Sharp CX68NF5 User manual

Printelligence (M) Sdn. Bhd
Dimension: 176 x 250 mm
MODEL
ONTIMER
POWER
SAVE
Please read this operation manual
carefully before using the colour
television.
OPERATION MANUAL
COLOUR TELEVISION
MODEL
CX68NF5
CX68NF5(Front) 11/12/02, 3:27 PM1

E 1
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Contents
Preparation
Accessories ................................................................................ 2
Easy setup .................................................................................. 3
Safety precautions ...................................................................... 4
Part names ................................................................................. 5
Installing batteries in the remote control unit .............................. 5
Watching TV
Watching a TV programme ......................................................... 7
Operating the TV buttons ............................................................ 8
Useful features
Channel/Timer display ................................................................ 9
Mute ............................................................................................ 9
AV Mode ..................................................................................... 9
Channel recall ........................................................................... 10
TV/Video selection .................................................................... 10
Selecting menu items
Selecting a menu item .............................................................. 11
Settings and adjustments
On-screen display language selection ...................................... 12
Manual channel tuning.............................................................. 13
Auto channel tuning .................................................................. 14
Channel setting ......................................................................... 15
Picture adjustment .................................................................... 16
Sound adjustment ..................................................................... 17
Blue screen ............................................................................... 18
Save .......................................................................................... 19
VM (Velocity Modulation) .......................................................... 20
AI (Artificial Intelligence) ........................................................... 20
Off timer .................................................................................... 21
On timer .................................................................................... 22
Reminder on-screen timer ........................................................ 23
Connections
Connecting to a DVD player...................................................... 24
Watching DVD Playback ........................................................... 24
Connecting to an antenna ........................................................ 25
Connecting to an antenna via a VCR ....................................... 25
Connecting to video equipment ................................................ 26
Troubleshooting
Troubleshooting ........................................................................ 27
Specifications
Specifications ........................................................................... 28
CX68NF5(01-05) 11/12/02, 3:28 PM1

E 2
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Dear SHARP Customer
Thank you for buying SHARP's Colour
Television. We hope you will have many
years of enjoyment from this television
set. To ensure proper operation, please
read this manual carefully, and keep it in
a safe place for future reference.
Remote control Size-AA batteries Operation manual
The following accessories are included with this television.
Accessories
CX68NF5(01-05) 11/12/02, 3:28 PM2

E 3
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Easy setup
To use your TV set, perform the easy setup procedure below.
The mark indicates the page numbers with more detailed information.
Connect the antenna.
• See
25
to connect the antenna.
Connect any video equipment.
• See
25
,
26
to connect video equipment.
• See the operation manual of your video equipment when
connecting to the TV set.
Insert the batteries into the remote control.
• Use the two batteries included with the TV.
• See
5
.
Insert the AC plug to the power outlet.
• If you will not use the TV set for a considerable length of
time, as a safety precaution, unplug the cord from the outlet.
Tune the channels.
• Use the buttons on the TV.
• See
13
,
14
.
CX68NF5(01-05) 11/12/02, 3:29 PM3

E 4
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Safety precautions
Do not place this TV set
on an unstable cart,
stand, shelf, or table. The
TV set may fall, causing
serious injury to a child
or adult, and serious
damage to the set.
Sharp recommends
securing the TV set to a
stable surface or wall to
prevent the set from
falling due to sudden
shocks or impact.
Do not place a flower
vase or anything else
containing liquid on the
TV set, as liquid spilt on
the TV set can cause
electrical shock or
failure.
Damage
Turn off the power and
unplug the power cord
from the wall outlet
immediately if the TV
set begins to make any
unusual noises or gives
off smoke or an unusual
smell. Then call your
dealer for service.
Servicing
To reduce the risk of
electric shock, do not
remove the back of the
cabinet. This TV set
contains dangerous
voltage.
Unstable surface and shocks
Liquid entry
Never insert or drop any
metallic or inflammable
objects into the
ventilation openings of
the TV set, as this can
cause fire, electrical
shock, or electrical
failure.
Object entry
Water
Power-cord protection
To prevent electrical
shock, do not subject the
AC power cord to damage
by bending or twisting it,
or by placing heavy items
on top of it and do not
place the AC power cord
under the TV set. If the AC
power cord becomes
damaged, unplug it from
the wall outlet immediately
and call your dealer for
service.
To prevent electrical
shock, do not use the TV
set in an excessively
damp place.
Moisture
Ventilation
Do not place this TV set
in a confined area, such
as on a bookshelf or in a
built-in case. Leave
adequate space behind
the TV for proper
ventilation.
TV Set position
To prevent fire or
electrical shock, do not
place the TV set near a
bathroom, swimming
pool or other area where
it may become wet.
Do place the TV set onto
an even stand, table or
track which size is bigger
than the TV set.
If the TV set is put onto a
smaller size or uneven
stand, table or track may
cause the TV cabinet distort.
Do not put or insert anything
between TV set and the
stand, table or track.
CX68NF5(01-05) 11/12/02, 3:29 PM4

E 5
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Part names
• Be sure to match the battery j/kterminals with the j/kmarks inside the compartment.
• Remove the batteries if weak or if the unit is not in use for long periods.
• Do not mix old and new batteries.
• Incorrect installation of the batteries may damage the remote control.
With your thumbnail, pull
up at the slit to open the
battery cover.
Insert two batteries
(size AA).
Replace the battery cover.
Installing batteries in the remote control unit
Remote control
The mark indicates the page numbers with more detailed information.
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
TV
123
456
78
0
9
CH
CH
Infrared transmitter window
Aim this window at the infrared
sensor window on your TV set.
Turns the TV on or to
Standby mode.
7
10
Returns to previously viewed
channel.
9
Mutes the sound and restores
sound to previous level.
19
POWER SAVE
9
Changes Picture and Sound setting.
STANDARD, SOFT, DYNAMIC
AV MODE
9
Displays the channel and timer
settings on the screen.
Number buttons
7
10
Switches between TV broadcasts
and A/V input programmes.
TV/VIDEO
7
Switches between one- or two-digit
mode channel selection.
7
Selects the channel.
Used for MENU setup.
CH
CH /
11
Calls the MENU screen.
MENU
16
Resets all settings.
NORMAL
7
Adjusts the volume.
Used for MENU setup.
/
CX68NF5(01-05) 11/12/02, 3:29 PM5

E 6
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
ONTIMER POWER
SAVE
ON TIMER POWER
SAVE
VIDEO (MONO) L-AUDIO-R
S-VIDEO AV-3 IN
MENU/PRESET
CH
Behind the door
7
7
22
19
5
TV Set (Bottom)
TV Set (Top)
7
11
26
26
26
8
7
On timer indicator
Power indicator
Power can be turned on by
the remote control when the
indicator is red.
Power switch
Turns on and off
the main power.
Infrared sensor window
Receives the infrared wave
from the remote control.
Power save indicator
Volume up/down buttons
Adjusts the volume.
Makes adjustments in PRESET.
MENU/PRESET button
Tunes the channels.
Used for MENU setup.
Audio input terminals
(AV-3)
Connects to a camcorder,
video game, etc.
Video input terminal (AV-3)
Connects to a camcorder,
video game, etc.
S-Video input terminal (AV-3)
Connects to a camcorder, video game, etc.
Headphone jack
Use to listen to the audio with headphone.
/
MENU/PRESET
Channel up/down buttons
Selects the channels.
Tunes or sets the channels.
CH
CH
/
TV set
• When using headphone, see
8
.
CX68NF5(06-10) 11/12/02, 3:29 PM6

E 7
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Watching TV
1Turn on power.
• When the power indicator is off, press .
• When the power indicator lights up red, press on the
remote control. The power indicator changes to green and a picture
appears.
ON TIMER POWER
SAVE
Power indicator
Watching a TV programme
Simple operations for watching a TV programme
With CH / CH
•Press
CH
and channels change as shown below.
1 /2 / ... /98 /99 /AV1 (or SAV1) /AV2 (or COMPONENT)
/ AV3 (or SAV3) /0 /1 /2 ...
•Press
CH
and channels change as shown below.
1 /0 / AV3 (or SAV3) /AV2 (or COMPONENT) /AV1 (or SAV1)
/99 /98 /... /2 /1 /0 ...
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
1
5
CH
CH
VOLUME 10
3Adjust volume using /
.
•The number of oval blocks “ ”
indicates the volume level. The
volume bar disappears
approximately three seconds after
the volume has been adjusted.
2Select channel.
With the number buttons (on remote control)
•To select a one-digit channel, such as 5, press
5
.
If “5-”is indicated, press to select one-digit input, and then
press
5
again.
•To select a two-digit channel, such as 15, press to select
the two-digit input. Press
1
, and then press
5
.
--
1-
15
PAL
•When the power indicator lights up red, either
CH
/
CH
on the TV can be pressed to turn on
the power.
•The channel number is displayed in green for channels tuned by auto tuning and displayed in yellow for
channels tuned using fine tuning.
•When the power indicator lights up red, the TV is in Standby mode and power is still supplied to the TV.
If you will not watch TV for a while, turn off the main power by pressing on the TV set. Also, if
you will not be at home for a considerable length of time, unplug the cord from the outlet.
•The AV1 (or SAV1), AV2 (or COMPONENT) and AV3 (or SAV3) input channels cannot be selected using
CH
/
CH
on the remote control. Use
TV/VIDEO
to select these channel.
•Channels that have been skipped cannot be selected. See
15
.
•The on-screen displays in this manual may differ from their actual appearance.
MENU/PRESET
CH
CH
CH
TV Set (Bottom)
TV Set (Top)
CX68NF5(06-10) 11/12/02, 3:30 PM7

E 8
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
•Select an appropriate volume so as not to injure your hearing.
•To avoid injuring your hearing, do not put on the headphone before plugging them into the headphone
jack and before the power is turned on.
•The proper impedance for the headphone is 32 ohms.
•Remove the headphone plug from the jack when not using the headphone.
Operating the TV buttons
Simple operation of the TV set
Using /
Press to increase volume.
Press to decrease volume.
MENU/PRESET
CH
CH
CH
VOLUME

15
5
PAL
Using
CH
/
CH
Press CH to increase channel
number.
Press CH to decrease channel
number.
Using headphone
Insert headphone plug into headphone jack to listen to audio with
headphone.
•The audio from the speakers is turned off.
VIDEO (MONO) L-AUDIO-R
S-VIDEO AV-3 IN
Behind the door
TV Set (Top)
CX68NF5(06-10) 11/12/02, 3:30 PM8

E 9
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Channel/Timer display
Displays the current channel number, the timer, and other
settings on the screen.
ON 8:00
OFF 2:30
1:50
5
PAL
2Press again.
•The channel number and colour
system appear on the screen.
1Press .
•The time remaining on the Off timer,
On timer, and Reminder appears on
the screen.
•When no Timer is set, the channel
number and colour system appear
on the screen. Press again to clear
these current settings display on the
screen.
Useful features
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
AV MODE
NORMAL
CH
CH
Mute
Silences the sound.
1Press .
•“ ”appears on the screen, and the
sound is silenced.
2Press again.
•The volume returns to its previous
level.
3Press once again.
•The display disappears.
AV Mode
Each time you press the
AV MODE
button, the mode switches between
STANDARD, SOFT and DYNAMIC.
STANDARD: Normal mode
SOFT: Soft mode
DYNAMIC: Dynamic mode
(STANDARD)
(DYNAMIC)
(SOFT)
•To return to the original setting (factory setting), press the
NORMAL
. For adjusting the Picture and Sound
modes, please see
16
and
17
.
•Mute will be cancelled if the is pressed at anytime.
CX68NF5(06-10) 11/12/02, 3:30 PM9

E 10
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
TV/Video selection
Switches between TV broadcasts and AV input programmes.
Each time you press the
TV/VIDEO
, the
input switches between AV1 (or SAV1),
AV2 (or COMPONENT), AV3 (or SAV3)
and TV programme.
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
TV/VIDEO
CH
CH
Channel recall
Switches back to the channel you were watching just before
the current channel.
25
SAV1 or AV1
PAL
COMPONENT or AV2
SAV3 or AV3
Press .
•The channel previously viewed returns to
the screen.
Example:
If, after switching from channel 5 to
channel 7, is pressed, the
channel will change to channel 5. Press
again to return to channel 7.
5
PAL
7
PAL
5
PAL
7
PAL
CX68NF5(06-10) 11/12/02, 3:30 PM10

E 11
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Selecting a menu item
MENU
SOUND
FEATURE
TIMER
CH-SETTING
1Press
MENU
/
MENU/PRESET
to
call MENU screen.
MENU
SOUND
FEATURE
TIMER
CH-SETTING
3Press / to
enter.
• The corresponding menu screen will
appear.
SOUND (STANDARD)
SURROUND
TREBLE
BASS
+10
-
20
ON
20
ON
S-BOOSTER
BALANCE
This TV set allows you to adjust the picture and sound, and set the channels and other features
using the On-screen display with the remote control or from the TV set. Select the desired
menu item by following the steps below and then refer to the indicated page for details.
Remote control
MENU/PRESET
CH
CH
CH
MENU/PRESET
2Press
CH
/
CH
or
CH
/
CH
to select
desired menu item.
• The selected item is highlighted in
yellow.
• If you press
MENU/PRESET
for more than two seconds, the LANGUAGE mode screen will appear instead of the MENU
screen. To display the MENU screen, press
MENU/PRESET
until the normal screen appears, then press the button again.
• The procedures for setting and selecting the menu items on the following pages are described using the buttons
on the remote control. These procedures can also be performed using the corresponding buttons on the TV set.
ONTIMER POWER
SAVE
MENU
SOUND
FEATURE
TIMER
CH-SETTING
CH SELECT
ENTER MENU RETURN
Operating guide
PICTURE menu SOUND menu
FEATURE menu TIMER menu
2018 – 2321 –
17
16
SOUND (STANDARD)
SURROUND
TREBLE
BASS
+10
-
20
ON
20
ON
S-BOOSTER
BALANCE
CH SELECT
ADJUST MENU RETURN
CH SELECT
ADJUST MENU RETURN
PICTURE (STANDARD)
CONTRAST
COLOUR
BRIGHTNESS +
10
- 10
ON
10
0
TINT
SHARPNESS
PICTURE NR
20
WHITE TEMP
CH SELECT
ADJUST MENU RETURN
TIMER
OFF
ON
POSITION
--:--
--:--
--:--
VOLUME
FEATURE
BLUE BACK
SAVE
VM
ON
ON
AI
ON
ON
CH SELECT
ADJUST MENU RETURN
CH SELECT
ADJUST MENU RETURN
CH-SETTING menu
15
CH-SETTING
POSITION
COLOUR
SKIP
AUTO
OF
F
168.
25M H Z
CH27
FINE
Selecting menu items
TV
POWER
SAVE
AV MODE
MENU
NORMAL
0
CH
CH
MENU
CH
CH
TV Set (Top)
CX68NF5(11-15) 11/12/02, 3:30 PM11

E 12
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Settings and adjustments
On-screen display language selection
The on-screen display language can be set to English,
Chinese, French, Russian, Malay or Arabic.
ENGLISH
FRANCAIS
BAHASA
MELAYU
3Press
MENU/PRESET
until normal
screen appears.
2Press
CH
/
CH
to
select desired language.
•Pressing
MENU/PRESET
changes the
screen as shown below.
1Press
MENU/PRESET
for more than
two seconds.
•The language select mode appears.
Language MANUAL
Normal screen
AUTO
MENU/PRESET
CH
CH
CH
MENU/PRESET
TV set
TV Set (Top)
CX68NF5(11-15) 11/12/02, 3:30 PM12

E 13
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Settings and adjustments
TV Set (Top)
Manual channel tuning
Enables manual channel tuning to a desired TV station. (e.g.
tuning the TV to a VCR, tuning in an additional TV station.)
NOTE: This TV is already tuned into 2, 7, 9, 10 and 28.
1Press
MENU/PRESET
for more than
two seconds.
•The language select mode appears.
ENGLISH
FRANCAIS
BAHASA
MELAYU
2Press
MENU/PRESET
twice to display
MANUAL mode screen.
•Pressing
MENU/PRESET
changes the
screen as shown below.
MANUAL(B/G)
VHF 1
48.25MH
z
Language MANUAL
Normal screen
AUTO
MANUAL(B/G)
VHF 5
107.50MH
z
3Press
CH
/
CH
or
CH
/
CH
or number
buttons to select channel
position.
4Press / on TV
set to locate channel you wish to
preset to current channel
position.
•Search is initiated and when a TV
signal is received during the search,
the search stops.
5Repeat steps 3 and 4 above, to preset channel positions for
other broadcasts.
6Press
MENU/PRESET
again to display normal screen.
Channel position
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
Number
buttons
MENU
CH
CH
MENU/PRESET
CH
CH
CH
MENU/PRESET
CX68NF5(11-15) 11/12/02, 3:30 PM13

E 14
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
TV Set (Top)
Auto channel tuning
Automatically tunes in and presets receivable TV stations,
using consecutive channels numbers (e.g. 2, 7, 9, 10 will be
stored as 1, 2, 3, 4).
AUTO(B/G)
VHF 1
48.25MH
z
1Press
MENU/PRESET
for more than
two seconds.
•The language select mode appears.
•AUTO PRESET stores all receivable channels including those which may be very weak and not clearly
visible. To preset only those channels designated for the local viewing region, use MANUAL PRESET.
See
13
.
•Unused channels are automatically skipped.
1
PAL
2Press
MENU/PRESET
again to display
AUTO mode screen.
•Pressing
MENU/PRESET
changes the
screen as shown below.
MENU/PRESET
CH
MENU/PRESET
3Press / on TV
set.
•All the TV stations in your area that
can be received by the TV set are
automatically preset between
channels 1 to 99.
•The screen shows whatever is on
channel 1 when auto channel preset
is finished.
ENGLISH
FRANCAIS
BAHASA
MELAYU
Language MANUAL
Normal screen
AUTO
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
MENU
CH
CH
CX68NF5(11-15) 11/12/02, 3:30 PM14

E 15
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Channel setting
Enables individual channel setting.
MENU
SOUND
FEATURE
TIMER
CH-SETTING
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to
select “CH-SETTING”.
CH-SETTING
POSITION CH27
AUTO
OFF
168.25MH
z
COLOUR
SKIP
FINE
CH SELECT
ADJUST MENU RETURN
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
MENU
CH
CH
3Press / to
display CH-SETTING menu.
4Press
CH
/
CH
to
select desired setting.
5Each time you press /
, setting for individual
items changes as follows:
•POSITION
The channel position changes to the higher or lower number.
•COLOUR
AUTO PA L
•SKIP
ON OFF
Channel numbers with a “”mark on the left are set to SKIP. To turn
off SKIP, press the number buttons to select the desired channel and
then set “SKIP”to “OFF”.
•FINE
The frequency changes to allow fine tuning.
•Switching COLOUR system:
Set the system to “AUTO”for normal TV reception. The AUTO mode automatically detects the receiving
signal system and changes the reception system of the TV set. When the picture is not stable, switching to
an appropriate system may improve the picture quality.
•In a weak reception area, or under bad reception conditions, you can change the frequency by fine tuning.
•When using FINE, the channel number changes from green to yellow.
•To return the channel to its original frequency setting, follow the manual channel tuning procedure. See
13
.
6Press
MENU
until normal
screen appears.
•When you select AV1, AV2 or AV3
for the channel position, the CH-
SETTING menu changes as shown
on the right and the colour mode
changes in the following order:
CH-SETTING
POSITION AV1
AUTO
COLOUR
CH SELECT
ADJUST MENU RETURN
AUTO PAL N443 N358
Settings and adjustments
CX68NF5(11-15) 11/12/02, 3:31 PM15

E 16
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
MENU
NORMAL
CH
CH
Picture adjustment
MENU
SOUND
FEATURE
TIMER
CH-SETTING
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to
select “PICTURE”.
PICTURE (STANDARD)
CONTRAST
COLOUR
BRIGHTNESS
0
+10
- 10
ON
20
50
TINT
SHARPNESS
PICTURE NR
WHITE TEMP
6Repeat steps 4 and 5 above to adjust other items.
7Press
MENU
until normal screen appears.
• When
NORMAL
is pressed while the PICTURE menu is displayed, the setting
for the selected item is reset to the standard (factory setting) position.
• When
NORMAL
is pressed while the MENU screen is displayed and
“PICTURE” is selected, all the settings for the PICTURE items are reset to
the standard (factory setting) position.
3Press / to
display PICTURE menu.
4Press
CH
/
CH
to
select adjustment items.
-+
CONTRAST 50
(STANDARD)
5Adjust using / .
• Wait for approximately three seconds
to return to PICTURE menu.
CONTRAST
Selected item Press Press
COLOUR
BRIGHTNESS
TINT -1
SHARPNESS
PICTURE NR -2
To decrease
contrast
For less colour
intensity
For less
brightness
To move tint toward
purple
For less
sharpness
To increase
contrast
For more colour
intensity
For more
brightness
To move tint toward
green
For more
sharpness
(See note below)
WHITE TEMP To more reddish
background
To more bluish
background
- +
- +
- +
- +
ON OFF
The following table lists the adjustment items shown in the PICTURE menu and how they change as you
press / .
*-1: TINT can only be selected and adjusted when receiving NTSC broadcasts. (AV only)
*-2: Picture Noise Reduction
Noise might be generated on images when playing deteriorated video tapes or when receiving broadcasts with relatively
weak signals. In these cases, set PICTURE NR to “ON”to reduce the noise. However, when receiving good images
without noise, you can get better image quality by turning OFF this feature.
CX68NF5(16-22) 11/12/02, 3:31 PM16

E 17
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Sound adjustment
MENU
SOUND
FEATURE
TIMER
CH-SETTING
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to
select “SOUND”.
SOUND (STANDARD)
SURROUND
TREBLE
BASS
+10
-20
ON
20
ON
S-BOOSTER
BALANCE
-+
TREBLE + 10
(STANDARD)
6Repeat steps 4 and 5 above to adjust other items.
7Press
MENU
until normal screen appears.
•When
NORMAL
is pressed while the SOUND menu is displayed, the setting
for the selected item is reset to the standard (factory setting) position.
•When
NORMAL
is pressed while the MENU screen is displayed and
“SOUND”is selected, all the settings for the SOUND items are reset to the
standard (factory setting) position.
SURROUND
TREBLE
BASS
Selected item
The surround effect is
ON
To decrease treble
To decrease bass
The surround effect is
OFF
To increase treble
To increase bass
Press Press
- +
- +
BALANCE To shift balance
toward left
To shift balance
toward right
ON OFF
S-BOOSTER To boost sound Normal sound
ON OFF
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
MENU
NORMAL
CH
CH
3Press / to
display SOUND menu.
4Press
CH
/
CH
to
select adjustment items.
The following table lists the adjustment items shown in the SOUND menu and how they change as you
press / .
5Adjust using / .
•Wait for approximately three
seconds to return to SOUND menu.
Settings and adjustments
CX68NF5(16-22) 11/12/02, 3:31 PM17

E 18
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Blue screen
Automatically turns the screen blue if a broadcast signal is
not received.
•Poor reception due to weak signals and too much noise may activate BLUE BACK, despite the
presence of a broadcast signal. To continue watching TV under these conditions, switch “BLUE BACK”
to “OFF”.
•When Off timer is set, the OFF TIMER setting has priority over BLUE BACK.
MENU
SOUND
FEATURE
TIMER
CH-SETTING
CH SELECT
ENTER MENU RETURN
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to
select “FEATURE ”.
3Press / to
display FEATURE menu.
4Press
CH
/
CH
to
select “BLUE BACK”.
5Press / to
select “ON”or “OFF”.
6Press
MENU
until normal screen appears.
FEATURE
BLUE BACK ON
ON
ON
SAVE
VM
ON
AI
CH SELECT
ADJUST MENU RETURN
after five seconds after 15 minutes
No signal
When BLUE BACK is set to “ON”
Blue screen TV off
Standby mode
(Indicator)
Power indicator
lights up red
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
MENU
CH
CH
CX68NF5(16-22) 11/12/02, 3:31 PM18

E 19
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
TV
TV/VIDEO
POWER
SAVE
AV MODE
MENU
NORMAL
123
456
78
0
9
CH
CH
MENU
POWER SAVE
CH
CH
Save
This function reduces the picture brightness to create a
softer image while saving electricity.
3Press / to
display FEATURE menu.
4Press
CH
/
CH
to
select “SAVE”.
5Press / to
select “ON”or “OFF”.
•When SAVE is set “ON”, the Power save indicator on the TV set
lights up in red.
•When SAVE is set “OFF”, the Power save indicator on the TV set is
turn off.
6Press
MENU
until normal
screen appears.
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to
select “FEATURE”.
MENU
SOUND
FEATURE
TIMER
CH-SETTING
CH SELECT
ENTER MENU RETURN
FEATURE
BLUE BACK ON
ON
ON
SAVE
VM
ON
AI
CH SELECT
ADJUST MENU RETURN
Settings and adjustments
Using
MENU
TV Set (Bottom)
ON TIMER POWER
SAVE
Power save indicator (Red)
Using Remote Control
1Press
POWER SAVE
to display the
SAVE mode screen.
2Each time you press
POWER SAVE
,
the mode switches between “ON”
and “OFF”.
•When SAVE is set “ON”, the Power
save indicator on the TV set lights
up in red.
•When SAVE is set “OFF”, the Power
save indicator on the TV set is turn
off.
3Press to turn off the
SAVE mode screen.
SAVE
ON
SAVE
OFF
CX68NF5(16-22) 11/12/02, 3:31 PM19
