sewerin UT 9200 User manual

17.03.2023 a –108791 –en
UT 9200/9100
Operating instructions

Battery compartment
Fig. 1: Receiver
Port for accessories
Headphonesocket
Loudspeaker
USB port
Volume key
Light sensor
Up key
key
y key
Antennas
Frequenc
Down key
Mode key
Fig. 2: Receiver control panel
Receiver UT 9200/9100 R
Handle
Display
Control panel
Arrow keys

Display
Control panel
Loop for carrying strap
USB port
Port for accessories
Battery compartment
Fig. 3: Generator
Volume key
Frequency key f+
Frequency keys
Power key
Fig. 4: Generator control panel
Frequency key f-
Generator UT 9012/9005 TX

Illustration of warnings in this document
AWARNING!
Risk of personalinjury.Couldresultin seriousinjuryor death.
ACAUTION!
Risk of personal injury. Could result in injury or pose a risk
to health.

Contents │I
1
1.1
1.2
1.3
1.4
1.5
Introduction .............................................................................1
Information about this document...............................................1
Purpose.....................................................................................2
Intended use .............................................................................2
Safety information.....................................................................2
Safety information for lithium-ion rechargeable battery.............4
2
2.1
2.2
System overview.....................................................................5
General information...................................................................5
System components..................................................................5
3
3.1
3.2
3.3
3.4
3.4.1
3.4.1.1
3.4.1.2
3.4.1.3
3.4.1.4
3.4.1.5
3.4.2
3.4.3
3.5
3.6
Receiver UT 9200/9100 R........................................................8
General information...................................................................8
Location modes and antennas ..................................................8
Control panel ...........................................................................10
Measuring mode and menu....................................................13
Display in measuring mode..................................................13
Approaching a location object (compass).........................14
Field strength display........................................................16
Gain display......................................................................16
Depth display....................................................................17
Toolbar ..............................................................................18
Display with main menu.......................................................18
Navigating the menus..........................................................19
Satellite connection.................................................................20
Power supply...........................................................................20
4
4.1
4.2
4.2.1
4.2.2
4.2.3
4.2.4
4.2.4.1
4.2.4.2
4.2.4.3
4.2.4.4
4.2.4.5
Receiver menus.....................................................................22
Main menu (overview).............................................................22
Configuration menu.................................................................22
Frequencies .........................................................................22
Modes..................................................................................22
Antennas..............................................................................23
Settings................................................................................23
Language..........................................................................23
Units..................................................................................24
Backlight............................................................................24
Shutdown Timer................................................................24
Communications...............................................................24

II │Contents
4.2.5
4.2.5.1
4.2.5.2
4.2.5.3
4.2.5.4
4.2.5.5
4.2.5.6
4.3
4.4
4.5
4.6
4.7
Options.................................................................................26
Audio.................................................................................27
Gain...................................................................................27
L/RArrows.........................................................................28
Autodepth..........................................................................29
Offset Depth......................................................................29
User Interface....................................................................30
Utility Type menu.....................................................................30
Metrics menu...........................................................................30
System Info menu...................................................................31
Ambient Noise menu...............................................................31
TX Control menu.....................................................................31
5
5.1
5.2
5.3
5.4
5.4.1
5.4.2
5.4.3
5.5
5.5.1
5.5.2
6
6.1
6.2
6.3
6.3.1
6.3.2
6.3.3
6.3.4
6.4
6.4.1
6.4.2
6.4.3
6.5
Generator UT 9012/9005 TX..................................................32
General information.................................................................32
Operating modes.....................................................................32
Control panel...........................................................................33
Transmitting mode and menu..................................................34
Display in transmitting mode................................................34
Display with main menu.......................................................36
Navigating the menus..........................................................36
Power supply...........................................................................37
Powered by batteries...........................................................38
Powered by lithium-ion rechargeable battery.......................39
Generator menus ..................................................................40
Main menu (overview).............................................................40
Frequencies menu ..................................................................40
Settings menu.........................................................................40
Backlight...............................................................................40
Output..................................................................................41
Meter....................................................................................43
Communications ..................................................................44
Options menu..........................................................................45
Language.............................................................................45
Shutdown Timer...................................................................45
Fault Mode...........................................................................46
System Info menu...................................................................46

Contents │III
7
7.1
7.1.1
7.1.2
7.2
7.3
7.3.1
7.3.2
7.4
7.5
7.6
7.7
7.7.1
7.7.2
7.7.3
7.8
7.8.1
7.8.2
7.8.3
7.8.4
7.9
Using the system ..................................................................47
Establishing a radio connection between devices...................47
Linking the receiver and generator.......................................47
Unlinking the receiver and generator...................................48
Adjusting the volume or switching off the sound.....................48
Setting the frequency..............................................................49
Enablingfrequencies............................................................50
Selecting a frequency...........................................................50
Adjusting the gain....................................................................51
Controlling the generator with the receiver (TX Control).........52
Ambient noise detection..........................................................53
Determining the depth.............................................................54
Determining the depth automatically....................................55
Determining the depth manually..........................................55
Determining the offset depth................................................56
Evaluating saved locating results externally ...........................57
Saving a measurement........................................................58
Connecting the receiver to a Bluetooth-enabled device.......58
Unpairing the receiver and Bluetooth-enabled device .........59
Reading out measurements.................................................59
Configuring or updating the receiver and generator via the
software...................................................................................60
8
8.1
8.1.1
8.1.1.1
8.1.1.2
8.1.2
8.1.2.1
8.1.2.2
8.2
8.3
8.4
Active locating of lines.........................................................61
Energisinga line......................................................................61
Direct energising..................................................................61
Enabling/disabling the connected cable set......................63
Parallel connection (splitter cable)....................................63
Indirect energising................................................................65
Energising without accessories on the generator.............65
Energising with a cable clamp...........................................66
Locating a line.........................................................................67
Using direction detection.........................................................68
Energising with a high power..................................................70
9 Active locating of beacons...................................................72
10 Passive locating....................................................................75

IV │Contents
11
11.1
11.1.1
11.1.2
11.2
11.2.1
11.2.2
11.2.3
11.2.4
11.2.5
11.3
11.4
Locating with special accessories......................................77
Step-voltage probe (locating cable faults)...............................77
Approaching a cable fault.....................................................78
Locating cable faults............................................................79
Marker ball antenna (locating a marker).................................80
General information..............................................................81
Connecting the receiver and marker ball antenna ...............83
Locating marker with known frequency ................................84
Locatingunknown marker....................................................85
Disconnecting the receiver and marker ball antenna ...........85
Receiver clamp (locating cable bundle)..................................86
Receiving antenna (locating single leads)...............................87
12
12.1
12.1.1
12.1.2
12.1.3
12.2
12.3
12.4
12.4.1
12.4.2
12.4.3
13
13.1
13.1.1
13.1.2
13.2
13.2.1
13.2.2
13.3
13.4
Maintenance and error management ..................................90
Lithium-ion rechargeable battery (generator)..........................90
Storingrechargeable batteries.............................................90
Charging the rechargeable battery.......................................90
Handling faulty lithium-ion rechargeable batteries...............91
Care ........................................................................................92
Servicing.................................................................................92
Solving problems.....................................................................93
Source of errors during the locating process.......................93
Problems with the receiver...................................................94
Problems with the generator................................................95
Appendix................................................................................96
Technical data.........................................................................96
Receiver UT 9200/9100 R....................................................96
Generator UT 9012/9005 TX................................................97
Preset frequencies (factory settings).....................................100
Receiver UT 9200/9100 R..................................................100
Generator UT 9012/9005 TX..............................................101
Symbols (meaning)...............................................................102
Connecting or linking devices? Difference between radio
and Bluetooth connection......................................................106
Accessories and consumables..............................................106
Declaration of conformity ......................................................107
FCC Compliance Statements................................................107
Advice on disposal................................................................108
13.5
13.6
13.7
13.8
14 Index.....................................................................................109

1 Introduction │1
1 Introduction
1.1 Information about this document
This document is a component part of the product.
●Read the document before putting the product into operation.
●Keep the document within easy reach.
●Pass this document on to any subsequent owners.
●Unless otherwise specified, the information in this document
refers to the product as delivered (factory settings) and applies
to all product variants.
●Contradictory national legal regulations take precedence over
the information in this document.
Note:
These operating instructions describe systems UT 9200 and
UT 9100.
The included components only differ slightly with regard to
functionality and some performance features. All of the functions
are described in the operating instructions even if they are not
available for individual product variants. Information about
the differences between the product variants is available in
section 3.1 and section 5.1.
The descriptions refer to the system as delivered (factory
settings).
Translations
Translations are produced to the best of our knowledge. The
original German version is authoritative.
Right of reproduction
No part of this document may be edited, duplicated or circulated
in any form without the express consent of Hermann Sewerin
GmbH.

2 │1 Introduction
Registered trademarks
Registered trademarks are generally not indicated in this
document.
1.2 Purpose
UT 9200/9100 is an electronic locating system to detect
electrically conductive, underground lines.
The system can be used for:
●Locatingand tracking lines
Linesreferto current-conductingand signal-transmittingcables
as well as supply lines, for example.
●Determining the depth of lines
1.3 Intended use
The product is suitable for the following uses:
●Professional
●Industrial
●Commercial
The product must only be used for the applications specified in
section1.2.
Note:
Specialist knowledge is required to operate the system. Work
on electrical installations may only be completed by trained
specialists.
1.4 Safety information
This product was manufactured in accordance with all binding
legal and safety regulations.
The product is safe to operate when used in accordance with the
instructions provided. However, when handling the product, there
may be risks to persons and property. For this reason, observe
the following safety information without fail.

1 Introduction │3
●Observe all the applicable safety standards and accident
prevention regulations. This particularly applies to work on
electrical systems (e.g. current-carrying cables).
●Use the product only as intended.
●Handle the product carefully and safely, both during transport
and when working.
●Do not make any changes or modifications to the product
unless these have been expressly approved by Hermann
Sewerin GmbH.
●Do not use the product if it is damaged or faulty. Never use
damaged or defective accessories.
●Only use accessories and consumables approved by Hermann
Sewerin GmbH.
If not described otherwise: Standard batteries or rechargeable
batteries can be used for the power supply of the products.
●At the same time, always use power sources that are identical
in terms of type (battery or rechargeable battery), capacity,
manufacturer, charge and state (new or used).
●Always observe the permitted operating and storage
temperatures.
●Before starting the location work obtain information about the
route of buried cables and lines from local utility companies.
●Always adequately cordon off the work area.
●Never operate the product in the vicinity of explosive areas.
●Protect the ports and sockets on the product against dirt, and
electrical ports in particular against moisture.
●Do not submerge the product in liquids.
●When you are wearing headphones, you are not fully
aware of ambient noise. Be especially vigilant, especially in
environments with an increased risk of accident (e.g. traffic).
●Only set the volume as high as absolutely necessary. Excessive
noise can cause permanent damage to your hearing.

4 │1 Introduction
1.5 Safety information for lithium-ion rechargeable battery
●Risk of short circuit! Do not touch the power connector poles
with metal.
●Never try to open the rechargeable battery.
●Do not use the rechargeable battery if it is damaged.
●Prevent the ingress of moisture into the rechargeable battery.
●Protect the rechargeable battery from mechanical loads
(impact, vibration). Never drop the rechargeable battery.
●Observe the permissible conditions during charging, storage
and operation. Protect the rechargeable battery against
very low and high temperatures even when these are in the
permissiblerange.
●Only charge the rechargeable battery using the relevant AC/
DC adapter.
●Never place the rechargeable battery on an open fire.
●Dispose of the rechargeable battery in accordance with
applicableguidelines.

2 System overview │5
2 System overview
2.1 General information
System UT 9200/9100 can be used for active and passive
locating. During active locating the required electromagnetic field
is generated with a generator. During passive locating existing
electromagnetic fields are used.
SEWERIN recommends: Always check the plausibility of the
system’s locationresults.
2.2 System components
The system has a modular construction. The main system
components are as follows:
UT 9200 system UT 9100 system
Receiver
UT 9200 R UT 9100 R
Generator
UT 9012 TX or UT 9005 TX
Software
UT configurator
App
UT 9200 Com –
The receiver and generator can be transported and stored in
bags.
Information about the receiver can be found in section 3 and the
generator in section 5.
Accessories
Accessoriescanbe addedto thesystematanytime,forexample:
●active locating of lines
−double cable set (splitter cable) or simple
−earthing spike
−cable clamp
●active locating of beacons
−beacon (locating transmitter)
−fibre glass rod

6 │2 System overview
●special locating tasks (only UT 9200 R)
−step-voltage probe
−marker ball antenna
−receiver clamp
−receiving antenna
UT configurator software
The UT configurator software can be used to update and
efficiently configure the receiver and generator.
The software can be used to execute the following tasks, for
example:
●update firmware
●preset, activate frequencies
●create own frequencies (in addition to available ones)
●configure the device (receiver, generator)
●set up the start screen (e.g. company logo as background)
●save individual settings and load again at a different point in
time
Prerequisites for using the software:
●software is installed on a computer
●device is connected to the computer via a USB cable
The software can be downloaded free of charge from
www.sewerin.com.
Information on updates and configurations is provided in
section7.9.

2 System overview │7
UT 9200 Com app
Note:
The app is only available for receiver UT 9200 R.
TheUT 9200Com appis designedforthesubsequentevaluation
of saved measurements.
Theapp canbe usedto executethefollowingtasks,forexample:
●read out receiver measurements
●view measurements in the app's map view
●transfer data, for example, by e-mail to another device so that
the measurements can be saved there
Prerequisites for using the app:
●app is installed on a Bluetooth-enabled device
●receiver and Bluetooth-enabled device are connected
The UT 9200 Com app is available free of charge for Android
and iOS.

8 │3 Receiver UT 9200/9100 R
3 Receiver UT 9200/9100 R
3.1 General information
The receiver can detect signals from electromagnetic fields.
Signals are reproduced:
●visually on the display
●audibly via the loudspeaker or headphones
The field strength is shown graphically and numerically on the
display. The direction arrows and other graphical elements help
when approaching the location object just like the audible sound
and special signal tones.
The volume set for the loudspeaker or headphones does not
affect the sensitivity of the receiver, i.e. loud signals are not
necessarily strong signals.
You will find an overview of the receiver parts inside the front
cover (fig. 1).
Product variants
Receiver
UT 9200 R UT 9100 R
for
system UT 9200 UT 9100
Differences
●
GNSS module for position
determination
●
measuring data memory
●
Bluetooth for external
GNSS
●
app to evaluate saved
measurements
●
accessories for special lo-
cating tasks available
–
3.2 Location modes and antennas
Different location modes can be used during active and passive
locating. Different antennas can be selected based on the
locating mode.

3 Receiver UT 9200/9100 R │9
Locating
method
Locating
mode
Antenna
active
Line Twin
Single
Null
Autogain
Single
Beacon Total Field
passive
Power
Twin
Single
Null
Radio Twin
Locating mode
Locating
mode
Suitable
locating objects
Line
●
lines that are energised by a generator
Features:
–
manual or semi-automatic gain control
–
several antennas can be used
Autogain
●
lines that are energised by a generator
Features:
–
automatic gain control
–
only Single antenna can be used
–
special audible signal
Power
●
live cables
–available network frequencies:
50 Hz, 100 Hz, 150 Hz (Europe)
or 60 Hz, 120 Hz, 180 Hz (North
America,
amongst others)

10 │3 Receiver UT 9200/9100 R
Locating
mode
Suitable
locating objects
Beacon
●
non-metallic lines into which a beacon (lo-
cating transmitter) is inserted
Radio
●
metal lines
–frequency range 11.6 –31.4 kHz (VLF
range)
Antennas
Antenna
Description
Twin
●
to determine the position of a line using
maximum mode
In
comparison to a Single antenna:
–
lower range
–
higher degree of accuracy
Single
●
to determine the position of a line using
maximum mode
In
comparison to a Twin antenna:
–
greater range
–
lower degree of accuracy
Null
●
to determine the position of a line using
minimum mode (null signal)
Feature:
–
significantly more distinct signal curve over
the line
Total
Field
●
for the exact location of a beacon (locating
transmitter)
3.3 Control panel
Youwill find an overview of the control panel elements inside the
front cover (fig. 2).
Thelightsensoris designedtoautomaticallycontrolthebacklight.

3 Receiver UT 9200/9100 R │11
The keys have several functions. Symbols next to the keys
illustrate the additional functions.
Volume
key
On/Off ●switching on the receiver
–press and hold the key
●switching off the receiver
–press and hold the key
Volume In measuring mode:
●adjust volume or switch off
sound
–briefly press key repeatedly
Exit the
menu
In the menu:
●exit menu and switch directly to
measuring mode
–press the key
Mode
key
Locating
mode In measuring mode: ●select locating mode
–briefly press key repeatedly
Depth In measuring mode:
●determine depth manually
–press the key until there is
an
Back audible signal tone
In the menu:
●switch back to the next level
up
–briefly press the key

12 │3 Receiver UT 9200/9100 R
Up
key
Gain In measuring mode:
●increase gain
–in semi-
automati
mode: press the
To top
–in manual gain
co
press the key se
In the menu:
●move to top
c gain control
key
ntrol mode:
veral times
–press key repeatedly
Down
key
Gain In measuring mode:
●decrease gain
–in semi-
automati
mode: press the
To bottom
–in manual gain
co
press the key se
In the menu:
●move to bottom
c gain control
key
ntrol mode:
veral times
–press key repeatedly
Antenna
key
Antenna In measuring
mode:
●select antenna
–briefly press
key
Menu In measuring
mode:
●open menu
repeatedly
–press and hold the key
