Sonoff NSPanel User manual

Smart Scene Wall Switch
User manual V1.1
NSPanel
NSPanel-US NSPanel-EU

Reset Button
English
The device weight is less than 1 kg. The installation height of less than 2 m is recommended.
Product Introduction
Shenzhen Sonoff Technologies Co., Ltd.
3.5" TFT Touch Screen
Pairing button/Physical switch
1
NSPanel-EU
NSPanel-US 3.5" TFT Touch Screen
Pairing button/Physical switch
Reset Button
NSPanel is a dual-channel smart touch control panel integrating three interactive methods, screen
touching, voice control and App control. Users can control the device types including smart switch
and plugs (heating/cooling) under the eWeLink account. Users are able to control multiple smart
devices through adding widgets on their smart phones, such as turn on/off, schedule on/off the
connected devices and share them with families to control.
Features
TFT
Thermostat
Adding Widgets
Smart Scene Inching Mode LAN ControlGroup Control
Remote Control Single/Countdown
Timing
Share Control Voice Control
Interlock
3.5" TFT Touch Screen
Temperature Sensor
Temperature Sensor

L OutL Out L In N
100-240V AC
N
L In
L1 Out
L2 Out
NN
English
2. Wiring instruction
Light fixture wiring instruction:
Make sure all wires are connected correctly.
Shenzhen Sonoff Technologies Co., Ltd.
ON O FF
ON O FF
ON O FF
ON O FF
Please install and maintain the device by a professional electrician. To avoid electric shock
hazard, do not operate any connection or contact the terminal connector while the device
is powered on !
Operating Instruction
1. Power off
2
NSPanel-EU
NSPanel-US
L OutL Out L In N
100-240V AC
N
L In
L1 Out
L2 Out
NN

3. Download the eWeLink App
eWeLink
eWeLink
Android™ & iOS
English
Shenzhen Sonoff Technologies Co., Ltd.
4. Power on
After powering on, the device will enter the bluetooth pairing mode during the first use.
The screen status is shown in the above image.
5. Add the device
Tap “+” and select “bluetooth pairing” , then operate following the prompt on the App.
Sou nd Pair ing
Avail able fo r eWeLi nk supp ort dev ices
Avail able fo r GSM
and ot her dev ices
with Q Rcode .
Available for camera
and other devices that
support this pairing
method.
Add D evice All de vices
Quick Pa irin g
Sca n QR code
Ava ilable for b lue too th
co nne cti on.
Bluetooth Pairing
Ple ase add d evice s with Bl uetoo th pair ing in eW eLink a pp
3

15:00
-15℃ZS leep 1 Min ute
>
15:00 6/ 9 Fir
Operation Guide
Drop down
Settings of the screen brightness and sleep time
English
Shenzhen Sonoff Technologies Co., Ltd.
15:00
-15℃
15:00 6/ 9 Fir
> > >
GSM开关 双⾊灯 多通 道设备 多通道设备
15:00
-15℃
15:00 6/ 9 Fir
28.5 ℃
+
-
A
Swipe left
After adding widgets in the App, you can control the added widgets on the device.
Swipe right
After adding temperature controller function in the App, you can set the added temperature
controller on the device.
4

English
Shenzhen Sonoff Technologies Co., Ltd.
Bind Temperature Control Device
There is a built-in temperature sensor in the NSPanel to monitor the room temperature and you
can maintain the room temperature by controlling the cooler/heater, which is connected with
smart switches or smart plus and these devices are required to pair with eWeLink App.
Access the NSPanel interface in the App and tap “Thermostat” to select the devices in the Action
device list. All the listed devices are supported to bind with the Thermostat (including two
NSPanel channels). You can only select one device or one channel of the multi-channel device
to execute and then choose heater or cooler as the Device type.
Active the Thermostat after selecting the Action device and Device type, then you can see there
are two modes to control the temperature which are Manual mode and Auto mode.
Manual mode:
Allow you to adjust the temperature manually whenever you want and then the Thermostat will
execute to maintain the manual setting temperature.
Auto mode:
Allow you to set 6 target temperature at most by tapping “Add” to set the temperature respectively.
Once set, all setting will execute automatically at certain time duration and cannot be controlled
manually unless switched to the Manual mode. The binding devices will turn off when they are
out of schedule.
Actual room temperature will be ±1℃. For example, the setting temperature is 26℃ but the
actual temperature range is between 25℃ and 27℃.
NSPanel
Sche duleTher mostat
Cha nnel1
27℃
Cho oseDevice
Heater
Coo ler
Done
Scl ectact iondevice
Thermostat
BAS ICR3
T2U K2C
S31
S26
Next
Cha nnel2
Time r LoopTimer
Thermostat
The rmostat
5

English
Shenzhen Sonoff Technologies Co., Ltd.
IEEE 802.11 b/g/n 2.4GHz
Wi-Fi
Android & iOS
100-240V ~ 50/60Hz 4A Max
100-240V ~ 50/60Hz 2A/Gang 4A/Total
PC V0+CRS+Toughened Glass
150W/110V/Gang，300W/110V/Total
300W/220V/Gang，600W/220V/Total
3.5" (Capacitive Touch Panel)
Screen Size
480*320px
Screen Resolution
Specifications
Model
Input
Output
LED load
Operating systems
Shell materials
NSPanel-EU, NSPanel-US
NSPanel-EU: 86x86x41.7mm
NSPanel-US: 120x74x41.7mm
Dimension
Bluetooth Standard 4.2 BLE
Add Widgets
NSPanel can be added 8 widgets in the screen for Quick Control. The form of widget can be single
device, group devices of the congeneric devices and Tap to Perform Scene. In addition, you can
control more features of the multi-gang and lighting devices in the secondary interface.
NSPanel
Sche duleTher mostat
Cha nnel1
27℃
Cha nnel2
Time r LoopTimer
S26
B05-F-A19
L2Li te
DeviceSettings Addwi dgets
Inc hingSett ings
Inte rlock
Tempe ratureun it
Wid gets
Scre ensetti ngs
Dev iceinfo
Man ufactur er
Mod el
Dev iceID
FWNa me
Del etedev ice
SON OFF
NSPanel
100 13831f 3
E32 -MSW-N X
Youmayaddwi dgetst ocontro ldevic eonthepanel.
Add
Save
BAS ICR3
T2U K2C
S31
Widget s
Widgets
Save
6

When you want to change the NSPanel's account or connected WIFI, it requires you to pair the
NSPanel again. Press any bottom of the device for 5s until the screen indicates that it had
entered into Bluetooth pairing mode and then release. Now the NSPanel is available for
Bluetooth pairing in the eWeLink App.
English
Deleting the device on the eWeLink app indicates you restore it to factory setting.
Factory Reset
Re-establish Pairing of the NSPanel
The device will exit the bluetooth pairing mode if not paired within 3mins.
Shenzhen Sonoff Technologies Co., Ltd.
Common Problems
Fail to pair Wi-Fi devices to eWeLink App
1. Make sure the device is in pairing mode. After three minutes of unsuccessful pairing, the
device will automatically exit pairing mode.
2. Please turn on location services and allow location permission. Before choosing the Wi-Fi
network, location services should be turned on and location permission should be allowed.
Location information permission is used to obtain Wi-Fi list information. If you click Disable,
you will not be able to add devices.
3. Make sure your Wi-Fi network runs on the 2.4GHz band.
4. Make sure you entered a correct Wi-Fi SSID and password, no special characters contained.
Wrong password is a very common reason for pairing failure.
5. The device shall get close to the router for a good transmission signal condition while pairing.
Ple ase add d evice s with Bl uetoo th pair ing in eW eLink a pp
15:00
-15℃
7

FCC Radiation Exposure Statement:
FCC Warning
Changes or modifications not expressly approved by the party responsible for compliance
could avoid the user’s authority to operate the equipment.
Note:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
— Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance20cm
between the radiator & your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
FCC Warning
Shenzhen Sonoff Technologies Co., Ltd.
8

Shenzhen Sonoff Technologies Co., Ltd.
MADE IN CHINA
1001, BLDG8, Lianhua Industrial Park, shenzhen, GD, China
ZIP code: 518000 Website: sonoff.tech
https://sonoff.tech/usermanuals
Hereby, Shenzhen Sonoff Technologies Co., Ltd. declares that the radio equipment type
NSPanel-EU, NSPanel-US is in compliance with Directive 2014/53/EU.The full text of the EU
declaration of conformity is available at the following internet address:
