Specifications for PC-TN10W
Parts Specifications
CPU Intel® Pentium®M 1.1GHz
Primary cache Instruction cache 32KB, write-back data cache 32KB (Integrated
in CPU)
Secondary cache 1MB (Integrated in CPU)
Chipset Intel® 855GM
RAM System DDR SDRAM 256MB, expandable up to 768MB
Video Max. 64MB (shared with system memory)
Panel Active Matrix (TFT) color LCD 12.1”(30.7cm)
Video controller Integrated in chipset
Display
Resolution/color 1024 x 768 dots/16M colors by dithering function
Keyboard IBM compatible keyboard
Pointing device Glide pad (touch-sensitive control pad with 2 buttons)
Tablet pen (electromagnetic pen with digitizer technology)
Drive Hard disk Approx. 30GB*1, IDE interface
Floppy disk
(option/external)
USB interface 3.5", 1.44MB/720KB
Optical (external) USB interface
PC card slot Type II ×1 (PC Card Standard compliant) CardBus compliant
CF card slot Type II ×1
Audio system monaural speaker, sound system compliant with AC’97 audio
I/O ports Audio Audio output jack (stereo), external microphone jack (monaural)
Others 2 USB ports (USB2.0 compliant), IEEE1394 connector,
external monitor port
Modem Data: 56Kbps (receive), 33.6Kbps (send), Fax: 14.4Kbps
LAN 100 BASE-TX/10 BASE-T LAN
Radio Technology DSSS(IEEE802.11b) compliantWireless LAN
Operating Channels 11 channels
Windows Security ButtonShortcut Button
4 Programmable Buttons
Operating system*2Microsoft® Windows® XP Tablet PC Edition
Power AC adapter 100-240V, 50-60 Hz
Battery Rechargeable lithium ion battery
Battery life*3 Approx. 5.0 hours
Battery charging time
*Charging time varies
depending on usage
Turned off/hibernation: Approx. 3.2 hours
Turned on: Approx. 4.0 hours
Dimensions
*No protrusion is included.
11.4 "wide x 9.0"(min.)/10.1"(max.) deep x 1.13" high
(290mm x 229.4mm(min.)/256.7mm(max.) x 28.8mm)
Weights Approx. 4.2 lbs (Approx. 1.9 kg)
Temperature 50°F to 95°F (10°C to 35°C)Operating
environment Humidity 20% to 80% (non-condensation)
∗1 1GB means 1 billion bytes. Windows OS system shows 27.9GB for total hard disk capacity.
(C: Approx. 9.7GB, D: Approx. 13.3GB and rest reserved as recovery image.)
∗2 This model (PC-TN10W) does not support other operating systems than the pre-installed one.
∗3 Battery life is based on BAPCo® MobileMark™ 2002. Battery life will vary based on many
factors including screen brightness, applications, features, battery conditioning, power management and
other customer preferences.
TINSE3593ACZZ
