Sharp 29F-PS370 User manual

29F-PS370
SERVICE MANUAL
COLOUR TELEVISION
Chassis No. GB-7S
MODEL
CONTENTS
WARNING
The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and
power receptacle, when servicing this chassis. To prevent electric shock, do not remove cover. No user -
serviceable parts inside. Refer servicing to qualified service personnel.
World Multi 21System
100-CH Program Memory
AV Mode (Movie/Music/News)
CATV Hyper Band Ready
White/Blue/Black Stretch Circuit
Picture Noise Reduction
White Temp. Select (5 mode)
Mono Bilingual
Multi Language OSD (English / Thai)
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS.......................................1-1
CHAPTER 2. IMPORTANT SERVICE NOTES
[1] IMPORTANT SERVICE NOTE................... 2-1
CHAPTER 3. ADJUSTMENT PRECAUTIONS
[1] ADJUSTMENT PRECAUTIONS .................3-1
[2] ADJUSTMENT ............................................3-30
CHAPTER 4. TROUBLE SHOOTING FLOWCHART
[1] TROUBLE SHOOTING FLOWCHART........4-1
CHAPTER 5. SOLID STATE DEVICE BASE DIAGRAM
[1] SOLID STATE DEVICE BASE DIAGRAM...5-1
CHAPTER 6. CHASSIS LAYOUT
[1] CHASSIS LAYOUT......................................6-1
CHAPTER 8. DESCRIPTION OF SCHEMATIC DIA-
GRAM
[1] DESCRIPTION OF SCHEMATIC DIAGRAM 8-1
CHAPTER 9. WAVEFORM
[1] WAVEFORM ............................................... 9-1
CHAPTER 10. SCHEMATIC DIAGRAM
[1] SCHEMATIC DIAGRAM : MAIN UNIT.........10-1
[2] SCHEMATIC DIAGRAM : CRT UNIT ..........10-2
CHAPTER 11. PRINTED WIRING BOARD ASSEMBLIES
[1] PWB-A : MAIN UNIT....................................11-1
[2] PWB-B : CRT UNIT .....................................11-5
In the interests of user safety (Required by safety regulations in some countries) the set should be restored to its original
condition and only parts indentical to those specified should be used.
Off Timer Only
Rear AV-IN 1, AV Output (Monitor Out),
and Front AV-IN 2
Blue Back
Component & Audio Input Terminal
AV Stereo Model
Child Lock
Surround
Loundness
Hotel Mode 29 Slim CRT
Parts Guide
1st Edition
SHARP MANUFACTURING (THAILAND) CO.,LTD
...
CHAPTER 7. BLOCK DIAGRAM
[1] BLOCK DIAGRAM : MAIN UNIT .................7-1
Front AV-2 IN Auto Select
29F-PS370
Headphone
29F-PS370
Gamma Correction

29F-PS370
TV29S-FX10MService Manual29S-FX10MMarketE
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
SPECIFICATIONS
Focus ..................................................................... Bi-Potential, Uni-Potential Electrostatic
Sweep Deflection ................................................................................................... Magnetic
Intermediate Frequencies
Picture IF Carrier ................................................................................................ 38.9MHz
Sound IF Carrier
6.5MHz ............................................................................................................ 32.4MHz
6.0MHz ............................................................................................................ 32.9MHz
5.74MHz ........................................................................................................ 33.16MHz
Colour Sub-Carrier
PAL ................................................................................................................ 34.47MHz
SECAM .............................................................................................. 34.494/34.65MHz
Power Input ................................................................................... 110 ~ 240V AC 50/60 Hz
Power Consumption ..................................................................................................... 116W
Audio Power Output Rating ......................................................10 w ( R M S ) x 2 (TTL 20W)
Speaker
Size ........................................................................................... 6 cm x 13 cm (square) x 2
Aerial Input Impedance
VHF/UHF ......................................................................................... 75 ohms Unbalanced
Receiving Channels
PAL-B/G ; SECAM-B/G
VHF ................................................................................................................ E2 thru E12
UHF .............................................................................................................. E21 thru E69
CATV ......................................................................................... X thru Z + 2, S1 thru S41
PAL-D/K, SECAM-D/K, K1
VHF .......................................................................................... R1 thru R12, C1 thru C12
UHF .......................................................................................... 21 thru 69, C21 thru C57
PAL-I, SECAM-I
VHF .................................................................................. (IRELAND): B thru J
UHF .................................................................................. (U.K., H.K.): 21 thru 69
Receiving Frequency ................................................................ 44.25 MHz thru 863.25 MHz
Dimensions ..................................................................................................... Width: 764 mm
Height: 613 mm
Depth: 430 mm
Weight(approx): 38.5 kg
Cabinet material .................................................................................................. All Plastics
Specifications are subject to change without prior notice.
Convergence ............................................................................... Self Convergence System
NTSC ............................................................................................................. 35.32MHz
5.5MHz ............................................................................................................ 33.4MHz
4.5MHz ............................................................................................................ 34.4MHz
NTSC-M
VHF ....................................................................... (U.S.) : 2 thru 13, (JAPAN) : 1 thru 12
UHF ................................................................... (U.S.) : 14 thru 69, (JAPAN) : 13 thru 62
CATV .................................... (U.S.) : A-6 thru A-1, A thru W+29 (JAPAN) : C13 thru C63
1 - 1

29F-PS370
TV29S-FX10MService Manual29S-FX10MMarketE
CHAPTER 2. IMPORTANT SERVICE NOTES
[1] IMPORTANT SERVICE NOTE
IMPORTANT SERVICE NOTES
Maintenance and repairing of this receiver should be done by
qualified service personnel only.
SERVICE OF HIGH VOLTAGE SYSTEM AND
PICTURE TUBE
When servicing the high voltage system, remove static charge from it by
connecting a 10K ohm resistor in series with an insulated wire (such as a test
probe) between picture tube dag and 2nd anode lead. (AC line cord should
be disconnected from AC outlet.)
1. Picture tube in this receiver employs integral implosion protection.
2. Replace with the same type number of picture tube for continued safety.
3. Do not lift picture tube by the neck.
4. Handle the picture tube only when wearing shatterproof goggles and after discharging
the high voltage completely.
X-RAY
This receiver is designed so that any X-Ray radiation is kept to an absolute
minimum. Since certain malfunctions or servicing may produce potentially
hazardous radiation with prolonged exposure at close range, the following
precautions should be observed:
1. When repairing the circuit, please make sure do not increase the high voltage of the set
to more then 30kV (at beam 0 A).
2. To keep the set in a normal operation, please make sure it's function at 26.0kV 1.5kV
(at beam 1700 A). The set has been factory - adjusted to the above-mentioned high voltage.
*If there is a possibility that the high voltage fluctuates as a result of the repaires,
never forget to check for such high voltage after the work.
3. Do not substitute a picture tube with unauthorized types and/or brands which may cause
excessive X-ray radiation.
BEFORE RETURNING THE RECEIVER
Before returning the receiver to the user, perform the following safety checks.
1. Inspect all lead dress to make certain that leads are not pinched or that hardware is not
lodged between the chassis and other metal parts in the receiver.
2. Inspect all protective devices such as non-metal control knobs, insulating fishpapers,
cabinet backs, adjustment and compartment covers or shields, isolation resistor- ca-
pacity networks, mechanical insulators etc.
2 - 1

29F-PS370
TV29S-FX10MService Manual29S-FX10MMarketE
CHAPTER 3. ADJUSTMENT PRECAUTIONS
[1] ADJUSTMENT PRECAUTIONS
ADJUSTMENT PRECAUTIONS
This model's setting are adjusted in two different ways: through the I2C bus control and in the
conventional analog manner. The adjustments via the I2C bus control include preset-only items and
variable data.
1. Setting the service mode by the microprocessor.
(1). Press and hold the local key "VOL DOWN" & "CH UP" when power on the main switch,
TV will enter into SERVICE MODE. (The initial values of EEPROM are automatically
preset when new EEPROM is used.)
(2). Press the CH DOWN / UP key on the remote controller to select the setting items
one by one.
(3). Using the VOLUME UP/DOWN key on the remote controller, the data can be modified.
(4). When press the local key "VOL DOWN" & "CH UP" at the same time, it will be released
from the service mode.
2. Factory Presetting.
(1). Press remote controller key of code "ED" for 4 seconds, the initial values are
automatically preset.
(2). The initial data are preset as listed in page 3 - 4 , 3 - 5 and 3 - 6.
(3). Make sure whether the data need to modify or not (Initial data).
Note: Once the chassis has been assembly together and in ready condition, please make
sure it's go through initialize process (see sect 2 above)
Precaution: If haven't done this initialization, malfunction might be happen.
3 - 1

29F-PS370
1) In the Service Mode, key is use to select the mode in the following order.
ADJUSTMENT MODE
RF AGC 50Hz/60Hz
GEOMETRIC ADJ
CUT OFF/
WHITE BALANCE ADJ
PICTURE/SOUND
SUB ADJ
3 - 2

29F-PS370
Notes:
FORWARD : CH UP KEY
REVERSE : CH DOWN KEY
E/W-PAR-60
EW-W-60
DRI-BS-DVD
DRI-GS-DVD
SUB-TINT
SUB-SHARP
SUB-CON-DVD
SUB-TINT-DVD
SUB-BRI
SUB-BRI-DVD
SUB-COL
SUB-CON
DRI-RS-DVD
CUT-GS
CUT-BS
DRI-RC
DRI-RS
DRI-GS
CUT-RS
DRI-BS
V-AMP-60
LOCOR-PAR
H-BOW
H-PAR
E/W-TRAP
V-SHI-50
V-AMP-50
V-LIN
CUT-RS-DVD
E/W-PAR-50
H-SHI-60
V-SHI-60
UPCOR-PAR
CUT-GS-DVD
CUT-BS-DVD
VSLOPE
EW-W-50
S-COR
H-SHI-50
GEOMETRIC
ADJ MODE
WHITE POINT
ADJ MODE
PICTURE SUB ADJ
MODE
ADJUSTMENT MODE ITEMS SEQUENCE
DRI-RC-DVD
3 - 3

29F-PS370
ADJUSTMENT MODE ITEM
SET UP (DEC)
ADJ
ADJ
OSD DEFAULT
RF-AGC 23
VSLOPE 31
V-SHI-50 36
V-AMP-50 20
EW-W-50
ITEM EEPROM SETTING DATA RANGE IC
01 RF-AGC 0…63 UOC-TV
02 V SLOPE 0…63 UOC-TV
03 V-SHI-50 0…63 UOC-TV
04 V-AMP-50 0…63 UOC-TV
28
05 H-SHI-50 0…63 UOC-TV
06 EW-W-50 0…63 UOC-TV
H-SHI-50 30
32
07 36
08 H-PAR 0…63 UOC-TV
15 DRI-RSDRI-RS 0…63 UOC-TV
H-PAR 30
E/W-PAR-50 0…63 UOC-TV E/W-PAR-50
09 H-BOW 0…63 UOC-TV H-BOW 30
10 UPCOR-PAR 0…63 UOC-TV UPCOR-PAR 42
11 LOCOR-PAR 0…63 UOC-TV LOCOR-PAR 44
12 E/W-TRAP 0…63 UOC-TV E/W-TRAP 30
13 V-LIN 0…63 UOC-TV V-LIN 28
14 S-COR 0…63 UOC-TV S-COR 32
16 DRI-GS 0…63 UOC-TV DRI-GS 32
17 DRI-BS 0…63 UOC-TV DRI-BS 32
18 CUT-RS 0…63 UOC-TV CUT-RS 32
19 CUT-GS 0…63 UOC-TV CUT-GS 32
21 SUB-BRI 0…63 UOC-TV SUB-BRI 24
22 SUB-CON 0…63 UOC-TV SUB-CON 59
23 SUB-COL 0…63 UOC-TV SUB-COL 10
24 SUB-TINT 0…63 UOC-TV SUB-TINT 36
25 SUB-SHARP 0…63 UOC-TV SUB-SHARP 32
26 DRI-RW 0…63 UOC-TV DRI-RW 32
27 DRI-GW 0…63 UOC-TV DRI-GW 32
28 DRI-BW 0…63 UOC-TV DRI-BW 32
29 CUT-RW 0…63 UOC-TV CUT-RW 32
30 CUT-GW 0…63 UOC-TV CUT-GW 32
31 DRI-RLW 0…63 UOC-TV DRI-RLW 32
32 DRI-GLW 0…63 UOC-TV DRI-GLW 32
33 DRI-BLW 0…63 UOC-TV DRI-BLW 32
34 CUT-RLW 0…63 UOC-TV CUT-RLW 32
35 CUT-GLW 0…63 UOC-TV CUT-GLW 32
20 CUT-BS 0…63 UOC-TV CUT-BS 32
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
3 - 4

29F-PS370
DRI-RC-DVD 3264 DRI-RC-DVD 0…63 UOC-TV
UOC-TV DRI-RLW-DVD61 DRI-BLW-DVD
SETTING DATAOSD DEFAULT
37 DRI-GC 0…63 UOC-TV
ITEM EEPROM SETTING DATA RANGE IC
36 DRI-RC 0…63 UOC-TV DRI-RC 32
DRI-GC 32
38 DRI-BC 0…63 UOC-TV DRI-BC 32
39 CUT-RC 0…63 UOC-TV CUT-RC 32
40 CUT-GC 0…63 UOC-TV CUT-GC 32
41 DRI-RLC 0…63 UOC-TV DRI-RLC 32
43 DRI-BLC 0…63 UOC-TV DRI-BLC 32
44 CUT-RLC 0…63 UOC-TV CUT-RLC 32
45 CUT-GLC 0…63 UOC-TV CUT-GLC 32
46 DRI-RS-DVD 0…63 UOC-TV DRI-RS-DVD 32
47 DRI-GS-DVD 0…63 UOC-TV DRI-GS-DVD 32
48 DRI-BS-DVD 0…63 UOC-TV DRI-BS-DVD 32
49 CUT-RS-DVD 0…63 UOC-TV CUT-RS-DVD 32
50 CUT-GS-DVD 0…63 UOC-TV CUT-GS-DVD 32
51 CUT-BS-DVD 0…63 UOC-TV CUT-BS-DVD 32
52 SUB-BRI-DVD 0…63 UOC-TV SUB-BRI--DVD 24
53 SUB-CON-DVD 0…63 UOC-TV SUB-CON-DVD 48
54 DRI-RW-DVD 0…63 UOC-TV DRI-RW-DVD 32
55 DRI-GW-DVD 0…63 UOC-TV DRI-GW-DVD 32
56 DRI-BW-DVD 0…63 UOC-TV DRI-BW-DVD 32
57 CUT-RW-DVD 0…63 UOC-TV CUT-RW-DVD 32
58 CUT-GW-DVD 0…63 UOC-TV CUT-GW-DVD 32
59 DRI-RLW-DVD UOC-TV DRI-RLW-DVD 32
60 DRI-GLW-DVD 0…63 UOC-TV DRI-GLW-DVD 32
62 CUT-RLW-DVD UOC-TV CUT-RLW-DVD 32
42 DRI-GLC 0…63 UOC-TV DRI-GLC 32
CUT-GLW-DVD 3263 CUT-GLW-DVD 0…63 UOC-TV
0…63
0…63
0…63
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
32
3 - 5

29F-PS370
SETTING DATAOSD DEFAULT
66 DRI-BC-DVD 0…63 UOC-TV
ITEM EEPROM SETTING DATA RANGE IC
65 DRI-GC-DVD 0…63 UOC-TV DRI-GC-DVD 32
DRI-BC-DVD 32
67 CUT-RC-DVD 0…63 UOC-TV CUT-RC-DVD 32
68 CUT-GC-DVD 0…63 UOC-TV CUT-GC-DVD 32
69 DRI-RLC-DVD 0…63 UOC-TV DRI-RLC-DVD 32
70 DRI-GLC-DVD 0…63 UOC-TV DRI-GLC-DVD 32
72 CUT-RLC-DVD 0…63 UOC-TV CUT-RLC-DVD 32
73 CUT-GLC-DVD 0…63 UOC-TV CUT-GLC-DVD 32
74 V-SHI-60 0…63 UOC-TV V-SHI-60 36
75 V-AMP-60 0…63 UOC-TV V-AMP-60 23
76 H-SHI-60 0…63 UOC-TV H-SHI-60 37
77 EW-W-60 0…63 UOC-TV EW-W-60 28
78 E/W-PAR-60 0…63 UOC-TV E/W-PAR-60 38
79 VSD 0/1 UOC-TV VSD 0
80 CUT OFF 0-3 UOC-TV CUT OFF 02
81 DCXO 0-255 UOC-TV DCXO 55
82 ISP MODE 0/1 UOC-TV ISP-MODE 0
83 SUB-VOL 0-60 UOC-TV SUB-VOL 55
71 DRI-BLC-DVD 0…63 UOC-TV DRI-BLC-DVD 32
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
ADJ
0
02
55
0
55
3 - 6

29F-PS370
NVM MAP ITEMS
ADDRESS
DATA
MICON EEPROM EEPROM
(HEX) D7 D6 D5 D4 D3 D2 D1 D0
DEFAULT [hex] RANGE [hex] WRITE (CPU)
0000 LOCKING PASSWORD 0000 0000-
270F 0000
0001
0002 PACKAGE NUMBER (MSB) 03 00-FF 03
0003 PACKAGE NUMBER (LSB) 20 00-FF 20
0004
0005
0006
0007
0008 RF-AGC (01) 17 00-3F 17
0009 V-SLOPE (02) 1F 00-3F 1F
000A V-SHI-50 (03) 24 00-3F 28
000B V-AMP-50 (04) 14 00-3F 1A
000C H-SHI-50 (05) 1E 00-3F 1F
000D EW-W-50 (06) 1C 00-3F 2F
000E E/W-PAR-50 (07) 24 00-3F 29
000F H-PAR (08) 1E 00-3F 20
0010 H-BOW (09) 1E 00-3F 23
0011 UPCOR-PAR (10) 2A 00-3F 2A
0012 LOCOR-PAR (11) 2C 00-3F 2B
0013 E/W-TRAP (12) 1E 00-3F 18
0014 V-LIN (13) 1C 00-3F 25
0015 S-COR (14) 20 00-3F 20
0016 DRI-RS (15) 20 00-3F 20
0017 DRI-GS (16) 20 00-3F 20
0018 DRI-BS (17) 20 00-3F 20
0019 CUT-RS (18) 20 00-3F 0A
001A CUT-GS (19) 20 00-3F 0A
001B SUB-BRI (21) 18 00-3F 18
001C SUB-CON (22) 3B 00-3F 3B
001D SUB-COL (23) 0A 00-3F 06
001E SUB-TINT (24) 24 00-3F 27
001F SUB-SHARP (25) 20 00-3F 20
0020 DRI-RS-DVD (46) 20 00-3F 20
0021 DRI-GS-DVD (47) 20 00-3F 20
0022 DRI-BS-DVD (48) 20 00-3F 20
0023 CUT-RS-DVD (49) 20 00-3F 20
0024 CUT-GS-DVD (50) 20 00-3F 20
0025 SUB-BRI-DVD (52) 18 00-3F 18
0026 SUB-CON-DVD (53) 30 00-3F 30
0027 SUB-TINT-DVD 20 00-3F 20
0028 DRI-RC (36) 20 00-3F 20
0029 DRI-GC (37) 20 00-3F 20
002A DRI-BC (38) 20 00-3F 20
002B CUT-RC (39) 20 00-3F 20
002C CUT-GC (40) 20 00-3F 20
002D DRI-RW (26) 20 00-3F 20
002E DRI-GW (27) 20 00-3F 20
002F DRI-BW (28) 20 00-3F 20
0030 CUT-RW (29) 20 00-3F 20
0031 CUT-GW (30) 20 00-3F 20
0032 DRI-RC-DVD (64) 20 00-3F 20
0033 DRI-GC-DVD (65) 20 00-3F 20
0034 DRI-BC-DVD (66) 20 00-3F 20
0035 CUT-RC-DVD (67) 20 00-3F 20
0036 CUT-GC-DVD (68) 20 00-3F 20
0037 DRI-RW-DVD (54) 20 00-3F 20
0038 DRI-GW-DVD (55) 20 00-3F 20
0039 DRI-BW-DVD (56) 20 00-3F 20
003A CUT-RW-DVD (57) 20 00-3F 20
003B CUT-GW-DVD (58) 20 00-3F 20
003C VER-SHI-P50 27 00-3F 27
003D VER-AMP-P50 23 00-3F 23
003E H0R-SHI-P50 1F 00-3F 1F
003F EW-W-P50 0B 00-3F 0B
MODEL
29F-PS370
3 - 7
