PG-D40W3D
DLP XGA (1280 X 800 PIXEL)
HIGH BRIGHTNESS (4000AL)
3D READY AND PJ LINK
HIGH CONTRAST (2200:1)
WIDE PC INPUT RANGE
VERTICAL KEYSTONE CORRECTION
EASY OPERATION
CONTROL VIA LAN AND RS232
With built-in LAN connectivity (for control applications), BrilliantColor technology and 3D Ready (by TI), Closed Caption, HDMI
input and 4000 ANSI Lumens brightness, the WXGA resolution Sharp PG-D40W3D is perfect for most any educational or
meeting room setting, as well as rental/staging and house of worship applications.

PANEL RESOLUTION
Chip panel size: DMD/0,65"
1-Chip DLP(TI) / 3-Chip DLP(TI) / 3-LCD-Panel: / /
Native Resolution: WXGA 1280x800
UXGA 1.600 x 1.200:
SXGA+ 1.400x1.050:
SXGA 1.280x1.024:
WXGA 1.280 x 800 / 1.360x 768 / 1.366 x 768: / /
XGA 1.024 x 768:
SVGA 800 x 600:
Mac Compatible:
PC-INPUT
H-Frequence (kHz): 15 - 110 KHz
V-Frequence (Hz): 45 - 85 Hz
Pixel Clock (MHz): 12 - 170 MHz
DATA TERMINALS
HDMI:
15 Pin-Sub D (RGB H/V; Y/Ucb/Ucr):
VIDEO TERMINALS
Composite (RCA/BNC):
S-Video (Y/C):
DVI-D/ DVI-I: /
Component (RCA/BNC):
HDMI:
HDCP Compatible:
CONTROL TERMINALS
RS232C (Sub-D):
LAN:
USB-Host:
AUDIO TERMINALS
Mini Jack (3.5 mm) In/Out:
RCA-Stereo Terminal In/Out:
Via HDMI-Terminal:
COLOUR STANDARDS
PAL 60/N/M: / /
SECAM:
NTSC (MHz) 3.58/ 4.43: /
Video Resolution, DTV-Lines / TV-Lines: 600
DTV 480i/480p/540p: / /
576i/576p: /
720p/1.035i: /
1.080i/1.080p: /
PICTURE DATA
Luminance ECO-mode (ANSI Lumen) / Standard (ANSI Lumen): 4000
Contrast: 2200
Projection lamp (W) / Lamp lifetime ECO-Mode (h) / Lamplife Standard (h):
330/3000/2000
Fan: 30 dB ECO/37 dB Standard
Lens built-In / Changeable Lens: /
Zoom-Lens (Manual/ Motorized): /
Zoom-Lens (Focal length, mm): 21 - 24,2
Luminous Intensity (F): 2,5 - 2,7
Lens Ratio (Width to Distance): 1,48 - 1,67
Keystone (manual/auto): /
AUDIO DATA
Audio-Monitor (stereo/mono): /
Output Power (W), RMS: 5
ACCESSORIES
Remote Control / Owners Manual (CD-ROM): /
Power Cable / PC Cable: /
OTHERS
Special Features: BrilliantColor System by TI
Class A: This is a Class A product. In a domestic environment this
product may cause radio interference in which case the user may be
required to take adequate measures.
Power supply (V) / power consumption, standard (W) / power consumption,
ECO (W) / stand-by (W): 100 -240/408 /
Heat Dissipation (BTU / h): ECO-lMode / Standard: /1392
Dimensions in mm (W x H x D): 400x100x335 (main body only)
Weight (kg): 5,8
EAN-code: 4974019659480
