Sentryus ECO Series User manual

Copyright © 2012. All Rights Reserved. I-356_I-351_I-357_I-352
www.sentryus.com R201210-V03
EIVD18-87036B 3.6mm Lens, Black Casing
EIVD18-87036 3.6mm Lens, White Casing
EIVD18-87060B 6.0mm Lens, Black Casing
EIVD18-87060 6.0mm Lens, White Casing
700TVL Weather Proof IR Dome Camera
USER MANUAL
FEATURES
1/3” Sony Super HAD CCD II
Sony Effio-E DSP
700 TV Lines
3.6mm or 6.0mm Lens
18 IR LED; IR distance 50ft / 15m
Various Angle LED Combination - Uniform IR light distribution for optimum viewing
angle
2DNR
Photodiode Design for accurate IR LED trigger activation
Double Glass: Effectively reducing the internal reflection
Aluminum design for better heat dissipation
12V DC
IP66 Rating

2
Disposal of Old Electrical & Electronic Equipment (Applicable in the European
Union and other European countries with separate collection systems).
This symbol on the product or on its packaging indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or the shop where you
purchased the product.
CAUTION
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may damage the pick-up
device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could damage the camera.
3. Requires a proper operating environment
This camera is designed for indoor use. The allowable temperature range for operation of this
camera is between 14°F ~ 122°F / -10C ~ 50C.
4. Clean the front face or lens
It is recommended that the surface be cleaned every 3~6 months. Cleaning should be done by
using a chamois, a very fine soft cloth, lens tissue, or cotton tipped applicator and ethanol to
carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera must meet the
specifications). Camera must be connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch dangerous voltage points of
short out parts that could result in a fire or electric shock. Never spill any kind of liquid on the
video product.
Please read the Manual before attempting to use this product.
Specifications and appearance are subject to change without notice.

3
7. Servicing
Do not attempt to service this video product by yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all service to qualified servicing
personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to qualified servicing personnel
under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet has been damaged.
e. When the video product exhibits a distinct change in performance.
LIMITED WARRANTY
This product is covered under warranty for one (1) year from the date of purchase. The warranty
will automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when
and where the product was purchased. We have no other way to verify the purchase record
without the serial number on the camera sticker; therefore, it should not be removed.
2. Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the
warranty will be voided immediately. It is the customer’s responsibility to keep the camera in
good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered with. Cutting or modifying of the
cables will result in termination of the warranty.
PACKAGE CONTENTS
A. One (1) Vandal Proof IR Dome Camera with power/video cable
B. Four (4) Mounting Screws
C. Four (4) Wall Anchors
D. One (1) User Manual
* For any returns, please include all components listed above with original packaging in Resalable
Condition. Absolutely No Returns will be accepted if any component is missing/damaged.
A. B. C. D.

4
DIMENSIONS
SPECIFICATION
Model (NTSC)
EIVD18-87036B
EIVD18-87036
EIVD18-87060B
EIVD18-87060
Model (PAL)
EIVD18-87036BP
EIVD18-87036P
EIVD18-87060BP
EIVD18-87060P
Casing Color
Black
White
Black
White
Sensor
1/3” Sony Super HAD CCD II
DSP
Sony Effio-E
Total Pixels
NTSC: 1028(H) x 508(V) / PAL: 1028(H) x 596(V)
Effective Pixels
NTSC: 976(H) x 494(V) / PAL: 976(H) x 582(V)
Resolution
700 TV lines
Synchronizing
System
Internal
Scanning System
2:1 Interlace
S/N Ratio
More than 48 dB(AGC OFF)
Electronic Shutter
Auto/1/60 (1/50) ~1/100,000 sec.
Min. Illumination
0.1 Lux / F2.0 (50IRE)
Video Output
1.0 Vp-p / 75 ohm composite
IR LED
18pcs IR
IR Distance
50ft / 15m
IR Trigger
7 Lux ± 3 Lux IR ON / OFF
Auto White Balance
1800°K~10500°K
Lens Type
3.6mm Lens
6.0mm Lens
Power Source
12V DC ± 10% / 1A
Power Consumption
2.88W
Current
240mA (Max)
IP Rating
IP66 weather proof
Operating
Temperature
14°F ~ 122°F / -10°C ~ 50°
Storage Temperature
-4°F ~ 158°F / -20°C ~ 70°C
Dimension
2.75(H) x 3.70(Dia) inches / 70(H) x 94(Dia) mm
Weight
0.66 lbs / 0.32 kg
*Specifications are subject to change without notice
MADE IN TAIWAN
Unit: mm
