ep EPL151 User manual

EPL151
EPL154
EPL185
Electric pallet trcuk Part No.508000003010
V3 09/2020
Operation Manual
WPL201
HPL152

EP EQUIPMENT CO.,LTD. is one of the world’s
leading companies manufacture, design
material handling equipment and provide related
service. With over 100,000 square metres plant
it produces over 100,000 trucks per year, and
provides professional, e󰀨ective and optimized
material handling solutions worldwide, until now
it has developed three major kinds of business:
Material handling equipment: Focus
on electric forklift and warehouse
equipment
OEM parts: Global parts supply
Imow industry,online: One-stop
industrial products supply
Guided by our customer-oriented concept, EP
has developed service centers in more than
30 countries around the world, from which
customers are able to receive timely local
service. Moreover, 95% of warranty parts can be
shipped out within 24 hours after been ordered.
Through our online after-sales service system,
customers can process their warranty claims,
order spare parts and consult the operation
manuals, maintenance materials and spare
parts catalogs.
With business all over the world, EP has
thousands of employees and hundreds
of agents worldwide to provide our global
customers with prompt local service.
Based on the concept of sharing economy ,
EP also o󰀨er rental service for various logistics
equipment. Adhering to the idea “Making the
leasing of logistic equipment more simple”,
EP is devoted to providing customized one-
stop leasing solutions for our customers with
our high quality, reasonable price and prompt
rental service.
EP’s mission&vision is “ Let more people apply
the electrical material handling equipment to
relieve the intensity of labour” and “Let’s grow
together”.
•
•
•
EP EQUIPMENT CO., LTD
Address: No.1 Xiaquan Village,
Lingfeng Street, Anji, Huzhou,
Zhejiang
Tel: + 86-0571-28023920
Website: www.ep-ep.com
Email: [email protected]

Thank you for buying our products.
The manual will show you the way of correctly using the truck as well as relevant preventive
maintenance and safety operation. The truck should be operated only by well-trained professionals
and by no means by non-working personnel. Operators are supposed to read through the manual
before actually operating the truck.
With the continuous upgradation and improvement of our company’s products, you may find a
slight di󰀨erence existing between your carrier and some introductions in the manual.
All the information, specications and illustrations in the manual are e󰀨ective in times of printing
and our company maintains the right to modify the specication (s) or design (s) of our products at
any time without any beforehand notication.
Means that failure to comply can cause risk to life and/or major damage to property.
Please strictly adhere to these safety instructions to avoid personal injury or major damage to
equipment.
Please pay attention to the important safety instructions.
Pay attention to Instruction.
CAUTION
NOTE
WARNING
DANGER
Explanations on the manual
Safety signs and corresponding esplations
Preface
Internet address and QR code of
Parts manual
By entering the address http://www.ep-
care.com in a web browser or by
scanning the QR code, Login after
registration, Select “Parts purchase"
function and input part number or model
name to nd the truck.
Note: After registration, please send email
to info@ ep-care.com to activate your
account
i

NOTE
Intended use
i
The lift truck is designed for transporting and stacking the loads stated in the
nameplate.
In particular we refer to:
• the safety rules of your trade association.
• In accordance with the special provisions for driving on public roads specied by national
specications.
• Other local regulations.
The rules for the intended and approved use of industrial trucks must be followed under all
circumstances by the responsible persons, especially by the operator and service personnel.
The user, and not EP, is responsible for any danger arising from applications not authorised by the
manufacturer.
If you want to use the truck for applications not mentioned in this manual, please rst contact your
authorised dealer.
No changes, particularly no modications and additions, may be made to the truck without the
approval of the manufacturer.
Technical description
• These trucks consists of robust steel chassis and is driving on a traction wheel and 2 load wheels.
Caster wheels provide for good stability even with high loads.
• The truck will be stopped by a regenerative service brake and hold by an automatic
electromagnetic parking brake in it’s parking position.
• The load is lifted by a hydraulic cylinder that activates a lifting shaft that transmits the lifting
movement by a push-rod to the load wheels.
• The control handle is used for smooth steering and control of drive speed, lifting and lowering,
braking and the horn without changing the position of the hand. The long tiller shaft allows
e󰀨ortless steering and a safe distance to the truck. A gas spring returns the control handle always
into a vertical position that activates the brake automatically.
• An emergency reverse switch on the control head protects the operator from being squeezed by
the truck in conned spaces.
• An electronic controller operates all electric functions and guaranties safety.
• A key switch secures the truck from unauthorized use.
• The ergonomic design of the truck guaranties safe and easy operation.
•Thismanualisusedforoperationandmaintenance,thedetailparameters,sizeandspecicatio
nsincontextisonlyforreference,therealparameterswilldependonsaleles.
•Manualpicturesforreferenceonly,therealcarshallprevail,andshallnotaectthemanualuse.
•Manualpicturesonlysignforoneofthemodelsinthisseriesmodels.

In the manual, “equipment user” refers to any natural person or legal person directly using or
appointing or authorizing others to use the carrier. In such special situations as renting or sales,
the “equipment user” represents the interested parties supposed to bear operation obligations
as specied by the contractual terms concluded between equipment owner and corresponding
users. Equipment users must ensure the use of the carrier only for purposes specied and timely
eliminate all the dangers that may threaten the life and health of the users themselves or any other
third party, in addition to which they must also strictly abide by accident prevention provisions,
other safety technology provisions and equipment operation, maintenance and repair guidelines,
and ensure that all the operators seriously read and completely understand the contents of the
operation instruction.
Should any violation of the operation instruction occur, the quality guarantee of our company will be
invalid automatically, and our company will assume none of the responsibilities for losses resulting
from any nonstandard operation of the equipment implemented by any client, equipment user or
any third party without the authorization of the client service department of our company.
Obligations and responsibilities of equipment user
Modication
Unauthorized modication to the truck can result in injury or death.
Can not remove, disable or modify any safeguards or other safety devices.
Exception:Only in the event that the truck manufacturer is no longer in business and there is no
successor in the interest to the business, may the user arrange for a modication or alteration to a
powered industrial truck, provided, however, that the user
a) arranges for the modication or alteration to be designed, tested and
implemented by an engineer(s) expert in industrial trucks and their safety.
b)maintains a permanent record of the design, test(s) and implementation of the modication or
alteration.
c) approves and makes appropriate changes to the capacity plate(s), decals, tags and operation
manual.
d) a󰀩xes a permanent and readily visible label to the truck stating the manner in which the truck
has been modied or altered, together with the date of the modication or alteration and the name
and address of the organization that accomplished those tasks.
Wind forces can a󰀨ect the stability of a truck when lfting, lowering and transporting loads with large
surface areas .
Light loads must be especially secured when they are subjected to wind forces. This will prevent
the load from sliding or falling.
Stop the truck in both cases.
Wind loads

Declaration
EP EQUIPMENT CO., LTD.
Address: No.1 Xiaquan Village, Lingfeng Street, Anji, Huzhou, Zhejiang
We declare that the machine
Industrial truck: according to this operation manual
Type: according to this operation manual
complies with the most recent version of Machinery Directive 2006/42/EC.
Personnel authorised to compile the technical documents:
See EC/EU Declaration of Conformity
EP EQUIPMENT CO., LTD.
EC/EU Declaration of Conformity
The manufacturer declares that this industrial truck complies with the EC Machinery Directive
and the provisions of other applicable EC/EU directives e󰀨ective at the time of sale. This can be
veried by means of the EC/EU Declaration of Conformity and the relevant certication label on the
nameplate.
The industrial truck is supplied with the EC/EU Declaration of Conformity document. This
declaration proves that this truck complies with the requirements of the EC Machinery Directive.
Unauthorised modication or additional installation of equipment to the structure of the industrial
truck may a󰀨ect its safety, and will therefore invalidate the EC/EU Declaration of Conformity.
The EC/EU Declaration of Conformity must be carefully stored and made available to be presented
to the relevant authorities when necessary. If this industrial truck is sold, this declaration document
must be handed over to the new owner.
Legal requirements for marketing

Table of contents Pg.
A Introduction.......................................................................................................................A1
1.1Nameplates and alarming labels .....................................................................................A1
1.2 Utilization safety specication.........................................................................................A4
1.3 Related Safety Instruction and Standard(For CE)..........................................................A6
1.3.1 EN standards...............................................................................................................A6
1.3.2 Conditions for application ............................................................................................A7
1.3.3 Vibration ......................................................................................................................A7
1.4 Transport and commissiong ...........................................................................................A8
1.4.1 Truck transport.............................................................................................................A7
1.4.2 Comissioning...............................................................................................................A7
B Operation ..............................................................................................................B1
1.1 Overview, Display, Manipulation .........................................................................B1
1.1.1 Truck overview................................................................................................B1
1.1.2 Control handle .................................................................................................B5
1.1.3 Key switch ......................................................................................................B6
1.1.4 Display instrument...........................................................................................B7
1.2 Truck use and operation ....................................................................................B11
1.2.1Preparation for use..........................................................................................B11
1.2.2 Comissioning.................................................................................................B15
1.2.3 Truck starting ..................................................................................................B16
1.2.4Running, swerving and braking .......................................................................B18
1.2.5Goods picking..................................................................................................B19
1.2.6 Parking the truck securely ..............................................................................B20
1.2.7 Drive directions...............................................................................................B22
1.2.8Loading............................................................................................................B23
1.2.9 Using the truck on a slope..............................................................................B24
1.2.10 Truck transport..............................................................................................B25
1.2.11 Operating the truck without its own drive system ........................................B26
C Battery use and maintenance ...............................................................................C1
1.1 Battery charging ................................................................................................C1
1.1.1Precautions.......................................................................................................C1
1.1.2Charging the battery with internal charger........................................................C1
1.1.3 Charging the battery with external charger......................................................C5
1.1.4 Battery type & dimensions&Charging time......................................................C6
1.1.5 Battery connector pins maintenance ...............................................................C7
1.2 Battery removal and installation ........................................................................C10
D Maintenance .........................................................................................................D1
1.1 Truck maintenance .............................................................................................D1
1.2 Maintenance table ..............................................................................................D3
1.2.1 Check the electrical fuses................................................................................D5
1.2.2 Recomissioning ...............................................................................................D5
1.2.3 Final decommissioning, disposal.....................................................................D5
1.2.4 Tire replacement..............................................................................................D5
E Technical data .......................................................................................................E1
F Lithium-ion battery.................................................................................................F1

1 Information on the conformity of lithium-ion batteries............................................F2
2 It is necessary to respect the following guidelines:................................................F2
3 Intended use..........................................................................................................F3
4 Reasonably foreseeable misuse ...........................................................................F3
5.Accessories ...........................................................................................................F3
6.BMS (Battery Management System).....................................................................F3
7 Safety and warning................................................................................................F4
8 Hazard of faulty or discarded battery .........................................................................F5
9 Transportation........................................................................................................F5
9.1 Shipping faulty batteries .....................................................................................F5
10 Instructions for disposal.......................................................................................F7
11 Charging ..............................................................................................................F8
12 Storage................................................................................................................F9
13 Common Problems and Solutions.......................................................................F9
Table of contents Pg.

REV. 09/2020
A1
Have the nameplates of a truck xed its main body and alarming labels pasted on its outer
cover.
Should any nameplate or alarming label lose or be damaged, please conduct replacement
immediately or contact with the sales department or corresponding agent of our company when
necessary.
Such truck-related information as product model, serial number, manufacturing date, rated
load lifting capacity, lifting height, load centre distance and dead weight are all shown in the
nameplates.
1.1 Nameplates and alarming labels
Introduction
A
Instructions label
Anti-pinch label Do not rest on the pallet label Lithium sign label
Battery nameplate

REV. 09/2020 A2
EPL151
Hoisting
Personnelmustnotstandbelowornearthetruckwhenthepallettruckisbeinglifted.
Onlyuseliftinggearwithsucientcapacity(fortruckweightseetrucknameplate).
When hoisting or laying down, it should be stable and slow to avoid collision or
accident.
DANGER
Nameplate
2
3
4
13
5
9
8
10
11
14
12
15
Item Description
1 PRODUCT NAME
2MODEL TYPE
3 SERIAL NO.
4 MANUFACTURE DATE
5 LIFT HEIGHT
6 UNLADEN MASS
7UNLADEN MASS WITHOUT
BATTERY
8 BATTERY VOLTAGE
9 RATED DRIVE POWER
10 MAX BATTERY WEIGHT
11 MIN BATTERY WEIGHT
12 RATED CAPACITY
13 LOAD CENTER
14 UNLADEN MASS WITHOUT
BATTERY
15 UNLADEN MASS WITH
BATTERY
1
2
3
4
5
6
7
8
9
10
11
12
13
Park the truck securely as described chapter B Section1.2.6
Secure the lifting slings to the strap point, and prevent them from slipping. Crane slings
should be fastened in such a way that they do not come into contact with any attachments
when lifting.
Load the truck and park it securely at its destination.

REV. 09/2020
A3
WPL201
HPL152 EPL154、EPL185

REV. 09/2020 A4
1.2 Utilization safety specication
Don’t use the truck in
rainwater.
Don’t use the truck in non-
position.
• Average ambient temperature
for continuous duty: ＋25℃;
• Maximum ambient
temperature, short term (up to
1h): ＋40℃;
• Lowest ambient temperature
for trucks intended for use
in normal indoor conditions:
＋5℃; Lowest ambient
temperature for trucks intended
for use in normal outdoor
conditions: －20℃;
• Best operating temperature
range: 15℃~`35℃;
• Charging temperature range:
5℃~40℃,No charging below
0℃.
i
NOTE
i
NOTE
Special equipment and authorisation are required if the truck is to be constantly used in
conditionsofextremetemperatureorairhumidityuctuations.Werecommendwithspecial
measuresforthetruckorbuythetruckforcoldstore.Ifindoubt,contactthemanufacturer's
customerservicedepartment.
Lithium battery charging temperature range: 5~40℃, 0℃below the low-temperature
environment under the conditions of large-scale charging will cause damage to the battery;
Discharge temperature range: -20℃~55℃,lowtemperature(-20℃~0℃)dischargecapacity
than at room temperature may be reduced compared to normal, it is normal; battery can be
40℃~55℃Ambient temperature, but the battery ambient temperature is too high, especially
in the long-term high temperature battery environment, will accelerate the aging of the battery
material,shortenthebatterylife,itisnotrecommendedforlong-termuseatthistemperature.
Ambient temperature exceeding the above range of charge and discharge temperature may
adverselyaectthebatteryperformanceordamage,maygreatlyshortenthebatterylife,it
shouldbeavoidedattheabovetemperature.

REV. 09/2020
A5
Avoid the use of the truck by non-
working personnel.
Don’t ride on the truck.
Don’t carry or lift people by the
truck.
Don’t use the truck on slippery
road surfaces.
(such as road surfaces with oil
stain or residual snow or those
frozen ones )
Don’t carry goods on steep
slope to prevent goods
from sliding o󰀨.
Conditionsofoperationroadsurface:thetruckshouldrunonsolid,at,levelandpavedroad
surfaces(includingbothrunningandlifting)
i
NOTE
Improper use
CAUTION
Whenworkingenvironmentisnotenoughlight,pleaseaddextralightingoftheworkingarea.
Don’t place any part of
your body in any moving
part of the truck to avoid
being clamped.
Don’t leave the truck before
it is parked as regulated.
Don’t use the truck when any
non-working personnel is in the
dangerous area.
Don’t be distracted when using the
truck.
Don’t be distracted when using the
truck.

REV. 09/2020 A6
• Only trained and authorized operator shall be permitted to operate the truck.
• Operator must wear helmet, working shoes and uniform
• Do wash the inner of the truck, do not place the truck outdoors and exposed to the rain.
• Fire extinguisher shall be equipped at the work site. Users can choose truck equipped with
re extinguisher. Driver and manger should be familiar with the re extinguisher position and
application method.
• Whenever you nd the forklift abnormal, stop the truck, put on the DANGEROUS or FAULT sign
to the truck, remove the key, and report to the managing person. Only after eliminating the fault
can you use the truck.
• The controller equips with energy accumulator, do not touch between B+
and B- to avoid electric injury. If you need check or clean the controller, connect load(like
contactor coil or horn or bulb or resistance) between controller B+ and B- to discharge the
controller capacity.
Only trained and authorized operator shall be permitted to operate the truck.
• Do not use truck under the weather of sand, snow, thunder, storm, typhoon, etc.
Avoid using the truck when the wind speed is larger than 5m/s.
• Cause the wheels of pallet truck is small, it is not allowed to run on the street, and only for
driving in specied stacking place.
• When handling bulky loads, which restrict your vision, please operate the
machine in reverse or have a guide.
• Do not drive the truck when the forks in high position.
• Goods are not allowed to deviate the fork center, when goods is deviating the fork center, turn
or pass uneven road, you are easily to fall. Meanwhile, possibility of turnover will increase.
• Wipe o󰀨 the oil, grease or water on the soleplate, foot pedal and control lever.
Safety Instructions
Stability
Stability is guaranteed if your truck is used properly in accordance with its intended
purpose. Common reasons for a loss of truck stability include:
• Emergency stops or sharp turns
• Driving with a raised load or a load handling device
• Turning the vehicle around on or driving across a slope
• Driving up or down a slope with the load pointing downhill
• Driving with a wide load
• Carrying a swinging load
• Driving near the edge of a ramp or up steps
• Tilting the mast forward while carrying a
raised load
• Driving on uneven surfaces
• Overloading the truck
• Carrying bulky loads in strong winds
• When carrying liquid, its centre of mass inside the container may shift due to
inertial force (such as when pulling away, braking or turning)

REV. 09/2020
A7
1.3 Related Safety Instruction and Standard(For CE)
1.3.1 EN standards
Continuous sound level: ＜74 dB(A)
according to EN 12053 as stipulated in ISO 4871
The continuous sound level is a value averaged according to standard regulations, taking the
sound pressure level into account when driving, lifting and idling. The sound pressure level is
measured at the ear.
Electromagnetic compatibility (EMC)
The manufacturer confirms compliance with the limit values for electromagnetic emission and
interference immunity as well as testing of static electricity discharge according to EN 12895 and
the references to other standards contained therein.
Electrical or electronic components and their arrangement may only be modied after written
approval by the manufacturer has been obtained.
1.3.2 Conditions for application
Working condition requirements:
– Use in specied rated load.
– Used in specied area as factory, tourist attraction and recreation place.
– Used on the at ground, that is xed and owns enough carrying capacity.
– It is prohibited to pass the bulge or cavity as the small wheel diameter may cause truck tipping
over.
– Used on the road with good vision and equipment use license.
– The truck's maximum operation altitude is up to 2000m.
– Trucks can only be operated in adequately illuminated working areas to avoid injuries. In case
of insu󰀩cient light, an additional lighting equipment is needed to ensure that the driver can see
properly.
If you must travel on an incline, the gradients should be below A% at full load, or below B%
without a load.(For the value of A and B, refer to the Gradability in technical data)

REV. 09/2020 A8
1.3.3 Vibrations
Vibrations to which the hands and arms are exposed
The following value is valid for all truck models:
Specied characteristics for upper limb vibrationspecied characteristics for
upper limb vibrations
vibration characteristics < 2.5 m/s2
Itismandatorytospecifythehand-armvibrations,evenwherethevaluesdonotindicate
anydanger,asinthiscase.
i
NOTE
Thevalueexpressedabovecanbeusedtocompareforklifttrucksofthesamecategory.It
cannotbeusedtodeterminetheoperator'sdailyexposuretovibrationsduringrealoperation
ofthetruck;thesevibrationsdependontheconditionsofuse(oorconditions,methodofuse
etc.)andthereforedailyexposuremustbecalculatedusingdatafromtheplaceof
use.
CAUTION

REV. 09/2020
A9
1.4 Transport and commissiong
1.4.1 Truck transport
•The load weight includes the net
weightofthetruck(includingbattery
weight)andthewoodenpallet.
•The pallet or wooden box should be
large and strong enough to withstand
theweightofthetruck.
• Pay attention to the fork blades
when lifting the truck onto the pallet, to
preventinjuriescausedbytheforks.
Follow the prescribed steps and park
thevehiclecorrectly.
Make sure the forks are aligned with
the pallet, move slowly and stop after
inserting the forks as far into the
palletaspossible.
Operate on open, level ground and pay
attention to ground conditions when
lifting and lowering the pallet to prevent
thetruckfromtipping.
When transporting the truck, make
sure it is fully secured and take
precautionary measures against bad
weather.
•Place the truck on a wooden pallet.
Only use haulage equipment with
sufcient loadcapacity.
CAUTION
i
NOTE
•Fix the truck to the pallet to prevent
loosening.

REV. 09/2020 A10
The truck must only be operated on battery current!
To prepare the truck for operation after delivery or transportation, the following operations must be
performed:
Check the equipment for completeness.
If necessary, install the battery. Make sure that the battery cable is not damaged.
Fully charge the battery.
Check for Fluid Leakage.
Check the brake function.
Check the lifting and lowering function.
Check the driving function.
Check the steering function.
The truck can now be started, see 1.2.3 Truck starting chapter B
Thetruckmustonlybeoperatedwithalithium-ionbattery.
1.4.2 Comissioning
WARNING
Wheel attening
If the truck has been parked for a long period, the wheel surfaces may tend to
atten. This attening has a negative e󰀨ect on the safety and stability of the truck.
Once the truck has covered a certain distance, the attening will disappear.
Ifthetruckisdeliveredinmultipleparts,setupandcommissioningmustonlybeperformedby
trained,authorisedpersonnel.
i
NOTE

REV. 09/2020
B1
Operation
B1.1 Overview, Display, Manipulation
1.1.1 Truck overview
1 Control Handle
2 Key switch
3 hydraulic unit
4 Drive wheel
5 Caster
6Charger(optional)
7 Batttery
8 Load wheels
9 Forks
10 Emergency stop switch
1
2
3
4
5
6
7
8
9
10
EPL151

REV. 09/2020 B2
1 Control Handle
2 hydraulic unit
3 Drive wheel
4 Load wheels
5 Forks
6 Batttery
7 Emergency stop switch
1
2
3
5
4
7
6
HPL152
