SGW6008 BLE-WiFi Gateway
User Manual
September 2020 V1.2

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential
Contents
1. Introduction
1
2. SGW6008 BLE-WiFi Gateway
2
a. Exterior
b. Specifications
2
3. Provisioning Procedures
a. AP Mode Configuration
3
b. WiFi Network Configuration for SGW IoT Platform
4
c. Gateway Provisioning
5
4. Edge Device Provisioning
6
5. Certification
7
6. Revision History
9

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 1
1. Introduction
The robust SGW6008 BLE-WiFi Gateway enables Bluetooth Low Energy (BLE) to WiFi connectivity without
using an external smartphone or app. It collects data from BLE edge devices and sends the data over WiFi to
the local server or remote cloud server using HTTPS and MQTTS protocols with TLS1.2 standard (Figure 1,
with the edge device depicted by the SGW8130 BLE Sensor Tags).
As the connected solution for the SGW111X BLE Module and SGW8130 BLE Sensor Tag, the SGW6008
Gateway enables real-time remote monitoring or asset tracking for IoT applications, hassle-free.
IoT applications include but are not limited to:
•Industrial Smart lighting
•Smart logistics and transportation
•Smart devices for connected homes
•Smart city infrastructure
This user manual details the SGW6008 Gateway’s provisioning process for access to the SGW IoT Platform
(server), involving three procedures:
a. AP Mode configuration
b. WiFi network configuration for SGW IoT Platform
c. Gateway provisioning
This manual also describes the provisioning process of connecting the SGW6008 Gateway to an edge device.
Figure 1: Data Collection and Transmission through SGW6008 Gateway

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 2
2. SGW6008 BLE-WiFi Gateway
a. Exterior (Figure 2)
1. Micro-USB power input (5.0V DC, 1A)
2. AP mode button for network configuration with WiFi and
Gateway provisioning
3. 3 LED status indicators (Table 1)
b. Specifications
Absolute Maximum Rating
Power Supply
5.5V DC
Storage Temperature
-20°C to 80°C
Recommended Operating Conditions
Power Supply
5.0V DC
Operating Temperature
-10°C to 60°C
General
Module
SGW BLE Module
Operating System
Amazon FreeRTOS
Protocol
TCP/HTTPS/MQTTS/TLS1.2
Power Input
1A @5V DC, micro-USB interface
Certification
CE, FCC and IC certified
Size
66.75 x 65.75 x 23.5mm
BLE RF Performance
Radio Operating Frequencies
2402MHz ~ 2480MHz
Radio On-air Data Rate
1Mbps, 2Mbps
Transmit Power
10+/-2dBm
Antenna
Onboard PCB Antenna
Range
Up to 200 meters (open space)
WiFi Performance
Wireless Standard
IEEE 802.11b/g/n (single stream)
Radio Operating Frequencies
2412MHz ~ 2484MHz
Radio On-air Data Rate
IEEE 802.11b, 1 –11Mbps
IEEE 802.11g, 6 –54Mbps
IEEE 802.11n (2.4GHz), 72.2Mbps
Transmit Power
17+/-2dBm
Antenna
Onboard PCB antenna
Security
WPA/WPA2
Encryption
WEP/TKIP/AES
Power LED
BT LED
WiFi LED
Regular Operation
Power On
On
Off
Off
BT Signal Transmission
On
Flashing
Off
WiFi Signal Transmission
On
Off
Flashing
AP Mode Operation
AP Mode, Not Connected
Flashing
Off
Flashing
AP Mode, Connected
Flashing
Off
On
WiFi Configuration Success
On
Off
Flashing
Power LED
BT LED
WiFi LED
USB Power Input
AP Mode Button
Figure 2: SGW6008 BLE-WiFi Gateway
Table 1: SGW6008 LED Status Indicators

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 3
3. Provisioning Procedures
The following tools are required for the provisioning process:
•Micro-USB cable and power source
•PC or mobile device
•Stable WiFi network
•SGW6008 BLE-WiFi Gateway
a. AP Mode Configuration
1. Put the SGW6008 Gateway in AP Mode by connecting it to the power source with the micro-USB
cable.
2. Use the PC or mobile device to connect to the Gateway’s WiFi network:
Network Name: (available after Gateway purchase)
Password: (available after Gateway purchase)
3. After joining the network, use a web browser to access the SGW Gateway Configuration Platform at
http://192.168.4.1 (Figure 1).
Figure 1: SGW Gateway Provisioning Platform

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 4
b. WiFi Network Configuration for SGW IoT Platform
There are two ways to configure the WiFi network for the Gateway:
1. Input your preferred WiFi network manually (Figure 2). Enter the network name and password (if ap-
plicable), and click ‘Save WiFi Setting’ when done.
2. Scan for available WiFi networks. Click ‘Scan’for a list of available networks and enter the password
(if applicable) for your selected network. Click the ‘+’ symbol and click ‘OK’ to verify and confirm the
network in the pop-up windows (Figure 3).
Note:
The Gateway is designed to support 2.4GHz-capable WiFi networks due to the low data rate
requirements for M2M. Up to a maximum of 32 characters in the WiFi password can be supported
(excluding special characters +, “ and \).
Note:
If needed, WiFi settings can be further configured once the network has been added to the WiFi
list. Be sure to click ‘Save WiFi Setting’ when done.
•If static IP is preferred, select ‘No’ for DHCP and enter the network’s IP address, Subnet Mask
and DNS.
•Use High Priority Slot to set the connection priority of saved networks.
•Remove WiFi networks from the list by deleting the network information.
Figure 3: WiFi Connection
Figure 2: Static IP and High Priority Slot

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 5
c. Gateway Provisioning
The Gateway has to be linked to a SGW IoT Platform account for data access.
1. Enter your SGW IoT Platform username (email address) and password, and label your Gateway with a
name, location and description (Figure 4).
2. Click ‘Start Provisioning’, then click ‘OK’ to confirm Gateway provisioning in the pop-up window. The
Gateway will self-reboot, and your PC or mobile device will reconnect to its original internet network.
You will be directed to the SGW IoT Platform when provisioning is complete.
3. Login to the Platform with your username (email address) and password, and click ‘Gateways’in the
navigation bar on the left. The provisioned Gateway will appear in blue (Figure 5).
Note:
Should the LEDs remain in AP mode operation after rebooting, please disconnect the Gateway
from its power source completely and redo the provisioning procedures.
Note:
Should you wish to configure a different WiFi network for the Gateway after provisioning is com-
plete, first disconnect the Gateway from its power source, then put the Gateway back in AP Mode
by holding down the AP Mode button while reconnecting it to power. Redo the procedures in
section 3a ‘AP Mode Configuration’.
Figure 4: Gateway Provisioning
Figure 5: Provisioned Gateways

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 6
4. Edge Device Provisioning
The edge device needs to undergo a provisioning process to connect to the SGW6008 Gateway.
1. If you are not already logged in, use a browser to access the SGW IoT Platform at https://www.sg-iot.com.
Login with your username (email address) and password.
2. Click ‘Gateway’ to show all provisioned Gateways (Figure 5). Select the Gateway to which you intend to
connect the edge device.
3. Ensure that the edge device is turned on, then click ‘SEARCH NEW BLE’ to scan for all nearby edge de-
vices. Discovered devices will appear as green icons with their network names matching the labels on the
device (Figure 6).
4. Click the device to which you intend to connect the Gateway and label it with a name, location and de-
scription.
5. Click ‘SUBMIT’ to connect the device. It will now appear in the list of connected BLE Devices.
6. The edge device will start collecting data. Click the device to access the data.
Figure 6: Edge Device Connection

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 7
5. Certification
a. CE Statement
Regulatory Conformance (RED)
Hereby, (SG Wireless Limited) declares that the radio equipment type (SGW6008) is in compliance with Di-
rective 2014/53/EU.
The full text of the EU declaration of conformity is available at the following website:
https://www.sgwireless.com.
b. FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifi-
cations to this equipment. Such modifications could void the user’s authority to operate the equipment
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pur-
suant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency en-
ergy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television reception, which can be de-
termined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
oReorient or relocate the receiving antenna.
oIncrease the separation between the equipment and receiver.
oConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
oConsult the dealer or an experienced radio/TV technician for help.
oThis device and its antenna(s) must not be co-located or operating in conjunction with any other antenna
or transmitter.
c. IC Statement
This device complies with RSS-247 of Industry Canada. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouil-
lage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 8
d. RF Exposure Information and Statement
This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of 20 cm between the radiator and
your body. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.

USGC1.01-V1.2 SGW6008 BLE-WiFi Gateway User Manual
SG Wireless™ Confidential 9
Revision History
Revised
Version
Description
9-Mar-2020
1.0
Initial document release
27-Mar-2020
1.1
Provisioning section update, formatting update
24-Sep-2020
1.2
Provisioning section update
