Sharp PC-A150 User manual

i
Notice for Users in the USA
FCC Statement
WARNING - FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
A shielded I/F cable and included cables with ferrite cores are required to insure
compliance with FCC regulation for Class B computing equipment.
*AsanENERGY STAR®Partner, SHARP has determined that this product meets
the ENERGY STAR®guidelines for energy efficiency.
Declaration of Conformity
SHARP PERSONAL COMPUTER, PC-A100 Series
This device complies with part 15 of the FCC rules. Operation is subject to the following
conditions:(1)this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Responsible Party: SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP

ii
About the Modem
This equipment complies with Part 68 of FCC rules. On the bottom of this
equipment is a label that contains, among other information, the FCC registration
number and ringer equivalence number (REN) for this equipment. If requested, this
information must be provided to the telephone company.
The modem jack of this equipment complies with Sub-part F of Part 68 of FCC
rules.
The REN is used to determine the quantity of devices which may be connected to the
telephone line. Excessive RENs on the telephone line may result in the devices not
ringing in response to an incoming call. In most, but not all areas, the sum of the
RENs should not exceed five (5.0). To be certain of the number of devices that may
be connected to the line, as determined by the total RENs contact the telephone
company to determine the maximum REN for the calling areas.
If the terminal equipment causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of service may be
required. But if advance notice isn't practical, the telephone company will notify the
customer as soon as possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it necessary.
The telephone company may make changes in its facilities, equipment, operations, or
procedures that could affect the operation of the equipment. If this happens, the
telephone company will provide advance notice in order for you to make the
necessary modifications in order to maintain uninterrupted service.
If trouble is experienced with this equipment, please contact Sharp Electronics Corp.
for repair and (or) warranty information (Refer to the end of this section). If the
trouble is causing harm to the telephone network, the telephone company may
request you remove the equipment from the network until the problem is resolved.
The equipment cannot be used on public coin service provided by the telephone
company. Connection to Party Line Service is subject to state tariffs. (Contact the
state public utility commission, public service commission or corporation
commission for information.)

iii
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person
to use a computer or other electronic device, including fax machines, to send any
message unless such message clearly contains in a margin at the top or bottom of
each transmitted page or on the first page of the transmission, the date and time it is
sent and an identification of the business or other entity, or other individual sending
the message and the telephone number of the sending machine or such business,
other entity, or individual. (The telephone number provided may not be a 900
number or any other number for which charges exceed local or long-distance
transmission charges.) To program this information, refer to the manual of the
communication software.
CAUTION: DISCONNECT TELEPHONE LINES BEFORE ACCESSING THE
MODEM CARD.
Copyright
It is the intent of Sharp that this product be used in full compliance with the
copyright laws of the United States and that prior permission be obtained from
copyright owners whenever necessary.
Product Information and Customer Assistance
For Product Information and Customer Assistance:
Call: 1-800-BE-SHARP (237-4277)
Sharp Electronics Corp.
Sharp Plaza, Mahwah, NJ 07430-2135
Home Page: http://www.sharp-usa.com
E-mail address: [e-mail]
CompuServe: Go Sharp

iv
Notice for Users in Canada
About Modem
The Industry Canada label identifies certified equipment.
This certification means that the equipment meet certain telecommunications
network protective, operational and safety requirements. The department does not
guarantee the equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company.
The equipment must also be installed using an acceptable method of connection. In
some cases, the company's inside wiring associated with a single line individual
service may be extended by means of a certified connector assembly (telephone
extension cord). The customer should be aware that compliance with the above
conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian
maintenance facility designated by the supplier. Any repairs or alterations made by
the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections
of the power utility, telephone lines and internal metallic water pipe system, if
present, are connected together. This precaution may be particularly important in
rural areas.
CAUTION Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority, or electrician, as
appropriate.
“The Ringer Equivalence Number (REN) assigned to each terminal device denotes
the percentage of the total load to be connected to a telephone loop which is used by
the device. To prevent overloading, the termination on a loop may consist of any
combination of devices subject only to the requirement that the total of Ringer
Equivalence Number of all the devices does not exceed 5.”

v
CAUTION:
DISCONNECT TELEPHONE LINES BEFORE ACCESSING THE MODEM
CARD.
ATTENTION:
DEBRANCHER LES LIGNES TELEPHONIQUES AVANT D’ENLEVER CE
COUVRICLE
Product Information and Customer Assistance
For Product Information and Customer Assistance:
Call: 1-905-890-2100 (Toronto Area)
1-800-56-SHARP (Outside Toronto)
Sharp Electronics of Canada Ltd.
335 Britannia Road East,
Mississauga, Ontario, L4Z 1W9
Canada

vi
Notice for Users in Australia
Service Inquiries
Please contact your dealer for service if required or contact Sharp Corporation of
Australia on 1-800-807820 (free call) for referral to your nearest Sharp authorised
Service Centre. Details can be found on the warranty card inserted with the
documentation.
Copyright
Copyright may exist in material you wish to record. Copying or broadcasting such
material without permission of the relevant licensees or owners of the copyright is
prohibited by law.
SHARP is not in a position to authorise the copying or broadcasting of copyright
materials and nothing in this OPERATION MANUAL should be implied as giving
that authority.

vii
Notice for Users in the UK
This apparatus is approved under approval number NS/G 1234/J/100003 for indirect
connection to the public telecommunication system in the United Kingdom.
Copyright
Recording and playback of any material may require consent, which SHARP is
unable to give. Please refer particularly to the provisions of the Copyright Act 1956,
the Dramatic and Musical Performers Protection Act 1958, the Performers
Protection Acts 1963 and 1972 and to any subsequent statutory enactments and
orders.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
BLUE: Neutral
BROWN: Live
As the colours of the wires in the mains lead of this apparatus may not correspond
with the coloured markings identifying the terminals in your plug proceed as
follows.
The wire which is coloured BLUE must be connected to the terminal which is
marked with the letter Nor coloured black.
The wire which is coloured BROWN must be connected to the terminal which is
marked with the letter Lor coloured red.
This apparatus must be protected by a 3A fuse in the mains plug or distribution
board.

viii
Notice for Users in Europe
This equipment complies with the requirements of Directives 89/336/EEC and
73/23/EEC as amended by 93/68/EEC.
Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG
und 73/23/EWG mit Änderung 93/68/EWG.
Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et
73/23/CEE modifiées par la directive 93/68/CEE.
Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en
73/23/EEG, gewijzigd door 93/68/EEG.
Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med
tillæg nr. 93/68/EEC.
Quest' apparecchio è conforme ai requisiti delle direttive 89/336/EEC e
73/23/EEC, come emendata dalla direttiva 93/68/EEC.
Ηεγκατασταση αυτη ανταποκρινεται στιζ απαιτησειζ των οδηγιων τηζ
Ευρωπαïκηζ Ενωσηζ 89/336/EOK κατ 73/23/EOK, óπωζ οι κανονισµοι αυτοι
συµπληρωθηκαν απó την οδηγια 93/68/EOK.
Este equipamento obedece às exigências das directivas 89/336/CEE e
73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
Este aparato satisface las exigencias de las Directivas 89/336/CEE y
73/23/CEE, modificadas por medio de la 93/68/CEE.
Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och
73/23/EEC så som komplette ras av 93/68/EEC.
Dette produktet oppfyller betingelsene i direktivene 89/336/EEC og
73/23/EEC i endringen 93/68/EEC.
Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on
muutettu direktiivillä 93/68/EEC.

ix
CAUTION:
TO PREVENT ELECTRICAL SHOCK, DISCONNECT THE AC CORD AND
THE BATTERY BEFORE SERVICING.
CAUTION:
FOR A COMPLETE ELECTRICAL DISCONNECTION, PULL OUT THE MAIN
PLUG AND THE BATTERY.
VORSICHT:
UM DIE STROMZUFUHR VOLLSTÄNDIG ZU UNTERBRECHEN, DEN
NETZSTECKER HERAUSZIEHEN UND DIE BATTERIE ÈNTFERNEN.
ATTENTION:
POUR UN ARRET TOTAL DU SYSTEME, DECONNECTEZ LA PRISE DE
COURANT SECTEUR ET LA BATTERIE.
VARNING:
FÖR TOTAL ELEKTRISK URKOPPLING, KOPPLA UR KONTAKTEN OCH
TA UR BATTERIET.
PRECAUCION:
PARA UNA COMPLETA DESCONEXION ELECTRICA DESENCHUFE LA
CLAVIJA DE LA RED Y LA BATERIA.

x
Safety Precautions
General
•Follow all cautions and instructions which may be marked on the computer.
•Except as described elsewhere in this manual, refer all servicing to qualified
personnel. Immediately shut off the computer and refer for servicing under the
following conditions:
•when the power cord or plug is damaged or frayed
•if liquid has been spilled on the computer
•if the computer has been dropped or the cabinet has been damaged
Location
•Do not expose the computer to direct sunlight.
•Try to avoid dusty environments.
•Keep the computer away from any magnetic devices and TVs.
•Keep the computer away from excessive humidity or fluids such as rain, snow,
water spray, juice, coffee, steam, etc.
•Do not move the computer from a cold place to a warm place. A temperature
difference of more than 10°C (18°F) will cause condensation inside the unit,
which may damage the data.
•Do not block or cover slots or openings on the cabinet to protect the computer
from over heating.
•Do not smoke near your computer.
Usage
•Never push any objects of any kind into cabinet openings. They may touch
dangerous voltage points or short parts that could result in fire or electrical shock.
•Turn off the computer before installing or removing a peripheral device(except
when connecting USB devices and PC cards).
•Check the AC power cord and power connectors periodically for damage. Replace
the power cord immediately if damage is found.
•Never subject your computer to sudden shocks or extreme vibration.
•Do not drop the computer nor hit it with other equipment.
•Do not scratch the surface of the LCD screen.

xi
•Turn off the computer and disconnect the AC power cord before cleaning.
Battery Pack Precautions
Handling
•Never put the battery pack in a fire, as it could explode and cause injury.
•Do not attempt to open or alter the battery pack.
•Do not place the battery where it might get hotter than 60°C (140°F).
•Do not allow metal objects such as jewelry to short across the battery terminals, as
it could heat up and explode.
•Do not allow liquids to come in contact with the battery pack.
•Avoid dropping the pack or other violent shock.
•Do not solder anything to the battery terminals.
Charging
•Charge the battery pack only with the AC adapter included with your computer.
Discharging
•Do not use the battery pack for any purpose other than powering the computer.
Storage
•Store the battery pack in a cool and dry place. Never allow the temperature to
exceed 60°C (140°F) during storage.
•Recharge the battery pack after storage, before use.

xii
Modem Precautions
•Never install telephone wiring during a lightning storm.
•Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
•Never touch uninsulated telephone wires or terminals unless the telephone line
has been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Avoid using the telephone during a lightning storm. There may be a remote risk
of electric shock from lightning.
•Do not use the telephone to report a gas leak in the vicinity of the leak.

xiii
About This Manual
Notice
Information in this manual is subject to change without notice and does not represent a
commitment on the part of SHARP Corporation.
SHARP Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from the furnishing,
performance, or use of this material.
SHARP strongly recommends that separate permanent written records be kept of all
important data. Data may be lost or altered in virtually any electronic memory product under
certain circumstances. Therefore, SHARP assumes no responsibility for data lost or
otherwise rendered unusable whether as a result of improper use, repairs, defects, battery
replacement, use after the specified battery life has expired, or any other causes.
SHARP assumes no responsibility directly or indirectly, for financial losses or claims from
third persons resulting from the use of this product and any of its functions, such as stolen
credit card numbers, the loss of or alteration of stored data, etc.
Edition
1st Edition, September 1998.
Copyright
© 1998 SHARP Corporation
This document contains or refers to proprietary information which is protected by copyright. All rights
are reserved. Copying or other reproduction of this document is prohibited without the prior written
permission of SHARP Corporation.
Trademarks
Pentium is a registered trademark, and MMX is a trade mark, of Intel Corporation.
IBM and PS/2 are trademarks of International Business Machines Corporation.
Microsoft, MS-DOS, Windows, and the Windows Logo are registered trademarks of Microsoft
Corporation.
Sound Blaster is a trademark of Creative Technology Ltd.
All other brand and product names are trademarks or registered trademarks of their respective holders.

xiv
Recording Important Information
For future reference, please record the following information in the spaces provided
below.
Model Number:
Serial Number:
Date of purchase:
Dealer’s Name:
Place of purchase:
Password:
The serial number is printed on a sticker located on the bottom of the computer.

xv
Manual Conventions
This manual uses a set of style conventions described below.
Notes and Cautions are italicized with icons:
A note icon informs you of a special technique or information that may
help you perform a task or better understand a process.
A caution icon alerts you to something that may cause problems or
damage to hardware, software or data.
Key Labels on the Keyboard, when referred to in the instructions, are shown in
boldface:
Press Enter to continue.
When more than one key are pressed simultaneously, the key labels are separated by
a plus (+) sign:
Restart your computer by pressing Ctrl+Alt+Delete.
When necessary, important key combinations are shown in graphics:
Sample Entries are shown in upper cases of different typeface. In the following
case, press the Enter key after you type the command:
C:\>DIR A: Enter
Words/Texts on Screen, such as window titles or possible parameters, are
italicized:
Double-click this icon to display the Power Properties window.
Set the item to Enabled.
Screens reproduced in this manual may differ slightly from the screens you see on
your computer.
Section Titles in other parts of this manual are italicized:
Refer to Infrared Communication section in Chapter 5.

xvi
Table of Contents
Notice for Users in the USA.......................................................................................i
Notice for Users in Canada.......................................................................................iv
Notice for Users in Australia ....................................................................................vi
Notice for Users in the UK......................................................................................vii
Notice for Users in Europe .....................................................................................viii
Safety Precautions......................................................................................................x
About This Manual.................................................................................................xiii
Recording Important Information...........................................................................xiv
Manual Conventions................................................................................................xv
Table of Contents....................................................................................................xvi
Overview of Computer..........................................................................................xviii
Quick Setup
Turning Power On ..................................................................................................1-1
Setting up Windows 98...........................................................................................1-3
Shutting Down the System......................................................................................1-4
Basic Operations
Choosing Power Source..........................................................................................2-1
Resetting the System...............................................................................................2-3
Using Glide Pad......................................................................................................2-4
Using Keyboard......................................................................................................2-6
Using External Floppy Disk Drive Unit..................................................................2-7
Battery and Power Management
Standard Battery Pack.............................................................................................3-1
Optional External Battery Pack ..............................................................................3-5
Power Management ................................................................................................3-8
Peripherals
Using Peripherals....................................................................................................4-1
PC Card ..................................................................................................................4-3
Keyboard / Mouse...................................................................................................4-6
Display....................................................................................................................4-7
Audio System..........................................................................................................4-9

xvii
USB Device............................................................................................................4-9
Printer...................................................................................................................4-10
RS-232C Device...................................................................................................4-10
Communication Functions
Infrared Communication ........................................................................................5-1
Built-in Modem......................................................................................................5-3
Security Features
Passwords...............................................................................................................6-1
Security Slot...........................................................................................................6-4
Setup Utility
Running the Setup Utility....................................................................................... 7-1
Main menu .............................................................................................................7-3
Advanced menu......................................................................................................7-4
Security menu.........................................................................................................7-5
Power menu............................................................................................................ 7-6
Exit menu...............................................................................................................7-7
Appendixes
Maintenance and Care........................................................................................... A-1
Specifications........................................................................................................ A-3
Troubleshooting
Troubleshooting .....................................................................................................T-1
Index
Index ...............................................................................................................Index-1

xviii
Overview of Computer
Each number after an arrow indicates the page referring to the part. Actual
appearance of your computer may be slightly different depending on the model.
Front

xix
Right
Left

xx
Rear
Bottom
