Serta Laguna Sofa & Table Set User manual

So Comfortable,
You’ll feel the dierence
the moment you sit down.
ASSEMBLY
INSTRUCTIONS
Laguna Sofa & Table Set
Part 1

Should you prefer to
speak with a customer
service representative,
you may call toll free :
1-855-372-2315.
03

Limited Warranty
Millwork Holdings seating products are warranted
against defects in material and workmanship while
owned by the “Original Purchaser”. The term “Original
Purchaser” is defined as that party or entity which
purchases Millwork Holdings furniture from an
authorized Millwork Holdings retailer as shown by the
original sales receipt. This warranty does not apply to
“as is” or previously owned seating products.
Millwork Holdings warrants its products to be free
from defects in materials and workmanship (normal
wear and tear, fading and stretching excepted),
for one year from the date of purchase, except as
provided below under the limited warranty.
This warranty gives you specific rights, and you may
also have other rights, which vary from state to state.
All warranties are limited to the original purchaser for
normal use by a maximum of two users. Total weight
capacity per chair is 250 pounds for a single user.
t he exceptions or exclusions to this warranty are:
•Upholstery material and foam cushion material is
warranted against defects in material and workmanship
for a period of one year, beginning on the date of
purchase as shown on the original sales receipt.
•Any warranty claim that is submitted after the limited
warranty period, or without proper proof of purchase
will not include the cost of parts, labor, or delivery on
the warranted parts within a reasonable amount of time.
We reserve the right to require damaged parts to be
returned to us upon request. Natural markings such as
scars, brands, grain variations, wrinkles, color variations,
etc. will be considered normal characteristics and not
construed as defects.
•For claims or questions concerning this warranty, please
contact Millwork Holdings Customer Service department
on the web at www.truecustomersupport.com. Be
prepared to provide your name, address, daytime phone
number, the model and purchase order number of the
product, date of purchase, and the store where it was
purchased. Millwork Holdings requires that the original
sales receipt be submitted with all requests to confirm
that you are the original purchaser according to our
written warranty.
04

Thank you for selecting a Serta furniture piece!
Our primary objective is to provide fast, friendly
customer service to all of our customers. We are
here to help if you have any questions, comments,
or are in need of warranty replacement parts.
Please call us toll free at: 1-855-372-2315
(Monday - Friday 6:00am - 5:00pm PST)
Or visit our website:
www.truecustomersupport.com
www.trueinnovations.com
Or call us toll free: 1-800-379-9973
Guidelines
FAILURE TO FOLLOW THESE WARNINGS
WHEN IN USE COULD RESULT IN INJURY
•Do not stand on the item or use as a step ladder
•The seat has been tested and approved for users
weighing up to 250 lbs (113kg) per seat.
•Do not use this item unless all bolts and screws are
firmly secured and fastened.
•Check all bolts and screws every 90 days. As
necessary tighten if any are loose.
•Lift up then move. Pushing over or dragging this
product can result in an injury or cause damage to
the floor and outdoor piece.
05

Pre-Assembly Preparation:
Please read through this instruction before beginning
assembly of this item.
Two adults assembly are recommended.
•Clear out space for assembly and lay out all parts
shown in parts list. Extra room will allow you to easily
determine if all the pieces are present.
•Save all packing materials until assembly is complete to
avoid accidentally discarding smaller parts or hardware.
•Keep small parts and pieces away from children
until fully assembled.
•Please check for any loose screws and tighten them
before you use.
WARNING: DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT
DUE TO THE POSSIBLE RISK OF INJURY.
Cleaning & Maintenance:
•Wash frame parts with mild soap and water, rinse
thoroughly. Dry frame parts completely. Do not
use bleach, acid or other solvents on the wicker or
metal parts.
•We recommend the use of furniture covers to
protect the set when not in use.
•Inspect and tighten all bolts on a regular basis to
ensure proper performance and safety.
•In order to prolong the life of your outdoor
furniture, we recommend storing it in a dry and
protected area during o season periods.
06

Parts & Assembly - Sofa
Left
Panel
Back Panel
Front
Panel
Base Panel
Right
Panel
Seat Panel
Fixing Panel
Seat CushionWasher
Allen Key
Back cushion
07

Please note, the box is well engineered
to fit all the pieces of the sofa in
it. Check that all layers have been
unpacked to locate all the pieces.
Assembly:
Front Panel
Base Panel
08

1Step One:
Attach Left Side panel (1) to Back
Panel (2) by using M6*35 bolt (A) and
Washer (B). Fasten with Allen Key (D).
step1
step2
09
NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED.

2Step Two:
Attach Seat panel (3) to assembled
panels (1) and (2).
10

3
Attach Right Side Panel (4) to
assembled Panels (1), (2) & (3) by
using M6*35 bolt (A) and Washer
(B). Fasten with Allen Key (D).
Step Three:
step3
step4
11
NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED.

4 Step Four:
Attach Front Panel (5) to panels
(1) & (4), by using M6*35 bolt
(A) with Washer (B). Fasten
with Allen Key (D).
12
NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED.

5 Step Five:
Lift up Seat Panel (3) then
Attach Base Panel (6) to Back
Panel (2) and Front Panel (5)
by clicking into place.
step5
Hold Seat Panel (3) by the hook of Base
Panel (6) when putting stuffs in the storage.
13

6 Step Six:
Attach Fixing Plates (E) by using
M6*15 bolt (C) with Washer (B).
Fasten with Allen Key (D).
step6
step7
14

So Comfortable,
You’ll feel the dierence
the moment you sit down.
15
INSTRUCTIONS
Laguna Sofa & Table Set
Part 2
ASSEMBLY

Parts & Assembly - Table
Front Panel Back Panel
Base Panel
Lid
Left Side Panel
Right Side Panel Allen Key
16

Please note, the box is well engineered
to fit all the pieces of the table in it.
Check that all layers have been
unpacked to locate all the pieces.
Assembly:
17

step1
step2
1Step One:
Attach Front Panel (7) to Left Side
Panel (8) by using M6*35 bolt (A)
and washer (B) with Allen Key (D).
Repeat with Right Side Panel (9).
18
NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED.

2Step Two:
Attach Side Panels (8) and (9) to
Back Panel (10) by using
M6*35 bolt (A) and Washer (B)
and fasten with Allen Key (D).
19
NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED.

3
Attach Base Panel (11) to Panels (7), (8),
(9), and (10) by using M6*35 bolt (A) and
Washer (B). Fasten with Allen Key (D).
Step Three:
step3
step4
20
NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED.
