Sharp K-71F28BM2-EU User manual

1
EN User Manual
K-71F28BM2-EU
Cooking
Home Appliances
AL Manual i Përdorimit
DK Handleiding
BG AИнструкции за Употреба
CZ HNávod k Obsluze
DE Bedienungsanleitung

-Declaration of conformity
We declare that our products meet the applicable
European Directives, Decisions and Regulations
and the requirements listed in the standards
referenced.
-Konformitätserklärung
Wir erklären, dass unsere Produkte die
geltenden europäischen Richtlinien,
Entscheidungen und Regularien sowie die
in den referenzierten Standards gelisteten
Anforderungen erfüllen.
-Déclaration de conformité
Nous déclarons que nos produits sont conformes
aux Directives, Décisions et Règlementations
européennes en vigueur et aux exigences visées
dans les normes citées en référence.
-Declaración de conformidad
Declaramos que nuestros productos cumplen
con las Directivas Europeas, Decisiones
y Regulaciones aplicables y los requisitos
enumerados en dichas normativas.
-Declaração de conformidade
Declaramos que os nossos produtos
cumprem as Diretivas Europeias, Decisões
e Regulamentos aplicáveis e os requisitos
enumerados nas referências normalizadas.
-Conformiteitsverklaring
We verklaren dat onze producten voldoen aan
de van toepassing zijnde Europese richtlijnen,
besluiten en voorschriften in de normen
waarnaar wordt verwezen.
-Dichiarazione di conformità
Dichiariamo che i nostri prodotti sono conformi
a Direttive, Decisioni e Regolamenti europei e ai
requisiti elencati negli standard di riferimento.
-Δήλωση συμμόρφωσης
Δηλώνουμε ότι τα προϊόντα μας πληρούν τις
εφαρμόσιμες Ευρωπαϊκές Οδηγίες, Αποφάσεις
και Κανονισμούς, καθώς και τις απαιτήσεις που
περιέχονται στα πρότυπα όπου γίνεται αναφορά.
-Декларация за съответствие
Ние заявяваме, че нашите продукти отговарят
на приложимите европейски директиви,
решения и регламенти и на изискванията,
посочени в гореописаните стандарти.
-Prohlášení o shodě
Prohlašujeme, že naše výrobky splňují příslušné
evropské směrnice, rozhodnutí, předpisy a
požadavky uvedené ve zmiňovaných normách.
-Vyhlásenie o zhode
Vyhlasujeme, že naše produkty spĺňajú príslušné
smernice, rozhodnutia, nariadenia a požiadavky
vypísané v uvedených štandardoch.
-Vastavusdeklaratsioon
Deklareerime, et meie tooted vastavad
kohaldatavatele Euroopa direktiividele, otsustele
ja määrustele ning viidatud standardites
sätestatud nõuetele.
-Försäkran om överensstämmelse
Vi försäkrar att våra produkter uppfyller gällande
EU-direktiv, beslut och förordningar och de krav
som anges i de standarder som refereras.
-Yhteensopivuuslauseke
Tuotteemme ovat yhteensopivia EU:n
tuotedirektiivien, päätösten ja säädösten kanssa,
sekä niissä listattujen standardien kanssa.
-Izjava o sukladnosti
Izjavljujemo da su naši proizvodu u skladu s
primjenjivim Direktivama, Odlukama i Uredbama
Europske unije te zahtjevima navedenima u

spomenutim standardima.
-Izjava o usklađenosti
Izjavljujemo da naši proizvodi zadovoljavaju
primenljive evropske direktive, odluke i
propise, kao i zahteve navedene u naznačenim
standardima.
-Overensstemmelseserklæring
Vi erklærer, at vores produkter opfylder de
gældende europæiske direktiver, beslutninger
og forordninger, og de anførte standarder der
henvises til.
-Samsvarserklæring
Vi erklærer at våre produkter oppfyller de
gjeldende europeiske direktiver, beslutninger
og forskrifter, og kravene i standardene som det
henvises til.
-Декларація відповідності
Цим ми заявляємо, що наші продукти
відповідають усім застосовним директивам,
рішенням та нормам Європейського союзу.
Вимоги зазначено в додаткових матеріалах
щодо стандартів.
-Декларација за усогласеност
Изјавуваме дека нашите производи ги
исполнуваат применливите европски
директиви, решенија и одредби, како и
побарувањата наведени во посочените
стандарди.
-Declarație de conformitate
Noi declarăm că produsele noastre respectă
Directivele Europene, Deciziile și Reglementările
aplicabile și condițiile enumerate în standardele
menționate.
-Megfelelőségi nyilatkozat
Ezúton igazoljuk, hogy termékeink megfelelnek
az EU direktíváknak, jogszabályoknak,
előírásoknak. Az előírások felsorolása a
referencia tartalmaknál.
-Izjava o skladnosti
Zagotavljamo, da so naši izdelki skladni z
ustreznimi evropskimi direktivami, sklepi in
predpisi ter zahtevami, ki so navedene v
referenčnih standardih.
-Deklarata e konformitetit
Ne deklarojmë se produktet tona përmbushin
Direktivat e aplikueshme evropiane, Vendimet
dhe Rregulloret si dhe kërkesat e renditura në
standardet e referuara.
-Atitikties deklaracija
Tvirtiname, kad mūsų produktai atitinka
susijusiose Europos direktyvose, sprendimuose
ir reglamentuose pateikiamų standartų keliamus
reikalavimus.
-Atbilstības deklarācija
Mēs apliecinām, ka mūsu produkti atbilst
attiecīgajām Eiropas direktīvām, lēmumiem un
noteikumiem, kā arī prasībām, kas norādītas
pieminētajos standartos.
-Deklaracja zgodności
Oświadczamy, że nasze produkty spełniają
wymagania odpowiednich dyrektyw, decyzji
i regulacji Unii Europejskiej oraz wymagania
określone w wymienionych standardach.

EN - 1

Our goal is to offer you, high quality products that exceed your expectations. Your
appliance is produced in modern facilities and is carefully, particularly tested for
quality. This manual is prepared in order to help you use your appliance, which has
been manufactured using the most recent technology with condence and maxi-
mum efciency. Before using your appliance, carefully read this guide which inc-
ludes basic information to safe installation, maintenance and use. Please contact
your nearest Authorized Service centre for the installation of your product.

EN - 2
Contents
Presentation and size of product
Warnings
Preparation for installation and use
Using the oven
Cleaning and maintenance of your product
Service and Transport

EN - 3
Control panel
Tray
Lower Heating
Element (behind the
plate)
Handle
Oven Door
Upper Heating Element (behind the plate)
Wire
Grill
Racks
Oven Light
Air Outlet Shutters
PRESENTATION AND SIZE OF PRODUCT

EN - 4
SAFETY WARNINGS
READ THESE INSTRUCTIONS CARE-
FULLY AND COMPLETELY BEFORE
USING YOUR APPLIANCE, AND KEEP
IT IN A CONVENIENT PLACE FOR RE-
FERENCE WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR
MORE THAN ONE MODEL IN COM-
MON. YOUR APPLIANCE MAY NOT
HAVE SOME OF THE FEATURES
THAT ARE EXPLAINED IN THIS MA-
NUAL. PAY ATTENTION TO THE EXP-
RESSIONS THAT HAVE FIGURES,
WHILE YOU ARE READING THE OPE-
RATING MANUAL.
General Safety Warnings
•This appliance can
be used by children
aged from 8 years
and above and per-
sons with reduced
physical, sensory or
mental capabilities
or lack of experience
and knowledge if they
have been given su-
pervision or instruc-
tion concerning use
of the appliance in
a safe way and un-
derstand the hazards
involved. Children
shall not play with the
appliance. Cleaning
and user maintenan-
ce shall not be made
by children without
supervision.
•WARNING: The app-
liance and its acces-
sible parts become
hot during use. Care
should be taken to
avoid touching hea-
ting elements. Child-
ren less than 8 years
of age shall be kept
away unless continu-
ously supervised.
•WARNING: Danger
of re: do not store
items on the cooking
surfaces.
•WARNING: If the
surface is cracked,
switch off the applian-
ce to avoid the possi-
bility of electric shock.
•The appliance is not
intended to be ope-
rated by means of an
external timer or se-

EN - 5
parate remote-control
system.
• During use, the app-
liance becomes hot.
Care should be taken
to avoid touching he-
ating elements inside
the oven.
• During use, handles
held for short periods
in normal use can get
hot.
• Do not use harsh
abrasive cleaners or
sharp metal scrapers
to clean the oven
door glass and other
surface since they
can scratch the surfa-
ce, which may result
in shattering of the
glass or damage to
the surface.
• Do not use steam cle-
aners for cleaning the
appliance.
• WARNING: Ensure
that the appliance is
switched off before
replacing the lamp to
avoid the possibility
of electric shock.
• CAUTION: Accessib-
le parts may be hot
when the cooking or
grilling is in use. Yo-
ung children should
be kept away.
• Your appliance is produced in ac-
cordance with all applicable local
and international standards and
regulations.
• Maintenance and repair work
must be made only by authorized
service technicians. Installation
and repair work that is carried out
by unauthorized technicians may
endanger you. It is dangerous to
alter or modify the specications
of the appliance in any way.
• Prior to installation, ensure that
the local distribution conditions
(nature of the gas and gas pressu-
re or electricity voltage and frequ-
ency) and the requirements of the
appliance are compatible. The re-
quirements for this appliance are
stated on the label.
• CAUTION: This appliance is de-
signed only for cooking food and is
intended for indoor domestic hou-
sehold use only and should not be
used for any other purpose or in
any other application, such as for
non-domestic use or in a commer-
cial environment or room heating.
• Do not try to lift or move the app-

EN - 6
liance by pulling the door handle.
•All possible security measures
have been taken to ensure your
safety. Since the glass may break,
you should be careful while clea-
ning to avoid scratching. Avoid hit-
ting or knocking on the glass with
accessories.
•Ensure that the supply cord is not
wedged during the installation.
If the supply cord is damaged, it
must be replaced by the manufac-
turer, its service agent or similarly
qualied persons in order to pre-
vent a hazard.
•While the oven door is open, do
not let children climb on the door
or sit on it.
Installation Warnings
•Do not operate the appliance be-
fore it is fully installed.
•The appliance must be installed
by an authorized technician and
put into use. The producer is not
responsible for any damage that
might be caused by defective pla-
cement and installation by unaut-
horized people.
•When you unpack the appliance,
make sure that it is not damaged
during transportation. In case of
any defect; do not use the appli-
ance and contact a qualied servi-
ce agent immediately. As the ma-
terials used for packaging (nylon,
staplers, styrofoam...etc) may
cause harmful effects to children,
they should be collected and re-
moved immediately.
•Protect your appliance against
atmospheric effects. Do not expo-
se it to effects such as sun, rain,
snow etc.
•The surrounding materials of the
appliance (cabinet) must be able
to withstand a temperature of min
100°C.
During usage
• When you rst run your oven a
certain smell will emanate from
the insulation materials and the
heater elements. For this rea-
son, before using your oven, run
it empty at maximum temperature
for 45 minutes. At the same time
you need to properly ventilate the
environment in which the product
is installed.
•During usage, the outer and inner
surfaces of the oven get hot. While
opening the oven door, step back
to avoid the hot steam coming out
of the oven. There may be a risk
of burns.
• Do not put ammable or combus-
tible materials, in or near the app-
liance when it is operating.
•Always use oven gloves to remo-
ve and replace food in the oven.
•Do not leave the cooker while co-
oking with solid or liquid oils. They
may catch re on condition of ext-
reme heating. Never pour water
on to ames that are caused by
oil. Cover the saucepan or frypan
with its cover in order to choke the
ame that has occured in this case
and turn the cooker off.
•If you will not use the appliance for
a long time, plug it off. Keep the

EN - 7
main control switch off. Also when
you do not use the appliance,
keep the gas valve off.
•Make sure the appliance control
knobs are always in the “0” (stop)
position when it is not used.
•The trays incline when pulled out.
Be careful not to let hot liquid spill
over.
•When the door or drawer of the
oven is open, do not leave any-
thing on it. You may unbalance
your appliance or break the cover.
• Do not put heavy things or am-
mable or ignitable goods (nylon,
plastic bag, paper, cloth...etc) into
the drawer. This includes cookwa-
re with plastic accessories (e.g.
handles).
•Do not hang towels, dishcloths or
clothes from the appliance or its
handles.
•During cleaning and maintenance
•Always turn the appliance off befo-
re operations such as cleaning or
maintenance. You can do it after
plugging the appliance off or tur-
ning the main switches off.
•Do not remove the control knobs
to clean the control panel.
•
• TO MAINTAIN THE EFFICIENCY
AND SAFETY OF YOUR APPLI-
ANCE, WE RECOMMEND YOU
ALWAYS USE ORIGINAL SPA-
RE PARTS AND TO CALL ONLY
OUR AUTHORIZED SERVICE
AGENTS IN CASE OF NEED.
PREPARATION FOR
INSTALLATION AND USE
Manufactured with best quality parts
and materials, this modern, functional
and practical oven will meet your ne-
eds in all respects. Make sure to read
the manual to obtain successful results
and not to experience any problems in
the future. The information given below
contain rules that are necessary for cor-
rect positioning and service operations.
They should be read without fail espe-
cially by the technician who will position
the appliance.
   


CHOOSING A PLACE FOR THE
OVEN
–There are several points to pay atten-
tion to when choosing a place for your
oven. Make sure to take into account
our recommendations below in order
to prevent any problems and dange-
rous situations, which might occur
later!
–When choosing a place for the oven,
attention should be paid that there are
no ammable or combustible materi-
als in the close vicinity, such as curta-
ins, oil, cloth etc. which quickly catch
re.
–Furnitures surrounding the oven must
be made of materials resistant to heat
more than 50 C° of the room tempe-
rature.

EN - 8
Required changes to wall cabinets and
exhaust fans above the built-in combi-
ned product as well as minimum he-
ights from the oven board are shown in
Figure 1. Accordingly, the exhaust fan
should be at a minimum height of 65 cm
from the hob board. If there is no ex-
haust fan the height should not be less
than 70 cm.
HOB
Minimum
42 cm
Minimum
42 cm
Minimum 65cm
(with hood)
Minimum 70cm
(without hood)
INSTALLATION OF BUILT-IN
OVEN

Insert the oven into the cabinet by pus-
hing it forward. Open the oven door and
insert 2 screws in the holes located on
the oven frame. While the product fra-
me touches the wooden surface of ca-
binet, tighten the screws.

EN - 9




 

If the oven is installed under a hob, the
distance between the worktop and the
top panel of the oven must be minimum
50 mm and the distance between the
worktop and the top of control panel
must be minimum 25 mm.
WIRING AND SAFETY OF
BUILT_IN OVEN
The instructions given below must be
followed without fail during wiring :
–The earthing cable must be connec-
ted via the screw with the earthing
mark. Supply cable connection must
be as shown in Figure 6. If there is
no earthed outlet conforming to regu-
lations in the installation environment,
call the Authorized Service immedia-
tely.
–The earthed outlet must be in close
vicinity of the appliance. Never use an
extension cord.
–The supply cable should not contact
the product’s hot surface.
–In case of any damage to the supply
cable, make sure to call the Authori-
zed Service. The cable must be repla-
ced by the Authorized Service.
–Wiring of the appliance must be per-
formed by the Authorized Service.
H05VV-F type supply cable must be
used.
–Faulty wiring may damage the appli-
ance. Such a damage will not be co-
vered under the warranty.
–The appliance is designed to connect
to 220-240V~ electricty is different
than the value given above, call the
Authorized Service immediately.
–   
    
     
     
   
–Wiring of the appliance must be per-
formed by the Authorized Service.
The appliance is
–designed to connect to 220-240V~
electricity. If the mains electricity is
different than the value given, call the
Authorized Service immediately. The
appliance is designed for using with
plug ofor xed connection to the ma-
ins. It is necessary that you install a
double pole switch between the pro-
duct and the electricity supply (ma-
ins), with a minimum gap of 3 mm bet-
ween the switch contacts. (20A rated,
delay function type).
–
3.4. GENERAL WARNING AND
PRECAUTIONS
Your appliance is produced in confor-

EN - 10
Defrost Function:
The oven’s warning lights will be turned
on, the fan starts operating.
To use the defrost function, take your
frozen food and place it in the oven
on a shelf placed in the third slot from
the bottom. It is recommended that
you can place an oven tray under
the defrosting food, to catch the wa-
ter accumulated due to melting ice.
This function will not cook or bake
your food, it will only help to defrost it.
Turbo Function
The oven's thermostat and warning
lights will be turned on, the ring heating
element and fan will start operating.
The turbo function evenly disperse
the heat in the oven. All foods on
all racks will be cooked evenly. It is
recommended to pre-heat the oven
about 10 minutes.
Static Cooking Function:
The oven’s thermostat and warning
lights will be turned on, the lower and
upper heating elements will start ope-
rating. The static cooking function emits
heat, ensuring even cooking of the lo-
wer and upper food. This is ideal for
making pastries, cakes, baked pasta,
lasagne and pizza. Prehating the oven
for 10 minutes is recommended and it is
best to cook on only one shelf at a time
in this function.
Fan Function:
mity with the relevant safety instruc-
tions relating to electrical appliances.
Maintanance and repair works must be
performed only by Authorized Service
technicians trained by the manufacturer
rm. Installation and repair works, per-
formed without observing the rules may
be dangerous.
The outer surfaces is heated while your
appliance is operating. The elements
heating the inner surface of the oven
and the steam out are extremely hot.
These sections will continue to preser-
ve their heat for certain while even if the
appliance is switched off. Never touch
the hot surfaces. Keep children away.
In order to cook in your oven, the oven
function and temperature setting butt-
tons need to be adjusted and the oven
timer, needs to be programmed. Other-
wise, the oven will not operate.
While the oven door is open, do not pla-
ce anything on it. You may disturb the
balance of the appliance or break the
door.
Unplug your appliance when it is not in
use.
Protect your appliance from atmosp-
heric effects. Do not leave it under the
effects of the sun,rain, snow, dust etc.
Using the oven function control
button
Oven Functions
* The functions of your oven may be dif-
ferent due to the model of your product.

EN - 11
oven door must be closed and the oven
temperature should be adjusted to 1900C
Double Grill and Fan Function:
The oven’s thermostat and warning
lights will be turned on, the grill and
upper heating elements and fan will start
operating.
The function is used for faster grilling of
thicker foods and for covering a larger
surface area. Both the upper heating
elements and grill will be energised along
with the fan to ensure even cooking.
Use the upper shelves of oven. Lightly
brush the wire grid with oil to stop foods
sticking and place foods in the center of the
grid. Always place a tray beneath to catch
any drips of oil or fat. It is recommended
to pre-heat the oven about 10 minutes.
Warning: When grilling, the oven door
must be closed and the oven temperature
should be adjusted to 190C°.
Pyrolytic Cleaning Function
This function allows you to clean throughly
the oven cavity.
WARNING:
•Before activating pyrolytic
cleaning function, remove any
excessive spillage and make sure
that the oven is empty. Do not leave
anything inside the oven cavity (e.g. wire
grids, shallow tray, deep tray etc. ) As this
could heavily damage them.
The oven’s thermostat and warning
lights will be turned on, the upper and
lower heating elements and fan will start
operating.
This function is very good for obtaining
results in baking pastry. Cooking is carried
out by the lower and upper heating element
within the oven and by the fan providing
air circulation, which will give a slight grill
effect to the food. It is recommended to
pre-heat the oven about 10 minutes.
Grilling Function:
The oven’s thermostat and warning lights
will be turned on, the grill heating element
will start operating. The function is used
for grilling and toasting foods, use the
upper shelves of oven. Lightly brush the
wire grid with oil to stop foods sticking
and place foods in the center of the grid.
Always place a tray beneath to catch any
drips of oil or fat. It is recommended to
pre-heat the oven about 10 minutes.
Warning: When grilling, the oven door
must be closed and the oven temperature
should be adjusted to 1900C.
Faster Grilling Function:
The oven’s thermostat and warning
lights will be turned on, the grill and upper
heating elements will start operating. The
function is used for faster grilling and for
covering a larger surface area, such as
grilling meats, use the upper shelves of
oven. Lightly brush the wire grid with oil
to stop foods sticking and place foods in
the center of the grid. Always place a tray
beneath to catch any drips of oil or fat. It is
recommended to pre-heat the oven about
10 minutes. Warning: When grilling, the

EN - 12
•Before activating the pyrolytic cleaning
function, remove the wire oven shelves
and shelf supports (if available).
• Ensure that the oven door closed before
activating the pyrolytic cleaning function.
•The oven door will be locked when the
pyrolytic function started.
•When the pyrolytic cleaning function is
on, it is advisable not to use a hob if it is
fitted above the oven. This could cause
overheating and damage to both appliances.
•During the pyrolytic cleaning cycle the oven
door becomes hot. Children should be kept
away until it has cooled.
•At the end of pyrolytic cleaning process,
the display shows the time of day.
Pyrolytic Cleaning
•The oven cavity is coated with a special
emanel resistant to high temperatures.
• During the pyrolytic cleaning operation, the
temperature inside the oven can reach about
475
ºC does burning food residuals. For
your security, during the pyrolytic cleaning
operation, the oven door automaticly locks.
• Upon completion of the cleaning
operation the oven door will be
locked until the oven cavity has
cooled down.
• The cooling fan operates until the oven has
cooled down. After cooking, it is advisable
to remove all the food residues with a wet
sponge.
•It is advisable to wipe the oven over with
a sponge soaked in warm water after each
pyrolytic cleaning cycle is carried out.
•During the Pyrolytic operation, some smell
and fume will be emanated due to destruction
of the food residual, it is normal. Oven
cleaning fumes could be fatal to birds and
disturb especially childrens and pets, so all
should be moved into the other room until it
was nished. During the Pyrolytic operation,
the room where the oven installed must be
ventilated sufciently and the kitchen door
should be closed to avoid passing smell
and fume to other rooms..
ENERGY SAVING
Minimize the amount of liquid or
fat to reduce cooking times.
Oven door should not be opened often
during cooking period.

EN - 13



On/Off Key lock Plus
Function selection Boost Minus
Play/Pause Thermostat Temperature display
Mode Time display Pyrolytic cleaning
The control unit will switch off after 5
minutes if no function is selected or
changed.
The appliance is operated using touch
control sensors. The functions are
controlled by touching the sensor elds.
When you are using the controls, make
sure that you touch the sensor field
correctly. If your touch is too at or too
small the sensors will not operate correctly.
The cooling fan will switch on automatically
in order to keep the surfaces of the
appliance cool. The fan will continue to
run until it automatically switches off, even
after the oven has been switched off.
Oven Function Selection
Touch the  sensor for 2 seconds
to switch the control unit on. The oven will
enter “” mode. During this mode, you
will be able to select the desired cooking
functions, adjust the temperature, activate
the  function, as well as adjust the
cooking time, end time, Minute Minder
timer and the time of day.
During “”mode, the desired cooking
function can be selected by touching the 
sensor button. Each touch on the sensor
will change the oven function, as shown
below (some of these cooking functions
may not be present in your cooker model):
Lamp → Defrost → Turbo → Upper and
Lower → Upper and Lower with Fan →
Grill (with/without turnspit) → Double Grill
(with/without turnspit) → Double Grill with
Fan (with/without turnspit).
The operated heaters and accessories
related to the selected function will be
displayed.
When a cooking function is selected
using the sensor, the previously
selected temperature value will show

EN - 14
on the Temperature display. This can be
adjusted using the and 
sensor buttons on the side of the display.
The temperature can be adjusted within
the range of 50°C to 275°C.
After the desired function has been
selected, and the temperature and time
are set, touch the  sensor
to start the oven function operation.
Adjusting the Time of Day
When the oven has been installed, the
time of day must be set according to the
following instructions.
Touch the  sensor to switch the
oven on and enter “” mode. During
this mode, touch the  sensor button
until the time is selected. The symbol for
the time will illuminate on the left side
and you can adjust it using the 
and  sensor buttons. To complete
the time adjustment, touch the 
sensor once again.
The time will only have to be set again if
the appliance is disconnected from the
power supply for a long period of time.
Adjusting the Cooking Time
The cooking time can be adjusted during
“” mode or during “”
mode.

Touch the  sensor until the Minute
Minder symbol illuminates on the Time
display and “” appears. Adjust
the desired time period for the warning
signal using the  and  sensor
buttons while the symbol is ashing. When
you have completed the adjustment, do
not press any buttons for a few seconds,
then the Minute Minder timer will be set.
When the timer reaches zero, an audible
warning will sound, and the Minute Minder
symbol and “” will flash on the
Time display. Press any button to stop
the audible warning and the symbol will
disappear.
Adjusting the Cooking Duration Time
This function helps you to cook for a
fixed period of time. Prepare the food
for cooking and put it in the oven. Then,
select the desired cooking function and
the temperature. Touch the  sensor
button until you see the Duration Time
symbol on the Time display. Set the
required cooking period using the 
and  sensors while the timer is in
this position. When you have completed
the adjustment, wait until the current time
of day is displayed and until the Duration
Time symbol remains illuminated.
When the timer reaches zero, the oven will
switch off, an audible warning will sound
and the Duration Time symbol will ash
on the Time display. Touch any sensor on
the control unit to end the sound.
Adjusting the Cooking End Time
This function is used to begin cooking
after a certain period of time and for a
specic duration of time. Prepare the food
for cooking and put it in the oven. Then,
select the desired cooking function and
the temperature.
Touch the  button until you see the
Cooking Duration Time symbol on the
Time display. Set the required cooking
period using the  and  sensor
while the timer is in this position. When
you have completed the adjustment, wait
until the current time of day is displayed
and until the Cooking Duration Time
symbol remains illuminated.

EN - 15
Then, touch the  sensor button until
you see the Cooking End Time symbol
on the Time display. The time of day and
the Cooking Duration Time symbol will
ash. Set the required nish time using
the  and  sensors while the
timer is in this position. When you have
completed the adjustment, wait until the
current time of day is displayed and until
the Cooking End Time symbol remains
illuminated.
The oven will calculate the operating time
by deducting the cooking period from the
set finishing time, at which it will stop
operating. The timer will give an audible
warning and the Cooking End Time symbol
will ash. Touching any button on the timer
will end the audible warning.
Digital Timer Sound Adjustment
To alter the warning signal sound, while the
Time display shows the time of day, press
and hold the  sensor button for 2
seconds until there is an audible signal
sound. After this, each time the 
sensor is pressed, a different signal will
sound. There are three different types of
signal sound. Select the desired sound
and do not press any other buttons. After
a short time, the selected signal sound
will be saved.
Boost Function
This function is used to shorten the
preheating time. The  sensor will
illuminate when the Turbo, Fan, Static
or Pizza functions are selected. To save
preheating time, touch the  sensor
button before starting a cooking operation.
Use this function to heat the oven the
desired temperature as quickly as
possible. This mode is not appropriate
for cooking.
Key Lock Function
The key lock is used to avoid unintentional
changes to oven settings.
To activate the key lock, touch the 
sensor button for 2 seconds until
you see Key Lock symbol on the display.
To deactivate the key lock, touch the 
sensor for 2 seconds until the key
lock symbol disappears from the display.
When the key lock is engaged, only the
 sensor button can be activated.
All other buttons will remain locked.

EN - 16
DISHES
TURBO LOWER-UPPER LOWER-UPPER FAN GRILL
Thermostat
pos. (°C)
Rack
pos.
Cooking
period
(min)
Thermostat
pos. (°C)
Rack
pos.
Cooking
period
(min)
Thermostat
pos. (°C)
Rack
pos.
Cooking
period
(min)
Thermostat
pos. (min)
Rack
pos.
Cooking
period
(min)
Layered pastry 170-190 2-3-4 35-45 170-190 2-3-4 35-45 170-190 2-3-4 25-35
Cake 150-170 2-3-4 30-40 170 -190 2-3-4 30-40 150-170 2-3-4 25-35
Cookie 150-170 2-3-4 25-35 170-190 2-3-4 30-40 150-170 2-3-4 25-35
Grilled meatballs 200 710-15
Watery food 175-200 2 40-50 175-200 2 40-50 175-200 2 40-50
Chicken 200 2-3-4 45-60 200 2-3-4 45-60 200 * 50-60
Chop 200 6-7 15-25
Beefstake 200 6-7 15-25 Two-tray cake 160-180 1-4 30-40
Two-tray pastry 170-190 1-4 35-45
* Cook with roast chicken skewer...
Wire Rack with Easyfix Full Extension
Telescopic Rail
The telescopic rail extends out fully to allow
easy access to your food.
Telescopic rails
Clean the accessories thoroughly with
warm water, detergent and a soft clean
cloth on first use.
Fastening tab
Fastener
• Positioning of the telescopic rails on the
wire rack is secured with the fastening
tabs on the fasteners.
• Remove the side runner. See section
“Removal of the wire shelf”.
• On each telescopic rail there are top
and bottom fasteners that allows you to
reposition the rails.
• Hang the telescopic rail top fasteners
on the side rack level reference wire
and simultaneously press the bottom
fasteners until you clearly hear the
fasteners clip into the side rack level
fixing wire.
• In order to remove, hold the front
surface of the rail and follow the
previous instructions in reverse.

EN - 17
Accessories
The product is supplied with accesso-
ries. You can also use accessories you
purchase from other sources, but they
must be heat and ame resistant. You
can also use glass dishes, cake molds
and oven trays that are appropriate for
use in oven. Follow manufacturer’s ins-
tructions when using other accessories.
In case small size dishes are used, pla-
ce the dish onto the wire grid, as it will
completely be on the middle part of the
grid. If the food to be cooked does not
cover the oven tray completely, if the
food is taken from the deep freezer or
the tray is being used for the collection
of food’s juices that ow during grilling,
the form changes can be observed in
the tray. This is due to the high tempe-
ratures that occur during cooking. The
tray will return to its old form when the
tray cools down after cooking. This is
a normal physical event that occurs
during heat transfer. Do not place hot
glass trays and dishes into a cold envi-
ronment straight from the oven to avoid
breaking the tray or dish. Do not put onto
cold and wet surfaces. Place on a dry
kitchen cloth and allow to cool slowly.
When using the grill in your oven; we
recommend (where appropriate) you
use the grid that was supplied with the
product. When using the wire grid; put
a tray onto one of the lower shelves to
enable oil to be collected. Water may be
added to the tray to assist cleaning. As
explained in the corresponding clauses,
never attempt to use the gas operated
grill burner without the grill protection
lid. If your oven has a gas operated grill
burner, but the grill heat shield is mis-
sing, or if it is da
maged and cannot be used, request a
spare part from the nearest service
centre.
Oven Accessories
The accessories for your oven may be
different due to the model of your pro-
duct.
Wire grid
Wire grid is used to grill or to place diffe-
rent cookwares on.
 Fit the grid correctly into
any corresponding rack in the oven ca-
vity and push it to the back.
Shallow Tray
Shallow tray is used to bake pastry such
as ans etc.To locate the tray correctly
in the cavity, put it to any rack and push
5. Rack
4. Rack
3. Rack
2. Rack
1. Rack

