SHARP
ATOMIC DIGITAL WALL CLOCK
with WIRELESS WEATHER DISPLAY
Instruction manual
. ..
•
RlEJ
ii
ftlliil
~
•
Thank you for your purchase. The utmost care has gone into the design and
manufacture of your clock. Please read these instructions carefully and keep
them forfuture reference.
This clock automatically synchronizes itself
to the US Government's National
Institute ofStandards
and Technology radio signal from Fort Collins, Colorado. The
WWVB radio signal daily broadcast ensures that the atomic clock will always
display the most accurate date and time. This clock never needs setting.
The weather station is equipped with many functions providing weather
information to you. The receiver unit has a clear, easy-to-read display that
shows the weather forecast, indoor temperature, time, month, date, as
well as the outdoor temperature measured and transmitted from the outdoor
sensor.
The 433 MHz technology means no wire installation is required and you can
place the sensor anywhere you like within 100 feet.
ht
Quick Start Set Up : Outdoor Sensor
1. Pick a sheltered place out of direct rain, snow or sunlight
2. Insert 2 x AA batteries
3. Replace battery door
2nd
Quick Start Set Up: Weather Station
1. Insert 2 x AA batteries
2. Press re-set button
on the back ofthe clock with a oin or paperclip to re-start
the clock. The clock will synchronize with the transmitter set automatically.
3. The antenna • 'f "flashes when the clock receives outdoor sensor signal.
NOTE:
When the antenna is flashing, it is searching for the atomic signal. Please
wa it
until the flashing stops before y ou try to setup the clock. The weather station is
disabled while searching for the atomic or the outdoor signal.
PLEASE NOTE:
· 1. Start this-clock at night and let the clock receieve the signal automatically
past midnight.
2. Always place the
unit away from interfering sources such as TV set ,
computer, metal objects and electrical appliances.
3. Areas with access to windows is recommended for better reception.
MAIN FEATURES:
WEATHER STATION
•
'Sl-1.C.RP
•
~
•
~-- ··~n
~
•
1. 12 H/24H button
Press it to switch 12 hour/ 24 hour .
Press and hold it
for 2 second to enter the receiving humi dity and
temperature data from the transmitter. ·
2. ° C/ °F button ·
Press it to switch between Celsius and Fahrenheit.
Press and hold it for 2 second to receive the time signal manually .
3. SET button
Press and hold it for 2 seconds to enter the time setting mode.
Press it to switch between hour/minute/year/month/date/DST .
4. UP
button
In setting mode, press it to increase the setting value.
5. DOWN button
In setting mode, press it to decrease the setting value.
6.TIME ZONE SWITCH
Slide the time zone switch to display the time in the desired time
zone.
7. WALL - MOUNTING HOLDER
Use it to support the main unit on the wall.
B. RESET : .
Press it to reset all values to default values .
In·case
of malfunction, the unit may be required to reset.
9. BATTERY COMPARTMENT
Accommodates 2 x AA size batteries (alkaline batteries
recommended).
1 O. TODAY'S FORECAST window
Shows the weather forecast for coming 12 hours.
11 . OUTDOOR temperature window
Shows current outdoor temperature .
12. INDOOR temperature window
Shows current indoor temperature .
13.
CLOCK window
Displays clock time .
14.
CALENDAR window
Displays calendar .
RECEPTION
This clock automatically synchronizes itself to the US Government's National
Institute
of Standards and Technology in Fort Collins, Colorado. The WWVB
radio signal daily broadcast ensures that the atomic clock will always display
the most accurate date and time.
In most areas, a signal can only be received at night. Ifyour clock does-not receive
the WWVB signal immediately,just wait overnight
and it will be set in the morning.
SETTING up THE WEATHER STATION !AFTER SETTING up OUTDOOR SENSOR\
1. Remove the battery door and insert 2 x AA size batteries intothe battery
compartment. Make sure you insert them the right way according to the
polarity information(+/-) marked on the battery compartment.
2. Replace the battery door .
3. Press the "RESET" button on the back of the clock with a pin or paperclip
to
re-start the clock . The clock will synchronize with the transmitter set
automatically .
4. The antenna "'f" flashes when the clock receives outdoor sensor
signal.
RECEPTION OF
RADIO CONTROLLED TIME SIGNAL
The time and date are radio-controlled . The current time and date are
automatically synchronized with the time signal transmitted from U.S.A
(WWVB).
When used for the first time (after inserting the batteries or pressing the
"RESET" key), the clock will start to receive the transmitter signal. It will
start to receive RC signal 3 minutes after.
RC SIGNAL STRENGTH INDICATOR
The signal indicator displays signal strength in 4 levels . Wave segment
flashing means time signals are being received. The signal qualitycould be
classified into 4
types : '
no signal weak good very good
If the RC clock receives signal successfully, a sync-time symbol "f" will
appear on the LCD.
The unit has alreadysynchronized with the time sign transmitter.Otherwise
the
segment will disappear from the LCD display .
TIME CALENDAR SETTING
If you are out of reach of the Radio Controlled transmitter or if the reception
is
poor, the time and calendar can be set manually. Once the signal of
transmitter is received again, the clock will automatically synchronize with
the
exact time and calendar.
1. In normal time mode, press and hold the "SET" key for 2 seconds to enter
the time setting mode.
2. Press the "UP"or "DOWN" key to change the value
of the flashing Hour digit.
3. Repeat the above operations to set time and calendar in this order:
> Hour> Minute > Year> Month > Date > DST.
4. The time zone setting are represented by the below abbreviations:
P=Pacific M=Mountain C=Central E=Eastem
5. Press "SET" key to save and exit the setting mode. Or let it ex it
automatically 30 Seconds later without pressing any key.
DAYLIGHT SAVINGS TIME (DST)
The
clock has been programmed to turn on DST as defaulted . Press
UP/DOWN key to change to OFJ= mode.during the.tirT).e settjng..
The DST will show when the clock receives the RC signal during the
summer.
FUTURE FORECAST
1. There are 6 weather icons to represent different weathers :
'.
Sunny
Sunny Intervals
Cloudy
~ C:::
• f I
ff f
1-v11
1
'~
Rain
~~ ·:. ":'·}
' f .
' 11 I I I
l"V/1
1 1
~
Rain+ Thunder
~B
.· .¥it . ..
. . ..
. : .
Snow
..__J
· ·.~
.. :rr· .
.. ..
~ : ..

NOTE:
1. The accuracy of a general pressure-based weather forecast is about
70% to 75%.
2.The weather forecast is meant for next 12 hours . It may not
necessarily reflect the current situation .
3.The "Sunny" icon, when applied to nightt ime, implies clear weathe r.
INDOOR AND OUTDOOR TEMPERATURE & HUMIDITY RECORDS
Change the temperature unit to 'C for Celsius or ' F for Fahrenheit by
pressing the "'C/'F" key.
NOTE :
1.lf no signal are received or the transmission is interfered , "-- -"will
appear on the LCD.
2.Relocate the clock or transmitter in other positions and make sure the
transmission is within the effective range
of 100 feet approx.
3.Afterseveral trials in vain, please resetthe clock. Reposition the weathe r
station where the reception is the best.
NOTE :
Attention! Please dispose of used unit or batter ies in an ecologically safe
manner . ~
USING THE TABLE STAND OR WALL-MOUNTING STAND
The receiver and transmitter have three mounting structures:
©~
For the receiver, place the screw on the desired wall and hang the receiv er
by the recessed hole at the back of the clock or just simply place it on th e
desktop by the table stand.
For the transmitter, fix the separate wall-mounting stand outside in the
area protected from direct rain by the screw. Once the stand is mounted,
place the transmitter into the stand on the wall. You can place it on the
des k top by its table stand.
SPECIFICATION
MAIN UNIT
Recommended operating range :
Resolution:
Calendar range:
Radio controlled signal:
REMOTE SENSOR
Recomm ended
operating range :
Resolution :
RF transm iss ion frequency:
Remote sen sor:
RF transmission range:
Temperature sens ing cycle :
POWER
Main unit:
Remote se nsor:
DIMENSION
Main unit :
R
emote sens or :
IMPORTANT NOTES
O' C to 45 'C
32' F to 11 3'F
0.1 'C/' F(above O 'C/3 2' F)
1 'C/'F(below O' C/32'F)
from year 2000 to 2099
WWVB
-50 ' C to 70' C
-122'F to 158 'F
0.1 ' C/'F(above O' C/32'F)
1°C/ ° F(below O' C/32 'F )
433MHz
1 unit
max imum 3 0 meters
around 30 secon ds
3.0V , us e 2 x AA 1.5V alkaline
battery
3V, use 2 x AA 1. 5V alk aline battery
240 (W)X240(H)X48(D)mm
9.45 (W)X 9.45( H)X 1.89(D)inch
42(W)X136(H)X25(D)mm
1.65(W)X 5.35 (H)X0 . 98(D)inch
Avoid i nstallin g this unit in places exposed to direct sunlight or close to
heat radiating app lian ces suc h as elect ric heat ers , on top of other s tereo
eq u ip m en t that radiates too much heat , places lacki ng ve ntil at ion or
du sty area s, places subj ec t to constant vibration and/or humid or moist areas.
Operat e co ntrol s and s wit ches as described in the manual.
FCC INFORMATION
Thi s equipme nt has been t es ted and found to com ply with the li mit s for a
Class B digital device , pursuant to Part 15 of the FCC Rules . T hese limits
are designed to provide re as onable protection aga inst harmfu l
interference in a res id e ntial ins tall a tion . This eq uipm e nt generates,
use s, and can radiate radio frequency energy and , if not installed and
us ed in accordance with the in st ru ct ions, may c ause h armf ul
interferen ce to radio communications. How ev er , there is no guarantee
that i nt e rf ere nce will n ot occur in a particular i nst alla tion . If this
equipmentdoescause harmful interference to radio ortelevision r ecep tion,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the in terference by one or more of the
following measures:
- Reorient or relocate the receiving antenna .
-
Increase the separation between the equipmentand receiver.
-
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected .
-
Consult the dealer or an experienced radio/TV technic ian for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference , and
(2)This device must accept any i nterference received, including
I nterference that may cause und es ired operation.
Warning: Changes or modifications to this unit not express ly approved by
the party responsible for compliance could void the user 's authority to
operate the equipment.
IMPORTANT SAFETY INSTRUCTIONS
1.Read these instructions. Keep these instructions. Follow all instructions .
Heed all
warnings.
2. Do not use this apparatus near water.
3.
Clean only with dry cloth.
4. Do not block any ventilation open i ngs. Install in a ccordance with the
manufacturer's instructions.
5. Do not install near any heat sources such as radiators, heat registers ,
stoves, or other apparatus (including amplifiers) that produce heat.
6. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two bl ades with one wider than the other . A
grounding type plug has two bl ades and a third grounding prong . Th e
wide blade or the third prong is provided for your safety . If the provided
plug does not fit into your outlet , co nsult an electrician for rep lacement
of the obsolete outlet.
7. Protect the power cord from being walked on or pinched particular ly at
plugs, convenience receptacles, and the po i nt where they exit from the
apparatus.
8. Only use attachments I acc essories specified by the manufacturer.
9. Unplug this apparatus dur ing lightning storms or when unused for long
periods of time .
10. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in a ny way, such as
power-s upply cord or plug is damaged, liquid has been spilled or
objects hav e falle n into the appa ratus , the appara tus has been
exposed to rain or moisture , does not operate normally , or has been
dropped .
11 . This appliance shall not be exposed to dripping or sp l ashing water and
noobjectfilled withliquidssuchasvasesshallbe placedon the apparatus.
12 Use only with the cart, stand , tripod, bracket,
or table specified by the manuf acturer, or sold •
with the apparatus . When a cart 1s u sed, use
ca ution when moving the car t/appara tus
combination to avo id injury from ti p-ove r. •
13 Do not overload wall outlet U se only :.\
power source as indicated. t~
14. Use replacement parts as specified by the ~
manufacturer.
15 . The produ ct may be mounted to a wa ll o nly if r ec ommen ded by the
· manufa ct ure r.
16 . Upon completion of any serv ice or repairs to th is pro duct, ask the
Service technician to perform safe ty checks.
For Customer Service Please Call Toll Free at
1-(800)-221-0131 and ask for Customer Service.
Monday-Friday 9:00 AM -4:00 PM EST
Please call for assistance before returning the clock to the store .
OneYear Limited Warranty
M.Z. Berger & Company warrants th e original consumer purchaser of this product
that it sha
ll be free of defects in materials a nd wo rkm ans hip for one year from the
p
ur chase date of this product. Defects caused by tampering, improper use,
u
na uthorized modifications or repa ir s, immersion in water or abuse are not
covered
by this warranty. If a defect covered by this warranty occurs during the
warranty
pe riod, wrap your clock carefully and se nd it to the following address:
MZ Be rg er Service Center
29-76 Northern Boulevard
Long Island City, NY 11101
You must include a Proof of Purcha se, ei th er th e origin al rec eipt ora photocopy and
a check or money order for USD $6.00 to cover the cost of handling. Also in c lu de
your return address inside the package. M .Z. Berger will repair or replace the clock
and return it to you. M.Z. Berger will not be liable for an y loss or damage,
including incidental or consequential damages of any kind; from any breach of
warranty ei ther expressed orimplied relating to the product. Si nce some states do
not allowthe exclusion or limitation
of incidental or consequential damages, this
limitation may not app ly ~ you.
Printed
in China . Model SPC 906
SHARP, registered in the U.S. Patent and Trademark Office.
