Sharp AE-X127J User manual

SHARR
SPLIT TYPE
ROOM AIR CONDITIONER
OPERATION MANUAL
.
INDOOR UNIT OUTDOOR UNIT
A&Xl 275
AE-X127J
/
Thank you for purchasing this Sharp product. Please read this manual carefully before
operating the air conditioner, and keep this manual and the Installation Manual as handy
references.

l PRECAUTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
l SPECIFICATIONS . . . . . . . . . . . . . ..*.....................
1
.ADDITIONAL NOTES ON OPERATION . . . . 2
@TIPS ON SAVING ENERGY
. . . . . . . . . . . . . . . . . . . . . .
2
l PART NAMES
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
l USING THE REMOTE CONTROL . . . . . . . . . . . . . 5
l BASIC OPERATION
. . . . ..a...........................
7
WARNING
.ADJUSTlNG THE AIR FLOW DIRECTION . . . 8
@TIMER OPERATION
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...*
9
l FULL POWER MODE
. . ..*............................
11
l ONE-HOUR TIMER
. . . . . . . . . ..*.........................
11
l AUXILIARY MODE
. . . . . . . . . . . ..*....................*...
12
l MAINTENANCE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13
l BEFORE CALLING FOR SERVICE . . . . . . . . . . . . 14
1 .
2 .
3
.
4
.
5
.
6
.
7
.
8
.
Using a power circuit with improper voltage and frequency can result in damage to the unit and
possibly fire.
Use a circuit with a 230-240 volt (*IO%) rating.
Open a window or door periodically to ventil,ate the room, especially when using gas appliances.
Inserting objects into the unit could result in injury due to rotation of the high-speed fans.
Pulling the power cord might result in damage or electrical shock. Do not misuse the power cord.
This appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
When using the air conditioner for infants, children, elderly, bedridden, or disabled people- make
sure the room temperature is suitable for those in the room.
Always use a fuse with the correct current rating.
Use only the manufacturer specified power cord (parts code; QACC-A234JBEO) for its replacement.
Replacement should be conducted by a service centre approved by Sharp.
A
1
This unit is designed for human comfort. Do not use for applications such as a kennel or
0
nursery to raise animals or plants.
For your safety, ensure that your new air conditioner is installed by a licensed electrical
contractor with accordance with the SAA WIRING RULES.
CAUTION
l To ensure that your warranty is not cancelled, both the indoor/outdoor units and supply/ interconnect-
ing cables must be installed by a licensed air conditioning contractor.
LOCATION
+
l Do not locate the unit where there is excessive dust, fumes or moisture in the air.
INSTALLATION / REMOVAL
l Do not attempt to install or remove the unit yourself. Consult a licensed air conditioning contractor.
Indoor unit
Outdoor unit
Rated A.C. voltage (V)
Rated frequency (Hz)
Cooling capacity (kw)
Heating capacity (kw)
AY-X127J
AE-X127J
230-240
50
3.4*
4.5*
1
*When tested in accordance with
AS 1861.1.

OPERATING TEMPERATURE RANGE
INDOOR TEMP. OUTDOOR TEMP. ’
upper limit
32°C D.B. 46°C D.B.
COOLING
23°C W.B.
I
-
I
I
lower limit
21°C D.B. 21°C D.B.
15°C W.B.
-
0
uDDer limit
27°C D.B. 21°C D.B.
4 t-on \A, l-i
HEATING ’ ’
lower limit
-
20°C c lY
-
I
-
1.0.
-u.3 b u.t).
-95°C W.B.
D.B.=Dry-bulb W.B.=Wet-bulb
WHEN POWER FAILURE OCCURS
A built-in protective device
might prevent the unit from
operating when used out of
this range.
Condensation might form on
the air outlet when the unit
operates continuously in the
COOL or the DRY mode
when the humidity is over 80
percent.
This air conditioner has a back-up function in case of power failure during operation.
After power recovery, the unit will automatically restart in the same settings which were actived
before the power failure, except for timer operation settings.
If the timers are set, they will need to be reset after power recovery.
PREHEATING FUNCTION
In the HEAT operation, the indoor fan might not start for two to five minutes after the unit is turned on
to prevent the air from circulating before the unit is sufficiently warmed up.
DE-ICING FUNCTION
l When ice forms on the heat exchanger in the outdoor unit during the HEAT operation, an
automatic de-icer operates for about 5 to IO minutes to remove the ice. During de-icing, the inside
and outside fans stop operating.
l A hissing sound may be heard originating from the indoor unit during de-icing.
l After de-icing is completed, the unit automatically resumes operation in the HEAT mode.
HEATING EFFICIENCY
l The unit employs a heat pump that draws heat from the outside air and releases it into the room.
The outside air temperature therefore greatly affects the heating efficiency.
l If the outside temperature is unusually low, you may require additional heating to maintain the
desired room temperature.
l On very cold days, it may take some time to heat the entire room, you may need to use the “full
power” feature to speed up heating.
Below are some simple ways to save energy when you use your air conditioner.
i
SET THE CORRECT TEMPERATURE
a Setting the temperature 1 “C higher in COOL mode, and 2°C lower in HEAT mode than the desired
temperature can result in a 10 percent saving in electricity.
l Setting the temperature colder than necessary during cooling will result in excess power consump-
tion.
KEEP OUT DIRECT SUNLIGHT AND DRAFTS
l Keeping out direct sunlight when cooling will aid in reducing the power consumption.
l Close the windows and doors when heating and cooling the room.
SET PROPER AIR FLOW DIRECTION TO OBTAIN THE BEST AIR CIRCULATION
KEEP FILTER CLEAN TO ENSURE THE MOST EFFICIENT OPERATION
MAKE MOST OF THE TIMER OFF FUNCTION
UNPLUG THE POWER CORD WHEN THE UNIT IS NOT TO BE USED FOR AN
EXTENDED PERIOD
l The indoor unit still consumes a small amount of power when it is not operating.
2

INDOOR UNIT
70
Hold the bottom corners of the
open panel and gently pull out-
wards.
0 Operation Lamp (red)
@I Timer Lamp (yellow)
@I Remote Control Reciever Window
@ AUX. Button
OUTDOOR UNIT
@ Inlet (Air)
@ Indicator Panel
@ Hinged Front Panel
@ Operation Panel
@ Air Filters
@ Power Supply Cord
0 Vertical Adjustment Louvre
@ Horizontal Adjustment Louvres
@ Outlet (Air)
@ Remote Control
@ Inlet (Air)
@ Refrigerant Tubes and Intercon-
necting Cord
0 Drainage Hose
@ Outlet (Air)
NOTE:
Actual units might vary slightly from those shown above.
3

REMOTE CONTROL
@TRANSMITTER
@ DISPLAY (Liquid Crystal Display)
@ THERMO. (Thermostat) Button
@ FULL POWER OPERATION Button
@ONE-HOUR TIMER Button
@ON/OFF Button
0 MODE Button
@I FAN Button
@TIMER OFF Button (for setting the timer)
@J SWING Button
0 TIMER SET/CANCEL Button, and CLOCK
SET Button
@TIMER ON Button (for setting the timer)
@TIME ADVANCE Button
@ CLOCK Button
@ Indicates BATTERY COMPARTMENT is
below this mark
@TIME REVERSE Button
L.C.D. REMOTE CONTROL DISPLAY
0
@THERMOSTAT SETTING FOR AUTO AND
@
DRY MODES
@TEMPERATURE SYMBOL
@
@TRANSMITTING SYMBOL
@I
@MODE SYMBOLS
Q
: AUTO & : DRY
# : HEAT + : FAN ONLY
#/c ’ COOL
.
@TEMPERATURE INDICATOR
@I FULL POWER OPERATION MODE SYMBOL
@ FAN SPEED SYMBOLS
P
: AUTO
@
: LOW
@
: HIGH
0
& : SOFT
\-------@
‘------0
@TIMER ON INDICATOR/CLOCK
Indicates the timer-on time or cur-
rent time.
@TIMER OFF INDICATOR
Indicates the timer-off time or one-
hour timer setting.
4

LOADING BATTERIES
Use two size-AAA (R03) batteries.
1 Slide open the remote control
cover as shown.
Now continue to pull the cover in
the same direction to completely
remove it.
2
Insert the batteries in the com-
partment, making sure the @
and 0 polarities are properly
aligned.
remote control
l AM 6:00 will appear on the
display when the batteries are
properly loaded.
3 Replace the cover.
NOTES:
l The battery life is approximately one year with normal use.
l When you replace the batteries, always use two new ones of the same type.
l If the remote control does not operate normally after replacing the batteries,
take out the batteries and replace them again after 30 seconds.
l If you will not be using the unit for a long time, remove the batteries from the
remote control.
HOW TO USE THE REMOTE CONTROL
Point the remote control towards the indoor
unit’s receiver window and press the de-
sired button. A beep will sound when the
indoor unit receives the signal.
l Make sure no objects, such as curtains, are
between the remote control and the indoor
unit.
l The remote control can operate up to 7me-
ters away, when the batteries are in good
condition.
5
_
_

A
! CAUTION
Do not expose the receiver window on the indoor unit to strong, direct sunlight, which
can adversely affect its operation. In such case, close the curtains to block the sunlight.
Use of a fluorescent lamp with a quick starter in the same room might interfere with
transmission of the signal.
The indoor unit might be affected by signals emitted from the remote control of a
television, VCR or other equipment used in the same room.
Do not leave the remote control in direct sunlight or near a heater. Also, protect the unit
and remote control from moisture and shock which
can
discolour or damaae them.
SETTING THE CURRENT TIME
There are two setting modes:
12-hour-clock and 24-hour-clock.
Example: 5 o’clock,in the afternoon
d
1 To set 12-hour-clock, press the CLOCK
button once.
To set 24-hour-clock, press the CLOCK
3
button twice.
2
Press the TIME ADVANCE or-REVERSE
1
buttons to set the current clock time.
l Hold the buttons down to fast-forward
2
or reverse the time on the display.
3 Press the SET/C button.
l The colon (:) blinks to indicate that the
clock is functioning.
NOTE:
l The time cannot be set, if the on or off
timers have programmed.
Please refer to “Timer Operation” on page 9
and IO.
-

7
-v
V
A
-v
-77
TIPS ABOUT AUTO MODE:
in the AUTO MODE, the
temperature setting and
mode (HEAT, COOL or
DRY) are automatically se-
lected depending on the
room temperature and out-
door temperature when the
unit is turned on.
Press the MODE button to select the operation
mode.
AUTO HEAT COOL DRY FAN ONLY
p+:Q+g+ & +*
Press the ON/OFF button to start operation.
l The red OPERATION lamp on the indoor unit will
light up.
Press the THERM0 button to set the desired
temperature.
In the AUTO and DRY
- 2°C higher
mode, the indicator bars
-
-
1°C higher
represent changes in
v
- 1 “C lower
temperature.
v
- 2°C lower
In the manual HEAT and COOL mode, the tem-
perature can be set within the range of 18 to 32
“C
In the FAN ONLY mode, the temperature cannot
be set.
7
Press the FAN button to set the desired fan
speed.
AUTO HIGH
LOW SOFT
pP+@+@+O-7
l In the DRY mode, the fan speed cannot be
changed.
l In the FAN ONLY mode, the fan speed AUTO
cannot be set.
7To turn off the unit, press the-ON/OFF button
again.
l The red OPERATION lamp on the indoor unit will
go out.
26
0
IO 18
31 34 outdoor temp (OC)
21
(Oc) The figures in ( ) are temperature settings.
7

VERTICAL AIR FLOW
The direction of the air flow is automatically preset for the optimum effect in each
mode as follows;
1
COOL and DRY mode Horizontal air flow
HEAT and FAN ONLY mode
Diagonal air flow
HOW TO ADJUST THE AIR FLOW DIRECTION
Press the SWING button of the
remote control once.
l The vertical adjustment louvre
will swing continuously within
the range of 80’.
Press the SWING button again
when the desired position is
reached and the louvre will stop.
Adjustment range
COOL and DRY mode HEAT and FAN ONLY mode
The range is narrower to
prevent condensation
from forming.
The range is wider for in-
creased air circulation.
Hold the horizontal adjustment
louvres as shown and adjust
the air flow direction.
HORIZONTAL AIR FLOW
>
I, il
n
1 CAUTION
0
Never attempt to adjust the vertical adjustment louvres manually.
l Manual adjustment of these louvres can cause the unit to malfunction when remote-
controlled later.
l When the vertical adjustment louvres are adjusted completely downward during COOL
and DRY modes for an extended period of time, condensation might form.
8

NOTE:
Before setting the timer, ensure that the current time is properly set.
TIMER OFF
1 Press the TIMER OFF ( a,0 ) button.
2 The TIMER OFF indicator will blink; press the
TIME ADVANCE or REVERSE buttons to set
the desired time. (The time can be set in IO-
minute increments.)
1
3
3 Point the remote control at the receiver window
on the indoor unit, and press the TIMER SET
(SET/C) button.
l The yellow TIMER lamp on the indoor unit
lights up.
.A beep will sound when the indoor unit re-
ceives the signal.
( TIPS ABOUT TIMER OFF OPERATION )
(
TO CANCEL TIMER MODE
)
When the TIMER OFF mode is set, the
room temperature is automatically ad-
justed to prevent the room from becom-
ing too hot or too cold while you sleep.
(Auto sleep function)
COOL/DRY MODE:
l One hour after the timer operation
has begun, the temperature rises 1°C
higher than the thermostat setting.
HEAT MODE:
l One hour after the timer operation
has begun, the temperature drops
3°C lower than the thermostat
setting.
Press the TIMER CANCEL (SET/C) but-
ton.
l The yellow TIMER lamp on the indoor
unit will go out.
l The current time will be displayed on
the remote control.
II
I I
NOTE:
l Both timers will be cancelled when
the SET/C button is pressed.
NOTE:
Auto sleep function will not activate dur-
ing the FAN ONLY mode.
First, cancel the TIMER, then set it
again.
(
TO CHANGE A TIME SETTING
)
9
