Sharp 14GT-16C User manual

1
14GT-16C/21C
20GT-21C/21GT-21C
WARNING
The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power
receptacle, when servicing this chassis. To prevent electric shock, do not remove cover. No user – serviceable
parts inside. Refer servicing to qualified service personnel.
SERVICE MANUAL
S52i714GT-16C
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
MODELS
14GT-16C
14GT-21C
20GT-21C
21GT-21C
SHARP CORPORATION
COLOUR TELEVISION
Chassis No. GA-1
Page
CONTENTS
»SPECIFICATIONS .............................................2
»IMPORTANT SERVICE NOTES ........................2
»ADJUSTMENT PRECAUTIONS........................3
»MEMORY MAP ................................................11
»GA1 HOTEL MODE APPLICATION ................15
»TROUBLE SHOOTING TABLE ........................15
»SOLID STATE DEVICE BASE DIAGRAM .......18
»WAVEFORMS..................................................19
»CHASSIS LAYOUT ..........................................22
»BLOCK DIAGRAM ...........................................26
»DESCRIPTION OF SCHEMATIC DIAGRAM ..35
»SCHEMATIC DIAGRAM
ËMAIN UNIT ...................................................36
ËCRT UNIT.....................................................44
Page
ËHEADPHONE UNIT .....................................45
ËMONO BILINGUAL UNIT.............................46
»PRINTED WIRING BOARD ASSEMBLIES.....48
»REPLACEMENT PARTS LIST
ËELECTRICAL PARTS
MAIN UNIT ...................................................54
CRT UNIT.....................................................58
HEADPHONE UNIT .....................................59
MONO BILINGUAL UNIT.............................59
ËSUPPLIED ACCESSORIES ........................60
ËPACKING PARTS .........................................60
ËCABINET PARTS .........................................60
»PACKING OFTHE SET ...................................62
FEATURES
ËPAL B/G
ËNTSC(AV Thru)
ËFull Auto Channel Preset and Auto Channel Skip
Ë100 CH Program Memory
ËCATV (Hyper Band) Ready
ËAVL (Sound Keeper) Function
ËHigh Contrast Picture (Black Stretch Circuit)
ËON Timer/Sleep Timer/Reminder Timer
ËFavourite Channel
ËBlue Back Noise Mute
ËFront AV In (Front AV Priority) (Except 14GT-16C)
ËRear AV In/Out Terminals
ËColour-Comb Filter (NTSC AV In)
ËHotel Mode
ËFront Headphone Jack (Except 14GT-16C)
ËEnglish/Thai Language OSD
ËMono Bilingual (20GT-21C & 21GT-21C Only)
14GT-16C 14GT-21C
20GT-21C 21GT-21C

14GT-16C/21C
20GT-21C/21GT-21C
14GT-16C/21C
20GT-21C/21GT-21C
1234567891011 12 13 14 15 16 17 18 19 20
A
B
C
D
E
F
G
H
I
J
46~47
MONO BILINGUAL UNIT:20GT-21C/21GT-21C




44
14GT-16C/21C
20GT-21C/21GT-21C
CRT UNIT : 14GT-16C/21C
A
B
C
D
E
F
G
H
I
J
12345678910




CRT UNIT : 20GT-21C





45
14GT-16C/21C
20GT-21C/21GT-21C
CRT UNIT : 21GT-21C
A
B
C
D
E
F
G
H
I
J
12345678910




HEADPHONE UNIT : 14GT-21C/20GT-21C/21GT-21C







22
14GT-16C/21C
20GT-21C/21GT-21C
MODEL 14GT-16C CHASSIS LAYOUT





23
14GT-16C/21C
20GT-21C/21GT-21C
MODEL 14GT-21C CHASSIS LAYOUT





24
14GT-16C/21C
20GT-21C/21GT-21C
MODEL 20GT-21C CHASSIS LAYOUT





25
14GT-16C/21C
20GT-21C/21GT-21C
MODEL 21GT-21C CHASSIS LAYOUT









14GT-16C/21C
20GT-21C/21GT-21C 14GT-16C/21C 20GT-21C/21GT-21C
26~27
BLOCK DAIAGRAM
MAIN UNIT (14GT-16C)





14GT-16C/21C
20GT-21C/21GT-21C
14GT-16C/21C
20GT-21C/21GT-21C
28~29
BLOCK DAIAGRAM
MAIN UNIT (14GT-21C)





14GT-16C/21C
20GT-21C/21GT-21C 14GT-16C/21C 20GT-21C/21GT-21C
30~31
BLOCK DIAGRAM
MAIN UNIT (20GT-21C/21GT-21C)





32
14GT-16C/21C
20GT-21C/21GT-21C
BLOCK DIAGRAM
CRT UNIT BLOCK DIAGRAM : 14GT-16C/21C
CRT UNIT BLOCK DIAGRAM : 20GT-21C









33
14GT-16C/21C
20GT-21C/21GT-21C
CRT UNIT BLOCK DIAGRAM : 21GT-21C






34
14GT-16C/21C
20GT-21C/21GT-21C
BLOCK DIAGRAM
HEADPHONE UNIT BLOCK DIAGRAM
MONO BILINGUAL UNIT BLOCK DIAGRAM









14GT-16C/21C
20GT-21C/21GT-21C 14GT-16C/21C 20GT-21C/21GT-21C
1234567891011 12 13 14 15 16 17 18 19 20
A
B
C
D
E
F
G
H
I
J
42~43
MAIN UNIT : 21GT-21C




Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
54
14GT-16C/21C
20GT-21C/21GT-21C
PICTURE TUBE
åL703 RCiLG0001KJZZ R Degaussing Coil AH
(14GT-16C/14GT-21C)
åL703 RCiLG0002KJZZ R Degaussing Coil
(20GT-21C)
åL703 RCiLG0003KJZZ R Degaussing Coil
(21GT-21C)
QEARC1431CEZZ R Ground-Part AE
(14GT-16C/14GT-21C)
QEARC2006CEZZ R Ground-Part(20GT-21C)
QEARC2115CEZZ R Ground-Part(21GT-21C)
LHLDW0003PEKZ R ADG Coil Holder AB
MSPRT0001PEFJ R CRT Spring AC
åDY601 RCiLHA026WJZZ R Deflection Yoke
(14GT-16C/14GT-21C)
åDY601 RCiLHA027WJZZ R Deflection Yoke
(20GT-21C)
åDY601 RCiLHA028WJZZ R Deflection Yoke
(21GT-21C)
PMAGF3041CEZZ R Magnet AG
(20GT-21C/14GT-16C/
14GT-21C)
PMAGF3046CEZZ R Magnet(21GT-21C) AF
åV801 VB34JXV80X/*S R Picture Tube
(14GT-16C/14GT-21C)
åV801 VB48LGS20X/*S R Picture Tube(20GT-21C)
åV801 VB51LMV20X/*S R Picture Tube(21GT-21C)
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTKA541WED1 - Main Unit(14GT-16C) —
PWB-A DUNTKA541WED0 - Main Unit(14GT-21C) —
PWB-A DUNTKA541WEC5 - Main Unit(20GT-21C) —
PWB-A DUNTKA541WEC9 - Main Unit(21GT-21C) —
PWB-B DUNTKA542WEB5 - CRT Unit —
(14GT-16C/14GT-21C)
PWB-B DUNTKA542WEB2 - CRT Unit(20GT-21C) —
PWB-B DUNTKA542WEB4 - CRT Unit(21GT-21C) —
PWB-C DUNTKA543WEA1 - Headphone Unit —
(14GT-21C/20GT-21C/
21GT-21C)
PWB-D DUNTKB232WEA0 - Mono-Billingual Unit —
(20GT-21C/21GT-21C)
REPLACEMENT PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the following
informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
MARK : SPARE PARTS-DELIVERY SECTION.
Ref. No. Part No. ★Description Code
DUNTKA541WED1(14GT-16C)
DUNTKA541WED0(14GT-21C)
DUNTKA541WEC5(20GT-21C)
DUNTKA541WEC9(21GT-21C)
PWB-A MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY NOT INDEPENDENTLY.
åTU201 VTUVTST5HD970 R Tuner AY
INTEGRATED CIRCUITS
IC301 VHiAN7523++-1 R AN7523 AH
åIC501 VHiAN5522++-1 R AN5522, Vert Out AH
(14GT-16C/14GT-21C)
åIC501 VHiTDA9302H-1 R TDA9302H, Vert Out AH
(20GT-21C/21GT-21C)
IC601 VHiKA7808AP-1 R KIA7808API AE
IC701 VHiSTRG5653-1 R STR-G5653, Regulator AQ
IC801 RH-iX3368CEN5 R TDA9381PS/N2 BE
IC1005 VHiM24C04W/-1 R M24C04-WBN6 AG
TRANSISTORS
Q201 VS2SC2735//1E R 2SC2735 AC
Q253 VS2PD601AR/-1 R 2PD601AR AB
Q254 VS2PD601AR/-1 R 2PD601AR AB
(14GT-16C/14GT-21C)
Q302 VS2PD601AR/-1 R 2PD601AR AB
(14GT-16C/14GT-21C)
Q321 VS2PD601AR/-1 R 2PD601AR AB
Q352 VS2PD601AR/-1 R 2PD601AR AB
Q501 VS2SC3198-G-1 R 2SC3198-G AA
Q601 VS2SC3207//-1 R 2SC3207, Hoirz Diriver AC
Q602 VS2SD2586//1E R 2SD2586, Hoirz Out AM
Q603 VS2SC3198-G-1 R 2SC3198-G AA
Q751 VS2SC3198-G-1 R 2SC3198-G, 5V Reg AA
Q752 VS2SC3198-G-1 R 2SC3198-G, 3.3V Reg AA
Q801 VS2PB709AR/-1 R 2PB709AR AB
Q802 VS2PB709AR/-1 R 2PB709AR AB
Q804 VS2SC2735//1E R 2SC2735 AC
Q1010 VS2PD601AR/-1 R 2PD601AR AB
DIODES AND LED
D201 RH-EX0676GEZZ R Zener Diode, 33V AA
D203 RH-DX0048GEZZ R DX0048GE AA
D301 RH-DX0048GEZZ R DX0048GE AA
D302 RH-DX0048GEZZ R DX0048GE AA
D331 RH-DX0302CEZZ R DX0302CE AC
(14GT-16C/14GT-21C)
D332 RH-DX0445CEZZ R DX0445CE AL
(20GT-21C/21GT-21C)
D503 RH-DX0048GEZZ R DX0048GE AA
D505 RH-DX0441CEZZ R DX0441CE AC
D506 RH-EX0630GEZZ R Zener Diode AA
D507 RH-DX0048GEZZ R DX0048GE AA
D508 RH-DX0131CEZZ R DX0131CE AC
D509 RH-EX0660GEZZ R Zener Diode AC
D531 RH-EX0627GEZZ R Zener Diode, 8.2V AA
D532 RH-EX0627GEZZ R Zener Diode, 8.2V AA
D601 RH-DX0048GEZZ R DX0048GE AA
D602 VHD1SS244//-1 R 1SS244 AB
D603 RH-EX0667GEZZ R Zener Diode, 27V AA
D604 RH-DX0048GEZZ R DX0048GE AA
D606 RH-DX0131CEZZ R DX0131CE AC
D607 RH-DX0048GEZZ R DX0048GE AA
D608 RH-DX0468CEZZ R DX0468CE AE
D651 RH-EX0627GEZZ R Zener Diode, 8.2V AA
D652 RH-EX0253TAZZ R Zener Diode, 3.3V AC
D653 RH-DX0048GEZZ R DX0048GE AA
D701 RH-DX0111PEZZ R DX0111PE AG
D705 VHD1SS82///1A R 1SS82 AC
D706 VHD1SS82///1A R 1SS82 AC
D707 VHD1SS82///1A R 1SS82 AC
D751 RH-DX0229CEZZ R DX0229CE AF

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
55
14GT-16C/21C
20GT-21C/21GT-21C
D752 RH-DX0131CEZZ R DX0131CE AC
D754 RH-EX0616GEZZ R Zener Diode, 5.6V AA
D755 RH-EX0603GEZZ R Zener Diode, 3.9V AA
D801 RH-DX0048GEZZ R DX0048GE AA
D802 RH-DX0048GEZZ R DX0048GE AA
D803 RH-DX0048GEZZ R DX0048GE AA
D804 RH-DX0048GEZZ R DX0048GE AA
D805 RH-DX0048GEZZ R DX0048GE AA
D806 RH-DX0048GEZZ R DX0048GE AA
D808 RH-EX0610GEZZ R Zener Diode, 4.7V AA
D1001 RH-PX0013PEZZ R PhotoDiode AC
D1003 RH-DX0048GEZZ R DX0048GE AA
D1004 RH-DX0048GEZZ R DX0048GE AA
D1007 RH-EX0263TAZZ R Zener Diode AB
D1012 RH-EX0611GEZZ R Zener Diode, 5.1V AA
D1018 RH-EX0263TAZZ R Zener Diode, 8.3V AB
D1019 RH-EX0263TAZZ R Zener Diode, 8.3V AB
D1024 RH-DX0048GEZZ R DX0048GE AA
VA701 RH-VX0073CEZZ R Varistor AD
PACKAGED CIRCUITS
PR701 RMPTP0001PEZZ R Packaged Circuit AN
(20GT-21C/21GT-21C)
PR702 RMPTP0028CEZZ R Packaged Circuit AG
(14GT-16C/14GT-21C)
X1001 RCRSB0300CEZZ R Crystal, CRSB0300CE AF
COILS
CF253 RFiLC0335CEZZ R Filter
CF3300 RFiLC0338CEZZ R Filter AG
(20GT-21C/21GT-21C)
SF201 RFiLC0442CEZZ R Filter AL
FILTERS
L202 VP-DF270K0000 R Peaking, 27µHAB
L203 VP-DF270K0000 R Peaking, 27µHAB
L204 VP-XF1R2K0000 R Peaking, 1.2µHAB
L253 VP-XF100K0000 R Peaking, 10µHAB
åL701 RCiLF0096PEZZ R Coil, CiLF0096PE AF
L751 RCiLP0225CEZZ R Coil, CiLP0225CE AF
L802 VP-DF100K0000 R Peaking, 10µHAB
L803 VP-DF100K0000 R Peaking, 10µHAB
L1030 VP-DF100K0000 R Peaking, 10µHAB
L1050 VP-DF100K0000 R Peaking, 10µHAB
L1051 VP-DF100K0000 R Peaking, 10µHAB
L3300 VP-DF1R0K0000 R Peaking, 1µHAB
(20GT-21C/21GT-21C)
L3301 VP-DF1R0K0000 R Peaking, 1µHAB
(20GT-21C/21GT-21C)
TRANSFORMERS
åT601 RTRNZ0144PEZZ R Transformer AE
åT602 RTRNF0228PEZZ R H-Volt Transformer AX
(14GT-16C/14GT-21C)
åT602 RTRNF0229PEZZ R H-Volt Transformer AY
(20GT-21C/21GT-21C)
åT701 RTRNW0015PEZZ R Transformer AL
CAPACITORS
C201 VCEA0A1CW476M R 47 16V Electrolytic AB
C202 VCEA0A1AW337M+R 330 10V Electrolytic
C203 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C204 VCEA0A0JW477M R 470 6.3V Electrolytic AC
C205 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C206 VCEA0A1HW106M R 10 50V Electrolytic AB
C207 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C208 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C209 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C210 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C231 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C232 VCKYCY1HB821K R 820p 50V Ceramic AA
C233 VCKYCY1HB472K R 4700p 50V Ceramic AA
C234 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C251 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C252 VCEA0A1CW107M R 100 16V Electrolytic AC
C301 VCEA0A1CW477M R 470 16V Electrolytic AC
C304 VCEA0A1CW106M R 10 16V Electrolytic AB
C306 VCEA0A1CW106M R 10 16V Electrolytic AB
C310 VCEA0A1HW105M R 1 50V Electrolytic AB
C311 VCEA0A1HW105M R 1 50V Electrolytic AB
C312 VCEA0A1HW224M R 0.22 50V Electrolytic AB
C316 VCEA0A1CW107M R 100 16V Electrolytic AC
(14GT-21C/20GT-21C/
21GT-21C)
C331 VCKYPA2HB102K R 1000p 500V Ceramic AA
C332 VCQYTA1HM103J R 0.01 50V Mylar AA
C333 VCEA0A1CW108M R 1000 16V Electrolytic AD
C352 VCEA0A1CW106M R 10 16V Electrolytic AB
C354 VCEA0A1CW106M R 10 16V Electrolytic AB
C356 VCKYCY1HB472K R 4700p 50V Ceramic AA
C359 VCEA0A1CW106M R 10 16V Electrolytic AB
C360 VCE9GA1HW225M R 2.2 50V Electrolytic AB
C409 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C410 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C411 VCKYCY1HB102K R 1000p 50V Ceramic AA
C412 VCEA0A1CW477M R 470 16V Electrolytic AC
C501 VCKYPA1HB102K R 1000p 50V Ceramic AA
C504 VCKYCY1HB103K R 0.01 50V Ceramic AA
C505 VCEA0A1HW107M R 100 50V Electrolytic AB
C507 VCKYCY1HB103K R 0.01 50V Ceramic AA
C508 VCFYSA1JB224J+ R 0.22 63V
MetalIized Polyester Film
C509 VCEA0A1CW477M R 470 16V Electrolytic AC
C510 VCKYPA2HB102K R 1000p 500V Ceramic AA
C514 VCFYSA1JB473J R 0.047 63V AC
MetalIized Polyester Film
(20GT-21C/21GT-21C)
C514 VCFYSA1JB563J+ R 0.056 63V
MetalIized Polyester Film
(14GT-16C/14GT-21C)
C529 VCKYCY1CB823K R 0.082 16V Ceramic AH
C531 VCKYCY1HB102K R 1000p 50V Ceramic AA
C532 VCKYCY1HB102K R 1000p 50V Ceramic AA
C533 VCQYTA1HM104J R 0.1 50V Mylar AA
C601 VCQYTA1HM563J R 0.056 50V Mylar AB
C602 VCEA0A1HW475M R 4.7 50V Electrolytic AB
C603 VCEA0A1HW105M R 1 50V Electrolytic AB
C604 VCEA0A2EW106M R 10 250V Electrolytic AD
C605 VCKYPA2HB102K R 1000p 500V Ceramic AA
C606 VCFPFA2EB334J R 0.33 250V AD
MetalIized Polypro Film
(14GT-16C/14GT-21C)
C606 VCFPVC2DB474J R 0.47 200V AE
MetalIized Polypro Film
(20GT-21C/21GT-21C)
C607 VCFPVC3ZA532H R 5300p 1800V AD
MetalIized Polypro Film
(14GT-16C/14GT-21C)
C607 VCFPVC3CA702H R 7000p 1600V
MetalIized Polypro Film
(20GT-21C)
C607 VCFPVC3CA802H R 8000p 1600V
MetalIized Polypro Film
(21GT-21C)
C608 VCKYPA2HB102K R 1000p 500V Ceramic AA
C610 VCEA0A1CW108M R 1000 16V Electrolytic AD
C611 VCEA0A1EW476M R 47 25V Electrolytic AB
C612 VCEA0A1CW477M R 470 16V Electrolytic AC
C620 VCKYPA2HB102K R 1000p 500V Ceramic AA
åC640 VCFYSB2EB823J R 0.082 250V M.Polyester AD
C651 VCQYTA1HM222J R 2200p 50V Mylar AA
C652 VCQYTA1HM472J R 4700p 50V Mylar AB
C653 VCEA0A1HW105M R 1 50V Electrolytic AB
C654 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C655 VCEA0A1HW106M R 10 50V Electrolytic AB
C656 VCEA0A1HW474M R 0.47 50V Electrolytic AB
C657 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C658 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C701 RC-FZA018WJZZ R 0.1 275V AD
MetalIized Polyester Film
C702 RC-KZ0029CEZZ R 0.01 250V Ceramic AC
C703 RC-KZ0029CEZZ R 0.01 250V Ceramic AC

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
56
14GT-16C/21C
20GT-21C/21GT-21C
C704 RC-KZ0029CEZZ R 0.01 250V Ceramic AC
C705 RC-EZ1046CEZZ R 220 400V Electrolytic AN
(20GT-21C/21GT-21C)
C705 RC-EZ1286CEZZ R 150 400V Electrolytic AT
(14GT-16C/14GT-21C)
C709 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C710 VCEA0A1HW476M R 47 50V Electrolytic AB
C711 VCKYPA1HB102K R 1000p 50V Ceramic AA
C712 VCKYPA1HB471K R 470p 50V Ceramic AA
åC751 RC-KZ0102GEZZ R 680p AC250V Ceramic AE
C752 VCKYPH3DB561K R 560p 2000V Ceramic AC
C753 RC-EZ0724CEZZ R 100 160V Electrolytic AG
C754 RC-EZ0638CEZZ R 33 160V Electrolytic AG
C755 VCEA0A1CW108M R 1000 16V Electrolytic AD
C756 VCQYTA1HM103J R 0.01 50V Mylar AA
C759 VCEA0A0JW477M R 470 6.3V Electrolytic AC
C760 VCEA0A0JW228M R 2200 6.3V Electrolytic AD
C801 VCEA0A1HW105M R 1 50V Electrolytic AB
C803 VCEA0A1CW107M R 100 16V Electrolytic AC
C804 VCKYCY1HB222K R 2200p 50V Ceramic AA
C805 VCKYD41HB102K R 1000p 50V Ceramic AA
C806 VCKYD41HB102K R 1000p 50V Ceramic AA
C807 VCKYD41HB102K R 1000p 50V Ceramic AA
C808 VCEA0A1CW107M R 100 16V Electrolytic AC
C809 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C810 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C811 VCEA0A1CW107M R 100 16V Electrolytic AC
C812 VCFYFA1HA224J R 0.22 50V Mylar AB
C813 VCFYFA1HA224J R 0.22 50V Mylar AB
C814 VCKYCY1HB471K R 470p 50V Ceramic AA
C816 VCKYCY1HB471K R 470p 50V Ceramic AA
C1001 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1002 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1003 VCEA0A1CW106M R 10 16V Electrolytic AB
C1004 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1005 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1006 VCEA0A1CW106M R 10 16V Electrolytic AB
C1008 VCCCCY1HH330J R 33p 50V Ceramic AA
C1009 VCCCCY1HH330J R 33p 50V Ceramic AA
C1010 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1011 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1012 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1013 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1014 VCEA0A1CW106M R 10 16V Electrolytic AB
C1016 VCQYTA1HM104J R 0.1 50V Mylar AA
C1018 VCKYCY1HB221K R 220p 50V Ceramic AA
C1019 VCEA0A1HW225M R 2.2 50V Electrolytic AB
C1024 VCQYTA1HM104J R 0.1 50V AA
MetalIized Polyester Film
RESISTORS
RJ2 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ4 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ8 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14GT-16C)
RJ9 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ10 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ13 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ14 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ15 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ16 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ17 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ19 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ21 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ24 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ26 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ28 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ32 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ33 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ35 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ37 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ38 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ41 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ42 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ43 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ46 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ48 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ49 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ51 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ52 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ53 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ56 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ57 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14GT-16C)
RJ58 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14GT-16C)
RJ71 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ73 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ75 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ76 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ77 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ78 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ80 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ81 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ82 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ83 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
RJ84 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ85 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ86 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ87 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
RJ88 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
RJ89 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R201 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R202 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R205 VRS-CY1JF680J R 68 1/16W Metal Oxide AA
R206 VRS-CY1JF122J R 1.2k 1/16W Metal Oxide AA
R207 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R208 VRS-CY1JF122J R 1.2k 1/16W Metal Oxide AA
R209 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R216 VRS-VV3LB223J R 22k 3W Metal Oxide AB
R219 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R220 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R230 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R231 VRD-RA2BE681J R 680 1/8W Carbon AA
R232 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
R233 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R234 VRS-CY1JF391J R 390 1/16W Metal Oxide AA
R257 VRS-CY1JF181J R 180 1/16W Metal Oxide AA
R258 VRS-CY1JF151J R 150 1/16W Metal Oxide AA
R259 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R259 VRS-CY1JF560J R 56 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R260 VRS-CY1JF223J R 22k 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R261 VRS-CY1JF223J R 22k 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R262 VRS-CY1JF560J R 56 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R262 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R263 VRS-CY1JF560J R 56 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R263 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R301 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R302 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R303 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R304 VRS-CY1JF100J R 10 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
57
14GT-16C/21C
20GT-21C/21GT-21C
R305 VRS-CY1JF274J R 270k 1/16W Metal Oxide AA
R310 VRS-CY1JF473J R 47k 1/16W Metal Oxide AA
R311 VRS-CY1JF473J R 47k 1/16W Metal Oxide AA
R313 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R314 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R315 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
R316 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
R318 VRD-RA2BE680J R 68 1/8W Carbon AA
(14GT-21C/20GT-21C/
21GT-21C)
R333 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R334 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R335 VRS-CY1JF564J R 560k 1/16W Metal Oxide AA
R352 VRS-CY1JF681J R 680 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R353 VRS-CY1JF681J R 680 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R359 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R360 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R361 VRS-CY1JF104J R 100k 1/16W Metal Oxide AA
R364 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R366 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R430 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R431 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R432 VRS-CY1JF820J R 82 1/16W Metal Oxide AA
R458 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R459 VRD-RA2BE680J R 68 1/8W Carbon AA
R501 VRD-RA2BE222J R 2.2k 1/8W Carbon AA
(20GT-21C)
R501 VRD-RA2BE272J R 2.7k 1/8W Carbon AA
(14GT-16C/14GT-21C)
R501 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
(21GT-21C)
R502 VRD-RM2HD102J R 1k 1/2W Carbon AA
R503 VRN-VV3AB2R2J R 2.2 1W Metal Film AA
(20GT-21C/21GT-21C)
R503 VRN-VV3AB2R7J R 2.7 1W Metal Film AA
(14GT-16C/14GT-21C)
R504 VRS-CY1JF181J R 180 1/16W Metal Oxide AA
R505 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R506 VRS-VV3AB331J R 330 1W Metal Oxide AA
(14GT-16C/14GT-21C)
R506 VRS-VV3AB391J R 390 1W Metal Oxide AA
(20GT-21C/21GT-21C)
R507 VRN-VV3AB1R0J R 1 1W Metal Film AA
R508 VRD-RA2BE153J R 15k 1/8W Carbon AA
R509 VRD-RA2BE153J R 15k 1/8W Carbon AA
R511 VRS-CY1JF181J R 180 1/16W Metal Oxide AA
R512 VRD-RM2HD5R6J R 5.6 1/2W Carbon AA
(21GT-21C/14GT-16C/
14GT-21C)
R512 VRD-RM2HD100J R 10 1/2W Carbon AA
(20GT-21C)
R521 VRD-RA2BE333J R 33k 1/8W Carbon AA
(14GT-16C/14GT-21C)
R521 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
(21GT-21C)
R529 VRD-RA2BE223J R 22k 1/8W Carbon AA
R530 VRS-CY1JF334J R 330k 1/16W Metal Oxide AA
R531 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R532 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R533 VRD-RA2BE393J R 39k 1/8W Carbon AA
R601 VRS-SV2HC102J R 1k 1/2W Metal Oxide AA
R602 VRD-RA2BE393J R 39k 1/8W Carbon AA
R603 VRD-RA2BE223J R 22k 1/8W Carbon AA
(20GT-21C/21GT-21C)
R603 VRD-RA2BE273J R 27k 1/8W Carbon AA
(14GT-16C/14GT-21C)
R604 VRD-RA2BE393J R 39k 1/8W Carbon AA
(20GT-21C/21GT-21C)
R604 VRD-RA2BE563J R 56k 1/8W Carbon AA
(14GT-16C/14GT-21C)
R605 VRD-RM2HD124J R 120k 1/2W Carbon AA
(14GT-16C/14GT-21C)
R605 VRD-RM2HD823J R 82k 1/2W Carbon AA
(20GT-21C/21GT-21C)
R606 VRN-VV3AB1R5J R 1.5 1W Metal Film AA
(14GT-16C/14GT-21C)
R606 VRN-VV3DB1R2J R 1.2 2W Metal Film AA
(21GT-21C)
R606 VRN-VV3DB2R2J R 2.2 2W Metal Film AB
(20GT-21C)
R607 VRD-RM2HD270J R 27 1/2W Carbon AA
R609 VRD-RA2BE154J R 150k 1/8W Carbon AA
R610 VRD-RA2BE102G R 1k 1/8W Carbon AB
R611 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R612 VRS-CY1JF123J R 12k 1/16W Metal Oxide AA
R613 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R614 VRS-SV2HC100J R 10 1/2W Metal Oxide AA
(20GT-21C/21GT-21C)
R614 VRS-SV2HC150J R 15 1/2W Metal Oxide AA
(14GT-16C/14GT-21C)
R615 VRS-VV3DB682J R 6.8k 2W Metal Oxide AA
R616 VRN-VV3ABR47J R 0.47 1W Metal Film AA
R618 VRS-VV3DB391J R 390 2W Metal Oxide AA
R619 VRS-VV3LB103J R 10k 3W Metal Oxide AB
(14GT-16C/14GT-21C)
R619 VRS-VV3LB562J R 5.6k 3W Metal Oxide AB
(20GT-21C/21GT-21C)
R620 VRS-VV3AB472J R 4.7k 1W Metal Oxide AA
R622 VRD-RA2BE102J R 1k 1/8W Carbon AA
R623 VRD-RM2HD184J R 180k 1/2W Carbon AA
R624 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R625 VRN-VV3DB4R7J R 4.7 2W Metal Film AB
(20GT-21C/21GT-21C)
R625 VRN-VV3DB8R2J R 8.2 2W Metal Film AB
(14GT-16C/14GT-21C)
R626 VRD-RM2HD470J R 47 1/2W Carbon AA
R633 VRD-RA2BE333J R 33k 1/8W Carbon AA
R634 VRD-RA2BE103J R 10k 1/8W Carbon AA
R641 VRN-SV2HCR47J R 0.47 1/2W Metal Film AA
R651 VRS-CY1JF223J R 22k 1/16W Metal Oxide AA
R652 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R653 VRS-CY1JF822J R 8.2k 1/16W Metal Oxide AA
R654 VRS-CY1JF273J R 27k 1/16W Metal Oxide AA
R655 VRS-CY1JF391J R 390 1/16W Metal Oxide AA
R656 VRS-CY1JF100J R 10 1/16W Metal Oxide AA
R658 VRD-RA2BE101J R 100 1/8W Carbon AB
R663 VRD-RA2BE101J R 100 1/8W Carbon AB
R701 VRW-KQ3NC3R9K R 3.9 7W Cement AE
R704 VRN-SV2HC1R0J R 1 1/2W Metal Film AA
(20GT-21C/21GT-21C)
R707 VRS-VV3DB104J R 100k 2W Metal Oxide AB
R708 VRD-RA2BE681J R 680 1/8W Carbon AA
R709 VRN-VV3DBR47J R 0.47 2W Metal Film AB
R710 VRN-VV3DBR39J R 0.39 2W Metal Film AA
(20GT-21C/21GT-21C)
R710 VRN-VV3DBR56J R 0.56 2W Metal Film AA
(14GT-16C/14GT-21C)
R711 VRD-RA2BE682J R 6.8k 1/8W Carbon AA
R712 VRD-RA2BE152J R 1.5k 1/8W Carbon AA
R716 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
åR751 VRC-UA2HG825K R 8.2M 1/2W Solid AA
åR752 VRC-UA2HG825K R 8.2M 1/2W Solid AA
R753 VRD-RM2HD124J R 120k 1/2W Carbon AA
R754 VRD-RM2HD150J R 15 1/2W Carbon AA
R755 VRD-RA2BE221J R 220 1/8W Carbon AA
R756 VRD-RM2HD220J R 22 1/2W Carbon AA
(20GT-21C/21GT-21C)
R756 VRD-RM2HD270J R 27 1/2W Carbon AA
(14GT-16C/14GT-21C)
R757 VRS-CY1JF151J R 150 1/16W Metal Oxide AA
(14GT-16C/14GT-21C)
R757 VRS-CY1JF331J R 330 1/16W Metal Oxide AA
(20GT-21C/21GT-21C)
R765 VRS-CY1JF331J R 330 1/16W Metal Oxide AA
R801 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R802 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R803 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R804 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R805 VRS-CY1JF822J R 8.2k 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
58
14GT-16C/21C
20GT-21C/21GT-21C
R806 VRS-CY1JF123J R 12k 1/16W Metal Oxide AA
R807 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R808 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R809 VRD-RA2BE224J R 220k 1/8W Carbon AA
R812 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R813 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R1001 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R1002 VRS-CY1JF331J R 330 1/16W Metal Oxide AA
R1003 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R1004 VRS-CY1JF821J R 820 1/16W Metal Oxide AA
R1005 VRS-CY1JF181J R 180 1/16W Metal Oxide AA
R1011 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1012 VRD-RA2BE271J R 270 1/8W Carbon AA
R1013 VRD-RA2BE101J R 100 1/8W Carbon AB
R1014 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1015 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1016 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1017 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1019 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R1020 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1021 VRS-CY1JF153J R 15k 1/16W Metal Oxide AA
R1022 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1023 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1024 VRS-CY1JF122J R 1.2k 1/16W Metal Oxide AA
R1025 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1026 VRS-CY1JF224J R 220k 1/16W Metal Oxide AA
R1028 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1030 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R1031 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
R1032 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1034 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1035 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1036 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1037 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1038 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1039 VRS-CY1JF223J R 22k 1/16W Metal Oxide AA
R1040 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1041 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1042 VRD-RA2BE101J R 100 1/8W Carbon AB
R1046 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1048 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R1050 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R1051 VRS-CY1JF683J R 68k 1/16W Metal Oxide AA
R1072 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1073 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
BALUNE
FB601 RBLN-0091GEZZ R Balun, BLN-0091GE AB
SWITCHES
åS702 QSW-P0591CEZZ R Switch AQ
S1001 QSW-K0003AJZZ R Switch, CH Up AB
S1002 QSW-K0003AJZZ R Switch, CH Down AB
S1003 QSW-K0003AJZZ R Switch, VOL Up AB
S1004 QSW-K0003AJZZ R Switch, VOL Down AB
S1005 QSW-K0003AJZZ R Switch, Picture/Preset AB
MISCELLANEOUS PARTS
åACC701 QACCZ3008KJSA R AC Cord
åF701 QFS-C3229CEZZ R Fuse, T3. 15A 250V AD
åFH701 QFSHD1013CEZZ R Fuse Holder AC
åFH702 QFSHD1014CEZZ R Fuse Holder AC
J402 QJAKE0210CE04 R Jack, 3Pin AC
(14GT-21C/20GT-21C/
21GT-21C)
J403 QJAKE0210CE09 R Jack, 3Pin AC
(14GT-21C/20GT-21C/
21GT-21C)
J409 QJAKH0044AJZZ R Jack, 12Pin AE
P302 QPLGN0241CEZZ R Plug, 2Pin AA
(14GT-16C/14GT-21C)
P302 QPLGN0461CEZZ R Plug, 4Pin AB
(20GT-21C/21GT-21C)
P303 QPLGN0461CEZZ R Plug, 4Pin(14GT-21C) AB
P303 QPLGN0561CEZZ R Plug, 4Pin AB
(20GT-21C/21GT-21C)
P601 QPLGN0660CEZZ R Plug, 6Pin AC
P602 LHLDW1104PEZZ R Holder AB
P603 QPLGN0341CEZZ R Plug, 3Pin AA
P701 QPLGN0260CEZZ R Plug, 2Pin AC
P702 QPLGN0269GEZZ R Plug, 2Pin AB
P1001 LHLDW1105PEZZ R Holder AB
P1002 QPLGN0561CEZZ R Plug, 5Pin AB
RDA301 PRDAR0341PEFW R Heat Sink, IC301 AD
(14GT-16C/14GT-21C)
RDA302 PRDAR0340PEFW R Heat Sink, IC301 AE
(20GT-21C/21GT-21C)
RDA501 PRDAR0118GJFW R Heat Sink, IC501 AD
RDA602 PRDAR0224PEFW R Heat Sink, Q602 AF
(20GT-21C/21GT-21C)
RDA701 PRDAR0298PEFW R Heat Sink, IC701 AF
RMC1001 RRMCU0222CEZZ R Remote Receiver AL
TP201 QLUGP0102PEZZ R Lug AA
LHLDP1066PE00 R Holder AC
DUNTKA542WEB5(14GT-16C/14GT-21C)
DUNTKA542WEB2(20GT-21C)
DUNTKA542WEB4(21GT-21C)
PWB-B CRT UNIT
TRANSISTORS
Q870 RH-TX0110BMZZ+ R TX0110BM
Q871 RH-TX0110BMZZ+ R TX0110BM
Q872 RH-TX0110BMZZ+ R TX0110BM
Q883 RH-TX0124BMZZ+ R TX0124BM
Q885 RH-TX0124BMZZ+ R TX0124BM
Q887 RH-TX0124BMZZ+ R TX0124BM
DIODES
D881 VHD1SS244//-1 R 1SS244 AB
D882 VHD1SS244//-1 R 1SS244 AB
D883 VHD1SS244//-1 R 1SS244 AB
D884 RH-DX0048GEZZ R DX0048GE AA
D885 RH-DX0048GEZZ R DX0048GE AA
D886 VHD1SS82///1A R 1SS82 AC
D887 VHD1SS82///1A R 1SS82 AC
D888 VHD1SS82///1A R 1SS82 AC
CAPACITORS
C871 VCCCCY1HH471J R 470p 50V Ceramic AA
C872 VCCCCY1HH471J R 470p 50V Ceramic AA
C873 VCCCCY1HH471J R 470p 50V Ceramic AA
C875 VCKYPA2HB102K R 1000p 500V Ceramic AA
C876 RC-KZ0150CEZZ R 1000p 3kV Ceramic AB
C878 VCEA0A2EW106M R 10 250V Electrolytic AD
C880 VCCCCY1HH471J R 470p 50V Ceramic AA
C881 VCKYPA1HB471K R 470p 50V Ceramic AA
C882 VCKYPA1HB471K R 470p 50V Ceramic AA
C886 VCKYPA2HB102K R 1000p 500V Ceramic AA
RESISTORS
R879 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R880 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R881 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R882 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R883 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R884 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R885 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R886 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R887 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R888 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
(20GT-21C/14GT-16C/
14GT-21C)
R892 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R893 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R894 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R895 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
(21GT-21C)
