SEVENOC IDL Q1 User instructions

STAND ALONE SETTING MENU
MODEL : Q1 (IDL SERIES)
SEVENOC INTELLIGENT DIGITAL LOCK

1. Function and Operation
1) Administrator information: refers to the administrator’s Password or
Fingerprint.
2) Unlock information: refers to the input Password or Fingerprint information
(including administrators and ordinary users).
3) Key “ * ” : Clear key / Back key. Click the key three times in success exit.
4) Key “ # ” : Confirmation key or menu function key.
5) Key “ 1 ” : Add User
6) Key “ 2 ” : Delete User
7) Key “ 3 ” : Passage Mode
8) Key “ 4 ” : Silent Mode

2. Original State
1) Press and hold the setup key (behind back plate, small button at battery
area) for 5 seconds, the voice announcement “Initialization succeeded”
2) The factory administrator initial password is 123456, under the initial state,
only 123456 Password can open the lock, and any Fingerprint can open the
lock.
3) Once the new administrator Password or Fingerprint has been set, any
Password and unknown Fingerprint cannot open the lock.
3. Register Administrator (Passcode, Fingerprint) - up to 3 administrators
- Initial password: 123456
i) password
- new administrator password: Ex: * # 147258 #
- enter new administrator password 2 times
ii) fingerprint
- place USER FINGER to the Sensor on the Digital Lock 2 times
Press * # 123456 # new admin passcode #
Press * # 123456 # Place USER FINGER to the Sensor on the Digital Lock

4. Add User (Password, Fingerprint, Remote Control) Settings
- “ 1 “ – Add user
i) Add Password
- new administrator password: 147258
- user password: Ex: * # 147258 # 1 741852 #
- enter user password 2 times
ii) Add Fingerprint
- place USER FINGER to the Sensor on the Digital Lock 2 times
iii) Add Remote Control
5. Delete User (Password, Fingerprint, Remote Control) Settings
i) “ 2 “ - Delete User
- new administrator password: 147258
- no user information: 2, 3, 4
- Ex: * # 147258 # 2 3 #
Press * # 147258 # 1 enter user password #
Press * # 147258 # Place USER FINGER to the Sensor on the Digital Lock
Press * # 147258 # 1 press Remote Control Button
Press * # 147258 # 2 enter no user information #

6. Enable Passage Mode Settings
i) “ 3 “ – Passage Mode
- new administrator password: 147258
- Ex: * # 147258 # 3
7. Disable Passage Mode Settings
ii) “ 3 “ – Passage Mode
- new administrator password: 147258
- Ex: * # 147258 # 3
Note: After the normally open mode is turned on, each unlock is normally open, and it
will not be automatically closed. It is necessary to unlock the lock manually once.
Press * # 147258 # 3
Press * # 147258 # 3

8. Enable Silent Mode Settings
iii) “ 4 “ – Silent Mode
- new administrator password: 147258
- Ex: * # 147258 # 4
9. Disable Silent Mode Settings
iv) “ 4 “ – Silent Mode
- new administrator password: 147258
- Ex: * # 147258 # 4
Note: After the silent mode is turned on, each unlocking process is muted.
Press * # 147258 # 4
Press * # 147258 # 4

10. Other Notes
1) Input the wrong password more than 5 times in a row, the keyboard lock for
1 minute, it does not respond to any operation within 1 minute.
2) Password peeping prevention function: input password as follows when
opening the door with password: XXX password XXX; you can add some
numbers before and after the password, and then press # to confirm. The
password must be included in the input contents.
3) If there is no operation more than 12 seconds and no action, system will
automatically exit.
4) When the voltage is lower than 4.8v, the lock will automatically alarm every
time when it is opened. After the alarm, the lock can be opened for 200 times.
After 200 times, unlocking will be delayed, be sure to replace new batteries
before this situation.
5) Initial state: enter “ 555666888# “ language switch, support both Chinese and
English.
11. Technical Parameters
Technical Parameters
Items Parameters Memo
1 Power Supply 4.5V – 6.5V (4 dry batteries)
2 Quiescent Current <55mA
3 Working Current <250mA
4 Fingerprint Users <=300
5 Password Users <=300
6 Open Door Remote
Control
<=120
7 Working Temperature -10°C ~ 60°C
8 Working Relative Humidity 20% ~ 93% RH
9 Passcode Length 6 Digit
10 Phantom Passcode 16 Bit
11 Low voltage Alarm 4.8 ± 0.2V
12 Unlock Time ≤1 Minute
