Sercomm RC8111 User manual

Wireless Network HD
Camera
User’s Guide

Table of Contents
CHAPTER 1 INTRODUCTION..............................................................................................1
Overview ............................................................................................................................1
Physical Details - Wireless Network HD Camera...........................................................4
Package Contents ..............................................................................................................6
CHAPTER 2 BASIC SETUP ...................................................................................................7
System Requirements........................................................................................................7
Installation - Wireless Network HD Camera..................................................................7
CHAPTER 3 VIEWING LIVE VIDEO..................................................................................9
Overview ............................................................................................................................9
Requirements.....................................................................................................................9
Connecting to a Camera on your LAN............................................................................9
Connecting to a Camera via the Internet ......................................................................11
Viewing Live Video .........................................................................................................13
CHAPTER 4 ADVANCED VIEWING SETUP ...................................................................15
Introduction.....................................................................................................................15
Adjusting the Video Image .............................................................................................15
Controlling User Access to the Video Stream...............................................................17
Making Video available from the Internet....................................................................18
Viewing Live Video via the Internet ..............................................................................20
Motion Detection Alerts..................................................................................................21
CHAPTER 5 WEB-BASED MANAGEMENT ....................................................................22
Introduction.....................................................................................................................22
Connecting to Wireless Network HD Camera..............................................................22
Welcome Screen...............................................................................................................23
Administration Menu......................................................................................................24
System Screen ..................................................................................................................25
Network Screen................................................................................................................27
Wireless Screen................................................................................................................30
Streamings........................................................................................................................32
Video & Audio Screen.....................................................................................................34
Video Access Screen........................................................................................................36
User Database Screen......................................................................................................38
Pan/Tilt Screen ................................................................................................................39
Motion Detection Screen.................................................................................................41
Audio Detection Screen...................................................................................................42
FTP Screen.......................................................................................................................43
HTTP Screen....................................................................................................................44
Trigger & Recording Screen ..........................................................................................45
Maintenance Screen ........................................................................................................47
Status Screen....................................................................................................................49
Log Screen........................................................................................................................51
CHAPTER 7 TROUBLESHOOTING..................................................................................52
Overview ..........................................................................................................................52
Problems...........................................................................................................................52
APPENDIX A SPECIFICATIONS........................................................................................54
Wireless Network HD Camera.....................................................錯誤! 尚未定義書籤。
Regulatory Approvals.....................................................................................................54
Copyright Notice..............................................................................................................56

Copyright 2014. All Rights Reserved.
Document Version: 1.0
All trademarks and trade names are the properties of their respective owners.

1
Chapter 1
Introduction
This Chapter provides details of the Wireless Network HD Camera's features,
components and capabilities.
Overview
The Wireless Network HD Camera has an Integrated Microcomputer and a high quality Mega
Pixel Omni Vision CMOS Sensor, enabling it to display high quality live streaming video over
your wired LAN, the Internet, and for the Wireless Network HD Camera, an 802.11N Wireless
LAN.
Using enhanced H.264 technologies, the Wireless Network HD Camera is able to stream high
quality video and audio directly to your PC. The high compression capabilities of H.264 reduce
network bandwidth requirements to amazingly low levels.
Furthermore, with the built-in infrared LED, the Wireless IP camera can provide illumination
around 5 meters long under low light conditions in a simple, economical manner.
Figure 1: Wireless Network HD Camera
Features
Standalone Design. The Wireless Network HD Camera is a standalone system with
built-in CPU and Video encoder. It requires only a power source and a connection to your
LAN or Wireless LAN.
Dual Video Support. The Wireless Network HD Camera can support H.264 and MJEPG
video for different image compression.
1

2
Stream Live Video to Multiple Users. The video encoder and HTTP server built into
the camera generate a ready-to-view video stream. Just connect to the camera using your
Web browser to view live video.
Suitable for Home, Business or Public Facilities. Whether for Home, Business or
Public Facility surveillance, or just for entertainment and fun, the Wireless Network HD
Camera has the features you need.
Multi-Protocol Support. Supporting TCP/IP networking, HTTP and other Internet
related protocols, the Wireless Network HD Camera can be easily integrated into your
existing network.
IR LED Support. Each Wireless Network HD Camera has one infrared LED. The LED
can provide illumination around 5 meters long, that can help to output a better video
quality while under low-light conditions such as indoors, on cloudy days, or in the
morning or evening.
Motion Detection. This feature can detect motion in the field of view. The Wireless
Network HD Camera will compare consecutive frames to detect changes caused by the
movement of large objects. This function only works indoors due to the sensitivity of the
CMOS sensor. When motion is detection or some other action may be triggered.
Flexible Scheduling. You can limit access to the video stream to specified times using
a flexible scheduling system. The Motion Detection feature can also have its own schedule,
so it is active only when required.
Syslog Support. If you have a Syslog Server, the Wireless Network HD Camera can
send its log data to your Syslog Server.
Audio Support. You can listen as well as look! Audio is encoded with the video if
desired. With built-in microphone, it is useful for bi-direction voice conversation.
Day/Night Switch. With the day/night switching feature, you are able to view and record
better images even in the dark of night.
Internet Features
User-definable HTTP/HTTPS port number. This allows Internet Gateways to use
"port mapping" so the Wireless Network HD Camera and a Web Server can share the
same Internet IP address.
NTP (Network-Time-Protocol) Support. NTP allows the Wireless Network HD
Camera to calibrate its internal clock from an Internet Time-Server. This ensures that the
time stamp on Video from the Wireless Network HD Camera will be correct.
Security Features
User Authentication. If desired, access to live video can be restricted to known users.
Users will have to enter their username and password before being able to view the video
stream.
Password-Protected Configuration. Configuration data can be password protected, so
that it only can be changed by the Wireless Network HD Camera Administrator.
Wireless Features
Supports 11n Wireless Stations. The 802.11n standard provides for backward
compatibility with the 802.11b standard, so 802.11n, 802.11b and 802.11g Wireless
stations can be used simultaneously.
Wired and Wireless Network Support. The Wireless Network HD Camera supports
either wired or wireless transmission.

3
WEP Support. Full WEP support (64/128 Bit) on the Wireless interface is provided.
WPA/WPA2 Support. The WPA Personal/WPA2 Personal standard is also supported,
allowing advanced encryption of wireless data.
WPS Support. WPS (Wi-Fi Protected Setup) can simplify the process of connecting any
device to the wireless network by using the push button configuration (PBC) on the
Wireless Network HD Camera, or entering a PIN code if there's no button.

4
Physical Details - Wireless Network HD Camera
Front - Wireless Network HD Camera
Figure 2: Front Panel
1. Light Sensor
This is hardware sensor to detect LUX.
2. Lens
No physical adjustment is required or possible for the lens, but you
should ensure that the lens cover remain clean. The image quality is
degraded if the lens cover is dirty or smudged.
3. infrared LED
It is used to provide illumination for night time.
4. Microphone
The built-in microphone is useful for bi-direction voice
conversation.
Rear - Wireless Network HD Camera
Figure 3: Rear Panel

5
1. LAN port
Use the provided RJ-45 cable to connect your Wireless Network
HD Camera to a 10/100BaseT hub or switch.
Note:
Plugging in the LAN cable will disable the Wireless
interface. Only 1 interface can be active at any time.
The RJ-45 cable should only be connected or disconnected
when the camera is powered OFF. Attaching or detaching the
RJ-45 cable while the camera is powered on does NOT
switch the interface between wired and wireless.
2. DC Power Input
Connect the supplied 12V power adapter here. Do not use other
power adapters; doing so may damage the camera.
3. WPS Button
Push the WPS button on the device and on your other wireless
device to perform WPS function that easily creates an encryption-
secured wireless connection automatically.
WPS PBC Mode. When pressed and released (less then 3
seconds), the Wireless Network HD Camera will be in the
WPS PBC mode (Auto link mode).
WPS Pin Code Mode. When pressed and held for over 3
seconds, the Wireless Network HD Camera will be in the
WPS Pin Code mode.
4. Reset Button
This button is recessed; you need a pin or paper clip can be used
to depress it. It can be activated at any time the camera is in the
"ready" mode.
Reset to manufacturer default valued and reboot. When
pressed and held over 10 seconds, the settings of Network
Camera will be set to their default values.
5. Power LED
(Green)
On - Power on.
Off - No power.
Blinking - The Power LED will blink during start up. This will
take 55 to 57 seconds.
6. Network LED
(Green, Amber)
On (Green) - Network (Wireless or LAN) connection is
available.
Off - Wireless or LAN is not connected or camera is not
sending/receiving data.
Blinking (Green) - Data is being transmitted or received via the
LAN or Wireless connection.
On (Amber) - If the LED is on for 5 seconds and then off, the
WPS function is failed.
Blinking (Amber) - WPS function is being processed.

6
Package Contents
The following items should be included: If any of these items are damaged or missing, please
contact your dealer immediately.
1. Wireless Network HD Camera x 1
2. Stand x 1
3. DC power adapter x 1

7
Chapter 2
Basic Setup
This Chapter provides details of installing and configuring the Wireless
Network HD Camera.
System Requirements
To use the wired LAN interface, a standard 10/100BaseT hub or switch and network cable
is required.
To use the Wireless interface on the wireless model, other Wireless devices must be
compliant with the IEEE802.11b, IEEE802.11g or IEEE 802.11n specifications. All
Wireless stations must use compatible settings.
The default Wireless settings are:
Mode: Infrastructure
SSID: ANY
Wireless Security: Disabled
Domain: USA
Channel No.: Auto
Installation - Wireless Network HD Camera
1. Assemble the Camera
Attach the Camera Stand to the camera.
2. Connect the RJ-45 Cable
Connect the Wireless Network HD Camera to a 10/100BaseT hub or switch, using the
supplied
RJ-45 cable.
For this Model, it will disable the Wireless Interface. The
Wireless and LAN interfaces cannot be used simultaneously.
Using the LAN interface is recommended for initial
configuration. After the Wireless settings are correct, the
Wireless interface can be used.
The first time you connect to the camera, you should connect
the RJ-45 cable and configure the Wireless Network HD
Camera with appropriate settings. Then you can unplug the
RJ-45 cable and power off the camera. The Wireless Network
HD Camera will be in wireless interface when you power on
the camera again.
2
