Sharp R-8730 User manual

ENGLISH
Important
R-8730
MICROWAVE OVEN WITH TOP & BOTTOM
GRILLS AND CONVECTION
OPERATION MANUAL
900 W (IEC 60705)
R-8730 ENGLISH 12/07/2001 12:20 PM Page A

R-8730 ENGLISH 12/07/2001 12:20 PM Page B

ENGLISH
1
CONTENTS
OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
BEFORE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
COOKING WITH PRE-PROGRAMMED MEMORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 8
PRE-SET MEMORY CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
TIME REDUCE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MANUAL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MICROWAVE POWER LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MICROWAVE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CONVECTION COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
PRE-HEATING THE OVEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
GRILL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
DUAL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
OTHER CONVENIENT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 - 18
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
SERVICE CALL CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
COOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 - 31
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
SERVICE ADDRESSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 - 38
OPERATION MANUAL
This operation manual contains important information which you should read carefully before
using your microwave oven.
IMPORTANT: There may be a serious risk to health if this operation manual is not followed or
if the oven is modified so that it operates with the door open.
R-8730 ENGLISH 12/07/2001 12:20 PM Page 1

2
OVEN AND ACCESSORIES
1Control panel
2Oven lamp
3Grill heating element (top grill)
4Door opening button
5Waveguide cover
6Oven cavity
7Turntable motor shaft
8Grill heating element (bottom grill)
9Ventilation openings
10 Door seals and sealing surfaces
11 Power cord
12 Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are
provided:
13 Turntable 14 Handle (x1, only one handle will be
supplied and will be marked either Lor R). When the
turntable is hot, use the provided handle to remove the
turntable from the oven. 15 Rack.
Place the turntable on to the turntable motor shaft so
that it locates firmly.
Before first using the turntable, clean with mild soapy
water. Do not cut or scratch the turntable.
WARNING:
The accessories (e.g. turntable) will become
very hot during operation (except Defrost)
modes. Always use thick oven gloves when
removing the food or turntable from the
oven to prevent burns.
1
2
3
4
13
10 9 8 7 6 5
15
9
11
12
NOTE: When you order accessories, please mention
the following two items: part name and model name
to your dealer or SHARP authorised service agent.
Bottom grill
Turntable motor shaft
14
R-8730 ENGLISH 17/07/2001 12:44 PM Page 2

CONTROL PANEL
3
1. DIGITAL DISPLAY
2. INDICATORS:
These indicators will light corresponding
with below symbols
: Time reduce
: Memory
: Manual
: Percentage (for microwave
power level)
: Lock (showing oven lock is set)
: Cook (showing oven in operation)
3. COOKING MODE indicator lights.
These indicator lights will light during
each cooking mode.
OPERATION KEYS:
4. NUMBER keys for time and memory
programming
5. START key
6. DOOR OPENING button
7. STOP key
8. TIME REDUCE key
9. MEMORY key
10. +1min key
11. BOTTOM GRILL key
12. TOP GRILL key
13. CONVECTION key
To change the convection temperature
14. MICROWAVE key
To change the microwave power setting
15. MANUAL key
2
4
1
15
14
13
12
11
10
9
75
6
3
8
R-8730 ENGLISH 12/07/2001 12:20 PM Page 3

To avoid the danger of fire
The microwave oven should not be left
unattended during operation. Power
levels that are too high or cooking times
that are too long may overheat foods
resulting in a fire.
This oven is not designed to be built into a kitchen
unit.
The electrical outlet must be readily accessible so that
the unit can be unplugged easily in an emergency.
The AC power supply must be 230 V, 50 Hz, with
a minimum 16 A distribution line fuse, or a
minimum 16 A distribution circuit breaker.
It is recommended that a separate circuit serving
only this appliance be provided.
Do not place the oven in areas where heat is
generated. For example, close to a conventional oven.
Do not install the oven in an area of high humidity
or where moisture may collect.
Do not store or use the oven outdoors.
If food being heated begins to smoke,
DO NOT OPEN THE DOOR. Turn off and
unplug the oven and wait until the food
has stopped smoking. Opening the door
while food is smoking may cause a fire.
Use only microwave-safe containers and
utensils. See Page 22 - 23.
Do not leave the oven unattended when
using disposable plastic, paper or other
combustible food containers.
Clean the waveguide cover, the oven
cavity and the turntable after use. These
must be dry and free from grease. Built-
up grease may overheat and begin to
smoke or catch fire.
Do not place flammable materials near the oven or
ventilation openings. Do not block the ventilation
openings.
Remove all metallic seals, wire twists, etc., from
food and food packages. Arcing on metallic
surfaces may cause a fire.
Do not use the microwave oven to heat oil for deep
frying. The temperature cannot be controlled and
the oil may catch fire.
To make popcorn, use only special microwave
popcorn makers.
Do not store food or any other items inside the oven.
Check the settings after you start the oven to ensure
the oven is operating as desired.
See the corresponding hints in the cookery book section.
4
IMPORTANT SAFETY INSTRUCTIONS
To avoid the possibility of injury
WARNING:
Do not operate the oven if it is damaged or
malfunctioning. Check the following before use:
a)The door; make sure the door closes properly and
ensure it is not misaligned or warped.
b)The hinges and safety door latches; check to make sure
they are not broken or loose.
c) The door seals and sealing surfaces; ensure that they
have not been damaged.
d)Inside the oven cavity or on the door; make sure there
are no dents.
e) The power supply cord and plug; ensure that they are
not damaged.
Never adjust , repair or modify the oven
yourself. It is hazardous for anyone
other than a competent person to carry
out any service or repair operation
which involves the removal of a cover
which gives protection against exposure
to microwave energy.
Do not operate the oven with the door open or
alter the door safety latches in any way.
Do not operate the oven if there is an object
between the door seals and sealing surfaces.
Do not allow grease or dirt to build up
on the door seals and adjacent parts.
Follow instructions for “Care and
Cleaning”, Page 19.
Individuals with PACEMAKERS should check with
their doctor or the manufacturer of the pacemaker
for precautions regarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstances should you remove the
outer cabinet.
Never spill or insert any objects into the door lock
openings or ventilation openings. In the event of a
spill, turn off and unplug the oven immediately, and
call an authorised SHARP service agent.
Do not immerse the power supply cord or plug in
water or any other liquid.
Do not let the power supply cord hang over the
edge of a table or work surface.
Keep the power supply cord away from heated
surfaces, including the rear of the oven.
Do not attempt to replace the oven lamp yourself or
allow anyone who is not an electrician authorised
by SHARP to do so. If the oven lamp fails, please consult
your dealer or an authorised SHARP service agent.
IMPORTANT SAFETY INSTRUCTIONS: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
R-8730 ENGLISH 12/07/2001 12:20 PM Page 4

Temperature of the container is not a true indication
of the temperature of the food or drink; always
check the food temperature.
Always stand back from the oven door when opening,
to avoid burns from escaping steam and heat.
Slice stuffed baked foods after heating to release
steam and avoid burns.
Keep children away from the door to prevent them
burning themselves.
Do not touch the oven door, outer cabinet, rear
cabinet, oven cavity, ventilation openings,
accessories and dishes during GRILL,
CONVECTION, DUAL and MEMORY
OPERATION modes as they will become hot.
Before cleaning make sure they are not hot.
To avoid misuse by children
WARNING: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the child
is able to use the oven in a safe way and
understands the hazards of improper use.
Do not lean or swing on the oven door. Do not
play with the oven or use it as a toy.
Children should be taught all important safety
instructions: use of pot holders, careful removal of
food coverings; paying special attention to
packaging (e.g. self-heating materials) designed to
make food crisp, as they may be extra hot.
Other warnings
Never modify the oven in any way.
Do not move the oven while it is in operation.
This oven is for home food preparation only and
may only be used for cooking food. It is not
suitable for commercial or laboratory use.
To promote trouble-free use of your oven
and avoid damage.
Never operate the oven when it is empty except
where recommended in the operation manual, see
Page 13. Doing so may damage the oven.
When using a browning dish or self-heating
material, always place a heat-resistant insulator
such as a porcelain plate under it to prevent
damage to the turntable due to heat stress. The
preheating time specified in the dish’s instructions
must not be exceeded.
Do not use metal utensils, which reflect microwaves
and may cause electrical arcing. Do not put cans
in the oven.
5
IMPORTANT SAFETY INSTRUCTIONS
If the power supply cord of this appliance is
damaged, it must be replaced with a special cord.
The exchange must be made by an authorised
SHARP service agent.
To avoid the possibility of explosion and
sudden boiling:
WARNING: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
Never use sealed containers. Remove seals and
lids before use. Sealed containers can explode due
to a build up of pressure even after the oven has
been turned off.
Take care when microwaving liquids. Use a wide-
mouthed container to allow bubbles to escape.
Never heat liquids in narrow necked
containers such as baby bottles, as this may
result in the contents erupting from the
container when heated and cause burns.
To prevent sudden eruption of boiling liquid and
possible scalding:
1. Stir liquid prior to heating/reheating.
2. It is advisable to insert a glass rod or similar utensil
into the liquid whilst reheating.
3. Let liquid stand in the oven at the end of cooking
time to prevent delayed eruptive boiling.
Do not cook eggs in their shells, and whole
hard boiled eggs should not be heated in
microwave ovens since they may explode
even after microwave cooking has ended.
To cook or reheat eggs which have not
been scrambled or mixed, pierce the yolks
and the whites, or the eggs may explode.
Shell and slice hard boiled eggs before
reheating them in the microwave oven.
Pierce the skin of such foods as potatoes, sausages
and fruit before cooking, or they may explode.
To avoid the possibility of burns
Use pot holders or oven gloves when removing food
from the oven to prevent burns.
Always open containers, popcorn makers, oven
cooking bags, etc., away from the face and hands to
avoid steam burns.
To avoid burns, always test food
temperature and stir before serving and
pay special attention to the temperature
of food and drink given to babies,
children or the elderly.
R-8730 ENGLISH 12/07/2001 12:20 PM Page 5

1. Remove all packing materials from the inside of the
oven cavity. Discard the loose polythene sheet from
between the door and cavity. Remove the feature
sticker, if attached, from the outside of the door.
2. Check the oven carefully for any signs of damage.
3. Place the oven on a flat, level surface strong
enough to support the oven’s weight plus the
heaviest item likely to be cooked.
4. The oven door may become hot during
cooking. Place or mount the oven so
that the bottom of the oven is 85 cm or
more above the floor. Keep children
away from the door to prevent them
burning themselves.
5. Do not allow the power supply cord to
run over any hot or sharp surfaces,
such as the hot air vent area at the top
rear of the oven.
Remove this film
6. Ensure there is a minium of free space above
the oven of 19 cm.
7. Do not stack this oven.
8. Securely connect the plug of the oven to a
standard earthed (grounded) household
electrical outlet.
6
IMPORTANT SAFETY INSTRUCTIONS
INSTALLATION
19 cm
NOTE:
If you are unsure how to connect your oven, please
consult an authorised, qualified electrician.
Neither the manufacturer nor the dealer can accept
any liability for damage to the oven or personal
injury resulting from failure to observe the correct
electrical connection procedure.
Water vapour or drops may occasionally form on
the oven walls or around the door seals and
sealing surfaces. This is a normal occurrence and is
not an indication of microwave leakage or a
malfunction.
Use only the turntable designed for this oven.
Do not use the oven without the turntable.
Do not place anything on the outer cabinet during
operation.
Do not use plastic containers for microwaving if the
oven is still hot from using the GRILL,
CONVECTION, DUAL and MEMORY
OPERATION modes because they may melt.
Plastic containers must not be used during above
modes unless the container manufacturer says they
are suitable.
R-8730 ENGLISH 17/07/2001 12:44 PM Page 6

BEFORE OPERATION
7
COOKING WITH PRE-PROGRAMMED MEMORIES
LOCK FUNCTION
•Your oven has a lock function and is locked when
you first connect to an electrical socket. At that time
the digital display will show:
•The lock will be set when the oven is plugged in,
you can use all functions except for the
MEMORY key.
•To release the lock function, press the
MANUAL key and hold for 2 seconds until the
audible sound is heard. LOCK indicator will
disappear and you can use the MEMORY key.
To lock the oven press the MANUAL key and
hold for 2 seconds.
•Your oven is already installed with 30 cooking
programmes for apetito products in each number
key. The first 20 programmes cannot be changed.
•The input is cancelled when any keys are not
pressed for more than 3 minutes.
•Heat the oven using the top and bottom grills
without food for 20 minutes. (For operation see
notes in GRILL COOKING, on page 13).
STOPPING THE OVEN
•or will appear on the display after
the time reaches zero (e.g. at the end of the
cooking time). will disappear when the
STOP key is pressed. If you press the STOP key
twice during cooking appears. If you
press the stop key again the display will return
to .
LET THE OVEN COOL DOWN WHILE
IS DISPLAYED TO PREVENT OVER
COOKING.
•If you wish to stop the oven during cooking:
Press the STOP key once or open the door.
To start the oven again, close the door and press
the START key within 1 minute.
•If you wish to cancel a programme during cooking,
press the STOP key twice.
•If you wish to erase a mistake during
programming, press STOP key once.
•The oven has 30 memory banks (1 - 30), the
programme numbers of Memory are made
especially for deep frozen menus of apetito.
•The total cooking times for each memory bank are
shown in the table on page 8. The memory banks
21 - 30 can be changed individually if required
(see page 16).
•In addition for all memory banks a reduce factor is
stored. It is useful if you use the same memory in
the memory banks continuously.
The reduce factor is separately made for each
programme.
The stored reduce factor for 21 - 30 can also be
changed individually if required (see page 17).
•Information in these memory banks is not lost
during power interruptions. If the power goes off,
the oven does not need to be re-programmed.
Batteries are not necessary for this type of memory.
•To check the stored programmes or reduce factors
refer to “memory check”on page 18.
R-8730 ENGLISH 12/07/2001 12:20 PM Page 7

PRE-SET MEMORY CHART
8
Memory No. 1234567890
Total Cooking 15’00”17’00”14’50”16’00”16’00”13’00”13’50”14’00”14’00”14’50”
Time
Reduce Factor 0.96 0.96 0.97 0.97 0.96 0.96 0.96 0.96 0.96 0.96
Example: Suppose you want to reheat frozen apetito menu by using MEMORY 1.
Follow instructions on the apetito Guide.
COOKING WITH PRE-PROGRAMMED MEMORIES
1. Press the NUMBER key 1. Display will count down
through the cooking time.
2. Press the START key.
Memory No. 11 12 13 14 15 16 17 18 19 20
Total Cooking 14’50”15’00”17’00”18’00”15’30”14’30”12’50”19’00”14’00”16’30”
Time
Reduce Factor 0.96 0.96 0.96 0.96 0.97 0.96 0.96 0.96 0.96 0.85
Memory No. 21 22 23 24 25 26 27 28 29 30
Total Cooking 15’00”5’50”8’00”1’15”5’30”6’00”4’50”5’20”7’30”12’30”
Time
Reduce Factor 0.96 0.85 0.92 0.90 0.93 0.85 0.91 0.91 0.91 0.91
Note: The correct Memory number for each menu is mentioned on the cover of each apetito-menu.
Note:
When you reheat with the memory key:
1. Place the upturned Pyrex dish onto the turntable. The Pyrex dish is supplied from apetito separately.
2. Place the frozen menus of apetito on top of the Pyrex dish. For details, please refer to apetito guide.
3. Do not remove the Pyrex dish just after cooking as it will be very hot.
4. The programmes 26 - 30 are baking menus. Remove outer package and container before reheating.
Place the food on the rack. Remove the Pyrex dish here.
WARNING:
The oven cavity, turntable, rack, dishes and especially the bottom grill will become very hot, always use
the handle or thick oven gloves at all times when removing food or turntable from the oven to prevent
burns.
x1 x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 8

TIME REDUCE COOKING
9
ENGLISH
When you use the same NUMBER key within a short time one after another, the food may be
overcooked. It is recommended to use the time reduce function to get the best results. This function will
shorten the total cooking time depending on the reduced factor for each memory;
Reduced cooking time = total cooking time x reduce factor.
Example: Suppose you want to reheat frozen Apetito menu by using MEMORY 1 with the time reduce setting.
•Your oven can be programmed for up to 3 cooking sequences. You can enter cooking time up to 99
minutes 99 seconds for each stage. (See page 15 for details.)
•To input manual cooking:
1. Press the MANUAL key.
2. Enter cooking time. (for preheating, you can omit this step).
3. Select desired cooking mode.
4. Press the START key.
•During cooking mode, the oven stops when the door is opened, and the programme is cancelled if the
START key is not pressed within 1 minute after the door is closed.
•Before cooking check the suitable utensils on pages 22 - 23.
1. Press the TIME
REDUCE key.
MANUAL COOKING
2. Press the NUMBER
key 1. 3. Press the START key. Display will count down
through the cooking time.
MICROWAVE POWER LEVELS
Your oven has 6 power levels. To choose the
power level for cooking, follow the advice given in
the recipe section. Generally the following
recommendations apply:
100 % - (900 W) used for fast cooking or
reheating e.g. soup, casseroles, canned food, hot
beverages, vegetables, fish, etc.
70 % - (630 W) used for longer cooking of dense
foods such as roast joints, meat loaf and plated
meals, also for sensitive dishes such as cheese
sauce and sponge cakes. At this reduced setting,
the sauce will not boil over and food will cook
evenly without over cooking at the sides.
50 % - (450 W) for dense foods which require a
long cooking time when cooked conventionally,
eg. beef dishes, it is advisable to use this power
setting to ensure the meat will be tender.
30 % - (270 W Defrost setting) to defrost, select
this power setting, to ensure that the dish defrosts
evenly. This setting is also ideal for simmering rice,
pasta, dumplings and cooking egg custard.
10 % - (90 W) for gentle defrosting, eg. cream
gateaux or pastry.
0 % - (0 W) for setting standing time.
(No microwave power.)
x1 x1 x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 9

Your oven has 6 preset power levels.
Press MICROWAVE key x1 x2 x3 x4 x5 x6
Microwave power level 100 % 70 % 50 % 30 % 10 % 0 %
Example: Suppose you want to cook for 2 minutes 30 seconds on 50 %.
Notes:
•Once the oven has started you can find out the power level you have programmed by pressing the
MICROWAVE key. The power level will appear on the display. This will not affect the programme or
the cooking time.
•If the power level is not selected, 100 % power is automatically set.
1. Press the
MANUAL key. 2. Enter desired cooking time.
All indicatior lights will flash
on and off.
3. Enter the desired power level 50% by
pressing the MICROWAVE key 3 times,
MICRO indicator light will remain on.
10
MICROWAVE COOKING
x3
4. Press the START key. Display will count down
through the cooking time.
x1 x1 x1 x1
x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 10

Your oven can be programmed to cook with ten different temperatures by combining the top and bottom grills with
the convection fan.
Notes:
•Once the oven has started you can find out the temperatures you have programmed by pressing the
CONVECTION key. The temperature will appear on the display. This will not affect the programme or
cooking time.
•After cooking is complete the cooling fan will continue working for a short time to lower the
temperature of the electrical and mechanical components.
WARNING:
The oven cavity, turntable, rack, dishes and especially the bottom grill will become very hot, always use
the handle or thick oven gloves at all times when removing food or turntable from the oven to prevent
burns.
11
CONVECTION COOKING
ENGLISH
x1
250
Press CONVECTION key
Oven Temp (°C)
x2
230
x3
220
x4
200
x5
180
x6
160
x7
130
x8
100
x9
70
x10
40
Example: Suppose you want to cook for 20 minutes at 200˚C.
1. Press the
MANUAL key. 2. Enter desired cooking time.
All indicatior lights will flash
on and off.
3. Enter the desired temperature 200˚C by
pressing the CONVECTION key 4 times.
CONVEC indicator light will remain on.
x4
4. Press the START key. Display will count down
through the cooking time.
x1 x1 x1 x1 x1
x1
Note:
Temperature measurements taken whilst the oven is in convection mode will differ from the displayed level.
This is due to the grill elements turning on and off in order to regulate the oven temperature. This will not
affect the cooking results as long as the operation manual and cookbook are followed correctly.
R-8730 ENGLISH 12/07/2001 12:20 PM Page 11

12
PREHEATING THE OVEN
Your oven can be preheated to a desired temperature prior to oven cooking.
Example: Suppose you want to preheat the oven to 200˚C.
When the oven reaches 200˚C, the audible signal will
sound and the oven will display 200˚C. Place food in
the oven, enter the desired cooking time and
temperature before pressing the START key.
Notes:
•The preheated temperature will be maintained for approximately 30 minutes before automatically
turning itself off.
If you open and close the oven door during the 30 minutes will appear and the oven will stop
keeping the preheated temperature.
•Once the oven has started you can find out the actual temperature by pressing the
CONVECTION key. The temperature will appear on the display. This will not affect the programme or
the cooking time.
WARNING:
The oven cavity, turntable, rack, dishes and especially the bottom grill will become very hot, always use
the handle or thick oven gloves at all times when removing food or turntable from the oven to prevent
burns.
1. Press the
MANUAL key. 2. Enter the desired temperature 200˚C by
pressing the CONVECTION key 4 times.
CONVEC indicator light will come on.
x4
3. Press the START key.
x1 x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 12

13
GRILL COOKING
ENGLISH
Your oven has 2 grill heating elements, and a combination of 3 grill cooking modes. Select the desired
grill mode by pressing the TOP GRILL or/and BOTTOM GRILL key.
Example: Suppose you want to cook for 5 minutes using the top and bottom grills.
Notes:
You may detect smoke or a burning smell when using the grill for the first time. This is normal and not a
sign that the oven is out of order. To avoid this problem, when first using the oven, operate the oven using
the top and bottom grills without food for 20 minutes.
Important: •During grill operation, to allow smoke or smells to disperse open a window or switch the
kitchen ventilation on.
•The oven door, outer cabinet & oven cavity will become hot. Take care to avoid burns
after using the oven.
WARNING:
The oven cavity, turntable, rack, dishes and especially the bottom grill will become very hot, always use
the handle or thick oven gloves at all times when removing food or turntable from the oven to prevent
burns.
1. Press the
MANUAL key. 2. Enter desired cooking time.
All indicatior lights will flash
on and off.
3. Press the TOP GRILL and BOTTOM
GRILL keys. TOP and BOTTOM
GRILL indicator lights will remain on.
x1
4. Press the START key. Display will count down
through the cooking time.
x1x1
x1
x1 x1 x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 13

14
DUAL COOKING
Your oven has 3 DUAL cooking modes to combine the microwave with convection or the grills. To select
the DUAL cooking mode, press the MICROWAVE key and one of the CONVECTION, TOP GRILL or
BOTTOM GRILL keys. Generally, dual cooking time shortens the total cooking time.
Programmed Dual Cooking modes.
WARNING:
The oven cavity, turntable, rack, dishes and especially the bottom grill will become very hot, always use
the handle or thick oven gloves at all times when removing food or turntable from the oven to prevent
burns.
Example: Suppose you want to cook for 11 minutes on Dual 1, combining 50 % Microwave power with
the 200˚C Convection.
Cooking method
MICRO 30 %
CONV 250°C
MICRO 30 %
TOP GRILL
MICRO 30 %
BOTTOM GRILL
Microwave Power Range
10 % - 50 %
10 % - 100 %
10 % - 100 %
DUAL 1
DUAL 2
DUAL 3
Notes:
•To adjust the microwave power, press the MICROWAVE key.
•To adjust the convection temperature, press the CONVECTION key until the desired temperature
appears on the display.
•For DUAL 1 the oven temperature can be changed from 40°C to 250°C in ten levels.
1. Press the
MANUAL key. 2. Enter desired cooking time.
All indicatior lights will flash
on and off.
3. Enter the desired temperature 200˚C by
pressing the CONVECTION key 4 times.
CONVEC indicator light will remain on.
x4
5. Press the START key. Display will count down
through the cooking time.
4. Enter desired power level 50 % by
pressing the MICROWAVE key 3 times.
MICRO indicator will come on.
x3
x1 x1 x1 x1 x1
x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 14

15
OTHER CONVENIENT FUNCTIONS
ENGLISH
1. MULTIPLE SEQUENCE COOKING
This facility enables continued operation of up to three different sequences.
Example:
Suppose you want to cook: 2 minutes 30 seconds on 70% microwave power (Stage 1)
5 minutes on Top grill (Stage 2)
Notes:
•You can programme a pause when you programme 2 cooking sequences (Stage 1 ➝ Pause ➝ Stage 2).
To set the pause, press the NUMBER KEY ‘0’ and MICROWAVE key once, after setting stage 1. The
oven will keep the programme during the pause. After pause, you must press the START key to resume
cooking.
•If you set the preheat in the sequence programming, the oven will keep the programme after preheat is over.
1. Press the
MANUAL key.
STAGE 1
2. Enter desired cooking time.
All indicatior lights will flash
on and off.
3. Enter desired power level 70 % by
pressing the MICROWAVE key twice.
MICRO indicator will remain on.
x2
6. Press the START
key.
Display will count
down through the
cooking time.
STAGE 2
4. Enter desired cooking time.
All indicatior lights will flash
on and off.
5. Press the TOP GRILL
key. TOP GRILL
indicator light will
remain on.
2. MINUTE PLUS FUNCTION
The +1min key allows you to operate the two following functions:
a. Microwave 100 % cooking.
You can cook for 1 minute on 100 % easily.
Example: Suppose you want to cook for 2 minutes on 100 % microwave power.
b. Extend the cooking time.
You can extend the cooking time for multiples of 1 minute if the key is pressed while the oven is in
operation.
NOTE: You cannot use this function during cooking with the pre-programmed memories of apetito products.
1. Press the
MANUAL key.
Display will count down
through the cooking time.
2. Press the +1min
key twice.
x2
x1 x1 x1 x1
x1 x1 x1 x1 x1
x1
R-8730 ENGLISH 17/07/2001 12:44 PM Page 15

OTHER CONVENIENT FUNCTIONS
3. MEMORY PROGRAMME ENTRY
You can change, if you need, the memory programmes for 10 memory banks (21 - 30).
You can programme for up to 3 cooking sequences using microwave, convection, grill, dual
cooking and you can enter cooking time up to 99 min 99 sec. for each stage.
For details of each cooking mode, see the following pages:
Microwave Cooking: page 10 Grill Cooking: page 13
Convection Cooking: page 11 Dual Cooking: page 14
Before you change the memory programme ensure that the oven is not in the lock function.
If you personnally have the wish to change the programmes, please consider that after changing
the programme, the best preparation time for apetito menus is no longer guaranteed.
3a. TO OVERWRITE TIME AND POWER LEVEL OF MEMORY
Example: Suppose you want to change the programme for Memory 23 as follows:
4 minutes on 50 % microwave power (Stage 1)
2 minutes on Dual 2 (10 % microwave power and bottom grill) (Stage 2)
16
1. Press the MEMORY
key and hold for 5
seconds until the
singal sounds twice.
MEMORY indicator
light will come on.
2. Select the memory
number. To programme
23 simply press the
NUMBER 3 key to
change the flashing
number 1.
STAGE 1
4. Enter desired
cooking time.
All indicator lights
will flash on and off.
x1 for 5
seconds
x3
STAGE 2
6. Enter desired
cooking time.
All indicator lights
will flash on and off.
7. Press the TOP GRILL
key. TOP GRILL
indicator light will
remain on.
5. Press the
MICROWAVE key 3
times for 50 % power,
MICRO indicator light
will remain on.
3. Press the
MANUAL
key.
x2
8. Press the
MICROWAVE key
twice for 10 % power,
MICRO indicator light
will come on.
x1 x1 x1 x1 x1
x1 x1 x1 x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 16

Notes:
•To select memory number 30, press the NUMBER keys 3 and 0, or simply press the NUMBER key 0.
•If you wish to change other preset memory programmes continually, press desired memory number key
prior to setting the STOP key. After selecting the memory number, follow the above example.
•The preset reduce factors of the memory banks are suitable for each cooking programme. It is
recommended to change it corresponding with new programmes you set.
9. Press the MEMORY key. 10. Press the STOP key to release the memory setting mode.
17
OTHER CONVENIENT FUNCTIONS
ENGLISH
Notes:
•To select memory number 30, press the NUMBER keys 3 and 0, or simply press the NUMBER key 0.
•The reduce factor can be set from 0.00 to 0.99
•If you wish to change the reduce factor in other memories continually, press desired memory number key
prior to pressing the STOP key. After selecting the memory number, follow the above example.
3b. TO CHANGE THE REDUCE FACTORS
The reduce factor is preset for each memory programme separately, but you can alter the factor to suit
your needs.
For preset reduce factor, see page 8.
Example: Suppose you want to reduce the factor in memory 23 (0.92) to 0.8.
1. Press the MEMORY key and hold for
5 seconds until the singal sounds twice.
MEMORY indicator light will come on.
2. Press the TIME
REDUCE key.
x1 for 5 seconds
3. Select the MEMORY number. Press
the NUMBER 3 key to change the
flashing number 1.
5. Press the
MEMORY key. 6. Press the STOP key to release
the memory setting mode.
4. Set the reduce factor.
x1 x1
x1 x1
x1 x1 x1 x1
R-8730 ENGLISH 12/07/2001 12:20 PM Page 17

18
OTHER CONVENIENT FUNCTIONS
3c. MEMORY CHECK
You can check the information programmed into the memory, for example time and power level.
Before you check the memory programme ensure the oven has released from the lock function.
NOTE:
•To cancel MEMORY CHECK, press the STOP key.
•If you wish to check other memory programmes continually repeat steps 2 and 3 prior to pressing the
STOP key.
•To check the reduce factor, press the TIME REDUCE key before pressing memory number key.
CHECKING TIME AND POWER LEVEL
Example: Suppose you want to know the information programmed into memory 27, programmed for
2 minutes on Dual 2 (100% microwave/top grill) for the first sequence and 2 minutes 50
seconds on top and bottom grills for the second sequence.
1. Press the
MEMORY key. 2. Select the memory
number.
STAGE 1
4. The programme will appear. MICRO and
TOP GRILL indicator lights will come on.
x1 x1
3. Press the MEMORY
key again.
x1
x1
STAGE 2
5. TOP and BOTTOM GRILL
indicator lights will come
on.
R-8730 ENGLISH 12/07/2001 12:20 PM Page 18
Table of contents
Languages:
Other Sharp Microwave Oven manuals

Sharp
Sharp R-937 User manual

Sharp
Sharp R-320CD User manual

Sharp
Sharp Carousel R-1514 User manual

Sharp
Sharp R-84A0STV User manual

Sharp
Sharp Carousel SMO1652DS User manual

Sharp
Sharp R-634 Instruction Manual

Sharp
Sharp YC-MS31E User manual

Sharp
Sharp R-742W User manual

Sharp
Sharp YC-MS02E User manual

Sharp
Sharp R-352M Instruction Manual

Sharp
Sharp R-4H55 User manual

Sharp
Sharp R-67B1S User manual

Sharp
Sharp Carousel R-90GCS User manual

Sharp
Sharp R-757H User manual

Sharp
Sharp R-208 Instruction Manual

Sharp
Sharp R-520LK User manual

Sharp
Sharp R-200J Series User manual

Sharp
Sharp R-3471K User manual

Sharp
Sharp R-25STM Instruction Manual

Sharp
Sharp EBR-4900 Series User manual
