Shenzhen Shenke Medical Instrument Technical Development SK-500II User manual

SyringePump
Model SK-500II
Instruction Manual
ShenzhenShenkeMedicalInstrument
Technical DevelopmentCo., Ltd.
Pleasereadthemanualbeforeusing theproduct
Pleasekeepthemanual forreference！
Product RegistrationNo.：Yue FDA（approved）2009 2540641
Implement Standard No.：YZB/Yue 0453-2009
ProductionLicense No.:Yue FDA(approved)20040977 Version：V2.1

Limited Guarantee
1. SK-500II syringepumpisdelicatelymadeoftop-qualitycomponents.
2. ShenzhenShenkeMedicalInstrumentTechnicalDevelopmentCo.,Ltd. guaranteesthatthe
productwill nothaveanydefectinmaterialortechnologywithin12monthsfromthe
purchasing date.
3. Thecompany sliabilityandtheagentsauthorizedbyShenzhenShenkeMedical
InstrumentTechnicalDevelopmentCo.,Ltd.underthislimitedguaranteeshouldbe
restrictiveundertheoperationprivilegeofShenzhenShenkeMedicalInstrumentTechnical
developmentCo.,Ltd.—undertakingthemaintenanceandreplacementofsyringepump
underthecircumstance thatithasdefectinmaterialandtechnologythroughinspection.
Themaintenanceandreplacementofanyproductsbasedonthislimitedguarantee should
notexceedthetimelimitoftheabovelimitedguarantee.
4. Allthemaintenance basedonthelimitedguarantee shouldbeundertakenbyqualifiedand
trainedpeople.Whensyringepumpisfounddefectivewithinthetimelimitofthelimited
guarantee,thepurchasershouldnotifyShenzhenShenkeMedicalInstrumentTechnical
DevelopmentCo.,Ltd.ortheauthorizedagentswithin30daystofindtheproduct s
defects.
5. ThedefectivesyringepumpshouldbesentdirectlytoShenzhenShenkeMedical
InstrumentTechnicalDevelopmentCo.,Ltd.ortheauthorizedagentsforthepurposeof
inspection,repairorreplacementofsyringepump.Thepostageshouldbebornebythe
purchaser.
6. TheproductsmailedbacktoShenzhenShenkeMedicalInstrumentTechnical
DevelopmentCo.,Ltd.oritsagentsshouldbeappropriatelypackedintransportation
packing boxwithinstructionmanualofShenzhenShenkeMedicalInstrumentTechnical
DevelopmentCo., Ltd.Inappropriatepackingwill causeseveredamagetosyringepump
whichshouldbebornebypurchaser.
7. Thelimitedguarantee ofShenzhenShenkeMedicalInstrumentTechnicalDevelopment
Co., Ltd.doesnotapplytoproduct sdamageordefectsresultedfromthefollowing causes:
mechanismdamageandincorrectinstallationcausedcompletelyorpartiallybyneglectof
duty, liquorfeeding, fallingofsyringepump,falseuseandabuse;reconstructionofsyringe
pump byanyunprofessional,disqualifiedoruntrainedpeople;damageduetoincorrect
packing whenthedefectiveunitismailedtoShenzhenShenkeMedicalInstrument
TechnicalDevelopmentCo., Ltd.anditsagents.
8. ShenzhenShenkeMedicalInstrumentTechnicalDevelopmentCo., Ltd.oritsagents
reservetherightstoissuetheproductsinspectioninvoicetopurchasers,providedtheyare
notabletoconfirmthematterafterinspection.
9. Thislimitedguarantee istheonlycompleteguarantee relatedtotheproductsofShenzhen
ShenkeMedicalInstrumentTechnicalDevelopmentCo.Ltd.Itdoesnotincludetheusage
orprocessguarantee ofwhatevernaturalcondition,whereveritisplaced,andinlegal,
commercialoranyotherkindofactivities.Itguaranteesbutbynomeansconfinesits
guarantee totheproduct smechanicalfunctionanditsadaptationtospecialpurposes.
Purchasersshouldclearlyagreethatthecompensationwillbepaidonlyunderthislimited
guarantee andthattheyshouldrespecttheannouncementunderthislimitedguarantee

Contents
1. BasicIntroduction......................................................................................................................2
1.1Productintroduction:.......................................................................................................2
1.2Applicationscope:............................................................................................................2
1.3Safetyprecaution:.............................................................................................................2
1.4Productfunctionsand features........................................................................................3
1.5Technicalparameters.......................................................................................................3
1.6Systemstructures.............................................................................................................4
1.7ExplanationofSymbolsontheLabel..............................................................................5
1.8Panelinstruction...............................................................................................................7
1.9Batterycharge..................................................................................................................8
2. SettingParameters...................................................................................................................10
2.1Settingmenuparameters...............................................................................................10
2.2Settingmodeparameters...............................................................................................12
2.3Settingparametersunder stop’condition....................................................................13
2.4Viewvolumelimitedandtimingoperationinrunningcondition.................................13
2.5View transducer value....................................................................................................14
2.6Otheroperation..............................................................................................................14
3. OperationInstruction..............................................................................................................14
3.1Basicoperationsteps......................................................................................................14
3.2StartBolus......................................................................................................................18
3.3Start/stopnearcompletionalarmfunction..................................................................19
3.4Replace injectorsuppliers..............................................................................................19
3.5Clearinjectorparameter,resetinjectorparameter......................................................21
3.6Adjustocclusionsensitivity............................................................................................22
4. Maintenance andStorage........................................................................................................23
4.1Machinemaintenance....................................................................................................23
4.2TransportandStorage....................................................................................................23
4.3Preventivetesting...........................................................................................................23
4.4Environmentalprotection..............................................................................................24
6. AlarmandSolutions................................................................................................................25
6.1Commonalarmindicationandsolutions.......................................................................25
6.2Commonproblemsand solutions.................................................................................26
6.3Maintenanceservice.......................................................................................................26

2
1.BasicIntroduction
1.1Productintroduction:
SK-500II syringepumpisacombinationofmicroelectronictechnologyandmodernnursing,an
importantoutcomeofmicrocomputerappliedtoclinicalnursing.Itcancontroltheinjectionrateand
totalvolumepreciselyandcontinuouslyoverlong hoursonalargescale,whichcompletelymeets
thevariousrequirementsofmodernclinicaltreatmentondifferentoccasionsandisnowwidelyused
inhospitals.
SK-500II syringepumpisaneconomicalproductofintellectualization,collectivizationandhi-tech
whichcanbeusedinallclinicsorwards,thuspromotingthepreviouslysinglepumpintravenous
syringecontroltomass control.Thepatients injectionsituationandalarminformation(e.g.
injectioncompletion, pipeocclusion)canallbeseenatthenurse sstation. Thisgreatlyimprovesthe
medicalnursingquality,reducesthenurse sworkload,andensuresthepatient snursingsafety.
SK-500II syringepumpisanonportabledevice, whichneedstobefixedforuse.
1.2Applicationscope:
Itisusedinhospitalswherepatientsneedintravenousinjectionatsteadyspeedorcontinuousand
preciseinjection.
1.3Safetyprecaution:
1.Unqualifiedanduntrainedpeoplearenotallowedtooperatethemachine.
2.Precautionsforinstalling themachine.
①Place thepumpindryplace.
②Donotplace thepumpinplaceswhereatmospherepressure,temperature,humidity,sunshine,
dust, salt andionairmaybringdamagetothepump.
③Payattentiontothesafetyofthemachine,avoiding drop,vibrationorbumpthepump
(includingintheprocess oftransportation).
④Donotusethepumpintheplace whichkeepschemicalmedicineorgivesoutpoisonousgas.
⑤Payattentiontothefrequencyofvoltageandallowablecurrentofvoltage.
⑥Makesurethereisnohighfrequencycacophonymaker,medicalequipmentorcellphoneetc.
nearthepump.
3.Precautionsbeforeusingthemachine:
①Makesurethepowercordissafelyandcorrectlyconnected.
②MakesuretheON-OFFfunctionandoperationofthepump isok.
③Makesurethereisnohighfrequencycacophonymaker,medicalequipmentorcellphoneetc.
nearthepump.
④Inspectthepatient sveinpassagehasbeenestablished.
4.Precautionsduringoperation
①Donotexceedthetimeofdiagnosisandcure.
②Tosupervisecontinuouslyifthemachineandpatientsarenormal.
③Whendetectinganything abnormalwiththemachineorpatients,considerthepatient ssafety
first, thenstop injectionandtakeproperaction.
5.Precautionsafterfinishingusingthemachine

3
①Turnoffthepowerandpull outthepowercordasperrequirement.
②Cleanthepumpbeforestoring itforconvenientusenexttime.
6.Warning:using improperinjectormaycauseinjectionpipecrack.
7. Warning:whenusing Nonnationalstandardinjectororsettinginjectorparametersincorrect,the
accuracywon tbemaintainedandthediscrepancymayreach5%orabove.
8.Warning:theusedpipelineshallnotbeinstalledonotherinfusiondevicestoavoidpotential
risk.
9.Warning:Donotusecell phoneorotherhighradiationdevicesawayfromthesyringepump
within0.5m.
10.Warning:Thepumpwon tinspecttheairbubble,makesurethatthereisnoairbubbleinthe
injectorbeforeusing.
11. Warning:Stop using themachinewhenthereisalarm.
12.Warning:Donotusethesyringepumpinplacesofflammability.
1.4Productfunctionsand features
(1) Precisecontrolofinjectionrate.
(2) Precisecontrolofinjectionvolume.
(3) Smoothflow,nopulsant.
(4) Warning informationaboutinjectioncompletion,nearcompletion,occlusion,lowbattery,
injectorabnormal, controlabnormal;
(5) Intellectualizedcontrolofinjection.
1.5Technicalparameters
Producttype SK-500II
Maximum injectionrate 1500ml/h(Differentinjectorshavedifferent
maximumrate.)
Rangeofflowrate 5mlinjector:0.1-100ml/h
10mlinjector:0.1-200ml/h
20mlinjector:0.1-400ml/h
30mlinjector:0.1-600ml/h
50mlinjector:0.1-1500ml/h
Injectionincrement 0.1ml/h
Bolusrate 5mlinjector:100ml/h
10mlinjector:200ml/h
20mlinjector:400ml/h
30mlinjector:400-600ml/h
50mlinjector:400-1500ml/h
Injectionmodeselection 1.Ratemode2.Timemode3.BodyWeight
mode
Ratemode Speed:0.1-1500ml/h(maximumvaluedepends
ontheinjectorspecifications)
TimemodeTime:1~2000minutes
Accumulatedinjectionvolume:0.1-999.9ml
BodyWeightmode Weight:0.1~300.0kg
Drug:0.1~999.9(mg)
Volume:0.1~999.9ml
Dose:0.1 ～9999.9(restrictedtounit,drug,
solution, weightandinjectorspecification).

4
Unit:mg/kg/h, ug/kg/min
KVOrate Adjustablerange:0.1ml/h～5.0ml/h(beginthe
KVOfunctionundertheocclusionsituation);
pressing STOPkeytocanceltheKVOfunction
whenit isunnecessaryinuse.
IPgrade IPX1
InjectionpressureThemaximumpressureis0.3Mpa,Occlusion
alarmpressurevalueis40kPa～160kPawhen
pressurevalueisminimum,injectionrateis
25ml/h,thelongestalarmtimeis10minutes.
Whenpressurevalueisminimum,injectionrate
is5ml/h, thelongestalarmtimeis10 minutes.
Presetvolume 0.1ml-9999.9ml
Presettime 0~99hours, 0~59minutes
Accumulatedinjectionvolume 0.1ml-9999.9ml
Accuracy ±3％
Powersupply AC100～240V，50/60Hz
Battery Rechargeablelithium polymerbattery,7.4V,
1600mAh.
Maximum powerconsumption 25VA,running morethan4hoursattherateof
25ml/hafterbeing fullycharged.
Batterycharge WhensyringepumpisconnectedtoACpower,
thebatterywillautomaticallyrecharge.(about
8～14hourstorechargefully.)
Fuses T2AL250V～
Displayedinformation Flowrate;accumulatedinjectionvolume;
injectorspecification;batterycapacity;bedNo.;
ACpowerindicator, operationindication,etc.
Stateindicationinformation Stop,inject,bolus, KVO(stop flashing, theother
indicatorsflashbyturns.)
Alarminformation nearcompletion,Over,occlusion,lowbattery,
abnormal1(communicationsfailure),abnormal
2(pumpstuck),abnormal3(wrongparameter),
volumelimitedalarm, noACpower
Maximum sizeoftheoutershell 380mm×190mm×180m（length×width×height）
,
Maximum weight＜3.0kg
Classification Class,TypeBF
Shellmaterial ABSplastic
Operatingconditions Environmenttemperature5~40℃℃, airpressure
80kPa~106kPa，relativehumidity ≤80%
StorageconditionsEnvironmenttemperature -40℃~55℃,air
pressure50kPa~106kPa，relativehumidity ≤95%
Applicablesyringes 5ml、10 ml、20 ml、30ml、50 ml syringes
Electricalsafety Inaccordancewiththestipulationof
IEC60601-1
1.6Systemstructures
SK-500II syringepumpcontainsthefollowingcomponents:

5
1. Themicrocomputersystem:the “brain”ofthewholesystem,givingintellectualizedcontroland
managementoverthewholesystemandprocessing thedetectedsignals.Thetwosingle-chip
Micyoco(SCM)systemsareusedformutualbackupcopyandsupervision.WhenoneSCM
goeswrong,theotheronewill giveanimmediatewarningsignalandcutthepowerofthehost
computer, whichwillthenstop completely, thusensuringpatient ssafety.
2. Thepump device:the “heart”ofthewholesystemandthemaindrivingforceoftheinjection.
Drivenbysteppermotor,theleadscrewmovestheinjectionpistonforward.
3. Theinspectiondevice:variouskindsofsensors,suchasdisplacementsensor(detecting liquid
flowrateandflowvolume),pressuresensor(detectingpipeocclusion),etc.Theycangive
corresponding signalswhichwill,afterbeing magnified,besentovertothecomputerforsignaql
processing.Thentheinspectiondevice canoperatecorrespondinglywiththecontrolinstruction
educedfrom theprocessing.
4. Thealarmdevice:afterthesignalgivenbythesensorisprocessedbythemicrocomputer,an
alarmcontrolsignalwillbeeduced,whichwillberespondedbythealarmdevicetoarouse
people sattentionforrighttreatment.Therearemainlytwokindsofalarms:photoelectricalarm
(LBD)andsoundalarm(loudspeakerandbuzzer).
5. Theinputanddisplaydevice:inputpartinchargeofvariousinjectionparameters,suchas
injectionvolumeandinjectionrate.Itdisplaysvariousparametersandthecurrentoperation
progress. LCDdisplayer.
6. Thechargeablebattery:thispartistoprovidethepowerforthepumpwhenthereisnoAC
power.
1.7ExplanationofSymbolsontheLabel
1. Productlabelpattern(pastedontheshellofthepump):

6
2. LabelMarkMark Description
ProductionbatchNo.
SerialNumber
Caution!Consultusermanual
ClassIIequipment
TypeBFappliedpart
IPX1 Protectionagainstverticallyfalling
waterdrops
Itindicatesthattheequipment
shouldbesenttothespecialagencies
according tolocalregulationfor
separatecollectionafteritsuseful
life.
Dateofproduction
Manufacturer
CE mark
～
Alternating current
EuropeanRepresentative
3. Standardconfigurationinthepackagingcase
Syringepumponeset①
ACpowercordonepc②
Introductionmanualonepc③
Poleclamponepc④
Certificateofapprovalonepc⑤
Maintenancecardonepc⑥

7
※Pleasecontactthesalesagentorthemanufactureriftherearecomponentsabovementioned
missingwhenyouopenthepackaging.
1.8Panelinstruction
No. Description Function
1 Batterycapacityindicatorlight FlashingwhenthereisnoACpowerconnection.
2 ACpowerindicatorlight ACindicatorlightisonwhenusing ACpower.
3 Redalarmlight Flashingwhenthereisalarmsignals.
4 Operationindicatorlight Aftertheinjectionbegins,thethreelightsflash alternatelyfromlefttoright.Whentheinjectionis
over,all thethree lightsareoff.
5 SET key Inthe ‘STOP condition,press thekeytoenteror
quitthemodesselectioninterface.
6 POWERkey
Turnonthepump:Pressthiskeyforabout2
seconds.
Turnoffthepump:Press thiskeyforabout3
seconds.
Nightvisionfunction:Pressthiskeyforabout5
secondstoopenorclosethisfunctionafterturning
onthepump.
7 START key Startinjectionaftertheinstallationandparameters
setting.
8 STOP/CLEAR Pressthekeytostopinjectionandsilence thealarm
atthesametime.
9 Knob Knobisusedtoadjusttheparametersandcursor. Presstheknob toclearthealarmfor2minutesand
confirmthevaluenewlyset.
10
Clutchbutton Keeppressingthebuttontomovethepistonfreely.
Whenunfasteningthebutton,theclutchwillgear,
1 234 5 6 7 8 9
151413 12 11 10

8
andcanonlybemovedbytheengine.
11
BOLUSkey
Keeppressing thiskeyduringinjection,the
machinewill injectatthemaximumrate,backto
originalspeedafterreleasing thiskey.Onsettings
menuscreen,press “BOLUS”canlockorunlock
thesyringesparameters.The
Start-updefault isinlockedcondition,andthe
syringesparameterscannotbesetinthecondition.
12
Piston Pushthepistonofthesyringe.
13
CLEARkey
InSTOPcondition,press thekeytoclearthe
accumulatedvolume.Onsettingsmenuscreen,all
thesyringesparameterswill beclearedwhenpress
STOPkeyintheunlockcondition.Thenthe
syringescannotbeacknowledged,andwehaveto
resetthesyringesparameters.
14
Injectorpressurelever Itholdsbackthesyringetoavoidsyringedropping.
QuickHelp Guidelines
SET+CLEAR InSTOPcondition,press thekeytoenterorquit
themainmenu.
SET+STOP InSTOPcondition,press thekeytoenterorquit
thesensorscreen.
15
Cursor Flashingdisplay,withoutthecursordisplay
whenit isrunning.,
1.9Batterycharge
1.Asshownindiagram1,afterthepumpisconnectedtotheACpowerandturnedon,theAC
indicatorlightisonandthebatterybeginstochargeautomatically.Whenthebatteryisfullycharged,
it willstop chargeautomatically.
2.Asshownindiagram2,theACindicatorlightwillbeoffiftheACpowerisdisconnected.And
thebatteryindicatorlightisflashing,whichmeansthesyringepumpisusingthebatterycapacity.
Thesyringepumpwillissueawarningsoundtoalerttheusertochargethebatterywhenthebattery
powershortage.
Itisneed8※～14 hourstochargethebatteryfully afteritspowerisusedup.
TheACindicatorlightisonand the
batterybeginstochargeautomatically
Diagram1
Indicator lightisflashing，means
the batteryis using.
Displaythebatterycapacity
Diagram 2

9
1.10 Machineinstallation
1.Thesyringepumpisusedatthegeneralleveloftheposition
2.Makesurethescrewaimsatthecentralthreadholeoftheundershell,thenrotatethescrewtofix
theanchoragecliponthesyringepump.
3. CheckthestabilityoftheIVstand.
4. RotatetheotherscrewontheanchoragecliptomakesurethesyringefixedontheIVstand.
Setting ofMenuParameters
Rotatetheotherscrew,makesure the
syringefixedontheIVstand
Sk medical
thescrewaimsatthecentral
threadhole,thenrotatethescrew
tofixthe
anchorage
clip

10
2. SettingParameters
2.1 Setting menuparameters
Understopcondition,press “clear+set”keystoentertheMenuParameterssettingscreen. Press
“clear+set”keysagaintogobacktotheoriginalscreen.Asshownindiagram3anddiagram4.
Theparametersneedtobeseton Settingsmenuscreenastable1:
Theparameterselected Suggestedparametervalue.
5mlinjector 37.5(setinunlockstate)(Savesetting
valueaftershutdown)
10mlinjector 55.4(setinunlockstate)(Savesetting
valueaftershutdown)
20mlinjector 61.2(setinunlockstate)(Savesetting
valueaftershutdown)
30mlinjector 68.3(setinunlockstate)(Savesetting
valueaftershutdown)
50mlinjector 75.7(setinunlockstate)(Savesetting
valueaftershutdown)
Basicocclusionvalue 0.1Mpa(Savesettingvalueaftershut
down)
KVOspeed 0.1~5.0,defaultvalue:0.1,SelectOFF
functiontocloseKVO
IDNo.setting Theafterfour-digitoftheMachineSerial
No.(Savesettingvalueaftershutdown)
BedNo. TheNo.ofthebedthemachineplaced.
(Savesettingvalueaftershutdown)
Nearcompletionalarm ON (Savesettingvalueaftershutdown)
English/Chinese Chinese(Savesettingvalueaftershut
down)
Thesettingvaluecanbesavedformorethan6months.※
1. Menu ParametersExplanation:
EntertheMenu
Parameterssettingscreen
Diagram3 Diagram4
Table1

11
.①5~50syringe:Thisparameteristhelengthoftheinjector,unitismm.Specificmeasurement
canbefoundinthebehindoperationalguidelines,[3.4'changesyringesuppliers'second
step].
②.Basicocclusionvalue:0.04～0.16Mpa.Default value0.1.Thisvaluedecidestheocclusion
alarmsensitivityofdifferentsyringes.
.③KVOspeed:theadjustablerangeis0.1~5.0ml/h,thedefault valueis0.1ml/h.Itentersinto
KVO stateinthecourseofocclusionafterrunning.Setthevalueto"OFF"tocloseKVO
function.
.④IDNo.setting:Thevalueistheafterfour-digitofthemachineSerialNo.inordertoidentify
eachsinglemachine.Theadjustablerangeis0~9999.
.⑤BedNo:ThisvalueistheNo. ofthebedinwhichthemachineisplaced.Therangeis0~999.
Whennoalarm,thebedNo. isdisplayedatthefirstlineofthemainscreenandisdisappeared
whenalarming.
.⑥Nearcompletionalarm:Canset ‘turnon or ‘turnoff thefunction.Thereisalarmwhennear
completionwhilethisfunctionisturnedonotherwisethereisnoalarm.
.⑦Languageselection:EnglishorChinesecanbeselected.
2. SettingParametersOperationExplanation
Turntheknobafterenteringintothesettingmenuscreen,differentparameterscanbechooseas
shownindiagram5.Thereisalock-like'icon' intheupperrightofLCDasshowninFigure5,and
it islockedbydefault statusaftereachtimeofturnon.Inthestatewecannotsetthefive
parametersof"5mlsyringes""10mlsyringes""20mlsyringes""30 mlsyringes""50 mlSyringe".
Onsettingsmenuscreen,press “BOLUS”keyinlockconditiontoenterintounlockstate,thenwe
cansetthesyringeparameters.Andwealsocanpress “BOLUS”inunlockstatetoenterintolock
condition.
Changetheparametersvalueofshownindiagram5:Turntheknob toadjustthecursortothe
parametersneededtobeset,andthenpress theknobtolettheparametersanti-marked.Thenturn
theknob againtoadjusttheparametersvalue,atlastpresstheknobtoconfirmthefinalparameters
andsave.Afterall settings, press “Clear”+ “Set”togobacktothestopcondition.
3.Thecourseofverificationbasicocclusionvalueisasfollows:
Thedefaultbenchmarkocclusionvalueis0.1Mpa, and theadjustablerangeis0.04~0.16 Mpa.①
Setbenchmarkocclusionvalueto0.1Mp
②Prepareanew10mlsyringewithweakresistance,amanometerandaconnectingpipe.
Fillthe10mlsyringewithliquidandinstallittothepump.Connectthepump andmanometer③
L
ockstate
Settheparameterof5mlinjector
unlockstate
Diagram5

12
wellwiththeconnecting pipe.
Press ‘start keytobegintheinjection,press④‘SET+STOP toenterthepressurevaluepreview
interface[diagram6].Observethemanometer, whenthevaluereaches0.1 ±0.02Mpa,thesyringe
pumpshouldgiveanalarmforocclusion,andthepressurevalueshows1.8kg.If itisnotalarming
whenthevaluereaches0.1 ±0.02Mpa, thepotentiometervalueneedstobere-adjustedsothatit can
alarmofocclusionwhenthemanometervaluereaches0.1 ±0.02Mpa.
2.2Settingmodeparameters
Underthe “stop”condition,press ‘SET keytoenterthemodeparametersetting interface[diagram
7].Turnthecoderandusethecursortopointtotheparameterneedtobeset,thenpress adjusting
knob,turnthecodertoset, presstheadjustingknobagaintosavetheparameternewlyset.
Theparameterneedtobesetisdifferentduetodifferentselectedmode[diagram2].
Parameter
value Parameterneedtobeset remark
Ratemode speed Mode1onthe
mainmenu
time
Timemode fluidvolume Mode2onthe
mainmenu
weight
drug
fluidvolume
dose
Weightmode
mg/kg/horug/kg/h
Mode3onthe
mainmenu
※Theratedisplayedinlastlineoftheparametersetting interface isthevaluecalculated
automaticallybythesyringepump,cannotbeset).
※Weightmodelspeedconversion:
Afteryouhavechangedthe
injectionnode,youhavetochange
theparameterstoo.
Diagram7
Diagram6

13
mg/kg/hflowrate=dose*weight*fluidvolume ÷drug
ug/kg/minflowrate=60*dose*weight*fluidvolume ÷drug ÷1000
2.3Settingparametersunder stop’condition
Underthe ‘stop condition,turnthecodertodisplaytheparametersthatcanbeadjusted.Turnthe
adjustingknobandusethecursortopointtotheparameterneedtobeset, thenpress adjustingknob,
turnthecodertoset,press theadjusting knob againtosavetheparameternewlyset.
Parameter Explanation Remark
SpeedUnitisdifferentunder
differentmode. Displayinjectiontime undertimemode,willnot
displayspeed.
Preset‘0standsforoff,turnon
thepresetfunctionwhenit
isnot ‘0.
Timing Timing functionisoff
whenbothhourandminute
parametersareclosed.
Bothcannotbesetunder
timemode.Displaythe
firstfinishedpresetvalue
first.Closethefirstpreset
valuewhenit isfinished
andthesecondoneison.
DrugTwo kindsofdrugs:
penicillin,vancomycin.(Savesetting valueafter shutdown)
Bolusrate Thebolusrateof5、10、
20mlsyringesare100、
200、400ml/h，thebolus
rateof30syringeis400～
600ml/handthebolusrate
of50mlsyringeis
400-1500ml/h.
(Savesetting valueafter
shutdown)
Attention:Aftersettingthepresetvolumeseparately, presetsignturnsto ‘P.Aftersettingthetiming
separately,presetsignturnsto ‘T.Aftersettingbothpresetvolumeandtiming,displaythefirst
finishedpresetvaluefirst.Press thestop key,thefirstpresetvalueturnsto ‘0andthesecondpreset
valuebeginstorun.Itdisplays ‘Nwhenbothpresetvolumeandtiming are ‘0(closefunction).
Undertheweightmode,thespeediscalculatedtoratewithsomeparameters, suchaskg,weightetc.
2.4Viewvolumelimitedandtimingoperationinrunningcondition
During injectionprocess,turntheadjusting knob,themarkedplace displayingtheinjectionvolume
Diagram8
Bed number
Underthe stop’condition,turn
thecodertodisplaytheparameters
thatcanbeadjusted
Accumulatesign
Modesign

14
willshowpresetvolume,timing informationandtotalamountofdrug(mg).
2.5View transducer value
Undertheinterfaceofmainmenu(operationorstop condition),modeparametersetting,menu
function,press ‘SET+STOP keystoenterthesensorvalueinterfacetochecklongpotentiometer
value,shortpotentiometervalue,pressuresensorvalueandbatterycapacityvalue.Press
‘SET+STOP keystoturnbacktotheoriginalinterface.
2.6Otheroperation
1. Run:press STOPkeytobegininjectionaftersetting parametersinstopconditionormode
parameterinterface.
2. Bolusfunction:keeppressingtheBOLUSkeyduringinjection,themachinewillinjectatthe
maximum rate,backtooriginalspeedafterreleasing theboluskey.
3. Stop:press theSTOPkeyundermainmenuorsensorvaluetochecktheinterface.
4. Clearaccumulation:clearaccumulationbypressing CLEARkeyinstopcondition.
5. Turnon/offthepump:press thePOWERkeyfortwosecondswhenthepumpisoff toturnon
thesyringepump. Whenthepump ison,keeppressing the ‘power keyfor3-5secondsandthen
releaseafterhearing 3sounds,thenitisoff.
6. Nightvisionoperation:keeppressingPOWERkeyuntilhearing asound,thenightvision
situationchanges.
3. OperationInstruction
3.1Basicoperationsteps
Diagram10
Diagram9
displayspresetvolume,timinginformation
and totalamountofdrug(mg)

15
Step1Power connection
Attention:Insertthepowercordintothepowersupply(50/60HZ, AC100V～240V).
Diagram11ConnectthepowercordasshowninDiagram11
Step2Turnthepoweron
Turnonthepower, thesyringepumpwill displayversioninformationandIDNo.etc.as
showninDiagram12。
Step3Installthesyringe
InstallthesyringeasshowninDiagram3:
(1)PressSTOPkey;
(2)Pressclutchbutton,dragpistontothesuitableplace;
(3)Beforetheinstallation,manuallyexhausttheairinsidethe syringeandthenputthe syringe
ontheinstallationmounting groove;
(4)Pullthepistontotheplace wherethesyringecanbeconnectedandthenloosentheclutch;
(5)Turnthecompressionstrutofthesyringearound90°andthenletgoofit.Whenthe
compressionstrutcompressesthesyringe,theindicatorlightcorresponding withthetypeof
syringewill beon.
Thelightison,itmeansthatthepumpisin
thestateofcharge.
Diagram12 Diagram13
Diagram11

16
Step4Selecttheinjectionmodeand adjustthespeed
(1)Press STOPkeyonce.
(2)Press SETkeytoentermodeparametersettinginterface,selectthecorresponding injection
modeandsetcorresponding parameters.
(3)Donotusethemodeparametersettingbutusethedefaultratemode.Adjustthespeedin
‘STOP interface,turntheknob untilthevaluereachestherequirement(diagram4).
Diagram15
Thecompressionstrutshould clingtothesyringe
TheLCD displaysthespecificationofinjector
Diagram14
right wrong
thesuitableplace
Turnthecompressionstrutofthe
syringearound 90°and thenletgoofit
Syringebutt closetothePistons

17
Step5Clearaccumulation
(1) Makesurethepump isinstop condition
(2) Press"CLEAR"keytoeliminatetheaccumulatedvolume.
Note:accumulationnumbercanbeobservableonlyininjectionconditionandbeeliminated
onlyinstopcondition.
Step6Starttheinjection
(1) Confirmtheinstallationandthenumericalvaluesetting, andmakesurethecorresponding
syringeindicatorlightison.
(2) Press STARTkey,thesyringepumpstartsworking.Therightbelowsideofthescreen
displaysthe ‘injection condition.
Attention: If theaccumulatedinjectionvolumeisnotneeded,press CLEARkeybefore
pressingSTART keytolettheformeraccumulatedvolumereturnto “0”.
Thefastertheindicatorlightflashesthequickeroftheinjectionrate.
Step7Operation
During theoperationprocess, The3operationindicatorlightswillflashalternatelyfromleftto
right.Press SET+STOPkeystoenterthesensorvaluechecking interfacetocheckthelong
potentiometervalue,shortpotentiometervalue,pressuresensorvalueandpowervalue.Press
SET +STOPkeyandreturntotheoriginalinterface.
KeeppressingtheBOLUSkeyduringinjection,themachinewillinjectatthemaximum rate,
backtooriginalspeedafterreleasingthiskey.
Diagram17
Diagram16
Press SETkeytoentermodeparametersetting
interface Adjusttheknob

18
Step8Injectioncompletion
(1) Whentheinjectionisnearcompletion,thealarmindicatorlightflashesandLCDscreen
displays ‘NEAR toremindtheuserthattheinjectionwill completesoon.
Attention: presstheknobtostopalarmbutit soundsagainintwominutes.
(2) Whentheinjectionisfinished,thepumpstopsoperationsandinthemeanwhilethe
indicatorlightflashes. LCDdisplays"COMPLETION"toremindtheuserthattheinjection
isfinished.
Attention: presstheknobtostopalarm. Itwillsoundagainaftertwominutes.
Step9Turnoffthepower
Press "POWER"for3-5secondsandthenreleaseit, themachineispoweroff.
3.2StartBolus
During theinjectionprocess,ifyouneedamomentoffasterinjection,youcanstartbolusfunction
bykeeppressingtheBOLUSkeyasshownindiagram22,thepumpshallbegininjectionatthe
fastestrate.Itwillgobacktotheoriginalrateafterreleasing BOLUSkey.
Diagram20Diagram19
Diagram21
Diagram18
The runningdirection
Running indicator light
Alarmindicator
Press knobtoeliminate
thealarm
LCDdisplaysthe
alarmmessage
