SOUND BAR SYSTEM

MODEL

HT-SB200

OPERATION MANUAL

Thank you for purchasing this SHARP product.

To obtain the best performance from this product, please read this

manual carefully. It will guide you in operating your SHARP product.

Accessories

Please confirm that only the following accessories are included.

Remote control x 1

(RRMCGA177AWSA)

RCA cable (2 pins - 2 pins) x 1

(QCNWGA041AWPZ)

( Spike + Nut ) x 4

Nut

(CLEGMA004AW01, Length: 30 mm)

AC/DC adaptor x 1

(RADPAA061AWZZ)

AC power cord x 1

(QACCDA005AWZZ)

Wall mount angle x 2

(LANGKA167AWFW)

Foot cushion x 4

(PCUSSA118AWZZ) Pattern paper x 1

(TCAUHA022AWZZ)

Spike x 4

(CLEGMA005AW01, Length: 25 mm)

Note:

This product is recommended for ﬂat panel TV

(LCD and plasma).

is a trademark of SRS Labs, Inc.

WOW HD technology is incorporated under license from

SRS Labs, Inc.

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

Important Instruction

SPECIAL NOTES

NOTE

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses,and can radiate

radio frequency energy and, if not installed and used

inaccordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

●

Reorient or relocate the receiving antenna.

●

Increase the separation between the equipment and receiver.

●

Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

●

Consult the dealer or an experienced radio/TV technician for

help.

WARNING

●

FCC Regulations state that any unauthorized changes or

modiﬁcations to this equipment not expressly approved by

the manufacturer could void the user's authority to operate

this equipment.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

Explanation of Graphical Symbols:

The lightning ﬂash with arrowhead

symbol, within an equilateral triangle, is

intended to alert the user to the

presence of uninsulated “dangerous

voltage” within the product’s enclosure

that may be of sufﬁcient magnitude to

constitute a risk of electric shock to

persons.

The exclamation point within an

equilateral triangle is intended to alert

the user to the presence of important

operating and maintenance (servicing)

instructions in the literature accompan-

ying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

FOR YOUR RECORDS

For your assistance in reporting this unit in case of loss or

theft, please record below the model number and serial

number whichare located on the rear of the unit. Please retain

this information.

Model number ........................................................

Serial number ........................................................

Date of purchase ........................................................

Place of purchase ........................................................

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

Important Instruction

IMPORTANT SAFETY INSTRUCTIONS

Electricity is used to perform many useful functions, but it can

also cause personal injuries and property damage if improperly

handled. This product has been engineered and manufactured

with the highest priority on safety. However, improper use can

result in electric shock and/or ﬁre. In order to prevent potential

danger, please observe the following instructions when

installing, operating and cleaning the product. To ensure your

safety and prolong the service life of this product, please read

the following precautions carefully before use.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance

with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliﬁers)

that produce heat.

9) Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided plug

does not ﬁt into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

11) Only use attachments/accessories speciﬁed by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or

table speciﬁed by the manufacturer, or sold with

the apparatus. When a cart is used, use

caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when

unused for long periods of time.

14) Refer all servicing to qualiﬁed service personnel. Servicing

is required when the apparatus has been damaged in any

way, such as power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

Additional Safety Information

15) Power Sources - This product should be operated only from

the type of power source indicated on the marking label. If

you are not sure of the type of power supply to your home,

consult your product dealer or local power company. For

product intended to operate from battery power, or other

sources, refer to the operating instructions.

16) Overloading - Do not overload wall outlets, extension cords,

or integral convenience receptacles as this can result in a

risk of ﬁre or electric shock.

17) Object and Liquid Entry - Never push objects of any kind into

this product through openings as they may touch dangerous

voltage points or short-out parts that could result in a ﬁre or

electric shock. Never spill liquid of any kind on the product.

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

Important Instruction

IMPORTANT SAFETY INSTRUCTIONS (continued)

18) Damage Requiring Service - Unplug this product from the

wall outlet and refer servicing to qualiﬁed service personnel

under the following conditions:

a) When the AC cord or plug is damaged,

b) If liquid has been spilled, or objects have fallen into the

product,

c) If the product has been exposed to rain or water,

d) If the product does not operate normally by following

the operating instructions. Adjust only those controls

that are covered by the operating instructions as an

improper adjustment of other controls may result in

damage and will often require extensive work by a

qualiﬁed technician to restore the product to its normal

operation,

e) If the product has been dropped or damaged in any

way, and

f ) When the product exhibits a distinct change in

performance - this indicates a need for service.

19) Replacement Parts - When replacement parts are required,

be sure the service technician has used replacement parts

speciﬁed by the manufacturer or have the same

characteristics as the original part. Unauthorized

substitutions may result in ﬁre, electric shock, or other

hazards.

20) Safety Check - Upon completion of any service or repairs to

this product, ask the service technician to perform safety

checks to determine that the product is in proper operating

condition.

21) Wall or ceiling mounting - When mounting the product on a

wall or ceiling, be sure to install the product according to the

method recommended by the manufacturer.

22) Power Lines - An outside antenna system should not be

located in the vicinity of overhead power lines or other

electric light or power circuits, or where it can fall into such

power lines or circuits. When installing an outside antenna

system, extreme care should be taken to keep from touching

such power lines or circuits as contact with them might be

fatal.

23) Outdoor Antenna Grounding - If an outside antenna or cable

system is connected to the product, be sure the antenna or

cable system is grounded so as to provide some protection

against voltage surges and built-up static charges.

Article810 of the National Electrical Code, ANSI/NFPA 70,

provides information with regards to proper grounding of the

mast and supporting structure, grounding of the lead-in wire

to an antenna discharge unit, connection to grounding

electrodes, and requirements for the grounding electrode.

24) Protective Attachment Plug - The product is equipped with

an attachment plug having overload protection. This is a

safety feature. See Instruction Manual for replacement or

resetting of protective device. If replacement of the plug is

required, be sure the service technician has used a

replacement plug speciﬁed by the manufacturer that has the

same overload protection as the original plug.

25) Stand - Do not place the product on an unstable cart, stand,

tripod or table. Placing the product on an unstable base can

cause the product to fall, resulting in serious personal

injuries as well as damage to the product. Use only a cart,

stand, tripod, bracket or table recommended by the

manufacturer or sold with the product. When mounting the

product on a wall, be sure to follow the manufacturer's

instructions. Use only the mounting hardware

recommended by the manufacturer.

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

General Information

Notes

Features

Supply of this product does not convey a license nor imply any

right to distribute content created with this product in revenue-

generating broadcast systems (terrestrial, satellite, cable and/or

other distribution channels), revenue-generating streaming

applications (via Internet, intranets and/or other networks), other

revenue-generating content distribution systems (pay-audio or

audio-on-demand applications and the like) or on revenue-

generating physical media (compact discs, digital versatile

discs, semiconductor chips, hard drives, memory cards and the

like). An independent license for such use is required. For

details, please visit http://mp3licensing.com

MPEG Layer-3 audio coding technology licensed from

Fraunhofer IIS and Thomson.

Contents

Page

■

General Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Controls and indicators . . . . . . . . . . . . . . . . . . 7 - 9

■

Preparation for Use

Speaker preparation . . . . . . . . . . . . . . . . . . . 10 - 12

Placing the speaker. . . . . . . . . . . . . . . . . . . . . . . . 13

Falling prevention . . . . . . . . . . . . . . . . . . . . . . . . . 13

Speaker connections to TVs . . . . . . . . . . . . . . . . 14

AC power connection . . . . . . . . . . . . . . . . . . . . . . 15

Remote control . . . . . . . . . . . . . . . . . . . . . . . 15 - 16

■

Basic Operation

General control . . . . . . . . . . . . . . . . . . . . . . . 16 - 17

■

References

Troubleshooting chart . . . . . . . . . . . . . . . . . . . . 18

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Error indicators and warnings . . . . . . . . . . . . . . . 19

Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

CONSUMER LIMITED WARRANTY . . . Back cover

ENERGY STAR®Program Information

ENERGY STAR®isa U.S. registered mark.

Productsthat have earned

the ENERGY STAR® are

designed to protect the

environment through

superior energy efficiency.

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

General Information

Precautions

■

General

●

Please ensure that the equipment is positioned in a well-

ventilated area and ensure that there is at least 4" (10 cm) of

free space along the sides and top of the equipment.

●

Use the speaker on a ﬁrm, level surface free from vibration.

●

Keep the speaker away from direct sunlight, strong magnetic

ﬁelds, excessive dust, humidity and electronic/electrical

equipment (home computers, facsimiles, etc.) which

generate electrical noise.

●

Do not place anything on top of the speaker.

●

Do not expose the speaker to moisture, to temperatures

higher than 140˚F (60˚C) or to extremely low temperatures.

●

If your system does not work properly, disconnect the AC

power cord from the AC outlet. Plug the AC power cord back

in, and then turn on your system.

●

In case of an electrical storm, unplug the speaker for safety.

●

Hold the AC power plug by the head when removing it from

the AC outlet, as pulling the cord can damage internal wires.

●

The AC power plug is used as a disconnect device and shall

always remain readily operable.

●

Do not remove the outer cover, as this may result in

electric shock. Refer internal service to your local

SHARP service facility.

●

This speaker should only be used within the range of

41˚F - 95˚F (5˚C - 35˚C).

Warning:

●

The voltage used must be the same as that speciﬁed on this

speaker. Using this product with a higher voltage other than

that which is speciﬁed is dangerous and may result in a ﬁre

or other type of accident causing damage. SHARP will not be

held responsible for any damage resulting from use of this

speaker with a voltage other than that which is speciﬁed.

●

The supplied AC/DC adaptor contains no user serviceable

parts. Never remove covers unless qualiﬁed to do so.

It contains dangerous voltages, always remove mains plug

from the main outlet jack before any service operation or

when not in use for a long period.

●

The AC/DC adaptor supplied with the HT-SB200 must not be

used with other equipment.

●

Never use an AC/DC adaptor other than the one speciﬁed.

Otherwise, problem or serious hazards may be created.

■

Volume control

The sound level at a given volume setting depends on speaker

efﬁciency, location, and various other factors. It is advisable to

avoid exposure to high volume levels, which occurs while

turning the speaker on with the volume control setting up high,

or while continually listening at high volumes.

4" (10 cm)

4" (10 cm) 4" (10 cm)

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

General Information

Controls and indicators

■

Front Panel

Reference page

1. Sport Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2. Standard Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . 17

3. Information Display. . . . . . . . . . . . . . . . . . . . . . . . . 16

4. Cinema/Game Indicator . . . . . . . . . . . . . . . . . . . . . 17

5. News Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

6. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . 16

7. Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . 16

8. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Reference page

9. Surround Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

10. Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

11. Remote Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

12. Left Front Speaker

13. Bass Reﬂex Duct

14. Subwoofers

15. Right Front Speaker

STANDARD

SPORT

SOUND BAR SYSTEM HT-S8200

VOL.

SURROUND FUNCTION

CINEMA / GAME

NEWS

ON/STAND-BY

6 7 89 10 11

12 13131514 14

451

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

General Information

Controls and indicators (continued)

■

Rear Panel

Reference page

1. Audio Line In 2 Jack . . . . . . . . . . . . . . . . . . . . . . . . 14

2. Line In 1 Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3. DC Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

LEFTRIGHT

LINE IN 1LINE IN 2

123

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

General Information

Note:

Before using remote control, please remove plastic shield at

battery holder.

■

Remote Control

Reference page

1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . 16

2. Cinema/Game Button. . . . . . . . . . . . . . . . . . . . . . . . 17

3. Standard Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5. Subwoofer Level Down Button . . . . . . . . . . . . . . . . 17

6. Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . . 16

7. Bass/Treble Button. . . . . . . . . . . . . . . . . . . . . . . . . . 17

8. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 16

9. Sport Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

10. News Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

11. Subwoofer Level Up Button . . . . . . . . . . . . . . . . . . 17

12. Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

13. Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

14. Line Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

15. TV Operation Buttons . . . . . . . . . . . . . . . . . . . . . . . . 9

Notes:

●

Some models of SHARP TV may not be operable.

●

SHARP TV remote will not work with HT-SB200 system.

Remote

control Plastic shield

Battery holder

TV Operation Buttons (Only SHARP TV):

On/Stand-by

Button

Sets the TV

power to “ON”

or “STAND-

BY”.

Input Select

Button (TV)

Press the

button to

switch the

input source.

Volume Up

and Down

Buttons

Turn up/down

the TV

volume.

Channel Up

and Down

Buttons

Switch up/

down the TV

channels.

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

Preparation for Use

Speaker preparation

Select from three installation methods according to the

preferred position.

Notes:

●

Option 1 or option 2 indicates spike positions based on LCD

TV stand.

●

When attaching the spikes, place the speaker on a cushion

or soft cloth to avoid damage.

Caution:

When using these spikes on glossy or slippery table such as on

glass top, stick foot cushions at the bottom of the spikes to avoid

slippage.

Note:

Option 1 or option 2 foot cushion positions based on LCD TV

stand.

Make sure to unplug the AC power cord before installing

the speaker or changing the position.

Tighten all spikes as shown

Option 2 Option 1

Using spikes

You may choose from the two different spike lengths provided:

25 mm and 30 mm.

Nuts (secured on 30 mm spikes) must be used when installing

either the 25 mm or 30 mm spikes.

The speaker can be leveled by adjusting the spikes and nuts.

Attach foot cushions as shown

Option 1

Using foot cushions

Option 2

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

Preparation for Use

Caution:

●

Be very careful to prevent the speaker [3.86 lbs. (1.75 kg)]

from falling when mounting on the wall.

●

Before mounting, check the wall strength. (Do not put on the

veneer plaster or whitewashed wall. The speaker may fall.) If

unsure, consult a qualiﬁed service technician.

●

Mounting screws are not supplied. Use appropriate ones.

●

Check all wall mount angle screws for looseness.

●

Select a good location. If not, accidents may occur or the

speaker may get damaged.

●

SHARP is not responsible for accidents resulting from

improper installation.

■

Driving screws

SHARP designed the speakers so you may hang them on the

wall. Use proper screws (not supplied). See below for size and

type.

■

Wall mount angle ﬁxed to the wall

(Horizontal position)

To mount the speaker on the wall

1/8" (3.2 mm)

3/8" (9 mm)

Min. 7/8" (22 mm)

3/16"

(5 mm)

Fix the pattern paper to the wall in horizontal position

as below.

Make a hole on the wall following the screw point

marks on the pattern paper by using a drill.

Fix a wall mount plug into the hole using a hammer,

until it is ﬂush with the wall surface.

29 mm

44 mm

509 mm

Pattern paper

Wall surface

3/8" (8-9 mm)

1-1/4" (32 mm)

Wall surface

3/8" (8-9 mm)

1-1/4" (32 mm)

Continued to the next page

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

Preparation for Use

Speaker preparation (continued)

Note:

Make sure all screws are fully tighten. (screws are not supplied)

■

Installing the speaker

Screw the wall mount angle to the wall as shown in the

illustration. (Total screw is 8 pieces)

Wall surface

Wall mount angle

Wall surface

Wall mount angle

(screws x 4)

Align the wall mount slot at the speaker to the wall

mount angle.

Slot the speaker into the wall mount angle.

Fix them securely.

Wall surface

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

Preparation for Use

Placing the speaker

Installation image:

Place the speaker as shown.

Notes:

●

As the sound from the speaker is omni-directional, you can

place the speaker anywhere you like. However, it is

recommended to place it as close to the TV as possible.

●

The front panel of the speaker is not removable.

Caution:

●

Do not change the installation direction when the speaker is

turned on.

●

Do not stand or sit on the speaker as you may be injured.

Falling prevention

Safety wires (not supplied) are useful to prevent the speaker

from falling off the table.

Loop the safety wires (not supplied) into each hole as shown

and tie the safety wires to the LCD TV stand.

VCR DVD player

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

Preparation for Use

Speaker connections to TVs

Caution:

Turn off all other equipment before making any connections.

Tuner receiving for other audio system

●

Placing the antenna near the speaker AC power cord may

cause noise pick up. Place the antenna away from the

speaker for better reception.

Notes:

●

To connect to TV, use either LINE IN 1 jacks or AUDIO LINE

IN 2 jack only.

●

Refer the operation manual of the equipment to be

connected.

●

Fully insert the plugs to avoid fuzzy pictures or noises.

■

Connecting to a TV

If the TV/monitor has an audio output, connect it to the LINE IN

1 jacks on the rear of the speaker.

■

Connecting to a TV (with Headphone jack)

If the TV/monitor has headphone jack, connect it to the AUDIO

LINE IN 2 jack on the rear of the speaker.

Notes:

●

If the TV volume is continuously in low level, the speaker will

automatically power off. Increase the TV output volume to

enjoy the sound from the speaker.

●

If the speaker volume is continuously in very high level, the

speaker will mute and recover after 3 seconds.

RIGHT LEFT

LINE IN 1

LINE IN 2

To audio output jacks

RCA cable (supplied)

Speaker

To LINE IN 1

jacks

RIGHT LEFT

HEADPHONE

LINE IN 1LINE IN 2

To HEADPHONE jack

Audio cable

(3.5 mm/stereo jack)

(not supplied)

Speaker

To AUDIO

LINE IN 2 jack

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

Preparation for Use

AC power connection

After checking all the connections have been made correctly,

connect the AC power cord to the AC power input jack, then to

the AC outlet.

■

Using with the AC/DC adaptor

Notes:

●

Unplug the AC/DC adaptor from the AC outlet if the speaker

will not be used for a long period of time.

●

Use only the supplied AC/DC adaptor. Using other AC/DC

adaptor may cause an electric shock or ﬁre.

Remote control

■

Battery installation

This product contains a CR Coin Lithium Battery which contains

Perchlorate Material – special handling may apply, California

residents, see www.dtsc.ca.gov/hazardouswaste/perchlorate/

Precautions for battery use:

●

Remove the battery if the speaker will not be used for a long

period of time. This will prevent potential damage due to

battery leakage.

Plug the AC power cord into the AC/DC adaptor.

Plug the AC/DC adaptor cable into the DC IN jack on

the speaker.

Plug the AC power cord into an AC outlet. The STAND-

BY indicator will turn RED when AC power is applied.

The power indicator will turn GREEN when the system

in “ON”.

RIGHT LEFT

LINE IN 1LINE IN 2

INPUT

AC/DC Adaptor Cable

DC IN jack

(DC 12V)

AC/DC Adaptor

AC Outlet

(AC 100 - 240 V ~ 50/60 Hz)

AC power cord

Insert pin into the hole as shown and pull to open the

battery holder.

Remove the old battery from the battery holder, insert

the new battery and then slide the battery holder back

into the remote control.

Back of

remote control

Battery holder

Polarity (+) symbol

Battery type

Locking tab Positive (+) side up

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

Preparation for Use

Remote control (continued)

Caution:

●

Do not use rechargeable battery (nickel-cadmium battery, etc.).

●

Danger of explosion if battery is incorrectly replaced.

●

Replace only with the same or equivalent type.

●

Batteries (battery pack or batteries installed) shall not be

exposed to excessive heat such as sunshine, ﬁre or the like.

●

Installing the battery incorrectly may cause the speaker to

malfunction.

Notes concerning use:

●

Replace the battery if the operating distance is reduced or if

the operation becomes erratic. Purchase “CR 2025”, coin

lithium battery.

●

Periodically clean the transmitter on the remote control and

the sensor on the speaker with a soft cloth.

●

Exposing the sensor on the speaker to strong light may

interfere with operation. Change the lighting or the direction

of the speaker if this occurs.

●

Keep the remote control away from moisture, heat, shock,

and vibrations.

■

Test of the remote control

Point the remote control directly at the remote sensor on the

speaker

The remote control can be used within the range shown

below:

Press the ON/STAND-BY button. Does the power turn on? Now,

you can enjoy your system.

General control

■

To turn the power on

Press the ON/STAND-BY button.

●

The power indicator turns green. If the power does not turn

on, check whether the power cord is plugged in properly.

To set the speaker to stand-by mode:

●

Press the ON/STAND-BY button again.

The STAND-BY indicator turns red.

■

Display brightness control

Press the DIMMER button to adjust the brightness of the display

and sound mode indicator.

■

Volume auto fade-in

If you turn off and on the speaker with the volume set to 40 or

higher, the volume starts at 20 and fades in to the last set level.

■

Volume control

STANDARD

SPORT

SOUNDBAR SYSTEM HT-SB200

VOL.

SURROUND FUNCTION

CINEMA / GAME

NEWS

ON/STAND-BY

15˚ 15˚

Remote sensor

8” - 20’

(0.2 m - 6 m)

Speaker operation:

Press volume up (VOL. +) to increase

the volume and press volume down

(VOL. –) to decrease the volume.

STANDARD

SPORT

SOUND BAR SYSTEM HT-SB200

VOL.

SURROUND FUNCTION

CINEMA / GAME

NEWS

ON/STAN D- BY

Sound mode indicator and display bright

Sound mode indicator and display dim

Sound mode indicator and display off. Pressing

any buttonwill li

ht up the display for 3secondsonly.

00 01 02 ..... 59 60

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

Basic Operation

Remote control operation:

Press the VOLUME + button to increase the volume and the

VOLUME – button to decrease the volume.

■

Preset sound mode

Main unit operation:

When the SURROUND button is pressed, the current mode

setting will light up. To change to a different mode, press the

SURROUND button repeatedly until the desired sound mode

lights up.

Remote control operation:

Press a desired sound mode on the remote control.

■

Subwoofer level control

Note:

When sound from the speaker is distorted, decrease the

subwoofer level.

■

Bass control

■

Treble control

■

Function

Note:

The backup function will protect the memorized function mode

for a few hours should there be a power failure or the AC power

cord becomes disconnected.

Auto power on function:

When you press the LINE button on the remote control, the

speaker will turns on at last function.

Auto power off and auto detect signal:

The speaker will automatically power off after 1 minute of

inactivity. The STAND-BY indicator turns orange. At this point,

it will automatically power ON if it detects audio signal from

connected equipment.

■

Muting

The volume is muted temporarily when pressing

the MUTE button on the remote control. Press

again to restore the volume.

The speaker level can be adjusted.

To increase

the level, press the

SUBWOOFER LEVEL button.

To decrease

the level, press the

SUBWOOFER LEVEL button.

NEWS

WOW HD off

WOW HD onfor cinema/game sound effect

WOW HD onfor news

WOW HD onfor sport broadcasting

STANDARD

CINEMA/GAME

NEWS

SPORT

STANDARD

SPORT

CINEMA/GAME

-5 -4 ... 4 5

1. Press the BASS/TREBLE button

to select “BASS”.

2. Within 5 seconds, press the

VOLUME (+ or –) button to adjust

the bass.

1. Press the BASS/TREBLE button

to select “TREBLE”.

2. Within 5 seconds, press the

VOLUME (+ or –) button to adjust

the treble.

When the FUNCTION button on

speaker or LINE button on the remote

control is pressed, the input source

will change. Press the FUNCTION

button on speaker or LINE button on

the remote control repeatedly to

select desired input source.

-5 +5

LINE 1

LINE 2

HT-SB200

2008 December 24

HT-SB200_A6_EN.fm

References

Troubleshooting chart

Many potential problems can be resolved by the owner without

calling a service technician.

If something is wrong with this product, check the following

before calling your authorized SHARP dealer or service center.

■

General

■

Remote control

■

Condensation

Sudden temperature changes, storage or operation in an

extremely humid environment may cause condensation inside

the cabinet or on the transmitter on the remote control.

Condensation can cause the speaker to malfunction. If this

happens, leave the power on until normal operation is possible

(about 1 hour). Wipe off any condensation on the transmitter

with a soft cloth before operating the speaker.

■

If problem occurs

When this product is subjected to strong external interference

(mechanical shock, excessive static electricity, abnormal

supply voltage due to lightning, etc.) or if it is operated

incorrectly, it may malfunction.

If such a problem occurs, do the following:

Set the

speaker

to the stand-by mode and turn the power on

again.

2. If the speaker is not restored in the previous operation,

unplug and plug in the speaker, and then turn the power on.

Symptom Possible cause

No sound is heard.

●

Is the input signal (selection) set

properly?

●

Is the volume level set to “0”?

Noise is heard

during playback.

●

Move the speaker away from any

computers or mobile phones.

When a button is

pressed, the

speaker does not

respond.

●

Set this speaker to the stand-by

mode and then turn it back on.

The power is not

turned on.

●

Is the speaker unplugged? (Refer to

page 15)

●

The protection circuit may be

activated. Unplug and plug in the

power cord again after 5 minutes or

more.

Symptom Possible cause

The remote control

does not operate

properly.

●

Is the battery polarity correct?

●

Is the battery dead?

●

Is the distance or angle incorrect?

●

Are there any obstructions in front of

the speaker?

●

Is there a strong light shining on the

remote sensor?

●

Is the remote control for another

equipment used simultaneously?

Symptom Possible cause

The speaker cannot

be turned on with

the remote control.

●

Is the AC power cord of the speaker

plugged in?

●

Is the battery inserted?

TV cannot be

operated with the

remote control.

●

Depending on the model, some or all

functions may not be operable using

the remote control of this speaker. In

this case, use the remote control

supplied with the TV.

HT-SB200

2008 December 24 HT-SB200_A6_EN.fm

References

Maintenance

■Cleaning the cabinet

Periodically wipe the cabinet with a soft cloth.

Caution:

●Do not use chemicals for cleaning (gasoline, paint thinner,

etc.). It may damage the cabinet ﬁnish.

●Do not apply oil to the inside of each component. It may cause

malfunctions.

Error indicators and warnings

When you fail to perform operations properly, the following

messages are displayed on the speaker.

(*): Should the same message appear even if the speaker is

unplugged and plugged in or is set to the stand-by mode and

on again, contact your local dealer where you purchased the

speaker.

Speciﬁcations

As part of our policy of continuous improvement, SHARP

reserves the right to make design and speciﬁcation changes for

product improvement without prior notice. The performance

speciﬁcation ﬁgures indicated are nominal values of production

speaker. There may be some deviations from these values in

individual speaker.

■General

Display Meaning

●Malfunction of the surround

circuit. Place the speaker away

from noise source and plug the

AC power cord into another AC

outlet. (*)

Power indicator (blinks red)

●When the protection circuit of the

ampliﬁer is activated.

Power source DC IN 12V 4A: AC/DC adaptor

(AC 100 - 240 V ~ 50/60 Hz)

Power

consumption

10 W

Maximum output

power

32 W

Speaker 2.1-way Speaker System

Front Speakers: 1-1/2" (38 mm) Full Range

Subwoofer: 2-1/4" (57 mm) Woofer (x4)

Audio output

terminals

Speakers: 12 ohms/channel

Subwoofer: 3 ohms

(12 ohms x 4 parallel connection)

Input terminals Analog input (LINE 1):

RCA type x 1pair (L/R)

500 mV / 47 kohms

Analog input (LINE 2):

Stereo mini jack Ø 3.5 mm

100 mV / 47 kohms

Dimensions Width: 31-1/2" (800 mm)

Height: 3-3/4" (96 mm)

Depth: 2-3/4" (70 mm)

Weight 3.86 lbs. (1.75 kg)

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07495 - 1163

08L R AS 2

CONSUMER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original con-

tainer, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof

with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has

been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in

design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.

The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING

THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW.

Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any

warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser.

Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the

purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event

shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone

other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states
