Ohms
Video formats NTSC and PAL
Video Encoding formats MPEG1, MPEG2 (MP@ML), MPEG4 (SP@L3 + B-frame support),
H.2 3, and MJPEG (Motion JPEG)
Resolution Up to Full-D1:
NTSC: 720x480 PAL: 720x57
Supported:
D1.N: 720x480 D1.P: 720x57 D.5: 480x352
SIF: 352x240 2SIF: 704x240 4SIF: 704x480
VGA: 640x480 QVGA: 320x240 QQVGA: 160x112
CIF: 352x288 QCIF: 17 x144 SQCIF: 128x9
4CIF: 704x57
Capture rate Up to: 30 frames/sec for NTSC/RS-170/CCIR
25 frames/sec for PAL
Bit-rate CBR/VBR, 1 Kbps to 10 Mbps
OSD ( On-Screen Display ) 9 characters, 1 x1 pixel font, multi-window supported
Video outputs 3 channels (only for direct loopbak monitoring and testing)
Audio input & output Stereo or monochrome line in/out from/to connector or optional Jacks
(output only for loopback testing).
Signal level: +/- 1.0 Volt
Digital I/O 1 input + 1 output, TTL signals
OS Platform Linux and Windows
Temperature 0 – 70 C

13
1313
13
Appendix A: Tested 314 Features

14
1414
14
Appendix B: Player Compatibility and Interoperability
