Setra Systems 224 User manual

Installation Guide
1-800-257-3872 Toll Free
1-978-264-0292 Fax
www.setra.com Web Site
Model 224
Ultra-High P rity Flow-Thro gh
Press re Transd cer
ISO
✓
Certified
9001:
2000

2
Setra Model 224
Ultra High Purity Flow-Through Pressure Transducer
1.0 GENERAL INFORMATION
Every Model 224 has been tested and calibrated before shipment. Model 224
performance specifications are listed on Page 6 of this Guide.
Setra Systems 224 pressure transducers sense gauge, compound or absolute
pressure and convert this pressure to a proportional high level analog output.
Two output versions are offered: A voltage output of 5 VDC FSO (Full Scale
Output) and 10 VDC FSO ), and a current output of 4 to 20 mA.
Note:These instructions are also available on our website at www.setra.com.
1.1 EMC Certification
This product complies with EN61326 Electrical Equipment for Measurement,
Control and Laboratory use – EMC Requirements for Minimum Requirements
and Industrial Locations. Special caution should be taken to meet Standard
EN61000-4-5: 1995 Surge Immunity if any of the following conditions apply to
the installation: The product is installed outside; all or any part of the cable is
exposed to the outside; the cable is greater than 30 meters in length. In order
to meet the Surge Immunity requirements, the following conditions must be
followed during installation:
1. Shielded cable must be used, and the shield must be tied to earth ground (not power supply
ground) on at least one end of the cable shield/drain wire. The shield must be maintained all the
way from sensor to the power supply.
2. If unshielded cable is used, an earth grounded metal conduit fitting can be used to replace the
shielded cable.
3. For a sensor with a metal body or enclosure, the body/enclosure must be grounded to earth. If a
protective metal housing is used, the metal housing should be grounded to earth
4. If a protective plastic housing is used, the housing must be able to withstand at least
2 KV from the housing to earth ground, without damaging the circuit.
2.0 MECHANICAL INSTALLATION
2.1 Media Compatibility
Model 224 transducers are designed to be used with any gas or liquid compat-
ible with 316L Stainless Steel. Never submerge the transducers in any liquid.
2.2 Environment
The operating temperature limits of the 224 are as follows:
Operating Temperature Range°F (°C) -40 to +185 (-40 to +85)
Compensated Temperature Range°F (°C) +15 to +150 (-9 to +65)
Current unit ordered with Option N1:
Operating Temperature Range°F (°C) -22 to +176 (-30 to +80)
Compensated Temperature Range°F (°C) +15 to +150 (-9 to +65)
2.3 Pressure Fittings
Mounting - Model 224 pressure transducers can be installed with Face Seal
Fittings or can be butt welded into place.
When installing units with Face Seal Fittings:
a.) Align piping system to transducer connections
b.) Hand tighten nuts
c.) Torque nuts by placing wrenches on nuts only (or on nut and wrench flats
of transducer body for units with fixed male face seals) Never hold the unit
by the electronics housing during installation.
NOTE: Welding purge gases are very hot! It is important to flow hot purge gases away from the
transducer. Disconnect all electrical connections to transducer when welding.

2.4 Venting
Model 224 transducers are vented through the electronics housing.
3.0 ELECTRICAL INSTALLATION
3.1 Voltage Output Units
The Model 224 voltage output transducer is supplied with a 6ft. multiconductor
cable, Bayonet style connector, Mini Din connector, or D-Sub style connectors.
The voltage output is either 5 VDC FSO or 10 VDC FSO. Diagram 1 shows electrical
connection wiring for voltage output transducers, and the excitation required.
Diagram 1
Note: Model 224 can be wired as a 3-wire device by connecting – OUTPUT and –EXCITATION and drain
wire to a common ground. However, accuracy may be reduced due to increase in resistance.
3.2 Current Output Units
The Model 224 is a two-wire loop-powered 4 to 20mA current output unit and
delivers rated current into any external load of 0-800 ohms. The Model 224 is
available with 6ft. of multiconductor cable, Bayonet, Mini Din, or D-Sub style
connectors. Diagram 2 shows electrical connection wiring for current output
transducers.
The power supply must be a DC voltage source with a voltage range between
10 VDC and 30 VDC measured between the + and - terminals. The unit is calibrated
at the factory with a 24 VDC loop supply voltage and a 250 ohm load.
Current must flow in one direction only - Please observe polarity. (See
Diagram 3.) We suggest that the cable shield Drain Wire be connected to the
system’s loop circuit ground for optimum electrical noise rejection. On transducers
with integral connectors (e.g., on Bayonet,D-sub, or MiniDin Connector types),
connection to transducer case ground can be achieved by connecting the cable
drain/shield wire to the mating cable-mounted connector shell (see Note 1).
Diagram 2
9 PIN 15 PIN 5 PIN
CABLE BAYONET D-SUB D-SUB MINI-DIN
CONNECTION WIRE PIN PIN PIN PIN
+ EXCITATION RED A 4 7 1
+ OUTPUT GREEN B 1 2 2
–OUTPUT WHITE C 8 12 4
–EXCITATION BLACK D 9 5 5
CASE GND DRAIN SHELL SHELL SHELL 3
CONNECTOR PIN WIRING FOR VOLTAGE TRANSDUCERS
CONNECTOR PIN WIRING FOR CURRENT TRANSMITTERS
EXCITATION: 10-30 VDC FOR 0.2 TO 5.2 VDC and 0 to 5 VDC
13-30 VDC FOR 0.2 TO 10.2 VDC and 0 to 10 VDC
Minimum Supply Voltage = 10 + 0.02 x Loop Resistance
Maximum Supply Voltage = 30 + 0.004 x Loop Resistance
9 PIN 15 PIN 5 PIN
CABLE BAYONET D-SUB D-SUB MINI-DIN
CONNECTION WIRE PIN PIN PIN PIN
+ EXCITATION RED A 4 7 1
–EXCITATION BLACK D & B 9 5 4
CASE GND DRAIN SHELL SHELL SHELL 3
3
and w/N1 option, see Notes 2 and 3, Page 4.) (

4
4.0 CALIBRATION
The 224 transducer is factory calibrated to the specific input pressure range vs.
output voltage or current and should require no field adjustment. For absolute
pressure ranges, the zero can be adjusted with full vacuum applied to the
pressure port. For compound ranges, the zero should be adjusted with the unit
at atmospheric pressure and the output adjusted as noted in Diagrams 5 & 6 on
pages 5 & 6. Zero and span adjustments can be made by removing the zero and
span hole plugs and washers and adjusting the zero and span potentiometers.
Be certain to replace the zero and span hole plugs and washers after adjustments
are made.Hole plugs and washers are installed in potentiometer holes to keep
contaminants out of the unit.
Diagram 4
Electrical
Connection
SPAN Adjustment ZERO Adjustment
Note 1). The transducer case and integral Bayonet Connector shell, D-sub
Connector Shell, and Mini Din shell clips are electrically connected.
Note 2: ETL Listed to UL1604 Standards:The current output unit (excluding units ordered
with the Mini Din Shell) may be installed in UL1604 Class 1 Hazardous (Classified)
Group A, B, C, D, Division 2 locations if the unit is ordered for these locations. (This
is denoted by an N1 designation in the Part Number, 12th and 13th digits.) Safety
barriers are not required as long as the unit is operated under normal conditions
with a maximum excitation voltage of 30 VDC between the input terminals.
Note 3: ATEX 94/9/EC Approved: Special hazardous area instructions for 224 transducers
(with the N1 suffix) with ATEX approval: The 224 transducer (with the N1 suffix) is
designed for use in hazardous areas indoor applications with ATEX rating: Non-
incendive II 3G Eex nL IIC T4 X -30°C<Ta<+80°C. (Note: Units ordered with the
Mini Din Shell are not ATEX approved for use in hazardous locations.)
•The device can only be used for“Indoor Applications”.
•Power must be turned off before connecting or disconnecting.
•For the connector version, the connector must be secured before applying
power and DO NOT SEPARATE WHEN ENERGIZED.
•The shielded cable must be used and the drain wire of the cable must be
connected to the earth ground.The drain wire of the cable must connect to
the connector metal outer shell for the connector version.
•The maximum allowable transient disturbance must not exceed more than
40% of the maximum excitation voltage.
Diagram 3
Setra
Transducer
Power Load
+
+
_
+
__

4.1 Voltage Output Zero Adjustment
While monitoring the voltage between the positive output (+OUT) and common
(COM), and with the pressure port open to atmosphere, or with zero pressure
applied,the zero may be adjusted by turning the zero potentiometer screw.
For the 5 VDC Full Scale Output, the tolerance on zero and span settings is
±25mV. For the 10 VDC Full Scale Output, the tolerance on zero and span
settings is ±50mV. For absolute pressure ranges, the zero should be adjusted
with a full vacuum applied. See the chart below for nominal“installed”output at
atmospheric pressure for compound pressure ranges.
Diagram 5
NOMINAL“INSTALLED”OUTPUT AT ATMOSPHERIC PRESSURE
PSI 5 VDC Full Scale Outputs 10 VDC Full Scale Outputs
Compound 0.2 to 5.2 0 to 5VDC 0.2 to 10.2 0 to 10VDC
Range Voltage (VDC) Voltage (VDC) Voltage (VDC) Voltage (VDC)
(Factory Set to within ±25mV) (Factory Set to within ±50mV)
-14.7 to 25 2.051 1.851 3.903 3.703
-14.7 to 50 1.336 1.136 2.472 2.272
-14.7 to 100 0.841 0.641 1.482 1.282
-14.7 to 250 0.478 0.278 0.755 0.555
-14.7 to 500 0.343 0.143 0.486 0.286
-14.7 to 1000 0.272 0.072 0.345 0.145
-14.7 to 3000 0.224 0.024 0.249 0.049
Bar 5 VDC Full Scale Outputs 10 VDC Full Scale Outputs
Compound 0.2 to 5.2 0 to 5VDC 0.2 to 10.2 0 to 10VDC
Range Voltage (VDC) Voltage (VDC) Voltage (VDC) Voltage (VDC)
(Factory Set to within ±25mV) (Factory Set to within ±50mV)
-1 to 1.7 2.052 1.851 3.904 3.704
-1 to 3.4 1.336 1.136 2.473 2.273
-1 to 7 0.825 0.625 1.450 1.250
-1 to 17 2.494 0.278 0.756 0.556
- 1 to 35 0.339 0.139 0.478 0.278
-1 to 70 0.270 0.070 0.341 0.141
-1 to 200 0.225 0.025 0.250 0.050
5

6
4.2 Voltage Output Span Adjustment
(Complete the zero adjustment before setting span.)
Span or full scale output adjustments should only be performed by using an
accurate pressure standard (electronic manometer, digital pressure gauge,etc.),
with at least comparable accuracy to the 224 transducer (±0.25% FS). With full
range pressure applied to the pressure port, the span may be adjusted by
turning the span potentiometer screw. The span (full scale) output is factory set
to within ±25mV for 5 VDC FSO or ±50mV for 0 to 10 VDC FSO.
4.3 Current Output Zero Adjustment
While monitoring the current output, and with the pressure port open to
atmosphere or with zero pressure applied, the zero may be adjusted by turning
the zero potentiometer screw. The factory setting is 4mA (±0.08mA). For absolute
pressure ranges, the zero should be adjusted with a full vacuum applied.
For compound pressure ranges, the zero should be adjusted with the unit at
atmospheric pressure and the output adjusted as noted in Diagram 6 below.
Note: When it is not possible to vent input pressure for zero adjustment (i.e., hazardous
gasses), zero may be adjusted by pulling a vacuum and setting the unit to 4.0 mA (±0.08
mA). This method may result in a small zero setting error due to variations in barometric
pressure.
4.4 Current Output Span Adjustment
Span or full scale output adjustments should only be performed by using an
accurate pressure standard (electronic manometer, digital pressure gauge, etc.)
with at least comparable accuracy to the 224 transducer (<0.25% FS). With full
range pressure applied to the pressure port, the span may be adjusted by turning
the span potentiometer screw. The span (full scale) output is factory set to within
±0.08mA.
5.0 MODEL 224 PERFORMANCE SPECIFICATIONS
NOMINAL“INSTALLED”OUTPUT AT ATMOSPHERIC PRESSURE
PSI COMPOUND CURRENT
RANGE OUTPUT (mA)
-14.7 to 25 9.92
-14.7 to 50 7.63
-14.7 to 100 6.05
-14.7 to 250 4.89
-14.7 to 500 4.46
-14.7 to 1000 4.23
-14.7 to 3000 4.08
BAR COMPOUND CURRENT
RANGE OUTPUT (mA)
-1 to 1.7 9.92
-1 to 3.4 7.63
-1 to 7 6.00
-1 to 17 4.88
-1 to 35 4.44
-1 to 70 4.22
-1 to 200 4.07
Diagram 6
Accuracy RSS*Thermal Effects
(at constant temperature.) ±0.25% FS Comp Range °F(°C) +15 to +150 (-9 to +65)
Non-Linearity, BFSL ±0.15% FS Zero Shift %FS/100°F (50°C) ±2.0 (±1.8)
Hysteresis 0.20% FS Span Shift %FS/100°F (50°C) ±2.0 (±1.8)
Non-Repeatability 0.02% FS Environmental Data (Temperature)
*RSS of Non-Linearity, Non-Repeatability and Hysteresis. Operating**°F (°C) -40 to +185 (-40 to +85)
Warm-up Shift <±0.1% FS total Storage °F (°C) -40 to +185 (-40 to +85)
Current Unit Ordered w/Option N1
Operating **°F (°C) -22 to +176 (-30 to +80)
Storage °F (°C) -22 to +176 (-30 to +80)
** Operating temperature limits of the electronics only. Pressure media temperature may
be considerably higher or lower.

6.0 RETURNING PRODUCTS FOR REPAIR
Please contact a Setra application engineer (800-257-3872, 978-263-1400) before
returning unit for repair to review information relative to your application. Many times
only minor field adjustments may be necessary.When returning a product to Setra, the
material should be carefully packaged, accompanied by the“Service/Repair/Calibra-
tion Order Return”form”on page 8 and shipped to :
Setra Systems, Inc.
159 Swanson Road
Boxborough, MA 01719-1304
Attn: Repair Department
Note: Return order form is also available on Setra’s web site @ www.setra.com.
Setra Systems, Inc.
159 Swanson Road
Boxborough, MA 01719-1304
Attn: Repair Department
To assure prompt handling, please supply the following information and include it
inside the package or returned material (Return Order Form provided on page 8):
1. Name and phone number of person to contact.
2. Shipping and billing instructions.
3. Full description of the malfunction.
4. Identify any hazardous material used with product.
Notes: Please remove any pressure fittings and plumbing that you have installed and
enclose any required mating electrical connectors and wiring diagrams.
Allow approximately 3 weeks after receipt at Setra for the repair and return of the unit.
Non-warranty repairs will not be made without customer approval and a purchase
order to cover repair charges.
Calibration Services
Setra maintains a complete calibration facility that is traceable to the National Institute
of Standards & Technology (NIST). If you would like to recalibrate or recertify your
Setra pressure transducers or, please call our Repair Department at 800-257-3872 (978-
263-1400) for scheduling.
7.0 WARRANTY AND LIMITATION OF LIABILITY
SETRA warrants its products to be free from defects in materials and workmanship, subject to the following terms and conditions: Without charge, SETRA will repair or replace
products found to be defective in materials or workmanship within the warranty period; provided that:
a) the product has not been subjected to abuse, neglect, accident, incorrect wiring not our own, improper installation or servicing, or use in violation of instructions
furnished by SETRA;
b) the product has not been repaired or altered by anyone except SETRA or its authorized service agencies;
c) the serial number or date code has not been removed, defaced, or otherwise changed; and
d) examination discloses, in the judgment of SETRA, the defect in materials or workmanship developed under normal installation, use and service;
e) SETRA is notified in advance of and the product is returned to SETRA transportation prepaid.
Unless otherwise specified in a manual or warranty card, or agreed to in writing and signed by a SETRA officer, SETRA pressure and acceleration products shall be warranted for
one year from date of sale.
The foregoing warranty is in lieu of all warranties, express, implied or statutory, including but not limited to, any implied warranty of merchantability for a particular purpose.
SETRA’s liability for breach of warranty is limited to repair or replacement, or if the goods cannot be repaired or replaced, to a refund of the purchase price. SETRA’s liability for all
other breaches is limited to a refund of the purchase price. In no instance shall SETRA be liable for incidental or consequential damages arising from a breach of warranty, or
from the use or installation of its products. 7

8159 Swanson Road,Boxborough,MA 01719-1304/Tel:[phone]/
Fax [phone]/Email:[email protected],Web:www.setra.com
SS2036 Rev.D 08/24/04
Setra Systems,Inc.
159 Swanson road
Boxborough,MA 01719
Repair Dept.Fax #:[phone]/Phone #:[phone]
✮ All lines must be filled out.
✮ This form must accompany all returns.Returns that arrive with no information will be rejected.
CONTACT NAME: EMAIL ADDRESS:
COMPANY: DATE:
PHONE NUMBER: FAX NUMBER:
PURCHASE ORDERWITH“NOT TO EXCEED”AMOUNT CREDIT CARD #,EXP.DATE / CARDHOLDER NAME:
MODEL / PART # AND QTY: SERIAL NUMBER/S:
EXPEDITE ,1-3 days ($50 FEE) RUSH,5-7 days STDTIME,2-3 weeks
CALIBRATION ONLY CERT NEEDED FAILURE ANALYSIS
REASON FOR RETURN/DESCRIPTION OF PROBLEM:
NOTES/COMMENTS OR SPECIAL HANDLING
Any product that has been used with Hazardous Materials must be 100% purged and should be accompanied by a MSDS sheet,
bagged,sealed,and tagged accordingly.Setra will not accept delivery of any product exposed to chemicals,
radioactive agents,or biological process without evidence of decontamination or laboratory analysis, and
proof the biological process is not harmful.
Hazardous chemicals: Yes No (circle one)
List of Chemicals used:
Has unit been purged? Yes No Purged with what?
Has unit been flushed? Yes No Flushed with what?
Has unit been decontaminated? Yes No Explain Process:
All wetted surfaces have been removed: Yes No
Billing Address: Shipping Address
MethodofShipment:
(circle one) PPD: Yes Collect: Yes Please list account #
SERVICE/REPAIR/CALIBRATION ORDER RETURN FORM
