Shindaiwa RS41 Instruction Manual

OWNER’S MANUAL
OWNER’S MANUALOWNER’S MANUAL
OWNER’S MANUAL
MODEL
MODELMODEL
MODEL
RS41
RS41RS41
RS41

Key
No.
Description
PART NO. Key
No.
Description
PART NO.
1Hopper Ass’y-includes #2&3 15845 13 Drive & Free Turning Wheel 14939-1
2Rate Cam & Chute Assembly 14455-1 14 Handle Braces (2) 13613-1
3Shutoff Plate 14454-1 15 Handle Tube 14513-1
4Impeller Assembly 15849 16 T-Handle Assembly 13634-2
5Frame Assembly 15837 17 Control Knob Spring 14462
6Legs (2) 13619-1 18 Control Knob & Wire Ass’y. 13640-1
7Axle 15842 19 Wire Retaining Clip 13643-1
8Axle Collar 14634 20 Gear Cover Assembly 13623-1
9Axle Bushings (2) 12696 21 Fastener Package 15880
10 Impeller Shaft Bearing 15833 22 Hopper Cover 15209
11 Axle Gear 13625-1 23 Handle Grip (2) 15264
12 Agitator 15866 24 Hopper Label 16235
1. SPREADER MODEL NUMBER
2. SPREADER NAME
3. PART NUMBER
4. NAME OF PART AS SHOWN
PART OF OUR SERVICE IS
PROVIDING REPLACEMENT
PARTS. Parts may be obtained
through your local distributor.
Be sure to give:
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
18
17
19
20
21
22
P rts List For shind iw Model RS41
P rts List For shind iw Model RS41P rts List For shind iw Model RS41
P rts List For shind iw Model RS41
400 Oakwood Road
Lake Zurich, IL. 60047
847 540-8400 Fax [phone]
www.shindaiwa. com
P / N 99922201052
23
24
