SGS SC8H User manual

FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
OWNER’S MANUAL
SC8H
AIR COMPRESSOR

PAGE 3
PAGE 2
1. Pressure switch
2. Regulator
3. Output pressure gauge
4. Tank pressure gauge
5. Safety valve
6. Return valve
7. Drain cock
8. Feet
9. Air reciever
10. High pressure pipe
11. Pump
12. Shroud
Model SC8H
Power 1 kW / 1.1 HP
Voltage 230 V @ 50 Hz
Motor Poles 2 P
Rated Speed 3450 rpm
Delivery 5.5 cfm
Discharge Pressure 116 psi / 0.8 MPa
Tank Capacity 8 L
Dimensions 510 x 250 x 510 mm
Net Weight 16 kg
Noise Specification LWA 97dB
WARNING SYMBOLS
READ THIS INSTRUCTION MANUAL CARE-
FULLY BEFORE OPERATING OR ADJUSTING
THE COMPRESSOR.
Risk of electric shock. The compressor must
be disconnected from the mains supply before
maintenance or removing any covers. Do not
use in a damp environment.
Risk of accidental start-up. The compressor
could start automatically in the event of a
power cut and subsequent reset. Do not carry
the compressor while it is connected to the
power source, or when the tank is filled with
compressed air.
This compressor contains surfaces which may
reach a high temperature during operation.
Never operate with the motor housing re-
moved.
Air and condensation water can burst from the
compressor when the drain plug is removed.
Wear a safety goggles and ear protectors
when using this compressor.
This compressor produces a high sound level
during operation. Ear protection should be
worn.
MAIN COMPONENTS
WWW.SGS-ENGINEERING.COM

PAGE 5
PAGE 4
TRAINING: Prior to use, all users must become familiar with the instruc-
tions given in this manual. In particular, become familiar with the ON/OFF
control for stopping the compressor in the event of an emergency.
ALWAYS USE EYE PROTECTION: When operating the air compressor, al-
ways use eye protection such as goggles, and make sure that other people
in the work area are also using eye protection. Eye protectors must pro-
vide protection from flying particles both from the front and from the side.
PROTECT YOUR HEARING: Hearing protection should be worn when
operating this compressor, use ear plugs or ear defenders.
NEVER TOUCH MOVING PARTS: Never place your hand near any moving
parts on the air compressor or operate with the covers removed.
PROTECT YOUR SELF AGAINST ELECTRIC SHOCK: Never operate the
air compressor in wet or damp locations.
DRESS PROPERLY: Loose clothing or jewellery may be caught in moving
parts. Always tie long hair back, and wear suitable clothing.
KEEP VISITORS/CHILDREN AWAY: Do not allow visitors/children to han-
dle the air compressor or attachments and ensure that any people in the
work area are suitably dressed.
KEEP THE WORK AREA CLEAN: Cluttered areas mean accidents, so clear
the work area of all unnecessary tools, debris and furniture.
SAFETY PRECAUTIONS
DO NOT TOUCH HOT SURFACES: During operation, the motor, con-
nections, compressor body, cylinder head and tubes may get hot, do not
touch.
DO NOT DIRECT AN AIR STREAM AT THE BODY: Do not direct the
air stream at people or animals, as injury may result. Compressed air can
cause soft tissue damage and propel dirt and other particles at high speed.
BREATHING AIR: This compressor should not be used to supply breathing
quality air. Never use it as breathing apparatus.
STAY ALERT: Watch what you are doing, use common sense, and do not
operate the air compressor when you are tired. The air compressor should
not be used if you are under the influence of alcohol, drugs or any medica-
tion that makes you drowsy.
DISCONNECT THE AIR COMPRESSOR: Always disconnect the air com-
pressor from the mains power supply and decompress before performing
maintenance, changing any parts and when not in use.
MAINS POWER CABLE PRECAUTIONS: Never pull on the cable when
removing the plug from the mains socket, or lift the compressor by the
mains cable.
SAFETY PRECAUTIONS
WWW.SGS-ENGINEERING.COM

PAGE 7
PAGE 6
AVOID UNINTENTIONAL STARTING: When connecting the air compres-
sor to the mains supply make sure the red button on top of the air com-
pressor is in the OFF (down) position.
STORE THE AIR COMPRESSOR PROPERLY: When not in use the air com-
pressor should be stored in a secure, dry place out of the reach of children.
Always lock up the storage area.
MAINTAIN THE AIR COMPRESSOR WITH CARE: If the air compressor is
damaged in any way, have it repaired by a qualified engineer.
DO NOT USE EXTENSION LEADS: Using extension leads can cause your
compressor motor to burn out. Only use extension hoses.
DISPOSAL INFORMATION: The air compressor should be disposed of in
a safe an environmentally friendly manner. Contact your local Council for
disposal assistance.
DO NOT WELD TO THE PRESSURE VESSEL: Do not weld or modify the
pressure vessel in any manner.
SAFETY PRECAUTIONS ASSEMBLY
1. Remove the travel plug
2. Attach the air filter, tightening
hand tight only
3. Remove the travel plug
4. Fit the breather plug
WWW.SGS-ENGINEERING.COM

PAGE 9
PAGE 8
BEFORE USE
1. Set the ON/OFF switch to the-
OFF position (pushed down).
2. Make sure that the compressor is
on level ground.
3. Check that the oil level is half way
up the oil sight glass
4. If not, remove the breather plug
and fill with compressor oil (our
part code SO2068)
OPERATION
1. Attach a hose to the quick re-
lease coupler on the compres-
sor and to an air tool.
2. Turn the compressor on by
lifting the on/off button. The
compressor will operate until
the tank is fully pressurised
before switching off. The com-
pressor will start again when
the tank pressure drops.
WWW.SGS-ENGINEERING.COM

PAGE 11
PAGE 10
OPERATION SWITCHING OFF
1. Push down on the on/off switch
to turn the compressor off.
2. Operate the air tool to depres-
surise the air hose.
3. Disconnect the tool from the
hose.
4. Open the drain cock to remove
any condensation from the
compressor.
3. Set the regulator to the correct pressure for the air tool (check in the
air tool manual). The output pressure is shown on the right gauge.
The left hand gauge shows the tank pressure.
WWW.SGS-ENGINEERING.COM

PAGE 13
PAGE 12
1. The compressor is controlled by a pressure switch. It can be stopped
automatically as the pressure increases to the maximum and restarted
as pressure decreases to the minimum. The rated pressure has been
adjusted during the manufacturing process - don’t alter it carelessly.
PRESSURE ADJUSTMENT THERMAL RESET SWITCH
This compressor has a thermal overload device.
If the motor gets too hot, the thermal overload device cuts the power
which prevents damage to the motor.
If the thermal overload device operates, let the motor cool down for 5
minutes and push the reset button.
If you start the compressor and the overload cutout operates again, stop
the compressor and disconnect from the power supply and have your
compressor examined by a qualified service agent.
WWW.SGS-ENGINEERING.COM

PAGE 15
PAGE 14
1. Disconnect power source then release all pressure from the system be-
fore attempting to install, service, relocate or perform any maintenance.
2. Never unscrew any connecting part when the tank is pressurised.
3. Never disassemble any electrical part before disconnecting the plug.
4. Never adjust the safety valve carelessly.
5. Never use the compressor where voltage is too low or too high.
6. Never disconnect the plug to stop the compressor, set the switch knob
to the off position instead.
7. Lubricating oil must be clean and at the level indicated.
8. Clean crankcase and renew lubricating oil after the first 10 working
hours. Check the oil level after every 20 working hours, and replenish if
necessary.
CAUTIONS MAINTENANCE
CLEAN THE AIR FILTERS (MONTHLY)
The air filters must be examined monthly and
more often in dusty conditions:
1. Unscrew the filters from the compressor.
2. Remove the filter covers from the filters.
3. Clean the sponge and the filter cover
using a soft brush. If necessary, the filters
can be carefully cleaned in warm soapy
water. Rinse and let the filters dry com-
pletely before refitting.
4. Make sure that the filters and filter cov-
ers are replaced into position. If the
filters are damaged, you must replace
them.
CLEANING
1. Open drain cock under the tank to ex-
haust condensate after every use.
2. Clean the crankcase and renew the oil,
clean air filter, and check safety valve and
pressure gauge after every 120 working
hours.
WWW.SGS-ENGINEERING.COM

PAGE 17
PAGE 16
REPLACEMENT PARTS DIAGRAM PARTS LIST
No. Part Qty Part No No Part Qty Part No
1 Bolt M6x35 4 903451 35 Screw M4x8 1 904968
2 Spring Washer 6 8 902094 36 Spring washer 5 4 904969
3 Cylinder head 1 904937 37 Bolt M5x85 4 904970
4 Cylinder seals 1 904938 38 Criclip 14 1 904971
5 Right-angle connector RP3/8 1 904939 39 Fan 1 904972
6 Valve plate 1 904940 40 M5x12 2 904973
7 Valve slice 0.3 1 904941 41 Centrifugal switch 1 904974
8 Locating pin 3x6 2 904942 42 Fan cover plate 1 904975
9 Valve gasket 0.8 1 904943 43 Fan cover 1 904976
10 Bolt M6x20 4 904201 44 Screw ST3.1x15 4 904977
11 Cylinder 42 1 904945 45 Bolt M5x14 4 901514
12 Cylinder gasket 1 904946 46 Start capacitor 1 904979
13 Piston ring 42x2 2 904947 47 Running capacitor 1 904980
14 Oil scraper ring 1 904948 48 Tooth washer 8 2 904981
15 Piston 42 1 904949 49 Nut M8 2 901995
16 Circlip 14 2 904950 50 Air filter 1 904983
17 Piston pin 12x39.5 1 904951 51 Handle 1 904984
18 Connecting rod 1 904952 52 Discharge pipe 1 904985
19 Breath pipe 1 904953 53 Bolt M8x20 8 900393
20 Oil leveler 1 904954 54 Nut 8 8 904987
21 Screw M5x14 4 904955 55 Tank 1 904988
22 Crankcase cover 1 904956 56 Washer foot 1 904989
23 Rubber gasket 1 904957 57 Drain cock 1/4” 1 904990
24 Bolt M8x20 1 900393 58 One-way valve 1 904991
25 Crank 1 904959 59 Release pipe 1 904992
26 Crankcase 1 904960 60 Quick coupler 1 904993
27 Sealing ring 17x35x7 1 904961 61 Regulator 1 904994
28 Bearing 6003-RS 1 904962 62 Pressure guage 2 904995
29 Rotor 1 904963 63 Connected pipe 1 904996
30 Stator 1 904964 64 Power cord 1 904997
31 Bearing 6202-RS 1 904965 65 Safety valve 1 904998
32 Motor bracket 1 904966 66 Pressure switch 1 904999
33 Tooth washer 4 1 904967 67 Thermal protectors 1 905000
34 Nut 1
WWW.SGS-ENGINEERING.COM

PAGE 19
PAGE 18
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE ACTION
Motor unable to run,
running slow or getting
hot
1. Fault in line or insufficient
voltage
2. Power wire too thin or long
3. Fault in pressure switch
4. Fault in motor
5. Sticking of main compres-
sor
1. Check the line
2. Replace the wire
3. Repair or replace
4. Repair or replace
5. Check and repair
Sticking of main com-
pressor
1. Moving parts burnt due to
insufficient oil
2. Moving parts damaged or
stuck by a foreign body
Check crankshaft, bearing,
connecting rod, piston, piston ring,
etc. and replace if
necessary
Shaking or abnormal
noise
1. Connecting part loose
2. Foreign body in the main
compressor
3. Piston knocking the valve
seat
4. Moving parts seriously
worn
1. Check and retighten
2. Check and clean away
3. Replace with thicker paper
gasket
4. Repair or replace
Pressure insufficient
or discharge capacity
decreased
1. Motor running too slow
2. Air filter choked up
3. Leakage of safety valve
4. Leakage of discharge pipe
5. Sealing gasket damaged
6. Valve plate damaged,
stuck or carbon build up
7. Piston ring and cylinder
worn or damaged
1. Check and remedy
2. Clean or replace the cartridge
3. Check and adjust
4. Check and repair
5. Check and replace
6. Replace and clean
7. Repair or replace
Excessive oil consump-
tion
1. Oil level too high
2. Breather pipe choked up
3. Piston ring and cylinder
worn or damaged
1. Keep the level within set range
2. Check and clean
3. Repair or replace
WWW.SGS-ENGINEERING.COM

EC Declaration of Conformity
This is an important document and should be retained
MANUFACTURER’S NAME:
TYPE OF EQUIPMENT:
PART NUMBER:
I, the undersigned, hereby declare that the equipment specied above con-
forms to the above European Communities Directive(s) and Standard(s).
PLACE:
DATE: (Signature)
Robert Wyatt
Company Secretary
Derby, UK
24th March 2019
SGS Engineering (UK) Ltd
SGS Engineering (UK) Ltd
West Side Park
Raynesway
Derby, DE21 7AZ
Air Compressor
SC8H
2014/30/EU Electromagnetic Compatibility Directive
2006/42/EC Machinery Directive
2009/105/EC Simple Pressure Vessel Directive
2000/14/EC Noise Emissions Directive (amended by 2005/88/EC)
2002/95/EC Restriction of Hazardous Substances
EN 55014-1:2006/+A1:2009/+A2:2011
EN 55014-2:1997/A1:2001/+A2:2008
EN61000-3-2:2014 EN61000-3-3:2013
APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:
