Portech MV-374 User manual

MV-374 / MV-378
VoIP GSM Gateway
User Manual
MV-374
MV-378
PORTech Co unications Inc.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

【Content】
1.INTRODUCTION .................................................................................................................1
2.FUNCTION DESCRIPTION ............................................................................................... 1
3.PARTS LIST ..........................................................................................................................1
4.DIMENSION : 30X28X4 CM ...............................................................................................2
5.CHART OF THE DEVICE .................................................................................................. 3
6.WEB PA E SETTIN ......................................................................................................... 4
7.SYSTEM INFORMATION. .................................................................................................5
8. ROUTE ..................................................................................................................................5
9.MOBILE............................................................................................................................... 12
10.NETWORK ........................................................................................................................20
11.SIP SETTIN ....................................................................................................................25
12. NAT TRANS ..................................................................................................................... 34
13.SYSTEM AUTHORITY ................................................................................................... 35
14.UPDATE............................................................................................................................. 36
15.SAVE CHAN E ................................................................................................................38
16.REBOOT ............................................................................................................................39
17. IP SETTIN ..................................................................................................................... 40
18.SPECIFICATION .............................................................................................................42
19. APPENDIX: SETUP MV-374/MV-378 WITH ASTERISK.........................................43
20.HOW TO SETUP ASTERISK TO RECEIVE CALLER ID FROM MV-374/MV-378
..................................................................................................................................................50
21. SIMPLE STEPS................................................................................................................59
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-1-
1.Introduction
MV-374/MV-378 is a 4 / 8 channels VoIP GSM Gateway for call
ter ination (VoIP to GSM ) and origination (GSM to VoIP). It is SIP
based and co patible with Asterisk. It can enable to ake 4 / 8 calls
si ultaneously fro IP phones to GSM networks and GSM network to IP
phone.
2.Function description
2.1 VoIP(SIP)、GSM conversion.
2.2 50 sets of LAN->MOBILE routes setting，50 sets of MOBILE->LAN
routes setting.
2.3 Voice response for setting and status (dial in fro obile).
2.4 Series connections to save bills.
2.5 Standard SIP(RFC2543,RFC3261) protocol，
Co unicates with other gateway or PC.
3.Parts list
Please check the parts for any issing parts. If do, please contact
our agents：
3.1 「MV-374/MV-378」ain body
3.2 Power adaptor AC-DC (110V AC – 12V DC) or (220V AC – 12V DC)
3.3 Network cable
3.4 Antenna: MV-374:1 pcs / MV-378: 2 pcs
3.5 Rack ount (co patible with 19“Rack) – option
3.6 User Manual
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-2-
(3.5)-option
4.Dimension : 30x28x4 cm
(3.1) MV-374
(3.2) MV-374
(3.4)
(3.3)
(3.1) MV-378
(3.2) MV-378
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-3-
5.Chart o the device
5.1 Antenna：Antenna connector.
5.2 WAN: RJ-45 internet connector，standard RJ-45 socket，connect to
HUB.
5.3 DC 12V：Power input.
5.4 SIM Card
5.5 LINK Indicator：Light up when network is connected.
5.6 CH3：an indicator light of VoIP3
5.7 CH4：an indicator light of VoIP4
5.8 PWR (Power LED)：Light up when power is nor al.
5.1
5.3
5.4
5.2
5.5 5.6 5.7 5.8
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-4-
6.Web Page Setting
When the IP setting is done, the operator ay setup all the rest
para eters via web page. Browse the IP address fro Internet
Explorer (e.g. http://192.168.0.100)。The following page shows up：
Enter the userna e and password for authentication. (default
userna e=voip, password=1234). The page follows when the
userna e and password are correct.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-5-
7.System In ormation.
7.1 When you login the web page, you can see the de o syste current
syste infor ation like fir ware version, co pany… etc in this
page.
7.2 Also you can see the function lists in the left side. You can use
ouse to click the function you want to set up.
8. Route
Important:
The route table -50 sets can share by two channels(1,2 ch / 3,4 ch /
5,6 ch / 7,8 ch ) . The setting,please refer 9.2 Mobile setting
ex: Mobile 1 use the route table for ite 0-24,
Mobile 2 use the route table for ite 25-49
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-6-
8.1 Mobile TO LAN Settings
The operator ay assign 50 sets of routing rule to transfer the call
inco ing fro MOBILE to LAN.
The MV-374/MV-378 will transfer to the URL according to the caller ID of
the Mobile.
*CID：
(1) ay enter the whole nu ber, e.g. 0911111111
(2) only part of the nu ber (prefix) e.g. 0911* eans any nu ber
starting with 0911 will be accepted
(3) * eans all nu bers can be accepted
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-7-
(4) N eans the calls without the CID
Please note the priority of the rules. The ite which has ore digits will
have higher priority. If the digits are the sa e, then for er one gets the
higher priority.
*URL：The IP address to transfer this call
(1) ay enter the whole IP address, e.g. 192.168.0.101 or proxy
extension or phone nu ber.
(2) If this field is blank or si ply ‘N’, it eans refuse to transfer.
(3) If an ‘*’ entered, it eans 2-stages-dialing. The call will be
answered and pro pt dial tone again to receive the IP address/sip
extension or any phone number as the destination. The caller ay
enter the IP such as 192*168*0*101#.
*If the device have register proxy server/Asterisk ,you can enter any
destination phone nu ber. Please note the proxy server/Asterisk
need to set the route of destination phone nu ber.
Exa ple:
(1) Mobile to Lan: 0932*,0911123456
MV-374/MV-378 have register proxy server/Asterisk
The proxy server/Asterisk have the route “09”
When the caller’s prefix nu ber is 0932,MV-374/MV-378 will
connect 0911123456 auto aticlly
(2) Mobile to Lan: *,*
Any caller call the MV-374/MV-378’s si ,MV-374/MV-378 will
pro pt dial tone.Caller can enter IP or sip extension or phone
nu ber.
*sip extension or phone nu ber both need to register SIP Proxy
Server or Asterisk.
*Phone nu ber, SIP Proxy Server or Asterisk need to set the route
of this phone nu ber.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

-8-
8.2 Mobile to LAN Speed Dial Settings
When you set Mobile to LAN Speed Dial Settings and Mobile to
LAN at the sa e ti e,MV-374/MV-378 will give priority to Mobile to LAN
Speed Dial Settings.
*The call will be answered and pro pt dial tone again. When the caller
ay enter the “Nu ”, syste will connect the “URL” as destination.
E.g Nu :0 Na e:test URL:192.168.0.107
When the caller hear dial tone and enter 0, syste will connect
192.168.0.107
