LCD COLOUR TELEVISION
OPERATION MANUAL
Printed in Japan
TINS-A011WJZZ
02P04-JKM
Printed on post-consumer recycled paper.
LC-15B2MA
LC-20B2MA
LC-15B2MA
LC-20B2MA
MENU
MENU
TINS-A011WJZZ
02P04-JKM

1
LC-15B2MA
LC-20B2MA
LCD COLOUR TELEVISION
OPERATION MANUAL
ENGLISH
CONTENTS
Page
DEAR SHARP CUSTOMER ................................ 2
SAFETY PRECAUTIONS ................................ 2, 3
SUPPLIED ACCESSORIES ................................ 4
PREPARATION ................................................5, 6
Preparing and Using the Remote Control .. 5
Batteries for Remote Control ....................... 5
Power Connection ......................................... 6
Antenna Connection ...................................... 6
LOCATION OF USERS CONTROL ........... 7, 8, 9
BASIC OPERATION ............................. 10, 11, 12
Turning on POWER...................................... 10
Switching TV/VIDEO AV1/AV2/
COMPONENT/TV Mode ............................. 10
Sound Volume .............................................. 11
ON/OFF Standby .......................................... 11
Changing the Channels ............................... 12
SELECTING THE MENU ITEMS ....................... 13
Selecting a Menu Item ................................. 13
Page
PRESET................................................. 14, 15, 16
On-Screen Display Language Selection ... 14
Presetting the Channels (AUTO) ................ 14
Presetting the Channels (MANUAL) .......... 15
Channel Setting ............................................ 16
ADJUSTMENT .......................... 17, 18, 19, 20, 21
Adjusting the SLEEP TIMER Setting ......... 17
Adjusting the PICTURE Settings ........ 18, 19
Adjusting the FEATURE Settings ....... 20, 21
NICAM BROADCASTS SELECTION ............... 22
IGR (German stereo system) BROADCASTS .... 23
CONNECTING WITH EXTERNAL
DEVICES ............................................. 24, 25, 26
LISTENING WITH HEADPHONES ................... 26
TROUBLESHOOTING ................................ 27, 28
HOW TO FIX THE CABLES .............................. 28
SPECIFICATIONS.............................................. 29
DIMENSIONAL DRAWINGS ...................... 30, 31
ENGLISH

2
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp LCD Colour TV product. To ensure safety
and many years of trouble-free operation of your product, please read the Safety
Precautions carefully before using this product.
SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent
potential danger, please observe the following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of your LCD colour TV product, please read
the following precautions carefully before using the product.
■Read instructions—All operating instructions must be read and understood before the product is
operated.
■Keep this manual in a safe place—These safety and operating instructions must be kept in a safe
place for future reference.
■Observe warnings—All warnings on the product and in the instructions must be observed closely.
■Follow instructions—All operating instructions must be followed.
■Attachments—Do not use attachments not recommended by the manufacturer. Use of inadequate
attachments can result in accidents.
■Power source—This product must operate on a power source specified on the specification label.
If you are not sure of the type of power supply used in your home, consult your dealer or local
power company. For units designed to operate on batteries or another power source, refer to the
operating instructions.
■Power cord protection—The power cords must be routed properly to prevent people from stepping
on them or objects from resting on them. Check the cords at the plugs and product.
■If you plan to use a DC power supply unit other than the AC adapter supplied with the product,
make sure the power supply unit provides stable voltage with minimum fluctuations. Unstable
power supply can cause problems in the product.
■Overloading—Do not overload AC outlets or extension cords.
Overloading can cause fire or electric shock.
■Entering of objects and liquids—Never insert an object into the product through vents or openings.
High voltage flows in the product, and inserting an object can cause electric shock and/or short
internal parts. For the same reason, do not spill water or liquid on the product.
■Servicing—Do not attempt to service the product yourself. Removing covers can expose you to
high voltage and other dangerous conditions. Request a qualified service person to perform
servicing.
■Repair—If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a.When the power cord or plug is damaged.
b.When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d.When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper
adjustment of controls not described in the instructions can cause damage, which often requires
extensive adjustment work by a qualified technician.
e.When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product
indicates that the product needs servicing.
■Replacement parts—In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same characteris-
tics and performance as the original parts. Use of unauthorized parts can result in fire, electric
shock and/or other danger.
■Safety checks—Upon completion of service or repair work, request the service technician to
perform safety checks to ensure that the product is in proper operating condition.
■Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.

3
■Cleaning—Unplug the power cord from the AC outlet before
cleaning the product. Use a damp cloth to clean the product. Do
not use liquid cleaners or aerosol cleaners.
■Water and moisture—Do not use the product near water, such as
bathtub, washbasin, kitchen sink and laundry tub, swimming pool
and in a wet basement.
■Stand—Do not place the product on an unstable cart, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal injuries as
well as damage to the product. Use only a cart, stand, tripod,
bracket or table recommended by the manufacturer or sold with
the product. When mounting the product on a wall, be sure to
follow the manufacturer’s instructions. Use only the mounting
hardware recommended by the manufacturer.
■When relocating the product placed on a cart, it must be moved
with utmost care. Sudden stops, excessive force and uneven
floor surface can cause the product to fall from the cart.
■Ventilation—The vents and other openings in the cabinet are
designed for ventilation. Do not cover or block these vents and
openings since insufficient ventilation can cause overheating and/
or shorten the life of the product. Do not place the product on a
bed, sofa, rug or other similar surface, since they can block
ventilation openings. This product is not designed for built-in
installation; do not place the product in an enclosed place such
as a bookcase or rack, unless proper ventilation is provided or
the manufacturer’s instructions are followed.
■The LCD panel used in this product is made of glass. Therefore,
it can break when the product is dropped or applied with impact.
Be careful not to be injured by broken glass pieces in case the
LCD panel breaks.
■Heat sources—Keep the product away from heat sources such
as radiators, heaters, stoves and other heat-generating products
(including amplifiers).
■The LCD panel is a very high technology product with 921,600 thin film transistors, giving you fine
picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or
red.
Please note that this does not affect the performance of your product.
SAFETY PRECAUTIONS (Continued)

4
ENGLISH
LCD COLOUR TELEVISION
OPERATION MANUAL
Printed in Japan
TINS-A011WJZZ
02P04-JKM
Printed on post-consumer recycled paper
LC-15B2MA
LC-20B2MA
MENU
Make sure the following accessories are provided with the product.
SUPPLIED ACCESSORIES
Operation Manual (×1)
Wireless Remote Control (×1)
“AAA”size (UM/SUM-4) dry battery (×2)
AC Cord
*Product shape varies in some countries.
Cable clamp (×2)
AC Adapter (×1)
Antenna Cable (×1)

5
PREPARATION
Batteries for Remote Control
If the remote control fails to operate LCD colour TV functions, replace the batteries in the remote
control.
–Caution!
Cautions regarding batteries
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the
instructions below.
•Place batteries with their terminals corresponding to the (+) and (–) indications.
•Different types of batteries have different characteristics. Do not mix batteries of different types.
•Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new
batteries and/or cause old batteries to leak chemicals.
•Remove batteries as soon as they are non-operable.
Chemicals that leak from batteries can cause a rash. If chemical leakage is found, wipe with a
cloth.
•The batteries supplied with the product may have a shorter life expectancy due to storage conditions.
•If the remote control is not used for an extended period of time, remove batteries from the remote
control.
Preparing and Using the Remote Control
■Use the remote control by pointing it towards the remote sensor window.
Objects between the remote control and sensor window may prevent proper
operation.
Cautions regarding use of remote control
■Do not expose the remote control to shock.
In addition, do not expose the remote control to liquids, and do not place in
an area with high humidity.
■Do not install or place the remote control under direct sunlight.
The heat may cause deformation of the unit.
■The remote control may not work properly if the remote sensor window of the
main unit is under direct sunlight or strong lighting. In such case, change the
angle of the lighting or LCD TV set, or operate the remote control closer to
the remote sensor window.
1Open the battery
cover.
2Insert batteries [two
“AAA”size (UM/SUM-4)
batteries, supplied with
product].
3Close the battery
cover.
■Slide the cover while
pressing the ([) part.
■Place batteries with their
terminals corresponding to
the (+) and (–) indications
in the battery compartment.

6
Power Connection
Antenna Connection
Note:
•Always turn the main power switch of the LCD TV set to OFF when connecting the AC adapter.
•Always unplug the AC adapter from the product and power outlet when not using for long periods of time.
PREPARATION (Continued)
•Using the supplied antenna cable, connect the room
antenna terminal to the antenna input terminal on the
TV set. (Refer to the figure below.)
To antenna input terminal
Room antenna terminal
(75-ohm type)
Antenna cable (supplied)
Plug into AC
outlet.
AC cord*
AC adapter
Household
power outlet
To DC input
terminal
Connect to the DC input
terminal of the product. Pull down the hook
to open the cover.
Pull down the hook
to open the cover.
* Product shape varies in some countries.
VOLCHMENUTV/VIDEOMAIN POWER
ANT.
VIDEO
S-VIDEO
AUDIO
L
R
HEAD
PHONE
POWER
INPUT
DC13V
AV-IN1
VIDEO
AUDIO
L
Y
P
B
P
R
R
AUDIO
L
R
COMPONENT
AV-IN2/OUT
VOLCHMENUTV/VIDEOMAINPOWER
ANT.
VIDEO
S-VIDEO
AUDIO
L
R
HEAD
PHONE
POWER
INPUT
DC13V
AV-IN1
VIDEO
AUDIO
L
Y
P
B
P
R
R
AUDIO
L
R
COMPONENT
AV-IN2/OUT

7
LOCATION OF USERS CONTROL
SLEEP indicator
The SLEEP indicator lights up red when
the SLEEP TIMER is set to on.
Remote sensor window
(The actual location is not visible.)
To change the vertical
angle of the LCD TV set,
tilt the screen up to 5
degrees forward or 10
degrees backward. The
TV set can also be
rotated 50 degrees
horizontally. Please adjust
the angle so that the TV
set can be watched most
comfortably.
Power/Standby indicator
A green indicator lights when the power is on
and a red indicator lights when in the standby
mode (the indicator will not light when the main
power is off).
POWERSLEEP
Upper control panel
Speaker
Speaker
PRESET 1
2
PRESET 1
2
CHVOL
MENU TV/VIDEO MAIN POWER
CHVOL
MENU TV/VIDEO MAIN POWER
LC-20B2MA
MENU MAIN POWER
TV/VIDEO
LC-15B2MA
CH( )/( )VOL ( - )/(+)
Note:
•TV/VIDEO, CH ( )/( ), and VOL (–)/(+) on the main unit have the same functions as the same buttons on the
remote control. Fundamentally, this operation manual provides a description based on operation with the remote
control.
Main unit (front view)
* The examples used throughout this manual are based on the LC-20B2MA
model. There may be a slight difference in the illustrations, if you are
using the LC-15B2MA model.

8
LOCATION OF USERS CONTROL (Continued)
ANT.
VIDEO
S-VIDEO
AUDIO
L
R
HEAD
PHONE
POWER
INPUT
DC13V
AV-IN1
VIDEO
AV-IN 1 AUDIO (L)
AUDIO (R)
S-VIDEO
HEADPHONE
Antenna terminal
POWER INPUT
DC 12V (LC-15B2MA)/
DC 13V (LC-20B2MA)
VIDEO
AUDIO
L
Y
P
B
P
R
R
AUDIO
L
R
COMPONENT
AV-IN2/OUT
VOLCHMENUTV/VIDEOMAINPOWER
ANT.
VIDEO
S-VIDEO
AUDIO
L
R
HEAD
PHONE
POWER
INPUT
DC13V
AV-IN1
VIDEO
AUDIO
L
Y
P
B
P
R
R
AUDIO
L
R
COMPONENT
AV-IN2/OUT
VIDEO
AV-IN 2/OUT
COMPONENT
AUDIO (L)
AUDIO (R)
Y
PB
PR
AUDIO (L)
AUDIO (R)
Carrying handle
Main unit (rear view)

9
CH
VOL
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX -/--
MENUSLEEP
MENU cursor
(Right/Left Selection)
VOL (+)/(–)
POWER
TV/VIDEO
MENU cursor
(Upward/Downward Selection)
CHANNEL SELECT
CH ( )/( )
Selects next higher channel.
Selects next lower channel.
FLASHBACK
Returns to previous channel.
DISPLAY
Press....Displays receiving channel for 10 seconds.
Channel indication reduces in size after
about 10 seconds.
Press again...Removes display.
Press....Stops sound.
Press again...Returns
sound to previous level.
MPX
Switches Audio mode.
BRIGHT
The brightness can be
switched between 3 levels.
MUTE
LOCATION OF USERS CONTROL (Continued)
Remote control

10
BASIC OPERATION
Control section of main unit
1Press MAIN POWER, located on
the upper part of the main unit to
ON.
2The POWER/STANDBY indicator
instantaneously changes from red
to green and the main unit is turned
on.
▼ On-Screen Display
Turning on POWER
Switching TV/VIDEO AV1/AV2/COMPONENT/TV Mode
Note:
•Input mode indication disappears after
several seconds.
AV1 mode
AV2 mode
1Turn on the power of the con-
nected video equipment.
2Press TV/VIDEO and select the
applicable input source. The screen
displays AV1, AV2, COMPONENT
or TV mode at the upper right
corner each time TV/VIDEO is
pressed.
•AV input mode indication remains for
five seconds.
• AV1: Video equipment connected to the
AV1 input terminals.
An S-video input terminal is
additionally provided for the AV1
input. If both S-video terminal and
normal video terminals are
connected with cables, the S-
video input terminal is selected as
the high priority.
• AV2: AV2 mode is used to adjust the
preset settings and IN or OUT can
be selected. AV2 indication is not
displayed when OUT is selected.
(For details on setting AV-OUT,
see page 21.)
• COMPONENT:
Video equipment connected to the
COMPONENT input terminals.
Note:
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
POWER
TV/VIDEO
CH
VOL
B/G
B/G
COMPONENT mode
COMPONENT
TV mode
B/G
B/G
Power/Standby indicator
MAIN POWER

11
Sound Volume
ON/OFF Standby
To mute sound
BASIC OPERATION (Continued)
1Press VOL (+) to increase sound
volume. The segment of indicator
increases.
2Press VOL (–) to decrease sound
volume. The segment of indicator
decreases.
1Press MUTE to temporarily turn off
the sound.
Screen displays the MUTE mark.
2Press MUTE or VOL (+)/(–) to turn
the sound back to the previous level.
MUTE is automatically cleared when
the following buttons are pressed:
POWER, VOL (+)/(–), MUTE.
To turn off the LCD TV
Press POWER on the remote control.
The Power/Standby indicator will turn
red. (Standby position)
To turn the LCD TV back on
Press POWER again.
The Power/Standby indicator will turn
green.
CH
VOL
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
MUTE
POWER
VOL(+)/(–)
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
POWER
CH
VOL

12
1Press the button.
2If “5-”is indicated and the picture
does not change, press the
-/--
button to switch over to the 1-digit
select mode and press again.
BASIC OPERATION (Continued)
Changing the Channels
Changing channels using CHANNEL SELECT on the remote control.
To select a one-digit channel
(e.g., Channel 5):
•To handle the increasing number of channels available, this LCD TV set allows you to select up to
100 positions (Channels 0 to 99). One-digit and two-digit methods of selection can be used. Follow
the procedure shown below to select channels.
1Press the
-/--
button to set the
2-digit select mode.
2Press the button.
3Press the button.
Note:
•Complete this procedure within 4 seconds,
otherwise the selection will not be made.
To select a two-digit channel
(e.g., Channel 15):
Changing channels with CH ( )/( ) on the remote control.
Press CH ( )and the channels change in the order shown below:
1 →2 →3 →. . . →98 →99 → 0 → 1 →2 →3 →. . .
Press CH ()and the channels change in the order shown below:
3 →2 →1 →0 → 99 →98 →. . . →3 →2 →1 →. . .
CH
VOL
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
CHANNEL
SELECT
CH ( )/
( )
B/G
B/G

13
MENU
MENU
SLEEP TIMER
FEATURE
CH-SETTING
SELECT: ENTER: EXIT:
SELECTING THE MENU ITEMS
•This LCD TV set allows you to adjust the picture and sound, and set the channels and other features
using the On-Screen Display. Select the desired menu item by following the steps below and then refer
to the indicated page for details.
SLEEP TIMER
menu ----------------- Page 17
PICTURE menu
(TV mode) ---------- Page 18
FEATURE menu --- Page 20
CH-SETTING
menu ---------------- Page 16
1Press MENU to display the MENU
screen.
2Press ]/[to select the desired
menu item.
• The “ ” mark moves up or down.
• The “ ” mark indicates the selected
menu item.
3Press </>to enter.
•The TINT display only appears when
the COLOUR SYSTEM sets N358 or
N443 in the NTSC mode.
•The displayed items differ depending
on the setting conditions.
•The selected item changes to yellow.
•Items in purple cannot be selected.
(AV mode) --------- Page 18
Selecting a Menu Item
Note:
* The screen indications shown above are larger than actual for easy reading.
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
MENU
]/[
</>
CH
VOL
MENU
SELECT: ADJUST: EXIT:
CH-SETTING
RETURN
POSITION [CH15 ]
COLOUR SYSTEM [AUTO ]
SOUND SYSTEM [B/G ]
SKIP [OFF ]
FINE [7 3.25MHz]
NICAM [ON ]
IGR [ON ]
SLEEP TIMER
RETURN
SLEEP TIMER [---REMAIN]
MENU
SELECT: ADJUST: EXIT:
PICTURE (TV)
RETURN
CONTRAST [ 30]
COLOUR [ 0]
BLACK LEVEL [ 0]
SHARPNESS [ 0]
RED-BLUE [ 0]
GREEN [ 0]
RESET
MENU
SELECT: ENTER: EXIT:
PICTURE (AV1/AV2/COMPONENT)
RETURN
CONTRAST [ 30]
COLOUR SYSTEM [AUTO]
COLOUR [ 0]
BLACK LEVEL [ 0]
SHARPNESS [ 0]
RED-BLUE [ 0]
GREEN [ 0]
RESET
MENU
SELECT: ENTER: EXIT:
TINT [ 0]
FEATURE
RETURN
BRIGHTNESS [BRIGHT ]
AUTO POWER OFF [OFF ]
UPSIDE [NORMAL ]
RIGHT/LEFT [NORMAL ]
BLUE BACK [ON ]
AV2 IN/OUT [IN ]
LANGUAGE [ENGLISH]
MENU
SELECT: ADJUST: EXIT:

14
On-Screen Display Language Selection
Note:
• When starting PRESET after setting the
SOUND SYSTEM with MENU of the
Remote Control, the SOUND SYSTEM
for all channels are stored into memory.
• Unused channels are automatically
skipped.
• The Preset mode is only available in the
TV mode and cannot be operated in the
AV mode.
PRESET
Sound System
NORMAL
SCREEN
Presetting the Channels (AUTO)
■MENU on the LCD TV set can also
be used to select the language.
■Automatically tunes in and presets
receivable TV stations.
Make sure the antenna cable is
properly connected.
(Auto mode screen)
Upper control panel
1Press MENU on the upper part of
the LCD TV set for more than two
seconds to display the PRESET
mode screen.
2Press MENU twice to display the
LANGUAGE select mode screen.
Press MENU again to change the
PRESET mode as shown below.
AUTO →MANUAL →LANGUAGE →
3Press CH ()/( )to select the
language you wish to display.
4Press MENU to return to the
normal screen.
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
MENU
CH
VOL
Note:
• Instead of pressing MENU for more than
two seconds, you can display the
LANGUAGE select mode by selecting
FEATURE → LANGUAGE on the
Menu screen.
12
VOL CH MENU TV/VIDEO
12
PRESET
1Press MENU (PRESET-1) on the
upper part of the LCD TV set for
more than two seconds. The
AUTO mode screen appears.
2Press VOL (–)/(+) (PRESET-2)
on the upper part of the LCD TV
set.
All the TV stations in your area
that can be received by the LCD
TV set are automatically preset.
3The screen shows whatever is on
channel 1 when full auto channel
preset is finished.
VOL CH MENU TV/VIDEO
12
PRESET
1,2,43
LANGUAGE
ENGLISH
MENU
SELECT: EXIT:
* In this example, the LC-20B2MA
model is used. Refer to page 8
if you are using the LC-15B2MA
model.
Upper control panel

15
1Press MENU (PRESET-1) on the
upper part of the LCD TV set for
more than two seconds. The
AUTO mode screen appears.
2Press MENU (PRESET-1) to
display the MANUAL mode screen.
Press MENU (PRESET-1) again
to change the MANUAL mode as
shown below.
3Select the channel position using
CHANNEL SELECT or
CH ( )/( ).
4Press VOL (+)/(–) to locate the
channel you want to preset to the
position. Search is initiated and
when a TV signal is received
during the search, the search
stops.
5Repeat steps 3and 4above, to
preset the channel positions for
other broadcasts, etc.
6Press MENU (PRESET-1) to
return to the normal screen.
Note:
• SYSTEM may not have been set correctly,
if noise can be heard or if there is no
sound.
In such case, reset to SOUND SYSTEM
using MENU.
■In a weak reception area, or under
bad reception conditions.
1Press MENU (PRESET-1) on the
upper part of the LCD TV set for
more than two seconds. The
AUTO mode screen appears.
2Press MENU (PRESET-1) to
display the MANUAL mode screen.
3While the MANUAL mode screen
is displayed, press MENU for more
than 2 seconds.
The channel position number
remains in green.
Note:
•While the MANUAL mode screen is
displayed, press MENU.
(The LANGUAGE mode screen will
appear.)
4Adjust for good reception using
VOL (+)/(–).
5After finishing the adjustment,
press MENU (PRESET-1) to
continue channel presetting.
PRESET (Continued)
AUTO →MANUAL →LANGUAGE →NORMAL
SCREEN
■Setting a channel to a desired TV
station:
Presetting the Channels (MANUAL)
Upper control panel
CH
VOL
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
MENU
VOL(+)/(–)
CH ( )/( )
CHANNEL
SELECT
1,2,63
VOL CH MENU TV/VIDEO
12
PRESET
4
1,2,3,5
VOL CH MENU TV/VIDEO
12
PRESET
4
Sound System
Channel position
number
Auto mode screen
Manual mode screen
➡➡
LANGUAGE
ENGLISH
MENU
SELECT: EXIT:
Upper control panel

16
PRESET (Continued)
Channel Setting
1Press MENU to display the MENU
screen.
2Press ]/[to move the cursor to
CH-SETTING.
3Press </>to display
CH-SETTING screen.
4Press ]/[to select the desired
function mode.
5Each time you press </>, the
setting for individual items is as
mentioned under Selected item:
6Press MENU to return to the
normal screen.
Note:
•Switching COLOUR SYSTEM
Set the system to AUTO for normal TV reception. The AUTO mode automatically detects the receiving signal
system and changes the reception system of the LCD TV set. When the picture or sound is not stable, switching to
an appropriate system may improve the picture or sound quality.
•When using FINE tuning, the channel number changes from green to yellow.
•To return the channel to its original frequency setting, follow the manual channel preset procedure. (Please see
page 15 “Presetting the Channels (MANUAL)” for details.)
•In AV mode, items in purple cannot be selected.
I D/K M B/G
(MENU screen)
(CH-SETTING screen)
•POSITION:
The channel position changes to the upper or lower number.
•COLOUR SYSTEM:
The mode changes in the following order:
•SOUND SYSTEM:
The mode changes in the following order:
•SKIP:
The mode changes in the following order:
ON ←→ OFF
Channel numbers with a “| (RED)” mark on the left are set to SKIP.
To turn off SKIP, press CHANNEL SELECT to select the desired channel, and then set
the SKIP mode on the CH-SETTING menu to “OFF”.
•FINE:
The frequency changes to allow fine tuning.
•NICAM:
The broadcast sound system changes in the following order:
ON (NICAM sound) ←→ OFF (Monaural TV sound)
•IGR:
German Stereo system changes in the following order:
ON (IGR sound) ←→ OFF (Monaural TV sound)
Selected item
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
CHANNEL
SELECT
CH
VOL
MENU
]/[
</>
MENU
MENU
SLEEP TIMER
FEATURE
CH-SETTING
SELECT: ENTER: EXIT:
AUTO N358
N443
PAL SECAM
PAL-N PAL-M
MENU
SELECT: ADJUST: EXIT:
CH-SETTING
RETURN
POSITION [CH15 ]
COLOUR SYSTEM [AUTO ]
SOUND SYSTEM [B/G ]
SKIP [OFF ]
FINE [7 3.25MHz]
NICAM [ON ]
IGR [ON ]

17
ADJUSTMENT
Adjusting the SLEEP TIMER Setting
To use Direct Key function
1Press SLEEP to display the
SLEEP TIMER screen.
2Press SLEEP to set the sleep
timer (in minutes).
• Each time you press SLEEP, the
timer changes as follows:
--- 30 60 90 120
The setting is turned off when --- is
displayed.
3Press MENU to return to the main
screen.
To use MENU item
1Press MENU to display the MENU
screen.
2Press ]/[to move the cursor to
SLEEP TIMER.
3Press </>to display the SLEEP
TIMER screen.
4Press </>to set the sleep timer
(in minutes).
The setting can be set in
increment of 30 minutes and in the
range between 30 and 120
minutes.
The setting is turned off when --- is
displayed.
5Press MENU to return to the main
screen.
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
CH
VOL
MENU
]/[
</>
SLEEP
60 REMAIN
MENU
MENU
SLEEP TIMER
FEATURE
CH-SETTING
SELECT: ENTER: EXIT:
MENU
MENU
SLEEP TIMER
FEATURE
CH-SETTING
SELECT: ENTER: EXIT:
SLEEP TIMER
RETURN
SLEEP TIMER [120REMAIN]
MENU
SELECT: ADJUST: EXIT:

18
ADJUSTMENT (Continued)
Adjusting the PICTURE Settings
1Press MENU to display the MENU
screen.
2Press ]/[to move the cursor to
PICTURE.
3Press </>to display the
PICTURE menu screen.
4Press ]/[to move the cursor
and select the desired adjustment
item.
All of adjustment items are shown
in the diagram on page 19.
5Press </>to display the screen
for the selected adjustment item.
6Press </>to make adjustment.
To adjust another item, move the
cursor by pressing ]/[while the
MENU screen is displayed.
7Press MENU to return to the main
screen.
CH
VOL
TV/VIDEO
DISPLAY
BRIGHTSLEEP
MENU
POWER
MPX
-/--
MENU
]/[
</>
RETURN
COLOUR
-+
0
MENU
SELECT: ADJUST: EXIT:
MENU
MENU
SLEEP TIMER
FEATURE
CH-SETTING
SELECT: ENTER: EXIT:
MENU
MENU
SLEEP TIMER
FEATURE
CH-SETTING
SELECT: ENTER: EXIT:
PICTURE (TV
RETURN
CONTRAST [ 30]
COLOUR [ 0]
BLACK LEVEL [ 0]
SHARPNESS [ 0]
RED-BLUE [ 0]
GREEN [ 0]
RESET
MENU
SELECT: ENTER: EXIT:
PICTURE (TV
RETURN
CONTRAST [ 30]
COLOUR [ 0]
BLACK LEVEL [ 0]
SHARPNESS [ 0]
RED-BLUE [ 0]
GREEN [ 0]
RESET
MENU
SELECT: ENTER: EXIT:

19
Selected item Press <. Press >.
CONTRAST Decrease contrast Increase contrast
TINT Toward purple Toward green
COLOUR Lower colour intensity Higher colour intensity
BLACK LEVEL Less bright More bright
SHARPNESS Soft picture Hard picture
RED-BLUE More red level More blue level
GREEN Less green level More green level
COLOUR SYSTEM Press >to select COLOUR SYSTEM.
(AV1/AV2) → AUTO → PAL → SECAM → N358 → N443 → PAL-M→ PAL-N → PAL60 
(COMPONENT) → AUTO → PAL → NTSC 
Note:
•TINT is displayed only when N358 or N443 is selected.
•COLOUR SYSTEM is displayed only in the AV mode.
Switching the COLOUR SYSTEM
Set the system to AUTO for normal reception. The AUTO mode automatically detects the receiving
signal system and changes the reception system of the set.
When the picture or sound is not stable, switching to an appropriate system may improve the picture
or sound quality.
ADJUSTMENT (Continued)
