Sharp Actius PC-MC22 User manual

Operation Manual
i
Preface
Notice for All Users
•Consult the operation manual (this document) for proper use of your computer.
•The product and the accessories are subject to change without prior notice.
•SHARP assumes no responsibility for results arising from use of pre-installed and
third party software. Consult the software vendor for resolution of problems.
(Read the service condition of the software before use.)
•SHARP assumes no responsibility for problems caused by incorrect handling,
repairs, defects, battery replacement or any other cause.

Preface
ii
Notice for Users in the USA
FCC Statement
WARNING - FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipments off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the distance between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
A shielded I/F cable is required to insure compliance with FCC regulation for Class
B computing equipment.
* As an ENERGY STAR®Partner, SHARP has determined that this product meets
the ENERGY STAR®guidelines for energy efficiency.
Declaration of Conformity
SHARP PERSONAL COMPUTER, PC-M4000 Series
This device complies with part 15 of the FCC rules. Operation is subject to the following
conditions:(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Responsible Party: SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP
This device complies with the FCC RF exposure requirements.

Operation Manual
iii
About the Modem
This equipment complies with Part 68 of the FCC rules and the requirements adopted
by the ACTA. On the bottom of this equipment is a label that contains, among other
information, a product identifier in the format US:AAAEQ##TXXXX. If requested,
this number must be provided to the telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements
adopted by the ACTA. See installation instructions for details.
The type of Connector is USOC RJ11C
The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact the local telephone
company. For products approved after July 23, 2001, the REN for this product is part
of the product identifier that has the format US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3).
For earlier products, the REN is separately shown on the label.
If this equipment causes harm to the telephone network, the telephone company will
notify you in advance that temporary discontinuance of service may be required. But
if advance notice isn't practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a complaint with the
FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the
telephone company will provide advance notice in order for you to make necessary
modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, for repair or warranty information,
please refer to the provided Consumer Limited Warranty sheet. If the equipment is
causing harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.

Preface
iv
Connection to party line service is subject to state tariffs. Contact the state public
utility commission, public service commission or corporation commission for
information.
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person
to use a computer or other electronic device, including FAX machines, to send any
message unless such message clearly contains in a margin at the top or bottom of
each transmitted page or on the first page of the transmission, the date and time it is
sent and an identification of the business or other entity, or other individual sending
the message and the telephone number of the sending machine or such business,
other entity, or individual. (The telephone number provided may not be a 900
number or any other number for which charges exceed local or long-distance
transmission charges.)
To program this information, refer to the manual of the communication software.
Copyright
It is the intent of Sharp that this product be used in full compliance with the
copyright laws of the United States and that prior permission be obtained from
copyright owners whenever necessary.
Product Information and Customer Assistance
For Product Information and Customer Assistance:
Call: 1-800-BE-SHARP (237-4277)
Sharp Systems of America
5901 Bolsa Avenue, Huntington Beach, CA 92647
Home Page: http://www.sharpsystems.com
E-mail address: [e-mail]

Operation Manual
v
Notice for Users in Canada
This class B digital apparatus complies with Canadian ICES-003.
About the Wireless LAN
Operation is subject to the following conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The installer of this radio equipment must ensure that the antenna is located or
pointed such that it does not emit RF field in excess of Health Canada limits for the
general population; consult Safety Code 6, obtainable from Health Canada’s website
www.hc-sc.gc.ca/rbp.
About the Modem
This product meets the applicable Industry Canada technical specifications. The
Ringer Equivalence Number is an indication of the maximum number of devices
allowed to be connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that the sum of
the RENs of all the devices does not exceed five (REN:0.2).
This product contains IC: 4005B-ATHENS

Preface
vi
CAUTION:
TO PREVENT ELECTRICAL SHOCK, DISCONNECT THE AC CORD AND
REMOVE THE BATTERY BEFORE SERVICING.
CAUTION:
FOR A COMPLETE ELECTRICAL DISCONNECTION, PULL OUT THE MAINS
PLUG AND THE BATTERY.
VORSICHT:
UM DIE STROMZUFUHR VOLLSTÄNDIG ZU UNTERBRECHEN, DEN
NETZSTECKER HERAUSZIEHEN UND DIE BATTERIE ÈNTFERNEN.
ATTENTION:
POUR UN ARRET TOTAL DU SYSTEME, DECONNECTEZ LA PRISE DE
COURANT SECTEUR ET LA BATTERIE.
VARNING:
FÖR TOTAL ELEKTRISK URKOPPLING, KOPPLA UR KONTAKTEN OCH TA
UR BATTERIET.
PRECAUCION:
PARA UNA COMPLETA DESCONEXION ELECTRICA DESENCHUFE LA
CLAVIJA DE LA RED Y LA BATERIA.

Operation Manual
vii
Safety Precautions
General
•Follow all cautions and instructions marked on your computer.
•Except as described elsewhere in this manual, refer all servicing to qualified
personnel. Immediately shut off your computer and seek servicing under the
following conditions.
•The power cord or plug is damaged or frayed.
•Liquid is spilled on your computer.
•Your computer has been dropped or the cabinet has been damaged.
Location
•Do not expose your computer to direct sunlight.
•Try to avoid dusty environments.
•Keep your computer away from any magnetic devices and TVs.
•Keep your computer away from heat sources such as radiator, heaters, stove, and
other heat-generating products.
•Keep your computer away from excessive humidity or fluids such as rain, snow,
water spray, juice, coffee, steam, etc.
•Keep your computer away from extremely high or low temperature.
•Do not move your computer from an extremely cold place to an extremely warm
place. A temperature difference of more than 18°F (10°C) will cause condensation
inside the unit, which may cause damage. (In this case, turn off your computer and
leave it for about an hour to completely dry the unit.)
•Do not block or cover the slots or openings on the cabinet. They protect your
computer from overheating.
•Do not place your computer on an unstable or uneven work surface.
•Care should be exercised when using on heat sensitive surfaces or your lap as the
base of your computer will get hot.
•Do not use your computer on your lap or any part of your body for an extended
period of time during operation or while charging to avoid injury from heat
exposure. The bottom of the computer may become hot and it could cause a low
temperature burn.

Preface
viii
Usage
•Never push any objects into the cabinet openings. They may touch the dangerous
voltage points or short parts that could result in fire or electrical shock.
•Do not press or place heavy objects on your computer. Strong pressure can
damage the cabinet or make your computer fail.
•If your computer or the AC power cord experiences an abnormal situation such as
heat generation or smoking, or produces an abnormal odor, turn off your computer,
unplug the AC power cord, and remove the battery pack immediately.
•Turn off your computer before installing or removing any peripheral devices except
USB devices, a PC card, or an SD card.
•Never subject your computer to sudden shocks or extreme vibration.
•Do not drop your computer or hit it with other equipment.
•Do not scratch the surface of the LCD screen.
•Before cleaning your computer, turn it off and disconnect the AC power cord.
•When carrying your computer:
•Turn off your computer.
•Do not subject your computer to shocks.
•Remove external media such as a PC card from the slot.
•Disconnect the external peripherals, cables and cords if connected.
•Do not hold your computer by the display unit.
Otherwise, your computer may be damaged or the stored data might be lost.
•When carrying your computer, hold it carefully not to drop it onto your feet or toes.

Operation Manual
ix
Battery Pack Precautions
CAUTION
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
Handling
•Do not put the battery pack in a fire. It could explode and cause injury.
•Do not attempt to open or alter the battery pack.
•Do not place the battery pack where it might get hotter than 140°F (60°C).
•The battery pack must be kept from metal objects such as keys. They might trigger
a short circuit and consequently cause the battery pack to heat up and explode.
•Do not allow liquids to come in contact with the battery pack.
•Care must be taken not to drop the battery pack. A violent shock damages the pack.
•Do not solder anything to the battery terminals.
Charging
•Charge the battery pack only with the AC adapter and AC power cord included
with your computer.
Discharging
•Use the battery pack only for powering your computer. Do not use it for any other
purpose.
Storage
•Store the battery pack in a cool and dry place. Do not store it in a place having
temperatures of above 140°F (60°C).
•Recharge the stored battery pack before using it.

Preface
x
AC Power Precautions
•Plug the AC power cord directly in a wall jack. Plugging too many leads into a
single socket may result in fire.
•Never plug in or remove the AC power cord or AC adapter with wet hands for
prevention of electric shock.
•The included AC power cord must be appropriate for the voltage used in your area.
Using an inappropriate cord can cause a fire.
•Unplug the AC power cord when your computer is not used for a long period.
•Never disassemble, repair, or modify the AC adapter.
•Never modify, twist, forcibly bend or pull, or place heavy objects on top of the AC
cord to avoid damaging it. Using a damaged cord can cause a fire or electric shock.
•The AC power cord must be appropriate for the voltage used in your area. Using an
inappropriate cord can cause a fire.
•Never plug in the AC adapter and AC power cord with dust on the plugs. This
could cause damage to the insulation that may result in fire, electric shock, and/or
injury.
•When unplugging the AC adapter from a wall outlet, hold it by the plug. Do not
pull it out by the cord. Damage to the cord may result in the fire and/or electric
shock.
•Check the AC power cord and power connectors periodically for damage. If
damage is found, change the power cord immediately.
Modem Precautions
IMPORTANT SAFETY INSTRUCTIONS
When you use your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the
following:
•Do not use this product near water (for example, near a bath tub, wash bowl,
kitchen sink or laundry tub), in a wet basement, or near a swimming pool.
•During a lightning or thunder storm,
•Never install a telephone wire.
•Avoid using any telephones other than a cordless type. There may be a remote
risk of electric shock from lightning.
•You should turn off your computer, unplug the AC power cord and remove the
modem cable from your computer.

Operation Manual
xi
•Do not use the telephones to report a gas leak in the vicinity of the leak.
•Never use telephone jacks in wet locations unless they are specifically designed for
wet locations.
•Never touch uninsulated telephone wires or terminals while they are connected to a
network interface.
•Use caution when you install or modify telephone lines.
•Save these instructions.
Wireless LAN Precautions
•Disable the integrated antenna and do not communicate with the wireless LAN in
specific environments where radio-susceptible equipment is nearby, on airplanes,
in hospitals, for example.
•Disable the integrated antenna and do not communicate with the wireless LAN in
crowded places for prevention of cardiac pacemaker interference.
•Keep the distance at least 8.7” (22 cm) between a cardiac pacemaker and an active
wireless LAN antenna.
•This equipment complies with FCC radiation exposure limits set forth for
uncontrolled equipment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This equipment should be installed and
operated with at least 20 cm and more between the radiator and person’s body
(excluding extremities: hands, wrists, feet and legs).
•This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
•Never disassemble or alter the wireless LAN unit.
•Do not remove the certification label on the wireless LAN unit.
Product Conformance
The wireless LAN device pre-installed in your computer is in conformance with
federal requirements. No license is required for use of this device.
Notice of Radio Interference
The wireless LAN device pre-installed in your computer operates in the 2.4GHz
frequency range that is shared by Industrial, Science, Medical (ISM) devices such as
microwave ovens and portable telephones. These devices may interfere with the
operation of the wireless LAN device. It is recommended that these interfering
devices be powered off or no activated interfering devices be nearby to ensure the
proper operation of the wireless LAN device.

Preface
xii
PC Disposal or Transfer
Warning
This product utilizes tin-lead solder, and a fluorescent lamp containing a small amount
of mercury. Disposal of this product may be regulated due to environmental
considerations. For disposal or recycling information, please contact your local
authorities or the Electronics Industries Alliance: www.eiae.org.
Data Erasing
Before you dispose or transfer your computer, you should erase the data from hard
disks.
To remove the data from the hard disk drive of your computer, you will need to:
•“Delete” the data by placing it in the Recycle Bin.
•Empty the Recycle Bin.
•Format the hard disk drives.
•Recover the system.
The above procedures do not completely delete all data from the hard disk drives.
When a file is deleted, the disk location where it was stored is marked as unallocated
space available for new data. It means that the old data is still there and can be
recovered. It allows for malicious persons to recover the “deleted” data and misuse
it. To avoid this, you must thoroughly erase all the data from the hard disks.
For permanent data deletion, it is recommended to:
•Use special software or paid services to thoroughly erase the data, or
•Hammer or strongly magnetize the hard disk to destroy the stored data.
Transferring your computer without deleting software including operating system(s)
or applications on the computer may be in conflict with the software agreement(s).

Operation Manual
xiii
Other Precautions
•Periodic back-up copies of your important data should be made to protect your data
in the event of hard disk failure or loss of the data on the hard disks. Use other
storage devices for the backup.
•Your computer is integrated with a magnet on the left side of the display. Be sure
to keep magnetic sensitive cards and floppy disks away from the left part of your
computer to prevent the data on the cards or floppy disks from being erased.
•Your computer has a sensor on the left side of the keyboard that responds to the
magnet. If the magnet gets close to the sensor:
•The backlight will be turned off.
•The system may enter the standby or hibernation mode according to the setting.
(See Chapter 2.)
For Your Health
•Take regular breaks of ten to fifteen minutes after every hour of continuously
viewing the screen to relieve your eyes.
•Adjust the brightness for comfortable viewing. (Brightness level of about 500 lux is
recommended.)
•Avoid using your computer in an environment where sunlight or indoor lighting
reflects off the screen.
•Position the display slightly below eye level and give a space of 15.8” (40cm)
through 23.7” (60cm) between you and the display.
•Adjust the volume for comfortable sound when using a headphone. Too much
volume may damage your ears.
•Do not power on or off when using a headphone. The produced noise may damage
your ears.
Magnet
Sensor

Preface
xiv
Notice of Computer Security
The Windows operating system on this computer provides the Security Center, which
manages the security features of your computer. It provides the status of the following
security functions and enables you to change their settings: Firewall, Automatic
Updates, and Virus Protection.
By default, the three functions are enabled in the Security Center to ensure the safety
of the computer. If one of them or more are disabled, Windows alerts you by
displaying the message “Your computer might be at risk.” in the notification area
located above the taskbar.
To open the Security Center, click start – Control Panel – Security Center.
Firewall
The firewall function blocks unauthorized connection to this computer through the
Internet or a network.
Automatic Updates
The automatic updates function periodically detects new security programs to be
installed and automatically installs them.
Virus Protection
The Norton AntiVirus software, which automatically checks the virus infection, is
preinstalled in this computer. To protect the computer against new viruses and other
security threats, the virus definition file of the software must be updated. The virus
protection function monitors whether the definition file is latest.
When the Windows setup is finished, be sure to complete the Norton AntiVirus
wizard and LiveUpdate to update the definition file. (You must establish the
connection to the Internet for the update.)
After completing the Norton AntiVirus wizard and LiveUpdate;
* The Windows Security Center always displays as ON regardless of the definition file
status. Since the preinstalled Norton Antivirus software manages virus check on
your computer, be sure to perform the LiveUpdate.
* You can enable the LiveUpdate automatically to run and update the file if any
updates are detected. (Refer to the Virus Protection section on page A-7.)

Operation Manual
xv
Notice of Security with Wireless Devices
Wireless LAN provides data transfer by means of electric waves instead of LAN
cables between communicating devices such as personal computers and a wireless
LAN station. Wireless LAN has an advantage of simple and ubiquitous LAN
connection in the ranges where electric waves are available. Since electric waves can
penetrate through walls and reach everywhere, wireless LAN without proper security
settings includes some security threats and can produce the situations mentioned
below.
•Eavesdropping
Malicious third parties can intercept the transmission and monitor your mail to
steal personal information such as an identification number, password, and credit
card number.
•Intruding
Malicious third parties can connect to a personal or office network without
authorization and illegally perform the following:
•Obtaining access to confidential customer records or sensitive corporate
information (Information leakage)
•Faking the original information (Spoofing)
•Altering the original data and transmitting (Falsification)
•Spreading computer viruses resulting in the destruction of data or systems
(Destruction)
Although wireless LAN cards and wireless LAN stations (Access Points) have
security measures against the threats above, no security settings may have been
configured at the time of your purchase.
All security features must be configured according to reference manuals of the
wireless LAN devices, which results in reducing vulnerability to the attacks
described above.
Use the wireless devices with a clear understanding that wireless LAN includes
vulnerabilities that could allow attackers to simply bypass security features. Security
measures are important for all users to understand for the safe use of wireless LAN.
SHARP encourages all users to configure the security settings with their own
judgment and responsibility.

Preface
xvi
About This Manual
Notice
Information in this manual is subject to change without notice and does not represent a
commitment on the part of SHARP Corporation and its sales subsidiaries.
SHARP Corporation and its sales subsidiaries shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from the
furnishing, performance, or use of this material.
SHARP strongly recommends that separate permanent written records be kept of all important
data. Data may be lost or altered in virtually any electronic memory product under certain
circumstances. Therefore, SHARP assumes no responsibility for data lost or otherwise rendered
unusable whether as a result of improper use, repairs, defects, battery replacement, use after the
specified battery life has expired, or any other causes.
SHARP assumes no responsibility directly or indirectly, for financial losses or claims from third
persons resulting from the use of this product and any of its functions, such as stolen credit card
numbers, the loss of or alteration of stored data, etc.
Copyright
© 2005 SHARP Corporation
This document contains or refers to proprietary information which is protected by copyright. All
rights are reserved. Copying or other reproduction of this document is prohibited without the prior
written permission of SHARP Corporation.
Trademarks
Intel, Pentium, and Celeron are registered trademarks of Intel Corporation.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Windows Media is a registered
trademark or trademark of Microsoft Corporation in the United States and/or other countries.
WinDVD is a registered trademark of InterVideo, Inc.
PowerQuest is a registered trademark and EasyRestore is a trademark of PowerQuest
Corporation.
BAPCo is a U.S. Registered Trademark of the Business Applications Performance
Corporation.
MobileMark is a U.S. Registered Trademark of the Business Applications Performance
Corporation.
All other brand and product names are trademarks or registered trademarks of their respective
holders.

Operation Manual
xvii
Recording Important Information
For future reference, please record the following information in the spaces provided
below.
Model Number:
Serial Number:
Date of purchase:
Dealer’s Name:
Place of purchase:
Password:
The serial number is printed on a sticker located on the bottom of the computer.

Preface
xviii
Manual Conventions
This manual uses a set of style conventions described below.
Notes and Cautions are italicized with icons:
A note icon informs you of a special technique or information that may
help you perform a task or better understand a process.
A caution icon alerts you to something that may cause a problem or
damage to hardware, software or data.
Key Labels on the Keyboard, when referred to in the instructions, are shown in
boldface:
Press Enter to continue.
When two or more keys are separated by a plus (+) sign, press and hold down the first
key (or first two keys), and then, press the last key:
Run Task Manager by pressing Ctrl+Alt+Delete.
Sample Entries are shown in lower cases of different typeface.
c:\windows\system
Words/Texts on Screen, such as window titles or possible parameters, are italicized:
Double-click this icon to display the Power Options Properties dialog box.
Set the item to Enabled.
Screens reproduced in this manual may differ slightly from the screens you see on
your computer.
Section Titles in other parts of this manual are italicized:
Refer to Connecting to AC Power Source section of Chapter 1.

Table of Contents
xix
Table of Contents
Preface
Notice for All Users ....................................................................................................i
Notice for Users in the USA ......................................................................................ii
Notice for Users in Canada ........................................................................................v
Safety Precautions....................................................................................................vii
Notice of Computer Security ..................................................................................xiv
Notice of Security with Wireless Devices................................................................xv
About This Manual .................................................................................................xvi
Recording Important Information ..........................................................................xvii
Manual Conventions .............................................................................................xviii
Table of Contents....................................................................................................xix
Overview of Computer...........................................................................................xxii
Basic Operations
Connecting to AC Power Source ........................................................................... 1-1
Turning Off Your Computer .................................................................................. 1-3
Choosing Power Source ......................................................................................... 1-4
Using the Touchpad ............................................................................................... 1-6
Using the Keyboard ............................................................................................... 1-8
Using the Optical Drive ......................................................................................... 1-9
Using the SD Card Slot........................................................................................ 1-16
Controlling the Volume........................................................................................ 1-18
Adjusting the Display........................................................................................... 1-19
Sharing Your Computer ....................................................................................... 1-21
Battery and Power Management
The Battery Pack.................................................................................................... 2-1
Power Saving ......................................................................................................... 2-7

Operation Manual
xx
Peripherals
Peripheral Device Ports ..........................................................................................3-1
USB Devices ..........................................................................................................3-3
Optional External Floppy Disk Drive Unit.............................................................3-4
Printers ...................................................................................................................3-7
External Monitors...................................................................................................3-8
Audio System .......................................................................................................3-11
PC Cards...............................................................................................................3-14
Communication Functions
Local Area Network (LAN)....................................................................................4-1
Wireless LAN.........................................................................................................4-7
Built-in Modem ....................................................................................................4-19
Network Setup Utility...........................................................................................4-23
Setup Utility
Running the Setup Utility .......................................................................................5-1
Main Menu .............................................................................................................5-3
Advanced Menu......................................................................................................5-4
Security Menu.........................................................................................................5-4
Boot Menu..............................................................................................................5-7
Battery Menu..........................................................................................................5-7
Exit Menu...............................................................................................................5-7
Appendixes
Memory Module .................................................................................................... A-1
Maintenance and Care ........................................................................................... A-5
Virus Protection..................................................................................................... A-7
Data Execution Prevention .................................................................................. A-10
Data Backup and Restore .................................................................................... A-12
Re-installation Instructions .................................................................................. A-13
