Sharp KA-70T50BHH-EU User manual

EN User Manual
DK Handleiding
Home Appliances
CZ HNávod k Obsluze
EE Kasutusjuhend
FI Käyttöohje
GR Οδηγίες Χρήσης
KA-70T50BHH-EU
Cooking
NL Handleiding

EN - 2
GB-Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions and
Regulations and the requirements listed in the
standards referenced.
DE-Konformitätserklärung
Wir erklären, dass unsere Produkte die
geltenden europäischen Richtlinien,
Entscheidungen und Regularien sowie die
in den referenzierten Standards gelisteten
Anforderungen erfüllen.
FR-Déclaration de conformité
Nous déclarons que nos produits sont
conformes aux Directives, Décisions et
Règlementations européennes en vigueur et
aux exigences visées dans les normes citées
en référence.
ES-Declaración de conformidad
Declaramos que nuestros productos cumplen
con las Directivas Europeas, Decisiones
y Regulaciones aplicables y los requisitos
enumerados en dichas normativas.
PT-Declaração de conformidade
Declaramos que os nossos produtos
cumprem as Diretivas Europeias, Decisões
e Regulamentos aplicáveis e os requisitos
enumerados nas referências normalizadas.
NL-Conformiteitsverklaring
We verklaren dat onze producten voldoen aan
de van toepassing zijnde Europese richtlijnen,
besluiten en voorschriften in de normen
waarnaar wordt verwezen.
IT-Dichiarazione di conformità
Dichiariamo che i nostri prodotti sono conformi
a Direttive, Decisioni e Regolamenti europei e ai
requisiti elencati negli standard di riferimento.
GR-Δήλωση συμμόρφωσης
Δηλώνουμε ότι τα προϊόντα μας πληρούν τις
εφαρμόσιμες Ευρωπαϊκές Οδηγίες, Αποφάσεις
και Κανονισμούς, καθώς και τις απαιτήσεις που
περιέχονται στα πρότυπα όπου γίνεται αναφορά.
BG-Декларация за съответствие
Ние заявяваме, че нашите продукти отговарят
на приложимите европейски директиви,
решения и регламенти и на изискванията,
посочени в гореописаните стандарти.
CZ-Prohlášení o shodě
Prohlašujeme, že naše výrobky splňují příslušné
evropské směrnice, rozhodnutí, předpisy a
požadavky uvedené ve zmiňovaných normách.
SK-Vyhlásenie o zhode
Vyhlasujeme, že naše produkty spĺňajú príslušné
smernice, rozhodnutia, nariadenia a požiadavky
vypísané v uvedených štandardoch.
EE-Vastavusdeklaratsioon
Deklareerime, et meie tooted vastavad
kohaldatavatele Euroopa direktiividele, otsustele
ja määrustele ning viidatud standardites
sätestatud nõuetele.
SV-Försäkran om överensstämmelse
Vi försäkrar att våra produkter uppfyller gällande
EU-direktiv, beslut och förordningar och de krav
som anges i de standarder som refereras.
FI-Yhteensopivuuslauseke
Tuotteemme ovat yhteensopivia EU:n
tuotedirektiivien, päätösten ja säädösten kanssa,
sekä niissä listattujen standardien kanssa.

EN - 3
HR-Izjava o sukladnosti
Izjavljujemo da su naši proizvodu u skladu s
primjenjivim Direktivama, Odlukama i Uredbama
Europske unije te zahtjevima navedenima u
spomenutim standardima.
SR-Izjava o usklađenosti
Izjavljujemo da naši proizvodi zadovoljavaju
primenljive evropske direktive, odluke i
propise, kao i zahteve navedene u naznačenim
standardima.
DA-Overensstemmelseserklæring
Vi erklærer, at vores produkter opfylder de
gældende europæiske direktiver, beslutninger
og forordninger, og de anførte standarder der
henvises til.
NO-Samsvarserklæring
Vi erklærer at våre produkter oppfyller de
gjeldende europeiske direktiver, beslutninger
og forskrifter, og kravene i standardene som det
henvises til.
UK-Декларація відповідності
Цим ми заявляємо, що наші продукти
відповідають усім застосовним директивам,
рішенням та нормам Європейського союзу.
Вимоги зазначено в додаткових матеріалах
щодо стандартів.
MK-Декларација за усогласеност
Изјавуваме дека нашите производи ги
исполнуваат применливите европски
директиви, решенија и одредби, како и
побарувањата наведени во посочените
стандарди.
RO-Declarație de conformitate
Noi declarăm că produsele noastre respectă
Directivele Europene, Deciziile și Reglementările
aplicabile și condițiile enumerate în standardele
menționate.
HU-Megfelelőségi nyilatkozat
Ezúton igazoljuk, hogy termékeink megfelelnek
az EU direktíváknak, jogszabályoknak,
előírásoknak. Az előírások felsorolása a
referencia tartalmaknál.
SL-Izjava o skladnosti
Zagotavljamo, da so naši izdelki skladni z
ustreznimi evropskimi direktivami, sklepi in
predpisi ter zahtevami, ki so navedene v
referenčnih standardih.
AL-Deklarata e konformitetit
Ne deklarojmë se produktet tona përmbushin
Direktivat e aplikueshme evropiane, Vendimet
dhe Rregulloret si dhe kërkesat e renditura në
standardet e referuara.
LT-Atitikties deklaracija
Tvirtiname, kad mūsų produktai atitinka
susijusiose Europos direktyvose, sprendimuose
ir reglamentuose pateikiamų standartų keliamus
reikalavimus.
LV-Atbilstības deklarācija
Mēs apliecinām, ka mūsu produkti atbilst
attiecīgajām Eiropas direktīvām, lēmumiem un
noteikumiem, kā arī prasībām, kas norādītas
pieminētajos standartos.
PL-Deklaracja zgodności
Oświadczamy, że nasze produkty spełniają
wymagania odpowiednich dyrektyw, decyzji
i regulacji Unii Europejskiej oraz wymagania
określone w wymienionych standardach.

EN - 4
Contents
Presentation and size of product
Warnings
Preparation for installation and use
Using the oven
Cleaning and maintenance of your product
Service and Transport

EN - 5
Control panel
Tray
Lower Heating
Element (behind the
plate)
Handle
Oven Door
Upper Heating Element (behind the plate)
Wire
Grill
Racks
Oven Light
Air Outlet Shutters
PRESENTATION AND SIZE OF PRODUCT

EN - 6
SAFETY WARNINGS
READ THESE INSTRUCTIONS CARE-
FULLY AND COMPLETELY BEFORE
USING YOUR APPLIANCE, AND KEEP
IT IN A CONVENIENT PLACE FOR RE-
FERENCE WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR
MORE THAN ONE MODEL IN COM-
MON. YOUR APPLIANCE MAY NOT
HAVE SOME OF THE FEATURES
THAT ARE EXPLAINED IN THIS MA-
NUAL. PAY ATTENTION TO THE EXP-
RESSIONS THAT HAVE FIGURES,
WHILE YOU ARE READING THE OPE-
RATING MANUAL.
General Safety Warnings
•This appliance can
be used by children
aged from 8 years
and above and per-
sons with reduced
physical, sensory or
mental capabilities
or lack of experience
and knowledge if they
have been given su-
pervision or instruc-
tion concerning use
of the appliance in
a safe way and un-
derstand the hazards
involved. Children
shall not play with the
appliance. Cleaning
and user maintenan-
ce shall not be made
by children without
supervision.
•WARNING: The app-
liance and its acces-
sible parts become
hot during use. Care
should be taken to
avoid touching hea-
ting elements. Child-
ren less than 8 years
of age shall be kept
away unless continu-
ously supervised.
•WARNING: Danger
of re: do not store
items on the cooking
surfaces.
•WARNING: If the
surface is cracked,
switch off the applian-
ce to avoid the possi-
bility of electric shock.
•The appliance is not
intended to be ope-
rated by means of an
external timer or se-

EN - 7
parate remote-control
system.
•During use, the app-
liance becomes hot.
Care should be taken
to avoid touching he-
ating elements inside
the oven.
•During use, handles
held for short periods
in normal use can get
hot.
•Do not use harsh
abrasive cleaners or
sharp metal scrapers
to clean the oven
door glass and other
surface since they
can scratch the surfa-
ce, which may result
in shattering of the
glass or damage to
the surface.
•Do not use steam cle-
aners for cleaning the
appliance.
•WARNING: Ensure
that the appliance is
switched off before
replacing the lamp to
avoid the possibility
of electric shock.
•CAUTION: Accessib-
le parts may be hot
when the cooking or
grilling is in use. Yo-
ung children should
be kept away.
•Your appliance is produced in ac-
cordance with all applicable local
and international standards and
regulations.
•Maintenance and repair work
must be made only by authorized
service technicians. Installation
and repair work that is carried out
by unauthorized technicians may
endanger you. It is dangerous to
alter or modify the specications
of the appliance in any way.
•Prior to installation, ensure that
the local distribution conditions
(nature of the gas and gas pressu-
re or electricity voltage and frequ-
ency) and the requirements of the
appliance are compatible. The re-
quirements for this appliance are
stated on the label.
•CAUTION: This appliance is de-
signed only for cooking food and is
intended for indoor domestic hou-
sehold use only and should not be
used for any other purpose or in
any other application, such as for
non-domestic use or in a commer-
cial environment or room heating.
•Do not try to lift or move the app-

EN - 8
liance by pulling the door handle.
•All possible security measures
have been taken to ensure your
safety. Since the glass may break,
you should be careful while clea-
ning to avoid scratching. Avoid hit-
ting or knocking on the glass with
accessories.
•Ensure that the supply cord is not
wedged during the installation.
If the supply cord is damaged, it
must be replaced by the manufac-
turer, its service agent or similarly
qualied persons in order to pre-
vent a hazard.
•While the oven door is open, do
not let children climb on the door
or sit on it.
Installation Warnings
•Do not operate the appliance be-
fore it is fully installed.
•The appliance must be installed
by an authorized technician and
put into use. The producer is not
responsible for any damage that
might be caused by defective pla-
cement and installation by unaut-
horized people.
•When you unpack the appliance,
make sure that it is not damaged
during transportation. In case of
any defect; do not use the appli-
ance and contact a qualied servi-
ce agent immediately. As the ma-
terials used for packaging (nylon,
staplers, styrofoam...etc) may
cause harmful effects to children,
they should be collected and re-
moved immediately.
•Protect your appliance against
atmospheric effects. Do not expo-
se it to effects such as sun, rain,
snow etc.
•The surrounding materials of the
appliance (cabinet) must be able
to withstand a temperature of min
100°C.
During usage
• When you rst run your oven a
certain smell will emanate from
the insulation materials and the
heater elements. For this rea-
son, before using your oven, run
it empty at maximum temperature
for 45 minutes. At the same time
you need to properly ventilate the
environment in which the product
is installed.
•During usage, the outer and inner
surfaces of the oven get hot. While
opening the oven door, step back
to avoid the hot steam coming out
of the oven. There may be a risk
of burns.
• Do not put ammable or combus-
tible materials, in or near the app-
liance when it is operating.
•Always use oven gloves to remo-
ve and replace food in the oven.
•Do not leave the cooker while co-
oking with solid or liquid oils. They
may catch re on condition of ext-
reme heating. Never pour water
on to ames that are caused by
oil. Cover the saucepan or frypan
with its cover in order to choke the
ame that has occured in this case
and turn the cooker off.
•If you will not use the appliance for
a long time, plug it off. Keep the

EN - 9
main control switch off. Also when
you do not use the appliance,
keep the gas valve off.
•Make sure the appliance control
knobs are always in the “0” (stop)
position when it is not used.
•The trays incline when pulled out.
Be careful not to let hot liquid spill
over.
•When the door or drawer of the
oven is open, do not leave any-
thing on it. You may unbalance
your appliance or break the cover.
• Do not put heavy things or am-
mable or ignitable goods (nylon,
plastic bag, paper, cloth...etc) into
the drawer. This includes cookwa-
re with plastic accessories (e.g.
handles).
•Do not hang towels, dishcloths or
clothes from the appliance or its
handles.
•During cleaning and maintenance
•Always turn the appliance off befo-
re operations such as cleaning or
maintenance. You can do it after
plugging the appliance off or tur-
ning the main switches off.
•Do not remove the control knobs
to clean the control panel.
•
• TO MAINTAIN THE EFFICIENCY
AND SAFETY OF YOUR APPLI-
ANCE, WE RECOMMEND YOU
ALWAYS USE ORIGINAL SPA-
RE PARTS AND TO CALL ONLY
OUR AUTHORIZED SERVICE
AGENTS IN CASE OF NEED.
PREPARATION FOR
INSTALLATION AND USE
Manufactured with best quality parts
and materials, this modern, functional
and practical oven will meet your ne-
eds in all respects. Make sure to read
the manual to obtain successful results
and not to experience any problems in
the future. The information given below
contain rules that are necessary for cor-
rect positioning and service operations.
They should be read without fail espe-
cially by the technician who will position
the appliance.
CONTACT THE AUTHORIZED SER-
VICE FOR INSTALLATION OF YOUR
OVEN!
CHOOSING A PLACE FOR THE
OVEN
–There are several points to pay atten-
tion to when choosing a place for your
oven. Make sure to take into account
our recommendations below in order
to prevent any problems and dange-
rous situations, which might occur
later!
–When choosing a place for the oven,
attention should be paid that there are
no ammable or combustible materi-
als in the close vicinity, such as curta-
ins, oil, cloth etc. which quickly catch
re.
–Furnitures surrounding the oven must
be made of materials resistant to heat
more than 50 C° of the room tempe-
rature.

EN - 10
Required changes to wall cabinets and
exhaust fans above the built-in combi-
ned product as well as minimum he-
ights from the oven board are shown in
Figure 1. Accordingly, the exhaust fan
should be at a minimum height of 65 cm
from the hob board. If there is no ex-
haust fan the height should not be less
than 70 cm.
HOB
Minimum
42 cm
Minimum
42 cm
Minimum 65cm
(with hood)
Minimum 70cm
(without hood)
INSTALLATION OF BUILT-IN
OVEN
2 x
Insert the oven into the cabinet by pus-
hing it forward. Open the oven door and
insert 2 screws in the holes located on
the oven frame. While the product fra-
me touches the wooden surface of ca-
binet, tighten the screws.
Worktop
min.
25 mm
min.
50 mm Built-in hob
Built-in oven

If the oven is installed under a hob, the
distance between the worktop and the
top panel of the oven must be minimum
50 mm and the distance between the
worktop and the top of control panel
must be minimum 25 mm.
WIRING AND SAFETY OF
BUILT_IN OVEN
The instructions given below must be
followed without fail during wiring :
–The earthing cable must be connec-
ted via the screw with the earthing
mark. Supply cable connection must
be as shown in Figure 6. If there is
no earthed outlet conforming to regu-
lations in the installation environment,
call the Authorized Service immedia-
tely.
–The earthed outlet must be in close
vicinity of the appliance. Never use an
extension cord.
–The supply cable should not contact
the product’s hot surface.
–In case of any damage to the supply
cable, make sure to call the Authori-
zed Service. The cable must be repla-
ced by the Authorized Service.
–Wiring of the appliance must be per-
formed by the Authorized Service.
H05VV-F type supply cable must be
used.
–Faulty wiring may damage the appli-
ance. Such a damage will not be co-
vered under the warranty.
–The appliance is designed to connect
to 220-240V~ electricty is different
than the value given above, call the
Authorized Service immediately.
–The Manucaturer Firm declares
that its bears no responsibility
whatsover for any kind of da-
mage and loss arising from not
complying with safety norms!
–Wiring of the appliance must be per-
formed by the Authorized Service.
The appliance is
–designed to connect to 220-240V~
electricity. If the mains electricity is
different than the value given, call the
Authorized Service immediately. The
appliance is designed for using with
plug ofor xed connection to the ma-
ins. It is necessary that you install a
double pole switch between the pro-
duct and the electricity supply (ma-
ins), with a minimum gap of 3 mm bet-
ween the switch contacts. (20A rated,
delay function type).
EN - 11

EN - 12
3.4. GENERAL WARNING AND
PRECAUTIONS
Your appliance is produced in confor-
mity with the relevant safety instruc-
tions relating to electrical appliances.
Maintanance and repair works must be
performed only by Authorized Service
technicians trained by the manufacturer
rm. Installation and repair works, per-
formed without observing the rules may
be dangerous.
The outer surfaces is heated while your
appliance is operating. The elements
heating the inner surface of the oven
and the steam out are extremely hot.
These sections will continue to preser-
ve their heat for certain while even if the
appliance is switched off. Never touch
the hot surfaces. Keep children away.
In order to cook in your oven, the oven
function and temperature setting butt-
tons need to be adjusted and the oven
timer, needs to be programmed. Other-
wise, the oven will not operate.
While the oven door is open, do not pla-
ce anything on it. You may disturb the
balance of the appliance or break the
door.
Unplug your appliance when it is
not in use.
Protect your appliance from
atmosp-heric effects. Do not leave
it under the effects of the sun,rain,
snow, dust etc.

EN - 13
Static Cooking Function:
The oven’s thermostat and warning
lights will be turned on, the lower and
upper heating elements will start ope-
rating. The static cooking function emits
heat, ensuring even cooking of the lo-
wer and upper food. This is ideal for
making pastries, cakes, baked pasta,
lasagne and pizza. Prehating the oven
for 10 minutes is recommended and it is
best to cook on only one shelf at a time
in this function.
Fan Function:
The oven’s thermostat and warning
lights will be turned on, the upper and
lower heating elements and fan will start
operating.
This function is very good for obtaining
results in baking pastry. Cooking is carried
out by the lower and upper heating element
within the oven and by the fan providing
air circulation, which will give a slight grill
effect to the food. It is recommended to
pre-heat the oven about 10 minutes.
Using the oven function control
button
Oven Functions
*The functions of your oven may be
dif-ferent due to the model of your
product.
Oven Lamp:
Only the oven light will be turned on and
it remains on in all the cooking function.
Defrost Function:
The oven’s warning lights will be turned
on, the fan starts operating.
To use the defrost function, take your
frozen food and place it in the oven
on a shelf placed in the third slot from
the bottom. It is recommended that
you can place an oven tray under
the defrosting food, to catch the wa-
ter accumulated due to melting ice.
This function will not cook or bake
your food, it will only help to defrost it.
Turbo Function
The oven's thermostat and warning
lights will be turned on, the ring heating
element and fan will start operating.
The turbo function evenly disperse
the heat in the oven. All foods on
all racks will be cooked evenly. It is
recommended to pre-heat the oven
about 10 minutes.

EN - 14
Grill and chicken Turning
Function
This function is used to grill and to turn
chicken, cooked food on a skewer.
To make turning, use the “turning skewer”.
To grill, place the food onto the grill, also
the grill onto the shelf at toppest level. You
can start to grill after placing the oven tray
onto the 3rd Shelf. The tray that is placed
onto the 3rd Shelf will ensure the collection
of oils that drop from food. Turn your
oven’s heat set up switch as it will show the
sign of this function. Place your food into
the oven after pre heating of 5 minutes.
At the end of cooking, as in all other
cooking processes; turn off the oven’s
switch and heat set up switch. Cancel
the oven’s time program and take the
cooked food from oven and leave onto a
safe place. Do not come close to the oven
until it will cool and keep children away.
Upper heater, Grill and Roast
Chicken Function
This function is used to grill rapidly and to
roast chicken, cooked food on a skewer.
To make roasting, use the “roasting
skewer”. To grill, place the food onto the
grill, also the grill onto the shelf at toppest
level. You can start to grill after placing the
oven tray onto the 3rd Shelf. The tray that
is placed onto the 3rd Shelf will ensure
collection of oils that drop from food.
Turn your oven’s heat set up switch
as it will show the sign of this
function. Place your food into the
oven after pre heating of 5 minutes.
At the end of cooking process, as in all
Pizza Function:
The oven’s thermostat and warning
lights will be turned on, the ring and
lower heating elements and fan will start
operating.
Fan and lower heating function is ideal for
baking food, such as pizza, equally in a
short time. While the fan evenly disperses
the heat of the oven, the lower heating
element ensures the baking of food dough.
.
other cooking processes; turn off the
oven’s switch and heat set up switch.
Cancel the oven’s time program and take
the cooked food from oven and leave onto
a safe place. Do not come close to the
oven until it cools and keep children away.

EN - 15
Grill, Chicken Roasting and
Fan Function
In this function, grill and upper
heater and the fan that ensures to
roast perfectly, operate together and
cook. It is also used to grill, to roast
chicken and cooked food on a skewer.
To make roasting; use the “roasting
skewer”. To grill, place the food onto the grill,
also the grill onto the shelf at the toppest
level. You can start to grill after placing the
oven tray onto the 3rd Shelf. The tray that
is placed onto the 3rd Shelf will ensure
collection of oils that drop from food.
Turn your oven’s heat set up switch
as it will show the sign of this
function. Place your food into the
oven after pre heating of 5 minutes.
At the end of cooking process, as in all
other cooking processes; turn off the
oven’s switch and heat set up switch.
Cancel the oven’s time program and take
the cooked food from oven and leave onto
a safe place. Do not come close to the
oven until it cools and keep children away.
ENERGY SAVING
Minimize the amount of liquid or
fat to reduce cooking times.
Oven door should not be opened
often during cooking period
Set your oven function to static function
at 90 °C to operate VapClean function.
Spill 200-250ml of water
to the tray which is stated on the oven
base. Start
the oven and Vapclean will take
approximately 20 minutes to prepare
your oven for cleaning easily.

EN - 16
Use of rotisserie accessories
Pass the skewer through the chicken
and lock the clamps, insert the tip of the
skewer into the hole found at the rear
panel of cavity and make sure that it
completely leans on the frame and ts in
motor shaft. To do this, rst you have
to turn the lid to the side,which is found
in front of the skewer insertion hole, as
shown in the gure. After that, t the
skewer t the skewer onto the skewer
grid which you will place on the third rack.
Remove the handle from skewer, if it is
installed and close the oven door.
The handle must be atteched only
for removing the food after grilling.
skewer insertion hole lid
skewer insertion hole
skewer handle
skewer tip
skewer
tray on rst rack
skewer grid on third rack
Make sure that the oven is not operating while
performing these operations.
Rotisserie

EN - 17
4.1 Monochrome Control Unit
Monochrome control unit consist of
a 4.3” monochrome LCD screen and
6 different touch buttons. Function
of the touch buttons of monochrome
control unit’s are described at below.
Monochrome control unit is designed
on principles such as making amateur
users to be able to implement
professional recipes easily with auto
cooking functions, also allowing
housewives to implement their own
inspired recipes with combined
manual cooking functions.
Monochrome control unit’s menus
such as manual cooking, auto cooking
and settings are described as below.
Manual Cooking:
Every cooking setting can be set by
user in the manual cooking. 7 different
cooking functions, temperature,
boost function, cooking duration and
cooking end time can be selected.
With the exiability of manual cooking
any cooking can be performed by
users with respect their own taste.
To perform cooking in the manual
cooking menu, below listed steps
should be followed.
•Use UP & DOWN buttons to naviga-
te in main menu.
•Tap OK button to when “Manual Co-
oking” is selected.
In the manual cooking menu, cooking
functions, temperature, boost function,
cooking duration and cooking end
time can be set by end user. To
change any specication, navigate
with UP & DOWN buttons and select
the specication with OK button. After
tapping, selected specication blinks.
While blinking, UP & DOWN buttons
are used to change the value of the
specication. You can nalize the
selection by tapping OK button.
NOTE: If cooking duration is set as
00:00, cooking continues until user
stops manualy.
To start cooking tap the START/
PAUSE button and cooking screen will
appear as below.
On the cooking screen;
•START/PAUSE button can be used
to pause or restart the cooking,

EN - 18
•Temperature can be changed by tap-
ping UP & DOWN buttons,
•While any cooking function is activa-
ted, BACK button is tapped to navi-
gate between oven function, tempe-
rature and cooking time. When any
specication is blinking, value of it can
be changed bytapping UP & DOWN
buttons.
•To stop cooking and go back to main
menu, tap START/PAUSE button,
then tap to BACK button.
Auto Cooking:
Pre determined recepies which are
prepared by professional cooks are
can be used by end user with auto
cooking menu. In auto cooking menu,
only name of the meal is selected
by user, every cooking settings like
cooking function, duration, temperature
is set by monochrome control unit
automaticaly.
To perform cooking with auto cooking
menu, below mentioned steps should
be followed.
•Use UP & DOWN buttons to navigate
in main menu.
•Tap OK button to when “Auto Coo-
king” is selected.
In the auto cooking menu, category,
name and weigth of the recipe is
selected by end user. Also cooking
end time can be changed by end
user. To change any specication,
navigate with UP & DOWN buttons
and select the specication with OK
button. After tapping, selected
specication blinks. While blinking,
UP & DOWN buttons are used to
change the value of the specication.
You can nalize the selection by
tapping OK button.
NOTE: To achive best cooking
performance, tray should placed to
displayed shelf.
To start cooking tap the START/
PAUSE button and cooking screen
will appear as below.
On the cooking screen;
•START/PAUSE button can be used
to pause or restart the cooking,
•To stop cooking and go back to main
menu, tap START/PAUSE button,
then tap to BACK button.

EN - 19
Settings:
On the settings menu, time, screen
brigthness, buzzer tone and language
options can be set. Also software
version is displayed as information.
To change any specication, navigate
with UP & DOWN buttons and select
the specication with OK button. After
tapping, selected specication blinks.
While blinking, UP & DOWN buttons
are used to change the value of the
specication. You can nalize the
selection by tapping OK button.

EN - 20
DISHES
TURBO LOWER-UPPER LOWER-UPPER FAN GRILL
Thermostat
pos. (°C)
Rack
pos.
Cooking
period
(min)
Thermostat
pos. (°C)
Rack
pos.
Cooking
period
(min)
Thermostat
pos. (°C)
Rack
pos.
Cooking
period
(min)
Thermostat
pos. (min)
Rack
pos.
Cooking
period
(min)
Layered pastry 170-190 2-3-4 35-45 170-190 2-3-4 35-45 170-190 2-3-4 25-35
Cake 150-170 2-3-4 30-40 170 -190 2-3-4 30-40 150-170 2-3-4 25-35
Cookie 150-170 2-3-4 25-35 170-190 2-3-4 30-40 150-170 2-3-4 25-35
Grilled meatballs 200 710-15
Watery food 175-200 2 40-50 175-200 2 40-50 175-200 2 40-50
Chicken 200 2-3-4 45-60 200 2-3-4 45-60 200 * 50-60
Chop 200 6-7 15-25
Beefstake 200 6-7 15-25 Two-tray cake 160-180 1-4 30-40
Two-tray pastry 170-190 1-4 35-45
* Cook with roast chicken skewer...
