XG-C430X /XG-C330X
True XGA Portable LCD Projectors
High-Brightness, High-Quality Projectors Even in a Compact Body Provide Business Mobility
As Well As Facilitate Network Control and Maintenance for Conference Rooms
© SHARP CORP. (AUG. 2006 PRINT) I 1 E Printed in Japan
SHARP CORPORATION OSAKA, JAPAN
URL http://www.sharp-world.com/
XG-C430X/XG-C330X
Optional Accessories
Dimensions
(Units: mm)
AN-C12MZ
(Wide-zoom lens) AN-C18MZ (Tele-zoom lens) AN-C27MZ (Tele-zoom lens) AN-C41MZ (Tele-zoom lens)
Ceiling Mounts
Cable
Lamp
USB Remote Receiver
Lenses
AN-C3CP2
3-RCA to 15-pin
D-sub cable (3 m)
AN-TK201
For high ceiling
installation
AN-TK202
For standard
ceiling installation
AN-60TK
Installation adaptor
6.0
10
AN-C12MZ
(1.5–1.9:1)
3.0–3.8 m
9.1–12.5 ft
Standard
(1.8–2.1:1)
3.6–4.3 m
11.9–14.1 ft
AN-C27MZ
(3.3–5.1:1)
6.7–10.3 m
22.0–33.1 ft
AN-C41MZ
(5.2–7.2:1)
10.5–14.7 m
34.5–48.4 ft
20
Projection Distances
for a Normal (4:3) 100” Screen (throw ratio)
3.0
30 40
Specifications
XG-C430X XG-C330X
Panels
Number of pixels
Resolution
RGB input signals
Video system
Lens
Projection size
Projection distance
Luminance
Contrast ratio
Audio amplifier
Speakers
Input terminals
Output terminals
Power source
Power consumption
Heat dissipation
Fan noise
Projection lamp
Lamp life
Dimensions (W x H x D)
Weight
Supplied accessories
* Temporary noise may be visible with vertical frequencies above 100 Hz if OSD functions are activated.
Design and specifications are current as of August 2006, but are subject to change without notice.
9.1 12.2
AN-C18MZ
(2.2–2.8:1)
4.5–5.7 m
14.1–18.1 ft
Poly Silicon 0.8” TFT LCD x 3 with Micro Lens
4,000 ANSI lumen (Eco/Quiet Mode off)/ 3,200 ANSI lumen (Eco/Quiet Mode on)
450:1
Poly Silicon 0.8” TFT LCD x 3
3,300 ANSI lumen (Eco/Quiet Mode off)/ 2,640 ANSI lumen (Eco/Quiet Mode on)
600:1
Model
15.2 (m)
50 (ft)
786,432 dots (1,024 x 768)
700 TV lines (DTV 720P input)
SXGA+/SXGA/WXGA/Mac 21” (in intelligent compression), XGA, SVGA, VGA, PC-98, VESA, Mac 19”/16”/13”,
15–70 kHz (horizontal), 43–85 Hz* (vertical), 12–108 MHz (pixel clock) (plug & play VESA; DDC 1/2B)
NTSC 3.58/NTSC 4.43/PAL/PAL (60 Hz)/PAL-M/PAL-N/SECAM/DTV (480I/480P/540P/576I/576P/720P/1035I/1080I)
1:1.2 manual zoom and focus
40” (102 cm) to 500” (1,270 cm)
40” (102 cm): 1.4–1.7 m, 100” (254 cm): 3.6–4.3 m, 500” (1,270 cm): 17.9–21.4 m
2 W (mono)
3.6 cm (round) x 1
Computer RGB/component x 2 (15-pin mini D-sub), DVI-DIGITAL x 1, audio x 2 (3.5-mm stereo mini jack), S-video x 1 (4-pin mini DIN), video x 1 (RCA),
audio L/R mono mixing x 2 (RCA), USB x 1, RS-232C serial port x 1 (9-pin mini DIN), LAN x 1 (RJ-45), wired remote control x 1 (3.5-mm mini jack)
Computer RGB/component x 1 (15-pin mini D-sub), audio L/R x 1 (3.5-mm stereo mini jack)
AC 100–240 V, 50/60 Hz (Multi-Voltage)
360 W (Eco/Quiet Mode off), 300 W (Eco/Quiet Mode on), 6 W (Standby) with AC 100 V
345 W (Eco/Quiet Mode off), 285 W (Eco/Quiet Mode on), 8 W (Standby) with AC 240 V
1,350 BTU/hour (Eco/Quiet Mode off), 1,125 BTU/hour (Eco/Quiet Mode on) with AC 100 V
1,295 BTU/hour (Eco/Quiet Mode off), 1,070 BTU/hour (Eco/Quiet Mode on) with AC 240 V
36 dB (Eco/Quiet Mode off), 31 dB (Eco/Quiet Mode on)
275 W AC
2,000 hours (Eco/Quiet Mode off), 3,000 hours (Eco/Quiet Mode on)
326 x 101.5 x 279.5 mm (main body only)
328.5 x 126.5 x 292 mm (including adjustment foot and projecting parts)
4.9 kg
Remote control, Two R-6 batteries (AA size, UM/SUM-3, HP-7 or similar), RGB cable (3.0 m), Lens cap, Lens cap strap,
Power cord (1.8 m), DIN-D-sub RS-232C adaptor (15 cm), Storage case, Operation manual
AN-MR2
AN-C430LP
The product pictured is the XG-C430X, which is identical in appearance to the XG-C330X
with the exception of the model number indication.
279.56.5
326 88.5
101.5
25
148148 74.5
76.5 50 6

XG-*** ********* *********** ***************** *******
XG-*** ********* *********** ***************** *******
XG-*** ********* *********** ***************** *******
Compact and
High-Brightness Performance in Such a Compact Body
4,000 ANSI Lumen (XG-C430X)/3,300 ANSI Lumen (XG-C330X)
High Brightness
Sharp’s optoelectronics technology in a three-LCD projection system
maximizes light output. This technology provides efficient 4,000 ANSI
lumen brightness, delivering a
bright, easy-to-see image even
in large, brightly lit rooms.
A Wide Variety of Interfaces Security and Safety (Notevision Security Pack)
Notevision Lockdown Function
The optical unit provides a solid mounting point for ceiling mount
hardware, and the joint area is reinforced by a metal plate. A strong
mount deters theft.
Variety of Interfaces
With a DVI digital terminal compatible with conventional players
and computers, the XG-C430X and the XG-C330X are equipped with
various video inputs, including composite inputs and four discrete
stereo audio inputs.
Easy Setting
Flexible Presentation
쎲Auto Keystone Correction
Automatically adjusts projected images to compensate for distortion.
쎲New Tilt Leveler
Easily levels tilted
images.
Four Optional Lenses and Easy Replacement System
The projector may be used with four optional interchangeable
lenses to meet a wide variety of applications and projection
situations. The lenses cover projection distances from 9.11 ft (3.0 m)
to 48.4 ft (14.7 m) for a 100” screen.
And, it is amazingly easy to change lenses. Just detach the cover
and turn the lever. Anytime you enter a new presentation venue,
you can simply relax and quickly change to the lens which best
suits your projection conditions
such as the room size,
projection distance and
projected picture size.
Side Access Lamp and Filter
The lamp and filter in the XG-C430X and the XG-C330X can be
easily replaced while the projector is on a tabletop or when even
ceiling mounted.
쎲Mouse Control
The computer mouse function enables a projector to be controlled
remotely using a built-in USB terminal. In addition, by using an
optional AN-MR2 remote IR receiver, even when the projector is
mounted on a desktop or ceiling and regardless of USB cable length.
Useful Features
Direct Power Off Function
The Direct Power Off function provides convenience for a variety of
applications by keeping the cooling fan operating even after the
power supply has been turned off. This lets users immediately unplug
the projector and take it from the location because there is no need to
wait for the projector to cool down. Along with Direct Power Off, the
Direct Power On function also helps control the power simultaneously
for multiple projectors by using the room’s primary power switch.
31dB Low Fan Noise (Eco Quiet Mode On)
Use of separate cooling systems for each RGB LCD panel achieves
low fan noise.
Eco Quiet Mode Direct Button
Eco Quiet Mode extends the LCD and lamp life and reduces fan noise.
With the Direct Buttons built into both the projector and the remote
control, this mode can be conveniently turned on or off at any time.
High-Brightness, High-Quality Performance in a Compact and Lightweight Body
with Ease of Operation, Maintenance and Network Controls
When a projector is subjected to a force of 7,000 N (714 kgf)
The conventional model is damaged. The XG-C430X and XG-C330X remain undamaged.
Compact and Lightweight Body
Sharp’s optical mechanism achieves an amazingly compact,
lightweight body, which can be carried easily, while the recessed
lens provides extensive protection against accidental damage.
SHARP Unique Network System
Remote Access for Control and Adjustment
Projector control functions,
including power on, input select,
volume, and AV mute, can be
controlled and adjusted by a
computer even in another room.
Diagnosis and Auto Email Alert
Email is automatically sent to
appointed addresses when
detecting an error message,
such as the lamp going out,
unusual heating or cooling fan
breakdown.
Link to a Specific Website for Service and Support
The projector can be registered to a specific website for
maintenance service and support. For example, the projector can
send an error message, such as to notify that the lamp is burnt out,
to a web address automatically
selected. The address accessed
for maintenance is also shown
on the display.
Remote Access for Multiple and Group Projector Control
A management computer can
control multiple projectors
simultaneously.
Periodic/Error Diagnosis and Auto Email Alert
The Display Manager sends
periodic reports and an error
message as well as directly
adjusts the projector gamma
values and other projector
conditions.
Theft Detection and Message
(Network Surveillance System)
A warning message will appear on the
screen of a computer when projector cables
are disconnected.
A greater variety of network projector control options can be
used when the Sharp Display Manager* is installed on the
main computer.
* Sharp Display Manager can be downloaded from the Sharp Global Home Page for free.
Sharp Global Homepage URL: http://sharp-world.com/projector
Web Browser Control Control with Downloadable Display Manager
Compact and
Lightweight
Lightweight
Web browser control enables remote access and
management of the projector by utilizing built-in firmware
without the need for additional special software.
Management PC
Maintenance Service Provider
Internet
LAN
e-mail
CAUTION received!
High
Temperature!
7,000 N
Room A
Room B
Easy Operation and Installation
쎲System Lock Function with Key Code Startup
쎲Network Surveillance System
쎲Kensington Lock
PJLink™ Capability
The XG-C430X and XG-C330X are compatible with devices that support PJLink™,
enabling systems to be easily built for centralized management and operation
using a controller.
For additional information about the PJLink™, visit http://pjlink.jbmia.or.jp/english/
Control System Compatibility
The XG-C430X and XG-C330X provides superior compatibility
with various control systems such as Crestron, AMX and Extron.
