SGS SC24M User manual

FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
OWNER’S MANUAL
SC24M
AIR COMPRESSOR

PAGE 3
PAGE 2
1. Housing cover
2. Pressure vessel
3. Wheel
4. Supporting foot
5. Quick-lock coupling
6. Pressure gauge
7. Pressure regulator
8. ON/OFF Switch
9. Transport handle
10. Safety valve
11. Drainage screw for
condensation
MAIN COMPONENTS WARNING SYMBOLS
READ THIS INSTRUCTION MANUAL CARE-
FULLY BEFORE OPERATING OR ADJUSTING
THE COMPRESSOR.
Risk of electric shock. The compressor must
be disconnected from the mains supply before
maintenance or removing any covers. Do not
use in a damp environment.
Risk of accidental start-up. The compressor
could start automatically in the event of a
power cut and subsequent reset. Do not carry
the compressor while it is connected to the
power source, or when the tank is filled with
compressed air.
This compressor contains surfaces which may
reach a high temperature during operation.
Never operate with the motor housing re-
moved.
Air and condensation water can burst from the
compressor when the drain plug is removed.
Wear a safety goggles and ear protectors
when using this compressor.
This compressor produces a high sound level
during operation. Ear protection should be
worn.
Model SC24M
Power 1.2kW / 1.6HP
Voltage 220-240 V @ 50 Hz
Motor Poles 2 P
Rated Speed 3450 rpm
Delivery 8 bar
Discharge Pressure 6.3 cfm
Tank Capacity 24 L
Net Weight 15.5 kg
Noise Specification LWA 97dB
WWW.SGS-ENGINEERING.COM

PAGE 5
PAGE 4
TRAINING: Prior to use, all users must become familiar with the instruc-
tions given in this manual. In particular, become familiar with the ON/OFF
control for stopping the compressor in the event of an emergency.
ALWAYS USE EYE PROTECTION: When operating the air compressor, al-
ways use eye protection such as goggles, and make sure that other people
in the work area are also using eye protection. Eye protectors must pro-
vide protection from flying particles both from the front and from the side.
PROTECT YOUR HEARING: Hearing protection should be worn when
operating this compressor, use ear plugs or ear defenders.
NEVER TOUCH MOVING PARTS: Never place your hand near any moving
parts on the air compressor or operate with the covers removed.
PROTECT YOUR SELF AGAINST ELECTRIC SHOCK: Never operate the
air compressor in wet or damp locations.
DRESS PROPERLY: Loose clothing or jewellery may be caught in moving
parts. Always tie long hair back, and wear suitable clothing.
KEEP VISITORS/CHILDREN AWAY: Do not allow visitors/children to han-
dle the air compressor or attachments and ensure that any people in the
work area are suitably dressed.
KEEP THE WORK AREA CLEAN: Cluttered areas mean accidents, so clear
the work area of all unnecessary tools, debris and furniture.
SAFETY PRECAUTIONS
DO NOT TOUCH HOT SURFACES: During operation, the motor, con-
nections, compressor body, cylinder head and tubes may get hot, do not
touch.
DO NOT DIRECT AN AIR STREAM AT THE BODY: Do not direct the
air stream at people or animals, as injury may result. Compressed air can
cause soft tissue damage and propel dirt and other particles at high speed.
BREATHING AIR: This compressor should not be used to supply breathing
quality air. Never use it as breathing apparatus.
STAY ALERT: Watch what you are doing, use common sense, and do not
operate the air compressor when you are tired. The air compressor should
not be used if you are under the influence of alcohol, drugs or any medica-
tion that makes you drowsy.
DISCONNECT THE AIR COMPRESSOR: Always disconnect the air com-
pressor from the mains power supply and decompress before performing
maintenance, changing any parts and when not in use.
MAINS POWER CABLE PRECAUTIONS: Never pull on the cable when
removing the plug from the mains socket, or lift the compressor by the
mains cable.
SAFETY PRECAUTIONS
WWW.SGS-ENGINEERING.COM

PAGE 7
PAGE 6
AVOID UNINTENTIONAL STARTING: When connecting the air compres-
sor to the mains supply make sure the red button on top of the air com-
pressor is in the OFF (down) position.
STORE THE AIR COMPRESSOR PROPERLY: When not in use the air com-
pressor should be stored in a secure, dry place out of the reach of children.
Always lock up the storage area.
MAINTAIN THE AIR COMPRESSOR WITH CARE: If the air compressor is
damaged in any way, have it repaired by a qualified engineer.
DO NOT USE EXTENSION LEADS: Using extension leads can cause your
compressor motor to burn out. Only use extension hoses.
DISPOSAL INFORMATION: The air compressor should be disposed of in
a safe an environmentally friendly manner. Contact your local Council for
disposal assistance.
DO NOT WELD TO THE PRESSURE VESSEL: Do not weld or modify the
pressure vessel in any manner.
SAFETY PRECAUTIONS ASSEMBLY
Attach the wheels to the compressor.
Fit in the rubber stopper as shown.
WWW.SGS-ENGINEERING.COM

PAGE 9
PAGE 8
BEFORE USE
1. Examine the machine for signs of transit damage. If damaged, call SGS
Customer Service immediately.
2. Avoid long air lines and slong supply lines (extensions).
3. Make sure the intake air is dry and dust free. Do not set up the
compressor in damp or wet rooms.
4. The compressor may only be used in suitable rooms, with good ventila-
tion and ambient temperature between 5° and 40° Celsius. There must
be no dust, acids, vapors, explosive or inflammable gases in the room.
5. Set up only on flat and stable surfaces.
6. Use flexible hoses in order to ensure proper airflow.
7. Supply hoses at pressures above 7 bar should be equipped with a safety
cable (e.g. a wire rope).
OPERATION
1. Attach a hose to the quick release coupler on the compressor and to an
air tool.
2. Turn the compressor on by lifting the on/off button. The compressor
will operate until the tank is fully pressurised before switching off. The
compressor will start again when the tank pressure drops.
3. Check the safety cut off valve is working correctly - pull on the ring to
release air. When you release the ring the air should stop. If the valve
does not operate correctly do not use the compressor.
4. Set the regulator to the correct pressure for the air tool (check in the air
tool manual). The output pressure is shown on the right gauge. The left
hand gauge shows the tank pressure.
1. Push down on the on/off switch to turn the compressor off.
2. Operate the air tool to depressurise the air hose.
3. Disconnect the tool from the hose.
4. Open the drain cock to remove any condensation from the compressor.
SWITCHING OFF
WWW.SGS-ENGINEERING.COM

PAGE 11
PAGE 10
TROUBLE SHOOTING
Trouble Possible causes Remedies
Motor not running, (1) Fault in line, or voltage insucient (1) Check the line
Running too slow, (2) Power wire too thin or too long (2) Replace the wire
or geng hot (3) Fault in pressure switch (3) Repair or replace
(4) Fault in motor (4) Repair or replace
(5) Scking of main compressor (5) Check and repair
Scking of
main compressor
(1) Moving parts burnt due to insuf-
cient oil
Check cranksha, bearing,
connecng rod, piston,
piston ring, etc., replace if
necessary.
(2) Moving parts damaged/ or stuck
by foreign body.
Shakeing or abnormal
noise
(1) Connecng part loose (1) Check and reghten
(2) Foreign body got into main com-
pressor
(2) Check and clean away
(3) Piston knocking valve seat (3) Replace with thicker
paper gasket
(4) Moving parts worn (4) Repair or replace
Pressure insucient (1) Motor running too slow (1) Check and remedy
(2) Air lter chocked up (2) Clean or replace the
cartridge
(3) Leakage of safety valve (3) Check and adjust
(4) Leakage of discharge pipe (4) Check and repair
(5) Sealing gasket damaged (5) Check and replace
(6) Valve plate damaged, carbon
buildup or stuck.
(6) Replace and clean
(7) Piston ring and cylinder worn or
damaged
(7) Repair or replace
Oil consumpon
excessive
(1) Oil level too high (1) Keep the level within
set range
(2) Breath pipe chocked up (2) Check and clean
(3) Piston ring and cylinder worn or
damaged
(3) Repair or replace
1. The compressor is controlled by a pressure switch. It can be stopped
automatically as the pressure increases to the maximum and restarted
as pressure decreases to the minimum. The rated pressure has been
adjusted during the manufacturing process - don’t alter it carelessly.
2. As soon as motor switched off the compressed air in the discharge pipe
should be released through the release valve under the switch. This is
the necessary condition for restart, or the motor will be damaged. The
rated pressure can be adjusted by turning the adjusting bolt of the
switch
PRESSURE ADJUSTMENT
THERMAL RESET SWITCH
This compressor has a thermal overload device.
If the motor gets too hot, the thermal overload device cuts the power which
prevents damage to the motor.
If the thermal overload device operates, let the motor cool down for 5 min-
utes and push the reset button.
If you start the compressor and the overload cutout operates again, stop the
compressor and disconnect from the power supply and have your compressor
examined by a qualified service agent.
WWW.SGS-ENGINEERING.COM

PAGE 13
PAGE 12
1. Put the cover off first and put on the breath pipe and air filter before
the compressor run.
2. Never unscrew any connecting part when the tank is in pressure condi-
tion.
3. Never disassemble any electrical part before disconnecting the plug.
4. Never adjust the safety valve carelessly.
5. Never use the compressor in place where voltage is too low or too high.
6. Never disconnect the plug to stop compressor, set the switch knob in
position off instead.
7. If the release valve doesn’t work as motor stopped, find the cause im-
mediately so as not to damage motor.
8. Lubricating oil must be clean, oil level should be kept in the score of oil
ruler.
9. Disconnect the plug to cut off power supply and open the outlet valve
CAUTIONS MAINTENANCE
CLEAN THE AIR FILTERS (MONTHLY)
The air filters must be examined monthly and more often in dusty condi-
tions:
1. Unscrew the filters from the compressor.
2. Remove the filter covers from the filters.
3. Clean the sponge and the filter cover using a soft brush. If necessary,
the filters can be carefully cleaned in warm soapy water. Rinse and let
the filters dry completely before refitting.
4. Make sure that the filters and filter covers are replaced into position. If
the filters are damaged, you must replace them.
CLEANING
1. Clean crankcase and renew lubricating oil after the first 10 working hours.
2. Clean the oil level after every 20 working hours, and replenish if neces-
sary.
3. Open drain cock under the tank toexhaust condensate after every 60
working hours.
4. Clean crankcase and renew the oil, clean air filter, and check safety valve
and pressure gauge after every 120 working hours.
WWW.SGS-ENGINEERING.COM

REPLACEMENT PARTS DIAGRAM No Part Qty Part No No Part Qty Part No
1 Nut 1 906229 24 Motor group 1 906252
2 Rubber Foot 1 906230 25 Air filter 1 906253
3 Bolt 1 906231 26 Screw 3 906254
4 Drain cock 1 906232 27 On/Off Switch 1 906255
5 Tank 1 906233 28 Upper cover 1 906256
6 Bolt 2 906234 29 Screw 9 906257
7 Washer 2 906235 30 Elbow 1 906258
8 Wheel 2 906236 31 Nut 2 906259
9 Nut 2 906237 32 Washer 2 906260
10 Nut 2 906238 33 Alu pipe 1 906261
11 Safety valve 1 906239 34 Lower cover 1 906262
12 Washer 2 906240 35 Rubber handle 1 906263
13 Gasket 2 906241 36 Pressure gauge 1 906264
14 Bolt 2 906242 37 Quick coupler 1 906265
15 Pressure switch 1 906243 38 Pressure regulator 1 906266
16 Zip tie 2 906244 39 Check valve 1 906267
17 Terminal 2 906245 40 Elbow 2 906268
18 Plug 1 906246 41 Pipe 1 906269
19 Electric board 1 906247 X-1 Iron ring 1 906270
20 Plastic tie 1 906248 X-2 Clamp 1 906271
21 Screw 2 906249 42 Seal ring 2 906272
22 Washer 7 906250 43 Stopper 2 906273
23 Screw 4 906251 4
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.

No Part Qty Part No No Part Qty Part No
1Bolt 4 906274 13 Bearing 2 906286
2Cylinder head 1 906275 14 Motor 1 906287
3Gasket 1 906276 15 Bearing 1 906288
4Valve 2 906277 16 Crankshaft 1 906289
5Alu Gasket 1 906278 17 Belt 1 906290
6Valve plate 2 906279 18 Connecting rod 1 906291
7Gasket 1 906280 19 Piston ring 1 906292
8Cylinder 1 906281 20 Rod cover 1 906293
9Screw 4 906282 21 Screw 1 906294
10 Motor cover 1 906283 22 Fan 1 906295
11 Circlip 1 906284 23 Washer 1 906296
12 Washer 1 906285 24 Screw 1 906297
EC Declaration of Conformity
This is an important document and should be retained
MANUFACTURER’S NAME:
TYPE OF EQUIPMENT:
PART NUMBER:
I, the undersigned, hereby declare that the equipment specied above con-
forms to the above European Communities Directive(s) and Standard(s).
PLACE:
DATE: (Signature)
Robert Wyatt
Company Secretary
Derby, UK
24th MARCH 2019
SGS Engineering (UK) Ltd
SGS Engineering (UK) Ltd
West Side Park
Raynesway
Derby, DE21 7AZ
Air Compressor
SC24M
2014/30/EU Electromagnetic Compatibility Directive
2006/42/EC Machinery Directive
2009/105/EC Simple Pressure Vessel Directive
2000/14/EC Noise Emissions Directive (amended by 2005/88/EC)
2002/95/EC Restriction of Hazardous Substances
EN 55014-1:2006/+A1:2009/+A2:2011
EN 55014-2:1997/A1:2001/+A2:2008
EN61000-3-2:2014 EN61000-3-3:2013
APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
This manual suits for next models
1
Table of contents
Other SGS Air Compressor manuals
Popular Air Compressor manuals by other brands

Black & Decker
Black & Decker 9527 instruction manual

Daikin
Daikin DWSC 050 Installation, operation and maintenance manual

Scheppach
Scheppach HC06 Translation of original instruction manual

Aerfast
Aerfast AC09210 operating manual

GEA
GEA Grasso M-Series operating manual

DeWalt
DeWalt DXCM271 instruction manual
