Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
PORTABLE CD STEREO
MODEL
OPERATION MANUAL
GX-CD5100W
COMPONENT SYSTEM
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
2
GX-CD5100W
General Information
Special notes
Supply of this product does not convey a license nor imply any right
to distribute content created with this product in revenue-generating
broadcast systems (terrestrial, satellite, cable and/or other distribu-
tion channels), revenue-generating streaming applications (via Inter-
net, intranets and/or other networks), other revenue-generating
content distribution systems (pay-audio or audio-on-demand appli-
cations and the like) or on revenue-generating physical media (com-
pact discs, digital versatile discs, semiconductor chips, hard drives,
memory cards and the like). An independent license for such use is
required. For details, please visit http://mp3licensing.com.
MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson.
WARNINGS:
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or broad-
casting such material without permission of the relevant licensees or
owners of the copyright is prohibited by law. SHARP is not in a posi-
tion to authorise the copying or broadcasting of copyright materials
and nothing in this OPERATION MANUAL should be implied as giv-
ing that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must
not be recorded without the authority of the owner of the copyright.
Please refer to the relevant laws in your country.
CAUTION:
●This product is classified as a CLASS 1 LASER product.
●Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
As the laser beam used in this compact disc player is harmful to
the eyes, do not attempt to disassemble the cabinet. Refer
servicing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
●When the ON/STAND-BY button is set at STAND-BY position,
mains voltage is still present inside the unit. When the ON/
STAND-BY button is set at STAND-BY position, the unit may be
brought into operation by the timer mode or remote control.
● This unit contains no user serviceable parts. Never remove covers
unless qualified to do so. This unit contains dangerous voltages,
always remove mains plug from the socket before any service
operation and when not in use for a long period.
● To prevent fire or shock hazard, do not expose this appliance to
dripping or splashing. No objects filled with liquids, such as vases,
shall be placed on the apparatus.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
3
GX-CD5100W
General Information
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
■ General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 7
■ Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 10
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
■ Basic Operation
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the clock (Remote control only) . . . . . . . . . . . . . . . . . 13
■ CD or MP3 disc playback
Listening to a CD or MP3 disc . . . . . . . . . . . . . . . . . . . . . .14 - 15
Advanced CD or MP3 disc playback . . . . . . . . . . . . . . . . .16 - 17
■ Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 - 19
Setting the FM/MW interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
■ Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2) . . . . . . .20 - 21
■ Tape Recording
Recording to a cassette tape . . . . . . . . . . . . . . . . . . . . . . .21 - 23
■ Advanced Features
Timer and sleep operation (Remote control only) . . . . . .24 - 26
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
■ References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 - 29
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Remote control 1 "AA" size battery (UM/SUM-3,
R6, HP-7 or similar) 2
AM loop aerial 1 AC power lead 1
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
4
GX-CD5100W
General Information
Precautions
■ General
● Use the unit on a firm, level surface free from vibration.
● Keep the unit away from direct sunlight, strong magnetic fields,
excessive dust, humidity and electronic/electrical equipment
(home computers, facsimiles, etc.) which generate electrical
noise.
● Do not place anything on top of the unit.
● Do not expose the unit to moisture, to temperatures higher than
60°C (140°F) or to extremely low temperatures.
● If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
● In case of an electrical storm, unplug the unit for safety.
● Hold the AC power plug by the head when removing it from the
wall socket, as pulling the lead can damage internal wires.
● The AC power lead/ AC power input socket is used as disconnect
device and shall always remain readily operable.
● Do not remove the outer cover, as this may result in electric
shock. Refer internal service to your local SHARP service
facility.
● The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths, curtains,
etc.
● No naked flame sources, such as lighted candles, should be
placed on the apparatus.
● Attention should be drawn to the environmental aspects of battery
disposal.
● This unit should only be used within the range of 5°C - 35°C
(41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of acci-
dent causing damage. SHARP will not be held responsible for any
damage resulting from use of this unit with a voltage other than that
which is specified.
■ Volume control
The sound level at a given volume setting depends on speaker effi-
ciency, location, and various other factors. It is advisable to avoid ex-
posure to high volume levels. Do not turn the volume on to full at
switch on and listen to music at moderate levels.
■ Care of compact discs
Compact discs are fairly resistant to damage, however mistracking
can occur due to an accumulation of dirt on the disc surface. Follow
the guidelines below for maximum enjoyment from your CD collec-
tion and player.
● Do not write on either side of the disc, particularly the non-label
side from which signals are read. Do not mark this surface.
● Keep your discs away from direct sunlight, heat, and excessive
moisture.
● Always hold the CDs by the edges. Fingerprints, dirt, or water on
the CDs can cause noise or mistracking. If a CD is dirty or does
not play properly, clean it with a soft, dry cloth, wiping straight out
from the centre, along the radius.
● Please ensure that the equipment is
positioned in a well ventilated area
and ensure that there is at least 10
cm (4") of free space along the
sides, top and back of the
equipment. 10 cm(4")
10 cm (4")
NO YES
Correct
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
5
GX-CD5100W
General Information
Controls and indicators
■ Top
1. Disc Compartment
■ Front panel
Reference page
1. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 20
2. Built in Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4. Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5. Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6. Line in Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7. On/Stand by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10. Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11. CD/MP3 disc Track Down or Fast Reverse Button . . . . . . 15
12. CD/MP3 Disc Play or Repeat Button . . . . . . . . . . . . 14, 15, 16
13. CD/MP3 Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
14. CD/MP3 Disc/Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15
15. CD/MP3 disc Track Up or Fast Forward Button . . . . . . . . . 15
16. Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
17. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
18. Simba Mode/Demo Button . . . . . . . . . . . . . . . . . . . . . . . . . 12
19. Mixing Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . 23
20. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 20
21. Tape 1 Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
22. Tape 1 Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
23. Tape 1 Rewind Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
24. Tape 1 Fast Forward Button . . . . . . . . . . . . . . . . . . . . . . . . 20
25. Tape Continuous Playback Button . . . . . . . . . . . . . . . 20, 29
26. Tape High Speed Dubbing Button . . . . . . . . . . . . . . . . . . . 23
27. Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . 22
28. Tape 2 Forward Play Button . . . . . . . . . . . . . . . . . . . . . . . . 22
29. Tape 2 Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
30. Tape 2 Fast Wind Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . 22
31. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . 23
1
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16 17
18
19
20
21 22 23 24 25 26 27 2829 30 31
PUSH
OPEN/CLOSE
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
6
GX-CD5100W
General Information
Controls and indicators (continued)
■ Rear Panel
Reference page
1. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Beat Cancel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3. CD/LINE Input Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6. Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7. Battery Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8. DC Power Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
■ Speaker system
■ Display
Reference page
1. Disc Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2. Disc Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. Disc Repeat Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 16
4. Tape Continuous Playback Indicator . . . . . . . . . . . . . . . . 20
5. Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7. CD Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 17
8. MP3 Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
9. High Speed Dubbing Indicator . . . . . . . . . . . . . . . . . . . . . . 23
10. Random Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
11. Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12. Tape 2 Record Indicator . . . . . . . . . . . . . . . . . . . . . . . . 22, 23
13. Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
14. Timer Recording Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 24
15. Tape 2 Reverse Mode Indicator . . . . . . . . . . . . . . . . . . . . . 23
16. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 18
17. Daily Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
18. FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 18
19. Tape 1 Play or Tape 2 Forward Play Indicator . . . . . . . . . . 20
20. Tape 2 Reverse Play Indicator . . . . . . . . . . . . . . . . . . . . . . 20
123456
78
1
2
4
3 5 6 78 910
11
12 13
15
16
1718
19
20
14
1. Tweeter
2. Bass Reflex Duct
3. Woofer
4. Speaker Wire
4
1
2
3
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
7
GX-CD5100W
General Information
■ Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 11
2. Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3. Clock/Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 24
4. Simba Mode/Demo Button . . . . . . . . . . . . . . . . . . . . . . . 9, 12
5. Equaliser Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. Dimmer/Display Button . . . . . . . . . . . . . . . . . . . . . . . . . 12, 16
7. Direct Search Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8. Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17, 18, 24
9. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10. CD/MP3 Disc Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
11. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
13. Line in Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
14. Tape 2 Reverse Mode Button . . . . . . . . . . . . . . . . . . . . . . . 20
15. Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . 20
16. Tape 1 Play or Tape 2 Forward Play Button . . . . . . . . . . . 20
17. Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
18. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . 22
19. Disc Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
20. CD/MP3 Disc Play or Repeat Button . . . . . . . . . . . . . . 14, 16
21. CD/MP3 Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15
22. Disc Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
23. CD/MP3 Disc Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down, Time Down Button . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 15, 18, 20, 21, 24
24. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 12
25. CD/MP3 Disc Track Up or Fast Forward, Tape Fast
Forward, Tuner Preset Up, Time Up Button . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 15, 18, 20, 21, 24
1
2
3
4
7
5
6
23 25
24
14 15 16
17 18
8
9
10
11
12
13
19 20
21
22
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
8
GX-CD5100W
Preparation for Use
System connections
■ Detachable speakers
■ Mounting the speakers to the main unit
Fit the grooves of the speaker to the guides on the main unit, and
then slide the speaker all the way down to lock it in place.
■ Removing the speakers from the main unit
Push the RELEASE lever as shown in the illustration to unlock the
speaker, and then lift up the speaker to remove it from the main unit.
■ Speaker connection
Connect each speaker wire to the SPEAKER terminals as shown.
Use speakers with an impedance of 8 ohms or more, as lower im-
pedance speakers can damage the unit.
Caution:
Supplied AM Loop aerial:
● Set the FUNCTION switch to STAND-BY before connecting or
disconnecting the speakers.
Red
Red
Right speaker Left speake
r
Black
● Connect the black wire to the minus (-) terminal, and the red wire
to the plus (+) terminal.
● Do not mix the right channel and left channel wiring when
connecting the speakers to the unit.
● Do not let the bare speaker wires touch each other as this may
damage the amplifier and/or speakers.
● Do not stand or sit on the speakers. If the speakers fall or collapse,
you may be injured.
Connect the AM loop aerial to the AM LOOP socket. Position the AM
loop aerial for optimum reception.
Note:
Placing the aerial on the unit or near the AC power lead may cause
noise pickup. Place the aerial away from the unit for better reception.
Aerial Adjustment
FM SW1/SW2
MW/SW1
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
9
GX-CD5100W
Preparation for Use
■ Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear
panel before plugging the unit into a wall socket. If necessary, adjust
the selector to correspond to the AC power voltage used in your
area.
Selector adjustment:
Slide the selector with a screwdriver to the appropriate voltage
number (AC 110 - 127 V or AC 220 - 240 V).
■ AC power connection
After checking all the connections have been made correctly, plug
the AC power lead of this unit into the wall socket. If you plug the unit
first, the unit will enter the demonstration mode.
Notes:
● The unit will start the tape initialisation when plugged in to the wall
socket. During this process, initialising sound will be heard and
the unit cannot be turned on. Wait until the process is finished.
● Unplug the AC power lead from the wall socket if the unit will not
be in use for a prolonged period of time.
■ Demonstration mode
To the wall socket
110-127/220-240 V
50/60 Hz
AC 220V
- 240V
VOLTAGE
SELECTOR
AC 110V
- 127V
AC 220V
- 240V
VOLTAGE
SELECTOR
AC 110V
- 127V
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
To cancel the demonstration mode:
When the unit is in the power
stand-by mode (demonstration
mode), press the SIMBA MODE/
DEMO button. The demonstration
mode will be cancelled and the
display will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the SIMBA
MODE/DEMO button again.
Notes:
● When the power is on, the SIMBA MODE/DEMO button can be
used to select the simba mode.
● Demonstration mode will not be displayed when DC adaptor is
connected or when battery is in use.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
10
GX-CD5100W
Preparation for Use
System connections (continued)
■ DC power connection
Plug the AC Adaptor/Car Adaptor into the wall socket/car supply
socket then insert the plug on the other end into the DC IN 12V socket.
Connection of the AC power lead to the unit disconnects the DC power
supply.
Caution:
● Use only AC Adaptor/Car Adaptor with DC 12V output voltage.
● Insert the plugs firmly.
● When the unit is not in use for an extended period, remove the AC
Adaptor/Car Adaptor from the wall socket/car supply socket.
■ Operation with batteries
Precautions for battery use:
● Insert the batteries according to the direction indicated on the rear
panel.
● Remove the batteries if they are weak or if the unit will not be used
for long periods of time. This will prevent potential damage due to
battery leakage.
● Replace all old batteries with new ones at the same time.
● Do not mix old and new batteries.
Caution:
● Do not use rechargeable batteries (nickel-cadmium battery, etc.).
Battery replacement:
Replace the batteries when they become weak and/or recording or
playback is impaired. This may occur even though radio broadcasts
are audible.
Attention: connection of DC lead and battery
terminals.
ª : Connect the red battery clip to (+) on
the battery terminal.
· : Connect the black battery clip to (–) on
the battery terminal.
DC power can only be used for a 12V
battery.
Do not use any battery besides a 12V.
To the wall socket
AC Adaptor
Socket: 12VDC
Car Adaptor
Socket: 12VDC
To DC IN
12V socket
OR
12V
Red
Black
24V
1 Disconnect the AC power lead, and remove the battery compart-
ment cover.
● Connection of the AC or DC power lead to the unit disconnects
the batteries.
2 Insert 10 "D" size batteries (UM/SUM-1, R20, HP-2 or similar)
into the battery compartment.
● When inserting or removing the batteries 5 and ! , push them
towards the · battery terminals.
Installing the batteries incorrectly may cause the unit to
malfunction.
● Batteries are not included.
3 Replace the battery compartment cover.
1
2
3
5
4
7
6
9
10
8
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
11
GX-CD5100W
Preparation for Use
Remote control
■ Battery installation
Precautions for battery use:
● Replace all old batteries with new ones at the same time.
● Do not mix old and new batteries.
● Remove the batteries if the unit will not be used for long periods
of time. This will prevent potential damage due to battery leakage.
Caution:
● Do not use rechargeable batteries (nickel-cadmium battery, etc.).
● Installing the batteries incorrectly may cause the unit to
malfunction.
Battery removal:
Open the battery cover and pull up the battery to take out.
Notes concerning use:
● Replace the batteries if the operating distance is reduced or if the
operation becomes erratic. Purchase 2 "AA" size batteries (UM/
SUM-3, R6, HP-7 or similar)
● Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
● Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
● Keep the remote control away from moisture, heat, shock, and
vibrations.
■ Test of the remote control
Check the remote control after checking all the connections (see
pages 8 - 10).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you
can enjoy music.
1 Open the battery cover.
2 Insert the supplied batteries according to the direction
indicated in the battery compartment (back of the battery
cover).
When inserting or removing the batteries, push them towards the
battery terminals.
3 Close the cover.
Remote
sensor
0.2 m - 6 m
(8" - 20')
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
12
GX-CD5100W
Basic Operation
General control
■ To turn the power on
Press the ON/STAND-BY button to turn the power on.
■ Illumination light control
When the power is turned on, the content of the display is light up.
To dim the light, press and hold the DIMMER/DISPLAY button on the
remote control for more than 2 seconds.
■ Volume control
■ Simba mode
■ Equaliser
When the EQUALIZER MODE button is pressed, the current mode
setting will be displayed. To change to a different mode, press the
EQUALIZER MODE button repeatedly until the desired sound mode
appears.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Main unit operation:
When the VOLUME control is turned
clockwise, the volume will increase.
When it is turned anti-clockwise, the
volume will decrease.
Remote control operation:
Press the VOLUME (+ or –) button to
increase or decrease the volume.
When the power is first turned on, the
unit will enter the simba mode which
emphasises the bass frequencies, and
"SIMBA MODE" will scroll in. To cancel
the simba
mode, press the SIMBA
MODE/DEMO button .
MAXIMUM300 .....
ROCK For rock music.
FLAT No equalisation.
CLASSIC For classical music.
POPS For pop music.
JAZZ For jazz.
VOCAL Vocals are enhanced.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
13
GX-CD5100W
Basic Operation
Setting the clock (Remote control only)
In this example, the clock is set for the 24-hour (0:00) display. To confirm the time display:
[When the unit is in the stand-by mode]
Press the CLOCK/TIMER button.
The time display will appear for about 10 seconds.
[When the power is on]
Press the CLOCK/TIMER button.
Within 10 seconds, press the
or button to display the time.
The time display will appear for about 10 seconds.
Note:
The "CLOCK" will appear or time will flash to confirm the time display
when the AC power supply is restored after a power failure or unplug-
ging the unit. If incorrect, readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from step 1. If the "CLOCK" is not appear
in step 3, step 4 (for selecting the 24-hour or 12-hour display) will be
skipped.
To change the 24-hour or 12-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK/TIMER button.
3Within 10 seconds, press the or button to select
"CLOCK", and press the MEMORY button.
4Press the or button to select 24-hour or 12-hour
display and then press the MEMORY button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
5Press the or button to adjust the hour and then press
the MEMORY button.
Press
the or button once to advance the time by 1 hour.
Hold it down to advance continuously.
6Press the or button to adjust the minutes and then
press the MEMORY button.
Press
the or button once to advance the time by 1 minute.
Hold it down to change the time in 5-minute intervals.
1 Clear all the programmed contents. [Refer to "Clearing all the
memory (reset)" on page 29 for details.]
2 Perform "Setting the clock" from step 1.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
14
GX-CD5100W
CD or MP3 disc Playback
Listening to a CD or MP3 disc
This system can play back a standard CD, CD-R/RW in the CD for-
mat and CD-R/RW with MP3 files, but cannot record on them.
Some audio CD-R and CD-RW discs may not be playable due to the
state of the disc or the device that was used for recording.
MP3 disc:
MP3 is a form of compression. It is an acronym which stands
for MPEG Audio Layer 3.
MP3 is a type of audio code which is processed by significant
compression from the original audio source with very little loss
in sound quality.
●This system supports MPEG 1 Layer 3, MPEG 2 Layer 3, and
VBR files.
●During VBR file playback, time counter in the FL display may differ
from its actual playback time.
●Bitrate which is supported by MP3 is 32 ~ 320 kbps.
Note:
●"MP3" indicator will light up after the unit reads information on an
MP3 disc.
Auto power off function:
In the stop mode of CD or MP3 operation, the main unit enters the
stand-by mode after 15 minutes of inactivity.
■Playback
To stop playback:
Press the ( ) button.
To remove the discs:
In the stop mode, press the PUSH OPEN/CLOSE portion on the CD
door.
Caution:
●Do not place two discs in the spindle.
●Do not play discs with special shapes (heart- or octagon-
shaped). It may cause malfunctions.
●If TV or radio interference occurs during CD operation, move the
unit away from the TV or radio.
●If a disc is damaged, dirty, or loaded upside down, the disc will not
play back.
1Press the ON/STAND-BY button to turn the power on.
2Press the CD(CD) button.
3Open the CD compartment by pushing the area marked
"PUSH OPEN/CLOSE".
4Place a disc on the spindle, label side up.
Be sure to place 8 cm (3") discs in the middle of the disc trays.
5Close the CD compartment by firmly pushing the right
corner of it.
6Press the / ( / ) button to start playback.
12 cm (5") 8 cm (3")
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
15
GX-CD5100W
CD or MP3 disc Playback
■Various disc functions Notes:
●Track up/track down and fast forward/fast reverse are possible
only within individual discs.
●During fast forward/fast reverse, no sound is produced.
■To change the display (MP3 discs only)
Whilst in the stop mode or playback mode, press the DIMMER/DIS-
PLAY button.
Each time the button is pressed, the display will change as follows.
[When in the stop mode]
[When in the playback mode]
Function Main Unit Remote
Control
Operation
Play Press in the stop mode.
Stop Press in the playback
mode.
Pause Press in the playback
mode. Press the /
( / ) button to resume
playback from the
paused point.
Track up/
Track
down
Press in the playback or
stop mode.
If you press the button
in the stop mode, press
the / ( / ) button
to start the desired
track.
Fast
forward/
Fast
reverse
Press and hold down in
the playback mode.
Release the button to
resume playback.
Total number of tracks Folder name
Track number
Track name
Track number Elapsed playback
time Folder name
Track name
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 GX-CD5100V_EN1.fm
16
GX-CD5100W
CD or MP3 disc Playback
Advanced CD or MP3 disc playback
■To select the desired folder or track by name
(MP3 discs only)
■Direct track search
By using the direct search buttons, the desired tracks on the current
disc can be played.
If the direct search buttons are pressed whilst the disc is stopped, press
the / ( / ) button to start the desired track on the current disc.
Notes:
●A track number higher than the number of tracks on the disc can-
not be selected.
●During random play, direct search is not possible.
■Repeat play
All tracks or a programmed sequence can be continuously repeated.
To cancel repeat play:
Press the / ( / ) button again. " " will disappear.
■Random play
The tracks on the disc can be played in random order automatically.
1Whilst in the stop mode, press the DIMMER/DISPLAY
button to display the folder name.
2Select the desired folder by pressing the or button.
3Press the DIMMER/DISPLAY button
to display the track name.
4Select the desired track by pressing the or button.
5Press the / ( / ) button to be-
gin playback.
Use the direct search buttons on
the remote control to select the
desired track whilst playing the
selected disc. Selected track number
●The direct search buttons allow you to select up to number 9.
●When selecting number 10 or more, use the "+10" button.
A. For example, to choose 13
1 Press the "+10" button once.
2 Press the "3" button.
B. For example, to choose 30
1 Press the "+10" button three times.
2 Press the "0" button.
To repeat all tracks:
Press the / ( / ) button twice.
To repeat a desired track:
Perform steps 1 - 6 in the "Programmed play" section on page 17
and then press the / ( / ) button twice.
To random play all tracks :
Press the RANDOM button on the remote control.
To cancel random play:
Press the / ( / ) button.
"NORMAL" will appear for 2
seconds.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 CX-GD5100V_EN2.fm
17
GX-CD5100W
CD or MP3 disc Playback
Notes:
●If you press the button during random play, you can move to
the track selected next by the random operation. On the other
hand, the button does not allow you to move to the previous
track. The beginning of the track being played will be located.
●In random play, the unit will select and play tracks automatically.
(You cannot select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the ( )
button. Otherwise, the disc will play continuously.
■Programmed play
You can choose up to 32 selections for playback in the order you like.
To cancel the programmed play mode:
Whilst in the stop mode and the "MEMORY" indicator is lit, press the
CLEAR button on the remote control. The "MEMORY" indicator will
disappear and all the programmed contents will be cleared.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indicator
will be displayed. Then follow steps 1 - 5 to add tracks. The new
tracks will be stored after the last track of the original programme.
To check which tracks are programmed:
Whilst the unit is stopped in the programmed play mode, press the
or button.
Notes:
● When open the CD compartment, the programme is automatically
cancelled.
● Even if you change the function from CD to another, the pro-
grammed selections will not be cleared.
● During programme operation, random play is not possible.
1
Whilst in the stop mode, press the
MEMORY button to enter the pro-
gramming save mode.
2
Press the direct search buttons on
the remote control to select
the desired track.
Selected track number
You can also select a track by pressing the or button.
3 Press the MEMORY button to save
the track number.
4
Repeat steps 2 - 3 for other tracks. Up to 32 tracks can be
programmed.
If you make a mistake, the programmed tracks can be cleared
by pressing the CLEAR button.
5
Press the ( ) button.
The total number of memory will ap-
pear.
6
Press the / ( / ) button to start playback.
To clear the programmed selections:
Press the CLEAR button on the remote control
whilst the "MEMORY" indicator is flashing.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 CX-GD5100V_EN2.fm
18
GX-CD5100W
Radio
Listening to the radio
Note:
This product can receive FM stereo/FM monaural and SW1/SW2/
MW monaural broadcast. SW1/SW2/MW stereo broadcasts will not
be played in stereo.
■ Tuning
Notes:
● When radio interference occurs, auto scan tuning may stop
automatically at that point.
● Auto scan tuning will skip weak signal stations.
● To stop the auto tuning, press the TUNING button again.
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
● " " will appear when an FM broadcast is in stereo.
● If the FM reception is weak, press the TUNER (BAND) button to
extinguish the "ST" indicator. The reception changes to monaural,
and the sound becomes clearer.
■ Memorising a station
You can store 40 (FM, SW-1, SW-2 and MW) stations in memory and
recall them at the push of a button. (Preset tuning)
Note:
The backup function protects the memorised stations for a few hours
should there be a power failure or the AC power lead disconnection.
1 Press the ON/STAND-BY button to turn the power on.
2
Press the TUNER (BAND) button repeatedly to select the
desired frequency band (FM, SW-1, SW-2 or MW).
3
Press the TUNING ( or ) button to tune in to the desired
station.
Manual tuning:
Press the TUNING button as many times as required to tune in
to the desired station.
Auto tuning:
When the TUNING button is pressed for more than 0.5
seconds, scanning will start automatically and the tuner will
stop at the first receivable broadcast station.
FM stereo mode indicator
FM stereo receiving indicator
1
Perform steps 1 - 3 in "Tuning" on page 18.
2
Press the MEMORY button to enter the preset tuning sav-
ing mode.
3
Within 30 seconds, press the PRESET ( or ) button to
select the preset channel number.
Store the stations in memory, in order, starting with preset
channel 1.
4 Within 30 seconds, press the MEMORY button to store that
station in memory.
If the "MEMORY" and preset number indicators disappear be-
fore the station is memorised, repeat the operation from step 2.
5
Repeat steps 1 - 4 to set other stations, or to change a pre-
set station.
When a new station is stored in memory, the station previously
memorised will be erased.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 CX-GD5100V_EN2.fm
19
GX-CD5100W
Radio
■ To recall a memorised station
■ To scan the preset stations
The stations saved in memory can be scanned automatically.
(Preset memory scan)
■ To erase entire preset memory
Setting the FM/MW interval
The International Telecommunication Union (ITU) has established
that member countries should maintain either a 100 kHz or 50 kHz
interval between broadcasting frequencies of FM stations and 10
kHz or 9 kHz for MW stations. The illustration shows the 50/9 kHz
zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
This product is not equipped with a span selector. However, it will be
adjusted to a 50 kHz FM (9 kHz MW) interval when shipped from the
factory.
Before using the unit, be sure to set it to the FM/MW tuning interval
(span) used in your area.
To change the FM/MW tuning interval:
Caution:
● When the unit is left for a few hours after the span has been
switched and the AC power lead disconnected, the FM span will
be automatically returned to 50 kHz (MW span to 9 kHz). If this
happens, set the span again.
● When the span is switched, all the memorised stations will be can-
celled.
Press the PRESET ( or ) button for less than 0.5 seconds to se-
lect the desired station.
1 Press the PRESET ( or ) button for more than 0.5 seconds.
The preset number will flash and the programmed stations will be
tuned in sequentially, for 5 seconds each.
2 Press the PRESET ( or ) button again when the desired sta-
tion is located.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the REC PAUSE button and the CON-
TINUOUS PLAYBACK button, press the TUNER (BAND)
button until "TUNER CL" appears.
1 Press the ON/STAND-BY button to turn the power on.
2 Press and hold down the TUNER (BAND) button, for 3 seconds.
3 The display will appear for 2 seconds and the new setting is acti-
vated.
or
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals

04/1/28 CX-GD5100V_EN2.fm
20
GX-CD5100W
Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2)
Auto power off function:
In the stop mode of tape operation, the main unit enters the stand-
by mode after 15 minutes of inactivity.
■ Tape 1 playback (one side)
■ Continuous playback (TAPE 1 to TAPE 2)
To stop playback:
Press the button.
To cancel continuous playback:
Press the CONTINUOUS PLAYBACK button again and " "
indicator will disappear.
Note :
This function cannot be operated from TAPE 2.
■ Tape 2 playback (two sides)
To change the side of tape:
Press the or button during playback.
Before playback:
● For playback, use normal or low-noise tapes for
the best sound. (Metal or CrO tapes are not
recommended.)
● Do not use C-120 tapes or poor-quality tapes, as
they may cause malfunctions.
● Before loading a tape into the cassette compartment,
tighten the slack with a pen or a pencil.
1
Press the ON/STAND-BY button to turn the power on.
2
Press the TAPE (1 2) button to select TAPE 1.
3
Open the cassette compartment by pushing the area
marked " ".
4
Load a cassette into the TAPE 1 cassette compartment
with the side to be played facing towards you.
5 Press the button to start
playback.
Tape play indicator
1
Press the area marked " " and load cassettes into the
TAPE 1 and TAPE 2 cassette compartments.
2
Press the TAPE (1 2) button to select TAPE 1.
3
Press the CONTINUOUS PLAYBACK button.
4
Press the TAPE 1 button to start playback.
● Playback begins from side A on TAPE 1, the playback se-
quence will be as follows:
TAPE 1 side A
→ TAPE 2 side A
→ TAPE 2 side B
→ stop
1
Press the ON/STAND-BY button to turn the power on.
2
Press the TAPE (1 2) button to select TAPE 2.
3
Open the cassette compartment by pushing the area
marked " ".
4
Load a cassette into the TAPE 2 cassette compartment with
side A facing you.
5
Press the button on the remote control to choose one
side or both sides.
… To listen to both sides.
To play both sides ( ), start from side A. When play-
back starts from side B, side A will not be played.
…For endless repeat play of both sides.
…To listen to one side.
6
Press the button to listen to side A, or the button for side B.
Reverse playForward play
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Sharp Manuals
