HuTools HT02 User manual
HuTools HT02
Installation Guide
PLEASE KEEP THIS GUIDE
This guide contains important information about your lock.
backset
60 or 70 mm
35 mm to 50 mm
A B C D
1"
25 mm
1Prepare the door and check dimensions
Measure to confirm that the hole in the door
is 2-1/8" (54 mm)
Measure to confirm that the backset is
either 2-3/8" or 2-3/4" (60 or 70 mm)
Measure to confirm that the the hole in
the door edge is 1" (25 mm)
Measure to confirm that the door is 1-3/8"
to 2" (35 mm or 50 mm)thick
Latch Exterior Assembly
Battery Cover
Strike
A
E
K
F
G
BCD
Parts List
Drive-In Collar
Latch and
Strike Screws
Mounting Plate
Interior Assembly
Screws
Interior
Assembly
Mounting Plate
Screws
L
Backup Key
H
I
1 / 6
2-3/8" or 2-3/4"
1-3/8" to 2"
54 mm
2-1/8"
J
Installation Guide
Latch/Strike
Screws(I)
Reinforcement
Screws(H)
Strike
Mounting
Screws(J)
Mounting
Plate
Screws(K)
Battery
Cover
Interior
assembly
Exterior
Assembly
Latch
A B C
D
2Install the latch and strike
B
A
Is the door edge chiseled?
Is the slotted hole centered in the door hole?
Hold the latch in front of the door hole, with
the latch face flush against the door edge
YES
YES
NO
NO
Install latch in door with
supplied screws.
No adjustment is
required. Proceed
to next step.
Slotted hole is centered. Slotted hole is NOT centered.
Rotate and pull the
latch as shown
to extend latch.
Use a screwdirver to test if deadbolt works smoothy.
chiseled not
chiseled
IMPORTANT: Make sure hole in door frame
is drilled a minimum of 1" (25 mm) deep.
I
HC
or
or
Use a flathead screwdriver to remove
Rectangular face from latch and install
drive-in collar.
Install strike on the door frame
1
φ2-3/4”
(70mm)
2
1
2
3
4
Install latch in door with wood
block and hammer.
Fingerprint
Sensor
2 / 6
3Install exterior assembly
AIMPORTANT: Before installation, make sure the latch is fully retracted (in the unlocked position) . Route the cable below the latch
B
Secure the mounting plate with the supplied screws.
D
J
Keep Parallel to door edge.
unlocked
Insert the torque blade
through the slot in the latch.
Send the cable through the bottom horizontal slot in the mounting plate.
C
Eunlocked
4Install interior assembly
Connect the cable and ensure tight cable connection.
BRotate the turnpiece in vertical position and the torque
blade in horizontal position, make sure the latch is
still fully retracted (in the unlocked position).
C
Test operation using backup key and thumbpiece
for smooth rotation.If turnpiece doesn’t rotate,
repeat step 4C, making sure the turnpiece in vertical
position, and touque blade in horizontal position.
D
IMPORTANT: Do not load batteries until lock is completely installed.
Remove the battery cover.
Locate the slot at the bottom and use your fingernail or a
flat head screwdriver to pry the cover up and pull it off.
A
Secure the interior assembly
with the supplied screws.
E
K
Horizontal
G
F
5Detect left/ right hand door installation
While the door is OPEN and UNLOCK, load 3 AA batteries
into the interior assembly. For best results, use new,
non-rechargeable Alkaline batteries only.
Press and hold the Reset button on the interior assembly
using a pen or a paper clip.
Reset the lock to teach the lock the orientation of the door.
APress and hold the Reset button on the interior assembly
using a pen or a paper clip.
BLoad the last battery and keep holding the reset button
for 3 seconds, until you hear the sound of “beep”. The
latch bolt will extend to learn the orientation of the door.
C
IMPORTANT: This step is required and crucial for the lock to operate properly.
unlocked
3 / 6
Information & Safety Warnings
Protect your User Codes and Master Code.
Restrict access to your lock’s interior assembly and routinely check your settings to ensure they have not been altered
without your knowledge.
This lockset is designed to provide the highest standard of product quality and performance. Care should be taken to ensure
a long-lasting finish. When cleaning is required use a soft, damp cloth. Using lacquer thinner, caustic soaps, abrasive
cleaners or polishes could damage the coating and result in tarnishing.
IMPORTANT: Do not load batteries until lock is completely installed.
123456789
A.
123456789
B.
222222222
C.
3865
D. If
Then
and
Forward number sequence
Backward number sequence
Repeat number sequence
38 1965
19 3865
Contain existing code sequence
1. Master Code( 4 to 10 digits) : The default Master Code is 12345678. It is required that you change it to a code of your
own before programming.
2. User Code(4 to 10 digits) : A total of 20 User Codes (and one temporary one-time User Code) may be programmed.
3. Both master and user pin codes don not support the following combination of numbers.
Programming Instructions
How To Use
UNLOCK the door with fingerprint ID
UNLOCK the door from outside LOCK the door from outside
LOCK the door from inside
Master/ User
code
Touch and hold the
Sensor with your finger
to unlock the lock.
Auto Re-lock Mode
In Auto re-lock mode, the bolt will
extend out automatically in 30 seconds
after unlocking.
Manual Mode
Press any key on keypad for 2 seconds.
Auto Re-lock Mode
In Auto re-lock mode, the device
will be locked automatically.
UNLOCK the door from inside
Rotate the thumb turn to
Unlock position.
Manual Mode
Rotate the thumb turn to Lock position.
Item Specifications Remarks
AA alkaline battery x4
(Operation voltage: 4.6~6.0V)
Last up to one year
(10 times open/close per day)
Parts Illustrations
The default Master Code is 12345678. It is required that you change it to a code of your own before programming.
4 / 6
Interior Assembly
Exterior Assembly
Keypad
Multi-function
Button
Fingerprint
Sensor
Battery Cover
Reset Button
Thumb Turn
Battery
(Use new, non-rechargeable
Alkaline batteries only.)
Definitions
Master Code
Required for programming and feature settings. Master
code can be used to unlock the door under vacation
mode. The default master code needs to be changed
before programming.
Property owner/ manager should keep this information
confidential.
Auto Lock
Automatically locks the deadbolt 30 seconds after
unlocking. This feature is off by default. You can set
the Auto Lock time delay between 10 and 99 seconds.
Wrong Entry Limit
After 10 unsuccessful attempts at entering a valid PIN
code, the unit will shut down for 3 minuets.
Silent Mode
The beep sounds when pressing keypad can be muted.
But you will still hear low battery and system alerts.
Vacation Mode
This is a security feature for you when you are leaving
your home for vacation or long trip. Enabling vacation
mode will restrict all user codes until master code is
entered on keypad. If the lock is unlocked by thumb
turn, the lock will sound an alarm.
One Time User Code
This code can only be used once and is automatically
deleted when used.
Unlock with Fake code
User can prevent pin code exposure from strangers by
entering random digits before or after pin code.
83618 137192 14710
password
Random digits
5 / 6
Quick Set Up
Notes:
When setting is unsuccessful, the indicator light will flash red.
IMPORTANT: The default Master Code is 12345678. It is recommended that you change it to a code of your own.
6 / 6
Factory Default Settings
The turnpiece cannot rotate or operate the lock.
Remove and re-install the lock, making sure that the turnpiece is in vertical position.
The lock cannot be locked or unlocked by the keypad.
Make sure that the codes are not disabled. If needed, restore the lock’s default settings.
The keypad doesn’t respond when touched ( no lights are visible and no beeping is heard) .
Make sure the cables are properly connected, and make sure the batteries are new and installed correctly.
After the installation of the batteries, there is no response when you press any button and no beeps are heard.
Check the cable connection and the polarity of the batteries. Also make sure the batteries are not dead.
I forgot my Master Codes.
Perform a reset in order to erase all passcodes. Once the reset is complete, all passcodes will be erased and the Master code
will return to the default value ( 12345678) .
Troubleshooting
Settings Factory Defaut
Master Code
Auto Lock
Silent Mode
Wrong Code Entry Limit
Shutdown Time
Vacation Mode
12345678
Disabled
Disabled
10 times
3 mins
Disabled
1. Keep the door open and unlock.
2. Press and hold the Reset button, at the same time take out one battery and then place it back.
3. Keep holding the Reset button for 3 seconds, until you hear the sound of beep.
Restore To Factory Default Settings
This procedure will delete all User Codes associated with the lock.
1. Make sure that the Sensor and your finger are clean and dry;
2. Touch and hold the Sensor with your finger until you hear a short beep;
3. Lift and rest your finger, making small adjustments to the position of your finger each time;
3. The Sensor needs to scan your fingerprint 8 times and storages all the information locally and safely.
How to set up fingerprint ID
* If none of the above resolves your issue, check out our updated user manual by scanning the code below. You could also
