SEVENOC M3F User manual

SEVENOC DIGITAL LOCK STAND ALONE SETTING MENU
MODEL : M3F

1. Function and Operation
1) Administrator information : refers to the administrator’s Passcode or SEVENOC
RFID Card.
2) Unlock information : refers to the input Passcode or SEVENOC RFID Card
information (including administrators and ordinary users).
3) Key “*” : Clear key / Back key. Click the key three times in success exit.
4) Key “#” : Confirmation key or menu function key.
2. Original State
1) The factory administrator initial passcode is 123456, under the initial state any
Passcode or SEVENOC RFID Card can open the lock.
2) Once the new administrator Passcode or SEVENOC RFID Card has been set,
any Passcode and unknown RFID card cannot open the lock.

3. Modify Administrator Passcode
Initiate State
Input “ *12 “ and press
confirmation key, “ # “
(enter *12#)
Input 123456 and
press “ # “
(enter 123456#)
Input new
administrator Passcode
and press “#”
(enter 456789#)
Enter again new
administrator Passcode
and press “ # “
(enter 456789#)

4. Add User (Passcode, SEVENOC RFID Card) Settings
a) Add Passcode
b) Add SEVENOC RFID Card
Input “ *85 “ and
press “ # “
(enter *85#)
Input
administrator Passcode
and
press confirmation key, “ # “
(enter 456789# )
(enter *12#)
Input Passcode and press “ # “
(enter 147258#)
Enter again Passcode
and press “#”
(enter 147258#)
Input “ *85 “ and
press “ # “
(enter *85#)
Input administrator Passcode and
press confirmation key, “ # “
(enter 456789# )
(enter *12#)
Place SEVENOC RFID Card
against the Card Reader Sensor
on the Digital Lock
Sound “BEEP” for three
times
Operation successful

c) Add Fingerprint
Input “ *85 “ and
press “ # “
(enter *85#)
Input administrator Passcode and
press confirmation key, “ # “
(enter 456789# )
(enter *12#)
Place USER FINGER to the
Sensor on the Digital Lock
Sound “BEEP” for three
times
Operation successful

5. Delete All User (Passcode, SEVENOC RFID Card) Settings
a) Delete All User Passcode Information
b) Delete All User Card Information
Input administrator Passcode and
press confirmation key, “ # “
(enter 456789# )
Input “ *71 “ and press
Confirmation key, “ # “
(enter *71#)
Operation successful
Input administrator Passcode and
press confirmation key, “ # “
(enter 456789# )
Input “ *69 “ and press
Confirmation key, “ # “
(enter *69#)
Operation successful

c) Delete All User Fingerprint Information
Input administrator Passcode and
press confirmation key, “ # “
(enter 456789# )
Input “ *70 “ and press
Confirmation key, “ # “
(enter *69#)
Operation successful

6. Other Notes
1) Input the wrong passcode more than 5 times in a row, the keyboard lock for
30 seconds, it does not respond to any operating system in 30 seconds.
2) Passcode peeping prevention function : input passcode as follows when
opening the door with passcode : XXX passcode XXX; you can add some
extraneous codes before and after the passcode, and then press # to confirm.
The passcode must be included in the input contents.
3) If there is no operation more than 10 second, system will automatically exit.
4) After the voltage is lower than 4.8v, the lock will automatically alarm every time
when it is opened. After the alarm, the lock can be opened for 200 times. After
the number of times exceeds, each unlock delay is 5 seconds, new batteries
must be replaced before the number of times available.
7. Technical Parameters
Technical Parameters
Items Parameters Memo
1 Quiescent Current ≤50uA
2 Dynamic Current ≤180mA
3 Administrator’s Number 9
4 Passcode + Card Capacity 300
5 Power Type 6V
6 Emergency Powering 5VDC
7 Working Temperature -25°C ~ 60°C
8 Working Relative Humidity 20% ~ 90% RH
9 KBD Touch Standard 12 – Bit Keyboard
10 Passcode Length 6 - 8 Bit
11 Phantom Passcode 16 Bit
12 Low voltage Alarm 4.8 ± 0.2V
13 Unlock Time ≤1 Second
