Sharp AY-AP18GR User manual

AY-AP18GR
AY-AP24GR
AY-AP18GR
AY-AP24GR
SPLIT TYPE
ROOM AIR CONDITIONER
OPERATION MANUAL
CONDIZIONATORE D’ARIA
RESIDENZIALE MONOSPLIT
MANUALE DI ISTRUZIONI
AR CONDICIONADO DE SALA
DE DUAS UNIDADES
MANUAL DE OPERAÇÃO
ΑΙΡΚΟΝΤΙΣΙΟΝ ∆ΩΜΑΤΙΟΥ
ΤΥΠΟΥ SPLIT
ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
SPL∑T KL∑MA
KULLANMA KILAVUZU
ENGLISH
AE-A18GR
AE-A24GR
*Plasmacluster is a trademark of
SHARP Corpration.
ITALIANO
PORTUGUÊS
INDOOR UNIT
UNITÀ INTERNA
UNIDADE INTERIOR
ΕΣΩΤΕΡΙΚΗ ΣΥΣΚΕΥΗ
∑Ç ÜN∑TE
OUTDOOR UNIT
UNITÀ ESTERNA
UNIDADE EXTERIOR
ΕΞΩΤΕΡΙΚΗ ΣΥΣΚΕΥΗ
DIΩ ÜN∑TE
ΕΛΛΗΝΙΚΑ
TÜRKÇE

EN
A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the ordinary dust
bin!
Used electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and recycling of
used electrical and electronic equipment.
Following the implementation by member states, private households within the EU
states may return their used electrical and electronic equipment to designated
collection facilities free of charge*. In some countries* your local retailer may also
take back your old product free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators, please
dispose of these separately beforehand according to local requirements.
By disposing of this product correctly you will help ensure that the waste undergoes
the necessary treatment, recovery and recycling and thus prevent potential negative
effects on the environment and human health which could otherwise arise due to
inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the
correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of
charge to the dealer, even if you don’t purchase a new product. Further collection
facilities are listed on the homepage of www.swico.ch or www.sens.ch.
B. Information on Disposal for Business Users.
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back of the
product. You might be charged for the costs arising from take-back and recycling.
Small products (and small amounts) might be taken back by your local collection
facilities.
For Spain: Please contact the established collection system or your local authority for
take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for
the correct method of disposal.
Attention: Your product is
marked with this symbol. It
means that used electrical
and electronic products
should not be mixed with
general household waste.
There is a separate
collection system for these
products.

ENGLISH
E-1
ENGLISH
Thank you for purchasing a SHARP air conditioner. Please read this manual carefully
before operating the product.
• IMPORTANT SAFEY INSTRUCTIONS ........ E-1
• ADDITIONAL NOTES ON OPERATION ...... E-3
• TIPS ON SAVING ENERGY......................... E-3
• PART NAMES............................................... E-4
• USING THE REMOTE CONTROL ............... E-6
• BASIC OPERATION ..................................... E-8
• ADJUSTING THE AIR FLOW DIRECTION ...... E-9
• TIMER OPERATION..................................... E-10
CONTENTS
• TURBO OPERATION .............................E-12
• ONE-HOUR OFF TIMER ........................E-12
• PLASMACLUSTER OPERATION .......... E-13
• AUXILIARY MODE ................................. E-13
• MAINTENANCE......................................E-14
• OPTION KIT ...........................................E-14
• BEFORE CALLING FOR SERVICE ....... E-15
IMPORTANT SAFETY INSTRUCTIONS
WARNINGS FOR USE
1Donotpullordeformthepowersupplycord.Pullingandmisuseofthepowersupplycord
can result in damage to the unit and cause electrical shock.
2Be careful not to expose your body directly to the outlet air for a long time. It may affect
your physical conditions.
3Whenusingtheairconditionerforinfants,children,elderly,bedridden,ordisabledpeople
make sure the room temperature is suitable for those in the room.
4Never insert objects into the unit. Inserting objects can result in injury due to the high
speed rotation of internal fans.
5Ground the air conditioner without fail. Do not connect the grounding wire to gas pipe,
waterpipe,lightningrodortelephonegroundingwire. Incompletegroundingmaycause
electric shock.
6If anything is abnormal with the air conditioner (ex. a burning smell), stop the operation
immediately and turn the circuit breaker OFF.
7Theapplianceshallbeinstalledinaccordancewithnationalwiringregulations.Improper
cable connection can cause the power supply cord, plug and the electrical outlet to
overheat and cause fire.
8Ifthesupplycordisdamaged,itmustbereplacedbythemanufactureroritsserviceagent
or a similarly qualified person in order to avoid a hazard. Use only the manufacture-
specified power cord for replacement.
WARNINGS FOR INSTALLATION / REMOVAL / REPAIR
• Donot attempttoinstall/remove/repairtheunitbyyourself. Incorrect workwillcauseelectric
shock, water leak, fire etc. Consult your dealer or other qualified service personnel for the
installation/removal/repair of the unit.

IMPORTANT SAFETY INSTRUCTIONS
CAUTIONS FOR USE
1Open a window or door periodically to ventilate the room, especially when using gas
appliances. Insufficient ventilation may cause oxygen shortage.
2Do not operate the buttons with wet hand. It may cause electric shock.
3For safety, turn the circuit breaker off when not using the unit for an extended period of
time.
4Check the outdoor unit mounting rack periodically for wear and to make sure it is firmly
in place.
5Do not put anything on the outdoor unit nor step on it. The object or the person may fall
down or drop, causing injury.
6This unit is designed for residential use. Do not use for other applications such as in a
kennel or greenhouse to raise animals or grow plants.
7Do not place a vessel with water on the unit. If water penetrates into the unit, electrical
insulations may deteriorate and cause electric shock.
8Do not block the air inlets nor outlets of the unit. It may cause insufficient performance
or troubles.
9Be sure to stop the operation and turn the circuit breaker off before performing any
maintenance or cleaning. A fan is rotating inside the unit and you may get injured.
10
Do not splash or pour water directly on the unit. Water can cause electrical shock or
equipment damage.
11
This appliance is not intended for use by young children or infirm persons without
supervision.
Young children should be supervised to ensure that they do not play with the appliance.
CAUTIONS FOR LOCATION / INSTALLATION
• Make sure to connect the air conditioner to power supply of the rated voltage and
frequency.
Use of a power supply with improper voltage and frequency can result in equipment
damage and possible fire.
• Do not install the unit in a place where inflammable gas may leak. It may cause fire.
Install the unit in a place with minimal dust, fumes and moisture in the air.
• Arrangethedrainhosetoensuresmoothdrainage. Insufficientdrainagemaycausewetting
of the room, furniture etc.
• Make sure a leak breaker or a circuit breaker is installed, depending on the installation
location, to avoid electrical shock.
E-2

ENGLISH
E-3
INDOOR TEMP. OUTDOOR TEMP.
COOLING upper limit 32˚C46˚C
lower limit 21˚C21˚C
HEATING upper limit 27˚C24˚C
lower limit - -7˚C
ADDITIONAL NOTES ON OPERATION
OPERATING TEMPERATURE RANGE • The built-in protective de-
vice may prevent the unit
from operating when used
out of this range.
• Condensation may form on
the air outlet if the unit op-
erates continuously in the
COOL or DRY mode when
humidity is over 80 percent.
PREHEATING FUNCTION
In the HEAT operation, the indoor fan may not start for two to five minutes after the unit is turned on
to prevent cold air from blowing out of the unit.
DE-ICING FUNCTION
• When ice forms on the heat exchanger in the outdoor unit during the HEAT operation, an
automatic de-icer provides heat for about 5 to 10 minutes to remove the ice. During de-icing, the
inside and outside fans stop operating.
• After de-icing is completed, the unit automatically resumes operation in the HEAT mode.
HEATING EFFICIENCY
• The unit employs a heat pump that draws heat from the outside air and releases it into the room.
The outside air temperature therefore greatly affects the heating efficiency.
• If the heating efficiency is reduced due to low outside temperatures, use an additional heater.
• It takes time to warm up and heat the entire room because of the forced air circulation system.
WHEN POWER FAILURE OCCURS
This air conditioner has a memory function to store settings when a power failure occurs.
After power recovery, the unit will automatically re-start in the same settings which were active before
the power failure, except for timer settings.
If the timers were set before a power failure, they will need to be re-set after power recovery.
TIPS ON SAVING ENERGY
Below are some simple ways to save energy when you use your air conditioner.
SET THE CORRECT TEMPERATURE
• Setting the thermostat 1°C higher than the desired temperature in the COOL mode and 2°C lower
in the HEAT mode will save approximately 10 percent in power consumption.
• Setting the temperature lower than necessary during cooling operation will result in increased
power consumption.
BLOCK DIRECT SUNLIGHT AND PREVENT DRAFTS
• Blocking direct sunlight during cooling operation will reduce power consumption.
• Close the windows and doors during cooling and heating operations.
SET PROPER AIR FLOW DIRECTION TO OBTAIN THE BEST AIR
CIRCULATION
KEEP FILTER CLEAN TO ENSURE THE MOST EFFICIENT OPERATION
MAKE MOST OF THE TIMER OFF FUNCTION
DISCONNECT THE POWER CORD WHEN THE UNIT IS NOT USED FOR AN
EXTENDED PERIOD OF TIME
• The indoor unit still consumes a small amount of power when it is not operating.

PART NAMES
1Inlet (Air)
2Open Panel
3AUX. Button
4Air Filters
5Receiver Window
6Power Supply Cord
(AY-AP18GR only)
7Indicator
8Vertical Adjustment Louvre
9Horizontal Adjustment Louvres
0Outlet (Air)
qRemote Control
wTURBO Lamp (green )
eTIMER Lamp (orange )
rOPERATION Lamp (red )
tPLASMACLUSTER Lamp (blue)
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
1
2
3
4
5
6
7
8
9
0
q
yInlet(Air)
uRefrigerant Tube and
Interconnecting Cord
iDrainage Hose
oOutlet(Air)
E-4
w
e
r
t
y
u
i
o

ENGLISH
REMOTE CONTROL
1TRANSMITTER
2DISPLAY (Liquid Crystal Display)
3ON/OFF Button
4TEMP. Button
5DISPLAY Button
6PLASMACLUSTER Button
7ONE-HOUR OFF TIMER Button
8MODE Button
9TIMER ON Button (for setting the timer)
0FAN Button
qTIMER OFF Button (for setting the timer)
wSWING Button
eTIMER CANCEL Button
rTURBO Button
tRESET Button
yMODE SYMBOLS
: AUTO : HEAT
: COOL : DRY
uTURBO SYMBOL
iPLASMACLUSTER SYMBOL
oFAN SPEED SYMBOLS
: AUTO : Manual setting
pTEMPERATURE AND TIMER COUNT DOWN
INDICATOR
aTRANSMITTING SYMBOL
sTIMER ON/TIMER OFF INDICATOR
Indicates when timer on or timer off is set.
L.C.D. REMOTE CONTROL DISPLAY
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
i
o
p
a
s
PART NAMES
E-5

1Remove the battery cover at the back
of the remote control.
2Insert batteries in the compartment,
making sure the ±and —
polarities are correctly aligned.
• Lines will be indicated on the dis-
play when batteries are properly in-
stalled.
3Reinstall the battery cover.
4Press the RESET button using a thin
stick.
USING THE REMOTE CONTROL
E-6
NOTES:
• The battery life is approximately one year in normal use.
• When you replace the batteries, always change both batteries, and make sure
they are the same type.
• If the remote control does not operate properly after replacing the batteries, press
the RESET button using a thin stick.
• If you will not be using the unit for a long time, remove the batteries from the
remote control.
Point the remote control towards the
unit’s signal receiver window and
press the desired button. The unit
generates a beep when it receives
the signal.
• Make sure there is no curtain or other
object between the remote control and
the unit.
• The remote control can send signals from
up to 7 metres away.
LOADING BATTERIES Use two size-AAA (R03) batteries.
HOW TO USE THE REMOTE CONTROL
Remote control
cover

ENGLISH
CAUTION
• Do not allow the signal receiver window to receive strong direct sunlight, since it can
adversely affect its operation. If the signal receiver window is exposed to direct sunlight,
close a curtain to block the light.
• Using a fluorescent lamp with a quick starter in the same room may interfere with
transmission of the signal.
• The unit can be affected by signals transmitted from the remote control of a television,
VCR or other equipment used in the same room.
• Do not leave the remote control in direct sunlight or near a heater. Also, protect the unit
and remote control from moisture and shock which can discolour or damage them.
E-7

Press the TEMP. button to set the
desired temperature.
AUTO/DRY MODE
The temperature can be changed in 1°C
increments within the range of 2°C higher
to 2°C lower from the temperature auto-
matically determined by the air conditioner.
COOL/HEAT MODE
The temperature can be set within the
range of 18 to 32°C.
1
E-8
BASIC OPERATION
2Press the ON/OFF button to start
operation.
• The red OPERATION lamp ( ) on the
unit will light.
3
4
Press the MODE button to select
the operation mode.
AUTO HEAT COOL DRY
5
Press the FAN button to set the
desired fan speed.
AUTO SOFT LOW HIGH
• In the DRY mode, the fan speed is pre-
set to AUTO and cannot be changed.
Automatic Operation
Mode Temperature Setting
Below 21°C HEAT 23°C
21°C-24°C DRY Room Temp. at start-up
24°C-26°C COOL 24°C
26°C-28°C COOL 25°C
Above 28°C COOL 26°C
Modes and Temperature Settings
Room temp.
at operation
start-up
TIPS ABOUT AUTO MODE
In the AUTO mode, the temperature set-
ting and mode are automatically selected
according to the room temperature when
the unit is turned on.
To turn off the unit, press the ON/
OFF button again.
• The red OPERATION lamp ( ) on the
unit will turn off.
1
4
5
2
3

ENGLISH
E-9
ADJUSTING THE AIR FLOW DIRECTION
VERTICAL AIR FLOW DIRECTION
The adjustment range
is narrower the SWING
range in order to pre-
vent condensation from
dripping.
Hold the horizontal adjustment louvre as
shown in the diagram and adjust the air flow
direction.
Press the SWING button on the remote con-
trol once.
• The vertical adjustment louvre will change
its angle continuously.
Press the SWING button again when the
vertical adjustment louvre is at the desired
position.
• The louvre will stop moving within the range
shown in the diagram.
• The adjusted position will be memorized
and will be automatically set to the same
position when operated the next time.
Adjustment range
HORIZONTAL AIR FLOW DIRECTION
CAUTION
Never attempt to adjust the vertical adjustment louvres manually.
• Manual adjustment of the vertical adjustment louvre can cause the unit to malfunction
when the remote control is used for adjustment.
• When the vertical adjustment louvre is positioned at the lowest position in the COOL or
DRY mode for an extended period of time, condensation may result.
Do not adjust the horizontal adjustment louvre to the extreme left or right in the COOL mode
with the fan speed set to "SOFT( )" for an extended period of time.
Condensation may form on the louvres.
COOL and DRY modes
The range is wide
and air flow can be
directed toward the
floor.
HEAT mode
1
2
1
2

E-10
The unit will turn off automatically according to your setting.
Timer duration can be set from a minimum half an hour (30 minutes) to a maximum
of 12 hours.
Up to 9.5 hours, you can set in half-hour (30-minute) increments, and from 10 to 12
hours, in 1-hour increments.
TIMER OPERATION
TIMER OFF
WhentheTIMEROFFisset,thetemperature
setting is automatically adjusted to prevent
the room from becoming excessively cold
while you sleep. (Auto Sleep function)
COOL/DRY MODE:
• Onehourafterthetimeroperationbegins,
the temperature setting rises 1°C higher
than the original temperature setting.
HEAT MODE:
• Onehourafterthetimeroperationbegins,
the temperature setting drops 3°C lower
than the original temperature setting.
1
TO CANCEL TIMER
TIPS ABOUT TIMER OFF OPERATION
Point the remote control at the signal receiver win-
dow on the unit.
1Press the TIMER OFF ( ) button and set
the time as desired.
• The time setting will change as you press the
button as follows,
Hold the button down to speed through the
settings.
• The orange TIMER lamp ( ) on the unit
will light.
• The unit will generate a beep when it re-
ceives the signal.
• The time setting will count down to show the
remaining time.
Display shown when you
set the unit to ture off 2.5
hours later.
Press the CANCEL button.
• The orange
TIMER lamp
( ) on the
unit will turn
off.
TO CHANGE TIMER SETTING
Press the TIMER button which you wish to
change, (TIMER OFF or TIMER ON) and
change the time setting.
0.5h 1.0h 1.5h 10h 11h 12h

ENGLISH
The unit will turn on automatically according to your setting.
Timer duration can be set from a minimum of half an hour (30 minutes) to a
maximum of 12 hours.
Up to 9.5 hours, you can set in half-hour (30 minute) increments, and from 10 to 12
hours, in 1-hour increments.
TIMER ON
1
Point the remote control at the signal reciever window
on the unit.
1Press the TIMER ON ( ) button.
• The time setting will change as you press the
button as follows.
Hold the button down to speed through the set-
ting.
• The orange TIMER lamp ( ) on the unit will
light.
• The unit will generate a beep when it receives
the signal.
• The time setting will count down to show the
remaining time.
Select the mode, temperature and fan speed set-
ting as desired.
• When the temperature is set with the TIMER ON, the
temperature will show in the display for 5 seconds
and then return to the time display.
• If you do not change the setting, the unit will operate
using the most recent settings.
• The unit will turn on prior to the set time to allow the
room to reach the desired temperature by the pro-
grammed time. (Awaking function)
Display shown when you
set the unit to reach the
desired room temperature
6.5 hours later.
E-11
NOTES ON TIMER SETTING AND OPERATION
• The latest time setting will be memorized and will appear on the remote control display
the next time you set the TIMER OFF or TIMER ON.
• The TIMER OFF and TIMER ON can not be set together.
Only the most recent TIMER setting will be valid.
• While ONE-HOUR OFF TIMER is set, the TIMER OFF and TIMER ON setting are
unavailable.
• If the ONE-HOUR OFF TIMER is set while the TIMER OFF or TIMER ON is activated,
the TIMER ON or TIMER OFF setting will be cancelled.
0.5h 1.0h 1.5h 10h 11h 12h

TURBO OPERATION
1Press the TURBO button during operation.
• The remote control will display " ".
• The temperature display will go off.
• The green TURBO lamp ( ) on the unit will light
up.
TO CANCEL
1
In this operation, the air conditioner fan works at "extra high" speed with a setting
temperature of 15°C in COOL and DRY modes and 32°C in HEAT mode to rapidly cool
or heat the room.
Press the TURBO button again.
• TURBO operation will also be cancelled when the
operation mode is changed, or when the unit is
turned off.
• The green TURBO lamp ( ) on the unit will turn
off.
E-12
1Press the ONE-HOUR OFF TIMER button.
• The remote control will display “ ”.
• The orange TIMER lamp ( ) on the unit will light
up.
• The unit will stop operating after one hour.
TO CANCEL
Press the CANCEL button.
• The orange TIMER lamp ( ) on the unit will turn
off.
Alternatively, turn the unit off by pressing the
ON/OFF button.
• The red OPERATION lamp ( ) and the orange
TIMER lamp ( ) on the unit will turn off.
1
When the ONE-HOUR OFF TIMER is set, the unit will automatically turn off after one
hour.
ONE-HOUR OFF TIMER
NOTES:
• The ONE-HOUR OFF TIMER operation has priority over TIMER ON and TIMER OFF
operations.
• If the ONE-HOUR OFF TIMER is set while the unit is not operating, the unit will operate for
an hour at the formerly set condition.
• If you wish to operate the unit for another hour before the ONE-HOUR OFF TIMER is
activated, press the ONE-HOUR OFF TIMER button again during operation.
NOTES:
• You cannot set the temperature or fan speed during TURBO operation.
• After the unit has run for 30 minutes in TURBO operation, the fan setting will become the
"HIGH" speed, and temperature setting will become 18°C in COOL and DRY modes.
• To turn off the TURBO lamp, press the DISPLAY button.

ENGLISH
1During operation, press the PLASMACLUSTER
button.
• The remote control will display " ".
• The blue PLASMACLUSTER lamp on the unit will
light up.
TO CANCEL
Press the PLASMACLUSTER button again.
• The PLASMACLUSTER lamp on the unit will turn
off.
1
NOTES:
• Use of the PLASMACLUSTER operation will be memorized, and it will be activated the next
time you turn on the air conditioner.
• To turn off the PLASMACLUSTER lamp, press the DISPLAY button.
• When the PLASMACLUSTER button is pressed while the unit is not operating, the
PLASMACLUSTERoperationwillbeperformedwithoutaccompanyingairconditioningmode
(eg, HEATING or COOLING). The mode symbol of the remote control will go off and the fan
speed can not be set AUTO.
PLASMACLUSTER OPERATION
The Plasmacluster ion generator inside the air conditioner will release positive and
negative Plasmacluster ions into the room.
Approximatelythesame numbersofpositiveandnegative ionsreleasedintotheair will
reduce some airborne mold.
AUXILIARY MODE
Use this mode when the remote control is not available.
TO TURN ON
Lift the front panel of the indoor unit and press the
AUX. button on the operation panel.
• The red OPERATION lamp ( ) on the unit will light
and the unit will start operating in the AUTO mode.
• The fan speed and temperature setting are set to AUTO.
TO TURN OFF
Press the AUX. button on the operation panel again.
• The red OPERATION lamp ( ) on the unit will turn off.
NOTE:
If the AUX. button is pressed during normal operation, the
unit will turn off.
E-13

E-14
CLEANING THE UNIT AND THE REMOTE CONTROL
Be sure to disconnect the power cord from the wall outlet or turn off the circuit
breaker before performing any maintenance.
MAINTENANCE AFTER AIR
CONDITIONER SEASON
1Operate the unit in the COOL mode,
temperature setting 32°C, for about
half a day to allow the mechanism to
thoroughly dry.
2Stop the operation and unplug the unit.
Turn off the circuit breaker.
3Clean the filters, then reinstall them.
MAINTENANCE BEFORE
AIR CONDITIONER SEASON
1Make sure that the air filters are not
dirty.
2Make sure that nothing obstructs the
air inlet or outlet.
3Check the outdoor mounting rack pe-
riodically for wear and to make sure
it is firmly in place.
• Wipe them with a soft cloth.
• Do not directly splash or pour water on them, or it can cause electrical shock or equipment
damage.
• Do not use hot water, thinner, abrasive powders or strong solvents.
MAINTENANCE
CLEANING THE FILTERS The air filters should be cleaned every two weeks.
1TURN OFF THE UNIT
2REMOVE THE FILTERS
1Lift the open panel.
2Push the air filters up slightly to unlock them.
3Pull the air filters down to remove them.
3CLEAN THE FILTERS
Use a vacuum cleaner to remove dust. If the
filters are dirty, wash them with warm water and a
mild detergent. Dry filters in the shade before
reinstalling.
4REINSTALL THE FILTERS
1Reinstall the filters in the original positions.
2Close the open panel.
3Push the arrow-marked points shown left firmly
to lock it in place.
OPTION KIT
Air Purifying Filter
During operation of the air conditioner, the air purifying filter removes dust and
tobacco smoke from the air and discharges clean air.
The apatite antibacterial material used in the air purifying filter suppresses
activities of adsorbed viruses and other germs.
The replacement period for the disposable type is approximately 3~6 months.
Contact your dealer for the purchase of this option. Type AZ-F1800C
1
23
2
3
1

ENGLISH
E-15
BEFORE CALLING FOR SERVICE
IF THE UNIT FAILS TO RECEIVE THE REMOTE CONTROL SIGNAL
Check whether the remote con-
trol batteries have become old
and weak.
Try to send the signal again with
the remote control pointed prop-
erly towards the unit’s signal re-
ceiver window.
Check whether the remote con-
trol batteries are installed with
the polarities properly aligned.
The following conditions do not denote equipment malfunctions
UNIT DOES NOT OPERATE
The unit will not operate if it is turned on immediately
after it is turned off. The unit will not operate
immediately after the mode is changed. This is to
protect the internal mechanisms. Wait 3 minutes
before operating the unit.
UNIT DOES NOT SEND OUT WARM AIR
The unit is preheating or de-icing.
CRACKING NOISE
The unit may produce a cracking noise. This sound
is generated by the friction of the front panel and
othercomponentsexpandingor connectingduetoa
temperature change.
If the unit appears to be malfunctioning, check the following points before calling for
service.
IF THE UNIT FAILS TO OPERATE
Check to see if the circuit breaker has tripped or the fuse has blown.
IF THE UNIT FAILS TO COOL (OR HEAT) THE ROOM EFFECTIVELY
Check the filters. If dirty, clean
them. Check the outdoor unit to make
sure nothing is blocking the air in-
let or outlet.
Check the thermostat is proper
setting.
Make sure windows and doors
are closed tightly. A large number of people in the room can prevent the unit from
achieving the desired tempera-
ture.
Check whether any heat-gen-
erating appliances are operat-
ing in the room.
ODORS
Carpet and furniture odors that entered into the
unit and the air conditioner's inner component
odors at the early stage of installation may be sent
out from the unit.
Please call for service when OPERATION lamp and TIMER lamp on the indicator panel blink.
A LOW BUZZING NOISE EMITTED
This is a sound emitted when the unit is generating
Plasmacluster ions.
SWISHING NOISE
The soft, swishing noise is the sound of the refrig-
erant flowing inside the unit.
WATER VAPOUR
• In the COOL and DRY operation, water vapour
can sometimes be seen at the air outlet due to
the difference between the room air tempera-
ture and the air discharged by the unit.
• In the HEAT operation, water vapour may flow
out of the outdoor unit during de-icing.
ODOR EMITTED FROM THE
PLASMACLUSTER AIR OUTLET
This is the smell of ozone generated from the
Plasmacluster Ion generator. The ozone
concentration is very small, posing no adverse
effect on your health. The ozone discharged into
the air rapidly decomposes, and its density in the
room will not increase.

IT
A. Informazioni sullo smaltimento per gli utenti (privati)
1. Nell'Unione europea
Attenzione: Per smaltire il presente dispositivo, non utilizzare il normale bidone della
spazzatura!
Le apparecchiature elettriche ed elettroniche usate devono essere gestite a parte e in
conformità alla legislazione che richiede il trattamento, il recupero e il riciclaggio
adeguato dei suddetti prodotti.
In seguito alle disposizioni attuate dagli Stati membri, i privati residenti nella UE
possono conferire gratuitamente le apparecchiature elettriche ed elettroniche usate a
centri di raccolta designati*.
In alcuni paesi*, anche il rivenditore locale può ritirare gratuitamente il vecchio prodotto se
l'utente acquista un altro nuovo di tipologia simile.
*) Per maggiori informazioni si prega di contattare l'autorità locale competente.
Se le apparecchiature elettriche o elettroniche usate hanno batterie o accumulatori, l'utente
dovrà smaltirli a parte preventivamente in conformità alle disposizioni locali.
Lo smaltimento corretto del presente prodotto contribuirà a garantire che i rifiuti siano
sottoposti al trattamento, al recupero e al riciclaggio necessari prevenendone il
potenziale impatto negativo sull'ambiente e sulla salute umana, che potrebbe derivare
da un'inadeguata gestione dei rifiuti.
2. In paesi che non fanno parte dell'UE
Se si desidera eliminare il presente prodotto, contattare le autorità locali e informarsi
sul metodo di smaltimento corretto.
Per la Svizzera: Le apparecchiature elettriche o elettroniche usate possono essere
restituite gratuitamente al rivenditore, anche se non si acquista un prodotto nuovo.
Altri centri di raccolta sono elencati sulle homepage di www.swico.ch o di www.sens.ch.
B. Informazioni sullo smaltimento per gli utenti commerciali
1. Nell'Unione europea
Se il prodotto è impiegato a scopi commerciali, procedere come segue per eliminarlo.
Contattare il proprio rivenditore SHARP che fornirà informazioni circa il ritiro del
prodotto. Potrebbero essere addebitate le spese di ritiro e riciclaggio. Prodotti piccoli
(e quantitativi ridotti) potranno essere ritirati anche dai centri di raccolta locali.
Per la Spagna: Contattare il sistema di raccolta ufficiale o l'ente locale preposto al
ritiro dei prodotti usati.
2. In paesi che non fanno parte dell'UE
Se si desidera eliminare il presente prodotto, contattare le autorità locali e informarsi
sul metodo di smaltimento corretto.
Attenzione: Il dispositivo è
contrassegnato da questo
simbolo, che segnala di non
smaltire le apparecchiature
elettriche ed elettroniche
insieme ai normali rifiuti
domestici. Per tali prodotti è
previsto un sistema di
raccolta a parte.

ITALIANO
I-1
ITALIANO
Grazie per aver acquistato il condizionatore d’aria SHARP. Leggete attentamente questo
manuale prima di usare il prodotto.
• IMPORTANTI ISTRUZIONI PER
LA SICUREZZA .......................................... I-1
• ULTERIORI NOTE RIGUARDANTI
IL FUNZIONAMENTO................................. I-3
• SUGGERIMENTI PER
RISPARMIARE ENERGIA .......................... I-3
• NOMI DEI COMPONENTI .......................... I-4
• USO DEL TELECOMANDO ....................... I-6
• FUNZIONI DI BASE.................................... I-8
• REGOLAZIONE DELLA DIREZIONE
DEL FLUSSO D’ARIA................................. I-9
INDICE
•FUNZIONAMENTO DEL TIMER ...............I-10
•FUNZIONAMENTO TURBO ......................I-12
•TIMER DI SPEGNIMENTO DOPO
UN’ORA .....................................................I-12
•FUNZIONAMENTO DEL
PLASMACLUSTER....................................I-13
•MODO AUSILIARIO...................................I-13
•MANUTENZIONE ......................................I-14
• KIT OPZIONALE ........................................I-14
•PRIMA DI RICHIEDERE ASSISTENZA ....I-15
IMPORTANTI ISTRUZIONI PER LA SICUREZZA
AVVERTIMENTI PER L’USO
1Non tirate o deformate il cavo di alimentazione. Se si tira o si usa erratamente il cavo,
l’unità si può danneggiare e provocare scosse elettriche.
2Fate attenzione a non esporvi direttamente all’uscita dell’aria per un lungo periodo di
tempo. Potrebbe danneggiare la vostra salute.
3Nelcasosiusiilcondizionatored’ariainpresenzadi neonati,bambini,personeanziane,
persone costrette a stare a letto o persone con handicap fisici, assicuratevi prima che la
temperatura della stanza sia confortevole per tali persone.
4Noninseritemaioggettinell’unità.Ciòpotrebbeportarealesioniacausadell’altavelocità
di rotazione dei ventilatori interni.
5Collegate correttamente il condizionatore d’aria a terra. Non collegate il cavo a terra al
tubo del gas, al tubo dell’acqua, al parafulmini o al cavo a terra del telefono. Un collega-
mento a terra incompleto potrebbe causare scossa elettrica.
6Incasodianomaliedelcondizionatored’aria(adesempio,odoredibruciato),interrompete
subito l’uso e SPEGNETE l’interruttore di circuito.
7L’apparecchio deve essere installato in conformità con i regolamenti di connessione
elettricanazionali.Uncollegamentoscorrettodelcavopuòprovocareilsurriscaldamento
del cavo di alimentazione, della spina e della presa elettrica e causare un incendio.
8Seèdanneggiatoilcavodialimentazione,bisognafarsostituirelostessodalfabbricante
o da un centro di assistenza o da una persona qualificata per evitare eventuali rischi.
Sostituite il cavo di alimentazione solo con un altro specificato dal produttore.
AVVERTIMENTI PER L’INSTALLAZIONE/RIMOZIONE/
RIPARAZIONE
• Noncercatediinstallare/rimuovere/ripararel’unità senza assistenza. Unusoerratocauserà
scosse elettriche, perdite d’acqua, incendi e così via. Consultate il vostro rivenditore o
dell’altropersonale di servizio qualificato perl’installazione/rimozione/riparazione dell’unità.

IMPORTANTI ISTRUZIONI PER LA SICUREZZA
PRECAUZIONI PER L’USO
1Aprite una finestra o una porta periodicamente per ventilare la stanza, specialmente
quandosiusanoapparecchiagas.Unaventilazioneinsufficientepotrebbecausareman-
canza di ossigeno.
2Non toccate i tasti con mani bagnate. Ciò potrebbe provocare una scossa elettrica.
3Per sicurezza, spegnete l’interruttore del circuito quando non usate l’unità per un lungo
periodo di tempo.
4Controllatelacremaglieradimontaggiodell’unitàesternaperiodicamenteedassicuratevi
che sia ben fissata.
5Non urtate l’unità esterna e non collocate alcun oggetto sopra di essa, poiché potrebbe
cadere causando lesioni personali.
6Questaunitàèstataprogettataperl’usoinareeresidenziali.Nonusatelaincanilioserre
per allevare animali o coltivare piante.
7Non collocate contenitori d’acqua sull’unità. Se l’acqua penetra nell’unità, l’isolamento
elettrico si potrebbe rovinare causando una scossa elettrica.
8Non bloccate gli sbocchi d’uscita ed entrata dell’aria dell’unità. Ciò potrebbe compro-
metterne il funzionamento o provocare guasti.
9Assicuratevi di spegnere l’apparecchio e l’interruttore di circuito prima di eseguire lavori
dimanutenzioneopulitura.Ilventilatorechegiraall’internodell’unitàpotrebbeprovocarvi
lesioni.
10
Non spruzzate o gettate acqua direttamente sull’unità. L’acqua potrebbe causare una
scossa elettrica o danni all’apparecchio.
11
Questoapparecchionondeveessereusatodabambiniopersone infermesenzasuper-
visione.
Assicuratevi che i bambini non giochino con l’apparecchio.
PRECAUZIONI PER IL LUOGO DI MONTAGGIO/
INSTALLAZIONE
• Assicuratevi di collegare il condizionatore d’aria ad una presa di corrente di voltaggio e
frequenza giusta.
L’uso di una presa di corrente dal voltaggio e frequenze errate potrebbe risultare dannoso
all’apparecchio e provocare un incendio.
• Non installate l’unità in un luogo dove ci potrebbero essere perdite di gas infiammabile.
Ciò potrebbe provocare incendi.
Noncollocate l’unità in luoghi neiquali l’aria contiene polvere, fumioppure umidità in misura
eccessiva.
• Sistemateiltubodidrenaggioinmodotaledaassicurareundrenaggiocorretto.Undrenaggio
insufficiente potrebbe far fuoriuscire acqua nella stanza, bagnare i mobili e così via.
• Assicuratevi di installare un interruttore differenziale o magnetotermico a seconda del luogo
d’installazione, per evitare scosse elettriche.
I-2
