Sentryus T7PTZ-V23 User manual

HD-TVI Speed Dome
Installation Manual
UD.6L0201A1711A02

Installation Manual of HD-TVI Speed Dome
i
Thank you for purchasing our product. If there is any question or request, please do not hesitate to
contact the dealer.
This manual is applicable to HD-TVI Speed Domes.
This manual may contain several technically inaccurate points or printing errors, and the content is
subject to change without notice. The updates will be added into the new version of this manual.
We will readily improve or update the products or procedures described in the manual.
0303011050119

Installation Manual of HD-TVI Speed Dome
ii
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information, see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For
more information, see: www.recyclethis.info.

Installation Manual of HD-TVI Speed Dome
iii
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger or
property loss. The precaution measure is divided into Warnings and Cautions:
Warnings: Neglecting any of the warnings may cause serious injury or death.
Cautions: Neglecting any of the cautions may cause injury or equipment damage.
Warnings:
Follow these safeguards to prevent
serious injury or death.
Cautions:
Follow these precautions to
prevent potential injury or
material damage.
Warnings
In the use of the product, you must be strict compliance with the electrical safety regulations of
the nation and region.
Please use the power adapter, which is provided by normal company. Refer to the specification
manual for the standard of power adapter and the power consumption cannot be less than the
required value.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or fire hazard.
Please make sure that the plug is firmly connected on the power socket.
When the product is installed on wall or ceiling, the device shall be firmly fixed.
If smoke, odors or noise rise from the device, turn off the power at once and unplug the power
cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the nearest service center.
Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cautions
Do not drop the dome or subject it to physical shock, and do not expose it to high
electromagnetism radiation. Avoid the equipment installation on vibrations surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise fire or
electrical shock will occur. For operating temperature, please refer to the specification manual
for details.
The dome cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low ventilation or heat source such as heater or
radiator is forbidden (ignorance can cause fire danger).
Do not aim the camera at the sun or extra bright places. A blooming or smear may occur

Installation Manual of HD-TVI Speed Dome
iv
otherwise (which is not a malfunction however), and affecting the endurance of sensor at the
same time.
Please use the provided glove when open up the dome cover, avoid direct contact with the
dome cover, because the acidic sweat of the fingers may erode the surface coating of the dome
cover.
Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, do not
use alkaline detergents.

Installation Manual of HD-TVI Speed Dome
v
Table of Contents
Chapter 1 Preparation................................................................................................................................................ 1
Chapter 2 Installation................................................................................................................................................. 2
2.1 Cable Descriptions .................................................................................................................................................. 2
2.2 DIP Switch Settings ................................................................................................................................................. 4
2.2.1 5-inch Speed Dome Settings ............................................................................................................................ 4
2.2.2 5-inch IR Speed Dome Settings ........................................................................................................................ 5
2.2.3 7-inch IR Speed Dome Settings ........................................................................................................................ 8
2.2.4 Mini Speed Dome Settings ............................................................................................................................. 10
2.3 Wiring and Installation ......................................................................................................................................... 12
2.3.1 Wiring ............................................................................................................................................................ 12
2.3.2 Installing the Bracket...................................................................................................................................... 13
2.3.3 Setting the DIP Switch.................................................................................................................................... 14
2.3.4 Installing the Speed Dome ............................................................................................................................. 14
Chapter 3 In-door Mounting Applications .................................................................................................................16
3.1 5-inch Speed Dome In-ceiling Mounting Applications.......................................................................................... 16
3.2 5-inch Speed Dome Ceiling Mounting Applications.............................................................................................. 18
3.2.1 Removing the Mounting Bracket ................................................................................................................... 18
3.2.2 Wiring ............................................................................................................................................................ 20
3.2.3 Ceiling Mounting............................................................................................................................................ 20
3.3 Mini Speed Dome In-ceiling Mounting Applications ............................................................................................ 22
3.3.1 Mini Analog Speed Dome In-ceiling Mounting .............................................................................................. 22
3.3.2 Mini IR Speed Dome In-ceiling Mounting ...................................................................................................... 24
3.4 Mini Speed Dome Ceiling Mounting Applications ................................................................................................ 26
3.4.1 Wiring ............................................................................................................................................................ 26
3.4.2 Ceiling Mounting............................................................................................................................................ 26
Appendix .................................................................................................................................................................29
Appendix 1 Lightning & Surge Protection....................................................................................................................... 29
Appendix 2 RS485 Bus Connection................................................................................................................................. 30
Appendix 3 24VAC Wire Gauge & Transmission Distance .............................................................................................. 33
Appendix 4 Wire Gauge Standards................................................................................................................................. 34

Installation Manual of HD-TVI Speed Dome
1
Chapter 1 Preparation
Basic Requirement
All the electronic operation should be strictly compliance with the electrical safety
regulations, fire prevention regulations and other related regulations in your local region.
Check the package contents and make sure that the device in the package is in good
condition and all the assembly parts are included.
Checking Installing Environment
Be sure that there is enough space to install the speed dome and accessories.
Make sure that the wall is strong enough to withstand at least 8 times the weight of the
dome and the bracket.
Preparing Cables
Choose the video cable according to the transmission distance, the minimum requirement for
the coaxial video cable are shown as follows:
75Ω impedance;
100% copper core conducting wire;
95% weaving copper shield;
RS485 communication cable, please refer to Appendix 2.
24V AC power cable, please refer to Appendix 3
Preparing Tools
Before installation, please prepare the tools needed, such as the expansion screws, electric
hammer, electric drill, wrench, screwdriver, electroprobe and network cable.
Original Packaging
When you unpack the dome, please keep the original package properly, in case of returning or
repairing the camera, you can pack the dome with the package.
The user should be responsible for any damage caused when transporting with unoriginal
package.

Installation Manual of HD-TVI Speed Dome
2
Chapter 2 Installation
Before you start:
Check the package contents and make sure that the device in the package is in good condition and
all the assembly parts are included.
Confirm the
wiring is right.
Start
Installation
Preparation
Wiring
Installing Bracket
Setting DIP Switch
Installing Speed Dome
& Connecting Cables
Power-on &
Self-test
End
Succeeded
Failed
No
Yes
Figure 2-1 Installation Flow Diagram
2.1 Cable Descriptions
Please turn the power off before connect the cables.
The cable interfaces of HD-TVI speed dome are shown in Figure 2-2. The cables of RS-485, power
supply, etc. are distinguished by different colors. Please refer to the labels attached on the cables for
identification.

Installation Manual of HD-TVI Speed Dome
3
RED AC24V
YELLOW/GREEN GND
BLACK AC24V
①
YELLOW R485-
ORANGE R485+
②
Video Output
Yellow&Green
Yellow
Orange
Black
Red
①
②
Figure 2-2 Cables of 7-inch IR Speed Dome
Name
Description
AC24V
Power supply
RS485+/-
485 control
VIDEO
Coaxial and analog video output
RED AC24V
YELLOW/GREEN
BLACK AC24V
VIDEO VIDEO
②
①
YELLOW R485-
ORANGE R485+
②
RED AC24V
YELLOW/GREEN GND
BLACK AC24V
①
AC24V
CVBS Video Output
HD-TVI Video Output
RS485
Alarm
Figure 2-3 Cables of Other Speed Domes
Name
Description
AC24V
Power supply
RS485+/-
485 control
CVBS VIDEO
SD analog video output
HD-TVI VIDEO
HD-TVI and coaxial video output
ALARM
2-ch alarm inputs and 1-ch alarm output

Installation Manual of HD-TVI Speed Dome
4
2.2 DIP Switch Settings
2.2.1 5-inch Speed Dome Settings
The DIP switch is used for setting the address and baudrate for the speed dome, with value ON=1
and OFF=0.
The SW1 switches from the first to the eighth are used to set the address. The SW2 switches are
used to set the baudrate.
The default dome address is 0. The default baudrate is 2400.
The speed dome is self-adaptive to the Pelco-P, Pelco-D and Private-Code. You do not have to
set the RS-485 control protocol by the DIP switch.
123456781
2
DIP Switch
Figure 2-4 DIP Switch Settings for 5-inch Outdoor Speed Dome
1 2 3 4 5 6 7
8
1 2
DIP Switch
Figure 2-5 DIP Switch Settings for 5-inch Indoor Speed Dome
Figure 2-6 Enlarged View of DIP Switch

Installation Manual of HD-TVI Speed Dome
5
Address Settings
The SW1-switches from 1 to 8 are used for setting the address of speed dome. You can refer to Table
2-1 for details of setting the speed dome address to a specific number.
Table 2-1 Set the Dome Address between 0 and 255
Switch No.
Dome Address
1
2
3
4
5
6
7
8
0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
...
...
...
...
...
...
...
...
...
255
ON
ON
ON
ON
ON
ON
ON
ON
Baudrate Settings
The number 1 and 2 SW2-switches are used for setting the baudrate of the speed dome. The
baudrate can be 2400bps, 4800bps, 9600bps and 19200bps. The baudrate will be set as 2400bps by
default if it is out of this range. Refer to the following table:
Table 2-2 Set the Baudrate of the Dome
Switch No.
Baudrate
1
2
2400
OFF
OFF
4800
ON
OFF
9600
OFF
ON
19200
ON
ON
2.2.2 5-inch IR Speed Dome Settings
The DIP switch is for setting the speed dome address, baudrate, protocol, etc., with value ON=1 and
OFF=0. The switch label is on the back of the SWITCH cover as shown in Figure 2-7.

Installation Manual of HD-TVI Speed Dome
6
DIP Switch
Screws
Switch Cover
Figure 2-7 Position of DIP Switch for 5-inch IR Speed Dome
Setting DIP Switch
1 75 6432 8 9 10
ON DIP
1 2
ON
Figure 2-8 Enlarged View of DIP Switch
For some certain models, the two individual DIP switches at the left side of the Figure 2-8 are
supported for turning on/off the terminator; while other models are not supported.
The default dome address is 0; the default baudrate is 2400; and the default value of the 120Ω
terminator is OFF.
Table 2-3 Switch Functions
Switch
Function
1 to 5
Set the address for the speed dome
6, 7
Set the baudrate for the speed dome
8, 9
Set the protocol for the speed dome
10
Reserved
The DIP switch is designed according to binary system. When the switch is ON, it stands for the
number 1. When the switch is OFF, it stands for the number 0.
Example:
The switches from No. 1 to 5 are used to set the speed dome address. No. 1 is the lowest digit and
No. 5 is the highest. Turning on all these 5 switches stands for the binary number 11111. Converting
the 11111 to a decimal number is 31. So the speed dome address will be 31.
Address List

Installation Manual of HD-TVI Speed Dome
7
For convenient settings, refer to the following list to set the address for the speed domes.
Table 2-4 Dome Address
Switch
Dome Address
1
2
3
4
5
0
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
5
ON
OFF
ON
OFF
OFF
6
OFF
ON
ON
OFF
OFF
7
ON
ON
ON
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
9
ON
OFF
OFF
ON
OFF
10
OFF
ON
OFF
ON
OFF
11
ON
ON
OFF
ON
OFF
12
OFF
OFF
ON
ON
OFF
13
ON
OFF
ON
ON
OFF
14
OFF
ON
ON
ON
OFF
15
ON
ON
ON
ON
OFF
16
OFF
OFF
OFF
OFF
ON
17
ON
OFF
OFF
OFF
ON
18
OFF
ON
OFF
OFF
ON
19
ON
ON
OFF
OFF
ON
20
OFF
OFF
ON
OFF
ON
21
ON
OFF
ON
OFF
ON
22
OFF
ON
ON
OFF
ON
23
ON
ON
ON
OFF
ON
24
OFF
OFF
OFF
ON
ON
25
ON
OFF
OFF
ON
ON
26
OFF
ON
OFF
ON
ON
27
ON
ON
OFF
ON
ON
28
OFF
OFF
ON
ON
ON
29
ON
OFF
ON
ON
ON
30
OFF
ON
ON
ON
ON
31
ON
ON
ON
ON
ON
Baudrate List
For convenient settings, refer to the following list to set the baudrate for the speed dome. The
baudrate will be set as 2400bps by default if it is out of this range.

Installation Manual of HD-TVI Speed Dome
8
Table 2-5 Baudrate
Switch
Baudrate
6
7
2400
OFF
OFF
4800
ON
OFF
9600
OFF
ON
19200
ON
ON
Protocol List
For convenient settings, refer to the following list to set the protocol for the speed dome.
Table 2-6 Protocol
Protocol
8
9
Self-adaptive
OFF
OFF
Pelco_D
OFF
ON
Pelco_P
ON
OFF
AD Manchester
ON
ON
The speed dome is self-adaptive to private protocol when the No.8 and 9 switches are both OFF.
2.2.3 7-inch IR Speed Dome Settings
Two DIP switches SW1 and SW2 are for setting the speed dome address, baudrate, protocol, etc.,
with value ON=1 and OFF=0. The switch label is on the back of the SWITCH cover as shown in Figure
2-9.
Each number of the switch represents a DIP value, ranging from 1 to 8 for the lowest to highest.
SW1 SW2
Figure 2-9 Label of DIP Switch for 7-inch IR Speed Dome
ON
12345678
SW2
ON
12345678
SW1

Installation Manual of HD-TVI Speed Dome
9
Figure 2-10 Enlarged View of DIP Switch
The default dome address is 0; the default baudrate is 2400; and the default value of the 120Ω
terminator is OFF.
Address Settings
The SW1 switch is used for setting the address of speed dome. You can refer to Table 2-7 for details
of setting the speed dome address to a specific number.
Table 2-7 Set the Dome Address
Dome
Address
1
2
3
4
5
6
7
8
0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
...
...
...
...
...
...
...
...
...
255
ON
ON
ON
ON
ON
ON
ON
ON
Baudrate Settings
The No. 1, 2 and 3 of SW2 switch are for setting the baudrate of the speed dome, standing for
2400bps, 4800bps and 9600bps respectively. The baudrate will be set as 2400bps by default if it is
out of this range. Refer to the following table:
Table 2-8 Set the Baudrate of the Dome
DIP Switch SW2-Baudrate Settings
Baudrate
1
2
3
2400
ON
OFF
OFF
4800
OFF
ON
OFF
9600
ON
ON
OFF
19200
OFF
OFF
ON
Protocol Settings
The speed dome is self-adaptive to PELCO-D, PELCO-P and private protocol which cannot set by the
DIP switches.
Communication Mode Settings
The No. 7 of SW2 switch is for setting the RS485 communication mode of the dome to simplex or
half-duplex.

Installation Manual of HD-TVI Speed Dome
10
Table 2-9 Set Communication Mode of the Dome
DIP Switch SW2-Simplex/Half-duplex Settings
Description
7
Simplex
OFF
Half-duplex
ON
Terminal Resistor Settings
The No. 8 of SW2 switch is used for turning on/off the 120Ωterminal resistor.
Table 2-10 Set Terminal Resistor
Switch No.
Description
8
Turn on the resistor
OFF
Turn off the resistor
ON
The o-ring in the groove of the switch cover is for waterproof.
2.2.4 Mini Speed Dome Settings
DIP Switch Location of Mini IR Speed Dome
Steps:
1. Remove the switch cover as shown in Figure 2-11(left).
2. Set the address and baudrate with DIP switch.
3. Install the switch cover back to the speed dome.
DIP Switch
Switch Cover
Figure 2-11 DIP Switch of Mini IR Speed Dome
DIP Switch Location of Mini Analog Speed Dome

Installation Manual of HD-TVI Speed Dome
11
DIP Switch
Figure 2-12 DIP Switch of Mini Analog Speed Dome
Setting DIP Switch
1 75 6432 8 9 10
ON DIP
1 2
ON
Figure 2-13 Enlarged View of DIP Switch
For some certain models, the two individual DIP switches at the left side of the Figure 2-8 are
supported for turning on/off the terminator; while other models are not supported.
The default dome address is 0; the default baudrate is 2400; and the default value of the 120Ω
terminator is OFF.
Table 2-11 Switch Functions
Switch No.
Function
1 to 5
Set the address for the speed dome
6, 7
Set the baudrate for the speed dome
8, 9
Set the protocol for the speed dome
10
Reserved
The DIP switch is designed according to binary system. When the switch is ON, it stands for the
number 1. When the switch is OFF, it stands for the number 0.
Example:
The switches from No. 1 to 5 are used to set the speed dome address. No. 1 is the lowest digit and
No. 5 is the highest. Turning on all these 5 switches stands for the binary number 11111. Converting
the 11111 to a decimal number is 31. So the speed dome address will be 31.
Address List
For convenient settings, refer to the following list to set the address for the speed domes.

Installation Manual of HD-TVI Speed Dome
12
Table 2-12 Dome Address
Switch No.
Dome Address
1
2
3
4
5
0
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
…
…
…
…
…
…
31
ON
ON
ON
ON
ON
Baudrate List
For convenient settings, refer to the following list to set the baudrate for the speed dome. The
baudrate will be set as 2400bps by default if it is out of this range.
Table 2-13 Baudrate
Switch No.
Baudrate
6
7
2400
OFF
OFF
4800
ON
OFF
9600
OFF
ON
19200
ON
ON
Protocol List
For convenient settings, refer to the following list to set the protocol for the speed dome.
Table 2-14 Protocol
Switch No.
Protocol
8
9
Self-adaptive
OFF
OFF
Pelco_P
ON
OFF
The speed dome is self-adaptive to private protocol when the No.8 and 9 switches are both OFF.
2.3 Wiring and Installation
There are several ways to install the speed dome. The wall mounting is taken as an example below.
2.3.1 Wiring
The survey of the actual installation environment and planning the wiring is highly recommended
before the accurate deployment of the wire is implemented in order to provide a safe and steady

Installation Manual of HD-TVI Speed Dome
13
power supply and a reasonable wiring route.
Get familiar with the installation environment before deploying the wire, including the wiring
distance, surrounding, and electromagnetic interference and so on.
Please choose the cable with nominal voltage higher than the actual voltage, to ensure a
normal running in case of unsteady voltage.
To protect the power cable and the signal transmitting cable from human tampering, you
should pay attention to the protection and reinforcement of the cables.
When deploying the wire, please do not tighten the wire or make the wire loose.
The wiring of the speed dome should be performed by professionals.
2.3.2 Installing the Bracket
Before you start:
Wall mounting is applicable to the indoor/outdoor solid wall construction. The followings are the
mandatory precondition for wall mounting:
The wall must be thick enough to install the expansion screws.
Please make sure that the wall is strong enough to withstand more than 8 times the weight of
the dome and the bracket.
Steps:
1. Check whether the type of the bracket and the number of accessories are right, as shown in the
figure below.
Figure 2-14 Wall Mounting Bracket, Nuts and Flat Washers
2. Drill 4 screw holes in the wall according to the holes of the bracket, and then insert M8
expansion screws (not supplied) into the mounting holes.
Figure 2-15 Drill Mounting Holes
3. Attach the bracket to the wall by aligning the 4 screw holes of the bracket with expansion
screws on the wall.
4. Secure the bracket with 4 hex nuts and washers.

Installation Manual of HD-TVI Speed Dome
14
Figure 2-16 Secure the Bracket
5. Install the speed dome to the bracket. Please refer to Section 2.3.4 Installing the Speed Dome for
installation details.
Follow the same instructions described above for the short-arm wall mounting. For outdoor
applications, please adopt the water-proof measures. The short-arm wall bracket is not
recommended for outdoor applications.
2.3.3 Setting the DIP Switch
Set the DIP Set the address and baudrate for the analog speed dome. The default value of DIP
switch is shown below:
Address: 0
Baudrate:2400
Terminal Resistor: OFF
Please refer to the Section 2.2 DIP Switch Settings for DIP switch settings.
2.3.4 Installing the Speed Dome
The sketched of installing the speed dome are for reference only.
Steps:
1. Hang the safety rope to the speed dome and then hook to the bracket as shown in Figure 2-17.
