Sharp CD-PC672 User manual

– 1 –
CD-PC672
No. S4915CDPC672/
CONTENTS Page
IMPORTANT SERVICE NOTES (For U.S.A. Only) ........................................................................................................... 2
SPECIFICATIONS ..............................................................................................................................................................3
NAMES OF PARTS ........................................................................................................................................................... 4
OPERATION MANUAL ...................................................................................................................................................... 7
QUICK GUIDE ................................................................................................................................................................... 8
DISASSEMBLY.................................................................................................................................................................. 9
REMOVING AND REINSTALLING THE MAIN PARTS................................................................................................... 12
ADJUSTMENT ................................................................................................................................................................. 13
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 16
BLOCK DIAGRAM ........................................................................................................................................................... 17
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD..............................................................................................20
VOLTAGE ........................................................................................................................................................................ 40
WAVEFORMS OF CD CIRCUIT...................................................................................................................................... 41
TROUBLESHOOTING (CD SECTION) ........................................................................................................................... 42
FUNCTION TABLE OF IC................................................................................................................................................ 47
FL DISPLAY......................................................................................................................................................................54
REPLACEMENT PARTS LIST/EXPLODED VIEW
PACKING OF THE SET (For U.S.A. Only)
CD-PC672
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
SERVICE MANUAL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
CD-PC672 mini component system consisting of CD-PC672 (main
unit), CP-C672 (front speakers), CP-SW672 (sub woofer),
GBOXS0022AWM1 (center speaker) and GBOXS0023AWM1 (rear
speaker).
Manufactured under license from Dolby Laboratories Licens-
ing Corporation.
DOLBY, the double-D symbol and "PRO LOGIC" are
trademarks of Dolby Laboratories Licensing Corporation.

CD-PC672
– 2 –
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
IMPORTANT SERVICE NOTES (For U.S.A. Only)
BEFORE RETURNING THE AUDIO PRODUCT
(Fire & Shock Hazard)
Before returning the audio product to the user, perform the
following safety checks.
1. Inspect all lead dress to make certain that leads are not
pinchedorthathardwareisnotlodgedbetweenthechassis
and other metal parts in the audio product.
2. Inspect all protective devices such as insulating materials,
cabinet,terminalboard,adjustmentandcompartmentcovers
or shields, mechanical insulators etc.
3. To be sure that no shock hazard exists, check for leakage
current in the following manner.
* Plug the AC line cord directly into a 120 volt AC outlet.
* Using two clip leads, connect a 1.5k ohm, 10 watt resistor
paralleled by a 0.15µF capacitor in series with all exposed
metal cabinet parts and a known earth ground, such as
conduit or electrical ground connected to earth ground.
* Use a VTVM or VOM with 1000 ohm per volt, or higher,
sensitivity to measure the AC voltage drop across the
resistor (See diagram).
* Connect the resistor connection to all exposed metal parts
havingareturnpathtothechassis(antenna,metalcabinet,
screw heads, knobs and control shafts, escutcheon, etc.)
and measure the AC voltage drop across the resistor.
AllcheckmustberepeatedwiththeAClinecordplugconnection
reversed.
Anyreading of0.3 voltRMS (thiscorresponds to0.2 milliamp.
AC.) or more is excessive and indicates a potential shock
hazard which must be corrected before returning the audio
product to the owner.
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
TEST PROBE
0.15 µ F
1.5k ohms
10W
VTVM
AC SCALE

– 3 –
CD-PC672
Front speaker section
Type: 2-way 5-1/4" (13 cm) woofer
and 2" (5 cm) tweeter type
Maximum input power: 80 W
Rated input power: 40 W
Impedance: 6 ohms
Dimensions: Width; 7-7/8" (200 mm)
Height; 11-13/16" (300 mm)
Depth; 9-7/16" (240 mm)
Weight: 6.3 lbs. (2.9 kg)/each
Center speaker section
Type: 4" (10 cm) full-range speaker
Maximum input power: 40 W
Rated input power: 20 W
Impedance: 4 ohms
Dimensions: Width; 10-1/4" (260 mm)
Height; 5-1/2" (140 mm)
Depth; 6-1/8" (155 mm)
Weight: 2.0 lbs. (0.9 kg)/each
Rear speaker section
Type: 4" (10 cm) full-range speaker
Maximum input power: 20 W
Rated input power: 10 W
Impedance: 8 ohms
Dimensions: Width; 6-3/4" (170 mm)
Height; 3-1/2" (88 mm)
Depth; 6-3/4" (170 mm)
Weight: 1.0 lbs. (0.5 kg)/each
Sub woofer section
Type: 5-1/4" (13 cm) full-range
speaker
Maximum input power: 80 W
Rated input power: 40 W
Impedance: 6 ohms
Dimensions: Width; 7-7/8" (200 mm)
Height; 11-13/16" (300 mm)
Depth; 11-5/8" (295 mm)
Weight: 7.5 lbs. (3.4 kg)/each
CP-C672
CP-SW672
GBOXS0022AWM1
General
Power source: AC 120 V, 60 Hz
Power consumption: Stand-by; 0.3 W
Power on; 150 W
Dimensions: Width; 10-5/8" (270 mm)
Height; 11-13/16" (300 mm)
Depth; 14-1/4" (362 mm)
Weight: 17.7 lbs. (8.1 kg)
Amplifier section
Output power: Front speakers; 40 W minimum
(Except for Canada) RMS into 6 ohms from 60 Hz to
20 kHz with no more than 10 %
total harmonic distortion.
Output power: Front speakers;
(For Canada) RMS; 80 W (40 W + 40 W)
(10 % T.H.D.)
Center speaker;
RMS; 20 W (10 % T.H.D.)
Rear speaker;
RMS; 20 W (total)
(10 % T.H.D.)
Sub woofer;
RMS; 40 W
(80 Hz 10 % T.H.D.)
Output terminals: Front speakers; 6 ohms
Center speaker; 4 ohms
Rear speaker; 8 ohms
Sub woofer; 6 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
CD digital output (optical)
Input terminal: Video/Auxiliary (audio signal);
× 2; 500 mV/47 kohms
Tuner section
Frequency range: FM; 87.5 - 108 MHz
AM; 530 - 1,720 kHz
Cassette deck section
Frequency response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/
playback)
Wow and flutter: 0.15 % (WRMS)
Compact disc player section
Type: 3-disc multi-play compact disc
player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A Converter: 1-bit D/A converter
Frequency response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz) Specifications for this model are subject to change without
prior notice.
SPECIFICATIONS
CD-PC672
GBOXS0023AWM1

CD-PC672
– 4 –
NAMES OF PARTS
CD-PC672
■Front panel
11. Disc Number Selector Buttons
12. Disc Tray
13. Multi Indicator
14. Disc Skip Button
15. Open/Close Button
16. Extra Bass Indicator
17. FM Stereo Mode Indicator
18. FM Stereo Indicator
19. (CD) Repeat Indicator
10. (CD) Play Indicator
11. (CD) Pause Indicator
12. Spectrum Analyzer/Volume Level Indicator
13. (TAPE 2) Record Indicator
14. (CD) Disc Number Indicators
15. (CD/TUNER) Memory Indicator
16. Timer Play Indicator
17. Timer Record Indicator
18. Sleep Indicator
19. (TAPE 2) Record Pause Button
20. (CD) Track Down/Review Button
3(TUNER) Preset Down Button
3(TAPE 2) Rewind Button
21. (CD) Track Up/Cue Button
3(TUNER) Preset Up Button
3(TAPE 2) Fast Forward Button
22. Bypass Button
23. Normal Button
24. Timer Set Indicator
25. Timer/Sleep Button
26. Clock Button
27. Power Button
28. Headphone Socket
29. Equalizer Mode Selector Button
30. Dimmer Button
31. Phantom Button
32. Extra Bass/Demo Mode Button
33. Volume Control
34. Function Selector Buttons
35. Memory/Set Button
36. (CD/TAPE) Stop Button
37. (TAPE) Play Button
3(CD) Play/Repeat Button
38. Tuning and Time Up/Down Buttons
39. Sub Woofer Volume Control
40. (TAPE 1) Cassette Compartment
41. (TAPE 2) Cassette Compartment
134
25
6
7
8
9
10
11
12 13
16
17
14 15
18
19 20 21
35
22
25
27
29
26 30
37
31
32
33
34 36 38 39
23
24
28
41
40

– 5 –
CD-PC672
■Rear panel
11. CD Digital Output Socket
12. AC Power Lead
13. FM/AM Loop Aerial Socket
14. Video/Auxiliary (Audio Signal) Input Sockets
15. Rear Speaker Terminals
16. Centre Speaker Terminals
17. Front Speaker Terminals
18. Sub Woofer Terminals
■Front speakers
11. Tweeter
12. Woofer
13. Bass Reflex Duct
14. Speaker Wire
■Centre speaker
15. Full-Range Speaker
16. Speaker Wire
■Rear speaker
17. Full-Range Speaker
18. Speaker Wire
■Sub woofer
19. Woofer
10. Bass Reflex Duct
11. Speaker Wire
CP-C672
CP-SW672
GBOXS0022AWM1
3
2
1
4
5678
1
2
34
9
10
11
5
6
7
8
GBOXS0023AWM1

CD-PC672
– 6 –
CD-PC672
■Remote control
11. Remote Control Transmitter LED
12. Surround Level Buttons
13. Centre Level Buttons
14. Dolby Pro Logic Button
15. Centre Mode Button
16. Test Tone Button
17. Balance Control Buttons
●Tuner control section
18. Preset Up/Down Buttons
●CD control section
19. Memory Button
10. Pause Button
11. Stop Button
12. Play/Repeat Button
13. Clear Button
14. Track Down/Review Button
15. Random Button
16. Track Up/Cue Button
17. Disc Skip Button
●Tape control section
18. (TAPE 1) Play Button
19. (TAPE 1/2) Stop Button
20. (TAPE 2) Record Pause Button
21. (TAPE 2) Rewind Button
22. (TAPE 2) Play Button
23. (TAPE 2) Fast Forward Button
24. Equalizer Mode Button
25. Function Selector Buttons
26. Power Button
27. Extra Bass Button
28. Volume Up/Down Buttons
1
7
4
5
109
6
8
11 12
13
14
24
19
20 22 21
15
17
2
18 16
23
25
26
27
28
3

– 7 –
CD-PC672
OPERATION MANUAL
SETTING THE CLOCK
1
Press the POWER button to enter the stand-by mode.
2
Press the CLOCK button.
3
Within 5 seconds, press the MEMORY/SET button.
4
Press the TUNING/TIME ( or ) button to select the time display mode.
"AM 12:00" →The 12-hour display will appear. (AM 12:00 - PM 11:59) "AM 0:00" →The 12-hour display will appear. (AM 0:00 - PM 11:59) "0:00" →The 24-hour display will appear. (0:00 - 23:59)
●Note that this can only be set when the unit is first installed
or it has been reset (see page 18).
5
Press the MEMORY/SET button.
6
Press the TUNING/TIME ( or ) button to adjust the hour.
●Press the TUNING/TIME ( or ) button once to advance
the time by 1 hour. Hold it down to advance continuously.
●When the 12-hour display is selected, "AM" will change auto-
matically to "PM".
7
Press the MEMORY/SET button.
8
Press the TUNING/TIME ( or ) button to adjust the minutes.
●Press the TUNING/TIME ( or ) button once to advance
the time by 1 minute. Hold it down to change the time in 5 minute intervals.
●The hour setting will not advance even if minutes advance from
"59" to "00".
9
Press the MEMORY/SET button.
●The clock starts operating from "0" seconds. (Seconds are not
displayed.)
Note: ●In the event of a power failure or when the AC power cord is
disconnected, the clock display will go out. When the AC power supply is restored, the clock display will flash on and off to indicate the time when the power failure occurred or when the AC power cord was disconnected.
CLOCK
POWER
MEMORY/ SET
TUNING/ TIME ( )
AM 12:00 AM 0:00 0:00
2 3
4
7
6 5
8 9
If this happens, follow the procedure below to change the clock time.
To change the clock time: ①
Press the CLOCK button.
②
Within 5 seconds, press the MEMORY/SET button.
③
Perform steps 6 - 9 above.
To see the time display:
Press the CLOCK button. ●The time display will appear for about 5 seconds. To change the time display mode: ①
Perform steps 1 - 2 in the section "RESETTING THE MICRO- COMPUTER", on page 18.
②
Perform steps 1 - 9 above.
(Main unit operation)
In this example, the clock is set for the 12-hour (AM 12:00) system.
RESETTING THE MICROCOMPUTER
Reset the microcomputer under the following conditions: ●To erase all of the stored memory contents (clock and timer
settings, and tuner and CD presets).
●If the display is not correct. ●If the operation is not correct. 1
Press the POWER button to enter the stand-by mode.
2
While pressing down the button and the button, hold down the POWER button for at least 1 second.
Caution: ●The operation explained above will erase all data stored in
memory including clock and timer settings, and tuner and CD presets.
2
1,2

CD-PC672
– 8 –
MINI COMPONENT SYSTEM Quick Guide/Guía rápida
CD-PC672
●Remote control x 1 ●
Controlador remoto x 1
●2 “AA” batteries ●
Dos pilas “AA”
Remote Sensor Sensor remoto
2
Preparation for use /
Preparación para su uso
1
Check the supplied accessories /
Compruebe los accesorios suministrados
●FM/AM loop antenna x 1 ●
Antena de cuadro de
FM/AM x 1
●Batteries are not included. ●
Las pilas no están incluidas.
8” - 20’ (0.2m - 6m) 0,2m - 6m
■Speaker connection ■
Conexión de los altavoces
■Antenna connection ■
Conexión de las antenas
Rear speaker (Right)
Altavoz
trasero
(Derecho)
Rear speaker (Left) Altavoz
trasero
(Izquierdo)
Front speaker (Right) Altavoz
delantero
(Derecho)
Front speaker (Left) Altavoz
delantero
(Izquierdo)
●AM Loop Antenna ●
Antena de cuadro
de AM
●FM Antenna ●
Antena de FM
●AC 120 V, 60 Hz ●
120 V de CA, 60 Hz
White line Línea blanca
Red Rojo
Center speaker Altavoz
central
■Turning the power on and off ■
Conexión y desconexión de la alimentación
■Remote control ■
Controlador remoto
POWER
POWER
15
15
Black Negro
Sub woofer Altavozde
subgraves
3
Listening to a CD /
Audición de discos CD
4
Listening to a tape /
Audición de una cinta
5
Listening to the radio /
Audición de la radio
6
Recording from CDs /
Grabaciones de discos CD
7
Sound control /
Control del sonldo
●Label facing up ●
Etiqueta hacia arriba
■To stop the playback ■
Para detener la reproducción
■To stop the playback ■
Para detener la reproducción
●Load the disc to be recorded. ●
Introduzca el disco
que va a grabar.
●CD recording starts. ●
La grabación de
CD empieza.
■Volume ■
Volumen
■Extra bass (X-BASS) ■
Graves extra (X-BASS)
■Pre-programmed equalizer ■
Ecualizador preprogramado
VOLUME
FLAT HEAVY-1 HEAVY-2
SOFT-2 SOFT-1 VOCAL
■To stop the playback ■
Para detener la reproducción
TAPE 1 TAPE 2
TAPE 2
■Sub woofer volume ■
Volumen de subgraves

– 9 –
CD-PC672
DISASSEMBLY
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Takeoffnylon bands orwireholders where theyneedto
beremovedwhendisassemblingtheunit.Afterservicing
theunit,besure to rearrangetheleads where theywere
before disassembling.
4. Take sufficient care on static electricity of integrated
circuits and other circuits when servicing.
Figure 9-2
Figure 9-3
CD-PC672
1 Top Cabinet 1. Screw ..................... (A1) x4 9-1
2 Side Panel 1. Screw ..................... (B1) x8 9-1
(Left/right)
3 CD Player Unit/ 1. Turn on the power supply, 9-2
CD Tray Cover open the disc tray, take out
the CD cover, and close.
(Note 1)
2. Hook....................... (C1) x3
3. Hook....................... (C2) x2
4. Socket .................... (C3) x3
5. Screw ..................... (C4) x2
4 Back Board 1. Screw ..................... (D1) x6 9-2
(with Digital 2. Socket .................... (D2) x1
Output PWB)
5 Main PWB 1. Socket .................... (E1) x2 10-1
2. Flat Cable............... (E2) x1
3. Flat Wire................. (E3) x1
6 Power PWB 1. Screw ..................... (F1) x4 10-1
2. Socket .................... (F2) x4
3. Holder PWB ........... (F3) x5
7 Front Panel 1. Screw ..................... (G1) x2 10-1
8 Display PWB/ 1. Screw ..................... (H1) x13 10-2
Switch PWB 2. Support Bracket ..... (H2) x1
Headphones PWB
9 Tape Mechanism 1. Open the cassette holder. 10-2
2. Screw...................... (J1) x6
3. Socket .................... (J2) x1
10 Turntable 1. Screw ..................... (K1) x1 10-3
2. Cover ..................... (K2) x1
11 Disc Tray 1. Screw ..................... (L1) x2 10-3
2. Guide ..................... (L2) x2
12 CD Servo PWB 1. Screw ..................... (M1) x1 10-4
(Note 2) 2. Socket .................... (M2) x4
13 CD Changer 1. Screw ..................... (N1) x4 10-5
Mechanism
14 CD Mechanism 1. Screw ..................... (P1) x1 10-5
STEP R EMOVAL PROCEDURE FIGURE
Note 1:
How to open the changer manually. (Fig. 9-3)
1. Change, turn fully the lock lever in the arrow direction
throughtheholeontheloadingchassisbottominthisstate.
After that, push forward the CD player base.
Note 2:
1.Afterremoving theconnectorfor theopticalpickup fromthe
connector, wrap the conductive aluminium foil around the
front end of connector to protect the optical pickup from
electrostatic damage.
Figure 9-1
CD-PC672
LOCK
LEVER
Top Cabinet
(A1)x2
ø3x12mm
(A1)x2
ø3x12mm
Side Panel
(Left)
(B1)x2
ø3x8mm
(B1)x2
ø3x10mm
(B1)x4
ø3x10mm
Back Board
(D1)x4
ø3x10mm
(D2)x1
(D1)x2
ø3x10mm
Back Board
CD Tray Cover
Main PWB
CD Player
Unit
Hook
( C1) x3
(C2) x1
(C4) x1
ø3x10mm (C4) x1
(C3) x3
1
1
2
Pull
(C2) x1

CD-PC672
– 10 –
Figure 10-1
Figure 10-2
Figure 10-3
Be careful when installing the CD changer mechanism.
InstalltheCDchangermechanismontheCDplayerbaseafter
the shift lever has been set in the highest position.
Figure 10-4
Figure 10-5
( L1 ) x1
ø3 x10mm
( L1 ) x1
ø3 x10mm
( K1 ) x1
ø3 x10mm
Turntable
Disc Tray
( K2 ) x1
( L2 ) x1
( L2 ) x1
CD Player Unit
Washer
( M1 ) x1
ø3 x10mm
( M2 ) x2
( M2 ) x2 CD Player Unit
CD Servo PWB
( N1 ) x4
ø3 x12mm
( P1 ) x1
ø2.6 x10mm
CD Changer
Mechanism
CD Mechanism
Shift Lever
CD Player Base
Front Panel
Display PWB
(H2)x1
Switch PWB
Open
Cassette
Holder
Tape Mechanism
(H1)x2
ø3x10mm
(H1)x10
ø3x10mm
(H1)x1
ø3x10mm
(J1)x6
ø3x10mm (G1)x2
ø3x10mm
Headphones
PWB
(J2)x1
(F1)x3
ø3x10mm
(E1)x2
(F3)x5
(E2)x1
Front Panel
(F2)x2
(F2)x2
(F1)x1
ø3x10mm
Push Push
1 1
2Pull
POWER
PWB
Main PWB
POWER PWB
(E3)x1
Headphoens
PWB

– 11 –
CD-PC672
CP-C672
1 Front Speaker 1. Net.......................... (A1) x1 11-1
2. Front Panel ............ (A2) x1
3. Screw ..................... (A3) x4
4. Tip .......................... (A4) x2
5. Screw ..................... (A5) x2
6. Tip .......................... (A6) x2
STEP REMOVAL PROCEDURE FIGURE CP-C672
Figure 11-1
Figure 11-2
CP-SW672
CP-SW672
1 Front Speaker 1. Net.......................... (A1) x1 11-2
2. Duct Panel ............. (A2) x1
3. Screw ..................... (A3) x4
STEP REMOVAL PROCEDURE FIGURE
Note:
The rear speakers and center speaker can be easily
disassembled.
Therefore the disassembling method is not discribed.
For details refer to the disassembling drawing in the
Parts Guide.
(A6)x2
(A5)x2
(A3)x4
(A4)x2
Front Panel
(A2)x1
Net
(A1)x1
Screw Driver
( A3 ) x4
ø4 x16mm
Net
( A1 ) x1
( A2 ) x1 Screwdriver
Woofer

CD-PC672
– 12 –
MECHANISM SECTION
•Driving Force Check
Torque Meter Specified Value
Play: TW-2412 Tape 1: Over 80 g
Tape 2: Over 80 g
•Torque Check
Torque Meter
Tape 2
Play: TW-2111 30 to 60 g. cm 30 to 60 g.cm
Fast forward: TW-2231 — 60 to 120 g.cm
Rewind: TW-2231 — 60 to 120 g.cm
Specified
Value
Adjusting
Point Instrument Connection
Test Tape
Normal MTT-111 Volume in 3,000 ±Speaker
speed motor. 30 Hz terminal
(MM1) (Load
resistance:
8 ohms)
ADJUSTMENT
Specified Value
Tape 1
•Tape Speed
TAPE MECHANISM
MM 1
Motor
Volume in motor
How to remove the pickup (See Fig. 12-2)
1.Removethescrews (B1) x 2pcs.,toremove the shaft (B2).
2. Remove the stop washer (B3) x 1 pc., to remove the gear
(B4).
3. Remove the pickup.
Figure 12-2
REMOVING AND REINSTALLING THE MAIN PARTS
CD MECHANISM SECTION
Performsteps1, 2, 3and10-14 ofthedisassembly method to
remove the CD mechanism.
How to remove the loading motor
(See Fig. 12-1)
1. Remove the screws (A1) x 2 pcs., to remove the loading
motor.
Figure 12-1
( A1 ) x2
ø2.6 x5mm
Loading / Up
/ Down Motor
Motor
PWB
( B1 ) x2
ø2.6 x6mm
Shaft
( B2 ) x1
Stop Washer
( B3 ) x1
Gear
( B4 ) x1
CD Mechanism
Pickup
Note
After removing the connector for the optical pickup from the
connector, wrap the conductive aluminium foil around the
front end of connector to protect the optical pickup from
electrostatic damage.

CD-PC672
– 16 –
•The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
1. In the tuner section,
( ) indicates AM
< > indicates FM stereo
2. In the main section, a tape is being played back.
3. In the deck section, a tape is being played back.
( ) indicates the record state.
4. In the power section, a tape is being played back.
5. In the CD section, the CD is stopped.
•Parts marked with “ ” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
NOTES ON SCHEMATIC DIAGRAM
•Resistor:
To differentiate the units of resistors, such symbol as K and
M are used: the symbol K means 1000 ohm and the symbol
M means 1000 kohm and the resistor without any symbol is
ohm-type resistor. Besides, the one with “Fusible” is a fuse
type.
•Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means micro-micro-farad and the unit of the
capacitor without such a symbol is microfarad. As to
electrolyticcapacitor,theexpression“capacitance/withstand
voltage” is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
•Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
REF. NO DESCRIPTION POSITION POSITION
SW715 VIDEO ON—OFF
SW716 TAPE ON—OFF
SW717 CD ON—OFF
SW722 FF ON—OFF
SW723 TUNING UP ON—OFF
SW724 TUNING DOWN ON—OFF
SW725 PLAY ON—OFF
SW728 X-BASS/DEMO ON—OFF
SW729 EQUALIZER ON—OFF
SW730 DIMMER ON—OFF
SW731 PHANTON ON—OFF
SW732 NORMAL ON—OFF
SW733 BYPASS ON—OFF
SWM 3 FOOL PROOF ON—OFF
SWM 4 F.A.S. ON—OFF
REF. NO DESCRIPTION
SW1 OPEN/CLOSE ON—OFF
SW2 MECHA UP ON—OFF
SW3 DISC NUMBER ON—OFF
SW4 PICKUP IN ON—OFF
SW701 POWER ON—OFF
SW703 CLOCK ON—OFF
SW704 TIMER/SLEEP ON—OFF
SW705 DISC 1 ON—OFF
SW706 DISC 2 ON—OFF
SW707 DISC 3 ON—OFF
SW708 DISC SKIP ON—OFF
SW709 OPEN/CLOSE ON—OFF
SW710 REW ON—OFF
SW711 REC PAUSE ON—OFF
SW712 MEMORY/SET ON—OFF
SW713 STOP ON—OFF
SW714 TUNER/BAND ON—OFF
Figure 16 TYPES OF TRANSISTOR AND LED
SVC211C
SVC348S
KTA1273 Y
KTC3203 Y
KTC3194 Y
KTC3199 GR
2SC2389 SE
KTA1274 Y
KRA102 M
KRA109 M
KRC102 M
KRC104 M
KRC107 M
KTA1266 GR
KTA1271 Y
FRONT
VIEW
E C B
(S)(G)(D)
(1) (2) (3)
2SA1318
FRONT
VIEW
B C E
(D)(G)(S)
(3) (2) (1)
1 2 3 L1154GT4
SLI342YCB
SLI342DCB
SLI342UCB
SLI342YCJ
SLI3256YC
SLI342UCJ1
VIEW
FRONT

– 17 –
CD-PC672
Figure 17 BLOCK DIAGRAM (1/3)
27
123418
67
18244020
45
15
23 16 26 27
7
2
25
20
29
21
22
35
14
3839284142 37 36
PU-IN SW
XL1
XIN
LD0
FIN2 JP–
CV+
SLC
SL1
FIN1 E F
TO
FD
SPO
NC
SLD
SL–
SL+
DRF
CL
DAT
CE
VCC1
6
+5V
PICKUP IN
SW4
FOCUS COIL
TRACKING COIL
M1
SPINDLE
MOTOR
M
M
M2
SLED
MOTOR
PICKUP UNIT
9
IC2
LC78622NE
SERVO/SIGNAL
CONTROL
+B1
IC3
M63001FP
FOCUS/
TRACKING/
SPIN/SLED
DRIVER
IC1
LA9241M
SERVO AMP.
RES. CQCK. COIN SQOUT. RWC. WRQ
~
~
~
CL, DAT, SELIAL CONTROL/CE
Q51
SL+. SL–. DRF
987654321
GND (D) MECHA UP GND (D) DISK NO. OPEN/CLOSE GND (D) M– M+ GND (M)
987654321
CNP10
M
+5V
+B1
62
64
45
36
23
43
37
31 38 39 40 24 25
10
12
21
3
321456
10
26
58
53
10 12 20
32 40 43 44
53
52
51
54
31
30
29
23
27
16
15
41
44
Q1
Q52
+4.3V
Q81
+7.3V (B1)
REGULATOR
TO MAIN SECTION
(TO IC601)
XOUT
EFMO EFMIN CLV+ JP–
CONT2 CONT1
LCHO
LVSS
RVSS
RCHO
VVDD
VDD
LVDD
RVDD
XVDD
SW1 OPEN/CLOSE
SW2 MECHA UP SW3 DISC No.
M3 LOADING
SOLM1
TO MAIN
SECTION
CNS10
+B5
~~
CNP11
BI1B
21
BI1A
CNP99
+5V
24 8
33
38
39
46
~
64
62
51
11
22

CD-PC672
– 18 –
Figure 18 BLOCK DIAGRAM (2/3)
IC
9
LA
4
P
O
X501
VOLUME
JOB
VR702
5 6 21
16
22
13
20
16
21
17
1 3
24 23
15
20 1 22
15
9
10
11
7
11 3 4 5 6
10
GNDAM IF FM DET
FM DET
FM IN
IC302
LC72131
PLL (TUNER)
OSC
VR381
MPX VCO ADJ
AM IF
AM MIX
AM IN AM+B
AM RF IN
X352
4.5MHz
FMOSC
AM TRACKING AM OSC
T382
+B4 +B4
T381
IC303
LA1805
FM/AM IF MPX.
DET OUT
L
R
STEREO
AM OSC IN
Q381
Q382
VT
DO DI CL CE
1
24
2
23
3
4
4
21
5
20
6 7
17
8
9
16
10
14
12
13
18
H/N
T1/T2
R-CH
L-CH
L-CH
R-CH
P.B
REC
TAPE 2
TAPE 1
L NF
L(T1)
R(T1)
L(T2)
R(T2)
R NF
L
R
POP REDUCE
L REC
R REC
L
R REC
P.B.
REC
ALC
NOR/
HIGH T1/T2
REF L NF
R NF
PB HEAD
REC PB HEAD
SWITCHING
Q103~Q106
AC BIAS
IC101
AN7345K
PLAYBACK AND RECORD
/PLAYBACK AMP.
PB
ERASE
HEAD
SWITCHING BAIS
Q126
Q124
Q128
L104
Q111
Q110
Q109
Q107
Q108
SWITCHING SWITCHING
SWITCHING
+B4
1
2
3
CNS11
FROM CD SECTION
CNP11
17 +B4
VOLTAGE
REGURATER
SWM3
FOOL PROOF
SWM4
F.A.S
SOLM1
SOLENOID
SWM5
CAM
52
60
51
61
53
59
54
58
55
57 49
63 48 33
48
33
45
44
34
38
35
37
36
33 32
1
3
9
9
IC401
LC75396N
AUDIO PROCESSOR
L
L
R
R
L
R
L
R
L
R
L
R
L
L
R
R
TUNER
VIDEO1
L
R
VIDEO2
TAPE
CD
3
IC704
1
+B7 2
BAIS
T1/T2
REC
MUTING
Q121
Q122
+B4
FM/AM
SWITCHING
17
31
30
18
22
20
28
Z
9
1
2 3 4 5 7 8
6
Q301
FM IF IN
FM IF
FM RF
FM
OSC
T301
FM OSC
FM
ANTENNA
FM B.P.F
IC301
TA7358AP
FM FRONT END
T301
L312
OSC BUFF
L301
7
FM
Q351
FM +B
SWITCHING
CF301
FM+B MO/ST
VCO
FM/AM
BIAS
OCS
15 19
23 24 25 56
MONO/ST
JK401
VIDEO IN
MPXIN
AM LOOP
ANTENNA
T331 T333
CF351
M
MM
TAPE M
O
IC501
LV1035M
DOLBY PRO LOGIC
DECORD
CL DI CE

– 19 –
CD-PC672
Figure 19 BLOCK DIAGRAM (3/3)
Q704
IC951
LA4551
POWER AMP.
IC803
IC806
IC805
IC804
IC650
IC651
Q601,Q602
Q603, Q604
KIA4558P
OPE AMP.
IC601
NJM4560D
OPE AMP.
D802
F804
3A/250V
F902 4A/125V
F901 4A/125V
IC471
Sub Woofer
Volume
VR701
F903
4A/125V Sub Woofer
Front
Speaker
Center
Speaker
Rear
Speaker
SO901
Speaker Terminal
1 2 3 4 15 2516 26 28 373839
FL701
DISPLAY
9 8 7 6 5 4 3 2 1
IC701
IX0310AW
SYSTEM CONTROL
MICROCOMPUTER
13 9
1
7
13 2
13 2
13 2
13 2
6
VDD
UNSWITCH
+B7
MEMORY
BACK UP
VDD
XL701
4.19MHz
+B5 +B7
KEY
SW703~SW717
SW722~SW725
SW728~SW733
Q908
Q904
Q903Q405
+B5
M
Q905
+B1
TO CD
SECTION
M901
FAN MOTOR
JK970
HEADPHONES
T.F
PT801
POWER
TRONSFORMER
RL801
AC POWER
SUPPLY CORD
AC 120V, 60Hz
PT802
POWER
TRONSFORMER
Q802
+B6
+B7 UNSWITCH
D801
D803~D806
Q801 D807
~D809
2 3
1
+B7
RX701
Q705
Q706
Q707
2
437
1 3
3 1
7
4
5
9
8 L-OUT
IC901
STK40704
POWER AMP.
–B +B R-OUT
Q401
Q402
ZD801
Q403
Q404
+B4
+B5
+B2
+12V(ANALOG)
+12V(MOTOR)
+5.6V
+5V
VOLTAGE
REGULATOR
VOLTAGE
REGULATOR
VOLTAGE
REGULATOR
VOLTAGE
REGULATOR
Q702
Q703
AVDD
~~~
16
18
12
15 20
101112131415161718192021222324
25
2627
282930
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
7170696867666564636261 80797877
767574
737260595857
56
5554
535251
VDD
PHM1
D811~D814
FRONT
F802
5A/125V
F803
5A/125V
F805
2A/250V
29 36
~
M
MM1
T
APE MOTOR
+B7
+B7
Q907
RL901
RL902
Q906

CD-PC672
– 20 –
Figure 20 SCHEMATIC DIAGRAM (1/12)
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 16.
D1
1SS133
C77
100/16
R36
220K
C57
0.001
R1
22
R35
220K
C21
0.0033
C20
47/16
C82
100/16
C55
100/16
R56 6.8K
C36
100/16
IC3
M63001FP
FOCUS/TRACKING/SPIN/SLIDE DRIVER
C25
27P R39
1K
C15
0.01
R41
47K
R43
56K
R44
33K
R42
47K
R28
10K
R29
56K
C17
0.001
R30
6.8K
R20
1K
R19
1K
C3
1/50
R34
3.3K
R11
6.8K C6 0.033
R10
2.2K C5
0.033
C54
0.001
R8
15K
R9
100K
C16
0.0047
R27
39K
R25
1.5K
R24
47K
R17
33K
C29
4.7/50
C28
0.1
C14
0.01
C4
0.1/50
C35
1/50
Q1
2SA1318
R18
15K
C11
0.1
IC1
LA9241M
SERVO AMP.
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
C13
330P
R26
82K
R37
82K
C19
1/50
R33
1.2K
R32
10K
C32
0.01
C31
220/6.3
C30
0.1/50
C27
0.001
C24
2.2P
R40
5.6K
C26
0.033
R31
1.2K
C18
0.47/50
R16
3.3K
C10
180P
C8
0.068
C7
0.1/50
R12
100
R13
1K
R14
27K
C12
0.1
R2
1K C1
47/16
C2
0.01
CNP3
R46
560
R38
470
R45
4.7K
C22
220P
R22
820
R21
1.5K
C34
0.33/50
C33
0.47/50
NC
SL_+
SL_–
CD_PUIN
SP+
SP–
(SPN)
VCC2
VCC4
CNS2ACNS2B
LD
VR
PD
GND
FO–
FO+
TR+
TR–
ACTUATOR
FO+
FO–
TR–
TR+
1M
2200P
1M
2200P
1/16
K
F
B
E
A
LD_M+
LD_M–
VCC3
M–
M+
SOL+
SOL–
SP–
SP+
SPO
SOL–
SOLD
MUTE
Vref
STANDBY
VCC1
SLD
SL–
SL+
GND
GND
TR+
TR–
FO–
FO+
FO (GAIN)
FD
TO
GND
LD
VR
PD
GND
FO–
FO+
TR+
TR–
TP1
HF
TE
TBC
JPCLO
SLOF
SLOF
SLOF
FSC
FE1
FOSTA
FSC
EFBAL
REF
JP
REF
CV–
REF
CV+
JP–
JP+
VREF
2FREQ
LASER
8/12CM
FSTA
S.Q.R
FOSTA
TOSTA
LATOH
FSTA
SLOF
CL
CE
DRF
HFL
DEF
VCC
THD
GL
THDL
TGL1
VCR
VCR
VCR
VCR
FE1
REF
–
+
–
+
–
+–
+
–
+
REF
RF
REF
DGND
SLI
FIN2
FIN1
E
F
TB
TE–
TE
TESI
SCI
REF
REF
REF
REF
REF REF
REF
REF
REF
REF
REF
TO
REF
JP
REF
TH
TD
TD–
JP
TO
FD
GEN
GEN
GEN
FD–
FA–
FA FE
FE–
AGND
SP
SPI
SPG SP–
SPO SLEO
SLD
SL– SL+
REF
REF
REF
REF
OR
REF
RF
SLC
RFSM
JP–
JP+
TGL
TOFF
TES
HFL
SLOF
CV–
CV+
CNP1
5
4
3
2
1
5
4
3
2
1
8
3
6
7
1
4
5
2
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
42
41
40
39
38
37
19
20
21
1 2 3 8
7
6
5
4
1
2
3
4
5
6
2
5
7
6
3
8
2
5
4
1
7
6
3
8
4
1
8
7
6
5
4
3
2
1
NC
64
63 62 61
60 59 58 57 56 55
54 53 52 51 50 49
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
VCC1 LDS
LDO
BHI
PHI
LF2
VR
REF1
VCC2
FSS
DRF
CE
DAT
CL
CLK
DEF
K
A
B
E
F
CD_GND
CNP12
CNP2
C37
0.02
2
R47
10K
D_GND RES(DSP) WRQ(DSP) RWC(DSP)
CQ CK(DSP) CO IN(DSP) SQ OUT(DSP)
DRF(ASP)
SLD+
R15
12K
C9
0.047
TR–
TR+
FO+
FO–
PD
C76
0.022
LD
CNS1A
5
1
2
3
4
F
B
A
E
K
CNS1B
5
4
3
2
1
+B
CNS12
FROM DISPLA
P29 12-
D
1
CNS3B
2
3
4
5
6
1
CNP3A
2
3
4
5
6
M
M1
SPINDLE
MOTOR
M
M2
SLED
MOTOR
SW4
PICKUP IN
+
+
–
–
CD MOTOR PWB-D
SPIN
SLIDE
PU-IN
1
CNS3A
2
3
4
5
6
RFS–
C23
0.0027
PICKUP UNIT
R23 10K
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+

– 21 –
CD-PC672
Figure 21 SCHEMATIC DIAGRAM (2/12)
78 9 10 11 12
• The numbers 1 to 12 are waveform numbers shown in page 41.
R54
330
R84
2.2K
IC2
LC78622N
R55
100
C57
0.001
R65
1K
D82
1SS133
C83
0.022
R80
820 R81
820
Q51
KRC102 M
D92
1SS133
D93
1SS133
R83
390
R82
390
C56
0.022
R91 1K
D91
1SS133
Q52
KTC3203 Y
C52
100/16
R64
22
R66
220
ZD61
MTZJ5.6B
C51
100/16
C50
0.022
L61
0.82µH
C46
100P
R51
3.3M
R88 1.2K
XL1
16.934MHz
C41
12P
C42
15P
R93
220
D81
1SS133
C45
100P(CH)
C44
100P(CH)
R89 1.2K
R90 220
R50
680
C39
0.047
C40
0.047
R52
27K
R60
1K
R57 1K
R58 1K
R61 1K
R59 1K
C38
0.01
R63 1K
R62 1K
C49
100P(CH)
C48
100P
C43
330/6.3
R74
100K
R73
100K C73
220P
C74
220P
R53
1.2K
C47
100P(CH)
C75
0.001
C71
10/50
C72
10/50
R71
2.7K
R72
2.7K
NC
NC
PIN27
LOW
HIGH
TRY SPEED
+5V
TEST5
/CS
TA1
SOL+
SOL–
M+
M–
GND(D)
OPEN CLOSE
DISC NO.
GND(D)
MECHA UP
GND(D)
+
–
2KX8
RAM
1BIT DAC
SERVO
COMMAND
TES
HLF
V/P
CLV–
CLV+
TEST2
EFMIN
EFMO
VSS
FR
VVDD
ISET
VVSS
PDO
DEF1
TOFF
TGL JP+ JP– PCK FSEQ VDD
CONT1
CONT2 CONT3 CONT4
CONT5
EMPH C2F
CLV
DIGITAL
SERVO
EXTERNAL
OUTPUT
SYNC-DETECT
EFM DEMODULATE
SLICE
LEVEL
CONTROL
VCO
CLOCK
OSC
CONTROL
ERROR
COERECT
FLAG
CONTROL
DIGITAL
OUT
TEST3
DOUT 4FS
DIGITAL
FILTER
TEST1
TEST4
MUTEL
LVDD
LCHO
LVSS
RVSS
RCHO
RVDD
MUTER
XVDD
XOUT
XIN
XVSS
SBSY
EFLG
SUB-CODE
MICRO-COM
INTERFACE
TEST11
SBCK
SFSY
PW
FSX
WRQ
RWC
SQOUT
COIN
/CQCK
/RES
16M
4M
X-TAL
GENERATOR
CNP11
1
CNS5
2
1
2
3
4
5
6
7
8
9
10
1
CNS10
2
3
4
5
6
7
8
9
10
CNP10
1
BIM5
2
3
4
5
6
48
47
45
44
43
42
41
40
39
38
37
36
35
34
33
64 63 61
62 60 59 58 57 56 55 54 53 52 51 50 49
46
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
5
4
1
2
3
16
15
14
13
12
11
10
9
8
7
6
9
8
7
6
10 11 12 13 14 15
1
2
1
2
3
4
5
6
NC NC
NC
NC
NC
NC
NC
NC
NC
NC NC
NC
NC
11 22 33
CNP99
BI99
2
M
M3
TURNTABLE
UP/DOWN
LOADING MOTOR
CD_RCH
A_GND
CD_LCH
M–
M+
CD_D_NO
C37
0.022
R47
10K
D_GND RES(DSP) DRF(ASP) SLD+ SLD– PUIN SW
SW1
OPEN/CLOSE
SOLM2
SOLENOID
SW3
DISC NUMBER
SW2
MECHA UP
PCCL OP/CLOS UP/DOWN DISC NO.
CNS12
M
DISPLAY PWB
P29 12-D
+12V
D-GND
+7V
L-CH
A_GND
R-CH
+B
+B
2
1
BI1-A
1
BI1-B
+B
CD SIGNAL
CNS99
CNS11
FROM MAIN PWB
P22 6-A
TO DIGITAL OUT PWB
P31 12-B
SERVO/
SIGNAL
CONTROL
(CH)
CD SENSOR PWB-E
CD SERVO PWB-B

CD-PC672
– 22 –
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 16.
Figure 22 SCHEMATIC DIAGRAM (3/12)
R521 1K
R522 1K
C563 0.022
C532 220/16
R512 4.7K
R509 4.7K
R507 1K
R506 4.7K
R505 4.7K
D516
1N4004S D515
1N4004S
C531 2.2/50
R508 39K
C527 10/50
C524 10/50
C523 10/50
C521 0.33/50
C547 0.022
C541 220/16
IC501
LV1035M
DOLBY PRO LOGIC
DECORDER
C544
220/16
C519 0.47/50
R503
1K
R518 1K
C508 680P
C507 0.047
C506 0.022
C505 0.47/50
C504 47/25
C503 1/50 C502 1/50
C509 0.1(ML)
X501
C514 0.082(ML)
C515 0.0033(ML)
C517 0.082(ML)
R501
100K
C420
0.0047(
M
C42
1/5
0
C412
C410
C414
C416
C418
0
0.
C408
NC
D_GND
D_GND
H/PSW
Q11
SPEANA1
SPEANA2
SPEANA3
TUN SM
M_+12V
SR_MUTE
S_MUTE
ENA
SPN_P
CLK
A_GND
SUB_VOL_OUT
SUB_VOL_IN
4V
0V
0V
R_RECT
L_RECT
VLR_TH
VLR_1
VLR_2
VCS_2
VCS_1
VCS_TH
L+R_RECT
L-R_RECT
DC_OUT1
DC_OUT2
DC_OUT4
DC_OUT3 OSC
OSC
VDD
A/D
NS
D/A
DC_OUT
DC_OUT
L_OUT
R_OUT
S_OUT
D_GND
IREF
DET
VCC
S_IN R_IN L_IN AC_GND L_OUT R_OUT S_OUT C_OUT VCC VREF L_DC_OUT R_DC_OUT C_DC_OUT S_DC_OUT R_BPF1 R_BPF2
TAPE BIAS
REC/PLAY
T1/T2
CE
DI
DO
C MUTE
POWER
123456
123456
CNS11
TUN_SM
A_GND
TUN_R
A_12V
TUN_L
DO
CE
DI
D_GND
M_GND
A_12V
REC_MUTE
BIAS
T1/T2
123456789
10 11 12 13 14 15 16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33343536373839404142434445464748
49
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
64
C436 22/25
R443 22K
C437 22/25
R442 22K
C438 22/25
R514
330
R513
3.3K R515
3.3K
C535 10/50 C536 10/50
C537 10/50
C538 10/50
C539
220/16
C540
10/50
C543
0.1(ML)
C534 0.1(ML)
R516 1K C549 100P
R523 1K
R517 1K C551 100P
C501
0.1
(ML)
R502 100K R520 22K
R519 1K
C550 100P
R504
1M
C542
220/16
R510
18K
CNP5021
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Q405
KRC104
M
D402
DS1SS1
3
R511
1K
A_GND
REC_L
TAPE_R
D_GND
TAPE_L
REC_R
C510 0.47/50
C512 4.7/50
C511 0.47/50
C513 4.7/50
C516 0.15/50
C518 3.3/50
C520 0.15/50
C522 0.15/50
C525 3.3/50
C526 0.15/50
C528 4.7/50
C529 0.47/50
C530 4.7/50
C533 0.47/50
L_BPF3
R_BPF3
L_BPF2 L_BPF1
RT_IN
LT_IN
C_MODE
DC_OUT
GND
NS_BPF1 NS_BPF2
OSC
CLK
ENABLE
CLK
VSS
DATA DATA
1 2
3
123456789
10 11 12 13 14 15 16 17 18 19 20 21
+B
+B
A_GND
LCH
RCH
D_GND
7.3V
M_12V
BI401
+B
C546
0.022
+B
+B
+B
+B
+B
FFC701
+B
MAIN PWB-A1(1/3)
TO TUNER SECTION
P27 12-F TO DECK SECTION
P25 12-B
TO CD SERVO PWB
P21 12-C
CNP11
CNP701
TO DISPLAY PWB
P28 1-D
CL

– 23 –
CD-PC672
Figure 23 SCHEMATIC DIAGRAM (4/12)
78 9 10 11 12
C627
22/25
R449
470
R450
470
R625
22
R613
100K
R445 330
C442 0.001
R614 100K
C607
47/25
C609
100P
R615
12K
C441
0.001
R447
330
R433
10K
R444
10K
R426 1K
R427 1K
R424
220K
C430
2.2/50
C432
47/25
C431 47/25
C429
2.2/50
C440
0.001 C439
0.001
C444
1/50
C449 0.047(ML)
C451 0.047(ML)
C453 0.047(ML)
C455 0.047(ML)
C457 0.047(ML)
C458 0.047(ML)
C456 0.047(ML) C454 0.047(ML)
C452 0.047(ML) C450 0.047(ML)
R416 1K R414 1K
R417 1K
R418 1K
C427 0.047(ML)
C420
0.0047(ML)
C424
10/50
C422
1/50
C423 10/50
R415 1K R413 1K
R412 1K
R411 1K
R428 1K
C435 47/25
C426 10/50
C412 0.22/50
C410 0.068(ML)
C414 0.027(ML)
C416 0.015(ML)
C418 0.0022(ML)
C421
1/50
C428
0.047(ML)
R423
220K
IC401
LC75396N
AUDIO PROCESSOR
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49505152535455565758596061626364
R410 1K
R409 1K
C433 2.2/50
C425 10/50
C406
0.22/50
C404
0.082(ML)
C408 0.018(ML)
R434 2.2K R435
22K
IC601 NJM4560D OPE AMP.
C603
47/25
R612
560
R611
560
C605
100P
C615
0.001
C616
0.001
R608
2.2K
R607
2.2K
R617 1K
C617
0.001
Q601
KTC3199 GR
C604
47/25
C618
0.001
Q602
KTC3199 GR
R610
100K
R609
100K
0V 0.7V
0V
0V
0V
0V
0V
0V
4V
0V
0V
RINVIN1
R5
R4 R3 R2 R1
VDD
L1 L2 L3 L4
L5
LINVIN1
LSELO
LF4C3
LF4C2
LF4C1
LF3C3
LF3C2
LF3C1
LF2C3
LF2C2
LF2C1
LF1C3
LF1C2
LF1C1
LTIN
LF5
LTOUT
LFIN
LFCOM LFOUT CIN LRCOM COUT VSS CL DI CE LVREF VREF RVREF RROUT RRCOM RRIN RFOUT
RFCOM
RFIN
RTOUT
RF5
RF4C3
RF4C2
RF4C1
RF3C3
RF3C2
RF3C1
RF2C3
RF2C2
RF2C1
RF1C3
RF1C2
RF1C1
RTIN
R471
220K
R472
220K
C481
0.022
C482
2.2/50
R482
100K
R480
1.5K
C479
10/50
C478
0.082
(ML)
IC471
KIA4558P
OPE AMP.
7
6
5
3
21
R481
1K
C480
47/25
C474
0.15
(ML) R476
27K R479
12K
R477
27K
R475
3.9K
C477
100P
C476
0.15
(ML)
C471
0.047
(ML)
C473
47/25
R478 6.8K
R474
15K
C484
0.001
R627
100
R403
1.8K
R404
1.8K
C461
390P
C462
390P
R448 330
123456789
10 11 12 13 14 15
6
6
CNS11
8
4
4
R401
27K
R405
27K
R406
27K
R664
220K
IC650
KIA4558P
D654
DS1SS133
IC651
KIA4558P
C666
2.2/50
R668
2.2M
R662
220K
R657
15K
C651
270P
C653
0.0027
R654
68K
R652
33K
R653
12K
R651
10K C657
270P
C659
0.0027
R658
390K
R655
56K
C661 0.022
R661 270K
C656
0.0068
C662
0.022
D652
DS1SS133
R663 330
C663
0.022
4
2
31
8
7
5
6
4
2
31
8
7
5
6
C436 22/25
R443 22K
C437 22/25
R442 22K
C438 22/25
C447
2.2/50
R421
2.7K
C445
100P
R419
33K
C448
2.2/50
R422
2.7K
C446
100P
R420
33K
C403 0.082(ML)
C401
0.047(ML)
C405 0.22/50
C407 0.018(ML)
C409 0.068(ML)
C411 0.22/50
C413 0.027(ML)
C415 0.015(ML)
C417 0.0022(ML)
C419 0.0047(ML)
C460 0.022
C459 1000/16
R484 100K
C475
47/25
R473
100K
C472
100P
R483
100K
SPEANA3
SPEANA2
SPEANA1
R674
100K
C664
2.2/50
C667
0.022
ZD651
DZ6R2BSC
R656
470K
C655
0.0068
R659 560K
C443
1/50
C402
0.047(ML)
R402
27K
R408
1.8K
R407
1.8K
C464
390P
C463
390P
2
1
3
4
6
5
VIDEO_2
IN
VIDEO_1
IN
L-CH
R-CH
L-CH
R-CH
JK401
R441 22K
R624
22K R606
22K R602
2.2K
C602
0.047
(ML)
5
6
R618 12K
C610
100P
C606
100P
R616
1K
C614
0.022
R622
2.7K
C613
220/16
C612
10/50 R626
22
7
C611
10/50 R621
2.7K
1
3
28
R601
2.2K
C601
0.047
(ML)
R605
22K
R623
22K
Q603
KTC3199 GR
R603
2.2K
Q604
KTC3199 GR
R604
2.2K
R429 47K
R430 47K
R431 47K
R432 47K
R666
2.2M
Q401
KTC3199 GR
Q402
KTC3199 GR
R440 2.2K
Q403
KTC3199 GR
R437
2.2K
Q404
KTC3199 GR
Q405
KRC104 M
D402
DS1SS133 D403
DS1SS133
R438 2.2K
R439
2.2K
0.7V
C434
2.2/50
R436
22K
R446
330
R660
390K
D651 DS1SS133
D653
DS1SS133
R665
100K
C665
2.2/50
R672
100K
R425
220K
R670 330
1 2
3
M
_
12V
BI401
+B
+B
+B
+B
+B
+B
R619 27
R620 27
C621
0.001
JK601
HEADPHONES
5
4
3
2
1
CNP601
GND
H/P SW
GND
L
R
FW601
–B
+B
R486
6.8
(1/2W)
+B
+B
–B
M_GND
+12V (M)
+12V (A)
D_GND
(CD)
CD_GND A_GND
POWER
SUB_WOOF CENTER_OUT
REAR_OUT
FRONT_Rch
FRONT_Lch A_GND
–15V
7.3V
CNP501
CNP803
TO POWER PWB
P30 1-E
+B
+B
+B
1
5
OPE AMP.
OPE AMP.
FM SIGNAL
PLAYBACK SIGNAL
RECORD SIGNAL
PWB
HEADPHONES PWB-A4
CD SIGNAL
