Sherex M5 User manual

Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150
866-4SHEREX ~ www.sherex.com





M5 Ratchet Style
Rivet Nut Hand Tool
Ratchet Style Rivet Nut Hand Installation Tool designed
for small production work and prototyping
Installation Sizes: 6-32 to 3/8-24 (M4 – M10)
M5 (Imperial Tool) Includes: 10-32, 1/4-20, 5/16-18, and 3/8-16 set ups
M5 (Metric Tool) Includes: M5, M6, M8, and M10 set ups
Weight: 2.80 pounds (1.25 kg)
Length: 8.35” (21.2 cm)

Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150
866-4SHEREX ~ www.sherex.com
M5 Ratchet Tool
Dimensions
7.6 in.
(19.3 cm)
*5.6 in.
(*14.2 cm)
13.0 in.
(33.0 cm)
*Does not include
length of mandrel

Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150
866-4SHEREX ~ www.sherex.com
Setting up the M5 Ratchet Tool
1) Remove the nosepiece (1) from the tool.
2) Thread the shorter portion of the mandrel (3) into the silver
threaded portion of the tool, align the flat surfaces.
3) Thread the nosepiece (1) over the mandrel (3) back onto the
tool until it is securely fastened.
4) Snap the anvil (2) onto the front of the nosepiece (1).
Installation Sequence
1) Thread rear assembly (4) so the first line of the stroke indicator
lines (8) is visible.
2) Adjust the nosepiece (1) for the specific rivet nut type so that the
rivet nut receives full thread engagement on the mandrel (3).
3) Thread rivet nut fully onto tool, contacting anvil (2).
4) Insert the rivet nut into the hole of your application while it is
threaded onto the tool.
5) Using the ratchet toggle (5), set tool for clockwise rotation.
6) Grasp the handles (6, 7) & separate them so that they are at a 45
degree angle or less, moving the back handle (6) counterclockwise.
7) Move the back handle (6) clockwise until it is parallel with the front
handle (7).
8) Repeat steps 5 and 6 until rivet nut is fully collapsed.
(Stroke can be determined by the indicator lines (8) which are in mm)
9) Turn the rear assembly (4) counterclockwise & remove the tool
from the application.
1
2
3
4
3
1
2
5
6
7
8

Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150
866-4SHEREX ~ www.sherex.com
Thread Size Sherex Head Set Part #’s
(Includes Anvil & Mandrel)
Sherex Anvil
Part #’s
Sherex Mandrel
Part #’s
6-32 MHS-0632 MA-0632 M-0632
8-32 MHS-0832 MA-0832 M-0832
10-24 MHS-1024 MA-1024 M-1024
10-32 MHS-1032 MA-1032 M-1032
1/4-20 MHS-2520 MA-2520 M-2520
1/4-28 MHS-2528 MA-2528 M-2528
5/16-18 MHS-3118 MA-3118 M-3118
5/16-24 MHS-3124 MA-3124 M-3124
3/8-16 MHS-3716 MA-3716 M-3716
3/8-24 MHS-3724 MA-3724 M-3724
M4 MHS-M4 MA-M4 M-M4
M5 MHS-M5 MA-M5 M-M5
M6 MHS-M6 MA-M6 M-M6
M8 MHS-M8 MA-M8 M-M8
M10 MHS-M10 MA-M10 M-M10
Sherex Fastening Solutions Line of Tooling
HAND TOOLS PNEUMATIC TOOLS HYDRO-PNEUMATIC
TOOLS
Mandrel
Anvil
