Sharp AN-3DG10-R User manual

EN-1
AN-3DG10-S
AN-3DG10-R
AN-3DG10-A
3D GLASSES FOR SHARP 3D AQUOS
OPERATION MANUAL
These 3D Glasses (AN-3DG10-S/R/A) are only for use with Sharp
AQUOS LCD TVs supporting 3D. For details of how to make
adjustments for 3D functions and to fully enjoy 3D viewing, refer to the
operation manual of your TV.
IMPORTANT INFORMATION
This product contains a CR Coin Lithium Battery which contains Perchlorate Material – special
handling may apply, California residents, See www.dtsc.ca.gov/hazardouswaste/perchlorate/
U.S.A. ONLY
Printed in China
10P08-CH-NM
ENGLISH
AN-3DG10hyo1.indd1AN-3DG10hyo1.indd1 2010/08/0314:04:592010/08/0314:04:59

EN-2
3D Glasses
Prevention of accidental ingestion
• Keep the batteries and band accessory out of the reach of small children. Small children can accidentally swallow these
parts.
– If a child accidentally swallows any of these parts, seek immediate medical attention.
Do not disassemble
• Do not disassemble or modify the 3D Glasses.
Caution for lithium battery
• Batteries must not be exposed to excessive heat such as direct sunlight or fire.
• Replace only with the same or equivalent type of battery. The battery may explode if improperly replaced.
• Take care not to reverse the battery poles (+ and –) when loading the battery. Follow the correct procedure when loading
the battery. Loading the battery incorrectly may damage the battery or cause it to leak battery fluid, which could result in
a fire, injury or damage.
Handling the 3D Glasses
• Do not drop, exert pressure on, or step on the 3D Glasses. Doing so may damage the glass section, which may result in
injury.
• Be careful not to trap your finger in the hinge section of the 3D Glasses. Doing so may result in injury.
– Pay special attention when children are using this product.
Using the 3D Glasses
• Parents/guardians should monitor children's viewing habits to avoid their prolonged use without rest periods.
• Use the 3D Glasses only for the specified purpose.
• Do not move around while wearing the 3D Glasses. The surrounding area appears dark, which may result in falling or
other accidents that may cause injury.
Caring for the 3D Glasses
• Use only the cloth provided with the 3D Glasses to clean the lenses. Remove dust and soil from the cloth. Any dust or
other soiling on the cloth may result in scratches on the product. Do not use solvents such as benzene or thinners as
doing so may cause the coating to peel off.
• When cleaning the 3D Glasses, take care not to allow water or other fluids to come into contact with the glasses.
• Always store the 3D Glasses in the case provided when not in use.
• When storing the 3D Glasses, avoid very humid or hot locations.
Viewing 3D images
• If you experience dizziness, nausea, or other discomfort while viewing 3D images, discontinue use and rest your eyes.
• Do not use the 3D Glasses if they are cracked or broken.
IMPORTANT SAFETY INSTRUCTIONS
DEAR SHARP CUSTOMER
Thank you for your purchase of the 3D Glasses for Sharp 3D AQUOS. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
AN-3DG10E01.indd2AN-3DG10E01.indd2 2010/07/1417:12:512010/07/1417:12:51

EN-3
CAUTION
•Not all consumers can experience and enjoy 3D TV. Some people suffer from stereo blindness which prevents
them from perceiving the intended depth of 3D entertainment. Also, some people who watch 3D programming
may experience initial feelings of motion sickness as they adjust to the picture. Others may experience
headaches, eye fatigue or continued motion sickness. Like a roller coaster, the experience is not for everyone.
•The 3D Glasses are precision equipment. Handle them with care.
•Improper use of the 3D Glasses or failure to follow these instructions can result in eye strain.
•If you experience dizziness, nausea, or other discomfort while viewing 3D images, immediately discontinue
use of the 3D Glasses. Using the binocular disparity 3D system of the TV with incompatible 3D broadcasts or
software can make images appear with a cross talk blur or create overlapping images.
•When viewing 3D images continuously, be sure to take a break periodically to prevent eye strain.
•If you are nearsighted or farsighted or have astigmatism or a different level of eyesight between the left and right
eyes, you should take the necessary steps, such as wearing eyeglasses, to correct your eyesight before viewing
3D images. The 3D Glasses can be worn over eyeglasses.
•When viewing 3D images, keep the 3D Glasses horizontally level with the TV screen. If you tilt the 3D Glasses
with respect to the TV screen, the images viewed by the left and right eyes may appear significantly different or
images may appear overlapping.
•View 3D images at the appropriate distance from the TV screen. The recommended distance is three times the
effective height of the TV screen.
•Be careful of your surroundings when viewing 3D images. When you view 3D images, objects may appear at
a distance closer or farther than the actual TV screen. This may cause you to misjudge the distance to the TV
screen and possibly result in injury if you accidentally hit the screen or surrounding objects.
•The 3D Glasses are only recommended for people ages 5 and older.
•When children are viewing 3D images, be sure a parent or guardian is present. Monitor children viewing 3D
images, and if they show signs of discomfort, immediately discontinue use of the 3D Glasses.
•People with a known history of photosensitivity and people with heart problems or poor health should not use
the 3D Glasses. This can worsen existing health conditions.
•Do not use the 3D Glasses for other purposes (such as general eyeglasses, sunglasses, or protective goggles).
•Do not use the 3D function or 3D Glasses while walking or moving around. This may result in injuries due to
running into objects, tripping, and/or falling.
•When using the 3D Glasses, take care not to accidentally strike the TV screen or other people. Viewing 3D
images may cause you to misjudge the distance to the TV screen and accidentally strike the screen, resulting in
possible injury.
Using the 3D Glasses
Supplied Accessories
Make sure the following accessories are provided with the 3D Glasses.
Nose pad *
(Large ×1, small ×1)
Cleaning cloth
(×1)
Glasses case
(×1)
3D Glasses band *
(×1)
Operation Manual
* Use the 3D Glasses band and nose pad as needed.
■
Precision screwdriver
(Phillips ×1, slotted ×1)
3D Glasses
(×1)
•The illustrations above are for explanation purposes and may vary slightly from the actual accessories.
AN-3DG10E01.indd3AN-3DG10E01.indd3 2010/07/2617:48:442010/07/2617:48:44

EN-4
Part Names
1 2
4
5
3
6
1 Power button
Press for at least 2 seconds to turn on and off the 3D
Glasses.
When the 3D Glasses are turned on, pressing this
button switches between 2D and 3D modes.
2 LED light
Blinks 3 times when the power is turned on.
Blinks 2 times when 2D mode is selected.
Blinks 3 times when 3D mode is selected.
Blinks 6 times when the battery power is low.
Lights for 2 seconds when the power is turned off.
3 Service terminal
This terminal is for service use only.
Please do not connect any other device to this terminal.
4 Infrared receiver
Receives an infrared signal sent from the TV. The 3D
Glasses turn off automatically after 3 minutes if no signal
is received from the TV.
5 Nose pad mount
The dedicated nose pad can be mounted here.
6 3D Glasses band mount
The dedicated 3D Glasses band can be mounted here.
•Do not soil or apply stickers or other obstacles to the
infrared receiver. Doing so may block signals from the TV
and prevent the 3D Glasses from working correctly.
•Interference from other infrared communications equipment
may prevent you from viewing 3D images correctly.
•
•
•
•
•
•
•
Attaching the Nose Pad
Attach either of the supplied nose pads as needed
(such as when the glasses do not fit properly). The
glasses come with a large and small nose pad.
Attaching the nose pad
2
1
1
Removing the nose pad
Attaching the 3D Glasses Band
Attach the supplied 3D Glasses band strap as needed
(such as when the glasses do not fit properly).
Insert the ends of the 3D Glasses into the 3D Glasses
band until they are secure.
Pull the cord stopper on the strap to adjust the strap
length.
•
Using the 3D Glasses
AN-3DG10E01.indd4AN-3DG10E01.indd4 2010/07/1213:32:232010/07/1213:32:23

EN-5
Before Using the 3D Glasses
Before using the 3D Glasses for the first time, remove
the insulating sheet attached to them.
Replacing the Battery
The battery has an expected service life of
approximately 75 hours.
• When the battery power is low, the LED light blinks 6 times
after the power is turned on.
• When replacing the button battery, use only the designated
battery (Maxell branded CR2032 lithium button battery).
1Loosen the screw used to secure the battery cover.
2Remove the battery cover.
3Place the tip of the slotted precision screwdriver into the
opening between the battery and the socket.
4Lift up the battery while taking care not to get the
screwdriver caught on the metal latch.
5When the battery comes loose from the socket, pick it out
with your fingers.
6Hook a new battery to the metal latch and insert it into the
socket.
7Close the battery cover.
8Insert the screw to secure the battery cover.
2
8
6
1
7
5
4
3
•Take care not to reverse the battery poles (+ and –) when
loading the battery.
•Used batteries should be disposed of strictly in accordance
with the applicable local laws and regulations.
Using the 3D Glasses
Turning On/Off the Power
Turn on the power of the 3D Glasses.
Press the power button for at least 2 seconds.
The LED light blinks 3 times.
Turn off the power on the 3D Glasses.
Press the power button for at least 2 seconds.
The LED light lights for 2 seconds.
• When the battery power is low, the LED light blinks 6 times
after the power is turned on.
Switching to 3D and 2D Mode
When viewing 3D images, you can press the power
button to switch between 2D and 3D modes. This is
useful when several people are viewing 3D images on
the same TV with some people wanting to watch in 3D
and some people wanting to watch in 2D.
Viewing 2D images
When you press the power button twice while viewing 3D
images, the LED light blinks 2 times and the 3D images
switch to 2D images.
Viewing 3D images
When you press the power button twice while viewing 2D
images, the LED light blinks 3 times and the 2D images
switch to 3D images.
Usage Range of the 3D Glasses
The 3D Glasses can be used by receiving an infrared
signal sent from the TV.
The 3D Glasses turn off automatically after 3 minutes if
no signal is received from the TV.
•
•
•
•
■
■
Using the 3D Glasses
AN-3DG10E01.indd5AN-3DG10E01.indd5 2010/08/0411:34:262010/08/0411:34:26

EN-6
• These 3D Glasses are only for use with Sharp LCD TVs supporting 3D.
3D Glasses lenses
• Do not apply pressure to the lenses of the 3D Glasses. Also, do not drop or bend the 3D Glasses.
• Do not scratch the surface of the lenses of the 3D Glasses with a pointed instrument or other object. Doing so may damage
the 3D Glasses and reduce the quality of the 3D image.
• Use only the cloth provided with the 3D Glasses to clean the lenses.
3D Glasses infrared receiver
•Do not allow the infrared receiver to become dirty, and do not attach stickers to or otherwise cover the infrared receiver. Doing
so may prevent the receiver from operating normally.
•If the 3D Glasses are affected by other infrared data communication equipment, the 3D images may not be displayed correctly.
Caution during viewing
•Do not use devices that emit strong electromagnetic waves (such as cellular phones or wireless transceivers) near the 3D
Glasses. Doing so may cause the 3D Glasses to malfunction.
•The 3D Glasses cannot operate fully at extreme high or low temperatures. Please use them within the specified usage
temperature range.
•If the 3D Glasses are used in a room with fluorescent lighting (50/60 Hz), the light within the room may appear to flicker. In this
case, either darken or turn off the fluorescent lights when using the 3D Glasses.
•Wear the 3D Glasses correctly. 3D images will not be correctly visible if the 3D Glasses are worn upside down or back-to-
front.
•Other displays (such as computer screens, digital clocks, and calculators) may appear dark and difficult to view while wearing
the 3D Glasses. Do not wear the 3D Glasses when watching anything other than 3D images.
•If you lie on your side while watching the TV with 3D Glasses, the picture may look dark or may not be visible.
•Be sure to stay within the viewing angle and optimum TV viewing distance when watching 3D images. Otherwise, you may not
be able to enjoy the full 3D effect.
•The 3D Glasses may not work properly if there is any other 3D product or electronic devices turned on near the glasses or
TV. If this occurs, turn off the other 3D product or electronic devices or keep the devices as far away as possible from the 3D
Glasses.
•Stop using this product in any of the following situations:
– When images consistently appear doubled while you are wearing the 3D Glasses
– When you have difficultly perceiving the 3D effect
•If the 3D Glasses are faulty or damaged, stop using them immediately. Continued use of the 3D Glasses may cause eye
fatigue, headaches and illness.
•If you have any abnormal skin reaction, stop using the 3D Glasses. In very rare instances, such reactions may be due to an
allergic reaction to the coating or materials used.
•If your nose or temples become red or you experience any pain or itchiness, stop using the 3D Glasses. Pressure caused by
long periods of use may lead to such reactions and may result in skin irritation.
Troubleshooting
Problem Possible Solution
Images displayed in 3D mode
appear doubled while you are
wearing the 3D Glasses.
• Is the power of the 3D Glasses turned on?
Press the power button for at least 2 seconds to turn on the 3D Glasses.
•
Images displayed in 3D mode
appear 2D while you are wearing
the 3D Glasses.
• Are the 3D Glasses set to 2D mode?
Press the power button twice while viewing 2D images, the LED light blinks 3 times
and the 2D images switch to 3D images.
•
■
■
■
Using the 3D Glasses
AN-3DG10E01.indd6AN-3DG10E01.indd6 2010/07/1414:14:332010/07/1414:14:33

EN-7
Product 3D Glasses
Model number AN-3DG10-S/AN-3DG10-R/AN-3DG10-A
Lens type Liquid crystal shutter
Power supply 3 V DC
Battery Lithium button battery (CR2032 × 1)
Battery life Approx. 75 hours of continuous use
Dimension (W x H x D) 172.7 × 47.5 × 170.0 mm
613/16 × 1 7/8× 6 45/64 inch
Weight 65.0 g/0.2 lbs.
(including the lithium button battery)
Operating temperature
10°C to 40°C/50°F to 104°F
(The 3D Glasses cannot operate fully at extreme high or low temperatures. Please use them within
the specified usage temperature range.)
Specifications
Using the 3D Glasses
The product serial number is displayed on the 3D Glasses as indicated in the illustration on
the left. The first four digits represent the product color and the date of manufacture.
Example: Silver colored glasses manufactured on August 11, 2010
S/N : S 0 8 B
Bottom
S: Silver
R: Red
A: Blue
0: 2010
1: 2011
2: 2012
1: 1
2: 2
3: 3
8 :8
9 :9
A:10
B:11
C:12
1: 1
2: 2
3: 3
A : 10
B : 11
H : 17
J : 18
N : 22
P : 23
W: 30
X : 31
Manufacture number
Color Year of
manufacture Month of
manufacture
Day of
manufacture
* "I", "O", "Y" and "Z" are not used.
These symbols displayed on the product and the individual carton package of the product are symbols about the
environment in Japan, China and the EU.
For Japan only
For China only
For China only
For the EU only
•Please contact your local authority for the correct method of disposal of this product and/or packaing.
AN-3DG10E01.indd7AN-3DG10E01.indd7 2010/08/0411:34:262010/08/0411:34:26

SHARP CORPORATION
AN-3DG10E01.indd8AN-3DG10E01.indd8 2010/07/1613:48:532010/07/1613:48:53

For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or
customer assistance, please call 1-800-BE-SHARP.
Calling for Service
LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
SHARP CORPORATION
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original
container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or
part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product or if the serial number or model number affixed to the Product has been removed, defaced,
changed, altered or tampered with. This warranty does not cover installation or signal reception problems. This limited warranty will not apply if the Product has
been or is being used in a commercial setting or application; this warranty is meant solely for the non-commercial, household use of the Product by consumers in
their home or residence. If you intend to or already use this Product for commercial purposes or in a commercial setting, there are warranties available to cover
your use of this Product, the terms of which may vary. Please contact 1-888-GO-SHARP for further information.
In order to enforce your rights under this limited warranty, you should follow the steps set forth below. You must be able to provide proof of purchase to the servicer,
which proof must include the date of purchase.
To the extent permitted by applicable state law, the warranties set forth are in lieu of, and exclusive of, all other warranties, express or implied. Specifically ALL
OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE EXCLUDED, ALL EXPRESS AND IMPLIED WARRANTIES INCLUDING THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR USE, AND FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED. IF, UNDER APPLICABLE STATE
LAW, IMPLIED WARRANTIES MAY NOT VALIDLY BE DISCLAIMED OR EXCLUDED, THE DURATION OF SUCH IMPLIED WARRANTIES IS LIMITED TO THE
PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
The warranties given herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser and
only for the time periods set forth herein. No other representations or promises made by anyone are permitted. Correction of defects, in the manner and for the
period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and
shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. Sharp does not warrant nor shall Sharp be liable,
or in any way responsible, for Products which have been subject to abuse (including, but not limited to, improper voltage), accident, misuse, negligence, lack of
reasonable care, alteration, modification, tampering, misuse, improper operation or maintenance or any damages or defects in the Product which were caused by
repairs or attempted repairs performed by anyone other than a Sharp authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or
consequential economic or property damage. Some states do not allow limits on warranties or on remedies for breach in certain transactions; in such states, the
limits herein may not apply.
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA. AND PUERTO RICO.
Model Specific Section
What to do to Obtain Service: Warranty service is available from a Sharp Authorized Service Center located in the United
States.
To receive repair handling instructions, please contact Sharp toll free at 1-800-BE-SHARP
(1-800-237-4277).
If it is necessary to ship the Product for servicing, please ensure it is shipped prepaid,
insured and packaged securely. Sharp shall not be responsible for lost, stolen or
misdirected mail or for damage to the product incurred during shipping. Please have
proof of purchase available when requesting warranty service.
TO OBTAIN PRODUCT INFORMATION OR PURCHASE ACCESSORIES, CALL 1-800-BE-SHARP OR VISIT www.SharpUSA.com
Additional Exclusions: User replaceable batteries are not covered by this Limited Warranty.
Warranty Period for this Product: One (1) year parts and labor from date of purchase.
YYour Product Model Number & Description: AN-3DG10-S / AN-3DG10-R / AN-3DG10-A 3D Glasses
(Be sure to have this information and Proof of Purchase available when you need service
for your Product.)
For USA customers only
AN-3DG10E01.indd9AN-3DG10E01.indd9 2010/07/1414:14:332010/07/1414:14:33

AN-3DG10E01.indd10AN-3DG10E01.indd10 2010/07/2210:39:322010/07/2210:39:32

AN-3DG10E01.indd11AN-3DG10E01.indd11 2010/07/0916:57:082010/07/0916:57:08

SHARP CORPORATION
AN-3DG10E01.indd12AN-3DG10E01.indd12 2010/07/0916:57:082010/07/0916:57:08
