SG SGSBox Mounting instructions

SG SMART BOX QUICK INSTRUCTION GUIDE page 1WWW.MYSUNGLOW.COM
SMART BOX
868MHz wi
reless smart home system
Package contents:
AC Power Adaptor
SG Smart Box
Network (Ethernet) Cable
Quick Installa on Guide
INTRODUCTION
CURRENTLY FOR USE WITH
APPLE DEVICES ONLY
A
B
C
D
CD
B
A
TECHNICAL SPECIFICATIONS
Power Consump on: 2 Wa s
Input Voltage: DC 5V, 1.5A
Protec on Class: IP40
Maximum Control Devices: 30
Antenna: Built-in
Radio Frequency: 433MHz, 868MHz
Radio Control Range: 35m
Network Port: 1xRJ45
Smart Box Size: 158mm x 83mm x 30mm (HxWxD)
6.22” x 3.27” x 1.18” (HxWxD)
Factory Reset Bu on: Yes
Opera ng Environment: Indoors
Opera ng Temperature Range: -10 °C to 55 °C
Storage Temperature Range: -20 °C to 70 °C
Installa on Environment
The SG Smart Box (SGSBox) should be installed in a
central area and equal distance away from devices
that are intended to be controlled. The SGSBox can be
wall-mounted or can sit horizontally on a table. There
should be no metal objects shielding or surrounding
the unit. Other metalic objects should be at least 15 cm
away from the SGSBox. The SGSBox should not be
exposed to humid environments or extreme
temperature changes. A router must be used in order
to control the SGSBox with mobile devices (i.e. iPhone,
iPad etc.).
INDICATOR LIGHTS TURN RED WHEN ACTIVE.
Power
DC 5V
Reset Reserved
RS232
EXT1 EXT2 LAN Port
Working
Indicator
Power
Indicator
Front Indicator Lights Back Connec on Ports
(Connect to LAN
port on any wireless
router)
Download
Instructions
868MHz wi
r
eless sma
r
t home s
QUICK INSTRUCTION GUIDE
15/09/2016

SG SMART BOX QUICK INSTRUCTION GUIDE page 2WWW.MYSUNGLOW.COM
STEP 1 INITIAL INSTALLATION OF SMART BOX
ENSURE DHCP IS ENABLED ON THE ROUTER (CONSULT YOUR NETWORK ADMINISTRATOR OR DEVICE MANUFACTURER FOR SUPPORT).
A
B
Connect the Power Supply to the Power Outlet then the Power adapter to the Smart Box.
Connect the LAN port on the Smart Box to an empty numbered port on the Wireless Router.
Wait  ll the power indicator light turns red on the SG Smart Box, then proceed to Step 2.
STEP 2 INSTALL THE APP ON APPLE DEVICE
ID SmartHouse
Go to the App store and download the free app on either your iPhone
or iPad.
LOGGING ON
STEP 3
A B
A
D
B
C
Check the “Auto Login” box to automa cally login next
 me the app is opened.
Check the “Save Password” box to retain your
password for the next  me you login.
Enter the Username (admin) and Password (123456).
Click “OK” to Login.
D
B C
A
