Sharper Image AIRBAR AXIS 16 User manual

MODEL
AXIS 16
16” AIRBAR™
TOWER FAN
OWNER’S GUIDE

3
English
Important Safety Instructions.....................................................................................................................................4
Assembly.......................................................................................................................................................................................8
How to Use.................................................................................................................................................................................10
Cleaning & Storage...........................................................................................................................................................11
Troubleshooting ..................................................................................................................................................................12
Warranty.....................................................................................................................................................................................13
CONTENTS

4English
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered part of the
product. They contain important information about safety, use and disposal.
Before using the product, please familiarize yourself with all operating and
safety instructions. Please keep all documents for future reference and pass
these documents on, together with the product, to any future owner. See
sihomecomfort.com to view, download and print the most current version of
these instructions.
INTENDED USE: This product is intended to circulate the air in indoor living
spaces only in the United States and Canada. This product is not intended for
commercial or industrial use. The manufacturer assumes no responsibility
for damage or injury due to unauthorized use or product modification.
Failure to follow these directions will void the product warranty.
WARNING: Risk to Children and Impaired Persons
- Supervision is required during the installation, operation, cleaning and
maintenance of this product by children age 12 years and younger and
anyone with reduced physical, sensory or mental capabilities. Children
should be supervised to ensure that they do not play with the appliance, its
parts and packaging material.
INSTALLATION WARNING—To reduce risk of fire, electrical shock and injury to
persons, observe the following:
- Place this product away from curtains, draperies, tablecloths and other
fabrics, since they may be drawn into the fan, damage the motor and/or
cause a fire.
- No part of this product (the appliance, power cord, plug, packaging,
etc.) should be placed near furnaces, fireplaces, stoves or other high

5
English
temperature heat sources. Do not use this product in a window, on an
uneven or unstable surface, or near water.
- The appliance, power supply, power cord and plug cannot come into
contact with water. Do not use this product on wet surfaces. Do not use this
product in a bathtub or shower or position product where it may fall into a
bathtub, laundry, swimming pool or other water container. Do not use this
product outdoors or expose it weather or elements.
- Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from traffic area and where it will not
be tripped over. The cord should not hang over edges of counters or
be placed where it can be crimped or closed in doors. Place appliance
near an easily accessible outlet so the product can be unplugged quickly
during an emergency.
SAFE USE WARNING—To reduce risk of fire, electrical shock and injury to
persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, fire and electric shock,
do not operate with a solid state speed device, such as a dimmer control
switch.
- Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair. Do
not operate unit if it has been dropped or if damage is apparent to any
part of the unit. To avoid risk of electrical shock, do not attempt to repair
or replace parts. Only original replacement parts may be used. Contact
(833.800.8669) or ([e-mail]) for further instructions
about replacement and repair.
- Never use the cord as a handle or otherwise yank, strain or stretch the
power cord.
- Do not sit or stand on product.
- While the product is plugged in, do not insert or allow foreign objects to
enter any input or output opening as this may cause risk of electric shock

6English
or fire, or damage the product.
- A loose fit between wall outlet (receptacle) and plug may cause
overheating and distortion of the plug. Discontinue use of the product in
this outlet. Contact a qualified electrician to replace loose or worn outlets.
- Before moving, repositioning, servicing, cleaning and when not in use, use
the product controls to turn off the power and then unplug. Also, power off
and unplug if the product will be left unattended for an extended period of
time or during electrical storms.
SERVICING WARNING—To reduce risk of fire, electrical shock and injury to
persons, observe the following:
- Clean your product regularly, only as is instructed in this manual. Prior
to cleaning, turn off the power on your product and unplug. Do not use
gasoline, thinners, solvents, ammonias or other chemicals for cleaning.
Refer to the CLEANING instructions provided.
- Do not open appliance housing while product is plugged in. To avoid
risk of shock, all service and/or repairs must be done by an Authorized
Service Center.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: this device may not cause harmful
interference, and this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or

7
English
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Contact Customer Service or dealer or an experienced radio/TV
technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Supplier’s FCC Declaration of Conformity
Unique Identifier: Sharper Image Model AXIS 16
Responsible Party: Vornado Air LLC
Mailing Address: 415 E. 13th St., Andover, KS 67002
Contact: www.sihomecomfort.com
SAVE THESE INSTRUCTIONS

8English
The AXIS 16 can be used in one of two orientations: horizontal or vertical.
ASSEMBLY No tools required.
For HORIZONTAL orientation:
Position product on metal base as shown below.

9
English
For VERTICAL orientation:
Install the base provided as
shown below.

10 English
POWER ON / OFF
1. Touch ( ) to power unit on and off.
2. There are three speeds: HIGH, MEDIUM, LOW.
3. Touch ( ) to lower speed. Touch ( ) to increase speed.
TASK LIGHT ON / OFF
1. Touch ( ) to turn task light on and off.
2. There are two settings: HIGH & LOW.
HOW TO USE

11
English
1. Power off and unplug the unit prior to cleaning.
2. Dust or wipe the fan with a damp cloth.
3. Use the brush attachment on your household vacuum cleaner to vacuum any
accumulated dust.
Your fan will need regular cleaning. The fan has no user serviceable parts inside
and cannot be opened for cleaning. Never clean the product in any manner
other than instructed in this owner's guide.
CLEANING & STORAGE
During the off-season or after extended periods of non-use, you may choose to
store your fan. To ensure long life of the product, it is recommended to store your
fan by following these instructions:
1. Unplug power cord and bundle loosely.
2. Cover, or place back in retail carton if available. This prevents fan from
accumulating dust over time.
3. Store fan in cool and dry location.
Note: The motor is permanently
lubricated and requires no oiling.

12 English
POSSIBLE CAUSE AND SOLUTIONPROBLEM
TROUBLESHOOTING
The unit fails to
power on.
Unit is not plugged in. Plug power adapter into electrical outlet.
Ensure unit fan speed setting is selected.
Unit is damaged or in need of repair. Cease usage and unplug.
Contact Consumer Service for assistance.
The outlet is worn or damaged. Try another outlet or contact a
qualified electrician.
Airflow is weak
or slow.
Ensure unit is set to highest setting for maximum air circulation.
Airflow is blocked. Remove obstruction.
Adjust direction of airflow towards the user.
GFCI has tripped. Under certain conditions, it is possible for a reset GFCI (Ground
Fault Circuit Interrupter) outlet to trip when the user is changing
speeds on a fan. In this event, change to an outlet that is not
connected to a GFCI device. It could also indicate a weak or
defective GFCI outlet. Contact a qualified electrician to check
the GFCI outlet.

13
English
Vornado Air, LLC warrants to the original consumer or purchaser this Sharper Image®
Fan (“Product”) is free from defects in material or workmanship for a period of one (1)
year from the date of purchase. If any such defect is discovered within the warranty
period, Vornado, at its discretion, will repair or replace the Product at no cost.
For warranty or repair service: Call 833-800-8669 or email [email protected]
to obtain a Return Authorization (“RA”) form. Please have or include your Product’s
model number and serial number, as well as your name, address, city, state, zip code
and phone number when contacting Vornado for warranty service.
After receiving the RA form, ship your Product to: Vornado Air LLC Attn: Warranty &
Repair 415 East 13th Street Andover, KS 67002. For your convenience, please have your
model number and serial number when contacting Vornado with service inquiries.
To assure proper handling, packages must be clearly marked with the RA number.
Packages not clearly marked with the RA number may be refused at the receiving
dock. Please allow 1-2 weeks for repair and return of your Product after the Product is
received.
Repairs not covered by the warranty or outside the warranty period will require a fee to
cover the cost of materials, labor, handling and shipping.
This warranty does not apply to defects resulting from abuse of the Product,
modification, alteration, mishandling, improper maintenance, commercial use or repair
or service of the Product by anyone other than Vornado; damages which occur in
shipment or are attributed to acts of God. Improper product use, which includes using
an external device that alters or converts the voltage or frequency of electricity, or
WARRANTY
If you’re not satisfied with this product, let us know.
1
YEAR
SATISFACTION
GUARANTEE

14 English
shipping a Vornado product to a country not intended for use will void all warranties.
Any unauthorized product modification, repair by unauthorized repair center, or use
of non-approved replacement parts is not recommended and any consequences
will not be covered by support services or product warranties. The product warranty
will be honored only on models that are being used in the country intended. REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY
OF THE CONSUMER. VORNADO SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, or allow limitations on how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you. This warranty gives you specific legal
rights, and you may have other rights that vary from state to state. The manufacturer
assumes no responsibility for damage caused by failure to follow these instructions or
improper product use. Any such actions will invalidate the product warranty.
All company names and product names are trademarks of their respective owners. ©
All rights reserved. All technical information, data, and instructions for the installation,
connection, and operation contained in these instructions for use correspond to the
latest available information at time of printing. The contents of this manual may differ
slightly from the actual product. Observe any additional supplements.
©2020 Vornado Air LLC, Andover, Kansas 67002 USA.
Specifications subject to change without notice.
Sharper Image® name and logo are registered trademarks.
Manufactured, marketed and distributed under license by Vornado Air LLC, Andover,
Kansas 67002.
Manufactured in China.
U.S. Patents Pending.
Sharper Image® Distributed under license by Vornado Air LLC, Andover, Kansas 67002.

CL30696 R, V00
