Shop Tuff DB-4400LB User manual

4400-lb Pallet Truck
OWNER’S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
03042011
Item
#
DB
-
4400LB

Page of 6
2
Thank you very much for choosing this product! For future reference, please complete the
owner’s record below:
Model: ___DB-4400LB_______ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This product is designed for certain applications only. The manufacturer cannot be responsible
for issues arising from modification. We strongly recommend this product not be modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the product until you have first contacted us to
determine if it can or should be performed on the product.
For technical questions please call 1-218-943-6296
TECHNICAL SPECIFICATIONS
Item
Description
Capacity 4400 lbs
Fork Dimensions 27in x 48in
Dimensions 62.5in x 45.5in x 27in
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this pallet truck until they
have read this manual and have developed a thorough understanding of how the pallet truck
works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS

Page of 6
3
WORK AREA
•Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause
accidents.
•Keep children and bystanders away while operating the pallet truck. Distractions can cause
you to lose control, so visitors should remain at a safe distance from the work area.
PERSONAL SAFETY
•Stay alert, watch what you are doing and use common sense when using a pallet truck. Do not
use a pallet truck while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating a pallet truck may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
•Use safety apparel and equipment. Use safety goggles or safety glasses with side shields
which comply with current national standards, or when needed, a face shield. Use of a dust
mask is recommended if working in dusty work conditions.Also use non-skid safety shoes,
hardhat, gloves, dust collection systems, and hearing protection when appropriate.
PALLET TRUCK USE AND CARE
•Do not modify the pallet truck in any way. Unauthorized modification may impair the function
and/or safety and could affect the life of the equipment. There are specific applications for which
the pallet truck was designed.
•Always check for damaged or worn out parts before using the pallet truck. Broken parts
will affect the pallet trucks operation. Replace or repair damaged or worn parts immediately.
•Do not exceed the pallet trucks load capacity.
•Distribute the load evenly. Uneven loads may cause the pallet truck to tip, resulting in
personal injury to the operator or others.
•Use the pallet truck on flat and level surfaces capable of supporting the pallet truck and its
maximum load. Pulling or pushing a load on a slanted or uneven surface can result in loss of
control.
•Store idle pallet truck. When pallet truck is not in use, store it in a secure place out of the
reach of children. Inspect it for good working condition prior to storage and before re-use.
B00OQ1Q8RI.

Page of 6
4
ASSEMBLY
1. Please refer to Figure 1, and pull out the pin shaft 23.
Figure 1 Figure 2
2. Insert Handle Tube into Position A. Connect Handle tube and the pump body 31 via the pin
shaft 23.
3. Replace pin shaft #23, and put the spring pin 24 through pin shaft 23 to secure.
4. Please refer to Figure 2. Insert the chain #10 of the Handle Tube through the hole of the
pin shaft 23.
Figure 3 Figure 4
5. Put the screw and nut at the end of chain 10 into the slot of the lever plate. Please refer to
Figure 2 and Figure 4.
6. Refer to Figure 3, move the handle to a horizontal position, pull out pin B and store to be
used for Handle replacement in the future. The pallet truck assembly is complete.
Check before using
1. After the assembly is complete, move the Trigger (# 1, Figure 5, below) into the three
different positions. This assures pallet operates lowering, neutral and raising operations
correctly after assembling.
2. The Screw #54 in Fig. 4 is used for the adjustment of the truck. When the truck body lowers
shortly after rising, turn Screw 54 a little counterclockwise before trying the truck again. In
the case that the truck body is unable to lower, turn Screw 54 a little clockwise and then try
the truck again till the truck is able to lower normally. The Hex nut 53 functions as a lock, so
it needs to be loosened before adjustment is made and locked after modification.
Figure 5

Page of 6
5
OPERATION
WARNING:
1. Lift the Trigger up a little when lowering the truck by controlling the Trigger to make the truck lower
slowly. Never drag the Trigger quickly because rapid descent will damage the truck and cargo!
2. Do not overload higher than rated capacity.
3. The cargo on forks should always be evenly positioned in the middle of two forks.
4. Do not use with loose or unstable cargo.
5. Do not leave cargo on the forks in raised positions long periods of time. This will cause damage.
6. Set the forks at the lowest position when the truck is not in use.
7. Pallet truck in not for carrying people or animals.
8. NEVER stand on the forks while the truck is stationary or moving.
9. Only use on flat and hard ground or surfaces.
10. Bring pallet truck to an authorized repair person only.
MAINTENANCE
•Maintain your pallet truck. It is recommended that the general condition of any pallet truck be
examined before it is used. Keep your pallet truck in good repair by adopting a program of
conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the
problem corrected before further use. Have necessary repairs made by qualified service
personnel.

Page of 6
6
DIAGRAM & PARTS LIST
For replacement parts and technical questions, please call 1-218-943-6296.
WARRANTY
One-year limited warranty
TG
PO BOX 203
Miltona, MN 56354
