Sharp LC52LE600E User manual

LCD 2009 12 02
Date of Issue: 5th December 2009
Classification: White
LCD TELEVISION TECHNICAL BULLETIN Page 1 of 1
Sharp Electronics (UK) Limited
Reference – LV315
Revision - 1
White – Carry out as required
Yellow – Carry out as required and whenever the unit comes in for service
Red – Carry out on all units
MODELS LC32LE600E LC40LE600E LC46LE600E LC52LE600E
REASON Changes in LCD panel assembly and Main PWB during production.
ACTION When servicing please check the rear rating plate to ensure the correct circuit and
parts list is being used as there are currently 3 versions including A an B variants.
Figure 1: Original Version Model Number only. Figure 2: Indication of “A” Version chassis.

LC-32/40/46LE600E/RU/S
vi
LC32LE600E Service Manual
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuit should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• Plug the AC cord directly into a 220~240 volt AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15µF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a nonpolarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 1.05 V peak (this corresponds to 0.7 mA peak AC.)
or more is excessive and indicates a potential shock hazard which
must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by “ ” and shaded areas in the Replacement Parts
List and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
CAUTION:
FOR CONTINUED PROTECTION AGAINST A
RISK OF FIRE REPLACE ONLY WITH SAME
TYPE FUSE.
LC-32LE600E/RU/S: F7001, F7002 (2.5A/250V)
LC-40LE600E/RU/S: F7001, F7002 (5A/250V)
LC-46LE600E/RU/S: F7001, F7002 (6.3A/250V)
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-32/40/46LE600E/RU/S
vii
Precautions for using lead-free solder
Employing lead-free solder
• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The
alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
Part No. Description Code
ZHNDAi123250E J φ0.3mm 250g (1roll) BL
ZHNDAi126500E J φ0.6mm 500g (1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg (1roll) BM
LFa
Indicates lead-free solder of tin, silver and copper.
LF a/a
Indicates lead-free solder of tin, silver and copper.

LC-32/40/46LE600E/RU/S
viii
End of life disposal
End of life disposal
Attention: Your
product is marked
with this symbol.
It means that used
electrical and
electronic products
should not be
mixed with general
household waste.
There is a separate
collection system for
these products.
A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin!
Used electrical and electronic equipment must be treated separately and in accordance with legislation that
requires proper treatment, recovery and recycling of used electrical and electronic equipment.
Following the implementation by member states, private households within the EU states may return their
used electrical and electronic equipment to designated collection facilities free of charge*. In some countries*
your local retailer may also take back your old product free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators, please dispose of these
separately beforehand according to local requirements.
By disposing of this product correctly you will help ensure that the waste undergoes the necessary treatment,
recovery and recycling and thus prevent potential negative effects on the environment and human health
which could otherwise arise due to inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the correct method of
disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of charge to the dealer, even if
you don’t purchase a new product. Further collection facilities are listed on the homepage of www.swico.ch
or www.sens.ch.
B. Information on Disposal for Business Users
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back of the product. You might be
charged for the costs arising from take-back and recycling. Small products (and small amounts) might be
taken back by your local collection facilities.
For Spain: Please contact the established collection system or your local authority for take-back of your used
products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for the correct method of
disposal.
The battery supplied with this product contains traces of Lead.
For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household
waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in
accordance with legislation. Please contact your local authority for details on the collection and recycling
schemes.
For Switzerland: The used battery is to be returned to the selling point.
For other non-EU countries: Please contact your local authority for correct method of disposal of the used
battery.

LC-32/40/46LE600E/RU/S
3 – 1
LC32LE600E Service Manual
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS
46"/40"/32"
(470.0 )/[420.0 ]/[[ 390.0 ]]
(1099.0 )/[964.0 ]/[[ 767.0 ]]
(740.0 )/[664.0 ]/[[ 554.0 ]]
(400.0 )/[300.0 ]/[[ 200.0 ]]
(175.0 )/[170.0 ]/[[ 135.0 ]]
(400.0 )/[300.0 ]/[[ 200.0 ]]
(688.0 )/[612.0 ]/[[ 502.0 ]]
(357.0 )/[309.0 ]/[[ 271.9 ]]
(575.6 )
[500.4 ]
[[ 394.5 ]]
(123.2 )
[99.0 ]
[[ 83.0 ]]
(93.2 )
[93.1 ]
[[ 91.9 ]]
(415.0 )/[377.0 ]/[[ 321.0 ]]
(1023.4 )/[887.8 ]/[[ 700.0 ]]
( ) LC-46LE600E/RU/S
[ ] LC-40LE600E/RU/S
[[ ]] LC-32LE600E/RU/S

LC-32/40/46LE600E/RU/S
4 – 1
LC32LE600E Service Manual
CHAPTER 4. ADJUSTMENT PROCEDURE
[1] ADJUSTMENT PROCEDURE
1. Adjustment method after PWB and/or IC replacement due to repair
The unit is set to the optimum at the time of shipment from the factory. If any value should become improper or any adjustment is necessary due to
the part replacement, make an adjustment according to the following procedure.
1. Procure the following units in order to replace the main unit, E2PROM (IC8455).
NOTE: [Caution when replacing ICs in the main unit (IC501)]
The above ICs are EEPROMs storing the EDID data of PC data.
Before replacing the relevant part, procure the following parts in which the data have been rewritten.
2. Entering and exiting the adjustment process mode
1. Press the “MAIN POWER” key on the set of running TV set to force power off.
(Or, unplug the AC power cord of running TV set to force power off.)
2. While holding down the “ (-)” and “INPUT” keys on the set at once, press the “MAIN POWER” key on the set to turn on the power.
The letter “K” appears on the screen.
3. Next, hold down the “ (-)” and “P ( )” keys on the set at once.
Multiple lines of orange characters appearing on the screen indicate that the set is now in the adjustment process mode.
If you fail to enter the adjustment process mode (the display is the same as normal start up), retry the procedure.
4. To exit the adjustment process mode after the adjustment is done, press the MAIN POWER key and turn off a power supply. or unplug the AC
power cord to force power off.
(When the power is turned off with the remote controller, once unplug the AC power cord and wait for 10 seconds before plug it in again.)
3. Remote controller key operation in adjustment process mode.
1. key operation
Input mode is switched automatically when relevant adjustment is started so far as the necessary input signal is available.
MAIN UNIT: DUNTKF111FM11
IC501 RH-iXC206WJQZS EDID (PC) ANALOG-RGB
CAUTION: Use due care in handling the information described here lest the users should know how to enter the adjustment process mode.
If the settings are tampered with in this mode, unrecoverable system damage may result.
Remote controller key Main unit key Remote controller key Main unit key Function
P(/) P(/) Moving an item (line) by one (UP/DOWN)
(+/-) (+/-) Changing a selected item setting (+1/-1)
Cursor ( / ) — Turning a page (PREVIOUS/NEXT)
Cursor ( / ) — Changing a selected line setting (+10/-10)
Input button Input button Input source switching (toggle switching)
(TV→EXT1→EXT2→EXT3→EXT4→HDMI1→HDMI2→HDMI3→EXT8)
OK — Executing a function

LC-32/40/46LE600E/RU/S
4 – 2
4. Description of display
No. Description Display specification
(1) Current page/total pages 2char/2char Decimal Number mark.
(2) Currently selected input TV→EXT1→EXT2→EXT3→EXT4→HDMI1→HDMI2→HDMI3→EXT8
(3) Inch setting and destination display 32/40/46
(4) Item name Max. 30 char
(5) Parameter table Max. 60 char (Preset value of each item)
(1) Current page / Total pages (2) Currentry selected input
(3) Inch setting and Model name display
PAGE 1/8 TV **E_LE600E Adjustment process menu header
Main Version 1.14
Boot Version 20090429.1.12
T-CON Version 00 00 00 00 32 4C 32 B1
INCH SIZE xx
CPLD Version xx
ERROR RESET NO [NO/YES]
STANDBY CAUSE 00 00 00 00 00
[1] 00H 00M
[2] 00H 00M
[3] 00H 00M
[4] 00H 00M
[5] 00H 00M
(4) Item name (5) Parameter

LC-32/40/46LE600E/RU/S
4 – 3
5. Adjustment process mode menu
The character string in brackets [ ] will appear as a page title in the adjustment process menu header.
Page Line Item Description Remarks (adjustment detail, etc.)
1/8
1 Main Version 1.14 Main microprocessor version
2 Boot Version 20090429.1.12 Boot version of the main microprocessor
3 T-CON Version 00 00 00 00 32 4C 32 B1 T-CON microprocessor version
4 CPLD Version xx CPLD Version for Backlight controller
5 INCH SIZE 32/40/46 Initial Setting of panel size
6 ERROR RESET NO [NO/YES] Lamp error reset. (Select “YES” and press “OK” key.)
7 STANDBY CAUSE 00 00 00 00 00 Error standby cause. Total operating time before error.
1) 00H 00M (5 times histories)
2) 00H 00M
3) 00H 00M
4) 00H 00M
5) 00H 00M
2/8
1 INDUSTRY INIT [NO/YES(E)/YES(I)/YES(F)/YES(R) Initialization to factory settings execution.
2 PUBLIC MODE OFF [OFF/ON] ON/OFF setting of hotel mode
3 I2C DATA 000000000000 Write and read of data in I2C BUS control IC.
4 I2C STATE WAIT [STANDBY/WAIT] Execution of write and read of I2C DATA
3/8
1 INSPECT USB TERM ENTER Reading inspection of USB memory terminal
2 HDMI CEC TEST ENTER HDMI CEC test
4/8
1 TUNER ADJ ENTER VIDEO level adjustment execution
2 CHANNEL E-12/E-9(SMPTE)/E-12(SMPTE)
3 GAIN 31 Gain adjustment
4 ADJ RESET NO [NO/YES] Reset of adjustment
5/8
1 VIDEO ADJ ENTER VIDEO level adjustment execution
2 GAIN 31
6/8
1 COM-ADJ ENTER COMPONENT level adjustment execution
2 Y OFF SET 70 Y CUTOFF adjustment value
3 PB OFF SET 128 PB CUTOFF adjustment value
4 PR OFF SET 128 PR CUTOFF adjustment value
5 Y GAIN 140 Y GAIN adjustment value
6 PB GAIN 140 PB GAIN adjustment value
7 PR GAIN 140 PR GAIN adjustment value
8 ADJ RESET NO [NO/YES] Reset of adjustment
7/8
1 RGB-ADJ ENTER SCART RGB level adjustment execution
2 R OFF SET 128 R OFF SET adjustment value
3 G OFF SET 128 G OFF SET adjustment value
4 B OFF SET 128 B OFF SET adjustment value
5 R GAIN 80 R DRIVE adjustment value
6 G GAIN 80 G DRIVE adjustment value
7 B GAIN 80 B DRIVE adjustment value
8 ADJ RESET NO [NO/YES] Reset of adjustment
8/8
1 COM BIAS 67 Common Bias auto adjustment execution
2 LCD TEST PATTERN 0 Pattern with built-in LCD controller display
3 WB Point A 1280 W/B adjustment, gradation Point A input setting
4 Point B 3712 W/B adjustment, gradation Point B input setting
5 Point A ADJ R 1280 W/B adjustment, gradation Point A R_adjustment value
6 ADJ G 1280 W/B adjustment, gradation Point A G_adjustment value
7 ADJ B 1280 W/B adjustment, gradation Point A B_adjustment value
8 Point B ADJ R 3712 W/B adjustment, gradation Point B R_adjustment value
9 ADJ G 3712 W/B adjustment, gradation Point B G_adjustment value
10 ADJ B 3712 W/B adjustment, gradation Point B B_adjustment value
11 WB WRITE NO [NO/YES] W/B writing of adjustment values
12 WB RESET NO [NO/YES] Reset of W/B adjustment value

LC-32/40/46LE600E/RU/S
4 – 4
6. Special features
1. STANDBY CAUSE (Page 1/8)
Display of a cause (code) of the last standby.
The cause of the last standby is recorded in EEPROM whenever possible.
Checking this code will be useful in finding a problem when you repair the troubled set.
7. ROM Writing (HDMI_EDID)
1. EDID writing
1) Get ready the PC with COM port (RS-232C) running on Windows 95/98/ME/2000/XP operating system, as well as the RS-232C cross cable.
2) Start the set with the set connected with the personal computer with the RS232C cross cable.
3) Start the terminal software. (The free ware readily available on the Internet will do.)
4) Make the following settings.
5) Input following commands to terminal software.
6) It usually returns to a state by AC-OFF/ON.
Disconnect and connect AC cable, then TV wakes up with normal mode.
2. Software version
*1 Please refer to the change report document for the latest version (Issued it to SEES).
Baud rate : 9600 bps
Data LENGTH : 8bit
Parity bit : none
Stop bit : 1 bit
Flow control : none
“KRSW0001”
PC replies “ERR” (you should ignore this replay)
“KKT10037”
PC replies “OK”
“WRED0000”
PC replies “OK”... At that time, EDID writing finish with success.
(1) Mainmicon Software Ver. 1.14 *1
(2) Boot version of mainmicon Software Ver. 1.12 *1
(3) T-CON Monitor micon Software Ver. 1.0 *1
(4) CPLD Version XX *1

LC-32/40/46LE600E/RU/S
4 – 5
8. Adjustment procedure
1. Inch Setting
2. COMB-BIAS Adjustment
Adjustment point Adjustment conditions Adjustment procedure
1 Inch Setting Adjustment process mode
Adjustment process
“INCH SIZE” menu page 1/8
1) Inch Setting with adjustment process mode.
2) Enter the adjustment process mode, refering to the 2nd item.
3) By using P ( / ) key of R/C, Move the cursor to “INCH SIZE” on page 1/
8.
4) Select inch size 32/40/46 with the Volume (+)/(-) key of remote control.
5) Press the “OK” key of remote control.
6) After a while, If “*** OK ***” is displayed, the setting is completed.
Adjustment point Adjustment conditions Adjustment procedure
1 COM-BIAS Adjustment A visual check
Adjustment process
“COM BIAS” menu page 8/8
1) COM-BIAS Adjustment with adjustment process mode.
2) Enter to the adjustment process mode, refering to the 2nd item.
3) By using / key and P ( / ) key of R/C, Move the cursor to “COM-
BIAS” on page 8/8.
4) Press the “OK” key. then, you can check that the pattern for adjustment is
displayed.
5) Adjust so that the flicker for the central part of a screen becomes the mini-
mum using the volume (+)/(-) key of R/C.
6) In order to exit from this process, press the “OK” key of remote control again.

LC-32/40/46LE600E/RU/S
4 – 6
9. Video signal adjustment procedure
* The adjustment process mode menu is listed in 5th item.
Signal generator level adjustment check (Adjustment to the specified level)
1. Picture Adjustment
1) Entering the adjustment process mode
2) TUNER adjustment
3) PAL signal adjustment
• Composite signal PAL/SECAM : 0.7Vp-p ±0.02Vp-p (White level from pedestal)
• PC (Analog D_sub15pin) signal : 0.7Vp-p ±0.02Vp-p (White level from pedestal)
• 33K component signal : Y level 0.7Vp-p ±0.02Vp-p (White level from pedestal)
: PB,PR level 0.7Vp-p ±0.02Vp-p
Adjustment point Adjustment conditions Adjustment procedure
Enter to the adjustment process mode, refering to the 2nd item.
Adjustment point Adjustment conditions Adjustment procedure
1 Setting [Signal]
PAL split colour Bar
In-house UV
[Terminal]
TUNER
• Feed the In-house signal (PAL color bar) to TUNER.
• Make sure the PAL colour bar pattern has the sync level of 7:3 with the pic-
ture level.
• Feed the SMPTE color bar signal to TUNER.
JABIL: 203.25MHz
2 Auto adjustment
performance
Adjustment process
[VIDEO ADJ] menu page 4/8
Bring the cursor on [VIDEO ADJ] and press OK key [*** OK ***] appears when
finished.
Adjustment point Adjustment conditions Adjustment procedure
1 Setting [Signal]
PAL full colour Bar
[Terminal]
EXT1 SCART Video input
• Feed the PAL full field colour bar (color saturation level 100%) signal to the
SCART video input of EXT1.
2 Auto adjustment
performance
Adjustment process
[VIDEO ADJ] menu page 5/8
Bring the cursor on [VIDEO ADJ] and press OK key [*** OK ***] appears when
finished.
[SMPTE pattern]
100% white Black
[VIDEO input signal]

LC-32/40/46LE600E/RU/S
4 – 7
4) ADC adjustment (Component 33K)
5) PC signal adjustment (Analog D-SUB15pin)
Adjustment point Adjustment conditions Adjustment procedure
1 Setting [Signal]
COMP 33K 50Hz 100% Full field
colour bar
[Terminal]
EXT3 CONPONENT input
• Feed the COMPONENT 33K 100% Full field colour bar (colour saturation
level 100%) signal to the CONPONENT video input of EXT3.
2 Auto adjustment
performance
Adjustment process [COM ADJ]
menu page 6/8
Bring the cursor on [COM ADJ] and press OK key [*** OK ***] appears when fin-
ished.
Adjustment point Adjustment conditions Adjustment procedure
1 Setting [Signal]
XGA 60 Hz 100% Full field
colour bar
[Terminal]
EXT4 PC input
• Feed the XGA 60Hz 100% Full field colour bar (colour saturation level 100%)
signal to the EXT4 PC input.
2 Auto adjustment
performance
Adjustment process [RGB ADJ]
menu page 7/8
Bring the cursor on [RGB ADJ] and press OK key [*** OK ***] appears when fin-
ished.
100% white Black
100% white Black

LC-32/40/46LE600E/RU/S
4 – 8
10. White Balance Adjustment
Adjustment gradation values (INFO) appear on page 8/8 3-4 lines of process adjustment, and adjustment initial values (offset value) appear on pages
8/8 5-10 lines. For white balance adjustment, adjust the offset values on pages 8/8 5-10 lines.
1. Preparation
1) Luminance meter reference device :Minolta CA-210
2) Condition of the unit for adjustment and inspection:Modulated light: MAX (+16)
2. Setting
1) The luminance meter is set to the center of the screen of the set.
2) In “INCH SIZE” on the process adjustment page 1/8, sets it to the size of each panel with the / key to R/C.
3. Adjustment method
Check that the values of point A and B on page 8/8 of process adjustment are set as below. If not, change them accordingly.
1) Display the current adjustment status at point B. (Page 8/8 of process adjustment)
The display for checking the adjustment status is toggled by pressing the “OK” button on the remote control.
(Normal OSD display →“B” →display for check (OSD disappears) →“B” →normal OSD display →...)
2) Read the value of the luminance meter.
3) Change Point B ADJ R/Point B ADJ B (Adjustment offset value) on page 8/8 of process adjustment so that the values of the luminance meter
approach x = 0.272 and y = 0.277.
(Basically, Point B ADJ G is not changed.)
4) Follow Point A as well as item 3).
Change Point A ADJ R/Point A ADJ B (Adjustment offset value) on page 8/8 of process adjustment so that the values of the luminance meter
approach x = 0.272 and y = 0.277.
5) Select “WB WRITE” on page 8/8 in the process, set “YES”, and press the OK key of remote control.
The adjustment value is written. and then shut down the AC power.
* Initial value of RGB of point B: 3712
* Initial value of RGB of point A: based on calculated of each G point
6) [Adjustment value]
* Teaching set send by engineering dept is set as reference
4. Adjustment reference standard value
WB Point A 1280 WB Point B 3712
Level Spec Data Adjustment Spec Inspection Spec
Point A ref. value
Point B ref. value
1280
3712
x=0.272
y=0.277
x=0.272
y=0.277
±0.001
±0.002
±0.002
±0.004
Adjustment spec ±0.004
Adjustment spec ±0.002
Inspection spec ±0.006 (point 1)
Inspection spec ±0.004 (Excluding the above-mentioned)

LC-32/40/46LE600E/RU/S
4 – 9
11. QS Temperature NVM Data Confirmation
During servicing of the LCD TV set, by software upgrading or by any cleaning NVM, it’s mandatory select the “INCH SIZE” in Service Mode, Page 1,
according to the size of the TV set.
12. Initialization to factory settings
After a factory setting, It ends with the AC power supply OFF.
After a factory settings, Do not turn on the power supply. If you turn on the power supply. execute the factory settings again.
Do not do power supply OFF by remote control.
CAUTION: When the factory settings have been made, all user setting data, including the channel settings, are initialized.
(The adjustments done in the adjustment process mode are not initialized.) Keep this in mind when initializing these settings.
Adjustment item Adjustment conditions Adjustment procedure
1 Factory settings Ends in AC power supply
OFF. (See to below caution)
[Factory setting with adjustment process mode]
• Enter the adjustment process mode.
• Move the cursor to “INDUSTRY INIT” on page 2/8.
• Use the / key of R/C to select a region from “YES (E)/YES (I)/YES (F)/YES (R)”
and press the [OK] key.
• “EXECUTING” display appears and initialization starts.
• After a while, “OK” display appears, the setting is completed.
When succeeding: The background color becomes green.
When failing: The background color becomes red.
NOTE: Never turn the power off during initialization.
When performing factory settings (while displaying page 2 of adjustment process), confirm
that the item “INCH SIZE” or the panel size displayed in the upper right corner corresponds
to each panel size.
The following items are initialized in the factory setting.
1) User settings
2) Channel data (e.g. broadcast frequencies)
3) Manufacturer option setting
4) Password data
After adjustments, exit the adjustment process mode.
To exit the adjustment process mode, turn off the MAIN power key.
When the power is turned off with the remote control, unplug the AC power cord and plug it back in.
(wait approximately 10 seconds before plugging in the AC power cord)
Default picture after cleaning NVM. Picture with [Inch Setting] to 32.䋨It is actually set as each inch.䋩
PAGE1/8 TV 32E_LE600E
㵘Main Version -
Boot Version -
T-CON Version -
INCH SIZE -
ERROR RESET NO
STANDBYCAUSE 0000000000
1) 00H 00M
PAGE1/8 TV 32E_LE600E
㵘Main Version -
Boot Version -
T-CON Version -
CPLD Version -CPLD Version -
INCH SIZE 32
ERROR RESET NO
STANDBY CAUSE 00 00 00 00 00
1) 00H 00M

LC-32/40/46LE600E/RU/S
4 – 10
13. Functional explanation of STANDBY CAUSE
13.1. [display method]
It is displayed in the top page of the process adjustment mode. (Page displayed first when entering process mode)
13.2. [Content of display]
1. NORMAL STANDBY CAUSE
The reason that became a power-off by the specification of usual use and the main body is displayed.
(Only the one latest) It is not displayed when power supply OFF is carried out with remote control.
2. ERROR STANDBY CAUSE
When main CPU becomes a power-off detecting some abnormalities, the use time of the set at the time of the reason and the power-off is dis-
played five times.
When time information can be acquired from digital broadcasting, the date and time when the error occurs at the same time is recorded, displayed
and when time information cannot be acquired, it becomes the above-mentioned display.
“00” is displayed when abnormality has not been detected even once.
14. Lamp error detection
1. Function description
This LCD colour television has a function (lamp error detection) to be turned OFF automatically for safety when the lamp or lamp circuit is abnor-
mal.
If the lamp or lamp circuit is abnormal, or some other errors happen, and the lamp error detection is executed, the following occur.
1) The main unit of television is turned OFF about 5 seconds after it is turned ON.
(The power LED on the front side of TV turns from green to red.)
2) If the situation “1” happens 5 times sequentially, the power is turned on (relay is turned ON).
However, the backlight is not turned on, and then the relay is turned OFF after 5 to 6 seconds. (The power LED remains red.)
2. Countermeasures
When television is turned OFF by the lamp error detection mentioned above, it enters the adjustment process with the power LED red.
Entering the adjustment process, turns OFF the error detection and turns ON TV.
This enables the operation check to detect errors in the lamp or lamp circuit.
Check whether “STANDBY CAUSE” on line 7, page 1/8 of the adjustment process is “1B”. it indicates the lamp error detection was executed.
After confirming that the lamp or lamp circuit is normal, reset the lamp error counter pushing “OK” in the R/C.
After resetting counter the green bar appears on Screen.
3. Reset standby cause error list
After confirming that the lamp error counter has been erased, select “ERROR RESET”, page 1/8 of the adjustment process and select YES using
the right cursor. For execute press “OK” in the R/C and the label “***OK***” appears on Screen.
Display code Display character string Reason
00 00 00 00 00 00 When based on No error
0x01 1 RC_STANDBY When based on RC Standby OFF
0x05 5 PC_OUT_OF_RANGE When based on out of range for pc OFF
0x06 6 NO_OPERATION When based on non-operated OFF
0x07 7 NO_SIGNAL When based on non-signal OFF
0x0A a SLEEP_TIMER When based on an sleep-timer OFF
0x0C c RS232C When based on the command from RS232C (standby)
0x18 18 AV_LINK When based on the command from AV-LINK (standby)
Display error code Display character string Reason
0x1A 1a TEMP_ERROR When temperature (high temperature) is abnormal.
0x1B 1b LAMP_ERROR When lamp is abnormal
0x1C 1c POWER_ERROR When power module is abnormal status.

LC-32/40/46LE600E/RU/S
4 – 11
15. Blinking display when error is detected
When system received error report, Standby LED (red) blinks as follows.
POWER LED should keep dark while error indication.
1) Lamp error
Blink timing (1 blink/1 period)
2) Power module error
Blink timing (2 blink/1 period)
3) High temperature
Blink timing (5 blink/1 period)
Light (H)
Dark (L)
250ms 1000ms
㪣㫀㪾㪿㫋㩷㩿㪟㪀
㪛㪸㫉㫂㩷㩿㪣㪀㩷
㪈㪇㪇㪇㫄㫊
㪉㪌㪇㪉㪌㪇
㪉㪌㪇
Light (H)
Dark (L)
1000ms
250 250 250 250 250
250
250250250

LC-32/40/46LE600E/RU/S
4 – 12
16. Upgrading the software
1. Unplug AC cable from outlet.
2. Insert an USB memory that is written a new software to USB port.
3. Keep pressing POWER button on LCD panel and plug AC cable to outlet.
4. POWER LED on panel automatically start blinking.
(POWER LED: Both red and green light blinking with sync. In other word, it looks, /blinking period is short ... 2 cycle - light - out - light - out / 1 sec.)
5. After a while (about 2 min.) following screen appears. Indicated percentage means progress of version up.
6. After the progress becomes 100%, then STATUS area changes “UPGRADE COMPLETE” as followings (POWER LED: Only green blinks slowly ...
2 sec./time).
* If above screen is not appeared and “UPGRADE FAILURE” is indicated in STATUS area, at that time update failure. Please repeat from step 1.
(POWER LED: Only red blinks slowly ... 2 sec./time).
7. Unplug AC cable from outlet.
8. Remove USB memory from USB port.
<SYSTEM UPGRADE>
System Version: EXXXXXXX
0%
STATUS
UPDATING...
<SYSTEM UPGRADE>
System Version: EXXXXXXX
100% OK
STATUS
UPGRADE COMPLETE
<SYSTEM UPGRADE>
System Version: EXXXXXXX
50% NG
STATUS
UPGRADE FAILURE

LC-32/40/46LE600E/RU/S
5 – 1
LC32LE600E Service Manual
CHAPTER 5. TROUBLESHOOTING TABLE
[1] TROUBLESHOOTING TABLE
<POWER BLOCK: LC-32LE600E/RU/S>
No power supply (Front LED does not light up) and no power-up even if turned on (Front LED light up).
Is the wire harness in the unit properly connected? NO Reconnect and recheck the wire harness.
YES
Are F7001 and F7002 normal? NO Are L7004, L7001,L7002,BD7001 etc. faulty?
Check if the peripheral circuits are short-circuited.
YES
Is BU+5V supplied from pin(11) of connector CN7003 (PD) when
the power switch is turned off?
NO Check the peripheral circuits,
IC7101, T101, C7401, C7403, PC7008, etc ⋅⋅⋅.
YES
Is the PS_ON signal sent to pin(10) of connector CN7003 (PD)
when the power switch is turned on
NO Check pin(AC11) of IC3303(VCT_P) on MAIN PWB.
YES
Is the AC_DET signal sent to pin(9) of connector CN7003 (PD)
when the power switch is turned on?
NO Check the peripheral circuits,PC7007, Q7004, PC7002,etc.
YES
Is the DC voltage of approx. 400V supplied to both ends of
C7015?
NO Does the PFC circuit normally work?
(Check IC7002, L7003, TH7001, IC7001, Q7005, Q7006etc. and
the peripheral circuits.)
YES
Is UR13V supplied from pins(1-4) of connector CN7003 (PD)
when the power switch is turned on?
NO Check the peripheral circuits
(T7002, D7051, L7051, PC7001)
YES
Is PNL12V supplied from pins(1-2) of connector CN7004 (PL)
when the power switch is turned on?
NO Check the peripheral circuits (U7053, etc ⋅⋅⋅)
YES
Is 144V supplied from pins(2,4,6) of CN7007(LA2) and
pins(2,4,6,8,10,12) of CN7006 (LA1) when the power switch is
turned on?
NO Check the peripheral circuits,
T7501, D7501, C7501, FA5511,etc ⋅⋅⋅.

LC-32/40/46LE600E/RU/S
5 – 2
<POWER BLOCK: LC-40/46LE600E/RU/S>
No power supply (Front LED does not light up) and no power-up even if turned on (Front LED light up).
Is the wire harness in the unit properly connected? NO Reconnect and recheck the wire harness.
YES
Are F7001 and F7002 normal? NO <40LE600E/RU/S>
Are L7001, L7002, L7003, D7101, D7103, VA7002, VA7001,
VA7003 etc... faulty?
Check if the peripheral circuits are short-circuited.
YES
<46LE600E/RU/S>
Are L7001, L7002, L7003, L7004, D7101, VA7002, VA7001,
VA7003 etc... faulty?
Check if the peripheral circuits are short-circuited.
Is F7102 normal? NO Are TH7102, C7130, etc... faulty?
YES
Is BU+5V supplied from pin(11) of connector CN7501 (PD) when
the power switch is turned off?
NO Check the peripheral circuits (IC7102, T7101, C7510, PC7102,
PC7101, etc ⋅⋅⋅)
YES
Is the PS_ON signal sent to pin(10) of connector CN7501 (PD)
when the power switch is turned on?
NO Check pin(AC11) of IC3303(VCT_P) on MAIN PWB.
YES
Is the AC_DET signal sent to pin(9) of connector CN7501 (PD)
when the power switch is turned on?
NO Check the peripheral circuits such as PS_ON circuits of Q7503,
PC7103, Q7118, Q7114 and PC7104, Q7501,Q7502, etc.
YES
Is the DC voltage of approx. 400V supplied to both ends of
C7144?
NO <40LE600E/RU/S>
Does the PFC circuit normally work?
(Check IC7104, L7105, TH7101, RL7101, IC7200, Q7109,
Q7110 etc... and the peripheral circuits.)
YES
<46LE600E/RU/S>
Does the PFC circuit normally work?
(Check IC7104, L7105, TH7101, RL7101, IC7101, Q7108,
Q7109 etc... and the peripheral circuits.)
Is UR13V supplied from pins(1-4) of connector CN7501 (PD)
when the power switch is turned on?
NO Check the peripheral circuits (T7102, D7507, C7514,7515,7516,
PC7105, PC7106, IC7503 etc...)
YES
Is PNL12V supplied from pins(1-2) of connector CN7503 (PL)
when the power switch is turned on?
NO Check the peripheral circuits (IC7502, etc ⋅⋅⋅)
YES
<40LE600E/RU/S>
Is VLED supplied to pins(1-5) of CN7606(LA1) and pins(1-5) of
CN7607(LA2) when the power switch is turned on?
NO <40LE600E/RU/S>
Check the peripheral circuits, T7102, D7516, D7517, C7528,
L7501etc ⋅⋅⋅.
<46LE600E/RU/S>
Is VLED supplied to pins(1-5) of CN7606(LA1), pins(1-5) of
CN7607(LA2), pins(1-3) of CN7608(LA3) when the power switch
is turned on?
NO <46LE600E/RU/S>
Check the peripheral circuits, T7102, D7516, D7517, D7518,
C7528, C7538, L7501etc ⋅⋅⋅.

LC-32/40/46LE600E/RU/S
5 – 3
<Backlight BLOCK: LC-32LE600E/RU/S>
The backlight does not light
Is either of fluorescence LEDs off? YES Check each fluorescent LED, and change defective parts.
(RUNTKA595WJ01, RUNTKA598WJ01,etc.)
NO
Are all fluorescent LEDs on? NO Check each fluorescent LED, and change defective parts.
(RUNTKA595WJ01, RUNTKA598WJ01,etc.)
YES
Is REG3.3V supplied to pin(1) of CN7603(Driver_sub_PCB)
when the power switch is turned on?
NO Check if the peripheral circuits are short-circuited or parts are
faulty. (U7701, U7702, etc ⋅⋅⋅)
YES
YES
Refer to "No power supply (Front LED does not light up)" and
"No power-up even if turned on (Front LED light up)"
Is UR13V supplied from pins(1-4) of connector CN7003 (PD)
when the power switch is turned on?
NO Check the peripheral circuits
(T7002, D7501, L7501, PC7001)
YES
YES
Refer to "No power supply (Front LED does not light up)" and
"No power-up even if turned on (Front LED light up)"
Is the STB_ON/OFF signal supplied from pin(8) of CN7008 (LB)? NO Check the STB signal line on the MAIN_UNIT side (pin(2) of
P7602(LB), pin(D23) of IC3303(VCT_P), etc...)
and the peripheral circuits.
YES
Is each control signal of CN7008(LB) normally function?
Pin(7) OFL (PWM light control signal input)
Pin(6) ERR (Error output)
NO Check each control circuit.
YES
Is [LAMP_ERROR] indicated with [5] in a process mode? NO [LAMP_ERROR] is returned to the default value in a process
mode.
YES
Is BL_ON output to pin(2) of CN7603 when the power switch is
turned on?
NO Check the peripheral circuits (IC7054, etc ⋅⋅⋅)
YES
Is 144V supplied to pins(2,4,6) of CN7007(LA2) and
pins(2,4,6,8,10,12) of CN7006(LA1) when the power switch is
turned on?
NO Check if the peripheral circuits are short-circuited or parts are
faulty.
IC7251,PC7004, PC7006, T7501, D7501, C7501, FA5511,etc ⋅⋅⋅
YES
YES
Refer to "No power supply (Front LED does not light up)" and
"No power-up even if turned on (Front LED light up)"
Check if the peripheral circuits are short-circuited or parts are
faulty.
U7651, U7502, U7601-7605, Q7501-7509, Q7601-7609
