AUTOMATIC RICE COOKER
MODELS KSH-206 / 211
KSH-215 / 218
KSH-222 / 228
TABLE OF CONTENTS
PARTS IDENTIFICATION AND SPECIFIC INFORMATION ..................................................
CAUTIONS FOR USE............................................................................................................
HOW TO CLEAN THE COOKER...........................................................................................
WIRING DIAGRAM AND CIRCUIT DIAGRAM.......................................................................
METHOD OF OPERATION....................................................................................................
ADJUSTMENT OF SWITCH LEVER AND CONTACTS.........................................................
INSPECTION AFTER REPAIRING.........................................................................................
TESTING OPERATING CONDITION......................................................................................
PROBLEMS AND SOLUTIONS..............................................................................................
SERVICE PARTS LIST...........................................................................................................
Page
2
3
3
4
5
6 - 7
8
8
9
10-26
In the interests of user-safety (Required by safety
regulation in some countries) the set should be
restore to its original condition and only parts identical
to those specied should be used.

2
PARTS IDENTIFICATION
Inner pot
Leg
Outer pot Power cord plug
(Model KSH-206 cord is xed with the pot)
SPECIFIC INFORMATION
Model
Rated voltage (V) 220
50
Power consumption
(W)
Rice cooking
Warming
Rice cooking
capacity Min
Product dimension
(mm.)
Weight (kg)
Rated frequency (Hz)
Max
KSH-206
300
35
237
198
195
1.1
485
42
261
222
215
1.5
530
46.5
308
255
246
1.9
600
48.5
323
269
244
2.0
800
52.5
351
289
268
2.9
1,000
65.5
367
304
289
3.4
KSH-211 KSH-215 KSH-218 KSH-222 KSH-228
W
D
H
0.6 . or 3.5 cups
0.18 . or 1 cup 0.18 . or 1 cup 0.27 . or 1.5 cups 0.36 . or 2 cups 0.36 . or 2 cups 0.72 . or 4 cups
1.1 . or 6 cups 1.5 . or 8 cups 1.8 . or 10 cups 2.2 . or 12 cups 2.8 . or 15 cups
Handle
Cook switch
Upper lid
Knob
Panel
“WARM” indicator lamp
“COOK” indicator lamp

3
HOW TO CLEAN THE COOKER
Always unplug and let the rice cooker cool down before cleaning.
1. Heater plate.
Use the damp ne sandpaper to clean the dirty area and wipe out with sponge or damp cloth, then wipe again
with the dry cloth to remove the humidity.
2. Inner pot / upper lid.
Soak inner pot and upper lid in lukewarm water and wash with sponge, washing detergent or liquid detergent
and then wipe with dry cloth.
3. Outer pot.
Wash with sponge and wipe with cloth to dry it. Do not use any harsh cleanser or outer pot as it could crack the
surface.
CAUTIONS FOR USE
1. Keep clean the brim and bottom of inner pot, heater plate at all times to avoid sticking cooked rice, uncooked
rice grains, dust and dirt. Cooking performance may be made worse by such sticking rice grain and the like.
2. Do not use the damaged inner pot. It may cause in malfunction.
3. When warming operation is no longer required, please unplug the power cord.
4. Never push the cook switch when the inner pot with rice is not placed in, never insert any object into the switch.
It may cause a trouble.
5. After cooking is over and need to continue cooking, please wait for in order to allow about 10 minutes
thermostat resume to normal condition.
6. Take precautions against intensive vibration or impact from inadvertent handling while cooking is carried on,
which may cause malfunction of thermostat, thus the nish of cooked rice may be made worse.
7. Do not immerse the set in water or sprinkling water on the heater plate.
8. In case the power cord is broken, it must be replaced by manufacturer or appointed service providers or
equivalent professionals to avoid any damages. (Model : KSH-206)
In case the power cord is broken, it must be replaced with specialized power cord or the standard power cord
made by manufacturer or appointed service providers. (Model : KSH-211, KSH-215, KSH-218, KSH-222,
KSH-228)
9. Disconnect the plug from the wall outlet every time after use.
10. Do not use the cooker on a wet oor, under direct sunlight or near the gas stove.
11. While cooking, do not put the rice cooker on or near combustible materials such as curtains or vinyl carpets.
12. During or immediately after cooking, the areas near the steam vent hole are kept at high temperature.
Do not touch those areas to avoid burns.
13. Never connect the plug with your wet hand as it may be dangerous from electric leakage.
14. Do not use any other inner pot except the provided one.
15. Keep the rice cooker out of the children’s reach, especially when cooking rice.
16. Never share the wall outlet with other appliances.
17. Do not opening the upper lid when during boiling because touched hot steam.
18. Insert the plug into the wall outlet rmly and when disconnecting, hold the plug and pull it out without touching
the power cord.
19. Do not use the inner pot with other heating appliances such as a gas stove. The inner pot may be transformed
and it may cause poor cooking result.
20. Do not leave the plastic spoon in the rice cooker while cooking or warming.
21. Do not disassemble or repair the cooker by yourself, it may cause troubles such as a re of electric shock.
Consult your nearest dealer.

4
WIRING DIAGRAM
CIRCUIT DIAGRAM
220VAC
Micro switch
COM.
NC.
W/H
H/P
Temp. fuse
Cooking Warming
Temp. fuse ass’y
Micro SW.
Terminal AMP (D)
Connecting ring
Heater plate ass’y
Connector P-2
Tube
Plug pin
Warm heater ass’y
Tube
Neon lamp ass’y
Closed terminal
com
nc
Neon lamp ass’y
Tube
Closed terminal
Power cord
Cord stopper
Brown
Temp. fuse ass’y
Heater plate ass’y
Connecting ring
Micro SW.
Terminal AMP (D)
com
nc
Terminal AMP (D)
Warm heater ass’y
Tube
Blue
Model : KSH-206
Model : KSH-211
KSH-215
KSH-218
KSH-222
KSH-228

5
METHOD OF OPERATION
Different degree of temperature at various parts of the cooker during its operation.
After being switch “ON” the operation will be started by generating heat from the heater plate and spread
through the bottom of inner pot. As long as there still be water in the inner pot, the temperature at the bottom will
be always lower than 100 C.
When rice at the bottom is well cooked cause no more water left, then the temperature will sharply raise
up to certain level more than 100 C that the thermostat will automatically switch off the heater plate operation.
(As a whole process, it takes about 30 minutes.)
At this stage, rice at the top is not yet still well cooked, warm heater will automatically start working
consecutively after heater plate being switch off. It takes another 15 minutes until rice is completely in the proper
manners.
To repair rice cooker, the following parts should be carefully checked and / or repaired in the proper manners.
1. Inner pot.
Outer side : It must be cleaned without any contaminants and particles at the bottom for it can be rmly
contacted the heater plate evenly.
Inner side : It must be cleaned without dry cooked rice at the bottom, otherwise it can be the prevention of
heat transmission throughout the inner pot. And it may cause temperature at the bottom raise
up to the level which can be switched of the heater plate (as above explained) before the proper
time. So, it may cause improper rice-cooking.
2. Heater plate and thermostat.
- Ensure that there is no any contaminant or deposits on heater plate and thermostat, it will cause the operation
of switching off before the proper time.
3. Switch lever and micro switch.
- The switch lever and micro switch must be in proper alignment.
4. Cook switch.
- Cook switch must be in proper working, otherwise it may cause thermostat be unable to cut off when rice is
already cooked.
30 MINUTES
C
TEMPERATURE
TIME
THERMOSTAT CUTS OFF
HEATER PLATE
INNER POT
THERMOSTAT
RICE
100 C

6
A. Thermostat rod must not be drew up by switch lever. It should be moving left and right easily.
ADJUSTMENT OF SWITCH LEVER AND CONTACTS
1. Turn over the outer pot with inner pot inside, disclose its bottom lid. Push cook switch, adjust switch lever
and switch angle. 
Bottom lid
Outer pot
Cook switch
Inner pot
Push the cook switch
Cook switch
Gap
Micro switch
Micro switch
Switch lever
Gap
Thermostat rod
Reector
Reector
Thermostat ass’y
Switch lever
Inner pot
Heater plate
A

7
3. Ensure the capability of up-down movement of switch lever.
2. As soon as inner pot is lifted up from outer pot, switch lever must be spring up and micro switch is pressed
completely. This rice cooker is so designed that the cook switch will not be put in “COOK” position whenever the
inner pot is taken off or not set into the cooker before use.
Micro switch
Switch lever
Cook switch
Reector
Heater plate
Thermostat spring back
Thermostat ass’y
Cook switch spring back
Switch lever
No gap
Thermo plate touch
reector
Reector
Thermostat ass’y

8
TESTING OPERATING CONDITION
1. Simplied Testing Method
1. Firmly put inner pot into the cooker, and also close the upper lid.
2. Plug the power cord.
3. Push cook switch to check the operation of thermostat. It will cut off approximately in 3-5 minutes, which is
the standard timing.
2. Water Boiling Method
1. Fill 2 measuring cups of water in the inner pot.
2. Firmly put inner pot into the outer pot.
3. Plug the power cord.
4. Push cook switch .
5. As soon as water evaporated dry, thermostat must cut off.
3. Rice-Cooking Method
1. Fill rice and water at the maximum level of the inner pot.
2. Plug the power cord, and push cook switch.
3. After rice is already cooked and warm for 15 minutes further, check whether the rice is completely cooked.
4. Turn over the inner pot, check the cooked rice at the bottom of inner pot. If its overdone layer is slightly
light drown, the cooking operation is acceptable. In contrary, if cooked rice is brownish of uncompletely
cooked, thermostat may be fault.
INSPECTION AFTER REPAIRING
1. Cook switch should be at the center of panel.
2. Ensure that there is no any contaminants, deposits, stains exist on heater plate, thermostat and outside
bottom of inner pot.
3. Firmly put inner pot inside the cooker, move inner pot right and left to ensure it can be closely contact
with outer pot.
4. Check the operation of cook switch and thermostat.
- When inner pot is already put in, little bit right and left moveable, push cook switch, the state of cook switch
must be steadily pushed down, as soon as the inner pot is lifted up, cook switch will automatically spring up.
5. Check the operation of indicator lamp and cook switch connection.
5.1 Plug the power cord.
5.2 Check the state of indicator lamp when push “COOK” switch and “WARM”.
5.3 Put the inner pot into the cooker, push cook switch. Ensure that the inner pot can be rmly contacted with the
heater plate.

PROBLEMS AND SOLUTIONS
1. Incompletely cooked
rice.
2. Unevenly cooked
rice.
3. Waterish uncooked
rice.
4. Overdone brown
rice.
5. Cook indicator
lamp not go “ON”.
6. Cook indicator lamp
go “ON” but failure
of heat conduction.
7. Failure warming.
1. Warm indicator
not go “ON”.
2. Failure to keep
warm.
1. Inner pot improperly
contacted with heater
plate.
2. Failure in setting inner
pot.
3. Faulty thermostat.
4. Dirty heater plate.
1. Deformed inner pot.
2. Dirty heater plate.
1. Faulty thermostat.
2. Faulty switch.
3. Deformed inner pot or
heater plate.
1. Malfunction of switch
lever.
2. Faulty thermostat.
3. Deformed inner pot or
heater plate.
1. Disconnected power cord.
2. Faulty wiring.
3. Malfunction of switch.
4. Disconnected resistor.
1. Faulty wiring.
2. Faulty heater plate.
1. Burned-out wire.
2. Faulty warm heater.
1. Faulty warm heater.
2. Disconnected wiring.
1. Adjust or replace. Boil about 800 cc. of
water. Check the state
of bubbles at the bottom
of inner pot.
If bubbles rise up evenly
around the bottom, it is
acceptable.
2. Adjust.
3. Replace.
4. Clean.
1. Replace.
2. Clean.
1. Replace.
2. Clean.
3. Replace.
1. Adjust or replace.
2. Replace.
3. Replace.
1. Repair.
2. Repair.
3. Adjust or replace.
4. Replace.
1. Repair.
2. Replace.
1. Replace.
2. Replace.
1. Replace.
2. Repair.
Problems Possible causes Solution Check
Acceptable
Unacceptable
9

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 1B631 * INSTRUCTION BOOK 1
1-2 1U6018 SET PACKING CASE 1
1-3 1U604 CARTON BOX 1
1-4 21A5062 MEASURING CUP 1
1-5 1U6052 BOTTOM PAD 2
1-6 1U6092 UPPER PAD 2
MECHANICAL PARTS
2-1 1U1033BASY UPPER LID ASS’Y Sky Blue 1
1U1033GRASY UPPER LID ASS’Y Green 1
1U1033NASY UPPER LID ASS’Y Navy Blue 1
1U1033RASY UPPER LID ASS’Y Red 1
1U1033GASY UPPER LID ASS’Y Grey 1
2-1-1 1U1033 UPPER LID 1
2-1-2 1A1122BL KNOB Sky Blue 1
1A1122GR KNOB Green 1
1A1122NB KNOB Navy Blue 1
1A1122RE KNOB Red 1
1A1122G KNOB Grey 1
2-1-3 1U1532 LID KNOB BUSH 1
2-1-4 1U1042 KNOB SCREW 1
2-2 1U1052 INNER POT 1
2-3 1U4014FL OUTER POT FL 1
1U4014JM OUTER POT JM 1
1U4014PC OUTER POT PC 1
1U4014PP OUTER POT PP 1
1U4014RB OUTER POT RB 1
1U4014M OUTER POT M 1
1U4014P OUTER POT P 1
2-4 1A4024BL HANDLE Sky Blue 2
1A4024GR HANDLE Green 2
1A4024NB HANDLE Navy Blue 2
1A4024RE HANDLE Red 2
1A4024G HANDLE Grey 2
2-5 1A4033BASY PANEL ASS’Y Sky Blue 1
1A4033GRASY PANEL ASS’Y Green 1
1A4033NASY PANEL ASS’Y Navy Blue 1
1A4033RASY PANEL ASS’Y Red 1
1A4033GASY PANEL ASS’Y Grey 1
2-6 1A3042 INSULATOR COVER 1
2-7 1U2031 THERMOSTAT SPRING 1
2-8 1A2051 * THERMO PLATE 1
2-9 1U3913SET SWITCH SET 1
2-10 1U309BASY BOTTOM LID ASS’Y Sky Blue 1
1U309GRASY BOTTOM LID ASS’Y Green 1
1U309NASY BOTTOM LID ASS’Y Navy Blue 1
1U309RASY BOTTOM LID ASS’Y Red 1
1U309GASY BOTTOM LID ASS’Y Grey 1
1U309BNASY BOTTOM LID ASS’Y Black 1
2-11 6AB041 CORD STOPPER HOLDER 1
10
SERVICE PARTS LIST KSH-206

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
ELECTRIC PARTS
3-1 1U4187 POWER CORD PLUG 1
3-2 1U2014 * HEATER PLATE ASS’Y 1
3-3 1U2021ASY * THERMOSTAT ASS’Y 1
3-4 1U4917ASY NEON LAMP ASS’Y 1
3-5 1U2391 TEMP. FUSE ASS’Y 1
3-6 1U4201 WARM HEATER ASS’Y 1
3-7 2A410 MICRO SWITCH 1
11

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 1B631 * INSTRUCTION BOOK 1
1-2 1A6029 SET PACKING CASE 1
1-3 1A6344 CARTON BOX 1
1-4 21A5062 MEASURING CUP 1
1-5 1A6052 BOTTOM PAD 2
1-6 1A6093 UPPER PAD 2
MECHANICAL PARTS
2-1 1A1034BASY UPPER LID ASS’Y Sky Blue 1
1A1034GRASY UPPER LID ASS’Y Green 1
1A1034NASY UPPER LID ASS’Y Navy Blue 1
1A1034RASY UPPER LID ASS’Y Red 1
1A1034GASY UPPER LID ASS’Y Grey 1
2-1-1 1A1034 UPPER LID 1
2-1-2 1A1122BL KNOB Sky Blue 1
1A1122GR KNOB Green 1
1A1122NB KNOB Navy Blue 1
1A1122RE KNOB Red 1
1A1122G KNOB Grey 1
2-1-3 1U1532 LID KNOB BUSH 1
2-1-4 1U1042 KNOB SCREW 1
2-2 1A106 INNER POT 1
2-3 1A4016FL OUTER POT FL 1
1A4016JM OUTER POT JM 1
1A4016PC OUTER POT PC 1
1A4016PP OUTER POT PP 1
1A4016RB OUTER POT RB 1
1A4016M OUTER POT M 1
1A4016P OUTER POT P 1
2-4 1A4024BL HANDLE Sky Blue 2
1A4024GR HANDLE Green 2
1A4024NB HANDLE Navy Blue 2
1A4024RE HANDLE Red 2
1A4024G HANDLE Grey 2
2-5 1A4033BASY PANEL ASS’Y Sky Blue 1
1A4033GRASY PANEL ASS’Y Green 1
1A4033NASY PANEL ASS’Y Navy Blue 1
1A4033RASY PANEL ASS’Y Red 1
1A4033GASY PANEL ASS’Y Grey 1
2-6 1A3042 INSULATOR COVER 1
2-7 1B2031 THERMOSTAT SPRING 1
2-8 1A2051 * THERMO PLATE 1
2-9 1A3915SET SWITCH SET 1
2-10 1A309BASY BOTTOM LID ASS’Y Sky Blue 1
1A309GRASY BOTTOM LID ASS’Y Green 1
1A309NASY BOTTOM LID ASS’Y Navy Blue 1
1A309RASY BOTTOM LID ASS’Y Red 1
1A309GASY BOTTOM LID ASS’Y Grey 1
1A309BNASY BOTTOM LID ASS’Y Black 1
2-11 1A492UASY PLUG INSULAOR ASS’Y 1
12
KSH-211

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
ELECTRIC PARTS
3-1 1B4934ASY POWER CORD ASS’Y 1
3-2 1A2014 * HEATER PLATE ASS’Y 1
3-3 1A2021ASY * THERMOSTAT ASS’Y 1
3-4 1A4917ASY NEON LAMP ASS’Y 1
3-5 1A2394 TEMP. FUSE ASS’Y 1
3-6 1A2076 WARM HEATER ASS’Y 1
3-7 2A410 MICRO SWITCH 1
13

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 1B631 * INSTRUCTION BOOK 1
1-2 1J6019 SET PACKING CASE 1
1-3 1J6045 CARTON BOX 1
1-4 21A5062 MEASURING CUP 1
1-5 1J6052 BOTTOM PAD 2
1-6 1J6092 UPPER PAD 2
MECHANICAL PARTS
2-1 1J1032BASY UPPER LID ASS’Y Sky Blue 1
1J1032GRASY UPPER LID ASS’Y Green 1
1J1032NASY UPPER LID ASS’Y Navy Blue 1
1J1032RASY UPPER LID ASS’Y Red 1
1J1032GASY UPPER LID ASS’Y Grey 1
2-1-1 1J1032 UPPER LID 1
2-1-2 1B1122BL KNOB Sky Blue 1
1B1122GR KNOB Green 1
1B1122NB KNOB Navy Blue 1
1B1122RE KNOB Red 1
1B1122G KNOB Grey 1
2-1-3 1B1531 LID KNOB BUSH 1
2-1-4 1A1043 KNOB SCREW 1
2-2 1J1052 INNER POT 1
2-3 1J4016FL OUTER POT FL 1
1J4016JM OUTER POT JM 1
1J4016PC OUTER POT PC 1
1J4016PP OUTER POT PP 1
1J4016RB OUTER POT RB 1
1J4016M OUTER POT M 1
1J4016P OUTER POT P 1
2-4 1B4023BL HANDLE Sky Blue 2
1B4023GR HANDLE Green 2
1B4023NB HANDLE Navy Blue 2
1B4023RE HANDLE Red 2
1B4023G HANDLE Grey 2
2-5 1B4035BASY PANEL ASS’Y Sky Blue 1
1B4035GRASY PANEL ASS’Y Green 1
1B4035NASY PANEL ASS’Y Navy Blue 1
1B4035RASY PANEL ASS’Y Red 1
1B4035GASY PANEL ASS’Y Grey 1
2-6 1A3042 INSULATOR COVER 1
2-7 1B2031 THERMOSTAT SPRING 1
2-8 1A2051 * THERMO PLATE 1
2-9 1J3912SET SWITCH SET 1
2-10 1J309BASY BOTTOM LID ASS’Y Sky Blue 1
1J309GRASY BOTTOM LID ASS’Y Green 1
1J309NASY BOTTOM LID ASS’Y Navy Blue 1
1J309RASY BOTTOM LID ASS’Y Red 1
1J309GASY BOTTOM LID ASS’Y Grey 1
1J309BNASY BOTTOM LID ASS’Y Black 1
2-11 1A492UASY PLUG INSULAOR ASS’Y 1
14
KSH-215

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
ELECTRIC PARTS
3-1 1B4934ASY POWER CORD ASS’Y 1
3-2 1J2011 * HEATER PLATE ASS’Y 1
3-3 1A2021ASY * THERMOSTAT ASS’Y 1
3-4 1J4918ASY NEON LAMP ASS’Y 1
3-5 1C2392 TEMP. FUSE ASS’Y 1
3-6 1B4201 WARM HEATER ASS’Y 1
3-7 2A410 MICRO SWITCH 1
15

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 1B631 * INSTRUCTION BOOK 1
1-2 1B6032 SET PACKING CASE 1
1-3 1B6264 CARTON BOX 1
1-4 21A5062 MEASURING CUP 1
1-5 1B6052 BOTTOM PAD 2
1-6 1B6093 UPPER PAD 2
MECHANICAL PARTS
2-1 1B1032BASY UPPER LID ASS’Y Sky Blue 1
1B1032GRASY UPPER LID ASS’Y Green 1
1B1032NASY UPPER LID ASS’Y Navy Blue 1
1B1032RASY UPPER LID ASS’Y Red 1
1B1032GASY UPPER LID ASS’Y Grey 1
2-1-1 1B1032 UPPER LID 1
2-1-2 1B1122BL KNOB Sky Blue 1
1B1122GR KNOB Green 1
1B1122NB KNOB Navy Blue 1
1B1122RE KNOB Red 1
1B1122G KNOB Grey 1
2-1-3 1B1531 LID KNOB BUSH 1
2-1-4 1A1043 KNOB SCREW 1
2-2 1B1061 INNER POT 1
2-3 1B4018FL OUTER POT FL 1
1B4018JM OUTER POT JM 1
1B4018PC OUTER POT PC 1
1B4018PP OUTER POT PP 1
1B4018RB OUTER POT RB 1
1B4018M OUTER POT M 1
1B4018P OUTER POT P 1
2-4 1B4023BL HANDLE Sky Blue 2
1B4023GR HANDLE Green 2
1B4023NB HANDLE Navy Blue 2
1B4023RE HANDLE Red 2
1B4023G HANDLE Grey 2
2-5 1B4035BASY PANEL ASS’Y Sky Blue 1
1B4035GRASY PANEL ASS’Y Green 1
1B4035NASY PANEL ASS’Y Navy Blue 1
1B4035RASY PANEL ASS’Y Red 1
1B4035GASY PANEL ASS’Y Grey 1
2-6 1A3042 INSULATOR COVER 1
2-7 1B2031 THERMOSTAT SPRING 1
2-8 1A2051 * THERMO PLATE 1
2-9 1B3918SET SWITCH SET 1
2-10 1B309BASY BOTTOM LID ASS’Y Sky Blue 1
1B309GRASY BOTTOM LID ASS’Y Green 1
1B309NASY BOTTOM LID ASS’Y Navy Blue 1
1B309RASY BOTTOM LID ASS’Y Red 1
1B309GASY BOTTOM LID ASS’Y Grey 1
1B309BNASY BOTTOM LID ASS’Y Black 1
2-11 1A492UASY PLUG INSULAOR ASS’Y 1
KSH-218
16

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
ELECTRIC PARTS
3-1 1B4934ASY POWER CORD ASS’Y 1
3-2 1B2012 * HEATER PLATE ASS’Y 1
3-3 1A2021ASY * THERMOSTAT ASS’Y 1
3-4 1B4951ASY NEON LAMP ASS’Y 1
3-5 1C2392 TEMP. FUSE ASS’Y 1
3-6 1B4201 WARM HEATER ASS’Y 1
3-7 2A410 MICRO SWITCH 1
17

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 1B631 * INSTRUCTION BOOK 1
1-2 1H6015 SET PACKING CASE 1
1-3 1H6253 CARTON BOX 1
1-4 21A5062 MEASURING CUP 1
1-5 1H6511 BOTTOM PAD 2
1-6 1H6521 UPPER PAD 2
MECHANICAL PARTS
2-1 1H1032BASY UPPER LID ASS’Y Sky Blue 1
1H1032GRASY UPPER LID ASS’Y Green 1
1H1032NASY UPPER LID ASS’Y Navy Blue 1
1H1032RASY UPPER LID ASS’Y Red 1
1H1032GASY UPPER LID ASS’Y Grey 1
2-1-1 1H1032 UPPER LID 1
2-1-2 1H1122BL KNOB Sky Blue 1
1H1122GR KNOB Green 1
1H1122NB KNOB Navy Blue 1
1H1122RE KNOB Red 1
1H1122G KNOB Grey 1
2-1-3 1B1531 LID KNOB BUSH 1
2-1-4 1A1043 KNOB SCREW 1
2-2 1G1052 INNER POT 1
2-3 1H4012FL OUTER POT FL 1
1H4012JM OUTER POT JM 1
1H4012PC OUTER POT PC 1
1H4012PP OUTER POT PP 1
1H4012RB OUTER POT RB 1
2-4 1H4024BL HANDLE Sky Blue 2
1H4024GR HANDLE Green 2
1H4024NB HANDLE Navy Blue 2
1H4024RE HANDLE Red 2
1H4024G HANDLE Grey 2
2-5 1H4035BASY PANEL ASS’Y Sky Blue 1
1H4035GRASY PANEL ASS’Y Green 1
1H4035NASY PANEL ASS’Y Navy Blue 1
1H4035RASY PANEL ASS’Y Red 1
1H4035GASY PANEL ASS’Y Grey 1
2-6 1A3042 INSULATOR COVER 1
2-7 1B203 THERMOSTAT SPRING 1
2-8 1A2051 * THERMO PLATE 1
2-9 1H3911SET SWITCH SET 1
2-10 1H308BASY BOTTOM LID ASS’Y Sky Blue 1
1H308GRASY BOTTOM LID ASS’Y Green 1
1H308NASY BOTTOM LID ASS’Y Navy Blue 1
1H308RASY BOTTOM LID ASS’Y Red 1
1H308GASY BOTTOM LID ASS’Y Grey 1
2-11 1A492UASY PLUG INSULAOR ASS’Y 1
18
KSH-222

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
ELECTRIC PARTS
3-1 1H4931ASY POWER CORD ASS’Y 1
3-2 1G2011 * HEATER PLATE ASS’Y 1
3-3 1A2021ASY * THERMOSTAT ASS’Y 1
3-4 1H4919ASY NEON LAMP ASS’Y 1
3-5 1C2392 TEMP. FUSE ASS’Y 1
3-6 1G420 WARM HEATER ASS’Y 1
3-7 2A410 MICRO SWITCH 1
19

REF. NO PARTS CODE DESCRIPTION Q’TY PRICE
(FEC)
PRINTING & PACKAGING MATERIAL
1-1 1B631 * INSTRUCTION BOOK 1
1-2 1C6014 SET PACKING CASE 1
1-3 1C6253 CARTON BOX 1
1-4 21A5062 MEASURING CUP 1
1-5 1C6052 BOTTOM PAD 2
1-6 1C6092 UPPER PAD 2
MECHANICAL PARTS
2-1 1C1032BASY UPPER LID ASS’Y Sky Blue 1
1C1032GRASY UPPER LID ASS’Y Green 1
1C1032NASY UPPER LID ASS’Y Navy Blue 1
1C1032RASY UPPER LID ASS’Y Red 1
1C1032GASY UPPER LID ASS’Y Grey 1
2-1-1 1C1032 UPPER LID 1
2-1-2 1H1122BL KNOB Sky Blue 1
1H1122GR KNOB Green 1
1H1122NB KNOB Navy Blue 1
1H1122RE KNOB Red 1
1H1122G KNOB Grey 1
2-1-3 1B1531 LID KNOB BUSH 1
2-1-4 1A1043 KNOB SCREW 1
2-2 1C1052 INNER POT 1
2-3 1C4012FL OUTER POT FL 1
1C4012JM OUTER POT JM 1
1C4012PC OUTER POT PC 1
1C4012PP OUTER POT PP 1
1C4012RB OUTER POT RB 1
2-4 1H4024BL HANDLE Sky Blue 2
1H4024GR HANDLE Green 2
1H4024NB HANDLE Navy Blue 2
1H4024RE HANDLE Red 2
1H4024G HANDLE Grey 2
2-5 1H4035BASY PANEL ASS’Y Sky Blue 1
1H4035GRASY PANEL ASS’Y Green 1
1H4035NASY PANEL ASS’Y Navy Blue 1
1H4035RASY PANEL ASS’Y Red 1
1H4035GASY PANEL ASS’Y Grey 1
2-6 1A3042 INSULATOR COVER 1
2-7 1B203 THERMOSTAT SPRING 1
2-8 1A2051 * THERMO PLATE 1
2-9 1C3913SET SWITCH SET 1
2-10 1C308BASY BOTTOM LID ASS’Y Sky Blue 1
1C308GRASY BOTTOM LID ASS’Y Green 1
1C308NASY BOTTOM LID ASS’Y Navy Blue 1
1C308RASY BOTTOM LID ASS’Y Red 1
1C308GASY BOTTOM LID ASS’Y Grey 1
2-11 1A492UASY PLUG INSULAOR ASS’Y 1
20
KSH-228
