serverLink ATS User manual

ATS
Automatic Transfer Switch
User Manual

Table of Contents
1. Introduction......................................................................................................................1
2. ATS Package ...................................................................................................................3
3. Function...........................................................................................................................4
4. Installation........................................................................................................................6
5. Configuration ...................................................................................................................8
6. Web Interface ..................................................................................................................9

ATS User Manual Ver. 1.0
1
1. Introduction
The ServerLink Automatic Transfer Switch (ATS) is a Single Phase Dual Input Power
Distribution Unit (PDU). When Input A falls below normal voltage and Input B is valid, the
output is automatically transferred to Input B. The output is transferred back to Input A
when Input A is valid and rises above normal. This high speed transfer rate ensures that
the transfer is transparent to the sensitive equipment. The two sources are not required
to be in the same phase. This is an effective solution that builds in redundancy and
increases the AC power availability of connected equipment. If the dual input power is fed
through two independent AC sources, then the system availability is increased and the
dual input advantages are fully used.
The ATS is an Internet ready device designed and is equipped with an intelligent current-
meter (True RMS) that will indicate the total power consumption of ATS.
The ATS offers an easy set up and user-friendly communication software. This software
provides the function that assistant manager to remotely monitor the multiple PDU power
consumption.
Features:
Dual input powers provide automatically redundant power protection.
Built-in web server, manager can real time to monitoring the current consumption of
the ATS.
Built-in true RMS current meter.
Setup easily, meter can read the IP address directly.
Security web access by SSL.
Provide voltage, frequency, power factor, active power, apparent power and kWh
information through web interface and SNMP.
Provide audible alarm when the power consumption over the threshold of warning and
overload.
Send the email and traps when the power consumption exceed the trigger value of
warning or overload to the PDU.
Provide utility, it can monitor a large mount of PDU at the same time.
Support the SNMP and provide MIB for ATS.
Indicate input and output status with LED.
Support to monitor temperature and humidity. (Need to purchase option accessory)
WARNING:
There is a risk of personal injury from electrical shock and hazardous energy levels.
The installation of options and routine maintenance and service of the product
must be performed by individuals who are knowledgeable about the procedures,

ATS User Manual Ver. 1.0 2
precautions, and hazards associated with AC power products (trained service
technician). To reduce the risk of electrical shock and/or equipment damage when
installing or servicing the ATS:
•The ATS must be disconnected from the product and unplugged from the AC
electrical outlet before servicing or repairing product.
•Do not overload the output of the ATS. The total connected load should not
exceed rated input power.
•Do not exceed the leakage current limit for the ATS in your system. See the
“Earth Leakage Current” section later in this document for limits.
Earth Leakage Current
To reduce the risk of electrical shock due to high leakage current, a reliable
grounded (earth) connection is essential before connecting ATS to AC power.
Observe the following limits when connecting the product to AC power
distribution devices.
For products that have attached AC power cords directly connected to the
building power, the total combined leakage current should not exceed 5 percent
of the rated input current for the device. For products that have detachable AC
power cords, the total combined leakage current should not exceed 3.5mA.

ATS User Manual Ver. 1.0 3
2. ATS Package
The standard ATS package contains:
zATS.
zRack mount Brackets.
zCD-ROM, it contains:
User Manual.
Monitoring Software.
MIB: Management Information Base for Network.
Adobe Acrobat Reader.

ATS User Manual Ver. 1.0 4
3. Function
Interface
ATS series interface
Functions Description
Ethernet RJ45 port for network communication port.
Audible Alarm Warning- 1 beeps in 1 second.
Overload- 3 beeps in 1 second.
Note: The audible alarm will keep beeping until the current
gets back to normal and the current is lower than the
threshold to 0.5 amps.
Function Button zPress and hold the key after 1 beeping; it can let the meter
to show up the current information and
temperature/humidity in sequence.
zPress and hold the key after 2 beeping; it can let the meter
to show up the IP address
zPress and hold the key after 4 beeping; it can change the
way to get IP by DHCP or Fixed IP.
zPress and hold the key after 6 beeping; it can reset PDU
back to default setting.
Meter 3 digits to display current and IP Address.
ID Information indication.
LED Indicator SSL (yellow):
Light on means that web access is protected by SSL.
DHCP (green):
Light on means that PDU gets IP address through DHCP.
Input (green):
Indicate input power status.
Output (green):
Indicate which input power source is active to provide output

ATS User Manual Ver. 1.0 5
power.
ENV RJ11 for option probe attached to detect temperature and
humidity.
Circuit Breaker Overload power protection. (Only 30 Amp above is available)

ATS User Manual Ver. 1.0 6
4. Installation
This section will provide a quick instruction to install the PDU.
Rack Mount Instructions
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the
operating ambient temperature of the rack environment may be greater than room
ambient. Therefore, consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature specified by the
manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not compromised.
C) Mechanical Loading - Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideration should be given to the connection of the equipment
to the supply circuit and the effect that overloading of the circuits might have on over
current protection and supply wiring. Appropriate consideration of equipment nameplate
ratings should be used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connections to
the branch circuit (e.g. use of power strips)."
Diagram

ATS User Manual Ver. 1.0 7
Hardware
1. Install mounting brackets.
2. The ATS comes with brackets for mounting in a rack. To mount the ATS into a rack
performs the following procedure:
3. Attach the mounting brackets to the unit, using the four retaining screws provided for
each of the brackets.
4. Choose a location for the brackets.
5. Align the mounting holes of brackets with the notched hole on the vertical rail and
attach with the retaining screws.
6. Connect input and output power.
7. Connect Ethernet cable to the ATS.
8. Switch on the ATS.
Note :
The default setting for the way to get IP address is DHCP. If ATS can not get the IP from
DHCP server, its IP address will stay at 192.168.0.216

ATS User Manual Ver. 1.0 8
5. Configuration
The ATS can be configured to fit several power distribution requirements.
Two supported configurations for Redundant Switch are shown below.
Minimum acceptable configuration: Redundant Switch with two UPS units connected
to the same facility power source.
Best configuration: Redundant Switch with two Smart-UPS units connected to two
separate AC lines, each UPS receiving power from a separate facility power source.

ATS User Manual Ver. 1.0 9
6. Web Interface
Login:
Input the ATS IP address in web browser.
Default ID is snmp.
Password is 1234.

ATS User Manual Ver. 1.0 10
Information: ATS
Indicate the status of ATS input power
Status Description:
Active
Standby: Backup power source
n/a: No power input or power is out of range.
Indicate the temperature and humidity

ATS User Manual Ver. 1.0 11
Information: System
Indicate ATS system information, including:
Model No.
Firmware Version
MAC Address
System Name
System Contact
Location

ATS User Manual Ver. 1.0 12
Information: Power
Provide ATS power information, including:
Voltage, Frequency, Power Factor, Active Power, Apparent Power and Main Energy.
Accumulated Energy: Subtotal for energy. User can reset to 0 and restart calculating.
Carbon Emission Data: Reference data.
CO2 Electricity Emission Rate: Users can check this parameter through their power
plant.

ATS User Manual Ver. 1.0 13
Configuration: ATS
ATS Selection
Manually select one of inputs as the primary power source.
Input Identification
Rename input power identification.

ATS User Manual Ver. 1.0 14
Configuration: Threshold
Set the warning and overload threshold for each circuit.
Set lower and upper threshold for temperature and humidity.

ATS User Manual Ver. 1.0 15
Configuration: User
Change ID and password.
Default ID is snmp and password is 1234.

ATS User Manual Ver. 1.0
16
Configuration: Network
PDU network information
Enable DHCP: Change the way to get IP address for PDU.

ATS User Manual Ver. 1.0 17
Configuration: Mail
When event occurs, PDU can send out email message to pre-defined account.
Email Server: The Email Server only support to be input domain name, not IP address.
Sender’s Email: Input the sender email address.
Email Address: Input the recipient email address.
The message in the email:
Indicate OutletA~H-XXXXXXXX status in order
X=0 : means the power off.
X=1 : means the power on.
Note: Make sure DNS server can resolve the Email Server’s domain name.

ATS User Manual Ver. 1.0 18
Configuration: SNMP
When event occurs, PDU can send out trap message to pre-defined IP address.
Trap Notification: Set receiver IP for trap.
Community: Set SNMP community.
Read Community is public and fixed.
Default Write Community is “public” and can be modified by user.
