Sharp CD-BP160W User manual

– 1 –
CD-BP160W/180W/1500W/1700W
No. S4023CDBP1500
CONTENTS Page
SAFETY PRECAUTION FOR SERVICE MANUAL ........................................................................................................... 2
VOLTAGE SELECTION..................................................................................................................................................... 2
SPECIFICATIONS ............................................................................................................................................................. 3
NAMES OF PARTS ........................................................................................................................................................... 4
OPERATION MANUAL ...................................................................................................................................................... 6
DISASSEMBLY.................................................................................................................................................................. 8
REMOVING AND REINSTALLING THE MAIN PARTS................................................................................................... 11
ADJUSTMENT ................................................................................................................................................................. 12
BLOCK DIAGRAM ........................................................................................................................................................... 15
SCHEMATIC DIAGRAM ...................................................................................................................................................18
VOLTAGE ........................................................................................................................................................................ 27
WIRING SIDE OF P.W.BOARD........................................................................................................................................28
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 34
WAVEFORMS OF CD CIRCUIT...................................................................................................................................... 35
TROUBLESHOOTING ..................................................................................................................................................... 36
FUNCTION TABLE OF IC................................................................................................................................................ 40
FL DISPLAY......................................................................................................................................................................46
REPLACEMENT PARTS LIST/EXPLODED VIEW
CD-BP1500W
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
SERVICE MANUAL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CD-BP1500W Mini Component System consisting of
CD-BP1500W (main unit) and CP-BP1500 (speaker system).
SHARP CORPORATION
CD-BP1700W
CD-BP1700W Mini Component System consisting of
CD-BP1700W (main unit), CP-BP1700 (front speaker ) and
GBOXS0041AWM1 (surround speaker).
CD-BP180W
CD-BP180W Mini Component System consisting of
CD-BP180W (main unit), CP-BP180 (front speaker ) and
GBOXS0041AWM1 (surround speaker).
Illustration: CD-BP1500W
CD-BP160W Mini Component System consisting of
CD-BP160W (main unit) and CP-BP160 (speaker system).
CD-BP160W

CD-BP160W/180W/1500W/1700W
– 2 –
SAFETY PRECAUTION FOR SERVICE MANUAL
Precaution to be taken when replacing and servicing the Laser Pickup.
The AEL (Accessible Emission Level) of Laser Power Output for this model is specified to be lower than Class I Requirements.
However, the following precautions must be observed during servicing to protect your eyes against exposure to the Laser beam.
(1) When the cabinet has been removed, the power is turned on without a compact disc, and the Pickup is on a position outer than
the lead-in position, the Laser will light for several seconds to detect a disc. Do not look into the Pickup Lens.
(2) TheLaserPowerOutputofthePickupinsidetheunitandreplacementservicepartshavealreadybeenadjustedpriortoshipping.
(3) No adjustment to the Laser Power should be attempted when replacing or servicing the Pickup.
(4) Under no circumstances look directly into the Pickup Lens at any time.
(5) CAUTION - Use of controls or adjustments, or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
VOLTAGE SELECTION
The voltage selector is located on the AC voltage selector box. If adjustment is necessary, use a screwdriver in order to turn the
selector in either direction unitil the correct voltage figure is displayed in the window next the adjustment screw.
QACCB0008AW00
Figure 2 AC POWER SUPPLY CORD AND PLUG ADAPTOR
QACCE0011AW00
QACCL0002AW00/QACCZ0008AW00
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO
BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
VARNING-OSYNLIG LASERSTRALNING NAR DENNA DEL AR OPPNAD. STIRRA
EJ IN I STRALEN OCH BETRAKTA EJ STRALEN MED OPTISKA INSTRUMENT.
ADVERSEL-USYNLIG LASERSTRALING VED ABNING. SE IKKE IND I
STRALEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO! AVATTAESSA OLET ALTTIINA NAKYMATON LASERSATEILYLLE.
ALA TUIJOTA SATEESEEN ALAKA KATSO SITA OPTISEN LAITTEEN LAPI.
VARNING-OSYNLIG LASERSTRALNING NAR DENNA DEL AR OPPNAD.
STIRRA EJ IN I STRALEN OCH BETRAKTA EJ STRALEN GENOM OPTISKT
INSTRUMENT.
ADVERSEL-USYNLIG LASERSTRALING NAR DEKSEL APNES. STIRR IKKE
INN I STRALEN ELLER SE DIREKTE MED OPTISKE INSTRUMENTER.
CAUTION
●This Mini Component System is classified as a CLASS
1 LASER product.
●The CLASS 1 LASER PRODUCT label is located on the
rear cover.
●Use of controls, adjustments or performance of proce-
dures other than those specified herein may result in
hazardous radiation exposure.
As the laser beam used in this compact disc player is
harmful to the eyes, do not attempt to disassemble the
cabinet. Refer servicing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
92LCORD577B
92LCORDZ1652A
QPLGA0003AWZZ QPLGA0004AWZZ

– 3 –
CD-BP160W/180W/1500W/1700W
●General
Power source: AC 110/127/220/230-240 V,
50/60 Hz
Power consumption: 100 W
Dimensions: Width; 270 mm (10-5/8")
Height; 330 mm (13")
Depth; 355 mm (14")
Weight: 6.7 kg (14.7 lbs.)
●Amplifier section
Output terminals:
(CD-BP160W/1500W) Speakers; 6 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
Input terminals: Video/Auxiliary (audio signal);
500 mV/47 kohms
●Compact disc player section
Type: 3-disc multi-play compact
disc player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A converter: 1-bit D/A converter
Frequency
response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
●Tuner section
Frequency range: FM; 88-108 MHz
AM; 531-1,602 kHz
●Cassette deck section
Frequency response: 50-14,000 Hz (Normal tape)
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2,
recording/playback)
Wow and flutter: 0.3 % (WRMS)
Type: 3-way type [10 cm (4")woofer ×2
and 5 cm (2") tweeter]
Maximum input power: 100 W
Rated input power: 50 W
Impedance: 6 ohms
Dimensions:
(CP-BP160) Width; 220 mm (8-11/16")
Height; 330 mm (13")
Depth; 227 mm (8-15/16")
Weight:
(CP-BP160) 3.0 kg (6.6 lbs.)/each
Output terminals:
(CD-BP180W/1700W) Front speakers; 8 ohms
Surround speakers; 16 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
Type: 3-way type [10 cm (4") woofer×2
and 5 cm (2") tweeter]
Maximum input power: 80 W
Rated input power: 40 W
Impedance: 8 ohms
Dimensions:
(CP-BP180) Width; 231.5 mm (9-1/8")
Height; 330 mm (13")
Depth; 210 mm (8-1/4")
Weight:
(CP-BP180) 3.1 kg (6.8 lbs.)/each
Type: 10 cm (4") full-range speaker
Maximum input power: 30 W
Rated input power: 15 W
Impedance: 16 ohms
Dimensions: Width; 170 mm (6-3/4")
Height; 170 mm (6-3/4")
Depth; 88 mm (3-1/2")
Weight: 0.5 kg (1.0 lbs.)/each
Dimensions:
(CP-BP1700) Width; 240 mm (9-7/16")
Height; 330 mm (13")
Depth; 234 mm (9-9/16")
Weight:
(CP-BP1700) 3.2 kg (7.0 lbs.)/each
Output power:
RMS; 100 W (50 W + 50 W)
(10 % T.H.D.)
RMS; 74 W (37 W + 37 W)
(0.9 % T.H.D.)
MPO; 160 W (80 W + 80 W)
(10 % T.H.D.)
Dimensions:
(CP-BP1500) Width; 231.5 mm (9-1/8")
Height; 330 mm (13")
Depth; 210 mm (8-1/4")
Weight:
(CP-BP1500) 3.1 kg (6.8 lbs.)/each
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
SPECIFICATIONS
CD-BP160W/180W/1500W/1700W CP-BP160/1500
CP-BP180/1700
GBOXS0041AWM1
Specifications for this model are subject to change without
prior notice.

CD-BP160W/180W/1500W/1700W
– 4 –
NAMES OF PARTS
CD-BP160W/180W/1500W/1700W
■Front panel
11. (CD) Disc Tray
12. Extra Bass Indicator
13. FM Stereo Mode Indicator
14. FM Stereo Indicator
15. (CD) Repeat Indicator
16. (CD) Pause Indicator
17. (CD) Play Indicator
18. (CD) Disc Number Indicators
19. (TAPE 2) Record Indicator
10. (CD/TUNER) Memory Indicator
11. (TAPE) Reverse Mode Indicator
12. (TAPE 2) Direction Indicator
13. (TAPE 1) Play Indicator
3 (TAPE 2) Direction Indicator
14. Sleep Indicator
15. Timer Record Indicator
16. Timer Play Indicator
17. Spectrum Analyzer/Volume Level Indicator
18. (CD) Track Down/Review Button
3 (TUNER) Preset Down Button
3 (TAPE 2) Rewind Button
19. (CD) Track Up/Cue Button
3 (TUNER) Preset Up Button
3 (TAPE 2) Fast Forward Button
20. Timer Set Indicator
21. On/Stand-by Button
22. Clock Button
23. Timer/Sleep Button
24. Function Selector Buttons
25. Dimmer Button
26. Volume Up/Down Buttons
27. Equalizer Mode Selector Button
28. Extra Bass/Demo Mode Button
29. (CD) Open/Close Button
30. Headphone Socket
31. Tuning and Time Up/Down Buttons
32. Memory/Set Button
33. (TAPE) Reverse Play Button
34. (CD/TAPE) Stop Button
35. (TAPE 2) Reverse Mode Button
36. (CD) Play/Repeat Button
3 (TAPE 1) Play Button
3 (TAPE 2) Forward Play Button
37. (TAPE 2) Record Pause Button
38. (CD) Disc Skip Button
39. (TAPE 1) Cassette Compartment
40. (TAPE 2) Cassette Compartment
1
23
35 36 37
24
30 33 34
31 32
18 19
20
21
22
25
26
27
29
28
38
67
8
9
45
2
31312 1415
17
16
17
11
10
17
39 40

– 5 –
CD-BP160W/180W/1500W/1700W
■Rear panel
11. AC Voltage Selector
12. AC Power Input Socket
13. FM 75 Ohms Aerial Terminal
14. FM Aerial Earth Terminal
15. AM Loop Aerial Input Socket
16. Span Selector Switch
17. Video/Auxiliary (Audio Signal) Input Sockets
18. Front Speaker Terminals
19. Surround Speaker Terminals
(For 180W/1700W Only)
11. Tweeter
12. Bass Reflex Duct
13. Woofers
14. Speaker Wire
11. Full-Range Speaker
12. Speaker Wire
11. Tweeter
12. Bass Reflex Duct
13. Woofers
14. Speaker Wire
CP-BP180/1500
CP-BP160/1700
GBOXS0041AWM1
6
1
3
4
5
2
7
8
9
1
23
4
1
23
4
1
2

CD-BP160W/180W/1500W/1700W
– 6 –
OPERATION MANUAL
CD-BP160W/180W/1500W/1700W
■ Remote control
15
15
Notes concerning use:
●Replace the batteries if the operating distance is reduced or if
the operation becomes erratic.
●Periodically clean the transmitter LED on the remote control
and the sensor on the main unit with a soft cloth.
●Exposing the sensor on the main unit to strong light may in-
terfere with operation. Change the lighting or the direction of
the unit.
●Keep the remote control away from moisture, excessive heat,
shock, and vibrations.
0.2 m - 6 m
(8" - 20')
RESETTING THE MICROCOMPUTER
Reset the microcomputer under the following conditions:
●To erase all of the stored memory contents (clock and timer
settings, and tuner and CD presets).
●If the display is not correct.
●If the operation is not correct.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the button and the X-BASS/DEMO
button, hold down the ON/STAND-BY button for at least 1
second.
●"CLEAR AL" will appear.
Caution:
●The operation explained above will erase all data stored in
memory including clock and timer settings, and tuner and CD
presets.
X-BASS/
DEMO
ON/
STAND-BY
■Remote control
11. Remote Control Transmitter LED
12. (CD) Disc Skip Button
13. (CD) Clear Button
14. (CD) Memory Button
15. (CD) Random Button
16. (TAPE 2) Record Pause Button
17. (CD) Track Down/Review Button
3 (TUNER) Preset Down Button
3 (TAPE 2) Fast Wind Button
18. (CD) Pause Button
19. (CD) Track Up/Cue Button
3 (TUNER) Preset Up Button
3 (TAPE 2) Fast Wind Button
10. Equalizer Mode Selector Button
11. (TAPE 2) Reverse Play Button
12. (CD/TAPE) Stop Button
13. (CD) Play/Repeat Button
3 (TAPE 1) Play Button
3 (TAPE 2) Forward Play Button
14. Function Selector Buttons
15. On/Stand-by Button
16. Extra Bass Button
17. Volume Up/Down Buttons
1
2
345
67
89
10111213
14
15
16 17

– 7 –
CD-BP160W/180W/1500W/1700W
SETTING THE CLOCK
In this example, the clock is set for the 24-hour (0:00) system.
ON/ STAND-BY
CLOCK
MEMORY/SET
TUNING/ TIME ( )
1
Press the ON/STAND-BY button to enter the stand-by mode.
2
Press the CLOCK button.
3
Within 5 seconds, press the MEMORY/SET button.
4
Press the TUNING/TIME ( or ) button to select the time display mode.
"0:00" → The 24-hour display will appear. (0:00 - 23:59) "AM 0:00" → The 12-hour display will appear. (AM 0:00 - PM 11:59) "AM 12:00" →The 12-hour display will appear. (AM 12:00 - PM 11:59)
●Note that this can only be set when the unit is first installed
or it has been reset.
5
Press the MEMORY/SET button.
6
Press the TUNING/TIME ( or ) button to adjust the hour.
●Press the TUNING/TIME ( or ) button once to advance
the time by 1 hour. Hold it down to advance continuously.
●When the 12-hour display is selected, "AM" will change auto-
matically to "PM".
7
Press the MEMORY/SET button.
8
Press the TUNING/TIME ( or ) button to adjust the minutes.
●Press the TUNING/TIME ( or ) button once to advance
the time by 1 minute. Hold it down to change the time in 5 minute intervals.
●The hour setting will not advance even if minutes advance from
"59" to "00".
9
Press the MEMORY/SET button.
●The clock starts operating from "0" second.
(Seconds are not displayed.) And then the clock display will disappear after a few seconds.
To see the time display: Press the CLOCK button. ●The time display will appear for about 5 seconds.
Note: ●The clock display will flash on and off at the push of the CLOCK
button when the AC power supply is restored after a power failure occurs or after the AC power lead is disconnected. If this happens, follow the procedure below to change the clock time.
To change the clock time: ①
Press the CLOCK button.
②
Within 5 seconds, press the MEMORY/SET button.
③
Perform steps 6 - 9 above.
To change the time display mode: ①
Perform steps 1 - 2 in the section "RESETTING THE MICRO- COMPUTER".
②
Perform steps 1 - 9 above.
(Main unit operation)
AM 12:00AM 0:000:00
2
3
4
7
6
5
8 9
(Continued)
■
AM/FM interval (span)
The International Telecommunication Union (ITU) has established that member countries should maintain either a 10 kHz or a 9 kHz interval between broadcasting frequencies of any AM station. The illustration shows the 9 kHz interval zones (regions 1 and 3), and the 10 kHz interval zone (region 2). Before using the unit, set the SPAN SELECTOR switch (on the rear panel) to AM tuning interval (span) of your area.
To change the tuning zone: 1
Press the ON/STAND-BY button to enter the stand-by mode.
2
Set the SPAN SELECTOR switch to "50/9" for 9 kHz AM interval (50 kHz FM interval), and "100/10" for 10 kHz AM interval (100 kHz FM interval).
3
Whilst pressing down the button and the X-BASS/DEMO button, hold down the ON/STAND-BY button for at least 1 second.
●"CLEAR AL" will appear. Caution: ●The operation explained above will erase all data stored in
memory including clock and timer settings, and tuner and CD presets.
■
Connecting the AC power lead
Check the setting of the AC voltage selector located on the rear panel before plugging the unit into an AC socket. If necessary, adjust the selector to correspond to the AC power voltage used in your area. Selector adjustment: Turn the selector with a screwdriver until the appropriate voltage number appears in the window (110V, 127V, 220V or 230V - 240V AC). Notes: ●Plug the AC power lead into a convenient AC socket, after
any connections.
●Unplug the AC power lead from the AC socket if the unit will
not be in used for a prolonged period of time.
●Never use a power lead other than the one supplied. Use of
a power lead other than the one supplied may cause an electric shock or fire.
●AC Plug Adaptor In areas (or countries) where an AC socket as shown in illustra- tion ②is used, connect the unit using the AC plug adaptor sup- plied with the unit, as illustrated. The AC plug adaptor is not included in areas where the AC wall socket and AC power plug can be directly connected (see illustration ①).
220V
1
2
Note for users in Australia and New Zealand: An AC plug adaptor is not supplied if the lead has an Australian Standard plug.
To an AC socket

CD-BP160W/180W/1500W/1700W
– 8 –
1 Top Cabinet 1. Screw ..................... (A1) x4 8-1
2 Side Panel 1. Screw ..................... (B1) x8 8-1
(Left/right)
3 CD Player Unit/ 1. Turn on the power supply, 8-2
CD Tray Cover open the disc tray, take out the
CD cover, and close. (Note 1)
2. Screw ..................... (C1) x1
3. Hook....................... (C2) x3
4. Hook....................... (C3) x2
5. Socket .................... (C4) x2
4 Rear Panel 1. Screw ..................... (D1) x6 8-2
5 Main PWB 1. Screw ..................... (E1) x5 8-2,9-2
2. Socket .................... (E2) x4 9-2
3. Flat Cable............... (E3) x1
4. Lug Wire................. (E4) x1
5. Flat Wire................. (E5) x1
6 Socket PWB 1. Screw ..................... (F1) x1 9-2
2. Socket .................... (F2) x1
7 Front Panel 1. Screw ..................... (G1) x2 9-2
8 Display PWB 1. Screw ..................... (H1) x15 9-3
2. Flat Cable............... (H2) x1
9 Tape Mechanism 1. Open the cassette holder. 9-3
2. Screw...................... (J1) x6
10 Headphones PWB 1. Screw ..................... (K1) x1 9-3
11 Turntable 1. Hook....................... (L1) x2 9-4
2. Cover ..................... (L2) x1
12 Disc Tray 1. Turn fully the lock lever in the 8-3
arrow direction.
2. While holding the lock lever,rotate 9-1
the cam gear until the cam gear
rib engages with the clamp lever.
3. Push the slide holder backward to 9-5
engage the claw with the groove
and remove it in the direction
of the arrow. .............. (M1) x6
13 CD Servo PWB 1. Screw ..................... (N1) x1 9-6
(Note 2) 2. Hook....................... (N2) x3
3. Socket .................... (N3) x4
14 CD Mechanism 1. Hook....................... (P1) x2 10-1
2. Hook....................... (P2) x3
DISASSEMBLY
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Takeoffnylonbandsorwireholderswheretheyneedto
beremovedwhendisassemblingtheunit.Afterservicing
theunit,besuretorearrangetheleadswheretheywere
before disassembling.
4. Take sufficient care on static electricity of integrated
circuits and other circuits when servicing.
Figure 8-2
Figure 8-3
CD-BP160W/180W/1500W/1700W
STEP REMOVAL PROCEDURE FIGURE
Note 1:
How to open the changer manually. (Fig. 8-3)
1. In this state, turn fully the lock lever in the arrow direction
through the hole on the loading chassis bottom.
2. While holding the lock lever, rotate the cam gear anticlockwise
until the cam gear rib engages with the clamp lever. (Fig. 9-1)
3. After that, push forward the CD slide holder.
Figure 8-1
Note 2:
1.After removing the connector fortheopticalpickup from the
connector, wrap the conductive aluminium foil around the
frontend of the connector to protect the opticalpickup from
electrostatic damage.
Note 3:
1. Be careful not to break the claw of the CD mechanism.
2.Whenfining back the cam gear assembly,letitlock by front
movement.
(B1)x4
ø3x12mm (B1)x2
ø3x10mm
Rear
Panel
(B1)x2
ø3x10mm
Side Panel
(Right)
Side Panel
(Left)
(A1)x2
ø3x12mm
(A1)x2
ø3x12mm Top Cabinet
Front Panel
(E1)x3
ø3x12mm
(C3)x1
(C1)x1
ø3x10mm
(D1)x6
ø3x10mm
CD Player
Unit
CD Tray Cover
Rear
Panel
Pull
(C3) x1
(C4)x2 (C2) x3
1
1
2
Main PWB
CD Servo PWB Disc Tray
Lock Lever
CD-BP160W/180W/1500W/1700W

– 9 –
CD-BP160W/180W/1500W/1700W
Figure 9-2
Figure 9-3
Figure 9-4
Figure 9-5
Figure 9-6
Figure 9-1
Clamp Lever
Cam Gear Rib
(H1)x15
ø3x10mm
(H2)x1
(J1)x6
ø3x10mm
(K1)x1
ø3x10mm
Display PWB
Open
Cassette
Holder(Lift/Right)
Tape
Mechanism
Front Panel
Headphones PWB
Turntable
Disc Tray
(L2) x1
CD Player Unit
(L1) x2
1
2
(M1) x3
(M1) x3
Disc Tray
CD Player Unit
(N3)x2
(N2)x3
(N3)x2
CD Servo
PWB Disc Tray
(N1)x1
ø3x8mm
(G1)x2
ø3x10mm
(E1)x2
ø3x10mm
(E3)x1
(E4)x1
(E2)x2
(E2)x1
Main PWB
(E5)x1
Headphones
PWB
(F1)x1
ø3x10mm
Socket PWB
Front Panel
(F2)x1
(E2)x1
Record/
Playback
PWB
Tape
Mechanism

CD-BP160W/180W/1500W/1700W
– 10 –
CP-BP180/1500
1 Woofer/ 1. Front Panel ............ (A1) x1 10-3
Sub Woofer 2. Screw ..................... (A2) x8
2 Tweeter 1. Screw ..................... (B1) x2 10-3
STEP REMOVAL PROCEDURE FIGURE
Figure 10-2
Figure 10-1
Figure 10-3
(B1)x2
ø3x10mm Tweeter
Speaker Box
(A1) x1
Screw
Driver
Driver should
be pried away
from Speaker
Box.
(A2)x4
ø4x12mm
(A2)x4
ø4x12mm
Sub Woofer
Woofer
(B1)x2
ø3x10mm Tweeter
Speaker Box
Screw
Driver
Driver should
be pried away
from Speaker
Box.
(A2)x4
ø4x12mm
(A2)x4
ø4x12mm
Sub Woofer
Woofer
(A1)x1
(P2)x3
(P1)x1 (P1)x1
CD
Mechanism
Disc Tray
CP-BP1700/160
1 Woofer/ 1. Front Panel ............ (A1) x1 10-2
Sub Woofer 2. Screw ..................... (A2) x8
2 Tweeter 1. Screw ..................... (B1) x2 10-2
STEP REMOVAL PROCEDURE FIGURE

– 11 –
CD-BP160W/180W/1500W/1700W
REMOVING AND REINSTALLING THE MAIN PARTS
TAPE MECHANISM SECTION
Performsteps 1, 2,3,4, 5,7and9 ofthedisassembly method
to remove the tape mechanism.
How to remove the record/playback and erase
heads (Tape 2) (See Fig. 11-1)
1.Carefullyremovetherecord/playbackheadanderasehead
screws (A1) x 2 pcs.
How to remove the playback head (Tape 1)
(See Fig. 11-2)
1. Carefully remove the playback head screws (B1) x 2 pcs.
How to remove the pinch roller (Tape 1/2)
(See Fig. 11-3)
1. Carefully bend the pinch roller pawl in the direction of the
arrow <A>, and remove the pinch roller (C1) x 1 pc., in the
direction of the arrow <B>
Note:
When installing the pinch roller, pay attention to the spring
mounting position.
How to remove the belt (Tape 1) (See Fig. 11-4)
1. Remove the main belt (D1) x 1 pc., from the motor side.
2. Remove the FF/REW belt (D2) x 1 pc.
How to remove the belt (Tape 2) (See Fig. 11-4)
1. Remove the main belt (E1) x 1 pc., from the motor side.
2. Remove the FF/REW belt (E2) x 1 pc.
How to remove the motor (See Fig. 11-5)
1. Remove the screws (F1) x 2 pcs., to remove the motor.
Figure 11-1
Figure 11-2
Figure 11-3
Figure 11-4Figure 11-5
(B1)x2
Ø2 x 9mm
TAPE1
Playback
Head
Pinch Roller
(C1)x1 <A>
Pull
<B>
Pull
Pinch
Roller
Pawl
TAPE2 TAPE1
Main Belt
(D1)x1
TAPE2
Main Belt
(E1)x1
TAPE1
Main Belt
(E1)x1
FF/REW
Belt
(E2)x1
FF/REW
Belt
(D2)x1
Motor
Motor
Main Belt
(D1)x1
(F1) x2
Ø 2.6 x 5mm
Motor
TAPE2
(A1)x2
Ø2 x 6mm
TAPE2
Record/Playback
Head
Erase Head

CD-BP160W/180W/1500W/1700W
– 12 –
How to remove the pickup (See Fig. 12-2)
1.Remove the screws (B1) x 2 pcs., to remove theshaft(B2).
2. Remove the stop washer (B3) x 1 pc., to remove the gear
(B4).
3. Remove the pickup.
Figure 12-2
CD MECHANISM SECTION
Perform steps 1, 2, 3, 11, 12, 13 and 14 of the disassembly
method to remove the CD mechanism.
How to remove the T/T Up/Down motor
(See Fig. 12-1)
1. Bend the hooks (A1) x 5 pcs., to remove the T/T Up/Down
motor.
2. Remove the drive belt (A2) x 1 pc.
Figure 12-1
Note
After removing the connector for the optical pickup from the
connector, wrap the conductive aluminium foil around the
front end of connector to protect the optical pickup from
electrostatic damage.
ADJUSTMENT
MECHANISM SECTION
•Driving Force Check
Torque Meter Specified Value
Play: TW-2111 Tape 1: Over 80 g
Tape 2: Over 80 g
•Torque Check
Torque Meter
Tape 2
Play: TW-2111 30 to 80 g. cm 30 to 80 g.cm
Fast forward: TW-2231 — 70 to 180 g.cm
Rewind: TW-2231 — 70 to 180 g.cm
Specified Value
Tape 1
Specified
Value
Adjusting
Point Instrument Connection
Test Tape
Normal MTT-111 Variable 3,000 ±Speaker
speed Resistor in 30 Hz terminal
motor. (Load
resistance:
6 ohms)
•Tape Speed
Figure 12-3
TAPE MECHANISM
Motor
Variable Resistor in motor
(B1) x2
ø2.6 x6mm
Shaft
(B2) x1
Stop Washer
(B3) x1
Gear
(B4) x1
CD Mechanism
Pickup
(A1)x3
T/T Up/Down Motor
Disc Tray
(A1)x2
Pulley
Drive Belt
(A2) x1
Motor

– 13 –
CD-BP160W/180W/1500W/1700W
CD SECTION
• AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
*1. Input: Antenna, Output: TP302
*2. Input: Antenna, Output: TP301
TUNER SECTION
fL: Low-range frequency
fH: High-range frequency
AM IF 450 kHz 1,602 kHz T351 *1
AM Band — 531 kHz (fL): T306 *2
Coverage 1.1 ±0.1 V
AM Tracking 990 kHz 990 kHz (fL): T303 *1
Figure 13-1 ADJUSTMENT POINTS
Test Stage Frequency Frequency
Display Setting/
Adjusting
Parts
Instrument
Connection
Figure 13-2
CD ERROR CODE DESCRIPTION
Error State Code
[Servo System Error]
0001 Cannot detect Pickup-in SW
0002 DSP access error
[Error during close operation]
0101 Open/Close SW Low → High not functioning
0103 Open/Close SW High →Low not functioning
[Error during open operation]
0201 Open/Close SW Low → High not functioning
0203 Open/Close SW High →Low not functioning
[Error during skip operation]
0302 Pickup-in SW is not detected
0306 During Disc 1 search, Open/Close SW or Clamp SW
or Disc SW do not change to low.
0307 Clamp SW Low → High not functioning
0308 Clamp SW High →Low not functioning
Since this CD system incorporates the following automatic
adjustment functions, readjustment is not needed when
replacingthepickup.Therefore,differentPWBsandpickups
can be combined freely.
Each time a disc is changed, these adjustments are
performed automatically. Therefore, playback of each disc
can be performed under optimum conditions.
Items adjusted automatically
(1) Offset adjustment (The offset voltage between the head
amplifier output and the VREF reference voltage is
compensated inside the IC.)
* Focus offset adjustment
* Tracking offset adjustment
(2) Tracking balance adjustment (waveform drawing 13-2
EFBL)
(3)Gainadjustment(Thegainis compensatedinside theIC
sothatthe loop gain at the gain crossover frequency will
be 0dB.)
* Focus gain adjustment
* Tracking gain adjustment
•Adjustment
T
T
EFBL
FDO
TE
Stopped
CH1=500mV
DC 10:1 CH2=200mV DC 10:1 CH3=1V DC 10:1 500ms/div
(500ms/div)
NORM:20kS/s
1
2
3
=Record Length=
Smoothing : ON CH1 : 0.000V
CH2 : 0.000V Main : 100K Zoom : 2k Mode : SINGLE Type : EDGE CH1
Delay : 0.0ns
Hold off : 0.2us
CH3 : 0.00V
CH4 : 0.00V
BW : FULL
=Trigger==Filter= =Offset=
CH2
v/DIV
200mV
1999/04/05 20:26:47
IC301
R382
TP302
TP301
R357
AM IF
T303
T306
AM
TRACKING fL
FM BAND
COVERAGE fL AM BAND
COVERAGE fL
T351
MAIN PWB
CNP301
AM LOOP
ANTENNA
1
T301
T302
SO302
FM TERMINAL
FM RF
L312
FM IF
*1. Input: Antenna, Output: TP301
*2. Input: Antenna, Output: Speaker terminal
•FM RF
Signal generator: 400Hz, 22.5 kHz dev., FM modulated
FM Band — 87.50 MHz T301(fL): *1
Coverage 3.4 V ±0.1V
FM RF 98.00 MHz 98.00 MHz L312 *2
(10-30 dB)
Test Stage Instrument
Connection
Frequency Frequency
Display Serring/ Adjusting
Point

CD-BP160W/180W/1500W/1700W
– 14 –
Function:-CD test mode.
-Enter test mode.
C D T E S T
OPEN/CLOSE operation is using manual.
<< >>, << >> buttons make pick's slide possible.
Do TOC IL. Do normal play
When these following key is input
into PLAY key, track number can
be appoint directly
<<PLAY>> key input. <<MEMORY>> key input.
<< 1>> key: Track 4
<< 2>> key: Track 9
<< 3>> key: Track 15
<<STOP>> key input.
STOP
Laser ON.
<<MEMORY>> key input.
Tracking OFF play at that
specific point.
<<MEMORY>> key input.
Tracking ON play at that
specific point.
<<STOP>> key input.
STOP
IL isn't done
VOL — Last memory
BAL — CENTER
P.GEQ — FLAT
X-BASS — OFF
To cancel : Power OFF
Sliding the PICKUP with
<< >>, << >> button
must only be in STOP mode.
•TEST MODE
Setting of test mode
Any one test mode can be set by pressing several keys as follows.
<X-BASS> + <CD> + <POWER> TEST: CD opertion test

– 15 –
CD-BP160W/180W/1500W/1700W
Figure 15 BLOCK DIAGRAM (1/3)
CNP12
CNP11
Q2
+3.3V
+5V
CONT5
CONT2 CONT3 CONT4 CONT7 CONT6
SLD0
SPD0
FD0
TD0
+5V
TO DISPLAY SECTION
CLAMP SW CDINT
WRQ
CE DO
CLK
DI CD RES GND DRF
CNS4 BI4
CNP4
M2
SLED
MOTOR
M1
SPINDLE
MOTOR
M
M
TRACKING COIL
FOCUS COIL
PICKUP UNIT
TE FE RFEV HFL VVDD ADAVDD VDD LVDD RVDD XVDD
VDD5V
RFEV
FE-
FE
TE-
TE
HFL
+3.3V
CONSTANT
VOLTAGR
+5V
Q1
Q3
LASER
DRIVER
LDD PD
VCC3
VCC2
VCC4
VCC1
TIN2 TIN1 FIN2 FIN1
IC3
M63001FP
FOCUS/TRACKING/
SPIN/SLED DRIVER
IC1
LA9235M
SERVO AMP.
TO MAIN SECTION
(TO IC401)
R-CH
L-CH AGND DGND +5V(+B3)
RCHO
RVSS
LVSS
LCHO
IC2
LC78641E
SERVO/SIGNAL
CONTROL
-
+
M
SW1
OPEN/
CLOSE
XL1
16.9344MHz
6
5
43
3
25
4
1
1234 78
217
89
10
12 4
35
SW2
CLAMP SW3
DISC
NUMBER
M3
T/T
UP/DOWN
MOTOR
6
12 4
356
12 4
356
75 76 45 46 47 48 32 31 30
65
66
67
68
69
70
71
72
CE
CL
DI
DO
INT
WRQ
RES
DEF
52
51
XOUT
XIN
73 518 36 44 49 50 7 14 15 16
23
24
25
26
33
3
13
19
40
64
74
17 18 19 20 21 22
30
23
11
9
1
4567 15 16 26 27
2 1725 4142 3839
35
29
22
21
14
8
40
18
24
23
28
SW4
PICKUP IN
+3.3V

– 16 –
CD-BP160W/180W/1500W/1700W
Figure 16 BLOCK DIAGRAM (2/3)
REC/PLAY
CL
CE
DI
MUTE
SYSTEM
Q402
Q401
DO CL DI CE
MO/ST
+B2
SWITCHING
+B2
FM/AM
IC302
LC72131
PLL(TUNER)
OUT
FM/AM
+B2
L
R
BAIS
T1/T2
MUTING
Q110
Q111
P.B.
REC
AC BIAS
R
L
SO401
VIDEO/AUX
L
L
R
R
R
L
R
L
AUX
TAPE
TUNER
CD
PB
CNS402
FROM CD
SECTION
CNP11
ERASE
HEAD
SWITCHING
SWITCHING
SWITCHING
BIAS
Q102
Q103
Q101
Q113
SWITCHING
Q112
OSC
BIAS L104
Q114
Q109
Q108
R-CH
L-CH
R-CH
L-CH
IC401
LC75341
AUDIO PROCESSOR
H/N
P.B
+B2
R
L
REC
R
L
L NF
R NF
ALC
REC
T1/T2
T1/T2HIGH
NOR/
REF
R REC
L REC
POP
REDUCE
R NF
L NF
SWITCHING
Q104~
Q107
L(T2)
R(T2)
R(T1)
L(T1)
IC101
PLAYBACK AND RECORD/
PLAYBACK AMP.
R
L
FM/AM
MPXIN
STEREO
AM RF IN
AM OSC IN
FM +B
Q360
VT
FM OSC
OSC
4.5MHZ
X352
COVERAGE
AM BAND
AM
TRACKING
T303
Q302
X351
MO/ST
VCO
DET
FM
FM+B
GND
AM IF
CF351
FM/AM IF MPX.
LA1832S
IC303
AM MIX
CF352
T351
RF
FM
OSC
FM
L312
CF303
T302
FM FRONT END
TA7358AP
IC301
BF301
FM ANTENNA
22
3
21
4
24
2
1
818
17
5
4
3
910
18
11
16
3
15
10
9
7
23
14
12
13
1
2
20
19
7
18
10
8
17
13
21
4
5
2
24
23
6
9
16
14
12 15
1
5
13
8
4
3
21
21
7
98
5
6
21 24
21
20 22 11
17
15
16
9
6
5713
14
12 15
16
23
4
7
17
T301
T306
4
FM
REC PB HEAD
TAPE 2
PB HEAD
TAPE 1
R
L
SO302
AM LOOP
ANTENNA
1
21
2
CNP302
113
3
1
VDD

– 17 –
CD-BP160W/180W/1500W/1700W
Figure 17 BLOCK DIAGRAM (3/3)
SPEAKER
SPEAKER
FRONT
SURROND
SO801
AC INPUT
SOCKET
SW801
VOLTAGE SELETOR
110V
127V
220V
230-240V
PT801
POWER TRONSFORMER
F802
T4.0A L 250V
5V
~
REC/PLAY
VLOAD
+B4
RESET IC
SYS. STOP
RESET
IC704
Q609 Q971
+B3
FAN MOTOR
M
SO902
SPEAKER
TERMINAL
RL951
+B4 +B4
+B4
SW401
SPAN SELETOR
+B4
VDD VDD VDD
R-OUT
L-OUT
SP. DET. Q904
Q903
Q902
Q901
UNSWITCH
+5V
A10V
+B4
+B3
+B2
+B1 –B1
~
IC852
IC851
IC841
MUTE
SYSTEM
Q402
Q401
CE DI CL DO
+B2
XL701
4.1943MHz
~
D802-D805
D801
F803
T2.0A L 250V
F801
T4.0A L 250V
~
~~~ ~
-Vcc
+Vcc
POWER AMP.
STK402-040
IC901
BAIS
T1/T2
AVDD
SW609-SW629
SW601-SW603
KEY
SECTION
TO CD
Q601-Q603
AC POWER
SUPPLY CORD
AC 110V/127/220/
230-240V, 50/60Hz
150 C
TF
IC701
IX0328AW
SYSTEM
MICROCOMPUTER
FL DISPLAY
FL701
~
~~
7
13
9
8
15
111
1
3
393837
93
92
90
63
21 36 2015
14
12
11
65
41
2
85
80
33
31
45
71112139 10 1516 17 2021 23
22 24
100
79
78
60 58575655545352 5051 49484746 444342414039
38
37
36
35
34
34
21
180W/1700W
ONLY
+B2
JK951
HEADPHONES
Q607
M
TAPE
MOTOR
MOTOR
DRIVER
Q606
Q605
RX701
1 2 3
+B4
LED722
Q604
Q608
SOLENOID
T2 PLAY
T1 PLAY
R. PLAY
F. PLAY
KIA7805P
VOLTAGE
REGULATOR
KIA7810AP
VOLTAGE
REGULATOR
AN78L05
CONSTANT
VOLTAGE
REGULATOR

– 18 –
CD-BP160W/180W/1500W/1700W
Figure 18 SCHEMATIC DIAGRAM (1/9)
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 34.
42
41
40
39
38
37
36
LOADING M-
VCC4
LD_M+
LD_M-
LOADING M+
35
34
33
32
31
30
29
28
27
26
25
24
23
22
SPDO
VCC3
VCC2(SPN)
SP-
SP+
SPO
GND
+B
NC
TEST
HFL
TE
TE-
FE
FE-
RFEV
BH
PH
RF
RF-
RFSW
VCC
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
REF
ODRV
AGCON
ODRV
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
AGCON
ODRV
APC
LPF
DH
PH
LPF
LPF
PH/BH
LDON
EFBL
FIN1
FIN2
REF1
TIN2
TIN1
AGON
LDD
TEST0
GND
VREF
TES1 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
FIN2
FIN1
TIN2
TIN1
+B
+B
2
5
3
1
7
6
44
3
2
1
7
6
5
CD SERVO PWB-B
5
1
3
7
6
4
2
4
3
2
1
7
6
5
Vcc
C
Vref
F
B
E
A
LD
VR
PD
GND
FO-
FO+
TR+
TR-
5
2
1
2
3
4
5
6
7
88
3
6
7
1
4
TR-
TR+
FO+
FO-
GND
PD
VR
LD
ACTUATOR
FO+
FO-
TR-
TR+ 1
2
3
4
5
6
7
88
3
6
7
1
4
5
2
PICKUP UNIT
GND(D)
PUIN
SP+
SP-
SL+
SL-
3
2
5
1
4
6
2
3
5
1
4
6
3
6
1
4
5
22
3
5
1
4
6
CD MOTOR PWB-C
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
SLDO
FDO
TDO
MUTE
Vref
STANDBY
VCC1
SL-
SL+
GND
TR+
TR-
FO-
FO+
FO
FD
TO
+B
+B
+
+
+
+ +
+
+
+ +
-
-
-
-
-
-
-
-
-
-
- -
-
-
-
+
+
+B
+B
+B
+B
+
-
-
+
M
M
+
+ +
+
R54 68K
R53 68K
R52 68K
R51 68K
CNP1
R56
68K R55
68K
C6
100/10
C54
47/10 C55
0.01
C51
47/10
C53
0.001
R25
10K
C7
10/16
C8
0.1
R47
3.3
Q3
KTA1266GR
LASER DRIVER
R50
47
C14
0.33
C13
0.01
R42
120K
R3
100K
R4
10K
C11
0.47/6.3
R6
27K
R7
6.8K
R5
39K
C12
0.1
C18
3P
(CH)
C19
100/10
R8
330
R10
27K
C26
0.047
C22
100P
R80
1M
C24
2.2/50
C23
0.047
C17
0.0047
R15
10K
C20
0.1
C42
68P
C25
0.1
C41
100/10
C
2
47/
1
C82
0.022
D93
DS1SS133 R43
220K
C47
100/16
C49
100/16
C50
100/16
C46
0.022
IC3
M63001FP
FOCUS/TRACKING/
SPIN/SLED DRIVER
R48
6.8K
C52
0.01
CNP2
CNP3
CNS3A CNS3B
M1
SPINDLE
MOTOR
M2
SLED
MOTOR
SW4
PICKUP IN
IC1
LA9235M
SERVO AMP.
CNS1A CNS1B
CNS2A CNS2B
CNP3A
13
5
4

– 19 –
CD-BP160W/180W/1500W/1700W
Figure 19 SCHEMATIC DIAGRAM (2/9)
78 9 10 11 12
• The numbers 1 to 13 are waveform numbers shown in page 35.
CD SIGNAL
RES
WRQ
CE
DO
CL
DI
DRF
INT
+B
XVDD
RVSS
RCHO
RVDD
XIN
51
50
49
48
47
63
62
61
60
59
58
57
56
55
54
53
52 XOUT
XVSS
ASLRCK
ASDACK
ASDFIN
LRSY
DATACK
DATA
16M
SFSY
SBSY
PW
64 SBCK
CE CL DI DO INT
WRQ
SERIAL
OUT
EXTERNAL AUDIO IN
DIGITAL FILTER
1BIT DAC
LPF
INTERPOLATION MUTE ATTENUATION DEEMPHASIS
CLOCK
GENERATOR
SUBCODE
DECODE
CRC
COMMAND
INTERFACE
AGND
R-CH
EMPH
MUTEL
MUTER
LVDD
LCHO
LVSS
+5V
DGND
1
2
3
4
5
+B
+B
CNS402
P22 1-B
FROM MAIN PWB
INT
DRF
WRQ
CE
DO
DI
CL
RES
DRF
GND
CD RES
DI
CLK
DO
CE
WRQ
CDINT
CLAMP SW
10
9
7
1
2
3
4
5
6
8
+B
+B
+B P21 11-B
CNS701
FROM DISPLAY PWB
DISC_NO
O/C
GND(D)
M-
M+
CD LOADING
MOTOR PWB-E
TEST
DOUT
VDD C2F PCK
40
39
38
37
36
35
34
33
32
31
30
29
28
27
EFLG
41
FSX
CONT5 CONT4 CONT3 CONT2 CONT1 LASER
+B
+B
+B
1
32
O
ADING M-
C
C4
D
_M+
D
_M-
O
ADING M+
SPDO
C
C3
C
C2(SPN)
P
-
P
+
P
O
N
D
+B
+B
JITTC
JITTV
EFMIN
EFBL
FDO
TDO
TBLO
BHREF
PHREF
ADAVSS
ADAVDD
VREF
TE
FE
PH(RFENV)
BH
TDO
SLDO SPDO
FDO
SPDO
FG(D_Vref)
SLDO
AUDIO
OUT
ERROR
CORRECT
GENERAL
SW
SERVO
PROCESSEROR
AUTO
ADJUST
S/H
JITER
DEFECT
CONTROL
A/DSW
D/A
+B
+B
5
4
3
2
1
PCKIST
VVDD
VVSS
PD02
PD01
73
80 79 78 77 76 75 74
FRAME SYNC
DEFECT,PROTECT
EFM DECODE
CLV
CONTROL
GENERAL
SLICE
LEVEL
CONTROL
PLL
VCEC
SLCO
SLCIST
HFL
FR
VDD5V
CONT7 CONT6 VSS V/vP FSEQ
DEFECT
EFMO
RES
DEF
O/C
DISC_NO
+B
72 71 70 69 68 67 66 65
11
10
9
8
7
6
24
23
22
21
20
19
18
17
16
15
14
13
12
-
+
+B
+
-
1
2
3
4
5
66
5
4
3
2
1
5
4
3
2
1
M
6
L-CH
+B
+B
46
45
44
43
42
+B
26
25
+B
C19
100/10
R8
330
R10
27K
C26
0.047
C22
100P
R80
1M
R79
1.5M
C24
2.2/50
C21
0.1
C23
0.047 R12
680
R14
1.2K
R11
12K
R13
680
C81
0.022
C27
0.1
C17
0.0047
R15
10K
C20
0.1
C42
68P
C25
0.1
C41
100/10
C28
47/10
C82
0.022
R44
1K
C29
0.1
D93
DS1SS133 R43
220K
R35
1K
R38
270
R39
470
R16
10K
R17 1K
R46 1K R45 1.2K R40 1.2K
C31
100/10
C30
0.1
L61
0.82µH
C64
0.47/6.3
ZD61
DZ3.9BSB
R19
47
C39
10/16
R58
220
Q1
KTC3203 Y
CONSTANT VOLTAGE
C56
330/6.3
C83
0.022
R84
10K
C40
0.0015
C43
0.0015
R83
10K
C34
0.022
R82
2.2K
R81
2.2K
C38
10/16
R20
220
XL1
16.9344MHz
C45
100/10
C44
0.1
C80
0.1
R73 1K
R71 1K
C72 0.01 R72 1K
C71 100P
C73 100P
C75 100P
C76 100P
C77 100P
C78 100P
R75 1K
R76 1K
R77 1K
R78 1K
C74 100P R74 1K
L62
2.2µH
R94
10K
R95
10K
R67 1K R68 1K
IC2
LC78641E
SERVO/SIGNAL
CONTROL
CNP11
CNP12
CNP4
SW3
DISC
NUMBER
SW2
CLAMP
SW1
OPEN/
CLOSE
D21
DS1SS133
R21
470 R22
470
Q2
KRC102M
D22
DS1SS133
C47
100/16
BI4
CNS4
M3
T/T
UP/DOWN
LOADING
1
69
13
2
10
11
12
3
7
8

– 20 –
CD-BP160W/180W/1500W/1700W
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 34.
Figure 20 SCHEMATIC DIAGRAM (3/9)
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51 30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
9.3V
9.3V
9.3V
9.3V
0V
0V
8.6V
9.3V
9.3V
-25.7V
-25.7V-25.7V
-25.7V
-25.7V
-25.7V
3.3V
3.3V
3.3V
M10V
F
F
T2 RUN
F F
F F
G11 G10 G09 G08 G07 G06 G05 G04 G03 G02 G01 P01 P02 P03 P04 P05 P06 P07 P08 P09 P10 P11 P12 P13 P14 P15 P16 P17 P18 P19 P20 P21 P22
KEY 0 KEY 1
KEY 2
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
50 49 48 47 46 45 44 43 42 41 39 38 37 36 35 34 33 32 31
S-BUSY
SP_RLY
SPK_DET
USE
DISTOUT/SW OUT
SPN
MIC IN
FPB
PLAY SW_A
T1 RUN
AVref
S
P
XT2
DRF
FPA
CD CLAMP
SW
T_SOL_B
VDD
G1 G2 G3 G4 G5 G6 G7 G8 G9
G10 G11
VLOAD
P16/DIST1
P17/DIST2
P18/DIST3
P19
P20
P21
P22
KARAOKE LATCH
PLAY SW_B
AC RLY_CONT
VDD TIMER LED T_MOTOR T_SOL_A SMUTE VSS REMOCON
NO
SYS STOP
S
P
S
N
M-BUSY/TUN SM
AVSS
DO
DI
CLK
CD DO
CD CLK
VPP/IC
RES OUT
REC/PLAY
CE
P15/DIST0
P14
P13
P12
P11
P10
P9
P8
P7
P6
P5
P4 P3 P2 P1
CD INT
WRQ
CD DI
CD CE
RESET
AVDD
X2
X1
VDD
T_T1/T2
T-BIAS
1
2
3
4
5
6
7
8
9
10
11
12
13
COM
T1 RUN
T2 SOL
MTR +
T2 PLAY
T2 RUN
+5V
T1 SOL
R_REC
T1 RUN
F-REC
4
1
8
7
2
3
5
6
4
1
8
7
2
3
5
6
40
13
12
11
10
9
8
7
2
1
3
4
5
6
--
+
M
TAPE MECHANISM PWB-D1
TAPE
MOTOR
DISPLAY PWB-A2
2
345 1 789 6 12131415 11171819 1016 22232425 21272829 20263032 31333435373839 36
13
13
1
1
SOLENOIDE
SOLENOIDE
R672
10K
R671
10K
R670
10K
R675
1K
R674
1K
R673
1K
R669 10K
R668 1K
R667
1K
LED722
R659
1K
R661 2.2K
R663 2.2K
R664 2.2K
R665 2.2K
R653
1K R654
1K
R656
10K
R660
10K
Q608
KTC3199 GR
R655
1K
R658
47K
D615
DS1SS133
C618
10/16
R650
68K
R649
10K
Q604
KTC3199 GR
R638
47K
R637
1K
C617
10/16
D611
DS1SS133
Q607
KTA1273Y R662
10K
R651
10K
R652
10K
Q606
KTA1271 Y
Q605
KTA1271 Y
D614
DS1SS133
D613
DS1SS133
C620
47/25
CNP703
C611
0.022
ZD601
DZ6.2BSC
C610
0.022
C614
2.2/50 R627
100K
D604
DS1SS133
R626
100K
C613
2.2/50
D603
DS1SS133
C612
2.2/50
R625
100K
D602
DS1SS133
R636
68K
R624
270
R623
270
IC702
KIA4558P
OPEAMP.
R618
220K
R617
220K
R613
820K
C605
270P
C601
270P
R603
10K
R607
33K
R608
68K
R604
12K C602
0.0027
R614
390K
D601
DS1SS133
R605
56K
C603
0.0068
R609
470K C604
0.0068 R619
2.2M
C607
0.022
R615
150K
R620
180K
C608
0.022
R610
15K
IC703
KIA4558P
OPEAMP.
R612
1M
C606
0.0027
R621
33 R630 10K
Q601
KTC3199 GR
R601
1K
R602
100K
Q602
KTC3199 GR
R606
1K
R611
100K
Q603
KTC3199 GR
R616
1K
R622
100K
C609
47/50 C616
1/50
FL701
FL DISPLAY
D608
DS1SS133
D612
DS1SS133
R642 22K
R646 1K
R645 22K
R644 1K
R643 1K
R648 1K
R725
10K
R632 10K
R629 10K
R633 10K
R634 10K
R635 10K
R
R
R
R
R
R
R
R
R
R
X
L
R
R
R
6
R
R
IC701
IX0328AW
SYSTEM
MICROCOMPUTER
R647 1K
R
R
6
FC702
+B
+B
+B
+B
+B
+B
–B
+B
+B
+B
+B
+
+B
+B
