1
AF-P80CX
S3208AFP08CX/
SERVICE MANUAL
Page
SPECIFICATIONS ................................................................................................................................................ 2
WIRING DIAGRAM............................................................................................................................................... 3
EXTERNAL DIMENSIONS ................................................................................................................................... 4
HOW TO OPERATE ............................................................................................................................................. 5
INSTALLATIOIN INSTRUCTIONS ......................................................................................................................15
DISASSEMBLING PROCEDURE....................................................................................................................... 18
HOW TO REPAIR REFRIGERATION .................................................................................................................21
ELECTRICAL COMPONENT TEST ....................................................................................................................23
MICROCOMPUTER CONTROL SYSTEM ..........................................................................................................24
TROUBLESHOOTING GUIDE ............................................................................................................................28
COOLING LOAD ESTIMATE FORM ...................................................................................................................33
RUNNING CONDITION .......................................................................................................................................35
PACKING AND ACCESSORIES .........................................................................................................................36
REPLACEMENT PARTS LIST ............................................................................................................................37
TABLE OF CONTENTS
AIR CONDITIONER
MODEL
Intheinterestsofuser-safety(Requiredbysafetyregulationsinsome
countries)theset should berestoredtoits original conditionandonly
parts identical to those specified should be used.
AF-P80CX
SHARP CORPORATION This document has been published to be used for after
sales service only.
The contents are subject to change without notice.

2
AF-P80CX
SPECIFICATIONS
Models AF-P80CX
Cooling capacity BTU/h 8000
Moisture removal Pints/h 2.3
ELECTRICAL DATA
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 6.7
Rated input Watts 730
Power factor % 95
EER BTU/Wh 11.0
COMPRESSOR
Type (Hermetically sealed rotary type)
Model, Motor output 2R12T126A-6A, 550W
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, Hair pin
Condenser Louver fin, Grooved tube, 7mm, Hair pin
Control O.D. x I.D. x Length x Q'ty(mm) 2.7 x 1.0 x 800 x 2
(Capillary tube)
Refrigerant volume R-22(OZ) 15.5
(Factory change)
NET DIMENSIONS
Width Height Depth inches(mm) 19-11/16(500) x 14-9/16(370) x 17-3/32(434)
Net Weight lbs 53
GROSS DIMENSIONS
Width Height Depth inches(mm) 22-27/32(580) x 18-5/16(465) x 19-31/32(507)
Gross Weight lbs 60
FAN SYSTEM
Indoor side(Evaporator) Centrifugal fan
Outdoor side(Condenser) Propeller fan
Air flow rate(indoor side) CFM High / Med / Low
187 / 173 / 155
OTHERS
Safety devices Compressor: Overload relay
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 10A

3
AF-P80CX
GR
OVERLOAD
PROTECTOR
A.C
EARTH
M.C
CONNECTOR
HML
FAN MOTOR
CAPACITOR
250V 6µF
FAN MOTOR
RUNNING
CAPACITOR
250V 35µF
THERMAL
PROTECTOR
BL
BL
BLBK
BK
BK
GY RE OR WH
COMPRESSOR
MOTOR
BK
BL
RE
WH
GR
GY
OR
: BLACK
: BLUE
: RED
: WHITE
: GREEN
: GRAY
: ORANGE
POWER SUPPLY CORD
115V 60Hz
3A 125V
IN
GR MRY CONTROL
BOARD UNIT
NR C1
CN1
BCN2
BCN3
TR
OUT
RIBBED
NON RIBBED
BK
BK
C
R
RE WH
GY
BCN1
CN2
CN3
WH
OR
RE
GY
S
FU1
123654
WIRE COLOR
YELLOW TH1
RY3 R26
CLUSTER
CN6
BKBL
SSR
C24
RY2
RY1
CNR3
CNR2
CNR1
THERMISTOR
(ROOM TEMP)
8
7
1
3
5
DISPLAY
BOARD
UNIT
ELECTRICAL PARTS
Models AF-P80 CX
Running capacitor 250V-35µF
Fan capacitor 250V-6µF
Thermistor 15kΩat 78˚F
Fan motor OBM-2508K1 (MLB003)
Overload relay MRA98706
WIRING DIAGRAM
Figure W-1

4
AF-P80CX
EXTERNAL DIMENSIONS
19-11/16"
35-7/16" (full opened)
23-5/8" (full closed)
17-3/32"
13-5/8"
1-15/32"
15-11/16"
4-15/32"
Fig. E-1

5
AF-P80CX
HOW TO OPERATE
PARTS NAMES
UNIT
CONTROL PANEL
1Front Cabinet
2Air Inlet (Indoor Side)
3Horizontal Louvers
4Vertical Louvers
5Air Outlet (Indoor Side)
6Control Panel
7Rear Cabinet
8Air Inlet (Outdoor side)
9Filter (Pull the filter handle
to the right to remove.)
0Filter Handle
qPower Cord
1Receiver window for remote control signal
2Display
3SELECTOR indicator
4SELECTOR pad
5TEMPERATURE setting pad
----Lower temp. ----Raise temp.
6TIMER ON/OFF pad
7TIMER indicator
8ENERGY SAVER pad
9ENERGY SAVER indicator
0POWER ON/OFF pad
qPOWER indicator
wPLASMACLUSTER indicator
34567
8
9
10
11
1
2
POWER
ON/OFF
F
hr
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
12
10
3
4 5 6 7 9
8
11
12

6
AF-P80CX
---Lower temp.
---Raise temp.
Touch POWER ON/OFF pad.
• The unit is preset at 74°F and HIGH
COOL. This will show in the display
when the power is first turned on.
• POWER indicator and SELECTOR
indicator (COOL) will light.
Toturnofftheunit,touchPOWER
ON/OFF pad again.
• POWER indicator and SELECTOR
indicator will go off.
Touch the TEMPERATURE setting
pad to adjust the temperature
setting.
• Temperature can be set within the range
of 64°F to 86°F.
• Display will change as you touch
the pad.
NOTE:
•The latest temperature setting will be memorized and will appear on the display the next time
the unit is turned on.
• In cases of power outages or when the unit is disconnected; when the power is restored or the
unit is plugged in, the unit and display will return to the preset conditions of 74°F and HIGH
COOL. The unit will not automatically turn back on. The user must touch POWER ON/OFF to
resume operation.
2
1
During cooling operation
COOLING OPERATION
TO CHANGETEMPERATURE SETTING
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
POWER
indicator
SELECTOR indicator
POWER ON/OFF pad
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
TEMPERATURE setting pad

7
AF-P80CX
TO CHANGE FAN SPEED AND OPERATION MODE
During operation
TouchSELECTORpadandselectthe
operation mode and fan speed.
•SELECTORindicatoranddisplaywilllight
in order as you touch.
NOTES ON OPERATION MODE:
SELECTOR DISPLAY
HIGH COOL
MED COOL
LOW COOL
HIGH FAN
MED FAN
LOW FAN
• The latest operation mode will be memorized and the selector indicator and display
will light when the unit is turned on.
• In fan only operation, the temperature display will go off.
• When the SELECTOR is changed to fan only operation from cooling operation, it will
take 5 seconds for the compressor to stop.
COOL
COOL
COOL
FAN
FAN
FAN
MODE
Cooling operation with high fan speed.
Cooling operation with medium fan speed.
Cooling operation with low fan speed.
Fan only operation with high fan speed.
Fan only operation with medium fan speed.
Fan only operation with low fan speed.
HIGH COOL MED COOL
MED FANLOW FAN
LOW COOL
HIGH FAN
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
SELECTOR indicator
SELECTOR pad

8
AF-P80CX
ENERGY SAVER
TO CHANGE AIR FLOW DIRECTION
Horizontal louvers
Adjust UP/DOWN air flow
The horizontal louvers are used to adjust the UP / DOWN direction of air flow, and the vertical
louvers are used to adjust the LEFT / RIGHT direction of air flow for uniform and efficient
cooling of the room.
During normal operation, the thermostat automatically controls cooling and the fan runs
continuously. When the ENERGY SAVER is selected, the thermostat automatically controls
cooling and the fan automatically stops when the compressor is not operating. (Fan will stop 30
seconds after the compressor stops. After the fan stops, the fan is programmed to rotate for
approx. 2 minutes to detect room temperature. This will occur within a 20 min time span.)
2Tocancel,touchENERGYSAVER
pad again.
•ENERGY SAVER indicator will go
off.
NOTE: ENERGY SAVER cannot be set during fan only (HIGH FAN, MED FAN, LOW FAN)
operation.
During cooling operation
1
Vertical louvers
Adjust LEFT/RIGHT air flow
Lever
Touch ENERGY SAVER pad.
•ENERGY SAVER indicator will light.
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
ENERGY SAVER indicator
ENERGY SAVER pad
Adjust UP/DOWN air flow

9
AF-P80CX
ONTIMER OPERATION
(If you wish to start the operation
6 hours and 30 minutes later, set
the delay time as shown above.)
1Touch the TIMER ON/OFF pad to set
the delayed start time.
•Thetimesettingwillchangeasyoutouchthe
pad. The display will change as follows;
•The timer will be set, 5 seconds after the
TIMER ON/OFF pad is touched for the last
time.
•SELECTOR indicator and TIMER indicator
will light.
•The time display will count down the
remaining time.
•The unit will start when the set time expires.
The temperature setting will be displayed.
•This unit has a built-in timer that can be programmed to start the unit up to 12 hours in advance. You can
set the timer to start in increments of 30 minutes (0.5 hours) up to 9.5 hours in advance of the start time,
or in 1 hour increments from 10 to 12 hours in advance of the start time.
•The unit will start automatically according to your setting.
NOTES FOR TIMER SETTING AND OPERATION:
•After setting the TIMER, change the temperature and fan speed settings as shown on pages 11 and 12.
When the temperature is set in the timer mode, the temperature will show in the display for 5 seconds
and then return to the time display.
•The last setting used will be memorized and will appear on the display the next time you operate the unit
with the TIMER function.
•Ifa power failure occurswhiletheONor OFF TIMER isset,theTIMERmemory will be cancelledandwill
not resume even after power is reinstated. The unit will not automatically start.
•OFF TIMER OPERATION can also be set with the REMOTE CONTROL.
When the unit is not operating
TO CANCEL THE TIMER SETTING
Touch the TIMER ON/OFF pad again after the
timer is set, or press the TIMER ON/OFF pad
until CL(cancel) appears on the display.
0.5h 1.0h 1.5h 10h
Preset(0.5h)
Previous setting
11h12h
CL(cancel)
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
SELECTOR indicator
TIMER ON/OFF pad
TIMER indicator

10
AF-P80CX
OFFTIMER OPERATION
•This unit has a built-in timer that can be programmed to shut the unit off up to 12 hours in advance. You
can set the timer to stop in increments of 30 minutes (0.5 hours) up to 9.5 hours in advance of the stop
time, or in 1 hour increments from 10 to 12 hours in advance of the stop time.
•The unit will stop automatically according to your setting.
1Touch the TIMER ON/OFF pad to set
the delayed stop time.
•Thetimesettingwillchangeasyoutouchthe
pad. The display will change as follows;
•The timer will be set, 5 seconds after the
TIMER ON/OFF pad is touched for the last
time.
•TIMER indicator will light.
•The time display will count down the
remaining time.
•The unit will stop when the set time expires.
All indicators and displays will go out.
(If you wish to stop the operation
10 hours later, set the delay time
as shown above.)
TO CANCEL THE TIMER SETTING
Touch the TIMER ON/OFF pad again after the
timerissetor,presstheTIMERON/OFFpad until
CL(cancel) appears on the display.
When the unit is operating
0.5h 1.0h 1.5h 10h
Preset(0.5h)
Previous setting
11h12h
CL(cancel)
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
TIMER indicator
TIMER ON/OFF pad

11
AF-P80CX
Remove the battery compartment cover.
Insert the batteries in the compartment,
making sure the and polarities
are properly aligned.
Replace the cover.
INSTALLING BATTERIES
Use two AA (R6) batteries.
Batterycompart-
ment cover
NOTES:
•The battery life is approximately one year with normal use.
•When you replace the batteries, always use two new ones of the same type.
•If the remote control does not operate normally after replacing the batteries, take out
the batteries and replace them again after 30 seconds.
•If you will not be using the unit for a long time, remove the batteries from the remote
control.
HOWTO USETHE REMOTE CONTROL
Point the remote control towards the unit's receiver window and press the desired button.
A beep will sound when the unit receives the signal.
•Make sure no objects, such as curtains, block the receiver window.
•The remote control operates from up to 20 feet (6 meters) away.
•The beep will also sound when each pad on the control panel is touched.
CAUTION:
•Do not expose the receiver window to direct
sunlight. This can adversely affect its opera-
tion. In such case, close the curtains to block
the sunlight.
•Use of a fluorescent lamp in the same room
may interfere with the transmission of the
signal.
•The unit may be affected by signals emitted
fromtheremotecontrolofatelevision,VCRor
other equipment used in the same room.
•Do not leave the remote control exposed to
direct sunlight or near a heater. Protect the
remotecontrolfrommoistureandshockwhich
can discolor or damage it.
2
1
3
USINGTHE REMOTE CONTROL

12
AF-P80CX
ON / OFF
SELECTOR
SET TIMER / OFF
POWER
ON / OFF
TEMP.
•Thetimesettingwillchangeasyoupushthebutton. Thedisplay
will change as follows;
•The last OFF time setting is memorized by the unit and will
appear on the display when the button is pushed.
•Thetimerwillbeset,5secondsaftertheSETTIMER/OFFbutton
is pushed for the last time.
•Ifyouwishtocancelthetimer,pushtheSETTIMER/OFFbutton
again after the time is set or, push the SET TIMER/OFF button
until CL (cancel) appears on the display. A double beep will
sound when the timer is cancelled.
•The "ON" TIMER cannot be set with the remote control.
It can only be activated by the TIMER ON/OFF pad on the unit's
control panel ( See page 9 ).
TEMP.
TEMP. ---Raise temp. setting 1°F at a time.
---Lower temp. setting 1°F at a time.
OPERATING WITHTHE REMOTE CONTROL
TRANSMITTER
TEMPERATURE setting button
POWER ON/OFF button
Push to start or stop the operation.
SELECTOR button
Push to change fan speed and operation
mode.
Fan speed and operation mode selec-
tions are shown to the right.
SET TIMER/OFF button
Push to set delay "OFF" timer during operation.
To change temperature setting when ON/OFF timer is in use
1. Push a TEMPERATURE setting button.
The current set temperature will be recalled on the unit's display.
2. Use the TEMPERATURE setting buttons to set the new temperature.
The new set temperature will show on the display for 5 seconds and return to
the time display.
HIGH COOL
MED COOL
LOW COOL
HIGH FAN
MED FAN
LOW FAN
0.5h 1.0h 1.5h 10h
Preset(0.5h)
Previous setting
11h12h
CL(cancel)
PLASMACLUSTER button (See page 13)

13
AF-P80CX
ON / OFF
SELECTOR
SET TIMER / OFF
POWER
ON / OFF
TEMP.
PLASMACLUSTER OPERATION
During operation
Cluster ions are released into the room, keeping air your room clean.
1Press PLASMACLUSTER button.
•PLASMACLUSTER indicator will light.
2Tocancel, pressPLASMACLUSTER
button again.
•PLASMACLUSTER indicator will go off.
NOTE:
PLASMACLUSTER button
PLASMACLUSTER operation will be
memorizedwhenoncesetandwillstartits
operation the next time the unit is turned
on.
POWER
ON/OFF
hr
F
SELECTOR
TIMER
ON/OFF
ENERGY
SAVER
COOL / FAN TEMP
PLASMACLUSTER indicator

14
AF-P80CX
NOTE FOR PLASMACLUSTER OPERATION
The ionizer inside the air conditioner will discharge cluster ions, which are collective
mass of positive and negative ions, into the room.
The cluster ions reduce airborne mold fungus and deodorize/decompose odor-
causing molecules.
Reduce, deodorize, decompose
Ionizer
Cluster ions
Mold fungus
Odor

15
AF-P80CX
10
8
6
7
3
45
1
2
10
9
8
7
6
5
4
3
2
1
ACCESSORIES
No. Accessories Q'ty
Right closure assembly 1
Left closure assembly 1
Window sash foam seal 1
1. Screw driver (medium size Phillips)
2. Tape measure or ruler
3. Knife or scissors
6 7
2
2
SUGGESTEDTOOLS
Window sash foam seal 1
(adhesive type)
Bottom gasket 1
Screws (L=1", 25.4mm) 7
Screws (L= 13/32", 10mm) 6
Base pan angle 2
Remote control 1
Battery 2
9
INSTALLATION INSTRUCTIONS

16
AF-P80CX
Insert the right closure assembly and the
left closure assembly into the top angle
and the bottom channels.
Secure the right and left closure to the
cabinet with six of the provided screws.
(L= 13/32", 10mm)
2
3Open the window sash and place theair
conditioner on the sill.
Balance the unit on the sill and closethe
window sash securely behind the top
angle.
4Insert the bottom gasket into the space
betweenthewindowsilland the bottomof
the unit to seal outside air.
If there is space between the bottom
channelandthesill, fill the gap with athin
board or other hard filler.
Closure assembly
Bottom gasket
Cut the window sash foam seal (adhesive
type) to the proper length and attach it to
the underside of the window sash.
1
WARNING: Make sure the unit is turned off and unplugged before working.
Sash
Jamb
Sill
Window sash foam seal
(adhesive type)
WARNING: unit
sill incline backwards approximately
1cm (3/8")
At this step, make sure the unit is inclined
approximately 1 cm (3/8") to the back.
If the unit is not properly inclined, the water
collected in the bottom tray during opera-
tionwill notdrain properlyand mayflowinto
the room where the air conditioner is in-
stalled.
INSTALLATION

17
AF-P80CX
1/2 inches
(13mm)
Indoor
side
Indoor
side
7
8Secure the top angle of the unit and the
top of the closure assemblies to the sash
with three of the provided screws. (L=1",
25.4mm)
And secure the bottom of the closure
assemblies to the sill with two of the
provided screws. (L=1", 25.4mm)
9Cut the window sash foam seal to the
proper length and seal the opening be-
tween the top of the inside window sash
and the outside window sash.
6
Top angle
Window sash foam seal
Secure the base pan angle to the sill by
using the hole of the front side on the
angle with one screw. (L=1", 25.4mm)
Loosen screws on both sides of the
cabinet, then hang the base pan angle
on and secure the screws again.
Insert the closure assemblies on both
sides into the rails of the jamb.
5
Jamb
(Left)
Sill
Stool
Closure assembly
(Left)
Closure assembly
(Left)

18
AF-P80CX
1. Unscrew the 2 screws holding the front panel on each
side.
DISASSEMBLING PROCEDURE
CAUTION: DISCONNECT THE ROOM AIR CONDITIONER FROM THE POWER SUPPLY BEFORE ANY SERVICE
2. Remove the front panel by pulling the front panel at the
lower corner toward you about one inch.
Next lift up and pull it toward you.
5. Unscrew the 2 screws holding wire fixing band.
6. Unscrew the 2 csrews holding cover and holder.
4. Remove the thermistor holder.
7. Remove the control panel.
3. Unscrew the 8 screws holding the cabinet.
2 screws are on each side.
4 screws are on back side.
2 screws are on top side.
And remove the cabinet.
8. Take off the fan motor connector.
9. Unscrew the 5 screws.
3 screws are holding the control box at the top and
right side.
1 screw is holding the power supply cord.
1 screw each screw on the evaporator.

19
AF-P80CX
10. Cut the wire fixing band, slide the control box rightward
and remove. 14. Unscrew the 2 screws holding the condenser shround.
And remove the condenser shround.
11. Unfasten the one nut at the top of the compressor
holding the terminal cover.
Then remove the wiring connector of the compressor
cord.
15. Unscrew the 7 screws.
4 screws are holding the evaporator on each side.
3 screws are holding the bulkhead to the base pan on
each side and back side.
12. Unscrew the 4 screws holding the condenser.
1 screw is on right side.
1 screw is on left side.
2 screws are on back side.
And remove the condenser from the unit.
13. Unfasten the nut holding the propeller fan by rotating it
counter-clockwise. And remove the propeller fan.
Slide
16. Lift up and take out the bulkhead.
17. Unscrew the 1 screw holding the orifice.
18. Unscrew the 1 screw holding the top duct ass'y.

20
AF-P80CX
19. Unscrew the 1 screw holding the centrifugal fan. 20. Unscrew the 1 screw holding wire holder.
Unscrew the 3 screws holding fan motor.
DISASSEMBLINGTHE CONTROL BOX
1. Unscrew the 1 screw holding the control box cover.
CAUTION: DISCHARGE THE FAN MOTOR CAPACITOR
AND RUNNING CAPACITOR BEFORE
TOUCHINGTHOSE CAPACITORSOROTHER
COMPONENTS OR WIRING.
4. Unscrew the 1 power supply cord grounding screw.
Unscrew the earth screw. Unscrew the 1 screw holding
the capacitor clamp and the fan motor capacitor.
2. Unscrew the 3 screws holding the printed wiring board. 5. Detach each connector by using long-noise pliers.
6. Unscrews the 2 screws holding the transformer and
removethecontrolboardwith unhooking the2spacers.
3. Cut the wire fixing bands holding the fan motor lead
wires, the compressor cord and the power supply cord.
